U
CDM-900
110-Disc CD Changer
OWNER’S MANUAL
FEA TURES
•
110-Disc Auto-changer
• Random Access Programmable Play
• Random-Sequence Play
• Single Track/Entire Disc/All Discs Repeat Play
• Album/Artist Name Filing Capability
• Favorite Tracks on Each Disc Filing Capability
• 220-Disc Relay Play by Connecting Two CDM-900s
• Group Play
• CD TEXT Compatibility
• Disc Search Using CD TEXT
• Index Search
• Full Operation Remote Control
• Optical Digital Output
• Timer Play Option
CONTENTS
Safety Instructions................................................2
Connections .........................................................4
Identification of Components................................5
Inserting CDs .......................................................7
Basic Operation....................................................8
Random-Sequence Play .................................... 11
Repeat Play........................................................12
Program Play......................................................13
Group play..........................................................15
Index Search ...................................................... 17
Intro scan ........................................................... 17
Disc filing............................................................ 18
Relay play...........................................................21
Timer play .......................................................... 22
Notes about the Remote Control T ransmitter.....23
CD Preventive Care ...........................................23
Troubleshooting.................................................. 24
Specifications .....................................................25
SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
• Explanation of Graphical Symbols
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.
1 Read Instructions – All the safety and operating
instructions should be read before the unit is operated.
2 Retain Instructions – The safety and operating instructions
should be retained for future reference.
3 Heed Warnings – All warnings on the unit and in the
operating instructions should be adhered to.
4 Follow Instructions – All operating and other instructions
should be followed.
5 Water and Moisture – The unit should not be used near
water – for example, near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming
pool, etc.
6 Carts and Stands – The unit should be used only with a
cart or stand that is recommended by the manufacturer.
6A A unit and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
unit and cart combination to overturn.
7 Wall or Ceiling Mounting – The unit should
be mounted to a wall or ceiling only as
recommended by the manufacturer.
8 Ventilation – The unit should be situated so that its location
or position does not interfere with its proper ventilation.
For example, the unit should not be situated on a bed,
sofa, rug, or similar surface, that may block the ventilation
openings; or placed in a built-in installation, such as a
bookcase or cabinet that may impede the flow of air
through the ventilation openings.
9 Heat – The unit should be situated away from heat
sources such as radiators, stoves, or other appliances that
produce heat.
10 Power Sources – The unit should be connected to a power
supply only of the type described in the operating
instructions or as marked on the unit.
11 Power-Cord Protection – Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the unit.
12 Cleaning – The unit should be cleaned only as
recommended by the manufacturer.
13 Nonuse Periods – The power cord of the unit should be
unplugged from the outlet when left unused for a long
period of time.
14 Object and Liquid Entry – Care should be taken so that
objects do not fall into and liquids are not spilled into the
inside of the unit.
15 Damage Requiring Service – The unit should be serviced
by qualified service personnel when:
A. The power-supply cord or the plug has been damaged;
or
B. Objects have fallen, or liquid has been spilled into the
unit; or
C. The unit has been exposed to rain; or
D. The unit does not appear to operate normally or
exhibits a marked change in performance; or
E. The unit has been dropped, or the cabinet damaged.
16 Servicing – The user should not attempt to service the unit
beyond those means described in the operating
instructions. All other servicing should be referred to
qualified service personnel.
17 Power Lines – An outdoor antenna should be located away
from power lines.
18 Grounding or Polarization – Precautions should be taken
so that the grounding or polarization is not defeated.
We W ant You Listening For A Lifetime
YAMAHA and the Electronic Industries Association’s Consumer
Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound
come through loud and clear without annoying blaring or
distortion – and, most importantly, without affecting your
sensitive hearing. Since hearing damage from loud sounds is
often undetectable until it is too late, YAMAHA and
the Electronic Industries Association’s Consumer
Electronics Group recommend you to avoid
prolonged exposure from excessive volume levels.
IMPORT ANT!
Please record the serial number of this unit in the space
below.
Model:
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.
2
CAUTION: READ THIS BEFORE OPERA TING YOUR UNIT
1 To ensure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2 Install your unit in a cool, dry, clean place, and in a
horizontal and stable position – away from windows, heat
sources, vibration, dust, moisture, or cold. To avoid
humming sounds, locate the unit away from other
electrical appliances, motors, and transformers. To prevent
fire or electrical shock, do not expose to rain and water.
3 Do not operate the unit upside-down. It may overheat,
possibly causing damage.
4 Do not put anything other than discs in the unit. If any
foreign object should fall into the unit, contact your dealer.
5 Do not use force on switches, knobs or cords.
6 Do not clean the unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
7 Be sure to read the “TROUBLESHOOTING” section on
common operating errors before concluding that your unit
is faulty.
WARNING
CAUTION
Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
DANGER
Invisible laser radiation when open and interlock failed or
defeated.
Avoid direct exposure to beam.
8 Do not place another component on top of this unit, as
damage or discoloration on the surface of the unit may
result.
9 To prevent damage by lightning, disconnect the power
cord from the AC outlet during an electrical storm.
10 When disconnecting the power cord from the AC outlet,
grasp the plug; do not pull the cord.
This unit is not disconnected from the AC power source as
long as it is connected to the wall outlet, even if this unit
itself is turned off. This state is called the standby mode. In
this state, this unit is designed to consume a very small
quantity of power.
CAUTION FOR CARRYING THIS UNIT
When you carry the unit:
1 Press STANDBY/ON and make sure “ST ANDBY”
disappears from the display .
2 Remove all CDs from the unit.
3 Disconnect the power cord from the AC outlet.
As the laser beam used in this compact disc player is harmful
to the eyes, do not attempt to disassemble the cabinet. Refer
servicing to qualified personnel only.
To avoid electrical shock, do not open the unit. Refer servicing
to qualified personnel only.
DANGER: The use of optical instrument with this product will
increase eye hazard.
CAUTION (FOR CANADA MODEL)
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT AND FULL Y INSER T.
FOR CANADIAN CUSTOMER
THIS CLASS B DIGITAL APPARATUS MEETS ALL
REQUIREMENTS OF THE CANADIAN INTERFERENCECAUSING EQUIPMENT REGULA TIONS.
FCC INFORMATION (for US customers only)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions
contained in this manual, meets FCC requirements.
Modifications not expressly approved by Y amaha may void your
authority, granted by the FCC, to use the product.
2. IMPORTANT: When connecting this product to accessories and/
or another product use only high quality shielded cables. Cable/
s supplied with this product MUST be used. Follow all
installation instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
3. NOTE: This product has been tested and found to comply with
the requirements listed in FCC Regulations, Part 15 for Class
“B” digital devices. Compliance with these requirements
provides a reasonable level of assurance that your use of this
product in a residential environment will not result in harmful
interference with other electronic devices.
This equipment generates/uses radio frequencies and, if not
installed and used according to the instructions found in the
users manual, may cause interference harmful to the operation
of other electronic devices.
Laser Diode Properties
• Material: GaAlAs
• Wavelength: 780 nm
• Emission Duration: continuous
• Laser Output: max. 44.6 µW*
* This output is the value measured at a distance of about
200 mm from the objective lens surface on the Optical Pickup Block.
Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this product is found
to be the source of interference, which can be determined by
turning the unit “OFF” and “ON”, please try to eliminate the problem
by using one of the following measures:
Relocate either this product or the device that is being affected by
the interference.
Utilize power outlets that are on different branch (circuit breaker or
fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead, change the
lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type of
product. If you can not locate the appropriate retailer, please
contact Y amaha Electronics Corp., U.S.A. 6660 Orangethorpe A ve,
Buena Park, CA 90620.
The above statements apply ONL Y to those products distributed by
Yamaha Corporation of America or its subsidiaries.
3
CONNECTIONS
• Never plug in this unit or other components until all connections are completed.
• Connections should be made to the correct input terminals of
the amplifier or other components.
• To connect another unit for relay play, see page 21.
• If the placement of this unit creates interference (noise) in
other equipment, such as a tuner, relocate this unit away
from the affected equipment.
U.S.A model
AUDIO
OPTICAL
2
Optical fiber cable
(not included)
OUT
LINE OUTDIGITAL
1
LINE OUT
2nd CHANGER
INPUT
1
RELAY PLAY REMOTE
CONTROL
2nd MAIN
OUT IN
CONTROL
DIGITAL
AUDIO
OUT
OPTICAL
T o AC outlet
1
Connection cord
(included)
OPTICAL
CDDIGITAL IN
Amplifier
To connect this unit to your amplifier, choose one of the following procedures:
1 When the LINE OUT (analog) terminals of
this unit are used
• Be sure that the left (“L”) and right (“R”) LINE OUT
terminals are connected to the corresponding (left and
right) terminals of the amplifier or other component.
• Connect the “LINE OUT” terminals to the “CD” (or “AUX”)
terminals of the amplifier. If the amplifier does not have
such terminals, use the “T APE PB” terminals. For
additional details concerning these connections, refer to
the operation instructions of the amplifier being used.
• The LINE OUT terminals of this unit are numbered 1.
When connecting this unit with a YAMAHA amplifier or
receiver whose terminals on the rear panel are
numbered as 1, 2, 3, etc., connect the LINE OUT
terminals of this unit to the input terminals numbered 1
on the rear panel of the amplifier or receiver.
4
2 When the DIGITAL OUT terminal of this unit
is used
This unit has a DIGITAL OUT (OPTICAL) terminal on the
rear panel.
• Before using the terminal on the rear panel, remove the
terminal’s cover .
• Make the connection from the terminal to the optical
input terminal of an amplifier or other digital audio
component by using a commercially available optical
fiber cable.
* Use an optical fiber cable that conforms to EIAJ
• Be sure to replace the terminal’s cover when the terminal
on the rear panel is not being used, in order to protect
from dust.
• The terminal can also be connected to the optical input
terminal of a DA T (Digital Audio Tape) deck or MD (Mini
Disc) deck, etc., to record a CD directly.
• The output level of this terminal is not variable.
standards. Other cables might not function correctly .
IDENTIFICATION OF COMPONENTS
REMOTE CONTROL TRANSMITTER
English
ALL button (p.8)
ACTIVE button (p.22)
POWER button (p.8)
INTRO button (p.17)
FILE MODE button (p.19)
DISC button (p.9)
FILE EDIT button (p.18)
GROUP EDIT button (p.15)
Number buttons (p.9)
DISC SKIP buttons (p.8)
SKIP buttons (p.9)
SEARCH buttons (p.10)
STOP button (p.8)
POWER ACTIVE ALL PROG +1 DISC
/ I
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
67890
DISK SKIP
DISC GROUP
2345
ENTER
SKIP
SEARCH
INDEX REPEAT RANDOM
STOP PAUSE PLAY
PROG (program) button (p.13)
+1 DISC button (p.10)
GROUP (A – E) buttons (p.15)
TEXT MODE button (p.19)
TEXT SRCH (search) button (p.19)
TIME MODE button (p.10)
CAPS (capital letters) button (p.16)
DELETE button (p.14)
ENTER button (p.13)
RANDOM button (p.11)
PLA Y button (p.8)
REPEAT button (p.12)
P AUSE button (p.8)
INDEX button (p.17)
* This manual describes how to operate this unit by using the remote control transmitter. To operate this unit from the front panel,
use the corresponding buttons on the front panel (see page 6).
For Custom Installer
For U.S.A., Canada and Australia models only
REMOTE CONTROL (IN, OUT) terminals
These terminals are used for custom installation system. When this unit is connected to the components for custom installation
system, you can operate this unit with the system remote control.
Connect the REMOTE CONTROL IN terminal of this unit to the output terminal of the central controller for custom installation
system.
By connection the REMOTE CONTROL OUT terminal of this unit to the REMOTE CONTROL IN terminal of the other component,
you can also operate the component with the system remote control. In this way, up to 6 components can be connected in series.
5
FRONT P ANEL
SINGLE
1
5
0
987
6
43
2
•
TEXT MODE button (p.19)
FILE MODE button (p.19)
GROUP EDIT
button (p.15)
ENTER button (p.13)
+1DISC button (p.10)
STANDBY/ON
STANDBY/ON
switch (p.8)
PROGRAM button (p.13)
GROUP (A – E)
buttons (p.15)
+1DISC A B C D E ALL PROGRAM
Remote control
DISC GROUP
Display panel
SKIP/CURSOR
buttons (p.9)
sensor (p.23)
ALL button
(p.8)
SKIP/CURSOR
SEARCH
SEARCH buttons
(p.10)
FILE TEXT
button (p.8)
FILE
EDIT
button
(p.18)
MODE
EDIT
FILE GROUP
(PLA Y/P AUSE)
STOP button
(p.8)
DELETE
button (p.14)
DELETE ENTER
DISC/CHARACTER
JOG dial
(p.9)
* The PLA Y/PAUSE button on the front panel has the functions of both the PLAY button and the PAUSE button on the remote control
transmitter.
DISC SLOT SECTION
For an explanation on how to open the front panel, see page 7.
Disc slots (p.7)
Loader carriage (p.7)
6
Disc slot for single disc play (SINGLE) (p.10)
Slot numbers (p.7)
INSERTING CDS
English
1 Open the front panel, by pulling gently from both ends.
Magnetic
latch
Notes
• Except when inserting or removing discs, keep your hands
out of the unit while the front panel is open. You could be
injured if your hands could become entagled in the
internal mechanism.
• Keep cassette tapes, video cassettes, or floppy discs
away from the magnetic latches.
2 Slide the loader carriage to the desired slot number to
insert a disc.
Disc slots
5
•
Grasp here and slide.
Slot
number
4 Close the front panel gently.
Note
• If you leave the front panel open while a disc is in play,
when the disc is over, the unit will stop.
To remove discs
1 Open the front panel.
2 Slide the loader carriage to the slot of the disc you want
to remove.
3 Press the eject button on the loader carriage.
Loader carriage
Slot No. 0 (SINGLE) is reserved for single disc play
mode.
3 Set the disc on the loader and flip the loader upwards.
With the Label side facing right
Flip this part upward.
Notes
• Do not use 8-cm (3-inch) CDs. Even if you use the
expander rings, the unit could be damaged.
• Do not put anything other than discs in the unit.
Loader carriage
Eject button
CAUTION FOR CARRYING THIS UNIT
When you carry the unit:
1 Press STANDBY/ON and make sure “ST ANDBY”
disappears from the display .
2 Remove all CDs from the unit.
3 Disconnect the power cord from the AC outlet.
Notes
• You can insert and remove discs while playing a disc.
– Do not set a disc in the slot of the disc being played (slot
indicator flashes). The disc in play is returned to its slot
when finished. If there is a disc in the slot of the disc at
play, when the disc is finished, “TAKE OUT” appears in the
display. Remove the disc from the currently playing disc’s
slot.
– Sometimes the front panel cannot be opened while a disc
is playing. In such case, wait a few moments or until the
disc stops playing then try again.
• Insert the CD correctly and avoid abrupt eject button
operation to prevent discs from popping out or falling into the
unit during operation.
7
1
PAUSE
1
67890
2345
ABCDE
POWER ACTIVE ALL PROG +1 DISC
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
DISC GROUP
FILE EDIT GROUP EDIT DISC DELETE CAPS
INDEX REPEAT RANDOM
STOP PAUSE PLAY
ENTER
DISK SKIP
SKIP
SEARCH
/ I
BASIC OPERA TION
1
2
3
1 Turn the power on.
POWER
/ I
“DISC LOADING” appears in the display for a few
seconds. Then, the disc number that was played most
recently appears in the display .
2 Press DISC SKIP repeatedly until the desired disc
number appears in the display.
DISC SKIP
3
The unit plays all discs in the unit from the selected one.
PLAY
To stop play temporarily
To resume play, press P AUSE again (or press PLAY).
* The
button on the front panel can also be used to stop
play temporarily or to resume play.
To stop play completely
STOP
To turn off the unit (standby mode)
Press POWER again.
Note
• To play all the discs in the unit, make sure the “ALL” indicator
appears in the display . If not, press ALL.
In ALL play mode, the unit plays all the discs from the
selected one. Empty disc slots are skipped.
Display information during disc play
12
ALL
8
DISC TRACK
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
34
1 Shows the disc number selected or being played.
2 Shows the track number selected or being played.
3 Shows the time. (Refer to “Selecting time displays” on page
10.)
4 Shows the CD track numbers (up to 20). After each track is
played, its corresponding number disappears so that
remaining track numbers can be seen at a glance.
To play a specific disc
SKIP
English
1 Press DISC and the number button of the desired disc.
1
DISC
2345
67890
The selected disc number is displayed.
DISC
You can also select the disc with the JOG dial on the front
panel. In this case, turn the JOG dial on the front panel until
the desired disc number appears in the display .
2 Press to start play.
PLAY
Example: To select disc 105,
press 1, then 0, then 5.
1
5
0
Note
• If there is no disc in the slot you select, the unit plays the disc
in the next slot up which contains a disc.
To play a specific track on the disc
DIRECT PLAY
1 Select a desired track using the number buttons.
1
2345
67890
The selected track number is displayed.
ALL
2 Press to start play.
Example: To select track 25,
press 2, then 5.
* If you enter a number that is higher than the last track
number on the disc, the final track is played.
DISC TRACK
2
1
2
3
6
7
8
11
12
13
16
17
18
5
SKIP PLAY
To skip to a succeeding track, press SKIP once or
repeatedly until the desired track number appears.
SKIP
To skip to the beginning of the current track, press
SKIP
4
5
9
10
14
15
19
20
To skip to a preceding track, press SKIP
once.
SKIP
repeatedly until
the desired track number appears.
Notes
• These operations can also be performed when the unit is in
the pause or stop mode.
• If SKIP is pressed and held, the track number successively
changes to higher numbers (or lower numbers).
9
T o advance or reverse play rapidly (MANUAL SEARCH)
SEARCH
PLAY
T o advance rapidly
SEARCH
(Press and hold.)
T o reverse rapidly
(Press and hold.)
• The sound can be heard (although slightly garbled) during manual search in either direction. This is convenient for locating a
precise position within a track, or for reviewing the contents quickly.
• Manual search can also be performed while disc play is paused, though no sound will be heard.
Selecting time displays
Y ou can select any of the four time displays by pressing TIME MODE. Each time you press TIME MODE, the display changes as
follows:
1 Elapsed time of the track now playing
ALL
DISC TRACK
2
3
6
7
8
11
12
13
16
17
18
after 2 seconds
ALL
DISC TRACK
2
3
6
7
8
11
12
13
16
17
18
4
5
9
10
14
15
19
20
4
5
9
10
14
15
19
20
TIME MODE
2 Remaining time of the track now playing
ALL
DISC TRACK
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
after 2 seconds
ALL
DISC TRACK
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
4 Total remaining time on the disc
ALL
DISC TRACK
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
after 2 seconds
ALL
DISC TRACK
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
SINGLE DISC PLAY
You can use the unit as a single CD player by using slot number 0 (SINGLE).
1 Insert a disc into slot number 0 (SINGLE) (see page 7).
3
2 Press +1 DISC so that “+1” appears in the display.
+ 1
Notes
• You can enjoy random-sequence play (see page 11) or
repeat play (see page 12) in this mode.
• When you press ALL or GROUP (A – E) during single disc
play mode, single disc play mode will be cancelled.
+1 DISC
3 Total disc play time
ALL
DISC TRACK
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
The unit stops automatically after finishing all the tracks
of the disc in slot number 0.
10
RANDOM-SEQUENCE PLAY
The unit can play all the tracks on a selected disc or on all discs in a random sequence selected by the unit’s microcomputer.
English
1 Press +1 DISC, ALL, or GROUP (see “GROUP PLAY”
on page 15) to select the playing mode.
2 Press RANDOM.
RANDOM
The mode indicator you select appears
POWER ACTIVE ALL PROG +1 DISC
/ I
DISC GROUP
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
2345
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
+1 DISC MODE
The unit plays all tracks on the current disc in random order.
ALL MODE
The unit plays all tracks on all discs in random order.
GROUP MODE
The unit plays all tracks on all the discs of the selected group in
random order.
T o cancel random-sequence play mode
Press STOP or RANDOM.
”RANDOM” disappears from the display .
1
1
1
2
ALL
RANDOM
RANDOM appears in the
display.
Notes
• This feature will not function during programming, or during
programmed play .
• If SKIP
is pressed during random-sequence play , the
next randomly programmed track will be played.
If SKIP is pressed, play will return to the beginning of
the current track.
• Total remaining time on the disc will not be displayed during
random-sequence play .
11
REPEAT PLAY
You can play any desired track or disc, or all discs repeatedly .
POWER ACTIVE ALL PROG +1 DISC
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
Press REPEAT to select the repeat mode.
/ I
DISC GROUP
ABCDE
1
2345
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
SINGLE REPEAT
The current track is played repeatedly .
REPEA T
REPEAT
Each time you press REPEAT , the display changes as
follows:
ALL
OFF
(No indication)
ALL
REPEAT
SINGLE
ALL
REPEAT
SINGLE
ALL
REPEAT
DISC
ALL DISCS
SINGLE REPEA T
SINGLE DISC REPEA T
ALL DISCS REPEAT
SINGLE DISC REPEAT
The current disc is played repeatedly .
* In the random-sequence play mode, all randomly sequenced
tracks are played repeatedly in the same order.
* In the programmed-play mode, SINGLE DISC REPEAT play
is not available.
ALL DISCS REPEAT
All tracks on all discs are played repeatedly .
* In the programmed-play mode, all programmed tracks are
played repeatedly.
* In the group play mode, all tracks on all discs in the group
you selected are played repeatedly .
* In the random-sequence play mode, all randomly sequenced
tracks on all discs are played repeatedly .
* In the +1 DISC mode, ALL DISCS REPEAT play is not
available.
T o cancel repeat play mode
Press REPEAT successively until ”REPEAT” disappears from
the display.
Note
• When you turn the unit off during SINGLE DISC REPEAT or
ALL DISCS REPEAT play mode, the next time you turn the
unit on, the play mode will be restored.
12
PROGRAM PLAY
1
67890
2345
PLAY
PROG
By creating a program, you can enjoy listening to your favorite discs or tracks in any desired order. As many as 40 steps can be
programmed in sequence.
English
1 Stop the unit.
2 Press PROG.
STOP
PROG
3
POWER ACTIVE ALL PROG +1 DISC
/ I
DISC GROUP
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
2345
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
4 Press the number button of the desired track, then
5 Repeat steps 3 to 4 to program more discs and tracks.
2, 6
4
4
7
1
press ENTER.
ENTER
* You can program an entire disc as one step by pressing 0
(“AL” flashes in the display).
You can select the same disc or track again.
3 Press DISC SKIP to select the disc number you want to
program.
DISC SKIP
Display information during programming
1
PROGRAM
PROGRAM
DISC TRACK
2
3
DISC TRACK
4
6 Press PROG to exit the program input mode.
7
1 Shows the selected disc number.
2 Shows the program number for the track to be entered
next.
3 Shows the selected track number.
4 Shows the numbers of programmed tracks.
2
13
Notes
• When you change to program play mode from another play
mode, press STOP and PROG (“PROG” appears in the
display), then press PLA Y to start program play.
• To select a disc directly, press DISC, the number button of
the desired disc and ENTER, or turn the JOG dial on the
front panel in step 3 of the previous page.
• SKIP (
skip to tracks within the program.
and ) can be used during program play to
• SEARCH ( and ) can be used during program play
to search all tracks, including unprogrammed tracks.
• Even if you press POWER to turn the unit off, the programs
you have set remain in the unit’s memory.
• If you program a track that is not included in a disc, “ERROR”
appears in the display.
• If you program an entire disc as one step, “1” appears in the
display during program play.
To cancel program play mode
Press ALL, +1 DISC, or GROUP (A – E) during program play
mode. Program play mode will be canceled.
T o check program data
1. Press STOP to stop program play .
2. Press PROG.
3. Press SKIP
and track number and the program number are displayed
in the order of the program. When you want to check the
preceding disc or tracks, press SKIP
Note
• When you program an entire disc as one step, “AL” appears
in the display when you press SKIP to check program data.
. Each time you press this button, the disc
.
T o change program data
1. Follow the preceding procedure described in “To check
program data.”
2. Display the disc or track number to be deleted or corrected
by pressing SKIP.
3. Press DISC SKIP to select the desired disc and press the
number button of the desired track you want to substitute
for the one currently displayed.
( When you want to program an entire disc as one step,
press 0 after pressing DISC SKIP.)
4. Press ENTER.
The previously programmed track or disc will be cleared
from the memory and the new one will be programmed.
If you want to delete the programmed track or disc
currently displayed, press DELETE before pressing
ENTER.
5. When you are finished, press PROG or PLAY.
Note
• When you program an entire disc as one step, “AL” appears
in the display when you press SKIP to change program data.
T o delete all program data
1. Follow of steps 1 and 2 of the procedure described in “To
check program data.”
2. Press and hold DELETE for more than 5 seconds.
3. “DELETE” appears for a moment, then “ALL DELETE”
appears and the entire contents of memory is deleted.
14
GROUP PLAY
You can create and name up to 5 groups in which to categorize discs according to your preference (artists, music type, etc.) and
enjoy any play mode within each group.
POWER ACTIVE ALL PROG +1 DISC
/ I
DISC GROUP
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
2345
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
2
3
T o cancel group play mode
1 Insert discs into the slots of the group you want to
create (see page 7). The pre-installed border numbers
between each group are:
Group A, from 1 to 20
Group B, from 21 to 40
Group C, from 41 to 60
Group D, from 61 to 80
Group E, from 81 to 110.
* You can change these border numbers (see this page).
2 Press GROUP (A – E) to select the group you want to
play.
The selected group appears in the
display.
DISC GROUP
ABCDE
3
PLAY
Press ALL or +1 DISC during group play mode. Group play
mode will be canceled.
T o change a border number
1. During stop, press GROUP EDIT.
2. Press GROUP (A – E) to select the group you want to
change.
3. Press SKIP
change.
Selected border numbers flash in the display .
4. Press DISC SKIP or turn the JOG dial on the front panel to
select the new border number.
The border number of any group adjacent to the border
number you changed will also be changed.
5. Press GROUP EDIT twice.
Notes
• Each group must have a at least one disc.
• Y ou can enjoy random-sequence or repeat play within a
certain group.
or to select the border you want to
English
The unit automatically stops after playing the last
disc in the group.
Display information during group edit (bordering)
1
GROUP B
2
GROUP EDIT
1 Shows the selected group.
2 Shows the border numbers of the selected group.
15
To edit the group name
1. During stop, press GROUP EDIT.
2. Press GROUP (A – E) to select the group you want to edit.
3. Press GROUP EDIT.
The group name appears in the display .
(The pre-installed group names are GROUP A, GROUP B,
GROUP C, GROUP D, and GROUP E.)
4. Press SKIP to select the cursor position you want to edit.
5. Press DELETE to delete the character, or press SEARCH
or turn the JOG dial on the front panel to select the
character you want.
6. Repeat steps 4 and 5 until all the characters you want are
input.
7. Press GROUP EDIT to store the group name.
To delete the group name
1. Follow of steps 1, 2, and 3 above.
2. Press SKIP to move the cursor to first character.
3. Press DELETE repeatedly until all the characters
disappear.
Available characters
Notes
• When you input a character, each time you press CAPS, the
type of character changes as follows.
→ Capital letters (A, B, C, D, ……)
↓
Small letters (a, b, c, d, ……)
↓
Figures (0, 1, 2, 3, 4, ……)
For details, see
“Available characters”
below.
↓
Symbols (!, “, #, $, %, ……)
• A maximum of 12 characters can be used in each group
name.
• Capital letters
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
• Small letters
a b c d e f g h i j k l m n o p q r s t u v w x y z
• Figures
0 1 2 3 4 5 6 7 8 9
Display information during group edit (naming)
1
GROUP A
2
GROUP A
GROUP EDIT
GROUP EDIT
• Symbols
! “ # $ % & ’ ( )
¢ £ ¤ ¥
3
/4 ¿ À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï Đ Ñ Ò Ó Ô Õ Ö × Ø Ù
§ C P R ¯ ˚ ± 2 3 ´ µ • † 1 1/4 1/2
Ú Û Ü Ý
ú û ü ý
ÿ (space)
+ , - . / : ; < = > ? @ [ \ ] ˆ _ ` { | } ¡
ß à á â ã ä å æ ç è é ê ë ì í î ï đ ñ ò ó ô õ ö ÷ ø ù
1 Shows the selected group.
2 Shows the cursor position.
3 Shows the group name you input.
16
3
INDEX SEARCH
If the disc includes index numbers, play can be started from any desired index number.
POWER ACTIVE ALL PROG +1 DISC
/ I
DISC GROUP
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
2345
1, 3
2
1 Select a track which has index numbers.
1
2345
67890
2
INDEX
3 Select the desired index number.
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
To cancel the index search function
Press the INDEX button.
Notes
• Not all discs have index numbers. The index system is a
method for sub-dividing tracks into smaller divisions (for
example, the movements within classical symphonies) for
easier location of those parts. The liner notes with the disc
usually tell if such index numbers are included.
• If an index number is selected that is higher than any index
number on that disc, play will start from the last index
number point on the disc.
• For some discs, play may begin slightly prior to the actual
designated index point.
• If the disc has no encoded index points, play will begin from
the start of the selected track.
• The index number can be designated only while “INDEX”
appears in the display.
English
1
2345
67890
ENTER
INTRO SCAN
Y ou can check the discs in the unit by listening to a short segment of each disc in turn. The unit will play several seconds segment
from the second minutes of each disc. The unit scans discs in order of disc number from the current disc.
When the desired disc is located
1 Stop the unit.
STOP
2
INTRO
During Intro scan, when the desired disc is located, press
INTRO or PLAY to exit Intro scan and continue listening.
To stop Intro scan
Press ST OP.
Note
• During program play mode, the unit scans all the discs in the
unit.
17
DISC FILING
FILE EDIT
FILE EDIT
TEXT FILING
You can file each disc by album title and/or artist name in the unit’s memory. You can easily locate a disc using the filed text data.
POWER ACTIVE ALL PROG +1 DISC
/ I
DISC GROUP
2, 5,
7, 8
1
3
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
2345
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
3
To input the album title and artist name for the
selected disc
1 During stop, press DISC SKIP to select the disc to
which you want to input the text data.
(Make sure that “PROGRAM” indicator in the display is
turned off before this step.)
DISC SKIP
4 Repeat step 3 until the all characters you want are
input.
5 Press FILE EDIT to store the album title.
ALL
DISC
ARTIST
“ARTIST” appears in the display and the cursor flashes.
You can input the artist name.
If you do not need to enter the artist name, skip step 6.
EDIT
TEXT
6 Repeat step 3 until the all characters you want are
input.
7 Press FILE EDIT to store the artist name.
FILE EDIT
2 Press FILE EDIT.
ALL
DISC
TITLE
Cursor position
“TITLE” appears in the display and the cursor flashes.
Y ou can input the album title.
If you do not need to enter the album title, skip steps 3
and 4.
EDIT
TEXT
3 Press SEARCH or turn the JOG dial on the unit to select the
character you want to input, then press SKIP.
The cursor moves to next position.
Selected character
ALL
ALL
DISC
TITLE
DISC
TITLE
EDIT
TEXT
EDIT
TEXT
“BEST” appears in the display.
(For “BEST FILING” program, see page 20.)
8
“SAVE” and “TEXT” appear in the display.
Notes
• When you input a character, you can change the type of
character by pressing CAPS. For details, see “Available
characters” on page 16.
• A maximum 12 characters can be used in each album title or
artist name.
18
English
ENTER
T o correct the text data
1. In step 4 for “TITLE” or step 6 for “AR TIST” on the previous
page, press SKIP to select the cursor position you want to
correct.
2. Press DELETE to delete the character, or press SEARCH
or turn the JOG dial on the front panel to select the new
character.
3. Repeat the above step 2 until all corrections are
completed.
4. Press FILE EDIT.
T o delete text data for a disc
1. Press STANDBY/ON on the front panel to turn off the unit.
2. Press STANDBY/ON and hold while simultaneously
pressing FILE MODE and DELETE. Then, release
ST ANDBY/ON first, then release FILE MODE and
DELETE.
3. Press SKIP to select the disc you want to delete text data
from.
4. Press DELETE.
5. Press FILE EDIT.
CAUTIONS
• If you press DELETE for more than 5 seconds after step
2, “DELETE” appears for a moment, then ”ALL DELETE”
appears, and the entire contents of memory is erased.
Be careful.
• Each disc file may contain up to 3 types of information:
– album title
– artist name
– BEST FILING data.
If you erase a disc file, all above information from that
file will be erased.
Note
• The unit’s memory can hold information for about 200 discs.
When the memory is full, “MEMORY FULL” appears in the
display. To add more text data, you must first erase some
unnecessary files from memory (you must erase all kinds of
disc file data (album title, artist name, and BEST FILING
data) for a disc).
To locate the disc by text data
1 During stop, press TEXT SRCH repeatedly until
“SEARCH TITLE” (when you search for an album title)
or “SEARCH ARTIST” (when you search for an artist
name) appears in the display .
DISC
SEARCH TITLE
DISC
SEARCH ARTIST
or
2 Press SEARCH or turn the JOG dial on the front panel
to select the first character of the album title or the artist
name you want to search for.
ALL
DISC
SEARCH TITLE
3
The unit locates all of the corresponding album titles or
artist names beginning with the selected character and
displays the first one according to slot number.
Press SKIP or turn the JOG dial on the front panel to
advance to the next album title or artist name beginning
with the selected character. Repeat until the desired
album title or artist name is located.
4 Press PLAY to play the selected disc.
CD TEXT
This unit is compatible with the CD TEXT function. The CD
TEXT disc has information, such as the album title, artist
names, and track names. If the current disc is a CD TEXT disc,
the unit captures the album title, artist name, and track names
from the disc. You can easily locate a disc using the text data of
a CD TEXT disc (see “To locate the disc by text data” on this
page) and display the CD TEXT data (see “To display the text
data” on this page.
Notes
• The album title, artist names, or track names may not be
displayed with some CD TEXT discs.
• You cannot change the CD TEXT data.
T o display the text data
Press TEXT MODE.
Each time you press TEXT MODE, the display changes as
follows.
Album title → Artist name → Track name → Time display
• If no data is entered for the current disc (album title, artist
name), “(NO ENTRY)” appears in the display .
• The track name is displayed only when the current disc is a
CD TEXT disc and has the track name data.
19
BEST FILING
It is possible to file only those tracks you want from each disc (i.e., hide unwanted tracks). You can easily play back the tracks in any
order you set.
Notes
• You can create as many as 32 edits for a each disc.
• If you input a track that the unit cannot accept, “ERROR”
appears in the display.
• The unit’s memory can hold information for about 200 discs.
When the memory is full, “MEMORY FULL” appears in the
display. To add more text data, you must first erase some
unnecessary files from memory . See “To change program
data” on this page.
T o play a disc with “BEST FILING” program
2
1
POWER ACTIVE ALL PROG +1 DISC
/ I
DISC GROUP
ABCDE
INTRO FILE MODE TEXT MODE TIME MODE TEXT SRCH
FILE EDIT GROUP EDIT DISC DELETE CAPS
1
2345
67890
DISK SKIP
SKIP
SEARCH
ENTER
INDEX REPEAT RANDOM
STOP PAUSE PLAY
3
3, 5
1. Press STOP to stop the unit.
2. Press FILE MODE so that “FILE” appears in the display.
T o input your favorite tracks
If “SA VE” and “BEST” appear in the display, the unit reads
“BEST FILING” program.
3. Press PLAY to start playing.
1 During stop, press DISC SKIP to select the disc to
which you want to edit.
(Make sure that “PROGRAM” indicator in the display is
turned off before this step.)
2 Press FILE EDIT repeatedly until “BEST” appears in
the display.
TRACK
BEST
EDIT
3 Press the number button of the desired track, then
press ENTER.
TRACK
Selected track number
BEST
EDIT
4 Repeat steps 2 and 3 to program more tracks. You can
select the same track again.
5 Press FILE EDIT to store the text data.
“SAVE” and “BEST” appear in the display.
Notes
• If the disc does not have any “BEST FILING” program data in
the memory, “BEST” does not appear in the display, and the
unit does not perform the “BEST FILING” function.
• When the FILE indicator is illuminated in the display, you can
play the filed data in random order by pressing RANDOM.
T o check “BEST FILING” program data
1. Press STOP to stop “BEST FILING” program play.
2. Press FILE EDIT.
3. Press SKIP . Each time you press this button, the
track number and the program number are displayed in the
order of the program. When you want to check the
preceding tracks, press SKIP
.
T o change “BEST FILING” program data
1. Follow the preceding procedure described in “To check
“BEST FILING” program data.”
2. Display the track number to be deleted or corrected by
pressing SKIP.
3. Press the number button of the desired track you want to
substitute for the one currently displayed. The previously
programmed track will be cleared from the memory and
the new one will be programmed.
If you want to delete the programmed track currently
displayed, press DELETE.
4. When you are finished, press FILE EDIT.
T o delete all discs “BEST FILING” program data
20
Press DELETE for more than 5 seconds after step 2 of the
procedure described in “To delete text data” on page 19.
CAUTION
Deleting all discs “BEST FILING” program data will also
erase the entire contents of memory (including album title
or artist name). Be careful.
RELAY PLAY
If you have two CDM-900s, you can connect them and enjoy any combination play of 220 discs.
Connections
Never plug in these units or other components until all connections are completed.
First, set the 2nd/MAIN switch of the unit connected to an amplifier to MAIN and the 2nd/MAIN switch of the other unit to 2nd. After
completing the connections as shown below, connect the power cords of both units to the AC outlet.
Main unit
English
To amplifier
L
R
2nd CHANGER
INPUT
1
RELAY PLAYLINE OUT
CONTROL
2nd MAIN
Set to
“MAIN”.
RL
2nd CHANGER
INPUT
1
RELAY PLAYLINE OUT
CONTROL
2nd MAIN
Set to “2nd”.
LINE OUT
2nd CHANGER
RELAY PLAY
INPUT
2nd MAIN
DIGITAL
AUDIO
OUT
OPTICAL
Remote control cable (sold separately)
2nd unit
LINE OUT
2nd CHANGER
RELAY PLAY
INPUT
2nd MAIN
DIGITAL
AUDIO
OUT
OPTICAL
CONTROL
CONTROL
After completing the connections, press the STANDBY/ON buttons of both units to turn the power on. “ACTIVE” appears in the
display of the main unit, ”INACTIVE” appears in the display of the second unit. Relay play (switching between both units) takes effect
according to the selected play mode.
Notes
• The 2nd/MAIN switch should be set before plugging into the AC outlet.
• If relay play is not needed and each unit is used separately, the 2nd/MAIN switch on the rear panel of each unit should be set to
the “MAIN” position.
21
Disc play
If the power of both units is switched on, you can begin relay play . You can set play mode (ALL, GROUP, +1, PROGRAM) on each
unit separately and enjoy any combination play using both units. First, the main (ACTIVE) unit starts play in the selected play mode,
and Relay play will take effect according to the following chart (at which time the main unit will become “INACTIVE” and the second
unit will become “ACTIVE”) :
When random sequence play mode of the ACTIVE unit is off
Playing mode of
ACTIVE unit
ALL
GROUP
+1
PROGRAM
When random sequence play mode of the ACTIVE unit is on
Playing mode of
ACTIVE unit
ALL
GROUP
+1
• When either unit is set to program play mode, the relay play
function in random sequence play does not work.
• The ACTIVE unit plays the BEST FILING program automatically if the current disc has BEST FILING data and “FILE” appears in
the display.
• The remote control transmitter controls the ACTIVE unit only. To operate the INACTIVE unit, you must use the controls on the front
panel.
• To switch the ACTIVE unit and INACTIVE unit manually , press ACTIVE on the remote control transmitter.
ACTIVE unit and INACTIVE unit will
switch when:
all discs finish playing.
all discs of the group finish playing.
the current disc finishes playing.
all steps you programmed finish playing.
ACTIVE unit and INACTIVE unit will
switch when:
one track finishes playing.
(In these cases, the INACTIVE unit
enters random sequence play mode
automatically .)
Example: When you set the main unit to GROUP play
mode and the second unit to +1 play mode.
• The main unit starts playing in group play
mode.
ACTIVE unit
MAIN
After all discs of the group finish playing
• The second unit becomes the ACTIVE unit and
starts playing in +1 play mode
INACTIVE unit
MAIN
After the current disc finishes playing
• The main unit becomes the ACTIVE unit again
and starts playing in group play mode
ACTIVE unit INACTIVE unit
MAIN
Relay play repeats until it is canceled
INACTIVE unit
2nd
ACTIVE unit
2nd
2nd
To exit relay play mode
Turn either unit off. The other unit can still be used.
TIMER PLAY
You can start play in any mode at any specified time by connecting a timer (sold separately). Refer also to the instructions for the
timer.
1. Select the desired play mode (ALL, GROUP, +1, or PROGRAM).
2. Press STANDBY/ON to turn the unit off.
3. Press STANDBY/ON while pressing PLAY on the front panel.
Shortly thereafter, “TIMER P. ON” appears in the display and the timer play function is on.
(When the timer play function is already on, in which case, “TIMER P. OFF” appears in the display and timer play function is off.
In this case, repeat the procedure in steps 2 and 3 to set the timer play function to on.)
4. Set the timer to the desired time.
When the set time comes, the unit turns on and starts play.
22
NOTES ABOUT THE REMOTE CONTROL TRANSMITTER
English
Battery installation
1
3
2
Battery replacement
If you find that the remote control transmitter must be used
closer to the main unit than usual, the batteries are weak.
Replace both batteries with new ones.
Notes
• Use only AA, R6, UM-3 batteries for replacement.
• Be sure the polarities are correct. (See the illustration inside
the battery compartment.)
• Remove the batteries if the remote control transmitter will not
be used for an extended period of time.
• If batteries leak, dispose of them immediately. Avoid touching
the leaked material or letting it come in contact with clothing,
etc. Clean the battery compartment thoroughly before
installing new batteries.
Remote control transmitter operation range
Remote control
sensor
Within approximately
6 m (19.7 feet)
30°
Notes
• There should be no large obstacles between the remote
control transmitter and the main unit.
• If the remote control sensor is directly illuminated by strong
lighting (especially an inverter type of fluorescent lamp etc.),
it might cause the remote control transmitter not to work
correctly. In this case, reposition the main unit to avoid direct
lighting.
30°
CD PREVENTIVE CARE
• This compact disc player is designed for playing compact
discs bearing the
other type of disc into the unit.
The unit cannot play 8-cm (3-inch) compact discs.
• Compact discs are not subjected to wear during play, but
damage to the disc surface when the disc is being handled
can adversely affect the disc’s play.
• Do not use cleaning discs or warped discs. All of these could
damage the unit.
T o prevent a malfunction of this unit
• Do not use any non standard shaped CD (heart etc.)
available on the market, because it may damage the unit.
• Do not use a CD with tape, seals, or paste on it, because
damage to the unit may result.
mark only. Never attempt to load any
• Compact discs are not affected by small particles of dust or
fingerprints on their playing surface, but even so they should
be kept clean. Wipe by using a clean, dry cloth. Do not wipe
with a circular motion; wipe straight outward from the center.
• Do not try to clean the disc’s surface by using any type of
disc cleaner, record spray, anti-static spray or liquid, or any
other chemical-based liquid, because such substances might
irreparably damage the disc’s surface.
• Do not expose discs to direct sunlight, high temperature or
high humidity for a long period of time, because these might
warp or otherwise damage the disc.
No!
23
TROUBLESHOOTING
If the unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple
measures suggested. If it cannot be corrected, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and
contact your authorized YAMAHA dealer or service center for help.
SYMPTOM
The player does not switch ON when
the STANDBY/ON switch or POWER
button is pressed.
This unit does not work normally .
Play does not begin.
Play is delayed, or begins at the
wrong place.
No sound.
Sound “skips.”
Sound “hums.”
Noise from a nearby tuner.
Noise from inside of the unit.
“TAKE OUT” appears in the display.
The remote control transmitter does
not work.
PROBABLE CAUSE
The power cord is not connected or not
completely connected.
Front panel is open.
There is an influence of strong external
noise (lightning, excessive static
electricity, etc.) or a misoperation was
performed while using this unit.
The disc is damaged.
There is moisture on the laser pickup.
The disc has been loaded backwards.
The disc is dirty.
The disc may be scratched or damaged.
Improper output cable connections.
Improper amplifier operation.
The player is being subjected to
vibrations or impacts.
The disc is dirty.
Improper cable connections.
The tuner is too close to the player.
The disc may be warped.
A disc is set in the slot of the disc being
played.
The unit fail to work properly due to
some external lighting or sound stimulus.
The batteries of the remote control
transmitter are too weak.
Direct sunlight or lighting (of an inverter
type of fluorescent lamp etc.) is striking
the remote control sensor of the main
unit.
Front panel is open.
REMEDY
Securely connect the power cord.
Close the front panel securely.
Turn the power off and disconnect the
AC power from the AC outlet. After about
30 seconds, connect the power and try
again.
Check the disc carefully; replace it if
necessary.
Wait 20 to 30 minutes after switching the
unit ON before trying to play a disc.
Reload the disc with the label side facing
right.
Clean the disc.
Check the disc carefully; replace it if
necessary.
Connect the cables properly . If the
problem persists, the cables may be
defective.
Set the amplifier controls to the correct
input selection.
Relocate the player.
Clean the disc.
Securely connect the audio cables. If the
problem persists, the cables may be
defective.
Move the tuner and player farther apart.
Replace the disc.
Remove the disc from the currently
playing disc’s slot.
Open and close the front panel while the
unit is turned on to reset the unit.
Replace the batteries with new ones.
Change the position of the main unit.
Close the front panel securely.
24
SPECIFICATIONS
English
AUDIO SECTION
Frequency response ...........................2 Hz – 20 kHz, ±0.5 dB
Harmonic distortion + noise (1 kHz)............... 0.003% or less
S/N ratio ........................................................... 104 dB or more
Dynamic range .................................................. 96 dB or more
Wow & flutter .....................................................Unmeasurable
Output level (1 kHz, 0 dB) ........................................ 2.0 ±0.5 V
GENERAL
Power requirements
U.S.A. and Canada models ..............................120 V, 60 Hz
Australia model................................................. 240 V, 50 Hz
Europe and U.K. models .................................. 230 V, 50 Hz
General model.........................110/120/220/240 V, 50/60 Hz
Power consumption ......................................................... 15 W
Dimensions (W × H × D).................... 435 × 176.5 × 407.5 mm
(17-1/4” × 7” × 16-1/8”)
Weight ....................................................... 8.4 kg (21 lbs. 3 oz)
Accessories .................................................... Connection cord
Remote control transmitter
Batteries (size AA, R6, UM-3)
Please note that all specifications are subject to change
without notice.
25
YAMAHA ELECTRONICS CORPORATION, USA 6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.
YAMAHA CANADA MUSIC LTD. 135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA
YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, F.R. OF GERMANY
YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE
YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND
YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN
YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA
Printed in MalaysiaYP V276350
Loading...
