Xerox WorkCentre 5325, WorkCentre 5330, WorkCentre 5335 PDL Reference Guide

Download

PDL Reference Guide for the

dc11cc0479

August 8, 2011

Xerox WorkCentre 53xx Series

Customer Tip

Accessing Extended Features

Overview

This document enables you to access the extended features of the WorkCentre 5325/5330/5325 in environments that do not have a custom print driver.

Note: Some of the commands and syntax used in this document requires familiarity with either PostScript (PS) or Printer Command Language (PCL).

This document provides the Printer Description Language (PDL) commands and syntax for each feature. The following tables are also included:

 PostScript tables that describes the PostScript features the WorkCentre supports and the syntax to use the

feature.

 PCL tables that describes the PCL features the WorkCentre supports and the syntax to use the feature.

This document is not intended as a PS or PCL reference manual.

Using this Guide

1. Search the Feature Table to determine whether the feature you wish to use is supported.

2. Verify that the feature is supported by the platform. For example, the WorkCentre must have the Finisher

option installed to use stapling commands.

3. Following across the table to find the syntax listed for the PDL examples shown. Read the

Dependencies/Caveats section.

dc11cc0479 Customer Support Page 1

Accessing Extended Features ................................................................................................................................................. 1

Overview ................................................................................................................................................................................... 1

Using this Guide .................................................................................................................................................................... 1

Table of Contents ........................................................................................................................................................................ 2

XRXBegin .................................................................................................................................................................................. 3

XRXEnd ...................................................................................................................................................................................... 3

PCL ............................................................................................................................................................................................... 3

PCL/PJL Implementation ......................................................................................................................................................... 4

Job Name ................................................................................................................................................................................ 4

Custom Paper Size ............................................................................................................................................................... 4

Media Size ............................................................................................................................................................................... 4

Media Source ......................................................................................................................................................................... 6

Output Location ................................................................................................................................................................... 6

Stapling .................................................................................................................................................................................... 6

Punch ......................................................................................................................................................................................... 6

Folding ...................................................................................................................................................................................... 6

Booklet ...................................................................................................................................................................................... 7

Quantity ................................................................................................................................................................................... 7

Resolution ................................................................................................................................................................................ 7

Bits Per Pixel ........................................................................................................................................................................... 7

Copies ....................................................................................................................................................................................... 7

Simplex ..................................................................................................................................................................................... 7

Duplex ....................................................................................................................................................................................... 8

Orientation ............................................................................................................................................................................. 8

Force short edge feeding ................................................................................................................................................. 8

Job Mode ................................................................................................................................................................................. 8

Job Type ................................................................................................................................................................................... 8

Interleaving Paper ............................................................................................................................................................... 8

Job Based Accounting / Auditron ................................................................................................................................. 8

Delay Print ............................................................................................................................................................................... 9

Banner Sheet ......................................................................................................................................................................... 9

PCL/PJL Feature Dependencies/Caveats ........................................................................................................................... 9

Examples ......................................................................................................................................................................................... 9

PJL/PCL Template ................................................................................................................................................................. 9

Sample PJL Headers......................................................................................................................................................... 10

Supported PostScript Fonts .................................................................................................................................................. 12

Supported PCL5 Fonts ............................................................................................................................................................ 14

Additional Information .......................................................................................................................................................... 15

dc11cc0479 Customer Support Page 2

XRXBegin

When the interpreter receives this command it begins to parse PJL COMMENT commands to check for Xeroxspecific commands until it receives the command to stop parsing.

PJL COMMENT Command DSC Comment Command

@PJL COMMENT XRXbegin %%XRXbegin

XRXEnd

When the interpreter receives this command it stops parsing PJL COMMENT commands.

PJL COMMENT Command DSC Comment Command

@PJL COMMENT XRXend %%XRXend

PCL

This WorkCentre supports PCL5e and PCL XL Color emulations that enable the features listed in the following table.

Feature Description

Job Name The value for Job Name is stored for printing on the banner

page.

Custom Paper Size

Media Size This command specifies the size of media on which to print

Media Source This command specifies the tray to supply the job’s media.

Output Location Indicates the output bin where the print job is sent.

Stapling This command indicates use and location of staple(s).

Punch This command indicates hole punches for a print job on a

Folding This command indicates to fold the print job.

Booklet This command enables you to print documents as small

Quantity

Resolution This command sets the resolution value.

Bits Per Pixel This command sets the color depth value.

This command specifies the customer designated media size.

the job.

device with hole punch capability.

booklets. The pages are reordered sequentially and are oriented so that when they are folded, the paging is correct.

Use this command to specify the number of collated sets of a document.

Copies Use this command to specify the number of uncollated sets of

a document in a print job.

Simplex Deliver one-sided output

Duplex Deliver two-sided output

Orientation Landscape or Portrait

dc11cc0479 Customer Support Page 3

5.5-inch x 720 decipoints/inch = 3960.

ROC16K = 16K (194 x 267mm) †

Feature Description

Force Short Edge Feeding

Job Mode Specify Job Mode

Job Type

(Secure Print / Proof Print / Box Print)

Interleaving Paper

(Transparency Separator)

Job Based Accounting

The values indicate the feed edge to use.

You can specify Confidential Print or Proof Print

Insert blank sheet between transparency sheets.

To support the Job Based Accounting feature.

Auditron This command sends the user’s pin number to support Internal

Delay Print Delays printing a job until the time specified by the command.

PCL/PJL Implementation

This section describes the PCL commands for specific features. This table lists each feature and the PCL syntax that is required to use the feature.

Feature Implementation Values

Job Name

Custom Paper Size

＠PJL SET JOBNAME = “jobname-string”

Not in PJL command.

You have to specify by PCL :

<ESC>&l101A

Auditron.

Where jobname-string is a maximum of 32 characters

Exclude [”](22H) character

Width of Custom Paper is specified by <ESC>&f#Iwhere # = decipoints for (89 - 297)mm.

Length of Custom Paper is specified by <ESC>&f#J where # = decipoints for (98 - 432)mm.

For instance:

4.25-inch x 5.5-inch will give <ESC>&f3060I3960J by

4.25-inch x 720 decipoints/inch = 3060 and

Media Size @PJL SET PAPER = value Where value is one of the following:

dc11cc0479 Customer Support Page 4

A5 = A5 (148 x 210mm) † A4 = A4 (210 x 297mm) A3 = A3 (297 x 420mm) JISB5 = B5 (182 x 257mm) JISB4 = B4 (257 x 364mm) STATEMENT = Statement (5.5 x 8.5") † EXECUTIVE = Executive (7.25 x 10.5") † LETTER = Letter (8.5 x 11") JISEXEC = 8.5 x 13" LEGAL = Legal (8.5 x 14") LEDGER = Tabloid (11 x 17")

Feature Implementation Values

ROC8K = 8K (267 x 388mm) †

C5 = C5 Envelope (162 x 229mm)

216 = Postcard (4 x 6")

16KAIGCO = 16K (195 x 270mm) † 8KAIGCO = 8K (270 x 390mm) †

†: Whether each paper is available depends on NV memory setting.

The following paper sizes are only available with Bypass tray.

A6 = A6 (105 x 148mm) JISB6 = B6 (128 x 182mm) 8X10 = 8 x 10" SPANISH = 215 x 315mm 11X15 = 11 x 15" A4COVER = A4 Cover (223 x 297mm) LETTERCOVER = 9 x 11" JPOST = Postcard (100 x 148mm) JPOSTD = Postcard (148 x 200mm) POSTCARD = Postcard (4 x 6") 50X70 = 5 x 7" TYOUKEI3 = Envelope (120 x 235mm) COM10 = No. 10 Envelope (4.1 x 9.5”) MONARCH = Monarch Envelope (3.9 x

7.5”) DL = DL Envelope (110 x 220mm)

<ESC>&l int A Where value is one of the following:

25 = A5 (148 x 210mm) † 26 = A4 (210 x 297mm) 27 = A3 (297 x 420mm) 45 = B5 (182 x 257mm) 46 = B4 (257 x 364mm) 41 = Statement (5.5 x 8.5") † 1 = Executive (7.25 x 10.5") † 2 = Letter (8.5 x 11") 18 = 8.5 x 13" 3 = Legal (8.5 x 14") 6 = Tabloid (11 x 17") 219 = 16K (194 x 267mm) † 220 = 8K (267 x 388mm) †

†: Whether each paper is available depends on NV memory setting.

The following paper sizes are only available with Bypass tray.

24 = A6 (105 x 148mm) 44 = B6 (128 x 182mm) 208 = 8 x 10" 43 = 215 x 315mm 217 = 11 x 15" 200 = A4 Cover (223 x 297mm) 201 = 9 x 11" 71 = Postcard (100 x 148mm) 72 = Postcard (148 x 200mm)

dc11cc0479 Customer Support Page 5

Feature Implementation Values

204 = 5 x 7"

91 = C5 Envelope (162 x 229mm)

TRAY5: Tray5 (Bypass)

21: Tray6

OUTBIN101: Finisher tray

6: Finisher tray

FOUR: 4 holes

BIFOLDMULTIOUTSIDE：Bi-Folding(multi page)

218 = Envelope (120 x 235mm) 81 = No. 10 Envelope (4.1 x 9.5”) 80 = Monarch Envelope (3.9 x 7.5”) 90 = DL Envelope (110 x 220mm)

Media Source @PJL SET

MEDIASOURCE = value

Where value is one of the following:

TRAY1: Feed from paper tray1 TRAY2: Tray2 TRAY3: Tray3 TRAY4: Tray4

<ESC>&l int H Where int is one of the following:

0: Feed paper from default tray 4: Tray1 1: Tray2 5: Tray3 8: Tray4 20: Auto 2 or 3: Tray5 (Bypass)

Output Location

@PJL SET OUTBIN = value

Where value is one of the following:

UPPER: Main tray (Hewlett-Packard compatible) MAINTRAY: Main tray

<ESC>&l int G Where int is one of the following:

0: Automatic Selection 1: Main tray

Stapling @PJL SET STAPLE =

value

Where value is one of the following:

TOPDUAL TOPLEFT TOPRIGHT BOTTOMDUAL BOTTOMLEFT BOTTOMRIGHT LEFTDUAL RIGHTDUAL SADDLE NONE

Punch @PJL SET PUNCH =

value1

Where value1 is one of the following:

TOP RIGHT LEFT

@PJL SET JOBATTR = ”@PNHN = value2”

BOTTOM NONE

Where value2 is one of the following:

TWO: 2 holes THREE: 3 holes

Folding @PJL SET JOBATTR =

dc11cc0479 Customer Support Page 6

"@FOLD = value1"

Where value1 is one of the following:

BIFOLDINSIDE ：Bi-Folding(single page)

Feature Implementation Values

The "Collated" feature needs to enabled for the

1200

1-999

booklet functions to work.

Booklet @PJL SET JOBATTR =

“@BKLT = value1”

@PJL SET JOBATTR = “@BKSG = value2”

@PJL SET JOBATTR = “@BKDN = int1”

@PJL SET JOBATTR = “@BKTP = int2”

Where value1 is one of the following:

NONEDIVIDE : Compile a booklet as long as the number of sheet does not exceed the limit AUTODIVIDE : Divide sheets into sets automatically in case of exceeding the limit number of sheets. MANUALDIVIDE : Divide sheets based on the specified limit manually

OFF : Do not compile a booklet

Where value2 is one of the following:

RIGHT : Right to left page order binding LEFT : Left to right page order binding

Where int1 is:

1-9999 : Booklet dividing number for each set

Where int2 is:

1-9999 : Booklet total pages of document

Quantity @PJL SET QTY = int Where int is:

1-999 (If you use this parameter, it also indicate use collate mode automatically.)

Resolution @PJL SET RESOLUTION

= value

Bits Per Pixel @PJL SET

BITSPERPIXEL = value

Where value is one of the following:

600

Where value is one of the following:

1: 1 bit per pixel (per plane)

Copies @PJL SET COPIES = int Where int is:

1-999

(This parameter used for uncollated mode.)

<ESC>&l int X Where int is:

Simplex @PJL SET DUPLEX =

value1

Where value1 is one of the following:

OFF: simplex

<ESC>&l int S Where int is one of the following:

0: simplex

dc11cc0479 Customer Support Page 7

Feature Implementation Values

Where string3 is a maximum of 32 character (legal

Duplex @PJL SET DUPLEX =

value1

@PJL SET BINDING = value2

Where value1 is one of the following:

ON: duplex

Where value2 is one of the following:

LONGEDGE SHORTEDGE (value2 is used combined with value1=ON)

<ESC>&l int S Where int is one of the following:

1: Duplex Long Edge Binding 2: Duplex Short Edge Binding

Orientation @PJL SET ORIENTATION

= value

Where value is one of the following:

PORTRAIT LANDSCAPE

<ESC>&l int O Where int is one of the following:

0: Portrait 1: Landscape 2: Reverse Portrait 3: Reverse Landscape

Force short edge feeding

@PJL SET PAPERDIRECTION = value

Where value is one of the following:

SEF: Short Edge Feed LEF: Long Edge Feed

Job Mode @PJL JOB MODE = value Where value is one of the following:

PRINTER: for Printer

Job Type

(Secure Print / Proof)

@PJL SET HOLD = value1

@PJL SET HOLDKEY = "string"

Where value1 is one of the following:

PROOF: proof print STORE: confidential print (secure print)

The HOLDKEY variable acts as a password without encryption to protect a held job.

string is a maximum of 16 character (legal value 20H-FFH) as password without encryption. The default value is “”.

When “”(empty string) is specified, no password is required.

Interleaving Paper

(Transparenc y Separator)

Job Based Accounting / Auditron

@PJL SET SLIPSHEET = value

@PJL SET JOBATTR = “@JOAU = string1”

@PJL SET JOBATTR = “@JOAP = string2”

Where value is one of the following:

OFF: no slipsheet BLANK: blank slipsheet COPY: imaged slipsheet

Where string1 is a maximum of 32 character (legal value: 20H-7EH) as job owner (Capital character & small character is distinguished)

Where string2 is a maximum of 12 character (legal value: 20H-7EH) as password without encryption. It can be null (zero length string)

dc11cc0479 Customer Support Page 8

Feature Implementation Values

value 20H-7EH) as account ID. It can be null (zero

YYYY:MM:DD:hh:mm

Where value is one of the following:

OFF: no banner sheet

@PJL SET JOBATTR = “@DAID = string3”

Delay Print @PJL SET JOBATTR =

“@PRTM = YYYY:MM:DD:hh:mm”

length string)

YYYY: year(AD 2000～2099) MM: month (1～12) DD: day (1～31) hh: hour(0～23)

mm: minute(0～59)

Banner Sheet @PJL SET JOBATTR=

“@BANR=value”

START: start sheet DEVICE: depend on device setting

PCL/PJL Feature Dependencies/Caveats

• All PJL commands must be in the first 2,500 bytes of the job.

• To combine printer escape commands (not including PJL commands):

o The first two characters after the <esc> MUST be the same.

o All alpha characters MUST be lowercase, except the final terminating character.

o The commands are read left to right. Combine commands in the order you wish them to execute.

For example, combine print 5 copies (<ESC>&|5X) and use letter size (<ESC>&|2A) as <ESC>&|5x2A.

• In case of duplicate commands, the last one requested takes precedence.

• The @PJL SET COPIES takes precedence over the PCL Escape Command (<ESC>& | int X>) to set copies. In

general, a PJL command takes precedence over a PCL command.

• Valid media sizes for duplexing are between 128.0 x 140.0mm and 297.0 x 432.0mm.

• Valid media sizes for stapling include A4 (210 x 297mm), A3 (297 x 420mm), B5 (182 x 257mm), B4 (257 x

364mm), Executive (7.25 x 10.5"), 8 x 10", Letter (8.5 x 11"), 215 x 315mm, 8.5 x 13", Legal (8.5 x 14"), 11 x 15", Tabloid (11 x 17"), 16K (194 x 267mm), 8K (267 x 388mm), 16K (195 x 270mm), 8K (270 x 390mm) for Finisher A/SB. For Finisher SB, A4 Cover, 9 x 11" are also valid.

Examples

PJL/PCL Template

This section illustrates a standard PJL template that is used to access general print features as well as WorkCentre Product specific features. This template lists each feature and the syntax, both PCL commands and PJL, required to use these features. The next section of this document contains other examples of how to use these commands.

Section 1 (Opening Command, Required for all files)

<ESC>%-12345X@PJL JOB MODE=PRINTER

Section 2 (PJL Set Commands)

@PJL SET RESOLUTION=600 @PJL SET COPIES=1

dc11cc0479 Customer Support Page 9

Section 3 (PCL Code used to invoke PCL Language)

@PJL ENTER LANGUAGE=PCL

Section 4 (PCL Data Stream or ASCII Document inserted here for Options such as selection

Different Fonts, Simplex, Duplex, etc.)

Section 5 (Closing Command, Required at end of Document)

<ESC>%-12345X@PJL EOJ

Sample PJL Headers

Example 1 - Simple Print

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL COMMENT Beginning PCL Job<CR><LF> @PJL SET OUTBIN=MAINTRAY<CR><LF> @PJL SET QTY=1<CR><LF> @PJL SET RESOLUTION=600<CR><LF> @PJL SET JOBATTR=”@JOAU=Nagaoka” <CR><LF>

Example 2 - Finishing Options (Stapling)

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET OUTBIN=OUTBIN101<CR><LF> @PJL SET FINISH=ON<CR><LF> @PJL SET STAPLE=TOPLEFT<CR><LF>

Example 3 - Finishing Options (Punch)

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET OUTBIN=OUTPIN101<CR><LF> @PJL SET FINISH=ON<CR><LF> @PJL SET PUNCH=LEFT<CR><LF> @PJL SET JOBATTR="@PNHN=TWO"<CR><LF>

Example 4 - Finishing Options (Saddle stapling and folding)

It is an example of division in every 5 sheets.

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET OUTBIN=BOOKLETTRAY<CR><LF> @PJL SET FINISH=ON<CR><LF> @PJL SET STAPLE=SADDLE<CR><LF> @PJL SET JOBATTR="@FOLD=BIFOLDMULTIOUTSIDE"<CR><LF> @PJL SET JOBATTR="@BKLT=MANUALDIVIDE"<CR><LF> @PJL SET JOBATTR="@BKSG=LEFT"<CR><LF> @PJL SET JOBATTR="@BKDN=5"<CR><LF>

Example 5 - Finishing Options (Bi-Folding(multi page))

It is an example of division in every 5 sheets.

dc11cc0479 Customer Support Page 10

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET OUTBIN=BOOKLETTRAY<CR><LF> @PJL SET FINISH=NONE<CR><LF> @PJL SET STAPLE=NONE <CR><LF> @PJL SET JOBATTR="@FOLD=BIFOLDMULTIOUTSIDE"<CR><LF> @PJL SET JOBATTR="@BKLT=MANUALDIVIDE"<CR><LF> @PJL SET JOBATTR="@BKSG=LEFT"<CR><LF> @PJL SET JOBATTR="@BKDN=5"<CR><LF> @PJL SET QTY=1<CR><LF>

Example 6 - Finishing Options (Bi-Folding(single page))

Example 7 - Proof Print

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET HOLD=PROOF <CR><LF> @PJL SET USERNAME="John" <CR><LF> @PJL SET JOBNAME="Job1" <CR><LF>

Example 8 - Confidential (Secure) Print without encryption

Password: 1234

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET HOLD=STORE <CR><LF> @PJL SET HOLDKEY="1234"<CR><LF> @PJL SET USERNAME="John" <CR><LF> @PJL SET JOBNAME="Job1" <CR><LF>

Example 9 - Banner Sheet

banner : start sheet

@PJL SET JOBATTR=”@BANR=START”<CR><LF> @PJL SET JOBATTR=”@BCMT=Banner Comment String”<CR><LF>

Example 10 - Job Based Accounting & Auditron

userID: Patricia, Password: none, accountID: none

<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF> @PJL SET JOBATTR=”@JOAU=Patricia”<CR><LF> @PJL SET JOBATTR=”@JOAP=”<CR><LF> @PJL SET JOBATTR=”@DAID=”<CR><LF>

dc11cc0479 Customer Support Page 11

Supported PostScript Fonts

The following PostScript fonts are resident with Adobe interpreter.

Albertus Albertus Italic Albertus Light Antique Olive Roman Antique Olive Italic Antique Olive Bold Antique Olive Compact Apple Chancery Arial Arial Italic Arial Bold Arial Bold Italic ITC Avant Garde Gothic Book ITC Avant Garde Gothic Book Oblique ITC Avant Garde Gothic Demi ITC Avant Garde Gothic Demi Oblique Bodoni Roman Bodoni Italic Bodoni Bold Bodoni Bold Italic Bodoni Poster Bodoni Poster Compressed ITC Bookman Light ITC Bookman Light Italic ITC Bookman Demi ITC Bookman Demi Italic Carta Chicago Clarendon Roman Clarendon Bold Clarendon Light Cooper Black Cooper Black Italic Copperplate Gothic 32BC Copperplate Gothic 33BC Coronet Courier Courier Oblique Courier Bold Courier Bold Oblique Eurostile Medium Eurostile Bold Eurostile Extended No. 2 Eurostile Bold Extended No. 2 Geneva Gill Sans Gill Sans Italic Gill Sans Bold Gill Sans Bold Italic Gill Sans Light Gill Sans Light Italic Gill Sans Extra Bold Gill Sans Condensed Gill Sans Condensed Bold Goudy Oldstyle Goudy Oldstyle Italic Goudy Bold Goudy Bold Italic Goudy Extra Bold

dc11cc0479 Customer Support Page 12

Helvetica Helvetica Oblique Helvetica Bold Helvetica Bold Oblique Helvetica Narrow Helvetica Narrow Oblique Helvetica Narrow Bold Helvetica Narrow Bold Oblique Helvetica Condensed Helvetica Condensed Oblique Helvetica Condensed Bold Helvetica Condensed Bold Oblique Hoefler Text Hoefler Text Italic Hoefler Text Black Hoefler Text Black Italic Hoefler Ornaments Joanna Joanna Italic Joanna Bold Joanna Bold Italic Letter Gothic Letter Gothic Slanted Letter Gothic Bold Letter Gothic Bold Slanted ITC Lubalin Graph Book ITC Lubalin Graph Book Oblique ITC Lubalin Graph Demi ITC Lubalin Graph Demi Oblique Marigold Monaco ITC Mona Lisa Recut New New Century Schoolbook Italic New Century Schoolbook Bold New Century Schoolbook Bold Italic NewYork OCR-B Letterpress M Optima Roman Optima Italic Optima Bold Optima Bold Italic Oxford Palatino Roman Palatino Italic Palatino Bold Palatino Bold Italic Stempel Garamond Roman Stempel Garamond Italic Stempel Garamond Bold Stempel Garamond Bold Italic Symbol Tekton Regular Times Roman Times Italic Times Bold Times Bold Italic Times New Roman Times New Roman Italic

Century Schoolbook Roman

Times New Roman Bold Times New Roman Bold Italic Univers 45 Light Univers 45 Light Oblique Univers 55 Univers 55 Oblique Univers 65 Bold Univers 65 Bold Oblique Univers 57 Condensed Univers 57 Condensed Oblique Univers 67 Condensed Bold Univers 67 Condensed Bold Oblique Univers 53 Extended Univers 53 Extended Oblique Univers 63 Extended Bold Univers 63 Extended Bold Oblique Wingdings ITC Zapf Chancery Medium Italic ITC Zapf Dingbat

dc11cc0479 Customer Support Page 13

Supported PCL5 Fonts

Font Name

PCL Escape Command

Albertus Medium

<esc>(<esc>(s1p12v0s1b4362T

Albertus Extra Bold

<esc>(<esc>(s1p12v0s4b4362T

Antique Olive

<esc>(<esc>(s1p12v0s0b4168T

Antique Olive Bold

<esc>(<esc>(s1p12v0s3b4168T

Antique Olive Italic

<esc>(<esc>(s1p12v1s0b4168T

Arial

<esc>(<esc>(s1p12v0s0b16602T

Arial Bold

<esc>(<esc>(s1p12v0s3b16602T

Arial Italic

<esc>(<esc>(s1p12v1s0b16602T

Arial Bold Italic

<esc>(<esc>(s1p12v1s3b16602T

CG Times

<esc>(<esc>(s1p12v0s0b4101T

CG Times Bold

<esc>(<esc>(s1p12v0s3b4101T

CG Times Italic

<esc>(<esc>(s1p12v1s0b4101T

CG Times Bold Italic

<esc>(<esc>(s1p12v1s3b4101T

CG Omega

<esc>(<esc>(s1p12v0s0b4113T

CG Omega Bold

<esc>(<esc>(s1p12v0s3b4113T

CG Omega Italic

<esc>(<esc>(s1p12v1s0b4113T

CG Omega Bold Italic

<esc>(<esc>(s1p12v1s3b4113T

Clarendon Condensed

<esc>(<esc>(s1p12v4s3b4140T

Coronet

<esc>(<esc>(s1p12v1s0b4116T

Courier

<esc>(<esc>(s1p12v0s0b4099T

Courier Bold

<esc>(<esc>(s1p12v0s3b4099T

Courier Italic

<esc>(<esc>(s1p12v1s0b4099T

Courier Bold Italic

<esc>(<esc>(s1p12v1s3b4099T

Garamond Antiqua

<esc>(<esc>(s1p12v0s0b4197T

Garamond Halbfett

<esc>(<esc>(s1p12v0s3b4197T

Garamond Kursiv

<esc>(<esc>(s1p12v1s0b4197T

Garamond Kursiv Halbfett

<esc>(<esc>(s1p12v1s1b4197T

Line Printer (Roman-8)

<esc>(8U<esc>(s0p16.67h8.5v0s0b0T

Line Printer (Latin-1)

<esc>(0U<esc>(s0p16.67h8.5v0s0b0T

Line Printer (PC-8)

<esc>(10U<esc>(s0p16.67h8.5v0s0b0T

Line Printer (PC-8 D/N)

<esc>(11U<esc>(s0p16.67h8.5v0s0b0T

Line Printer (PC-850)

<esc>(12U<esc>(s0p16.67h8.5v0s0b0T

Line Printer (Legal)

<esc>(1U<esc>(s0p16.67h8.5v0s0b0T

Marigold

<esc>(<esc>(s1p12v0s0b4297T

Times New

<esc>(<esc>(s1p12v0s0b16901T

Times New Bold

<esc>(<esc>(s1p12v0s3b16901T

Times New Italic

<esc>(<esc>(s1p12v1s0b16901T

Times New Bold Italic

<esc>(<esc>(s1p12v1s3b16901T

Symbol

<esc>(19M<esc>(s1p12v0s0b16686T

Wingdings

<esc>(579L<esc>(s1p12v0s1b31402T

Univers Bold

<esc>(<esc>(s1p12v0s3b4148T

Univers Bold Italic

<esc>(<esc>(s1p12v1s3b4148T

Univers Bold Condensed

<esc>(<esc>(s1p12v4s3b4148T

Univers Bold Condensed Italic

<esc>(<esc>(s1p12v5s3b4148T

Univers Medium

<esc>(<esc>(s1p12v0s0b4148T

Univers Medium Italic

<esc>(<esc>(s1p12v1s0b4148T

Univers Medium Condensed

<esc>(<esc>(s1p12v4s0b4148T

Univers Medium Condensed Italic

<esc>(<esc>(s1p12v5s0b4148T

Letter Gothic

<esc>(<esc>(s1p12h0s0b4102T

Letter Gothic Italic

<esc>(<esc>(s1p12h1s0b4102T

Letter Gothic Bold

<esc>(<esc>(s1p12h0s3b4102T

The following PCL fonts are resident.

dc11cc0479 Customer Support Page 14

Font Name

PCL Escape Command

Times Roman

<esc>(<esc>(s1p12h0s3b4102T

Times Italic

<esc>(<esc>(s1p12h0s3b4102T

Times Bold

<esc>(<esc>(s1p12h0s3b4102T

Times Bold Italic

<esc>(<esc>(s1p12h0s3b4102T

Helvetica

<esc>(<esc>(s1p12v0s0b24580T

Helvetica Oblique

<esc>(<esc>(s1p12v1s0b24580T

Helvetica Bold

<esc>(<esc>(s1p12v0s3b24580T

Helvetica Bold Oblique

<esc>(<esc>(s1p12v1s3b24580T

CourierPS

<esc>(<esc>(s0p12h0s0b24579T

CourierPS Oblique

<esc>(<esc>(s0p12h1s0b24579T

CourierPS Bold

<esc>(<esc>(s0p12h0s3b24579T

CourierPS Bold Oblique

<esc>(<esc>(s0p12h1s3b24579T

SymbolPS

<esc>(19M<esc>(s1p12v0s0b45358T

Palatino Roman

<esc>(<esc>(s1p12v0s0b24591T

Palatino Italic

<esc>(<esc>(s1p12v0s0b24591T

Palatino Bold

<esc>(<esc>(s1p12v0s0b24591T

Palatino Bold Italic

<esc>(<esc>(s1p12v0s0b24591T

ITC Bookman Light

<esc>(<esc>(s1p12v0s-3b24623T

ITC Bookman Light Italic

ITC Bookman Demi

<esc>(<esc>(s1p12v0s2b24623T

ITC Bookman Demi Italic

<esc>(<esc>(s1p12v1s2b24623T

Helvetica Narrow

<esc>(<esc>(s1p12v4s0b24580T

Helvetica Narrow Oblique

<esc>(<esc>(s1p12v5s0b24580T

Helvetica Narrow Bold

<esc>(<esc>(s1p12v4s3b24580T

Helvetica Narrow Bold Oblique

<esc>(<esc>(s1p12v5s3b24580T

New Century Schoolbook Roman

<esc>(<esc>(s1p12v0s0b24703T

New Century Schoolbook Italic

<esc>(<esc>(s1p12v1s0b24703T

New Century Schoolbook Bold

<esc>(<esc>(s1p12v0s3b24703T

New Century Schoolbook Bold

<esc>(<esc>(s1p12v1s3b24703T

ITC Avant Garde Book

<esc>(<esc>(s1p12v0s0b24607T

ITC Avant Garde Demi

<esc>(<esc>(s1p12v0s2b24607T

ITC Avant Garde Demi Oblique

<esc>(<esc>(s1p12v1s2b24607T

ITC Zapf Chancery Medium Italic

<esc>(<esc>(s1p12v1s0b45099T

ITC Zapf Dingbats

<esc>(<esc>(s1p12v0s0b45101T

Italic

<esc>(<esc>(s1p12v1s-3b24623T

ITC Avant Garde Book Oblique

<esc>(<esc>(s1p12v1s0b24607T

Additional Information

You can reach Xerox Customer Support at http://www.xerox.com or by calling Xerox Support in your country.

Xerox Customer Support welcomes feedback on all documentation - send feedback via e-mail to:

USA.DSSC.Doc.Feedback@xerox.com.

Other Tips about Xerox multifunction devices are available at the following URL:

http://www.office.xerox.com/support/dctips/dctips.html.

dc11cc0479 Customer Support Page 15

Xerox WorkCentre 5325, WorkCentre 5330, WorkCentre 5335 PDL Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Using this Guide

Table of Contents

PCL/PJL Implementation

Job Name

Custom Paper Size

Media Size @PJL SET PAPER = value Where value is one of the following:

Media Source @PJL SET

Output Location

Stapling @PJL SET STAPLE =

Punch @PJL SET PUNCH =

Folding @PJL SET JOBATTR =

Booklet @PJL SET JOBATTR =

Quantity @PJL SET QTY = int Where int is:

Resolution @PJL SET RESOLUTION

Bits Per Pixel @PJL SET

Copies @PJL SET COPIES = int Where int is:

Simplex @PJL SET DUPLEX =

Duplex @PJL SET DUPLEX =

Orientation @PJL SET ORIENTATION

Force short edge feeding

Job Mode @PJL JOB MODE = value Where value is one of the following:

Job Type

(Secure Print / Proof)

Interleaving Paper

(Transparenc y Separator)

Job Based Accounting / Auditron

Delay Print @PJL SET JOBATTR =

Banner Sheet @PJL SET JOBATTR=

PCL/PJL Feature Dependencies/Caveats

Examples

PJL/PCL Template

Sample PJL Headers

Supported PostScript Fonts

Supported PCL5 Fonts

Additional Information
