Xerox C8130, C8135, C8145, C8155, C8170 User Manual

Xerox® AltaLink® Colour Multifunction Printers

C8130/C8135/C8145/C8155/C8170

AltaLink® C8100 Series Colour Multifunction Printers are built on Xerox® ConnectKey® Technology. For more information, go to www.ConnectKey.com.

System Specification AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Speed

Colour/Black-and-White

Monthly Duty Cycle

Hard Drive / Processor / Memory

Connectivity

Controller Features

Optional Controller

Copy and Print

Copy and Print Resolution Copy: Up to 600 x 600 dpi; Print: Up to 1200 x 2400 dpi

First-Print-Out Time

(as fast as)

First-Copy-Out Time (as fast as) (from platen/ warmed up state)

Page Description Language Adobe

Print Features

Mobile and Cloud Ready

Mobile Connectivity Near-Field Communication (NFC); Optional: Wi-Fi Direct, Wi-Fi (802.11 b/g/n/ac), AirPrint (iOS) including iBeacon (Bluetooth)

Mobile Printing AirPrint

Mobile Scanning

Mobile Apps and Xerox App Gallery

Xerox® Workplace Suite and Xerox® Workplace Cloud

Up to 30/30 ppm Up to 35/35 ppm Up to 45/45 ppm Up to 55/55 ppm Up to 70/70 ppm

Up to 90,000 pages Up to 110,000 pages Up to 200,000 pages Up to 300,000 pages Up to 300,000 pages

Minimum 128 GB SSD / Optional: 500 GB HDD / Intel® Atom™ Quad Core 1.91 GHz / 4 GB system memory (8 GB system memory AltaLink C8170)

Ethernet 10/100/1000 Base-T, High-speed USB 2.0 direct print, Wi-Fi/Wi-Fi Direct with optional Xerox (iBeacon)

Uniﬁed Address Book, Remote Control Panel, Conﬁguration Cloning, Fleet Orchestrator, Conﬁguration Watchdog

Xerox® EX-c C8100 Print Server Powered by Fiery

5.7 seconds colour/4.2 seconds black and white 4.9 seconds colour/3.8

6.1 seconds colour/4.5 seconds black and white 5.5 seconds colour/4.4

PostScript® 3™, Adobe® PDF, PCL® 5c / PCL® 6

Print from USB, Print from Cloud Repositories (Dropbox, One Drive and Google Drive), Encrypted Secure Print, Xerox® Earth Smart Driver Settings, Job Identiﬁcation, Booklet Layout, Store and Recall Driver Settings, Bi-directional Real-time Status, Scaling, Job Monitoring, Application Defaults, Two-sided Printing (as default), Hold All Jobs, Long-Sheet (Banner) Printing, Print Around, Print on Alternate Pages

, Mopria®, Xerox® Print Service (Android), @PrintByXerox App; Optional: Xerox® Workplace Mobile App

(iOS/Android), AirPrint (iOS) including iBeacon (Bluetooth)

AirPrint®, Mopria®; Optional: Xerox® Workplace Mobile App (iOS/Android)

Automate everyday processes with apps that translate, redact, eSign, personalise print, convert, route, collaborate and communicate. Visit xerox.com/WorkplaceApps to ﬁnd apps by industry or workﬂow. Sof tware and services: Xerox

XMPie

(xerox.com/XMPie), Xerox® Workplace Solutions (xerox.com/WorkplaceSolutions)

Optional: Xerox® Workplace Suite is a modular set of workﬂows designed to save customers time and money by providing effective control over their print ﬂeet, while enabling worker productivity and mobility through a set of robust workﬂows. Xerox enables ultimate customer ﬂexibility by offering these capabilities in both an on-premises server version (Workplace Suite) and with a cloud based-version (Workplace Cloud) of this solution.

seconds black and white

4.5 seconds colour/3.2 seconds black and white

4.7 seconds colour/3.7 seconds black and white

Dual Band Wireless Kit, NFC, Bluetooth

3.8 seconds colour/3.0 seconds black and white

4.0 seconds colour/3.2 seconds black and white

DocuShare® (xerox .com/ecm),

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Scan

Standard Features Destinations: Scan to USB / Email / Network (FTP/SMB), HTTP, HTTPS, SFTP

Optional Features

Fax

Standard Features Internet Fax, Fax Build Job, Network Server Fax Enablement, Fax Build Job

Optional Features

Security

Standard Features

Optional Features

Print Management

Standard Features

Optional Features

destinations; File Formats: PDF, PDF/A, XPS, JPEG, TIFF; Convenience Features: Scan Preview, Scan to Home, Searchable PDF, Single/Multi-Page PDF / XPS / TIFF, Password Protected PDF, Uniﬁed Address Book, Optical Character Recognition (OCR), Scan to Folder, 1-Touch Apps, TWAIN Support.

Scan to Cloud Repositories (Dropbox, One Drive and Google Drive)2; Xerox® Scanning App for DocuShare®, other solutions available through various Xerox Business Innovation Partners at xerox.com/Software-Solutions

Walk-up Fax (one-line and two-line options available, includes LAN Fax, Direct Fax, Fax Forward to Email or SMB Share

802.1x, IPsec, HTTPS, SFTP and Encrypted Email, McAfee® Embedded Control Whitelisting, Firmware Veriﬁcation, McAfee® ePolicy Orchestrator®, McAfee Enterprise Security Manager2, LogRhythm SIEM2, Splunk SIEM2, Network Authentication, SNMPv3, SHA-256 Hash Message Authentication, TLS 1.1/1.2, Security Certiﬁcates utilizing ECDSA, Automatic Self-signed Certiﬁcate, Cisco

DXL/Cisco® pxGrid integration, Local Authentication(Internal Database), FIPS 140-2.User Access and Internal Firewall, Port/IP/Domain Filtering,

McAfee Audit Log, Access Control, User Permissions, Conﬁguration Watchdog, TPM, Trusted Boot Encrypted Storage Drive (AES 256-bit, FIPS 140-2), Job Level Encryption via HTTPS and Drivers, Signed Email Under evaluation for Common Criteria Certiﬁcation (ISO 15408), Encrypted Secure Print

McAfee® Integrity Control, Smart Card Enablement Kit (CAC/PIV/.NET)3, Xerox® Integrated RFID Card Reader, Encrypted Hard Disk (AES 256-bit, FIPS 140-2) with Image Overwrite, Xerox® Workplace Cloud/Suite Print Management and Content Security; learn more at xerox.com/WorkplaceSolutions

Xerox® Standard Accounting (Copy, Print, Scan, Fax, Email), Network Accounting Enablement

Xerox® Workplace Cloud/Suite, other network accounting solutions available through various Xerox Business Innovation Partners. Xerox® Virtual Print Management Service; learn more at xerox.com/PrintManagement

Identity Services Engine (ISE) integration, automated threat response through

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Features and Accessories

Single-Pass Duplex Automatic

Document Feeder (DADF)

saves time by simultaneously scanning both side s of two-sided documents, up to 270 impressions per minute (ipm).

PAPER INPUT

Two 520-sheet Adjustable Trays (common

with all configurations). Tray 1 handles media sizes up to A3 and Tray 2 handles media sizes up to SRA3.

Envelope Kit (optional – replaces Tray 1) provides feeding of up to 60 envelopes.

USER INTERFACE

Intuitive Tablet-Like 10.1-inch Colour Touchscreen is

customisable and lets you perform tasks in just a few taps. Try it out at

xerox.com/AltaLink8100UI.

INNOVATIVE TECHNOLOGIES

Xerox® Integrated RFID Card Reader (optional) adds card-based

authentication with support for over 90 access cards.

Near Field Communication (NFC) Tap-to-Pair allows users to tap their

mobile device to the AltaLink C8100 Series user panel and quickly conne ct with the multifunction printer.

Smart Proximity Sensor detec ts when users are nearby. It conser ves energy during inac tive periods and automatically activates the device when a user approaches.

High-Capacity Tandem Tray Configuration

of up to 3,140 sheets.

Four-Tray Module Configuration (available of up to 2,180 sheets .

Byp as s Tra y handles up to 100

sheets; Custom sizes: 89 x 98 mm to 320 x 1,320 mm.

High-Capacity Feeder (optional) holds

3,000 sheets of A4 paper, increasing the maximum paper capacity to 6,140 sheets.

holds a total paper capacity

for C8130/C8135) holds a total

LONG SHEET PRINTING

Long Sheet Feed Kit (optional) provides

the ability to print up to 320 x 1,320 mm media.

PAPER OUTPUT / FINISHERS

Off ice Finish er

(optional) provides advanced finishing functions, optional crease/score and saddle-stitch booklet, making it capable of 60-page booklets (2 to 15 sheets).

Dual Of fset Catch Tray (available when no finishers are installed; Single Offs et Catch Tray with finishers).

Business Ready (BR) Finisher (optional)

gives you advanced finishing functions at a great value.

C-Fold/Z-Fold Unit

(optional) adds C-fold, Z-fold and Z-half-fold to the BR Finisher or BR Booklet Maker Finishe r.

Integrated Office Finisher (optional with C8130/C8135/ C8145/C8155) provides 500-sheet stacking and 50-sheet, 2-position stapling.

BR Booklet Maker Finisher (optional)

create 64-page saddle-stitched booklets (2 to 16 sheets).

Convenience Stapler (optional) s taples up to 50 sheets of 75 gsm media.

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Device Speciﬁcation

Control Panel Languages US English, International English, International French, Italian, German, International Spanish, Dutch, Brazilian Portuguese, Swedish, Norwegian, Danish,

Accessories

Optional High-Capacity Feeder 3000 A4

Electrical Requirements AltaLink

North America Voltage: 110-127 VAC +/- 10%

Europe Voltage: 220-240 VAC +/- 10%

Finnish, Turkish, Greek, Russian, Czech, Polish, Hungarian, Romanian, Catalan, Arabic

Envelope Tray (Replaces Tray 1) Horizontal Transport Kit BR (Business Ready) Finisher (requires Horizontal Transport Kit) BR Booklet Maker Finisher (requires Horizontal Transport Kit) C-fold / Z-fold Unit for BR Finisher or BR Booklet Maker Finisher Convenience Stapler (includes Work Surface

) Integrated Ofﬁce Finisher (Available AltaLink C8130, C8135, C8145, C8155) Ofﬁce Finisher Booklet Maker for Ofﬁce Finisher Hole Punch (2/3, 2/4, Swedish) Ofﬁce Finisher Smart Card Enablement Kit

Xerox® EX-c C8100 Print Server Powered by Fiery Walk Up Fax (One- or Two-line options, includes LAN Fax) Wi-Fi/Wi-Fi Direct with Dual Band Wireless Kit Bluetooth Kit McAfee® Integrity Control Enablement Kit USB Keyboard / Shelf Kit Xerox® Integrated RFID Card Reader Kit Unicode Font kit Foreign Device Interface (also known as Auxiliary Access Device) Interface for third-party access control devices, such as coin machines and card readers Long-Sheet Feed kit (banner printing) 500 GB HDD Scan To Cloud Enablement Kit

C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Voltage: 110-127 VAC +/- 10%

Frequency: 50/60 Hz +/- 3%, 15 A

Frequency: 50/60 Hz +/- 3%, 20 A

Voltage: 220-240 VAC +/- 10%

Frequency: 50/60 Hz +/- 3%, 10 A

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Device Speciﬁcation (continued)

Power Consumption AltaLink

Running (Average) 115 V: 576 watts

Standby Mode 115 V: 67 watts

Auto Off/Sleep Mode 115 V: 0.69 watts

Warm-up (from Off)

Recovery from Sleep

Operating Environment

C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

230V: 586 watts

230V: 71 watts

230V: 0.71 watts (Default time to sleep mode = 0 minutes)

As fast as 85 seconds

As fast as 4.5 seconds

115 V: 600.3 watts 230V: 595.8 watts

115 V: 64 watts 230V: 70 watts

115 V: 0.69 watts 230V: 0.72 watts (Default time to sleep mode = 0 minutes)

115 V: 717 watts 230V: 674 watts

115 V: 71 watts 230V: 71 watts

115 V: 0.67 watts 230V: 0.71 watts (Default time to sleep mode = 0 minutes)

115 V: 806 watts 230V: 760 watts

115 V: 72 watts 230V: 70.3 watts

115 V: 0.67 watts 230V: 0.71 watts (Default time to sleep mode = 0 minutes)

115 V: 929 watts 230V: 908 watts

115 V: 91.1 watts 230V: 79 watts

115 V: 0.68 watts 230V: 0.75 watts (Default time to sleep mode = 0 minutes)

Required Temperature Range

Required Relative Humidity

Sound Power Levels

Dimensions and Weight

Base Conﬁguration Width: 620 mm

With Integrated Ofﬁce Finisher (C8130, C8135, C8145, C8155)

With Ofﬁce Finisher (with Booklet Maker)

Base Conﬁguration with Business Ready (BR) Finisher

Base Conﬁguration with BR Booklet Maker Finisher

Base Conﬁguration with BR Booklet Maker Finisher and C-fold / Z-fold Unit

Base Conﬁguration with BR Booklet Maker Finisher, C-fold / Z-fold Unit and High Capacity Feeder

10 to 28 °C

15% to 85%

Operating: 63.7 / 64.2 dB(A) Standby: 4.0 / 4.0 dB(A)

Depth: 723 mm Height: 1,130 mm Weight: 143.1 kg

Width: 819 mm Depth: 723 mm Height: 1,130 mm Weight: 154.2 kg

Width: 1,207 mm Depth: 723 mm Height: 1,130 mm Weight: 182.5 kg

Width: 1,395 mm Depth: 723 mm Height: 1,130 mm Weight: 187 kg

Width: 1,496.3 mm Depth: 723 mm Height: 1,130 mm Weight: 204 kg

Width: 1,632 mm Depth: 723 mm Height: 1,130 mm Weight: 254.3 kg

Width: 2,361 mm Depth: 723 mm Height: 1,130 mm Weight: 285.2 kg

Operating: 65.2 / 67.3 dB(A) Standby: 4.3 / 4.3 dB(A)

Operating: 70.4 dB(A) Standby: 4.3 dB(A)

Width: 620 mm Depth: 793 mm Height: 1,169 mm Weight: 159.7 kg

N/A

Width: 1207 mm Depth: 793 mm Height: 1,169 mm Weight: 199 kg

Width: 1,395 mm Depth: 723 mm Height: 1,169 mm Weight: 203.4 kg

Width: 1,496.3 mm Depth: 723 mm Height: 1,169 mm Weight: 220.6 kg

Width: 1,632 mm Depth: 723 mm Height: 1,169 mm Weight: 270.9 kg

Width: 2,361 mm Depth: 723 mm Height: 1,169 mm Weight: 302 kg

System Certiﬁcation / Regulatory Compliance

Certiﬁcations To view the latest list of certiﬁcations, go to xerox.com/OfﬁceCertiﬁcations

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Paper Handling AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Single-pass Duplex Automatic Document Feeder (DADF)

Capacity

Speed (Up to) 82 ppm black-and-white and colour (simplex)

Paper Sizes Sensed 85 x 125 mm to 297 x 432 mm

Weights 60 to 128 gsm

Bypass Tray (Standard)

Capacity

Sizes Custom Sizes: 89 x 98 mm to 320 x 1320 mm (SEF); Optional: Long Sheet Feed Kit (Banner Printing)

Weights 52 to 300 gsm, Long sheets/banners (>19 in. / 483 mm) 28lb Bond - 120lb Index / 106 - 220 gsm

Media Types Bond

Trays 1 and 2 (Standard)

Capacity

Sizes Tray 1: Custom Sizes: 140 x 182 mm to 297 x 432 mm (SEF)

Weights 52 to 300 gsm

Media Types Bond

130 sheets 250 sheets

141 ipm black-and-white and colour (duplex)

100 sheets

Card Stock Card Stock Reloaded Custom Envelopes Glossy Card Stock Glossy Card Stock Reloaded Heavyweight Card Stock Heavyweight Card Stock Reloaded Heavyweight Glossy Card Stock Heavyweight Glossy Card Stock Reloaded Hole punched Labels Letterhead Lightweight Lightweight Card Stock Lightweight Card Stock Reloaded Lightweight Glossy Card Stock Lightweight Glossy Card Stock Reloaded Plain Plain-Reloaded Preprinted Recycled Transparencies

Long Sheets/Banners:

Card Stock Card Stock Reloaded Lightweight Card Stock Lightweight Card Stock Reloaded

520 sheets each

Tray 2: Custom Sizes: 140 x 182 mm to SRA3 (SEF)

135 ppm black-and-white and colour (simplex) 270 ipm black-and-white and colour (duplex)

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Paper Handling (continued) AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Four Tray Module (Trays 3 and 4) (Available on C8130/C8135)

Capacity

Sizes

Weights 52 to 300 gsm

Media Types Bond

High Capacity Tandem Tray (Available with all models)

Capacity

Sizes A4, JIS B5, Executive (7.25 x 10.5 in) LEF

Weights 52 to 300 gsm

Media Types Bond

Envelope Tray (Optional – Replaces Tray 1)

Capacity

Sizes No. 10 Commercial (9.25 x 4.125 in.) / Monarch, DL, C5

Weights 75 to 90 gsm

High-Capacity Feeder (HCF) (Optional with all models)

Capacity

Sizes Standard Sizes: A4 or B5 LEF

Weights 52 to 300 gsm

Total Capacity

Device Total Capacity

Tray 3: 520 sheets Tray 4: 520 sheets

Trays 3 and 4: 140 x 182 mm to SRA3 mm (SEF)

Tray 3: 867 sheets Tray 4: 1,133 sheets

Card Stock Custom Glossy Card Stock Hole Punched Labels Letterhead Lightweight Card Stock Lightweight Glossy Card Stock Plain Preprinted

Up to 60 envelopes

Custom Sizes: 98 x 148 mm to 162 x 241 mm

3,000 sheets

Four Tray Module: 2,180 sheets Four-Tray Module with High-Capacity Feeder: 5,180 sheets High-Capacity Tandem Tray Module: 3,140 sheets High-Capacity Tandem Tray Module with High-Capacity Feeder: 6,140 sheets

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Finishing AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Output Trays (Standard) (Dual Offset Catch Trays not available with Integrated Ofﬁce Finisher and limited to one with Ofﬁce Finisher and BR Finishers)

Stacking Tray Capacity

Integrated Ofﬁce Finisher (Optional with AltaLink C8130/C8135/C8145/C8155)

Stacking Tray Capacity

Sizes 89 x 98 mm to 297 x 432 mm

Weights 52 to 300 gsm

Stapling Single / Dual Position

Ofﬁce Finisher (Optional)

Stacking Tray Capacity

Stacking Tray Sizes 210 x 182 mm to 297 x 432 mm

Weights 52 to 300 gsm

Multiposition Stapling

Hole Punch (Optional) North America: 2/3-hole punch

Booklet Maker for Ofﬁce Finisher (Score/Crease, Saddle-stitch Staple) (Optional)

Top Tray Capacity

Sizes Letter – A4 SEF

Saddle-Stitch Stapling 2-15 sheets / 8-60 page booklet

Score / Crease

Business Ready (BR) Finisher (Optional) (Requires Horizontal Transport Kit)

Capacity

Sizes 100 x 148 mm x 320 x 488 mm for top tray

Weights 52 to 300 gsm

Stapling Single and multiposition stapling

Hole Punch North America: 2/3-hole punch

BR Booklet Maker Finisher (Optional) (Requires Horizontal Transport Kit)

Capacity

Sizes 100 x 148 mm x 320 x 488 mm for top tray

Weights 52 to 300 gsm

Stapling Single and multiposition stapling

Hole Punch North America: 2/3-hole punch

Booklet maker Saddle-stitch 2 to 16 sheets (7 sheets at 106 to 176 gsm coated or 5 sheets at 177 to 220 gsm coated)

Dual Offset Catch Tray: Up to 250 sheets each Left Side Face-up Tray: Up to 100 sheets

500 sheets of 80 gsm – A4 or 250 sheets of 80 gsm – A3

Auto-Stapling: 50 sheets maximum: Letter / A4 / B5 size sheets (less than 90 gsm or (2) 220 gsm covers) 30 sheets maximum: Legal / Tabloid / A3 / B4 size sheets (less than 90 gsm or (2) 220 gsm covers)

2,000 sheets unstapled or 1,000 sheets single stapled or 750 sheets dual stapled (A4)

50 sheets maximum: Letter / A4 / B5 size sheets (less than 90 gsm or (2) 220 gsm covers) 30 sheets maximum: Legal / Tabloid / A3 / B4 size sheets (less than 90 gsm or (2) 220 gsm covers)

Europe: 2/4-hole punch Optional: 4-hole “Swedish” punch

40 booklets (2-15 sheets per booklet – 80 gsm or less)

Legal – B4 SEF Tabloid – A3 SEF

60 to 256 gsm

1-15 sheets / unstapled 60 to 105 gsm

Offsetting Top Tray: 500 sheets Stacking Stapling Tray: 3,000 sheets unstapled or 100 sets (dual or 4-position stapling) A3 or 200 sets (single-position staple) A4

182 x 203 mm to 320 x 488 mm for stacking B5 to A3 for stapling

Auto stapling (50 sheets maximum) – 90 gsm Letter, Legal, Tabloid, A3, A4, B4 and B5 sizes supported

Europe: 2/4-hole punch Optional: 4-hole “Swedish” punch

Offsetting Top Tray: 500 sheets of A4 unstapled Stacking Stapling Tray: 1,500 sheets of A4 / A3 unstapled or 200 stapled sets of A4 (single-position stapling or dual or 4-position stapling) or 100 stapled sets of A3

182 x 203 mm to 320 x 488 mm for stacking B5 to A3 for stapling

Auto stapling (50 sheets maximum) – 90 gsm Letter, Legal, Tabloid, A3, A4, B4 and B5 sizes supported

Europe: 2/4-hole punch Optional: 4-hole “Swedish” punch

Bi-fold up to 5 sheets Letter, Legal, Tabloid, A3, A4 supported

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Finishing (continued) AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

C-fold / Z-fold Unit (Optional with BR Finisher and BR Booklet Maker Finisher)

Types C-fold, Z-fold and Z-half-fold

Capacity

Sizes C-fold and Z-fold: Letter – A4 SEF only

Weights 64 to 90 gsm

Output Trays

Convenience Stapler (Optional - Includes Work Surface

Capacity

Copy AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

First-Copy-Out Time

(from platen/warmed up Colour/Black-and-White)

Sides (input:output) 1-1, 1-2, 2-2, 2-1

Quantity 1 to 9,999

Resolution (max) Up to 600 x 600 dpi

Reduction / Enlargement Variable zoom from 25% to 400% in 1% increments

Concurrency Program-ahead to allow a job to be queued while the initial job is processed (Copy, Print, Fax and Scan)

Copy Features Annotation and Bates™ stamping (with colour capability and font size adjustment)

Xerox

Copier Assistant®Xerox® Copier Assistant® Software provides a PC-based alternative to the user interface touchscreen. Used in conjunction with a customer-supplied

40 sheets

Z-half-fold: A3 only

Envelope Tray: C-fold, Z-fold and Tri-fold Stacker Tray or Top Tray: Z-half-fold

)

50-sheet stapling 5,000 staples Requires separate power outlet

As fast as 6.1 seconds / As fast as 4.5 seconds

As fast as 5.5 seconds / As fast as 4.4 seconds

As fast as 4.7 seconds / As fast as 3.7 seconds

As fast as 4.0 seconds / As fast as 3.2 seconds

Authentication for Services (i.e. Colour Copy) Auto Paper Select Auto Reduction & Enlargement (to ﬁt the selected paper size) Auto Tray Switching Automatic 2-sided / Duplex Booklet Creation Build Job (enables page-level programming and also lets you proof each section or delete the last section as the job is built) Collation Covers (front only, front and back, back only, printed inside and out: Blank or Printed) Dividers (blank) Edge Erase Features Help (Intuitive text and graphic descriptions) ID Card Copy Image Quality Adjustments Image Shift (with Auto Centre option) Invert Image (negative or mirror image) Large Job Interrupt Multi-up (up to 15 columns by 15 rows) Sample Set Save Job Settings Single Colour Stapling Transparencies

PC attached via the USB port, this software supports text-to-speech, screen magniﬁcation and easy PC keyboard access to basic and advanced copy features. Section 508 compliant. For more information or to download Xerox® Copier Assistant for free, visit xerox.com

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Print AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Resolution (up to) 1200 x 2400 dpi

Print Features Application Defaults

Print from USB Allows walk-up printing from Type A USB port on front panel

Operating Systems Windows Server 2008 SP2 (32- and 64-bit)

Network Protocols TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD

Font Capability PCL: 93 scalable fonts, line printer and bitmap font (including Cyrillic font support) PostScript 3: 173 Type 1 fonts, 2 Multiple Master fonts

Global Print Driver®A truly universal print driver that lets IT administrators install, upgrade and manage Xerox® and non-Xerox devices from a single driver. It provides a

Xerox

Pull Print Driver Makes it easy for IT managers to qualify, deploy and manage all print devices using a single driver in a Pull Print environment. Uses a single queue and

Xerox

Uniﬁed Address Book for Fax, Internet Fax, Email and Scan to...

Features Services supported: Fax, Internet Fax, Email, Scan to

Banner Sheet Enable/Disable Custom Colour Options (Colour by Words) Bi-directional Real-time Status Cover Selection Delay Print (speciﬁc time) User Permissions Image Options (Toner Saver, Resolution (Standard, Enhanced, High)) Job Identiﬁcation (Print ID or Banner, Print ID in margins on ﬁrst page only or all pages) LAN Fax (requires optional Fax Kit) Layout/Watermark N-up (up to 16 pages per sheet) Booklet Layout Long Sheet/Banner Finishing Fit to New Paper Size Hold All Jobs Paper Selection by Attribute Sample Set Saved Job (colour jobs can be printed as monochrome) Secure Print with Timed Deletion Special Pages (exception page programming: covers, inserts, exception pages) Store and Recall Driver Settings Sustainability Features (Xerox

Earth Smart Settings, Duplex, N-up, Turn-off Banner and Print ID, Smart Sample Set, Hold All Jobs) Two-sided Printing (as default) Print from Cloud Repositories (Dropbox, One Drive and Google Drive)

Supports direct printing from computer via Type B USB port Supported ﬁle formats: PDF, JPEG, TIFF, PS, XPS, PCL Colour jobs can be printed as black-and-white

Windows Server 2008 R2 (64-bit) Windows Server 2012 and R2 (64-bit) Windows Server 2016 (64-bit) Windows Server 2019 (64-bit) Windows 7 (32- and 64-bit) Windows 8 (32- and 64-bit) Windows 8.1 (32- and 64-bit) Windows 10 (32- and 64-bit) Mac OS 10.13, 10.14, 10.15

Core

Fedora

Ubuntu

Microsoft Windows Networking over IP Bonjour® / AirPrint® IPv6 Most protocols not in use can be disabled

consistent, easy-to-use interface for end users, reducing the number of support calls and simplifying print services management.

single driver. The Xerox® Pull Print Driver extends convenience across a broad range of printing assets. IT administrators no longer need to manage and conﬁgure multiple drivers. Used in conjunction with Equitrac Ofﬁce

, Ysoft® SafeQ®, Pharos® and others.

Maximum contacts: 5,000 Contacts: Supports 1 or more destinations Favourites for quick access of all services supported

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Scan AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Concurrency Scan while the system is printing, copying or while it is transferring scan-to-network or fax jobs (priority is for the return of scanned originals and printing

Input Speed

(up to)

Resolution 72 x 72 dpi to 600 x 600 dpi

Bit Depth 1-bit (black-and-white), 8-bit (greyscale), 24-bit (colour)

Maximum Scan Area A3

Scan Template Management

Network Protocols SFTP, FTP, SMB, HTTP, HTTPS

File Compression Colour TIFF (TIFF 6.0 or TTN2 with JPEG, LZW)

Document Management Fields (Metadata)

Scan Features Mixed Size Originals Scan Build Job

Scan to Email (Standard)

Scan Features • Email signatures (6 lines each of 128 character max), email message body (user conﬁgurable), email Embedded Web Server conﬁrmation sheet

Directory Access Address list via LDAP (Windows Active Directory, Exchange, Notes, Domino), Device Address Book

Scan To

Standard Features Scan to USB

Optional Features Native Scan to Cloud Repositories (Dropbox, One Drive and Google Drive)

Workﬂow Scanning (Optional)

Scanning Software Autostore v7

Scanning Apps and Xerox App Gallery

concurrent jobs)

82 ppm black-and-white and colour (simplex) 141 ipm black-and-white and colour (duplex)

135 ppm black-and-white and colour (simplex) 270 ipm black-and-white and colour (duplex)

Support 250 scan templates Create Xerox

CentreWare® IS scan templates and share via device cloning to other multifunction printers’ conﬁrmation sheet options

Black-and-white TIFF (G3MH, G4 MMR compression – single or multiple pages) Searchable PDF/OCR and PDF/A-1b (MRC, JPEG, G3 MH, G4 MMR, JBIG 2 Huffman, JBIG Arithmetic Compression, Deﬂate (for black-and-white and within MRC)) Linearised PDF / PDF/A

Features only available in Network Scan-to-File Templates:

• 1 to 6 user-programmable metadata ﬁelds per network scan to ﬁle templates and unlimited ﬁelds within the template –

Metadata ﬁeld consists of ﬁeld name, default value and other conﬁgurations

• Customised ﬁelds viewed on user interface for variable data input

Scan Preview Compression Quality/File Size Control Original Type (Photo and Text, Photo, Text, Map, Newspaper / Magazine) Auto Background and Shadow Suppression Size for Size (for mixed size originals) TWAIN Support / WIA 2.0 Support Bound Originals Edge Erase Reduction/Enlargement Single Touch Scan buttons (up to 10)

options

• Scan to Email S/MIME Encryption

• Email signing (requires Smart Card option)

• Auto send to self

Scan to Network Folder (using Secure FTP/HTTP/HTTPS) Scan to Home Scan to Network (using Secure FTP/HTTP/HTTPS) Scan to Email Scan to PC/Server Client (SMB or FTP) Scan to Mailbox

ecopy ShareScan v5.2 eCopy ScanStation v5.2

Scan to/from: Dropbox™, Google Drive™, Microsoft

OneDrive®, Microsoft Ofﬁce 365™, Box®, Xerox® Workplace Mobile App (iOS/Android)

See the full list of apps available in the Xerox App Gallery: xerox.com/AppGallery

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Security AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Features • Expanded Authentication

Xerox® Integrated RFID Card Reader (Optional kit)

- Network authentication to access device and/or device services via Kerberos (UNIX / Windows Server 2008), SMB (Windows Server 2008, Windows server 2012), NDS, LDAP authentication

- Local Authentication (internal database)

- Smart Card authentication – 144k CAC / PIV Card Support (2,048-bit certiﬁcate key) / .NET

- Secure Data

- Digitally signed PDF (when using Smart Card authentication)

- Encrypted and authentication to SMTP server for Scan to Email

- Encrypted / Password-Protected PDF (when using Email and Network Scan Templates only)

- Secure Print (up to 10-digit PIN or Network Authentication)

- Immediate Image Overwrite / Securely delete jobs using approved algorithms

- On-Demand Image Overwrite (Scheduled, Manual), includes sanitation of unused area of disk

- FIPS 140-2 256 bit Hard Disk Encryption, TLS, IPPS, HTTPS, SFTP, SNMPv3

• Expanded Authorisation

- SA access based on network credentials

- Authorisation per user per service

- User Permissions required to access Print and Print Features (e.g. colour access or time restrictions) reﬂects in the print driver

- Secure Network Access

• Conﬁguration Watchdog (Monitor and remediate 29 security settings):

- Front USB Port 2

- Rear USB Port 1

- Rear USB Port 2

- Password Reset Access Control

- 802.1x

- Email Alerts - Group 1, 2 and 3 addresses, enablement, Recipient Group Preferences

- Hold all jobs

- Reprint Saved Jobs

- Scan to Mailbox enablement

- Fax Passcode length

- System timeout

- Show/Hide Login Name

- PostScript® Passwords

- Remote Services Set-up Supplies / Consumables: Enablement

- Remote Services Set-up Supplies / Consumables: Software Download

- Remote Services Set-up Supplies / Consumables: Feature Activation

- Remote Services Set-up Supplies / Consumables: Update Device Settings

- Remote Services Set-up Supplies / Consumables: Daily Synchronisation Time

- Remote Services Set-up Supplies / Consumables: Automatically Send Diagnostic Information

- FIPS 140-2 Encryption

- Firmware Updates (Firmware Upgrade) Enable/Disable

- Scheduled Upgrade

- SNMP V1/V2 Protocols: Enable/ Disable Services

- Scan services on multifunction printers

- Remote Start (TWAIN) Scan services on multifunction printers

- Scan Workﬂow Management

- PII - Conceal Job Names

- PII - Show Concealed Job Names in Network Accounting Reports

- PII - Show Concealed Job Names in Audit Logs

• IP Filter, IPsec, IPv6, TLS v1.0, v1.2, SNMPv3, HTTPs, 802.1X, SFTP

• McAfee® Embedded Control (whitelisting), McAfee® Integrity Control (optional)

• Port disablement including USB ports

• Audit Log

• Hide Print Job Names

• Cisco® Identity Services Engine (ISE) compatible

• Security Information and Event Management (SIEM) support for McAfee Enterprise Security Manager, LogRhythm and Splunk

• Full System Common Criteria certiﬁed by NIAP under HD Protection Proﬁle for Hardcopy Devices v1.0 (HCD-PP v1.0)

Integrated support for most industry security cards providing additional security; with embedded multifunction printer card readers in the multifunction printer panel.

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Fax AltaLink® C8130 AltaLink® C8135 AltaLink® C8145 AltaLink® C8155 AltaLink® C8170

Network Server Fax Features

Compatibility ITU (CCITT) group 3; Various Xerox Business Innovation Partner Solutions

Maximum Scan Area A3

Fax Send Features One- or Two-sided Scanning (up to A3)

Fax Print Features One- or Two-sided Printing, Staple, Secure Print

Transmission Resolution Superﬁne: 400 x 200 dpi (Scan at 600 x 600 dpi)

Internet Fax Features

Compatibility Direct print-ready document transmission to remote Internet Fax machines or email clients (SMTP)

Directory Access Utilises the Uniﬁed Address Book

Send / Receive Send: Multi-page TIFF, PDF, PDF/A

Resolution 72 x 72 dpi to 600 x 600 dpi

Network Protocols SMTP (send), POP3 (receive)

Compliance ITU-T T.37

Walk-up Fax Features (Optional; Customer-Installable – 1 and 2 lines)

Compatibility ITU (CCITT) Group 3

Speed / Modems One or Two V.34 modems: 33,600 bps. Less than 4 seconds per page transmission time

Compression / Speed MH/G3, MR/G3, MMR/SG3, JBIG/SG3

Resolution Walk-up Send:

Fax Send Features LAN Fax (fax from print driver)

Fax Receive Features One- or Two-sided Printing

Fax forward Forward to Email or SMB Location

Fax Reports Activity, Dial Directory, Group Directory, Transmission Conﬁrmation, Pending Fax, Options Report, On Demand Overwrite Report, Mailbox Report,

Directory Access Utilises the Uniﬁed Address Book

Auto Redial Up to 14 attempts (per country requirements)

Auto Resend Up to 5 attempts

Add to Send List (200 numbers maximum) Build Job, Favourites, Delay Send (speciﬁc time) Original Type (photo, text or photo and text)

Fine: 200 x 200 dpi Standard: 200 x 100 dpi

Reception and automatic printout of documents sent via email from remote Internet Fax machines or email clients

Receive: TIFF, MTIFF, PDF, PDF/A, PS, text, PCL, PRN, JPEG

Bit Depth: 1-bit (black-and-white)

Standard: 200 x 100 dpi Fine: 200 x 200 dpi Superﬁne: 600 x 600 dpi Receive: Accepts all sizes

Auto Fax Transmission Reduction Page-by-page Job Status at the Machine Delay Start, Build Job, Favourites Automatic Memory Resend Automatic Cover Sheets PSTN Fax Batch Send (up to memory capacity) Device Address Book (up to 5,000 contacts)

Stapled or Unstapled Receive Print Mode – Manual (size, margin, stock, header) / Auto Output Tray Selection Up to 200 Password-Protected Mailboxes Secure Receive Receive Timestamp Auto Answer Delay

Fax Forward on Receive Only

Broadcast Report

Group fax available

1 to 25 minute intervals

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Device Management

Administrative Protocols DHCP, BOOTP, SNMP, SLP

Management Support SNMP Version 1. SNMP Version 2c and SNMP Version 3 trap over TCP/IP and IP

MIB access (IETF-MIBII RFC 1213) Host Resources MIB RFC 2790, Printer MIB RFC 3805, PWG-Imaging-System- Power MIB, Conﬁguration Orchestrator, Conﬁguration Watchdog

Xerox

CentreWare® Web A web-based server application for network administrators that permits web browser-based device management from any workstation, whether running

Windows, UNIX or any other operating system:

• Works with any SNMP-managed printer from any manufacturer.

• Provides help with device discovery and installation, health checks and troubleshooting, and device upgrades, as well as basic accounting and asset management.

• Requires Windows 7 and Internet Explorer 6.0 and higher.

• Auto-detect Xerox

Device Manager Xerox® Device Manager collects and manages the data that drives fact-based decisions for your enterprise device management environment. It is a

Xerox

single tool to install print queues and conﬁgure, manage, monitor and report on both networked and locally connected devices – regardless of vendor – across your enterprise. Xerox

• Device monitoring and troubleshooting

• Extensive reporting and discovery of new devices

• Usage collection, chargeback and billing capabilities

• Auto-detect Xerox

Fleet Orchestrator The Fleet Orchestrator feature offers the ability to create a group of devices that share information with each other via a secure peer-to-peer

The following data can be shared: Software update ﬁles, clone ﬁles and 1-Touch App ﬁles.

Novell NDPS/NEPS Server gateway application: centralised management tool.

Xerox

Device Types for

SAP Environment

Xerox, together with SAP through our Gold-level membership in the SAP Printer Vendor Programme, provides seamless connectivity between SAP systems and your Xerox right from SAP’s online delivery model. SAP-certiﬁed device types for Xerox

ofﬁce.xerox.com/Software-Solutions

Xerox

Device Types for SAP R/3 Intelligent Barcode Utility (optional)

Barcode Pro PS

Xerox (optional)

Provides built-in process intelligence that allows the printing of barcodes on any appropriately conﬁgured PostScript printer in speciﬁc versions of SAP environment and within Latin-1 (ISO8859-1) SAP system code pages only. Used in conjunction with Xerox ment and Xerox

Enables intelligent PostScript printing on Xerox® multifunction printers by storing Xerox® software, as well as the barcode fonts on the printer hard disk. Enables the printing of barcodes from any application (SAP client or mainframe) that supports PostScript printing. Information available at

ofﬁce.xerox.com/Software-Solutions

Xerox

Embedded Web Server – Integrated Device Web Pages Provided by the Device

Device Status Web server embedded in Network Controller:

• Tray status/contents

• Consumables status

• Alerts

• Remote Control Panel

Job Submission Print-ready ﬁles: PS, PCL, TIFF, PDF, JPG, TXT, PRN

Output feature selection (2-sided, output colour, collate, orientation, staple, hole punch, folding, output destination) Delivery options (Immediate, sample set, delay and secure, Save job or reprint)

Device Administration Allows simple, remote installation setting of conﬁguration options and management of the device, Fleet Orchestrator

Browsers Internet Explorer 10.x, 11.x

Safari 10.x, 11.x Mozilla Firefox 45.x to 53.x Opera 25.x to 53.x Chrome 48.x to 72.x

Support Install print / scan drivers and online support available via support.xerox.com

Languages Supported International English, International French, Italian, German, International Spanish, Dutch, Brazilian Portuguese, Swedish, Norwegian, Danish, Finnish,

Russian, Simpliﬁed Chinese, Korean, Japanese, Arabic

Remote Services

Xerox

Automatic Meter Readings (AMR)

Xerox

Automatic Supplies

Automates the process of collecting and submitting meter reads for the tracking and billing of Xerox® device usage. Eliminates the need for time-consuming end-user involvement and ensures that meter reads are submitted to Xerox on time.

Automatically orders supplies for Xerox® output devices based on actual usage, eliminating the need to manually manage supplies inventory.

Replenishment (ASR)

Accounting

Xerox

Standard Accounting (Standard)

Tracking Copy, Print, Fax, Scan and Email usage

Accounting Up to 2,497 User Accounts (User ID)

Up to 500 General Accounts (Client) Up to 498 Group Accounts (Department)

Features • Administrator can manage the feature via the Web User Interface or device control panel in tools.

• Administrator has the ability to import or export user accounts, Group Accounts, General Accounts and User limits via an industry-standard CSV ﬁle.

Accounting Options – Network Accounting (Allows central server to manage all accounting)

• Enhanced network accounting with up-to-the-minute data on how the system is being used

• Comprehensive management and enterprise-scale tracking and reporting of device usage of copy, print, scan and server fax

• Numerous solutions are available through Xerox Alliance Partners. For details, visit www.xerox.com

• Security enhancements with the addition of HTTPS protocol support

• Device requests account authentication from third-party server enabling larger databases of users and accounts

• Accept Authentication Login at the control panel and pass to a third-party Networking Account

• Interface with a third-party accounting terminal for accounting user interface

v2, HTTP, HTTPS, DHCP Autonet, TLS, NTP, DNS, SMB, SMTP/POP3, WSD, LDAP, Multicast DNS

CentreWare® Web server and download conﬁgurations ﬁles for touchless remote installation

Device Manager provides:

Device Manager server and download conﬁgurations ﬁles for touchless remote install

printers and multifunction printers. As an SAP customer, you beneﬁt from having SAP-certiﬁed Xerox® device types available

printers and multifunction printers are available to download.

Font Centre Barcode Fonts. Information available at ofﬁce.xerox.com/Software-Solutions

PostScript Device Types for SAP environ-

connection

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Xerox® EX-c C8100 Print Server Powered by Fiery® (Optional)

Processor AMD

Memory (ESS) 2 GB

System Disk 500 GB HDD

Page Description Language PostScript v 3020

Features Fiery Command WorkStation for Mac and Windows clients (customer provided)

Connectivity 10 Base-T/100 Base-TX/1000 Base-T Ethernet

Optional Fiery Options Bundle (Fiery Spot-On, Auto Trapping, Hot Folders, Virtual Printers), Fiery Hot Folders/Virtual Printers, Fiery Spot-On, Fiery Colour Proﬁler

GX-424CC processor, 2.4 GHz, Quad-Core, 2M cache

Fiery drivers for Mac and Windows Job Preview Job Presets Image Enhance Spool-RIP-Print simultaneously Automatic two-sided printing N-up Watermarks Calibration

PANTONE

Colour Enabled Expert Colour Settings: Proﬁle, Rendering and Simulation Fiery FreeForm Create to create personalised ﬁles for free Booklet Maker – booklet wizard to create booklets Standard support for long sheet banners Print from USB ﬂash drive Secure Erase Encryption of critical information Secure Printing User authentication Access controls PostScript security Port blocking IP ﬁltering Digitally signed software updates Fiery API Integrates with common cost accounting software, Xerox Standard Accounting, Xerox App Gallery apps and more

Suite w/EFI ES-2000 Spectrophotometer, Network Switch to connect both printer and Fiery Server to network

Xerox® AltaLink® C8130/C8135/C8145/C8155/C8170 Colour Multifunction Printer

Supplies Description Yield

Toner Cartridge

Transfer Belt Cleaner 1 Assembly 160,000 pages

Second Bias Transfer Roll 1 Assembly 200,000 pages

Staple Cartridges For BR Finisher, Integrated Ofﬁce Finisher, Ofﬁce Finisher

Staple Reﬁlls For Integrated Ofﬁce Finisher, Ofﬁce Finisher, BR Finisher and Convenience Stapler (3 reﬁlls per carton) 5,000 each reﬁll

Fan Filter 1 Assembly (AltaLink C8170) 500,000 pages

Xerox

Drum Cartridge

Waste Toner Container w/o Suction Filter

Waste Toner Container with Suction Filter

Maximum volume capacity expected in any one month. Not expected to be sustained on a regular basis.

Available post-launch via software update.

Not available in all geographical locations.

Paper capacities are based on 75 gsm stock; capacities will vary with different weight stocks.

Sold separately in some geographical locations.

Average standard pages. Declared in accordance with ISO/IEC 19798. Toner yield can vary due to many factors, including but not limited to, image area coverage, image content, media size, media orientation, run

mode, application types, monthly print volumes and image quality set-points.

Under evaluation; certiﬁcation expected in Q4 2020.

Average drum yield is based on a run length of 5 pages of A4 LEF pages, with split of 35% colour / 65% black-and-white pages.

Waste Toner Container yield will vary depending on type of image, area coverage % and job run length.

Smart Kit

Black Cyan Magenta Yellow

59,000 pages 28,000 pages 28,000 pages 28,000 pages

5,000 each cartridge

and Convenience Stapler (1 cartridge per carton)

For BR Booklet Maker (1 cartridge per carton) 5,000 each cartridge

For Ofﬁce Finisher Booklet Maker (8 cartridges per carton) 2,000 each cartridge

1 Cartridge per Colour 180,000 pages

1 Cartridge (AltaLink C8130/35/45/55) 69,000 pages

1 Cartridge (AltaLink C8170) 69,000 pages

Return spent imaging supplies through the Xerox Green World Alliance collection/reuse/recycling programme. For more information, visit www.xerox.com/About-Xerox/Recycling.

For more information, visit us at www.xerox.com/Ofﬁce.

© 2020 Xerox Corporation. All rights reserved. Xerox®, AltaLink®, CentreWare®, ConnectKey®, Copier Assistant®, DocuShare®, Global Print Driver®, MeterAssistant®, SmartKit® and SuppliesAssistant® are trademarks of Xerox Corporation in the United States and/or other countries. As an ENERGY STAR® partner, Xerox Corporation has determined that this product meets the ENERGY STAR guidelines for energy efﬁciency. ENERGY STAR and the ENERGY STAR mark are registered US marks. Mopria is a trademark of the Mopria Alliance. The information in this brochure is subject to change without notice. 10/20 TSK-861 AC8SS-03EC BR29564

Xerox C8130, C8135, C8145, C8155, C8170 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
