Yamaha CDR-HD1300, CDR-HD1300E Owner Manual

CDR-HD1300 CDR-HD1300E
HDD/CD Recorder
Enregistreur CD/Disque Dur
REC
TEXT/TIME MODE
TRACK NO.
BOOKMARK
FINALIZE ERASE
COMPLETE
OPTICAL
COAXIAL
ANALOG
MULTI JOG
PUSH ENTER
DIGITAL REC LEVEL
INPUT
ANALOG REC LEVEL
MIN MAX
MENU
CLEAR
OWNER’S MANUAL
MODE D’EMPLOI
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
• Explanation of Graphical Symbols
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
IMPORTANT!
Please record the serial number of this unit in the space below.
Model: Serial No.:
The serial number is located on the rear of the unit. Retain this Owner’s Manual in a safe place for future reference.
1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with dry cloth. 7 Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod,
bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning
storms or when unused for long periods of time.
14 Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
FCC INFORMATION (for US customers)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.
2. IMPORTANT: When connecting this product to
accessories and/or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.
3. NOTE: This product has been tested and found to comply
with the requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices.
This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices.
Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:
Relocate either this product or the device that is being affected by the interference.
Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA 90620.
The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.
We Want You Listening For A Lifetime
YAMAHA and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.
CAUTION: READ THIS BEFORE OPERATING THIS UNIT
• To assure the finest performance, please read this manual carefully. Keep it in a safe place for future reference.
• Install this unit in a well ventilated, cool, dry, clean place – away from direct sunlight, heat sources, vibration, dust, moisture, and/ or cold. Avoid ventilation space of at least 30 cm on the top, 20 cm on the left and right, and 10 cm on the back of this unit.
• Locate this unit away from other electrical appliances, motors, or transformers to avoid humming sounds.
• Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit in a environment with high humidity (i.e. a room with a humidifier) to prevent condensation inside this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury.
• Avoid installing this unit where foreign object may fall onto this unit and/or this unit may be exposed to liquid dripping or splashing. On the top of this unit, do NOT place:
• Other components, as they may cause damage and/or discoloration on the surface of this unit.
• Burning objects (i.e. candles), as they may cause fire, damage to this unit, and/or personal injury.
• Containers with liquid in them, as they may fall and liquid may electrical shock to the user and/or damage to this unit.
• Do not cover the rear panel of this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radiation. If the temperature inside this unit rises, it may cause fire, damage to this unit, and/or personal injury.
• Do not plug in this unit to a wall outlet until all connections are complete.
• Do not operate this unit upside-down. It may overheat, possibly causing damage.
• Do not use force on switches, knobs and/or cords.
• When disconnecting the power cord from the wall outlet, grasp the plug; do not pull the cord.
• Do not clean this unit with chemical solvents; this might damage the finish. Use a clean, dry cloth.
• Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit, and/or personal injury. YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than specified.
• To prevent damage by lightning, disconnect the power cord from the wall outlet during an electrical storm.
• Do not attempt to modify or fix this unit. Contact qualified YAMAHA service personnel when any service is needed. The cabinet should never be opened for any reasons.
• When not planning to use this unit for long periods of time (i.e. vacation), disconnect the AC power plug from the wall outlet.
• Be sure to read the “TROUBLESHOOTING” section on common operating errors before concluding that this unit is faulty.
• Before moving this unit, first check that there is no disc in the disc tray. Finally, press POWER to turn off this unit, and disconnect the AC power plug from the wall outlet.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
Laser component in this product is capable of emitting radiation exceeding the limit for Class 1.
SPECIAL INSTRUCTIONS FOR U.K. MODEL
IMPORTANT
The wires in this mains lead are coloures in accordance with the following code:
GREEN-and-YELLOW:Earth BLUE:Neutral BROWN:Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: The wire which is coloured GREEN-and-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol or coloured GREEN or GREEN-and ­YELLOW. The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
For U.K. customers
If the socket outlets in the home are not suitable for the plug supplied with this appliance, it should be cut off and an appropriate 3 pin plug fitted. For details, refer to the instructions described above.
Note: The plug severed from the mains lead must be destroyed, as a plug with bared flexible cord is hazardous if engaged in a live socket outlet.
For Canadian Customers
To prevent electric shock, match wide blade of plug to wide slot and fully insert. This Class B digital apparatus complies with Canadian ICES–
003.
i
Hard Disk Drive (HDD)
Before using
• If you purchase CDR-HD1300; this model is not equipped with a hard disk drive (HDD). Please purchase a commercially available HDD for internal use and install it on this unit correctly, following the attached instruction.
• It is necessary to format a new HDD after installation. Also refer the attached instruction for formatting.
• If you purchase CDR-HD1300E; this model is equipped with an HDD.
Capacity of the HDD
Following table shows the total recordable time for different capacities of an HDD.
Capacity
20 GB
40 GB
60 GB
80 GB
Total recordable time
Approx. 30 hours
Approx. 60 hours
Approx. 90 hours
Approx. 120 hours
Handling of the HDD
• The HDD formatted on your CDR-HD1300 cannot be used on other CDR-HD1300s for any reading or writing. If you wish to use the HDD that has been formatted on other CDR-HD1300 on yours, format it again on your CDR-HD1300. See page 85 for formatting.
• Carefully handle an HDD before installation because it is a precision device. Also do not give vibration or shock to this unit after the HDD is installed. Incorrect operation can damage the HDD and/or the data written onto the HDD.
• Yamaha and suppliers accept no liability for the loss and/or damage of data caused by vibration and/or shock.
CD player mode
This unit does not make any recordings if no HDD is installed. In this case, only reading of a CD, CD-R, and CD-RW disc is possible. Permit some time until this unit becomes ready after the power is turned if no HDD is installed.
ii
English
About This Manual
Structure
This owner’s manual is composed of following sections.
GETTING STARTED
This section explains necessary preparations such as remote control and connection. Please read this before using this unit.
COPYING AND RECORDING ONTO THE HDD
This section describes basic operations; copying from a CD to the HDD and recording from an external component connected to this unit to the HDD. Additional functions and operations are explained in “Advanced Operations” following this basic operation. Skip this part, if you wish to try to use all the basic functions equipped on this unit.
EDITING
This section describes how to edit the data copied and/or written on the HDD. Editing method is explained for “album”, “track”, and “disc” respectively. See “EDITING MENU ITEMS” for outline of the editing menu.
COPYING AND RECORDING ONTO A CD-R OR CD-RW DISC
This section describes basic operations; copying from the HDD to a CD-R or CD-RW and recording from an external component connected to this unit to a CD-R or CD-RW. Additional functions and operations are explained in “Advanced Operations” following these basic operations. Skip this part, if you wish to try to use all the basic functions equipped on this unit.
DUPLICATION OF A CD
This section describes how to duplicate a whole CD.
PLAYBACK
This section describes how to play the data copied/written on the HDD, your original CDs that are made using this unit, or commer­cially available CDs.
APPENDIX
This section provides you with the information about system setting of this unit and troubleshooting.
About this manual
• This manual is printed prior to production. Design and specifica­tions are subject to change in part for the reason of the improve­ment in operativity ability, and others. In this case, the product has priority.
• Some of the illustrations and names of the package contents etc written in this manual may differ from the actual products and the names written on the package etc.
Features
• Copying a CD to the HDD at maximum 10x speed
• Copying data on the HDD to a CD-R disc at maximum 8x speed
• Copying data on the HDD to a CD-RW disc at maximum 4x speed
• High quality recording by the Audio Master Quality Recording (copying from the HDD to a CD-R only)
• Long-hour-recording useful for recording satellite broadcasting programs and timer recording using an external timer
iii
Contents

GETTING STARTED

SUPPLIED ACCESSORIES ............................................ 2
CD/CD-R/CD-RW COMPATIBLE WITH THIS UNIT ........ 3
RULES OF DIGITAL RECORDING AND NOTES ON
SYSTEM ...................................................................... 5
Rules of Digital Recording .................................................... 5
Notes on System .................................................................... 5
Data on the HDD ................................................................... 6
NAMES OF BUTTONS AND CONTROLS ...................... 7
Front Panel ............................................................................. 7
Remote Control ..................................................................... 8
Display ................................................................................. 10
Display Information ............................................................. 11
Rear Panel ............................................................................ 12
CONNECTIONS ............................................................ 12
COPYING AND RECORDING ONTO THE HDD
COPYING FROM A CD ONTO THE HDD ..................... 14
Copying All Tracks on a CD ............................................... 14
Copying Favorite Tracks on the CD .................................... 16
Advanced Operations .......................................................... 17
RECORDING FROM AN EXTERNAL COMPONENT
ONTO THE HDD ........................................................ 20
Recording from the Digital Components ............................ 20
Recording from the Analog Components ............................ 21
Recording Using an External Timer .................................... 22
Adjusting the Recording Level ............................................ 24
Advanced Operations .......................................................... 25
EDITING
EDITING MENU ITEMS ................................................. 29
ALBUM EDITING .......................................................... 30
Album Editing Operation .................................................... 30
TRACK EDITING ........................................................... 39
Track Editing Operation ...................................................... 39
DISC EDITING ............................................................... 52
Disc Editing Operation ........................................................ 52
UNDO FUNCTION ......................................................... 58
BOOKMARK ................................................................. 59
DUPLICATION OF A CD
DUPLICATION OF A CD ............................................... 72
High Quality Duplication .................................................... 74
PLAYBACK
PLAYBACK.................................................................... 76
Playing a CD ........................................................................ 76
Playing Tracks on the HDD................................................. 76
Finding the Desired Passage (Search) ................................. 77
Finding the Desired Group (Group Skip) ............................ 77
Finding the Desired Track (Track Skip) .............................. 78
Selecting Tracks Using On-Screen-Display (OSD) ............ 79
Listening with Headphones ................................................. 79
VARIOUS PLAYBACK .................................................. 80
Finding the Desired Passage by Time (Time Search) .......... 80
Setting the Play Style ........................................................... 80
Single Repeat Play ............................................................... 81
Full Repeat Play .................................................................. 82
Random Play ....................................................................... 82
Intro Play ............................................................................. 83
Bookmark Play .................................................................... 83
APPENDIX
DAC (DIGITAL/ANALOG CONVERTER) MODE .......... 84
HDD UTILITY ................................................................. 85
SYSTEM UTILITY .......................................................... 86
ON-SCREEN DISPLAY (OSD) ...................................... 89
DISPLAY MESSAGES................................................... 90
TROUBLESHOOTING................................................... 92
ABOUT PRODUCT INFORMATIONS ........................... 93
SPECIFICATIONS ......................................................... 94
COPYING AND RECORDING ONTO A CD-R OR CD-RW DISC
COPYING FROM THE HDD ONTO A CD-R OR CD-RW
DISC ........................................................................... 60
Copying a Whole Group (Disc, Album or Bookmark) ........ 60
Copying Favorite Tracks on the HDD ................................. 62
High Quality Copying ......................................................... 63
Advanced Operations .......................................................... 64
RECORDING FROM AN EXTERNAL COMPONENT
ONTO A CD-R OR CD-RW DISC .............................. 67
Advanced Operations .......................................................... 69
FINALIZATION .............................................................. 70
ERASING A CD-RW DISC ............................................ 71
English
E-1

SUPPLIED ACCESSORIES

Make sure the following items are included in your package.
Remote Control Batteries (size AA, UM-3, or R6) (2)
OPEN/CLOSE
COPY REC
TIMER REC
A.M.Q.R.
FINALIZE
ERASE
INPUT
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
0+10
SPACE
SYMBOL
REPEAT RANDOM
GROUP SKIP
TRACK NO.
WRITE
ENTER
BOOKMARK
INTRO
TEXT/TIME
COMPLETE
HDD CDR
Audio Pin Cables (2)
Optical Cable
Video Pin Cable
Power Cable (for U.S.A. model)
Coaxial Cable (for U.S.A. model)
E-2

CD/CD-R/CD-RW COMPATIBLE WITH THIS UNIT

Discs that can be used for recording on this unit
Be sure to use only CD-R and CD-RW discs made by reliable manufacturers. CD-R and CD-RW digital audio discs that display either of the following marks can be used with this unit.
FOR CONSUMER FOR CONSUMER USE FOR MUSIC USE ONLY
Discs that can be used for recording
CD-R discs can only be recorded on once, and the recorded
material cannot be erased.
CD-RW discs can be recorded on, have the recorded material
erased, and then recorded on again any number of times.
Discs that cannot be used for recording on this unit
Discs bearing marks other than those shown above.
Discs intended for recording computer data.
Discs intended for professional use or labeled FOR PROFES-
SIONAL USE ONLY”.
79-minute CD-R disc
The actual recordable time of the CD-R disc with “80” written on its package is 79 minutes 57 seconds. This manual describes such CD-R disc as 79-minute CD-R disc”.
Finalization of CD-R/CD-RW discs
To play back CD-R discs on a standard CD player and CD-RW discs on CD-RW-compatible players, you need to perform the process known as “finalization”. In the finalization process, the Table of Contents (TOC) is written onto the discs.
Finalized CD-R discs
CD-R discs can be played on a standard CD player.
Further recording onto CD-R discs is not possible.
Some CD players may not play back the finalized CD-R discs
properly due to differences in the playback system of different manufacturers.
Finalized CD-RW discs
CD-RW discs cannot be played on a standard CD player. CD-RW
discs can be played back on CD-RW-compatible players such as this unit.
Tracks written on CD-RW discs can be erased, and additional
tracks can be recorded after the TOC has been erased.
Discs that can be played back
In addition to CD-R and CD-RW digital audio discs described above, commercially available pre-recorded CDs bearing the marks shown below can also be played on this unit.
Caution
If you use the CDs that do not meet the CD standards, this unit may not operate properly.
Playback of the CD-R disc copied with the
Audio Master Quality Recording mode
The Audio Master Quality Recording mode enables you to create a CD with high quality sounds by increasing the linear velocity when copying. The CD-R discs copied with this mode meet the CD standards and can be played on a standard CD player. However, some CD recorders may not play back these CD-R discs properly.
Playback on DVD players
Before playing back a finalized CD-R or CD-RW discs on a DVD player, please check whether the DVD player is compatible with CD-R or CD-RW discs or not. Refer to the owner’s manual of the DVD player for more information. CD-R or CD-RW discs cannot be played on a DVD player that is not compatible with CD-R or CD-RW discs.
IMPORTANT
Please check the copyright laws in your country to record from
records, CDs, radio, etc. Recording of copyright material may infringe copyright laws.
GETTING STARTED
Erasure or loss of data
Yamaha and suppliers accept no liability for the loss of data written on the HDD and CD-R or CD-RW discs, or any problems caused as a result of using this unit. As a precaution, it is recommended that the discs are tested after they have been recorded on. Furthermore, under no circumstances do Yamaha and suppliers guarantee the reliability of the discs.
English
E-3
CD/CD-R/CD-RW COMPATIBLE WITH THIS UNIT
Handling of discs
Heed the following notes on handling of discs not to create any cause for a recording failure, a loss of the recorded data, or a malfunction of this unit.
This compact disc recorder is designed for use with CDs (including 8cm [3] discs) bearing the , , , or marks only. Never attempt to load any other type of disc into this unit.
CDs are not subjected to wear during play. However if the disc is handled improperly, damage may be created on the disc to adversely affect the disc’s play.
When writing on the label side of CD-R or CD-RW discs, use an oil-based felt-tipped pen.
Do not use cleaning discs or warped discs. All of these could damage this unit.
Although playback of CDs is generally not affected by small particles of dust or fingerprints on their playing surface, dust, fingerprints, small scratches and direct sunlight on the recording surface of a CD-R or CD-RW disc may make recording impos­sible. Therefore, for optimal performance of the recorder and for long-term enjoyment of your CD collection, handle discs correctly as outlined in the following guidelines.
1. Hold discs by touching only the edges or center hole.
2. When a disc is not currently being used, remove it from the
recorder and store in an appropriate case.
3. With proper disc maintenance, cleaning should not be
necessary. However, should cleaning be required, wipe by using a clean, dry cloth. Do not wipe with a circular motion; wipe straight outward from the center.
To prevent a malfunction of this unit
Do not use any non-standard shaped CDs (heart, flower shaped, etc.) available on the market, because they are off-balance in their weight. If a non-standard shaped CD is loaded into this unit, it may create problems such as improper playback, opening the disc tray, creating an usual noise, and this units failure.
Be sure to use a felt-tip pen or similar writing tool when writing on the label side of the disc. Do not use a ball-point pen, pencil, or other hard-tipped writing tool, as these may damage the disc and may adversely affect further recording on the disc.
Do not use the discs with glue left on their surface. It may get stuck in this unit or create damage to this unit.
When using an 8cm (3) disc, do not place a normal 12cm (5) disc on top of it.
Do not use the discs printed with commercially available label printers.
Do not try to clean the discs surface by using any type of disc cleaner, record spray, antistatic spray or liquid, or any other chemical-based liquid, because such substances might irreparably damage the discs surface.
Do not expose discs to direct sunlight, high temperature, or high humidity for a long period of time, because this might warp or otherwise damage the disc.
No!
E-4

RULES OF DIGITAL RECORDING AND NOTES ON SYSTEM

Rules of Digital Recording
SCMS—Serial Copy Management System
As a digital audio component, this unit conforms with the Serial Copy Management System (SCMS) standards. The Serial Copy Management System restricts copies made by recording digital signals to first-generation copies only. The digital program sources that have been recorded cannot be digitally recorded again. There are 2 rules as follows:
Rule 1
Digital sources such as commercially available CDs can be copied digitally onto other recordable digital media with this unit (a first­generation digital copy). However, the first-generation digital copy cannot be copied digitally any further.
Rule 2
The source that was recorded via the ANALOG LINE IN (REC) jacks can be copied digitally onto other recordable digital media (a first-generation digital copy). However, the first-generation digital copy cannot be copied digitally any further.
This unit monitors the SCMS status for each track when a digital recording is made. If the track is protected from digital recording and copying, it is not possible to make a digital recording and copy of that track. The SCMS standard does not apply to analog recording and copying.
When making a copy from a CD onto the HDD, or from the HDD onto a CD-R or CD-RW disc, any of the copy methods described below can be selected. The following selections are contained in
Copy Method”.
•“Auto Dig/Anlg”:
Automatically switches to analog recording if the track cannot be digitally recorded for SCMS.
•“Digital Copy”: Performs digital copying of only those tracks that can be digitally copied.
•“Digital Move”: Performs digital copying of the tracks that cannot be digitally copied by “Digital Copy” when copying from the HDD onto a CD-R or CD-RW disc.
•“Analog Copy”: Performs analog copying regardless of the SCMS standard.
Digital Move
This unit has a built-in HDD with large space that makes a long recording possible. You can create your own CD by editing the various program sources that have been recorded onto the HDD of this unit and copying them onto a CD-R or CD-RW disc. If you want to make a digital copy of the original data that has been created on the HDD to a CD-R or CD-RW disc, the Digital Move method is convenient. You can make a digital copy from the HDD onto a CD-R or CD-RW disc even if the track is protected from making a second-generation copy by the SCMS standard. However, since the concept of Digital Move is that the data is moved from the HDD onto a CD-R or CD-RW disc, the original data on the HDD is erased when moving is complete. See page 65 for details.
Notes on System
Number of recordable discs and tracks and their length
One CD-R or CD-RW disc, or one disc on the HDD can be
recorded with up to 99 tracks on them.
Once 99 tracks have been recorded, no further recording is
possible even if space for recording is available on the disc.
The minimum length of one track must be 4 seconds. If a
recording is stopped while the track is less than 4 seconds long, this unit will record for 4 seconds, and then stop recording. The maximum length of one track is 99 minutes 59 seconds for the HDD.
999 discs can be created at maximum on the HDD of this unit.
However, the number of discs that can be created is limited according to the space availability (total recordable time) on the HDD.
The maximum length of one disc on the HDD is 99 minutes 59
seconds. However, since each track on the HDD is handled in the unit of frame (75 frames are equal to one second), the maximum length of one track or disc may vary slightly.
When recording on a CD-R or CD-RW disc, 2-second silence will
be automatically added to the beginning of the first track. Therefore the actual total recordable time will be 2 seconds shorter than the total recordable time of a CD-R or CD-RW disc.
Source sampling rate conversion
Digital input of this unit supports sampling frequencies of 32kHz,
44.1kHz, 48kHz, and 96kHz. This unit converts these inputs to the 44.1kHz,16-bit digital signals and records them onto the HDD, or a CD-R or CD-RW disc.
Analog input is also converted to the same digital signal to be
recorded.
This unit outputs the signals at the sampling frequency of
44.1kHz, 16-bit from its digital output.
Recording of non-audio signals
This unit is designed exclusively for recording audio signals.
Recording is only possible for audio signals.
When a CD with CD TEXT is copied onto the HDD, CD TEXT
will be automatically copied if it is not copy protected. When a CD with CD TEXT is recorded from an external CD player, CD TEXT cannot be copied even if it is not copy protected. To copy CD TEXT, use the built-in CDR drive of this unit.
If the digital signals contain graphic data such as CD graphics, the
non-audio signals will not be recorded.
It is not possible to record from non-audio sources such as CD-
ROM or DVD.
Data processing
A small amount of space may be used for data processing besides
recording the actual program sources.
Although this unit is capable of recording 999 albums at
maximum onto the HDD, the data processing speed may slow down if a large number of albums is created.
GETTING STARTED
English
E-5
RULES OF DIGITAL RECORDING AND NOTES ON SYSTEM
Disc
1 1 2 2
Track
1 2 2 3
Disc
1 2 1
999
2
Track
1 2 3 3
99
Data on the HDD
The data recorded onto the built-in HDD of this unit will be numbered and organized based on the following concept:
Disc
One consequent recording is counted and numbered as one unit of disc. The HDD of this unit can record 999 discs at maximum. (However, the number of discs to be created may be less than 999 for the space availability on the HDD.) The maximum length of one disc on the HDD is 99minutes 59 seconds.
Track
99 tracks can be recorded onto a disc at maximum. (However the number of discs tracks to be recorded may be less than 99 for the space availability on the HDD.) One track must be 4 seconds at shortest and 99 minutes 59 seconds at longest.
Album
A group of the source programs selected from different discs and recorded as the playlist is called “album”. “Album corresponds to the program function (to play back favorite tracks in the desired order) of a standard CD player. This unit can record 999 albums at maximum onto the HDD.
Disc Track Bookmark Album
Bookmark
This unit can make a temporary bookmark on a favorite track as playing back. The list of the program sources marked is called bookmark. This marking is temporary and cannot be duplicated. However, an album can be easily created by copying the bookmarked tracks. See page 32 for details.
Group
A collection of disc(s), album(s), and a bookmark are generically called group.
Disc 1
Disc 2
Disc 999
Track 1
Track 2
Track 3
Track 99
Track 1
Track 2
Track 3
Track 99
Track 1
Track 2
Track 3
Track 99
Example of the playlist
Example of the copied tracks
with bookmarks
* The tracks are listed in the
order of copying.
E-6
Front Panel
1

NAMES OF BUTTONS AND CONTROLS

GETTING STARTED
23 4 5 6 7890q wer
NATURAL SOUND HDD/CD RECORDER
POWER
COPY
CDRHDD
LEVELPHONES
MIN MAX
ty
A.M.Q.R.
uiopasdfgh
1 POWER 2 HDD 3 CDR 4 COPY 5 Front panel display 6 Disc tray 7 v (Open/Close) 8 TRACK NO./BOOKMARK 9 TEXT/TIME 0 COMPLETE q MODE w MULTI JOG knob/DIGITAL REC LEVEL control e MENU
TEXT/TIME MODE
TRACK NO.
COMPLETE
BOOKMARK
FINALIZE ERASE
REC
r CLEAR t PHONES jack y PHONES LEVEL control u A.M.Q.R. i REC o t/e (Skip/Search) p FINALIZE a ERASE s r/y (Search/Skip) d INPUT f w/d (Play/Pause) g ANALOG REC LEVEL control h a (Stop)
DIGITAL REC LEVEL
INPUT
OPTICAL
COAXIAL
ANALOG
MULTI JOG
PUSH ENTER
ANALOG REC LEVEL
MIN MAX
MENU
CLEAR
E-7
English
NAMES OF BUTTONS AND CONTROLS
Remote Control
1
2 3 4 5 6
7
8
9
0
q w e
r t y
u
OPEN/CLOSE
TIMER REC
COPY REC
A.M.Q.R.
FINALIZE
ERASE
INPUT
SYMBOL
GROUP SKIP
TRACK NO.
WRITE
ENTER
BOOKMARK
INTRO
TEXT/TIME
MODE MENU
COMPLETE
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
0+10
SPACE
REPEAT RANDOM
HDD CDR
i
o
p a s
d
f
g
h
j
k
l ; z x
1 OPEN/CLOSE 2 COPY 3 TIMER REC 4 A.M.Q.R. 5 FINALIZE 6 TEXT/TIME 7 MODE 8 COMPLETE 9 CLEAR 0 Alphabetical/numeric buttons q REPEAT w RANDOM e GROUP SKIP q r t (Track Skip) t d (Pause) y e (Search) u HDD i REC o ERASE p TRACK NO. WRITE a INPUT s MENU d +/– f ENTER g BOOKMARK h INTRO j GROUP SKIP w k y (Track Skip) l r (Search) ; w (Play) z CDR x a (Stop)
E-8
NAMES OF BUTTONS AND CONTROLS
Loading the batteries in the remote control
1. Remove the battery compartment cover on the back
of the remote control.
2. Insert 2 batteries (AA, UM-3 or R6 type) according to
the polarity markings on the inside of the battery compartment.
3. Close the cover until it snaps into place.
1
3
2
Battery replacement
If you find that the remote control must be used closer to this unit than usual, the batteries are weak. Replace both batteries with new ones.
Notes on batteries
Use only AA, UM-3, or R6 type batteries for replacement.
Do not mix a new battery with a used one.
A rechargeable battery cannot be used.
Do not mix different types of battery.
Do not attempt to short out the batteries by directly connecting the plus (+) and the minus () with a piece of metal.
Remove the batteries if the remote control will not be used for an
extended period of time.
If batteries leak, dispose of them immediately. Clean the battery compartment thoroughly before installing new batteries.
Remote control operation range
NATURAL SOUND HDD/CD RECORDER
POWER
COPY
CDRHDD
LEVELPHONES
MIN MAX
A.M.Q.R.
Remote control sensor
Within 6m (20’)
30°
30°
Cautions
If operation of this unit by the remote control creates any malfunction in any other components, change the placement of the component.
Do not spill any liquid on or drop the remote control. Do not place it near a heater or in the bathroom where the temperature and humidity become high.
Make sure the remote control sensor is not exposed to direct sunlight or strong lights. If it is, it may not function correctly.
MULTI JOG
PUSH ENTER
TEXT/TIME MODE
TRACK NO.
BOOKMARK
FINALIZE ERASE
REC
MENU
COMPLETE
CLEAR
DIGITAL REC LEVEL
ANALOG REC LEVEL
INPUT
OPTICAL
COAXIAL
ANALOG
MIN MAX
GETTING STARTED
E-9
English
NAMES OF BUTTONS AND CONTROLS
Display
1
23 4 5
8888888888888
TOTAL
ALBM MARK
S G A REP
8 r9 0
1 HDD mark 2 TOTAL indicator 3 DUPLCT indicator 4 A.M.Q.R. indicator 5 Information display 6 CDR mark 7 REC indicator 8 ALBM indicator 9 MARK indicator 0 Playback mode/play style indicator
S indicator
G indicator
A indicator
REP indicator
RNDM indicator
DUPLCT
A.M.Q.R. AUTO PRD DIG M
MULTRNDM ALL SYNC ANLG
qw
q Recording/copying mode indicator
w Copying method indicator
e Level meter r TOC indicator t CD-RW indicator y MULTI JOG status indicator
L
dB –30 –10 –6 –2 0
R
e t y
AUTO indicator
PRD indicator
MULT indicator
ALL indicator
SYNC indicator
DIG indicator
M indicator
ANLG indicator
LEVEL indicator
TRACK indicator
GROUP indicator
TIME indicator
67
REC
LEVEL
TRACK
TOC GROUP
CDR W
TIME
E-10
Display Information
NAMES OF BUTTONS AND CONTROLS
The display located in the center of this unit provides the information about the drive (HDD or CDR drive) selected. Each time TEXT/TIME is pressed, the display changes according to the operation.
Display while playing the data on the HDD
Group number, track number and elapsed time of the
Display while playing a CD
Track number and elapsed time of the track being played
track being played
1 004
L
Dsc001 1 004
G
L
dB –30 –10 –6 –20
R
GROUP
dB –30 –10 –6 –20
R
Track number and remaining time of the track being
Group number, track number and remaining time of the
played
track being played
1- 221
L
dB –30 –10 –6 –20
Dsc001 1- 221
G
L
dB –30 –10 –6 –20
R
GROUP
R
Disc total time
Group number and group total time
6545
Dsc001 6545
TOTAL
G
L
dB –30 –10 –6 –20
R
GROUP
TOTAL
L
dB –30 –10 –6 –20
R
Disc remaining time
Group number and group remaining time
-6240
Dsc001 -6240
TOTAL
G
L
dB –30 –10 –6 –20
R
GROUP
TOTAL
L
dB –30 –10 –6 –20
R
CD TEXT (when available)
Group title or track title
Group title
LIVE AT CRANE
G
Track title
PRIDE AND JOY
G
L
dB –30 –10 –6 –20
R
L
dB –30 –10 –6 –20
R
GROUP
TRACK
Disc title
LIVE AT CRANE
L
dB –30 –10 –6 –20
R
Track title
PRIDE AND JOY
L
dB –30 –10 –6 –20
R
The group title with the GROUP indicator and the track title with The group title with the GROUP indicator and the track title with the TRACK indicator are switched by pressing the MULTI JOG
the TRACK indicator are switched by pressing the MULTI JOG
knob. knob.
Display while recording onto a CD-R or CD-
Display while recording onto the HDD
Disc number, track number and elapsed time of the track being recorded
Dsc001 1 004
L
dB –30 –10 –6 –20
R
Disc number and total recorded time on the disc
Dsc001 1543
TOTAL
L
dB –30 –10 –6 –20
R
REC
REC
RW disc
Track number and elapsed time of the track being
recorded
1 004
L
dB –30 –10 –6 –20
R
Total recorded time on a disc
1543
TOTAL
L
dB –30 –10 –6 –20
R
TOC GROUP CD
TOC GROUP CD
TOC GROUP CD
TOC GROUP CD
TOC GROUP CD
TRACK
TOC CD
REC
GROUP
CDRW
REC
GROUP
CDRW
GETTING STARTED
Total recordable time on a disc
TOTAL
- 221
L
dB –30 –10 –6 –20
R
CDRW
REC
GROUP
English
E-11
NAMES OF BUTTONS AND CONTROLS
Rear Panel
12 3
L
L
R
R
REC COAXIAL OPTICAL COAXIAL OPTICAL
PLAY
4 3
LINE IN LINE OUT IN OUT
ANALOG
DIGITAL
VIDEO OUT
S VIDEO
VIDEO
RS–232C
1 HDD slot 2 VIDEO OUT jacks
S VIDEO jack
VIDEO jack
3 AC inlet 4 ANALOG jacks
5 64
5 DIGITAL jacks
DIGITAL IN (COAXIAL) jack
DIGITAL IN (OPTICAL) jack
DIGITAL OUT (COAXIAL) jack
DIGITAL OUT (OPTICAL) jack
6 RS-232C terminal
(U.S.A. model)
ANALOG LINE IN (REC) jacks
ANALOG LINE OUT (PLAY) jacks

CONNECTIONS

Turn off the power of this unit and the other components, and unplug them from the wall outlet before making any connections.
Digital connections
This unit has the DIGITAL OPTICAL jacks and DIGITAL COAXIAL jacks. Connect either the DIGITAL OPTICAL jacks, or the DIGITAL COAXIAL jacks according to the component to be connected.
Using the optical fiber cable, connect the DIGITAL IN (OPTICAL) jack on this unit to the digital optical output jack on the other component, and the DIGITAL OUT (OPTICAL) jack on this unit to the digital optical input jack on the other component.
When using the DIGITAL IN/OUT (COAXIAL) jacks, make connections with coaxial cables. Connect the DIGITAL IN (COAXIAL) jack on this unit to the digital coaxial output jack on the other component, and the DIGITAL OUT (COAXIAL) jack on this unit to the digital coaxial input jack on the other component.
Analog connections
Make sure to connect the L (left) and R (right) input and output jacks on this unit to the correct L (left) and R (right) input and output jacks on the other component.
Connect the ANALOG LINE IN (REC) jack on this unit to the analog output jack on the other component, and the ANALOG LINE OUT (PLAY) jack on this unit to the analog input jack on the other component.
The ANALOG LINE IN (REC)/LINE OUT (PLAY) jacks on this unit are numbered # and $ respectively. Connect these jacks to the jacks with the same numbers when connecting this unit to a Yamaha amplifier or receiver.
To connect the turntable directly to this unit, first connect it to the phono equalizer and then connect to the ANALOG LINE IN (REC) jacks on this unit.
Notes
When you play the data on the HDD or CDs, signals are output both from the ANALOG LINE OUT (PLAY) jack and from the DIGITAL OUT (OPTICAL/COAXIAL) jacks.
Signals that are output through the DIGITAL OUT (OPTICAL) jacks or the DIGITAL OUT (COAXIAL) jacks while playing the data on the HDD do not have information about the track markers. Therefore if these signals are recorded by an MD player, the track markers may not be placed correctly on the recorded MD disc.
E-12
CONNECTIONS
Connecting a monitor
You can display the list of groups or tracks to be played, copying/recording settings or the list of setting items on the monitor by connecting
the monitor to this unit. Connect the S VIDEO jack or the VIDEO jack whichever available on your monitor.
Use a commercially available S-video cable to connect the S VIDEO jack on this unit and the S-video input jack on the monitor.
Use an included video pin cable to connect the VIDEO jack on this unit and the composite video jack on the monitor.
Arrow marks () in the illustration below indicate the direction of the audio signal.
Monitor
DVD player, cable TV tuner, etc
Coaxial cable
DIGITAL
OUTPUT
COAXIAL
(optional)
S VIDEO
VIDEO IN
VIDEO
GETTING STARTED
Audio pin cable (included)
L
R
REC COAXIAL OPTICAL COAXIAL OPTICAL
4 3
LINE IN LINE OUT IN OUT
ANALOG
Audio pin cable
S video cable (optional)
VIDEO OUT
S VIDEO
VIDEO
L
R
PLAY
DIGITAL
RS–232C
*RS-232C terminal
Video pin cable (included)
(U.S.A. model)
(included)
Optical cable (one included)
DIGITAL
INPUT
PLAY
REC
L
R
L
R
IN
OUT
COAXIAL
OPTICAL
OPTICAL
DIGITAL
OUTPUT
**Coaxial cable
To wall outlet
Amplifier or receiver
*This terminal is for connection of the personal computer. Information about the connection software is to be announced on the YAMAHA website (see page 93). **For U.S.A. model, one coaxial cable with ferrite core is included. Be sure to connect to the DIGITAL OUT (COAXIAL) jack with this cable, directing the side with ferrite core to this unit.
Connecting the power cable
Plug the power cable into the AC inlet when all connections are complete, and then plug in the power cable to the wall outlet.
[Europe, U.K. and Australia models]
Plug in this unit to the wall outlet.
English
E-13

COPYING FROM A CD ONTO THE HDD

OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
14 6817
TOC GROUP
CD
L
R
dB –30 –10 –6 –20
Copying All Tracks on a CD
You can copy all tracks on a CD onto the HDD.
2,4
2,4
REC
TEXT/TIME MODE
TRACK NO.
BOOKMARK
FINALIZE ERASE
NATURAL SOUND HDD/CD RECORDER
POWER
LEVELPHONES
MIN MAX
5
COPY
CDRHDD
A.M.Q.R.
3
1
1. Turn on the power of this unit by pressing POWER on
the front panel.
The message “WELCOME TO YAMAHA HDD/CD SYS- TEM appears on the display. After the message is displayed, this unit is ready for operation.
2. Press v (OPEN/CLOSE on the remote control) to
open the disc tray.
3. Load the CD to copy from on the disc tray.
Place a CD correctly aligned in the recessed area of the disc tray with its label side facing up.
COMPLETE
5
MULTI JOG
PUSH ENTER
MENU
CLEAR
DIGITAL REC LEVEL
ANALOG REC LEVEL
INPUT
OPTICAL
COAXIAL
ANALOG
MIN MAX
6
This unit starts reading the information (type and capacity of the CD) when the CD is loaded. It takes approximately 10 to 15 seconds to complete the reading. The following message appears on the display during the reading.
Reading
When reading the information has been completed, the display changes as follows, and this unit becomes ready for operation.
Total number of tracks Total time
L
dB –30 –10 –6 –20
R
6
4. Press v (OPEN/CLOSE on the remote control) to
close the disc tray.
Note
The disc tray can be also closed by pressing the front edge of the disc tray gently. If the disc tray is closed in this way, this unit starts playback of a CD. Press a to stop playback.
E-14
1
L
dB –30 –10 –6 –20
R
TOC GROUP
CD
COPYING FROM A CD ONTO THE HDD
5. Press COPY once.
The following message appears on the display, and this unit enters the copy standby mode. Copying has not been started yet at this stage.
HDD π CD-RW
ALL SYNC
003 1 π 1 000
ALL SYNC
L
DIG
dB –30 –10 –6 –20
R
L
DIG
dB –30 –10 –6 –20
R
REC
TOC GROUP
CD
REC
TOC GROUP
CD
6. Start copying.
Press w/d (w on the remote control) to start copying.
003 1 π 1 001
ALL SYNC
L
DIG
dB –30 –10 –6 –20
R
The copying conditions (initial settings) are as follows:
Copy Method: Digital Copy
Copy Level: 0dB
Copy Speed: Best Effort
To change the settings, see Copying menu setting on page 18.
Notes
It takes a few seconds for this unit to become ready to start copying after w/d (w on the remote control) has been pressed.
This unit may create some vibration and rotation noise while performing the copying process by rotating a CD at high speed. If this problem occurs, lower the copying speed to decrease the vibration and rotation noise. (See “Copy Speed” on page 19.)
To cancel copying, press a.
When copying has been completed, the operation of the HDD and the CD automatically stops.
REC
TOC GROUP
CD
CD TEXT
If the CD to be copied contains CD TEXT that can be copied, CD TEXT is automatically copied when the CD is copied onto the HDD.
Output of the signals during copying
During copying at 1x speed, signals are output both from the
ANALOG LINE OUT (PLAY) jack and from the DIGITAL OUTPUT (OPTICAL/COAXIAL) jacks.
During copying at 2x speed, signals are output only from the
ANALOG LINE OUT (PLAY) jack.
During copying at 4x or more speed, signals are output neither
from the ANALOG LINE OUT (PLAY) jack nor the
DIGITAL OUTPUT (OPTICAL/COAXIAL) jacks.
COPYING AND RECORDING ONTO THE HDD
E-15
English
COPYING FROM A CD ONTO THE HDD
OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
Copying Favorite Tracks on the CD
You can copy your favorite tracks on a CD onto the HDD.
1
NATURAL SOUND HDD/CD RECORDER
POWER
COPY
LEVELPHONES
MIN MAX
CDRHDD
A.M.Q.R.
1
1 3,65
MULTI JOG
PUSH ENTER
TEXT/TIME MODE
TRACK NO.
COMPLETE
BOOKMARK
DIGITAL REC LEVEL
ANALOG REC LEVEL
INPUT
FINALIZE ERASE
REC
OPTICAL
COAXIAL
ANALOG
MIN MAX
5
MENU
CLEAR
3,6
2,7 4
2,7 4
1. Load the CD to copy from on the disc tray.
Press v (OPEN/CLOSE on the remote control) to open the disc tray, and place a CD with its label side facing up. Then press v (OPEN/CLOSE on the remote control) to close the disc tray.
2. Start playback of the CD.
Press w/d (w on the remote control) to start playback. Playback is started from the beginning of the first track.
3.Press TRACK NO./BOOKMARK (BOOKMARK on the
remote control) while your favorite track is being played. The MARK indicator lights on the display.
MARK
Press t/e or r/y (t or y on the remote control) to skip tracks, and repeat above operation.
To cancel a bookmark
Press TRACK NO./BOOKMARK (BOOKMARK on the remote control) to cancel the bookmark during playback of the track. The MARK indicator turns off on the display.
4. When the bookmark have been placed to all favorite
tracks, press a to stop playback.
Tracks are listed and stored in order that the bookmarks have been placed.
To cancel all bookmarks
Press CLEAR as pressing TRACK NO./BOOKMARK on the front panel while this unit is in the stop mode. Bookmark Clr appears on the display, and all bookmarks are canceled.
Note
The bookmark placed to the track on the CD will be canceled
if the disc tray is open, or the power of this unit is turned off.
E-16
5. Press COPY once.
This unit enters the copy standby mode. Copying has not been started yet at this stage.
6. Press TRACK NO./BOOKMARK (BOOKMARK on the
remote control).
The list of the track that the bookmark is placed to is selected as the group to be copied (the MARK indicator lights on the display). Press TRACK NO./BOOKMARK (BOOKMARK on the remote control) again to return to the normal copy standby mode.
7. Start copying.
Press w/d (w on the remote control) to start copying.
003 1 π 1 001
MARK
ALL SYNC
L
DIG
dB –30 –10 –6 –20
R
Notes
It takes a few seconds for this unit to become ready to start copying after w/d (w on the remote control) has been pressed.
This unit may create some vibration and rotation noise while performing the copying process by rotating a CD at high speed. If this problem occurs, lower the copying speed to decrease the vibration and rotation noise. (See “Copy Speed” on page 19.)
To cancel copying, press a.
When copying has been completed, the operation of the HDD and the CD automatically stops.
REC
TOC GROUP
CD
Advanced Operations
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0+10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0+10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
COPYING FROM A CD ONTO THE HDD
Making an additional copying onto an already recorded disc
MULTI JOG
ER
COPY
A.M.Q.R.
When the copying onto the HDD, you can select the disc on the HDD to make copy on. Rotate the MULTI JOG knob (press GROUP SKIP q/GROUP SKIP w on the remote control) to select the disc number to make the copy on while this unit is in the copy standby mode.
003 1
Disc number to make the copy on
π 1 000
DIG
ALL SYNC
Notes
If the disc number is not selected, copying will be made on the
disc with the smallest number available on the HDD.
When a disc number with recorded tracks is selected, new
recordings will be added to the end of the last track that has been previously recorded.
TEXT/TIME MODE
TRACK NO.
COMPLETE
BOOKMARK
FINALIZE ERASE
REC
GROUP SKIP wGROUP SKIP q
L
dB –30 –10 –6 –20
R
OPTICAL
COAXIAL
ANALOG
CD
MULTI JOG
PUSH ENTER
MENU
CLEAR
DIGITAL REC LEVEL
ANALOG REC LEVEL
INPUT
MIN MAX
REC
TOC GROUP
Setting the copying mode
This unit provides various copying modes. Choose the one that suits your needs.
Initial setting: All Synchro
MULTI JOGMODE
ER
COPY
A.M.Q.R.
MODE
ENTER
+, –
FINALIZE ERASE
REC
t/e, r/y
TEXT/TIME MODE
TRACK NO.
BOOKMARK
COMPLETE
OPTICAL
COAXIAL
ANALOG
MULTI JOG
PUSH ENTER
DIGITAL REC LEVEL
INPUT
MENU
CLEAR
ANALOG REC LEVEL
MIN MAX
t, y
1. Press MODE while this unit is in the copy standby
mode.
You can select the copying mode.
2. Rotate the MULTI JOG knob (press +/– on the remote
control) to select the copying mode.
Choose one of the modes listed below.
All Synchro (All-synchronized copying mode)
This mode copies all of the material from a single audio source at the same time as the source programs are being played. Track markers are automatically placed between the tracks being recorded.
Multi Synchro (Multi-synchronized copying mode)
This mode copies the set number of tracks at the same time as the source programs are being played. The number of tracks to be recorded can be set in the range of 1 to 99 tracks. This mode is convenient to record a mix of tracks from different sources.
E-17
COPYING AND RECORDING ONTO THE HDD
English
OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
COPYING FROM A CD ONTO THE HDD
3. Press the MULTI JOG knob (ENTER on the remote
control) to confirm the copying mode selected.
If “All Synchro is confirmed, this unit returns to the copy standby mode. If Multi Synchro is confirmed, the following message appears on the display. Go to step 4.
How many ?1
MULT SYNC
L
DIG
dB –30 –10 –6 –20
R
TOC
CD
REC
4. Select the number of tracks by rotating the MULTI
JOG knob (pressing +/– on the remote control).
The number can be selected in the 1 to 99 tracks range.
5. Press the MULTI JOG knob (ENTER on the remote
control) to confirm the number selected.
This unit returns to the copy standby mode.
6. Select the track to start copy from by pressing t/e
or r/y (t or y on the remote control).
Copying menu setting
You can make detailed settings on the menu for your copying. Follow the steps described below for menu setting.
MULTI JOG MENU
ER
COPY
A.M.Q.R.
FINALIZE ERASE
REC
MENU
+, –
ENTER
TEXT/TIME MODE
TRACK NO.
BOOKMARK
COMPLETE
OPTICAL
COAXIAL
ANALOG
MULTI JOG
PUSH ENTER
DIGITAL REC LEVEL
INPUT
MENU
CLEAR
ANALOG REC LEVEL
MIN MAX
1. Press MENU while this unit is in the copy standby
mode.
You can start setting the copying menu.
2. Select the menu item to be set by rotating the MULTI
JOG knob (pressing +/– on the remote control).
The copying menu contains 3 items as follows:
Copy Method (setting the copying method)
Copy Level (setting the copying level)
Copy Speed (setting the copying speed)
3. Press the MULTI JOG knob (ENTER on the remote
control) to confirm the menu item to be adjusted.
4. Adjust the parameter for each item by rotating the
MULTI JOG knob (pressing +/– on the remote control).
See the further steps for detailed instructions on parameter adjustment for each item.
5. Press the MULTI JOG knob (ENTER on the remote
control) to confirm the setting when adjustment has been completed.
6. Press MENU to close the menu.
This unit returns to the copy standby mode.
E-18
COPYING FROM A CD ONTO THE HDD
Copy Method
Setting of the copying method. Copying may fail if the setting for Copy Method is not correctly made.
Copy Method
ALL SYNC
L
DIG
dB –30 –10 –6 –20
R
TOC
CD
REC
Initial setting: Digital Copy
Digital Copy
This method always makes digital copies. Copying is not possible if the tracks are copy protected by the SCMS standard (see page 5).
Auto Dig/Anlg
Digital and analog copying are automatically switched depending on the track. If digital copying is prohibited by the SCMS standard (see page 5), an analog copy is made. For those tracks that can be digitally copied, a digital copy is made.
Analog Copy
This method always makes analog copies.
Notes
In analog copying, the data may be copied at a lower sound level.
The setting is stored in the memory and applies to future copying.
Copy Level
Setting of the sound level for copying. Sound level adjustment is not normally necessary. However it is possible to adjust the copying sound level to suit you needs.
Copy Level
ALL SYNC
L
DIG
dB –30 –10 –6 –20
R
The following message appears on the display when Copy Level setting is confirmed in step 3 for Copying menu setting on page
18.
Level 0.0dB
ALL SYNC
L
DIG
dB –30 –10 –6 –20
R
TOC
CD
TOC
CD
REC
REC
LEVEL
2. Press the MULTI JOG knob (ENTER on the remote
control) to confirm the copying level setting.
Notes
Level adjustment is not possible during copying.
If the red part on the peak level meter lights at the loudest sound
levels, stop copying to adjust the copying level, and then resume copying.
L
dB –30 –10 –6 –20
R
If the level is adjusted, copying is made at maximum 2x speed.
Copy Speed
Setting of the copying speed.
Copy Speed
Initial setting: Best Effort
Best Effort
Copying is made at the maximum speed possible depending on the
Copy Method and Copy Level settings.
When Digital Copy is selected: maximum 10x speed
When Auto Dig/Anlg” is selected: maximum 2x speed
When Analog Copy” is selected: maximum 2x speed
1x Copy
Copying is always made at 1x speed despite the Copy Method and Copy Level settings.
2x Copy
Copying is always made at 2x speed despite the Copy Method and Copy Level settings.
Notes
If there are scratches or dust on the CD, the copy speed may drop automatically even when Best Effort” is selected.
The setting is stored in the memory and applies to future copying.
ALL SYNC
TOC
CD
L
DIG
dB –30 –10 –6 –20
R
TOC
CD
REC
COPYING AND RECORDING ONTO THE HDD
1. Adjust the copying sound level by rotating the MULTI
JOG knob (pressing +/– on the remote control).
Adjustment is possible in the –12dB to +12dB range by 0.4dB steps.
English
E-19

RECORDING FROM AN EXTERNAL COMPONENT ONTO THE HDD

OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
Recording from the Digital Components
You can make recordings from the component such as a cable TV tuner and a DVD player digitally connected to this unit.
Note
Recording onto the HDD is made in the unit called disc. The maximum length of one disc on the HDD is 99 minutes 59 seconds. If the recording has been made exceeding the maximum length, the recording will be made continuously to the next available disc.
NATURAL SOUND HDD/CD RECORDER
POWER
COPY
LEVELPHONES
MIN MAX
CDRHDD
A.M.Q.R.
1
1. Turn on the power of this unit by pressing POWER on
the front panel.
The message “WELCOME TO YAMAHA HDD/CD SYS- TEM appears on the display. After the message is displayed, this unit is ready for operation.
2. Press HDD to select the HDD.
3. Press REC.
The HDD mark flashes, and the disc and track numbers to be recorded are indicated on the display. Recording has not been started yet at this stage. (Recording pause mode)
Dsc002 1 000
Disc number to be recorded Track number to be recorded
SYNC
L
dB –30 –10 –6 –20
R
4. Select the input source to be recorded.
Press INPUT repeatedly until the OPTICAL or COAXIAL indicator lights up.
5. Adjust the recording level.
The adjustment of the digital recording level is not normally necessary. However it is possible to adjust the recording level to suit your needs.
Play the loudest passage (highest sound level) of the source to be recorded. By pressing MENU, the display changes for the level adjustment. Rotate the MULTI JOG knob (press +/– on the remote control) to adjust the recording level. When the adjustment is com­pleted, press MULTI JOG knob (ENTER on the remote control) to confirm the adjusted recording level.
Note
Adjust the recording level so that the red part on the peak level meter does not light at the loudest sound levels.
See Adjusting the Recording Level on page 24 for details.
E-20
REC
GROUP
65 5
MULTI JOG
PUSH ENTER
TEXT/TIME MODE
TRACK NO.
COMPLETE
BOOKMARK
FINALIZE ERASE
REC
OPTICAL
COAXIAL
ANALOG
DIGITAL REC LEVEL
INPUT
MENU
CLEAR
ANALOG REC LEVEL
MIN MAX
3
4
5
5
2
6 6 8
4832
6. Start recording.
Press w/d (w or d on the remote control) to start recording.
Dsc002 1 001
SYNC
L
dB –30 –10 –6 –20
R
REC
7. Start playing the source.
Press w/d (d on the remote control) to stop recording temporarily. The HDD mark flashes and the track number is advanced to the next. Press w/d (w or d on the remote control) to resume recording.
8. Press a to stop recording.
The first track number of the disc at which recording has been stopped is indicated on the display.
Dsc002 1
G
IMPORTANT
Never turn off the power of this unit during recording. Recording may not be correctly made, or the data on the HDD may be damaged.
During recording, make sure that this unit is not subjected to shock or vibration as the HDD may be damaged.
L
dB –30 –10 –6 –20
R
GROUP
RECORDING FROM AN EXTERNAL COMPONENT ONTO THE HDD
OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
Recording from the Analog Components
You can make recordings from the component such as a cassette deck and a turntable connected to this unit.
Note
Recording onto the HDD is made in the unit called disc. The maximum length of one disc on the HDD is 99 minutes 59 seconds. If the recording has been made exceeding the maximum length, the recording will be made continuously to the next available disc.
COPYING AND RECORDING ONTO THE HDD
NATURAL SOUND HDD/CD RECORDER
POWER
COPY
LEVELPHONES
MIN MAX
CDRHDD
A.M.Q.R.
1. Turn on the power of this unit by pressing POWER on
the front panel.
2. Press HDD to select the HDD.
3. Press REC.
This unit enters the recording pause mode.
Dsc002 1 000
SYNC
L
dB –30 –10 –6 –20
R
4. Select the input source to be recorded.
Press INPUT repeatedly until the ANALOG indicator lights up.
5. Adjust the recording level.
Play the loudest passage (highest sound level) of the source to be recorded, and rotate the ANALOG REC LEVEL control to adjust the recording level.
Note
Adjust the recording level so that the red part on the peak level meter does not light at the loudest sound levels.
See Adjusting the Recording Level on page 24 for details.
6. Start recording.
Press w/d (w or d on the remote control) to start recording.
Dsc002 1 001
SYNC
L
dB –30 –10 –6 –20
R
REC
GROUP
REC
6
MULTI JOG
PUSH ENTER
TEXT/TIME MODE
TRACK NO.
COMPLETE
BOOKMARK
DIGITAL REC LEVEL
ANALOG REC LEVEL
INPUT
FINALIZE ERASE
REC
OPTICAL
COAXIAL
ANALOG
MIN MAX
58321
4
3
MENU
CLEAR
4
6
2
6 8
7. Start playing the source.
Press w/d (d on the remote control) to stop recording temporarily. The HDD mark flashes and the track number is advanced to the next. Press w/d (w or d on the remote control) to resume recording.
8. Press a to stop recording.
The first track number of the disc at which recording has been stopped is indicated on the display.
Dsc002 1
G
IMPORTANT
Never turn off the power of this unit during recording. Recording may not be correctly made, or the data on the HDD may be damaged.
During recording, make sure that this unit is not subjected to shock or vibration as the HDD may be damaged.
L
dB –30 –10 –6 –20
R
GROUP
English
E-21
RECORDING FROM AN EXTERNAL COMPONENT ONTO THE HDD
Recording Using an External Timer
Notes on recording time setting
This unit is not equipped with the clock function. Use an external timer when making a timer recording.
It may take 30 seconds to 1 minute after the power of this unit is turned on by an external timer until an actual recording starts. (This length
of time is subject to change depending on the condition.) During this time, no recording is made. Therefore set the time that is 2-minute earlier than the starting time of the program to be recorded for turning on this unit.
As a characteristic of an HDD recorder, it is necessary to store information to control audio data as well as audio data itself. This informa­tion is normally recorded when recording is stopped. Therefore if the power of this unit is turned off before recording is stopped, no information to control audio data and no audio data are stored. Set the time that is longer than 3-minute after the program to be recorded finishes for turning off this unit by an external timer.
Set the time that is 2-minute longer than actual recording time for the total recording time.
Following chart indicates the time flow when this unit makes timer recordings.
Time to be set on the external timer
(2 minutes + recording time + 3 minutes or longer)
Recording time to be set on the CDR-HD1300
(Recording time + 2 minutes)
Recording time
External timer turns on
CDR-HD1300 starts recording
(30 seconds to 1 minute after the
external timer turns on.)
Program starting time
Time flow
Program ending time
External timer turns off
CDR-HD1300 finishes recording
Example: To record the program that starts at 9:00 and ends at 10:00.
Set the external timer to be turned on at 8:58.
Set the external timer to be turned off after 10:03.
Set 1 hour 2 minutes for the total recording time on this unit.
Notes
Actual recorded material includes a little more than the set amount of time at both beginning and end of the recording. Delete unnecessary parts using the editing operation.
Recording will be stopped if copy protected digital signals are input while timer recording is being made.
If you set the total recording time over 99 minutes 59 seconds, recording will be made extending several discs. To play the recorded
materials sequentially, select Style All as the play style. See Setting the Play Style” on page 80.
See next page for the setting procedure.
E-22
Setting for a timer recording
OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0+10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0+10
BOOKMARK
REPEAT RANDOM
GROUP SKIP
INTRO
HDD CDR
RECORDING FROM AN EXTERNAL COMPONENT ONTO THE HDD
NATURAL SOUND HDD/CD RECORDER
POWER
COPY
LEVELPHONES
MIN MAX
CDRHDD
A.M.Q.R.
1. Turn on the power of this unit by pressing POWER on
the front panel.
2. Press HDD to select the HDD.
Notes
A timer recording cannot be made when recording onto a CD-R or CD-RW disc.
You can directly go to step 7 to set the total time of timer recording by pressing TIMER REC on the remote control.
3. Press REC.
This unit enters the recording pause mode.
4. Select the input source to be recorded.
Press INPUT to select the input source from among OPTI­CAL, COAXIAL, and ANALOG.
5. Adjust the recording level.
See Adjusting the Recording Level on page 24.
6. Select a recording mode.
Select one of Manual (manual recording), Track Synchro (track-synchronized recording) or “Auto Period” (auto-period recording). Other modes cannot be selected when timer recording is made.
7. Press and hold REC for approximately 3 seconds
(press TIMER REC on the remote control).
Following message appears on the display. Then set the total amount of time of timer recording.
T.Span 1h 2m
SYNC
L
dB –30 –10 –6 –20
R
655,6,8,9
FINALIZE ERASE
REC
REC
TIME
3,7 2,7
4 6
5,6,8,9
9
TEXT/TIME MODE
TRACK NO.
BOOKMARK
COMPLETE
OPTICAL
COAXIAL
ANALOG
MULTI JOG
PUSH ENTER
DIGITAL REC LEVEL
INPUT
4
MENU
CLEAR
ANALOG REC LEVEL
MIN MAX
53,721
8. Rotate the MULTI JOG knob (press +/– on the remote
control) to set the total time of timer recording.
Total time can be set as long as the recordable maximum time by 1-minute step.
9. Press the MULTI JOG knob (ENTER on the remote
control) to confirm the total time of timer recording.
Timer Standby appears on the display.
Timer Standby
G
To cancel timer recording setting, press a.
10.
Leave the power of this unit on. Turn off the power of this unit by the external timer.
If the power of this unit is turned on by the external timer, Timer Standby flashes for approximately 5 seconds. Then recording starts according to the setting.
Note
Once timer recording is set, recording starts every time the power of this unit is turned on. To cancel the setting, press a while Timer Standby is flashing, or while recording is being made.
L
dB –30 –10 –6 –20
R
COPYING AND RECORDING ONTO THE HDD
2
English
E-23
RECORDING FROM AN EXTERNAL COMPONENT ONTO THE HDD
OPEN/CLOSE
COPY REC
TEXT/TIME
TRACK NO.
WRITE
MODE MENU
CLEAR
1
ABC2DEF3GHI
4
JKL5MNO6PQR
7
STU8VWX9YZ
SPACE
SYMBOL
0 +10
BOOKMARK
ENTER
COMPLETE
A.M.Q.R.
FINALIZE
INPUT
TIMER REC
ERASE
MENU
ENTER
+, –
Adjusting the Recording Level
There is an adjusting procedure for each input source to be recorded as explained below. Choose the one for your input source and follow the steps.
MULTI JOG
ER
COPY
A.M.Q.R.
TEXT/TIME MODE
TRACK NO.
COMPLETE
BOOKMARK
FINALIZE ERASE
REC
INPUT
OPTICAL
COAXIAL
ANALOG
MULTI JOG
PUSH ENTER
DIGITAL REC LEVEL
ANALOG REC LEVEL
MENU
MENU
CLEAR
MIN MAX
ANALOG REC LEVEL
When recording a digital input source
The digital recording level is set to 0dB, the level of the input source, as an initial setting. Further adjustment is not normally necessary. However it is possible to adjust the recording level to suit your needs.
1. Press MENU while this unit is in the recording pause
mode.
The following message appears on the display.
REC
Level 0.0dB
SYNC
L
dB –30 –10 –6 –20
R
LEVEL
2. Play the loudest passage (highest sound level) of the
source to be recorded.
3. Rotate the MULTI JOG knob (press +/– on the remote
control) to adjust the recording level.
4. Press the MULTI JOG knob (ENTER on the remote
control) to return to the previous display.
Notes
The recording level can be adjusted while this unit is in either the recording or recording pause mode. Once recording has been stopped, the recording level is reset to 0dB.
Adjustment of the recording level can be canceled by pressing MENU when the level is adjusted in the recording pause mode.
The recording level is set to 0dB by pressing CLEAR when the level is adjusted in the recording pause mode.
When recording an analog input source
1. Play the loudest passage (highest sound level) of the
source to be recorded.
2. Adjust the recording level by rotating the ANALOG
REC LEVEL control.
Rotate the control clockwise to increase the level and counterclockwise to decrease the level. Adjust the recording level so that the red part on the peak level meter does not light at the loudest sound levels.
Adjustment is possible in the –12dB to +12dB range by 0.4dB steps. Adjust the recording level so that the red part on the peak level meter does not light at the loudest sound levels.
L
dB –30 –10 –6 –20
R
E-24
Note
The recording level can be adjusted while this unit is in either the recording or recording pause mode.
Loading...
+ 76 hidden pages
