Yamaha 396, AX-496 User Manual

AX-496/396

STEREO AMPLIFIER

AMPLIFICATEUR STEREO

G B

OWNER’S MANUAL

MODE D’EMPLOI

BEDIENUNGSANLEITUNG

BRUKSANVISNING

MANUALE DI ISTRUZIONI

MANUAL DE INSTRUCCIONES

GEBRUIKSAANWIJZING

UNPACKING After unpacking, check that the following items are contained. DEBALLAGE Après le déballage, vérifier que les pièces suivantes sont incluses. AUSPACKEN Nach dem Auspacken überprüfen, ob die folgenden Teile vorhanden sind. UPPACKNING Kontrollera efter det apparaten packats upp att följande delar finns med. DISIMBALLAGGIO Verificare che tutte le parti seguenti siano contenute nell’imballaggio dell’apparecchio. DESEMBALAJE Desembale el aparato y verifique que los siguientes accesorios están en la caja. UITPAKKEN Controleer na het uitpakken of de volgende onderdelen voorhanden zijn.

DISC SKIP

MD

AUX

–

PRESET

STANDBY/ON

TUNER

VOLUME

DECK A/B

TAPE

DIR BDIR A

CD

A/B/C/D/E

+–

CD/DVD

TAPE

TUNERPHONO

+

● Batteries (size AA, R6, UM-3)

● Piles (format AA, R6, UM-3)

● Batterien (Größe AA, R6, UM-3)

● Batterier (Storl. AA, R6, UM-3)

● Batterie (dimensioni AA, o R6, o UM-3)

● Pilas (tamaño AA, tipo R6, UM-3)

● Batterijen (maat AA, R6, UM-3)

● Remote control

● Télécommande

● Fernbedienung

● Fjärrkontroll

● Telecomando

● Control remoto

● Afstandbediening

Opening and closing the front cover

Close the front cover whenever the controls inside the panel are not used.

Ouverture et fermeture du couvercle avant

Fermer le couvercle avant lorsque les commandes placées à l’intérieur du panneau ne sont pas utilisées.

Öffnen und Schließen der Reglerfachklappe

Schließen Sie die Reglerfachklappe, wenn Sie die Regler im Fach nicht verwenden.

Öppning och stängning av frontluckan

Ha frontluckan stängd när kontrollerna innanför den inte används.

Apertura e chiusura dello sportello anteriore

Richiudere sempre lo sportello anteriore quando i comandi non vengono utilizzati.

Apertura y cierre de la cubierta delantera

Cierre la cubierta delantera cuando no utilice los controles del panel.

Openen en sluiten van het voorklepje

Sluit het voorklepje steeds wanneer de bedieningsorganen binnen in het paneel niet gebruikt worden.

To open the front cover
Pour ouvrir le couvercle avant
Öffnen der Reglerfachklappe
Öppning av frontluckan
Apertura
Para abrir la cubierta delantera
Openen van het voorklepje

1

2

To close the front cover
Pour fermer le couvercle avant
Schließen der Reglerfachklappe
Stängning av frontluckan
Chiusura
Para cerrar la cubierta delantera
Sluiten van het voorklepje

Thank you for selecting this YAMAHA stereo amplifier.

FEATURES

AX-496

v

85W + 85W (8Ω) RMS Output Power, 0.019% THD, 20–20,000 Hz

AX-396

60W + 60W (8Ω) RMS Output Power, 0.019% THD, 20–20,000 Hz
Highly Dynamic Power, Low Impedance Drive Capability

v

Continuously Variable LOUDNESS Control

v

CD/DVD DIRECT AMP Switch Used to Reproduce the Purest CD and DVD Sound

v

Remote Control Capability

v

AX-496 only

REC OUT Selector Independent of Input Source Selection

v

PURE DIRECT Switch Used to Reproduce the Purest Source Sound

v

English

CONTENTS

UNPACKING ............................................................................. Inside of Front Cover

FEATURES ............................................................................................................... 1

CAUTION ...................................................................................................................2

NOTES ABOUT THE REMOTE CONTROL.............................................................. 3

CONNECTIONS........................................................................................................ 4

CONTROLS AND THEIR FUNCTIONS .................................................................... 6

OPERATION ............................................................................................................. 9

TROUBLESHOOTING ............................................................................................ 13

SPECIFICATIONS................................................................................................... 14

E-1

CAUTION: Read this before operating your unit.

1. To assure the finest performance, please read this

manual carefully. Keep it in a safe place for future
reference.

2. Install this unit in a cool, dry, clean place – away from

windows, heat sources, sources of excessive vibration,
dust, moisture and cold. Avoid sources of humming
(transformers, motors). To prevent fire or electrical
shock, do not expose the unit to rain or water.

3. Never open the cabinet. If something drops into the

set, contact your dealer.

4. Do not use force on switches, controls or connection

wires. When moving the unit, first disconnect the
power plug and the wires connected to other
equipments. Never pull the wires themselves.

5. The openings on the unit cover assure proper

ventilation of the unit. If these openings are
obstructed, the temperature inside the unit will rise
rapidly; therefore, avoid placing objects against these
openings. Install the unit in a well-ventilated area to
prevent fire or damage.
Be sure to allow a space of at least 20 cm behind, 20
cm on both sides and 30 cm above the top panel of the
unit to prevent fire or damage.

6. The voltage used must be the same as that specified

on this unit. Using this unit with a higher voltage than
specified is dangerous and may result in fire or other
accidents. YAMAHA will not be held responsible for
any damage resulting from use of this unit with a
voltage other than specified.

7. Always set the VOLUME control to “

” before starting

∞

the audio source play. Increase the volume gradually
to an appropriate level after the play has been started.

8. Do not attempt to clean the unit with chemical solvents

as this might damage the finish. Use a clean, dry
cloth.

9. Be sure to read the “TROUBLESHOOTING” section

regarding common operating errors before concluding
that the unit is faulty.

10. When not planning to use this unit for a long period

(ie., vacation, etc.), disconnect the AC power plug from
the wall outlet.

11.

To prevent lightning damage, disconnect the AC power
plug when there is an electric storm.

12. Grounding or polarization – Precautions should be

taken so that the grounding or polarization of an
appliance is not defeated.

13. Do not connect any audio equipment to the AC outlet

on the rear panel if the equipment requires more power
than the outlet is rated to provide.

For U.K. customers

If the socket outlets in the home are not suitable for the plug
supplied with this appliance, it should be cut off and an
appropriate 3 pin plug fitted. For details, refer to the
instructions described below.
Note: The plug severed from the mains lead must be
destroyed, as a plug with bared flexible cord is hazardous if
engaged in a live socket outlet.

SPECIAL INSTRUCTIONS FOR U.K. MODEL

IMPORTANT:

THE WIRES IN MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:

Blue: NEUTRAL
Brown: LIVE
As the colours of the wires in the mains lead of this

apparatus may not correspond with the coloured
markings identifying the terminals in your plug, proceed
as follows: The wire which is coloured BLUE must be
connected to the terminal which is marked with the letter
N or coloured BLACK. The wire which is coloured
BROWN must be connected to the terminal which is
marked with the letter L or coloured RED. Making sure
that neither core is connected to the earth terminal of the
three pin plug.

When this unit is turned off by pressing the STANDBY/ON
switch on the front panel or the remote control, the
STANDBY indicator on the front panel lights up. This
state is called the standby mode. In this mode, this unit is
designed to consume a small amount of power. This
unit’s power supply cannot be completely cut off from the
AC line until the POWER switch on the front panel is set
in the OFF position or the AC power cord is disconnected.

WARNING
Do not change the IMPEDANCE SELECTOR switch
setting while the power to this unit is on, otherwise
this unit may be damaged.

If this unit fails to turn on when the POWER switch is
pressed:
The IMPEDANCE SELECTOR switch may not be set to
either end. If so, set the switch to either end when this
unit’s power supply is completely cut off.

(Europe model)

SPEAKERS

EE INSTRUCTION MANUAL FOR CORRECT SETTING.

IMPEDANCE SELECTOR

SET BEFORE POWER ON

L

A OR B : 6ΩMIN. /SPEAKER

A B : I2

Ω

MIN. /SPEAKER

A OR B : 4ΩMIN. /SPEAKER

A B : 8

Ω

MIN. /SPEAKER

l00W MAX. TOTAL

AC OUTLETS

SWITCHED

MAINS

E-2

IMPEDANCE SELECTOR

NOTES ABOUT THE REMOTE CONTROL

English

Battery installation

Since the remote control will be used for many of this unit’s
control operations, you should begin by installing the
supplied batteries.

1. Turn the remote control over and remove the battery
compartment cover by sliding it in the direction of the
arrow.

2. Insert the batteries (AA, R6, UM-3 type) according to the
polarity markings on the inside of the battery
compartment.

3. Close the battery compartment cover.

1

3

2

Battery replacement

If you notice that the remote control must be used closer to
the main unit, the batteries are weak. Replace both
batteries with new ones.

Notes

● Use AA, R6, UM-3 batteries.

● Be sure the polarities are correct. (See the illustration

inside the battery compartment.)

● Remove the batteries if the remote control is not used for

an extended period of time.

● If batteries leak, dispose of them immediately. Avoid

touching the leaked material and contact with clothing,
etc. Clean the battery compartment thoroughly before
installing new batteries.

Remote control operation range

REC OUT

CD

TAPE

TUNER

MD

PHONO

AUX

Remote control
sensor

Within approximately
6 m (19.7 feet)

30°

Notes

● The area between the remote control and the main unit
must be clear of large obstacles.

● Do not expose the remote control sensor to strong
lighting, in particular, an inverter type fluorescent lamp;
otherwise, the remote control may not work properly. If
necessary, position the main unit away from direct
lighting.

30°

E-3

CONNECTIONS

Caution: Plug in this unit and other components after all connections are completed.

● All connections must be correct, that is to say L (left) to L, R (right) to R, “+” to “+” and “–” to “–”. Also refer to the owner’s
manual for each of your components.

● Use RCA type pin plug cables for audio/video units except speakers.

● The output (or input) terminals of YAMAHA audio/video units numbered 1, 2, 3, 4, etc. on the rear panel must be

connected to the same-numbered terminals of this unit.

Turntable

GND

R

GND

R

OUTPUT

L

PHONO

1

CD/DVD

L

Tuner

OUTPUT

Tape deck, etc.

LINE IN

LINE OUT

Right Left

Speakers A

(Europe model)

L

R

TUNER

2

IN

3

(PLAY)

TAPE

OUT

4

(REC)

IN

3

(PLAY)

MD

OUT

4

(REC)

AUX

L

R

A

B

3

SPEAKERS

R

CAUTION

:SEE INSTRUCTION MANUAL FOR CORRECT SETTING.

L

IMPEDANCE SELECTOR

SET BEFORE POWER ON

A OR B : 6ΩMIN. /SPEAKER

Ω

MIN. /SPEAKER

A B : I2

A OR B : 4ΩMIN. /SPEAKER

Ω

MIN. /SPEAKER

A B : 8

*

l00W MAX. TOTAL

1

AC OUTLETS

SWITCHED

*

2

MAINS

E-4

*

1

,

*

*

OUTPUT

CD player or
DVD player

2

3

,

: Refer to page 5 for descriptions.

*

: Indicates the direction of signals.

Video cassette player,
etc.

AUDIO OUT

LINE OUT

LINE IN

MD recorder, etc.

Right

To AC outlet

Left

Speakers B

Connecting speakers

Connect the SPEAKERS terminals to your speakers with
the wire with the proper gauge (keep it as short as
possible). If the connections are faulty, no sound will be
heard from the speakers. Make sure that the + and –
polarity markings of the speaker wires are observed and set
correctly. If these wires are reversed, the sound will be
unnatural and lack bass.

Caution
Do not let the bare speaker wires touch each other or
any metal part of this unit. This could damage this unit
or the speakers, or both.

How to Connect:

Red: positive (+)
Black: negative (–)

2

1

3

1 Loosen the knob.
2 Insert the bare wire.

[Remove approx.
10 mm (3/8”)
insulation from the
speaker wires.]

3 Tighten the knob

and secure the wire.

English

● One or two speaker systems can be connected to this
unit. If you use only one speaker system, connect it to
either the SPEAKERS A or B terminals.

● Use speakers with the specified impedance shown on the
rear of this unit.

● <Australia, China and General models only>

Banana Plug connections are also possible. Simply
insert the Banana Plug connector into the corresponding
terminal.

Rear panel parts

1

IMPEDANCE SELECTOR switch

WARNING
Do not change the IMPEDANCE SELECTOR switch
setting while the power to this unit is on, otherwise
this unit may be damaged.

If this unit fails to turn on when the POWER switch is
pressed:
The IMPEDANCE SELECTOR switch may not be set to
either end. If so, set the switch to either end when this
unit’s power supply is completely cut off.

Select the position whose
requirements your speaker
system meets.

(Right position)
If you use one pair of speakers, the impedance of
each speaker must be 4Ω or higher.
If you use two pairs of speakers, the impedance of
each speaker must be 8Ω or higher.

(Left position)
If you use one pair of speakers, the impedance of
each speaker must be 6Ω or higher.
If you use two pairs of speakers, the impedance of
each speaker must be 12Ω or higher.

A OR B : 6ΩMIN. /SPEAKER

A B : I2

Ω

MIN. /SPEAKER

A OR B : 4ΩMIN. /SPEAKER

A B : 8

*

Ω

MIN. /SPEAKER

AC OUTLET(S) (SWITCHED)

(Europe, China and General models)

...................................................... 3 SWITCHED OUTLETS

(U.K. and Australia models)............. 1 SWITCHED OUTLET

Use these to connect the power cords of your components
to this unit.
The power to the SWITCHED outlets is controlled by this
unit’s POWER or STANDBY/ON switch. These outlets will
supply power to any connected unit whenever this unit is
turned on.
The maximum power (total power consumption of
components) that can be connected to the SWITCHED AC

OUTLETS is 100W.

GND terminal (For turntable use)

Connecting the ground wire of the turntable to the GND
terminal will normally minimize hum, but in some cases
better results may be obtained with the ground wire
disconnected.

2

*

3

*

E-5

CONTROLS AND THEIR FUNCTIONS

FRONT PANEL

AX-496

457321

STANDBY

POWER

ON

STANDBY/ON

890

AX-396

NATURAL SOUND STEREO AMPLIFIER

OFF

PHONES

SPEAKERS

A

ON

OFF

AX–496

B

BASS

l0l

2

3

4

55

AUX PHONOTUNERCD/DVDTAPEMD

TREBLE

BALANCE

l0l

2

2

3

3

4

4

55

LR

LOUDNESS

3

l0l

2

2

2

3

3

3

4

4

4

55

REC OUT

CD/DVD

FLAT

TAPE

—30dB

TUNER

I0

MD

PHONO

AUX

9

8

l

2

4

567

PURE DIRECT CD/DVD DIRECT AMP

INPUT

VOLUME

l6

20

28

40

60

l2

0

–dB

8

4

2

B C D EGFA

4321

67

E-6

NATURAL SOUND STEREO AMPLIFIER

STANDBY

POWER

ON

OFF

PHONES

STANDBY/ON

SPEAKERS

A

ON

OFF

AX–396

B

2

3

4

890

BASS

l0l

2

3

4

55

TREBLE

l0l

2

3

4

55

2

3

3

4

AUX PHONOTUNERCD/DVDTAPEMD

BALANCE

l0l

2

2

3

4

4

55

LR

B C EGFA

LOUDNESS

FLAT

l

2

3

4

567

—30dB

TAPE MONITOR

INPUT

I0

9

8

CD/DVD DIRECT AMP

VOLUME

l6

20

28

40

60

–dB

l2

8

4

2

0

English

1 POWER

Press this switch inward (ON) to use this unit. In this
state, you can turn on this unit or turn this unit in the
standby mode by pressing STANDBY/ON. Press this
switch to release it outward (OFF) to completely cut off
this unit’s power supply from the AC line.

2 STANDBY indicator

Lights up only while this unit is in the standby mode.

3 STANDBY/ON

Press this switch to turn on the power. Press again to
set this unit in the standby mode.
* This switch can be used only when POWER is set in

the ON position.

Standby mode
This unit is still using a small amount of power in this
mode in order to be ready to receive infrared-signals
from the remote control.

4 Input source indicators

The indicator of the currently selected input source
lights up.

5 PURE DIRECT and indicator AX-496 only

Press this switch, and the indicator above it lights up.
You can listen to a source in the purest sound with this
function. (Refer to page 12 for details.)
Press this switch again to cancel this function.

6 TAPE MONITOR and indicator AX-396 only

Press this switch to turn on the indicator above it. You
can listen to the sound played on the tape deck
connected to the TAPE terminals on the rear of this
unit. When the tape deck is used for recording, you
can also monitor the sound being recorded.
* To listen to the source selected with the INPUT

selector, press this switch again to turn off the
indicator.

* When this function is on (the indicator is illuminated),

the tape deck (TAPE) cannot be selected with the
INPUT selector.

* When the tape deck (TAPE) is selected with the

INPUT selector, this function will not turn on even if
TAPE MONITOR is pressed.

7 CD/DVD DIRECT AMP and indicator

Press this switch, and the indicator above it lights up.
You can listen to a CD or DVD source in the purest
sound with this function. (Refer to page 12 for details.)
Press this switch again to cancel this function.

8 Remote control sensor

Receives signals from the remote control.

9 PHONES jack

When you listen with
headphones, connect the
headphones to the

PHONES jack and set both
SPEAKERS A and B

switches to the OFF
position.

0 SPEAKERS

Press the switch A or B (or both) inward (ON) for the
speakers you will use. Press and release the switch
outward (OFF) for the speakers you do not use.

A Tone controls

BASS

Rotate this knob to increase or decrease the low
frequency response. The 0 position produces a flat
response.

TREBLE

Rotate this knob to increase or decrease the high
frequency response. The 0 position produces a flat
response.

B BALANCE

The balance of the output volume to the left and right
speakers can be adjusted to compensate for sound
imbalances caused by the speaker location or listening
room conditions.

C LOUDNESS

Used to compensate for the human ears’ loss of
sensitivity to high and low-frequency ranges at low
volume. (Refer to page 12 for details.)

D REC OUT selector AX-496 only

Rotate this knob to select the source for recording to
an MD recorder or tape deck. This setting is
independent of the INPUT selector setting, so this
function allows you to record the selected source while
listening to another source.

E Front cover

Refer to inside of the front cover on how to open and
close the front cover.

F INPUT selector

Turn this knob to select the input source.
The selected source will be shown by the lighting of
corresponding input source indicator.

G VOLUME

Turn this knob to raise or lower the volume level. (The
REC OUT level is not affected.)

PHONES

PHONES

E-7

REMOTE CONTROL

The remote control is designed to control the most commonly used functions of the main unit. If you have a YAMAHA CD
player, tuner, tape deck, etc. with remote control compatibility, this remote control will also control their various functions.

For Control of This Unit

1

2

3

STANDBY/ON

TAPE

DISC SKIP

PRESET

TUNER

MD

AUX

VOLUME

–

CD

+–

TAPE

DECK A/B

DIR BDIR A

A/B/C/D/E

CD/DVD

TUNERPHONO

+

11

2

3

1 STANDBY/ON

Press this key to turn on this unit or turn it into the
standby mode.
This key can be used only when the POWER switch on
the main unit is set in the ON position.

Standby mode
In this state, this unit consumes a very small
quantity of power to receive infrared-signals from
the remote control.

2 Input selector keys

Press a key to select the input source.

3 VOLUME +/–

Press these keys to increase or decrease the volume.

For Control of Other Components

Note

The functions of the keys to control other YAMAHA
components are the same as the corresponding keys on
those components. Refer to those components’
instruction manuals for details.

1 Tape deck keys

These keys control tape decks.
* DIR A, B and A/B apply only to double cassette tape

decks.

* Pressing DIR A will reverse the tape direction on a

single cassette tape deck with the automatic reverse
function.

E-8

2 CD player keys

These keys control compact disc players.
* DISC SKIP is used for disc changers only.

3 Tuner keys

These keys control tuners.
PRESET +: Press this key to select the next preset

station number.

PRESET –: Press this key to select the previous

preset station number.

A/B/C/D/E: Press this key to select the group (A – E)

of preset station numbers.

OPERATION

English

m Playing a source

ST ANDBY

2
3

l6

1

20

28

40

60

–dB

Set to the “∞” position.

2 Press POWER inward (ON).

STANDBY

POWER

ON

OFF

l2

0

STANDBY

POWER

ON

OFF

STANDBY/ON

AX-496

REC OUT

TAPE

MD

AUX

INPUT

CD/DVD

TUNER

PHONO

2

3

4

AUX PHONOTUNERCD/DVDTAPEMD

BALANCE

l0l

2

2

3

3

4

4

55

LR

LOUDNESS

2

3

4

8

FLAT

l

—30dB

I0

9

8

567

85 4

BASS

SPEAKERS

PHONES

A

ON

TREBLE

l0l

l0l

B

2

2

2

3

3

3

4

4

4

OFF

55

55

PURE DIRECT

AX-396

CD/DVD DIRECT AMP

VOLUME

20

28

40

60

l6

–dB

TAPE MONITOR

l2

8

2

0

8

4

1, 7
4

8

4

2

5 Select speakers A or B.

SPEAKERS

A

B

ON

OFF

* Both speakers A and B can be selected.
* Be sure that the IMPEDANCE SELECTOR switch is

correctly set as explained on page 5.

* If you listen with headphones, press both switches to

release them outward (OFF).

6 Play the source.

3 If the STANDBY indicator is illuminated, press

STANDBY/ON to turn on the power. (The STANDBY

indicator turns off.)

STANDBY/ON

STANDBY/ON

–

+

STANDBY

POWER

Turns off.

4 Select the desired input source.

MD

TAPE

AUX

–

+

AUX PHONOTUNERCD/DVDTAPEMD

The indicator of the selected source lights up.

CD/DVD

TUNERPHONO

7

40

l6

20

28

60

l2

8

4

2

0

–dB

–

+

–

VOLUME

+

Adjust the output level.

8 Adjust the tonal quality by using the BASS,

TREBLE, BALANCE, LOUDNESS controls or the
CD/DVD DIRECT AMP switch (or PURE DIRECT

switch for AX-496 only). (Refer to page 12).

AX-396 only

If the TAPE MONITOR indicator is illuminated when you
listen to a source, press TAPE MONITOR to turn off the

TAPE MONITOR indicator.

When you finish using this unit

Press STANDBY/ON again to set this unit in the standby
mode. (The STANDBY indicator lights up.)

To completely cut off this unit’s power
supply from the AC line

Press POWER to release it outward (OFF).

E-9

m Recording a source to tape (or MD)

AX-496

STANDBY

POWER

ON

OFF

PHONES

STANDBY/ON

1 Select the source you want to record.

REC OUT

CD/DVD

TAPE

MD

TUNER

PHONO

AUX

2 Play the source.
3 Select the source with the INPUT selector and

adjust VOLUME to chec k the sound output.

SPEAKERS

A

ON

3, 5, 6

AUX PHONOTUNERCD/DVDTAPEMD

BASS

TREBLE

BALANCE

LOUDNESS

l0l

55

2

3

4

l0l

2

3

4

55

LR

FLAT

l

—30dB

2

2

I0

AUX

3

3

9

4

4

8

567

l0l

B

2

2

2

3

3

3

4

4

4

OFF

55

TAPE

MD

1

PURE DIRECT

CD/DVD DIRECT AMP

REC OUT

INPUT

CD/DVD

TUNER

PHONO

VOLUME

l6

20

l2

28

8

4

40

2

60

0

–dB

3

4 Begin recording on the tape deck (or MD recorder).
5 The sound of the recording can be monitored by

selecting the tape deck (or MD recorder) with the
INPUT selector.

MD

AUX

–

+

TAPE

CD/DVD

TUNERPHONO

E-10

MD

TAPE

CD/DVD

6 Listening to another source by selecting it with the

INPUT selector will not affect the recording.

AUX

–

+

l6

20

28

40

60

l2

8

4

2

0

–dB

–

–

+

VOLUME

TUNERPHONO

+

English

TAPE MONITOR

AX-396

STANDBY

POWER

ON

OFF

STANDBY/ON

1 Select the source you want to record.

–

+

MD

AUX

1

AUX PHONOTUNERCD/DVDTAPEMD

BASS

TREBLE

2

3

4

l0l

55

BALANCE

LOUDNESS

FLAT

l0l

l0l

l

2

3

4

2

2

3

4

4

55

LR

—30dB

2

I0

3

3

9

4

8

567

2

2

3

3

4

4

55

SPEAKERS

PHONES

A

B

ON

OFF

4

TAPE MONITOR

CD/DVD DIRECT AMP

REC OUT

TAPE

MD

AUX

INPUT

CD

TUNER

PHONO

1

VOLUME

l6

20

l2

28

8

4

40

2

60

0

–dB

2

3 Begin recording on the tape deck (or MD recorder).

TAPE

CD/DVD

TUNERPHONO

4 If the tape deck is used for recording, you can

monitor the sound of recording.
To monitor the sound of recording, light up the TAPE

MONITOR indicator by pressing TAPE MONITOR.

2 Play the source and then turn VOLUME up to check

Notes on recording

● The VOLUME, BASS, TREBLE, BALANCE, LOUDNESS
controls and CD/DVD DIRECT AMP switch (and PURE
DIRECT switch for AX-496 only) have no effect on the
material being recorded.

● Please check the copyright laws in your country to record
from records, compact discs, radio, etc. Recording of
copyright material may infringe on copyright laws.

AUX PHONOTUNERCD/DVDTAPEMD

the sound output.

l6

20

28

40

60

l2

0

–dB

Note

Turn off the TAPE MONITOR indicator when the recording
is finished by pressing TAPE MONITOR.

8

4

2

–

+

–

VOLUME

+

E-11

m Sound control

Adjusting the BALANCE control

Adjust the balance of the output volume to the left and right
speakers to compensate for sound imbalance caused by
speaker location or listening room conditions.

BALANCE

l0l

2

3

4

2

3

4

55

LR

Using the CD/DVD DIRECT AMP switch

You can enjoy the purest possible sound from your CD or
DVD player by pressing this switch. The indicator above it
lights up. With this function on, input signals from the CD or
DVD player are sent directly to the built-in special amplifier
for CD/DVD bypassing the INPUT selector, the BASS,

TREBLE, BALANCE and LOUDNESS controls (and the
TAPE MONITOR switch for AX-396 only), and then sent to

the power amplifier. This signal routing reproduces the
purest sound eliminating any alterations to the CD or DVD
signals.

CD/DVD DIRECT AMP

Adjusting the BASS and TREBLE controls

BASS

l0l

2

3

4

55

BASS: Turn this knob clockwise to increase (or counter-

clockwise to decrease) the low frequency
response.

TREBLE: Turn this knob clockwise to increase (or counter

clockwise to decrease) the high frequency
response.

TREBLE

2

3

4

l0l

2

3

4

55

2

3

4

Adjusting the continuously variable

LOUDNESS control

This control compensates for the human ears’ loss of
sensitivity to high and low-frequency ranges at low volume.
This control is adjustable to retain full tonal range at any
volume level.

LOUDNESS

1

2

3

4

FLAT

l

567

—30dB

I0

9

8

Set to the “FLAT” position.

Using the PURE DIRECT switch

AX-496 only

You can enjoy the purest possible sound from your audio
sources by pressing this switch. The indicator above this
switch lights up. With this function on, the audio signals
bypass the BASS, TREBLE, BALANCE and LOUDNESS
controls, thus eliminating any alterations to the audio
signals.

PURE DIRECT

Note

If both the CD/DVD DIRECT AMP and PURE DIRECT
switches are on, only the CD/DVD DIRECT AMP switch will
function.

l6

2

3

20

28

40

60

LOUDNESS

2

3

4

–dB

FLAT

l

567

l2

0

—30dB

I0

9

8

8

Set to the loudest listening level
that you would listen to.

4

2

Turn until the desired volume is
obtained.

WARNING

If the CD/DVD DIRECT AMP switch (or PURE DIRECT
switch for AX-496 only) is pressed to turn it on with the
LOUDNESS control set at a certain level, the sound will
suddenly increase and may damage your ears or the
speakers. (The LOUDNESS control function may be
bypassed.) For this reason, be sure to press the CD/
DVD DIRECT AMP switch (or PURE DIRECT switch for
AX-496 only) after lowering the volume or after checking
that the LOUDNESS control is properly set.

E-12

TROUBLESHOOTING

Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if
the instructions given below do not help, disconnect the power cord and contact your authorized YAMAHA dealer or service
center.

Problem

The unit cannot be turned on or
turns off suddenly soon after the
power is turned on.

This unit does not work normally.

No sound.

The sound suddenly goes off.

Only one of the speakers
produces the sound.

There is a lack of bass and no
ambience.

Sound “hums”.

The volume level is low while
playing a record.

The volume level cannot be
increased, or sound is distorted.

The sound is degraded when
listening with the headphones
connected to the compact disc
player or tape deck that are
connected with this unit.

Sound level is low.

The input source cannot be
changed, though the INPUT
selector is turned.

Using the BASS, TREBLE,
BALANCE and LOUDNESS
controls does not affect the tone.

The remote control does not
work.

The remote control does not
function properly.

Power cord is not plugged in nor
completely inserted.

The IMPEDANCE SELECTOR switch on
the rear panel is not set to either end.

There is an influence of strong external
noise (lightning, excessive static
electricity, etc.) or a misoperation on this
unit while using this unit.

Incorrect output cord connections.

Appropriate input source is not selected.

The SPEAKERS switches are not set
properly.

Speaker connections are not secure.
The protection circuit has been activated

because of short circuit etc.

Incorrect setting of the BALANCE
control.

Incorrect cord connections.

The + and – wires are connected in
reverse at the amplifier or speakers.

Incorrect cord connections.

No connection from the turntable to the
GND terminal.

The record is being played on a
turntable with an MC cartridge.

The component connected to the TAPE
OUT or MD OUT terminals of this unit is
turned off.

This unit is turned off or in the standby
mode.

The LOUDNESS control is functioning.

The CD/DVD DIRECT AMP switch is
ON.

The CD/DVD DIRECT AMP switch (or
PURE DIRECT switch for AX-496 only)
is ON.

The batteries of this remote control are
weak.

Wrong distance or angle.

Direct sunlight or lighting (of an inverter
type fluorescent lamp etc.) is striking the
remote control sensor of the main unit.

Cause

What to Do

Firmly plug in the power cord.

Set the switch to either end when this
unit is off.

Turn off this unit by pressing the
POWER switch. After about 30 seconds
have passed, turn on this unit and
operate this unit again.

Connect the cords properly. If the
problem persists, the cords may be
defective.

Select an appropriate input source with
the INPUT selector.

Set the corresponding SPEAKERS
switch to the ON position.

Secure the connections.
Turn off this unit by pressing the

POWER switch, and then turn this unit
on to reset the protection circuit.

Adjust it to the appropriate position.

Connect the cords properly. If the
problem persists, the cords may be
defective.

Connect the speaker wires in the
correct phase (+ and –).

Firmly connect the audio plugs. If the
problem persists, the cords may be
defective.

Make the GND connection between the
turntable and this unit.

The turntable should be connected to
this unit through the MC head amplifier.

Turn on the power to the component.

Turn on the power to this unit.

Set the LOUDNESS control to the FLAT
position.

Switch off the CD/DVD DIRECT AMP
switch.

The CD/DVD DIRECT AMP switch (or
PURE DIRECT switch for AX-496 only)
must be switched OFF to use those
controls.

Replace the batteries with new ones.

The remote control will function from a
maximum range of 6 meters and no
more than 30 degrees off-axis from the
front panel.

Reposition of the main unit.

English

E-13

SPECIFICATIONS

Power Section

Minimum RMS Output Power

8Ω, 20 Hz to 20 kHz, 0.019% THD

<AX-496> ......................................................85W+85W

<AX-396> ......................................................60W+60W

Maximum Output Power (EIAJ)
(1 kHz, 10% THD)

<AX-496>

8/6Ω........................................................................ 130/150W

<AX-396>

6Ω ................................................................................... 110W

Dynamic Power (IHF)

8/6/4/2Ω

<AX-496> ........................................ 130/150/185/220W

<AX-396> ........................................ 100/120/140/150W

DIN Standard Output Power
(4Ω, 1 kHz, 0.7% THD)

<AX-496>................................................................ 120W

<AX-396>.................................................................. 95W

IEC Output Power (8Ω, 1 kHz, 0.019% THD)

<AX-496>................................................................ 100W

<AX-396>.................................................................. 75W

Power Band Width

8Ω, Half power, 0.04% THD...................... 10 Hz to 50 kHz

Damping Factor

8Ω, 20 Hz to 20 kHz .....................................................240

Frequency Response .................... 20 Hz to 20 kHz50.5 dB

Total Harmonic Distortion (20 Hz to 20 kHz)

CD/DVD to SP OUT (8Ω, Half power).....................0.008%

Signal-to-Noise Ratio (IHF-A Network)

CD/DVD (Input Shorted, CD/DVD DIRECT AMP: ON)

............................................................................... 110 dB

PHONO (Input Shorted) .......................................... 88 dB

Residual Noise (IHF-A Network)

CD/DVD DIRECT AMP: ON..................................... 35 µV

Control Section

Input Sensitivity/Impedance

CD/DVD, etc. ...............................................150 mV/47 kΩ

PHONO ........................................................ 2.5 mV/47 kΩ

Output Level

REC OUT ................................................... 150 mV/1.6 kΩ

Headphone Output.............................................0.25V/680Ω

Channel Separation (1 kHz/10 kHz)

CD/DVD (Input 5.1 kΩ Terminated) ................ 65 dB/50 dB

Tone Control Characteristics

BASS ........................................................ 510 dB (20 Hz)

TREBLE.................................................. 510 dB (20 kHz)

Continuous LOUDNESS Control

Attenuation ................................................ –30 dB (1 kHz)

General

Power Supply

[Europe and U.K. models] ......................... AC 230V, 50 Hz

[Australia model]....................................... AC 240V, 50 Hz

[China model] ........................................... AC 220V, 50 Hz

[General model] .............. AC 110/120/220/240V, 60/50 Hz

Power Consumption

<AX-496>.................................................. Approx. 210W

<AX-396>.................................................. Approx. 150W

AC Outlets

3 SWITCHED OUTLETS

[Europe, China and General models]..... 100W max. total

1 SWITCHED OUTLET

[U.K. and Australia models] .................... 100W max. total

Dimensions (W x H x D)....................... 435 x 151 x 391 mm

(17-1/8” x 5-15/16” x 15-3/8”)

Weight

<AX-496>.................................................. 9.5 kg (21 lbs.)

<AX-396>......................................... 8.7 kg (19 lbs. 3 oz.)

Accessories.................................................. Remote control

Batteries

E-14

Specifications subject to change without notice.

YAMAHA ELECTRONICS CORPORATION, USA 6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.
YAMAHA CANADA MUSIC LTD. 135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA
YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR, 22-34, 25462 RELLINGEN, BEI HAMBURG, F.R. OF GERMANY
YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE
YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND
YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VASTRA FRÖLUNDA, SWEDEN
YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA
