Yale T1L Installation And Programming Instructions

®
Key Free Touchscreen Deadbolt
Yale Real Living
Installation and Programming Instructions
®
with
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DAMAGE TO
THE PRODUCT AND VOID THE FACTORY WARRANTY
#7 wood & #8-32 machine x 20mm
Combination screws
1
P/N AYRD-120-INST-FUL Rev G
#8-32 x 5/16"
Machine screws
M6x47mm
Long through bolt
Preparing Door
2
P/N AYRD-120-INST-FUL Rev G
1
x4
Installing Latch & Strike Plate
2-3/8" position
d faute
2-3/4" position
O
optional
Press
Bolt must be in retracted (unlocked) position. Note
horizontal orientation of
mechanism.
Pull
3
P/N AYRD-120-INST-FUL Rev G
2
Installing Touchscreen Escutcheon
Outside of DoorInside of Door
Bolt must be in retracted (unlocked) position. Note horizontal orientation
!
of mechanism.
4
P/N AYRD-120-INST-FUL Rev G
3
x2
Installing Interior Mounting Plate
Loosen screw to remove cover.
5
P/N AYRD-120-INST-FUL Rev G
4
Attaching the Cable Assembly
6
P/N AYRD-120-INST-FUL Rev G
5
x3
Installing Interior Escutcheon
7
P/N AYRD-120-INST-FUL Rev G
Testing Operation
!
Bolt must be in retracted
(unlocked) position before
installing AA batteries.
8
P/N AYRD-120-INST-FUL Rev G
Handing the Lock
Press .
Enter new Master PIN code (4-8
digits). Press to complete.
After entering the Master PIN
code, press any key to complete
handing.
9
P/N AYRD-120-INST-FUL Rev G
6
Installing Cover
Congratulations, you've installed the Yale Real Living
Key Free Touchscreen Deadbolt T1L with ! Turn
sheet over for Programming Instructions to customize
your product.
®
10
P/N AYRD-120-INST-FUL Rev G
Programming Instructions
Lock-out Mode-
Touchscreen Flashes
Low Battery Warning Flashes RED
Failsafe 9 volt Battery Connection (Use Alkaline battery)
Master PIN Code must be created before any further programming. Max User Codes = 100
Warning: Changes or modifications to this device, not expressly approved by Yale Security Inc. could void the user's authority to operate the equipment.
11
P/N AYRD-120-INST-FUL Rev G
1
Creating Master PIN Code
Press
Enter 4-8 digit Master PIN Code.
Press
12
P/N AYRD-120-INST-FUL Rev G
2
Creating User PIN Codes
Master PIN code must be created first. *Max User Codes = 100
Enter Master PIN code
Press
Press
Press
Press
Press
Enter 4-8 digit PIN code
Press
13
P/N AYRD-120-INST-FUL Rev G
3
Unlocking Door with PIN Code
Enter PIN
Press
"Unlock"
Code Chart
PIN Code Management (With Network Module - Up to 100 Users)
User Type
Master
User ___
User ___
User ___
User ___
User ___
User ___
User ___
User ___
User ___
User ___
Duplicate if necessary
User Name User #
PIN Code
User ___
User ___
User ___
User ___
User ___
14
P/N AYRD-120-INST-FUL Rev G
Resetting Lock to Factory Default
When lock is reset to factory defaults all user codes (including the Master PIN code*) are deleted and all programming features are reset to original default settings (see "Factory Default Settings").
1. Remove the battery cover.
2. Remove the batteries.
3. While pressing the reset button (minimum of 3 seconds) reinstall batteries. Release reset button.
4. Replace battery cover.
Upon reset, Master Code creation is the only option available and must be performed prior to any other programming of the lock. NOTE: After setting the Master Code, press any key to complete handing of the lock.
Enrolling Lock In Network
®®
Your network controller first needs to be in enrollment or exclusion mode for the lock to be enrolled or removed from network.
Once you put the controller in the enrollment or exclusion mode, the lock can be enrolled or removed in the Z-Wave network two ways - through the touchscreen using the #7 key (see Programming Through Menu Mode) or by pressing the button.
To enroll lock using the button option:
1. Remove the battery cover.
2. Press button and hold until unit beeps two (2) times.
3. Release button and network joining automatically begins.
4. Replace battery cover.
To remove lock using the button option:
1. Remove the battery cover.
2. Press button and hold until unit beeps five (5) times.
3. Release button and network removal automatically begins.
4. Replace battery cover.
®
15
P/N AYRD-120-INST-FUL Rev G
Definitions
All Code Lockout Mode: This feature is enabled by the Master code. When enabled, it restricts all user (except Master) PIN code access. When attempting to enter a code while the unit is in Lockout, the touchscreen flashes 8 times and the lock beeps 3 times as well.
Audio Mode: Disable (3)Choosing in Audio mode shuts off the code confirmation tone play-back for use in quiet areas. Audio mode is enabled or disabled through feature programming by the Master code.
Automatic Re-lock Time: After a successful unlock, the unit will automatically re-lock after thirty (30) seconds.
Low Battery: When battery power is low, the Low Battery Warning Indicator flashes RED. If battery power is
completely lost, use the 9Volt battery override. To use the 9V battery override apply 9V battery, in either direction, to terminals below the touchscreen for backup power option. Wake up the lock and enter your pin code to unlock the door.
Master PIN Code: It must be createdThe Master PIN code is used for programming and for feature settings. prior to programming the lock. The Master code will also operate (unlock/lock) the lock.
Network Setting: This setting is available thru the main Menu (7) and allows the lock to connect with a network
controller. It is also available through the wireless button on the interior escutcheon .
One Touch Locking: When the latch is retracted, activating the touchscreen will extend the latch (during Automatic Re-lock duration or when Automatic Re-lock is disabled).
Shutdown Time: The unit will shutdown (flashing touchscreen) for sixty (60) seconds and not allow operation after the wrong code entry limit has been met.
Tamper Alert: Audible alarm sounds if attempting to forcibly remove outside lock from door.
User PIN Code: The User code operates the lock. Maximum number of user codes is 100.
Wrong Code Entry Limit: After five (5) unsuccessful attempts at entering a valid PIN code, the unit will shut
down and not allow operation.
16
P/N AYRD-120-INST-FUL Rev G
Feature Programming Through Menu Mode Using Master PIN code*
1. Enter the 4-8 digit Master PIN code followed by the
2. Enter digit corresponding to the function to be performed followed by the key.
*The Master PIN code must be registered prior to any other programming of the lock.
12
M
Master PIN Code Setting
User PIN Code Registration
Advanced Lock Settings
Default settings in bold.
Audio Mode
Enable
M
Register
Delete
Automatic Re-lock
One Touch Locking
Handing the Lock
key.
User Number (PIN) 1~100: with network module
4~8 Digits
U
U
Enable
Disable
Enable
Disable
Performs automatic handing of the lock.
N/A
All Code Lockout Mode
Network Setting
Factory Settings
Settings
Master PIN Code
Automatic Re-lock
One Touch Locking
Audio Enabled
Automatic Re-lock Time Wrong Code Entry Limit
Shutdown Time 60 Seconds
Disable
Factory Setting
Registration
For quiet areas, select Disable (3) in Audio Mode.
Enable
Disable
Join the network
Exit the network
required*
Disabled
Enabled
30 Seconds
5 Times
*The Master PIN code must be registered prior to any other programming of the lock.
17
P/N AYRD-120-INST-FUL Rev G
Programming Troubleshooting
Symptom
Lock does not respond – door is open and accessible.
Lock does not respond – door is locked and inaccessible.
Unit chimes to indicate code acceptance, but the door will not open.
Unit operates to allow access, but will not automatically re-lock.
PIN codes will not register.
Suggested Action
Press each touchscreen key for response when pressed.
• Check batteries are installed and oriented correctly (polarity)
• in the battery case. Check batteries are in good condition; replace batteries*
• if discharged. Check to see if cable is fully connected and not pinched.
Batteries may be completely discharged.
• Apply 9V battery to terminals below the touchscreen for
• backup power option.
Check to see if there is another locking device on the door.
• Check the door gaps for any foreign objects between door
• and frame.
Check that the cable is firmly connected to the PC board.
Check to see if Auto Re-lock Mode is enabled.
• If low battery indicator is lit (see below), change batteries*.
PIN codes must consist of 4 to 8 digits to register.
• The same PIN code cannot be used for multiple users.
• Registration/management of PIN codes is set by the
• authority of the Master Code.
Contact the Master user.
• User codes must be entered within 20 seconds or the
• process will have to be restarted.
Check mark
or gear cannot be used as part of the
PIN code.
Upon entering a PIN code and pressing the key, the lock gives a series of beeps, flashes red 7 times, and
• All Code Lockout Mode is enabled.
• Only the Master can enable/disable All Code Lockout Mode.
• Contact the Master user.
does not unlock. Upon entering a PIN code
and pressing the key, there are different tones.
The unit operates, but it makes no sound.
The unit displays inter­mittent RED flashes.
• Check to see if the lock is set to All Code Lockout Mode.
• Setting/managing All Code Lockout Mode is done through Master Code only. Contact the Master user.
Enable Audio Mode.
• This is the Low Battery indicator alerting that it is time to replace the batteries. Replace all four (4) batteries* with new AA Alkaline batteries.
Upon entering a PIN code and pressing the key,
the unit responds with a series of beeps and the
The digits entered were incorrect or incomplete. Re-enter the correct code followed by the check mark (*) key.
touchscreen flashes three times.
* When batteries are replaced, Network locks have a real time clock that will be set through the User Interface (UI); it
is recommended to verify correct date and time particularly those locks operating under Daylight Saving Time (DST).
18
P/N AYRD-120-INST-FUL Rev G
FCC:
FCC ID: U4A-YRIZW1US (Z-Wave )
®
Model(s): YRD120-ZW-US This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful Interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
Industry Canada: Canadian ID: 6982A-YRIZW1US (Z-Wave )
®
Model(s): YRD120-ZW-US This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Cet appareillage numérique de la classe B répond à toutes les exigences de l'interférence canadienne causant des règlements d'équipement. L'opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l'interférence nocive, et (2) ce dispositif doit accepter n'importe quelle interférence reçue, y compris l'interférence qui peut causer l'opération peu désirée.
Section 7.1.2 of RSS-GEN Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. En vertu des règlements d'Industrie Canada, cet émetteur radio ne peut fonctionner avec une antenne d'un type et un maximum (ou moins) approuvés pour gagner de l'émetteur par Industrie Canada. Pour réduire le risque d'interférence aux autres utilisateurs, le type d'antenne et son gain doivent être choisies de façon que la puissance isotrope rayonnée équivalente (PIRE) ne dépasse pas ce qui est nécessaire pour une communication réussie.
Section 7.1.3 of RSS-GEN This Device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme avec Industrie Canada RSS standard exemptes de licence(s). Son fonctionnement est soumis aux deux conditions suivantes: 1) ce dispositif ne peut causer des interférences, et 2) cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement du dispositif.
19
P/N AYRD-120-INST-FUL Rev G
NOTE TO INSTALLER AND CONSUMER While Yale has included several features to prevent lockout (9-
®
Volt battery jumper, low battery warnings), it is still possible for a lockout situation to occur. Because this product does not have a mechanical override (a key), Yale recommends to use
®
this product in an environment where there are additional entry points into the dwelling.
Product Support Tel 800.810.WIRE (9473) • www.yalelocks.com
Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company.
Yale® and Yale Real Living® are registered trademarks of Yale Security Inc., an ASSA ABLOY Group company.
Copyright © 2017, Yale Security Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
YALE, with its unique global reach and range of products, is the world's favorite lock
– the preferred solution for securing your home, family and personal belongings.
ASSA ABLOY is the global leader in door opening solutions,
dedicated to satisfying end-user needs for security, safety and convenience.
20
P/N AYRD-120-INST-FUL Rev G
