Xerox WORKCENTRE 5638, WORKCENTRE 5655, WORKCENTRE 5675, WORKCENTRE 5665, WORKCENTRE 5645 User Manual [tr]

®

Printer Drivers Guide

For Windows

Release 7.0

Prepared by:

Xerox Corporation
Global Knowledge & Language Services
800 Phillips Rd., Building 845-17S
Webster, NY 14580-9791 USA

Copyright © 2006, 2007 by Xerox Corporation. All rights reserved.

Printed in the United States of America.

XEROX®, CentreWare®, WorkCentre and the identifying product names and numbers herein are trademarks of
XEROX CORPORATION.

Other product names and images used in this guide may be trademarks or registered trademarks of their respective
companies and are hereby acknowledged.

Document Version: 1.2 - June 2007

Table of

Contents

Chapter 1 CentreWare Printer Drivers for Microsoft Windows . . . . . . . . . . . . . . . . 1-1

What’s Included in this Release? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Printer and Fax Driver Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Types of CentreWare Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

PostScript . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

PCL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Obtaining CentreWare Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

CentreWare Print and Fax Services CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

Downloading from the Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Xerox System PPD Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

CentreWare Printer Driver Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Xerox Printer Driver Installation Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Admin Config Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

TIFF Submission Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Xerox Font Management Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Print and Fax Driver Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

CentreWare Printer Drivers Guide for Windows (This guide) . . . . . . . . . . . . . . . . . . . . . . . 1-6

Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Quick Reference Cards for Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6

Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Internet Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7

Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Additional Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Chapter 2 Installing Windows Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Xerox Printer Driver Installation Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Installing Printer Drivers on Windows Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Direct Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Custom Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Point and Print Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Direct Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Customizing the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

XeroxInstallerAdmin.xml . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10

Considerations for Enterprise Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Clustering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Citrix MetaFrame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Add Printer Driver Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

Point and Print Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

iii

Installing Printer Drivers on Other Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

Configuring Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Preconfiguring Default Driver Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Configuring Installable Options at the Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17

About Bi-Directional Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21

Status Dialog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21

Bi-Directional Driver Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-22

Uninstalling Windows Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23

For Windows 2000 / XP / Server 2003 / Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23

Chapter 3 Printer Driver Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Driver Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

General Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Default Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Driver Help System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Quick Reference Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Chapter 4 Installing the Xerox Font Management Utility . . . . . . . . . . . . . . . . . . . . . 4-1

Installing the Xerox Font Management Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Accessing the Xerox Font Management Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Using the Xerox Font Management Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Uninstalling the Xerox Font Management Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Chapter 5 Installing the TIFF Submission Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Workstation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Installing the TIFF Submission Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Accessing the TIFF Submission Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Using the TIFF Submission Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Uninstalling the TIFF Submission Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Chapter 6 Problem Solving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Troubleshooting a Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

Common Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Adobe Acrobat Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Booklet and Multiple-Up (N-Up) Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Euro Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

PDF Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Microsoft Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

PCL Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Sample Set Not Supported in FrameMaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

Watermarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

WordPerfect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6

iv

Chapter 1

CentreWare Printer Drivers for Microsoft Windows

CentreWare is software that brings the power of your Xerox systems to your desktop. The interactive
drivers om CentreWare make printing from the desktop simple to perform and easy to understand.

With this guide, administrators can install and configure CentreWare printer drivers and general users
can increase their productivity using the Xerox system’s printing options.

What’s in this chapter:

 What’s Included in this Release? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

 Printer Driver Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

 Types of CentreWare Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

 Obtaining CentreWare Drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

 Xerox System PPD Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

 CentreWare Printer Driver Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

 Print and Fax Driver Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

 Internet Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

 Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

1-1

What’s Included in this Release?

The CentreWare 7.0 release of the WorkCentre printer drivers supports the following new features
and / or hardware.

 PostScript and PCL drivers for the following models:

 WorkCentre 5632

 WorkCentre 5638

 WorkCentre 5645

 WorkCentre 5655

 WorkCentre 5665

 WorkCentre 5675

 WorkCentre 5687

 Upgraded user interface and nomenclature for a consistent, coherent Xerox customer experience

 TIFF Submission Tool

 Font Management Utility

 Xerox Admin Config Wizard

 Xerox Printer Driver Installation Utility

 Unicode Printing Support - Unicode fonts are downloaded to the device and converted to appropriate

PDL (PS or PCL) using the Font Management Utility.The downloaded fonts are resident on the
device hard drive and do not need to be sent with each print job containing Unicode characters.

 Additional Covers functionality - Drivers now support Front Only, Back Only, Front and Back

Covers, Imaged and Blank Covers, as well as all supported Media Types, Colors, and Sizes.

 Print quality improvements for multiple media. This feature provides optimal image quality

adjustment for multiple medias requested within a print job

 PCL 1200dpi printing

 Ability to print on tabs

 New Media Type - Rough Stock

 Variable hole punch capability: 2/3 hole and 2/4 hole

 Support for four-position stapling (Letter LEF, A4 LEF, Ledger SEF, and A3 SEF)

 Support for High Volume Office Finisher and High Volume Professional Finisher

 Paper Feed Platform (PFP) - a high volume paper feed tray

 Finishing capabilities (optional on some models). Finishing options may include: Stapling, Hole

Punching, Folding, Booklet Creation, and Offsetting. Features vary based on the finishing unit.

 Feature Facts and Feature Finder quick reference cards describe selected printing options and where

to locate them in the printer drivers.

 Bi-Directional printer drivers that automatically configure the driver with the installable options,

report the system’s current status, provide information on active jobs, and a history of the last
twenty-five jobs on your Xerox system.

Note: Windows 9x and NT drivers will no longer be delivered.

1-2 CentreWare Printer Drivers for Microsoft Windows

Printer Driver Overview

A printer driver makes documents created with specialized software applications (word processing,
spreadsheets, graphics) compatible with a specific printer. Each type of printer requires unique
commands to print correctly and to enable special features. For these reasons, different types of printers
require their own printer drivers to operate correctly.

With CentreWare printer drivers, you can print from your workstation to a Xerox system in a network
environment. CentreWare drivers contain a variety of feature options that you can use to customize your
print jobs.

Types of CentreWare Printer Drivers

The CentreWare printer drivers are available in PostScript 3, PCL 5c, and PCL 6c printing formats.

PostScript

PostScript gives you greater ability to scale and manipulate images; it offers more precision with
high-end graphics. PostScript also provides you with different types of error-handling and font
substitution options.

PCL

PCL (Printer Command Language) generally has fewer advanced features than PostScript. However,
using PCL enables you to process most jobs faster.

Printer Driver Overview 1-3

Obtaining CentreWare Drivers

CentreWare Print and Fax Services CD

The installation .inf files for the Xerox system printer drivers are available in the Drivers folder on the
CentreWare Print and Fax Services CD. Browse to the Drivers folder and locate the drivers you need.

NOTE: Driver availability may vary by printer model or operating system.

For updates and additional information, visit the Xerox Web site.

Downloading from the Web

CentreWare printer drivers can be downloaded from the Xerox Web site at www.xerox.com. The
installation files for all Xerox system models are also available from the Web site.

For more information on downloading drivers, see Step 1 on page 2-4.

Xerox System PPD Files

A PostScript Printer Description (PPD) file is a readable text file that provides a uniform approach to
specifying special features for printer drivers that interpret PostScript.

Xerox provides PostScript PPDs for use with generic Windows 2000 / XP / Server 2003 / Vista
PostScript printer drivers. These PPDs are available on the CentreWare CD or from the Xerox Web site.

1-4 CentreWare Printer Drivers for Microsoft Windows

CentreWare Printer Driver Applications

The following applications are included on the CentreWare Print and Fax Services CD:

 Xerox Print Driver Installation utility

 Admin Config Wizard

 TIFF Submission Tool

 Xerox Font Management Utility

Xerox Printer Driver Installation Utility

This utility is for anyone who would like to install printer drivers directly onto a PC or network server.

NOTE: You may require administrator rights to perform the installation.

Admin Config Wizard

The Admin Config Wizard is for system administrators who would like to set up standardized
configuration files, enabling users to install printer drivers quickly and easily.

TIFF Submission Tool

With the TIFF Submission Tool, you can submit TIFF (Tagged Image File Format) files directly to a
Xerox system for printing. TIFF files print faster when they are sent to the Xerox system in this format.

NOTE: You must have a TIFF interpreter on your Xerox system to use this tool.

See Installing the TIFF Submission Tool on page 5-1 for more information.

Xerox Font Management Utility

The Xerox Font Management Utility is a tool used for managing fonts and printer lists. Fonts may be
viewed, printed, or downloaded to printers, and your downloaded (non-resident) fonts can be exported to
a file. Printers can be added or deleted from a printer list which is used for adding and deleting fonts
from one or multiple printers.

See Installing the Xerox Font Management Utility on page 4-2 for more information.

CentreWare Printer Driver Applications 1-5

Print and Fax Driver Documentation

The CentreWare printer drivers include the following documentation, designed to get you up and running
quickly and easily.

CentreWare Printer Drivers Guide for Windows (This guide)

This guide is intended for anyone who installs and configures CentreWare printer drivers and wants to
know more about the features available in the printer drivers.

The CentreWare Printer Drivers Guide is available on the CentreWare Print and Fax Services CD in
electronic (PDF) format. You can download a free Adobe Acrobat Reader from Adobe at

www.adobe.com.

Help

The Help system is the primary source for information about using the printer drivers. You can access the
Help system through the Help buttons in the driver. Included in the Help system are feature descriptions,
step-by-step procedures, Xerox system information, problem-solving information, and support
information.

Quick Reference Cards for Printer Drivers

Included in this guide are Quick Reference Cards for printer drivers:

 Feature Finder Card - Two Quick Reference cards, one for PostScript and one for PCL, help you

locate the many printing options available through the printer driver to make printing easier.

 Feature Facts Card - This single Quick Reference card describes selected printing options, such

as Watermarks, Booklet Layout, and Stapling.

The Quick Reference Cards are provided in Adobe Acrobat PDF format and are included on the
CentreWare Print and Fax Services CD.

1-6 CentreWare Printer Drivers for Microsoft Windows

Support

Support for your CentreWare printer drivers is available both online and by telephone.

Internet Support

Please visit the Xerox Web site (www.xerox.com) for product support information, product overviews,
updates, and links to specific product sites. Printer drivers and PPDs can also be downloaded by clicking
Support & Drivers.

Telephone Support

For additional assistance, you may contact the Xerox Welcome Center by telephone to speak with a
Product Support Analyst. Locate your Xerox system serial number, and record it in the space below
before you make your call.

Xerox System Serial Number:

The Xerox Welcome Center telephone numbers are listed in the following table. If the Welcome Center
telephone number for your country is not listed, it will be provided to you when your Xerox system is
installed. For future reference, please record the telephone number in the space provided below.

Welcome Center Telephone Numbers:

UNITED STATES 800-821-2797

UNITED STATES (TTY) 800-855-2880

CANADA 800-939-3769 (800-93-XEROX)

OTHER

Additional Tips

Additional tips and technical information for printer drivers are available at the Xerox Web site. Click
Support & Drivers, identify your product, and click the Documentation link. The documents listed in
this section cover specific issues that may require special procedures or application notes regarding the
operation and configuration of your Xerox system.

Support 1-7

1-8 CentreWare Printer Drivers for Microsoft Windows

Chapter 2

Installing Windows Printer Drivers

The CentreWare printer drivers support the special features and functions of Xerox systems, enabling
fast, efficient printing from your desktop. This chapter provides installation instructions for all current
Windows environments.

What’s in this chapter:

 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

 Installing Printer Drivers on Windows Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

 Direct Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

 Customizing the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

 Considerations for Enterprise Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

 Point and Print Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

 Installing Printer Drivers on Other Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

 Configuring Printer Drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

 Preconfiguring Default Driver Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

 Configuring Installable Options at the Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

 About Bi-Directional Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18

 Uninstalling Windows Printer Drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20

2-1

Requirements

Printer Drivers

The Xerox printer drivers require:

 A maximum of 32 MB of available hard disk space per CentreWare Windows printer driver.

 Internet Explorer 5.5 or higher installed on the workstation for Windows 2000, XP, Server 2003, or

Vista drivers.

Xerox Printer Driver Installation Utility

The Xerox Printer Driver Installation Utility and Admin Config Wizard require:

 Administrator privileges in Windows 2000 / XP / Server 2003 / Vista.

 Internet Explorer 5.5 or higher.

 Service Pack 2 installed on Windows XP systems.

 Service Pack 4 installed on Windows 2000 systems.

2-2 Installing Windows Printer Drivers

Installing Printer Drivers on Windows Networks

In Windows environments, you can install a Xerox printer driver by using a direct installation, a custom
installation, or a Point and Print installation.

Direct Installation

Use the Xerox Printer Driver Installation utility to install Xerox printer drivers for your network printers
quickly and easily. If you have the
where the contents of the CD have been saved, you need only run the installer once per Xerox system to
install the drivers for multiple page description languages (PDLs) directly onto a PC or print server.

NOTE: You can use the Add Printer Wizard to install Xerox printer drivers, but you must install each

driver separately.

Custom Installation

System administrators can use the Admin Config Wizard to pre-configure the driver installation. Use
this wizard to control settings such as printer detection method, default printer assignment, and network
printer sharing. Set multiple installation configurations to distribute and apply the settings to individuals
or groups, as appropriate.

Copy the contents of the CentreWare Print and Fax Services CD to your network. Then start the Admin
Configuration Wizard to set up a configuration file. (
perform a custom installation.)

CentreWare Print and Fax Services CD or know the network location

See Customizing the Installation on page 2-7 to

Point and Print Installation

Copy the contents of the CentreWare Print and Fax Services CD to your network. Install the drivers
locally and modify the device settings and document settings (

Settings on page 2-15). Then copy the new configurations to the server for enterprise use (see Point and
Print Installations on page 2-14).

NOTE: It is possible to upgrade a Windows driver without uninstalling the previous version. However,

the impact of such an upgrade on system performance can be unpredictable. The most reliable way
to upgrade is to uninstall the old drivers and perform a clean installation of the new ones. For
information on uninstalling drivers,

see Uninstalling Windows Printer Drivers on page 2-20.

see Preconfiguring Default Driver

Installing Printer Drivers on Windows Networks 2-3

Direct Installation

You can install the CentreWare printer drivers from the CD, from network location, from a URL, or
intranet address.

NOTE: After you start the installer, it detects the operating system of the server or workstation. If that

operating system does not meet the product requirements, the installer issues a message and exits.
This behavior would occur, for example, if you attempted to install drivers housed on a Windows 2000
server onto a client running Windows 3.1.

To install Windows printer drivers:

1 Do one of the following:

If installing from: Then:

CD-ROM Insert the CentreWare Print and Fax Services CD into the CD-ROM drive. The

AutoRun program displays the available selections. Continue with Step
–or–
If the AutoRun is disabled on the workstation, open My Computer and
double-click the CD-ROM drive.

3.

Internet

a) Open a browser window and access www.xerox.com.

b) Click Support & Drivers.

c) Identify your product.

d) Click Drivers and Downloads under the printer model.

e) Choose the desired operating system and language, then click Go. The

available driver options are updated.

f) From the list of drivers, click the appropriate driver to download.

g) Read the End User License Agreement and click Accept.

h) Click Save from the File Download dialog.

i) Choose a location to download the file and click Save.

intranet Open a browser window and type the appropriate intranet address, such as

http://xyz.mycompany.com.

network location Use Windows Explorer to find the CentreWare installation files.

2 Double-click install.exe. The AutoRun program displays the available selections.

3 Click Install Drivers.

4 An administrator may have created a screen containing customized instructions for the site. If such a

screen appears, record and follow any posted instructions. Then click Next.

5 The installer scans supported direct connections as well as the local network subnet for printers. The

results appear on the Select Printer screen.

Do one of the following:

 If the printer that you want to install appears in the list of discovered printers, click Select From

the Following Discovered Printers and select the printer.

 If the printer does not appear in the list of discovered printers, do one of the following:

2-4 Installing Windows Printer Drivers

 Click Advanced Search and choose an automatic or manual search method.

Search Action

Automatic The installer detects and searches for all printers on all available subnets.

Manual

 Enter the gateway and subnet mask for the search directly,

–or–

 Use Previous Search. Select a search that the installer has previously

performed from a drop-down list.

After making your selections, click Search.

 Choose Enter Printer’s IP address, DNS name, or UNC path. Enter the information or

browse for one of those identifiers.

NOTE: Examples of printers that may not appear on the discovered printers list or search results,

regardless of operating system, include printers connected to a different subnet or printers on a
print queue.

Using the discovered printers list, IP address, or DNS name to identify the printer results in the
creation of a local print queue, while using the UNC name associates the printer with an existing
queue.

If you enter an invalid IP address or device discovery fails, the Select Printer Configuration dialog
appears and enables you to choose the correct driver to install from the list of supported printers.

6 Click Options to configure any of the following settings:

 Language - Select the language in which to run the installer.

 Driver Selection (PDL) - Choose at least one of the following PDLs: PCL 5e, PCL 6, or

PostScript (all printers). The PostScript driver is the default selection. For more information on
driver selection, see

Types of CentreWare Printer Drivers on page 1-3.

NOTE: This setting does not impact installation of a printer that is assigned to a network queue.

 Driver Settings - Select any of the following options:

 Share the printer on the network (requires Windows 2000 / XP / Server 2003 / Vista).

 Convert the printer’s DNS name to an IP address.

 Set the printer as your Windows default.

 Download driver files from the Internet (You must be connected to the Web Site during

installation).

Click OK to exit Options.

Direct Installation 2-5
