Xantrex Technology XDC 60-100SL, XDC 30-200SL, XDC 40-150SL, XDC 100-60SL, XDC 10-600SL User Manual
...
TM-XDSL-01XN.book Page i Tuesday, November 5, 2002 3:22 PM
XDC 10-600SL
XDC 20-300SL
XDC 30-200SL
XDC 40-150SL
XDC 60-100SL
XDC 80-75SL
XDC 100-60SL
XDC 150-40SL
XDC 300-20SL
XDC 600-10SL
XDC 6000 Watt Series
Slave Power Supply
Operating Manual
TM-XDSL-01XN.book Page ii Tuesday, November 5, 2002 3:22 PM
TM-XDSL-01XN.book Page i Tuesday, November 5, 2002 3:22 PM
Operating Manual for
XDC 6000 Watt Series
Slave Power Supply
TM-XDSL-01XN.book Page ii Tuesday, November 5, 2002 3:22 PM
Limited
Warranty
What does this warranty cover and how long does it last?
This Limited Warranty is provided by Xantrex Technology, Inc. (“Xantrex”) and
covers defects in workmanship and materials in your XDC 6000 Watt Series Slave
Power Supply. This warranty lasts for a Warranty Period of 5 years from the date
of purchase at point of sale to you, the original end user customer.
What will Xantrex do?
Xantrex will, at its option, repair or replace the defective product free of charge,
provided that you notify Xantrex of the product defect within the Warranty Period,
and provided that Xantrex through inspection establishes the existence of such a
defect and that it is covered by this Limited Warranty.
Xantrex will, at its option, use new and/or reconditioned parts in performing
warranty repair and building replacement products. Xantrex reserves the right to use
parts or products of original or improved design in the repair or replacement. If
Xantrex repairs or replaces a product, its warranty continues for the remaining
portion of the original Warranty Period or 90 days from the date of the return
shipment to the customer, whichever is greater. All replaced products and all parts
removed from repaired products become the property of Xantrex.
Xantrex covers both parts and labor necessary to repair the product, and return
shipment to the customer via a Xantrex-selected non-expedited surface freight
within the contiguous United States and Canada. Alaska and Hawaii are excluded.
Contact Xantrex Customer Service for details on freight policy for return shipments
outside of the contiguous United States and Canada.
How do you get service?
If your product requires troubleshooting or warranty service, contact your merchant.
If you are unable to contact your merchant, or the merchant is unable to provide
service, contact Xantrex directly at:
Phone: 604 422 2777
Toll Free North America: 1 800 670 0707
Fax: 604 420 2145
Email: customerservice@xantrex.com
ii Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page iii Tuesday, November 5, 2002 3:22 PM
Direct returns may be performed according to the Xantrex Return Material
Authorization Policy described in your front panel controlled XDC product manual.
For some products, Xantrex maintains a network of regional Authorized Service
Centers. Call Xantrex or check our website to see if your product can be repaired at
one of these facilities.
In any warranty claim, dated proof of purchase must accompany the product and the
product must not have been disassembled or modified without prior written
authorization by Xantrex.
Proof of purchase may be in any one of the following forms:
• The dated purchase receipt from the original purchase of the product at point of
sale to the end user, or
• The dated dealer invoice or purchase receipt showing original equipment
manufacturer (OEM) status, or
• The dated invoice or purchase receipt showing the product exchanged under
warranty
What does this warranty not cover?
This Limited Warranty does not cover normal wear and tear of the product or costs
related to the removal, installation, or troubleshooting of the customer’s electrical
systems. This warranty does not apply to and Xantrex will not be responsible for any
defect in or damage to:
a. the product if it has been misused, neglected, improperly installed, physically
damaged or altered, either internally or externally, or damaged from improper
use or use in an unsuitable environment;
b. the product if it has been subjected to fire, water, generalized corrosion,
biological infestations, and high input voltage from lightning strikes;
c. the product if repairs have been done to it other than by Xantrex or its authorized
service centers (hereafter “ASCs”);
d. the product if it is used as a component part of a product expressly warranted by
another manufacturer;
e. the product if its original identification (trade-mark, serial number) markings
have been defaced, altered, or removed.
Release 1.0 iii
TM-XDSL-01XN.book Page iv Tuesday, November 5, 2002 3:22 PM
Disclaimer Product
THIS LIMITED WARRANTY IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED
BY XANTREX IN CONNECTION WITH YOUR XANTREX PRODUCT AND IS, WHERE
PERMITTED BY LAW, IN LIEU OF ALL OTHER WARRANTIES, CONDITIONS,
GUARANTEES, REPRESENTATIONS, OBLIGATIONS AND LIABILITIES, EXPRESS
OR IMPLIED, STATUTORY OR OTHERWISE IN CONNECTION WITH THE PRODUCT,
HOWEVER ARISING (WHETHER BY CONTRACT, TORT, NEGLIGENCE, PRINCIPLES
OF MANUFACTURER’S LIABILITY, OPERATION OF LAW, CONDUCT, STATEMENT
OR OTHERWISE), INCLUDING WITHOUT RESTRICTION ANY IMPLIED WARRANTY
OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE TO THE EXTENT REQUIRED UNDER
APPLICABLE LAW TO APPLY TO THE PRODUCT SHALL BE LIMITED IN DURATION
TO THE PERIOD STIPULATED UNDER THIS LIMITED WARRANTY.
IN NO EVENT WILL XANTREX BE LIABLE FOR ANY SPECIAL, DIRECT, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSSES, COSTS OR EXPENSES
HOWEVER ARISING WHETHER IN CONTRACT OR TORT INCLUDING WITHOUT
RESTRICTION ANY ECONOMIC LOSSES OF ANY KIND, ANY LOSS OR DAMAGE TO
PROPERTY, ANY PERSONAL INJURY, ANY DAMAGE OR INJURY ARISING FROM OR
AS A RESULT OF MISUSE OR ABUSE, OR THE INCORRECT INSTALLATION,
INTEGRATION OR OPERATION OF THE PRODUCT.
Exclusions If this product is a consumer product, federal law does not allow an exclusion of
implied warranties. To the extent you are entitled to implied warranties under federal
law, to the extent permitted by applicable law they are limited to the duration of this
Limited Warranty. Some states and provinces do not allow limitations or exclusions
on implied warranties or on the duration of an implied warranty or on the limitation
or exclusion of incidental or consequential damages, so the above limitation(s) or
exclusion(s) may not apply to you. This Limited Warranty gives you specific legal
rights. You may have other rights which may vary from state to state or province to
province.
iv Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page v Tuesday, November 5, 2002 3:22 PM
Information WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, UNLESS
SPECIFICALLY AGREED TO BY IT IN WRITING, XANTREX
a. MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY
OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN MANUALS OR
OTHER DOCUMENTATION PROVIDED BY IT IN CONNECTION WITH THE
PRODUCT; AND
b. ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES,
COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT,
CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF
SUCH INFORMATION.
THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.
WARNING:
Limitations
on Use
Information
About Your
Power
Supply
Please refer to your product user manual for limitations on uses of the product.
Specifically, please note that this power supply is not intended for use in connection
with life support systems and Xantrex makes no warranty or representation in
connection with any use of the product for such purposes.
Xantrex Technology, Inc.
8999 Nelson Way
Burnaby, British Columbia
Canada V5A 4B5
Please record the following information when you first open your Power Supply
package:
Model Number ______________________________________________
Serial Number ______________________________________________
Purchased From ______________________________________________
Purchase Date ______________________________________________
Release Release 1.0 (2002-09)
Copyright © 2002 Xantrex Technology Inc. All rights reserved.
Printed in Canada
Release 1.0 v
!
!
!
TM-XDSL-01XN.book Page vi Tuesday, November 5, 2002 3:22 PM
Warnings
and
Cautions
Power
Supply
Safety
Warnings and cautions are defined and formatted in this manual as shown below.
WARNING
Describes a potential hazard which could result in injury or death, or, a procedure
which, if not performed correctly, could result in injury or death.
CAUTION
Describes a procedure which, if not performed correctly, could result in damage
to data, equipment, or systems.
WARNING—High Energy and High Voltage
Exercise caution when using and calibrating a power supply. High energy levels
can be stored at the output voltage terminals on a power supply in normal
operation. In addition, potentially lethal voltages exist in the power circuit and on
the output and sense connectors of a power supply with a rated output greater
than 40 V. Filter capacitors store potentially dangerous energy for some time after
power is removed.
CAUTION
Operate the power supply in an environment free of flammable gases or fumes. To
ensure that the power supply’s safety features are not compromised, use the
power supply as specified in this manual and do not substitute parts or make any
unauthorized modifications. Contact the service technician for service and repair
help. Repairs must be made by experienced service technicians only.
CAUTION
For Use as a Battery Charger
When you are using any of these power supplies for battery charging applications,
it is essential to provide an appropriately sized fuse or circuit breaker in series
between the power supply output and the battery.
Installation of a protector (fuse or DC circuit breaker) rated for about 115% of the
maximum current rating of the power supply and designed specifically to interrupt
the DC voltage of the battery, will provide adequate reverse polarity current
protection. Where several power supplies are in parallel, it is best to fuse each one,
rather than one large fuse for all.
vi Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page vii Tuesday, November 5, 2002 3:22 PM
Approvals CE Mark
CE-marked units meet the following standards:
• IEC 1010-1-92 including Amendments 1 and 2:
• Overvoltage Category II
• Permanently Connected Equipment
• Pollution Degree 2
• EN50081-2-1996 Electromagnetic Generic Emission - Industrial Equivalent
• EN50082-2-1995 Electromagnetic Compatibility Generic Immunity - Industrial
Environment
CSA Certified
CSA C22.2 No. 1010.1-92
UL Listed (pending)
Meets UL3101-1 Electrical Equipment for Laboratory Use; Part 1: General
Requirements
General safety requirements for electrical equipment intended for professional,
industrial process, and educational use, including equipment and computing devices
for: measurement and test; control; laboratory use; and accessories intended for use
with the above.
FCC Compliance
FCC Part 15 - Radio Frequency Devices - Class A Limits
Canadian EMC Requirements
The unit complies with Canadian EMC requirements of ICES-001.
Release 1.0 vii
TM-XDSL-01XN.book Page viii Tuesday, November 5, 2002 3:22 PM
viii Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page ix Tuesday, November 5, 2002 3:22 PM
About This Manual
This Operating Manual contains operating instructions for the XDC Series Slave
power supplies. This power supply is based on the XDC Series of digital,
programmable power supplies, with the same high level of accuracy and reliability,
but specifically designed with no front panel interface for use as a slave unit
controlled via CANbus (Control Area Network bus).
Who Should Use This Manual
This manual is designed for users who understand basic electrical theory, especially
as applied to the operation of power supplies. This implies a recognition of constant
voltage and constant current operating modes and the control of input and output
power, as well as the observance of safe techniques while making connections to the
supply and any changes in settings.
Revisions
This manual is intended to be used in conjunction with the full digital front panel
XDC Series Operating manual. If you do not plan to use this power supply in a
system with a full digital front panel XDC Series power supply, please contact the
manufacturer for additional application data.
The current release of this manual is listed in the right-hand page footer. Insert pages
may update already-printed manuals.
Release 1.0 (2002-09)
Release 1.0 ix
TM-XDSL-01XN.book Page x Tuesday, November 5, 2002 3:22 PM
About This Manual
x Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page xi Tuesday, November 5, 2002 3:22 PM
Table of Contents
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Section 1. Overview
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Section 2. AC Input Power
AC Input Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AC Input Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
AC Wire Input Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Section 3. Current Sharing
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
CANbus Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Current Share Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setup Current Sharing Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Appendix A. Specifications and Characteristics
Electrical Specifications—Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
AC Line Input Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
AC Line Input Voltage Operating Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Output Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Environmental Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Thermal Specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Humidity Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
International Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Mechanical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Release 1.0 xi
TM-XDSL-01XN.book Page xii Tuesday, November 5, 2002 3:22 PM
Table of Contents
xii
Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 13 Tuesday, Novem ber 5, 2002 3:22 PM
Section 1. Overview
The XDC series Slave power supply is designed for use in current sharing systems
as a slave module connected in parallel with an XDC 6000 Watt series full digital
controlled front panel unit. In such a configuration, the XDC full digital controlled
front panel unit is acting as the master of the current sharing system. The
communication between the master and slave is made via a CANbus digital interface
to control all the parameters needed for proper current sharing.
The XDC 6000 Watt series full digital controlled front panel unit used as a master
needs to be the same model as the slave module (i.e. Voltage-Current), and be
equipped with the CANbus digital interface (optional on the XDC 6000 Watt series).
It also needs the proper firmware version for the control mother board (see page 19).
Features
• Supports up to five XDC units in current sharing configuration (one master and
four slaves)
• Front panel with the standard rack mount brackets, handles, ON/OFF switch and
two status LEDs (one green for POWER ON and one red for OUTPUT OFF - lit
when the output is off)
• Standard CANbus and RS-232 digital remote control
• Auto Addressing in current share initialization
• Digital processing for accurate control
• CE mark, UL and CSA Approvals, FCC compliant
Release 1.0 13
TM-XDSL-01XN.book Page 14 Tuesday, Novem ber 5, 2002 3:22 PM
Overview
Front Panel
Front Panel
1
3
4 5 6
2
Figure 1.1 Slave Front Panel
1. Rack mount brackets
2. Handles
3. ON/OFF Switch
4. Power On status LED (green)
5. Ouput Off status LED (red) Lit when the output is disabled
6. Front panel display (vacuum fluorescent display)
1
2
14 Operating Manual for XDC Series Slave Power Supply
!
TM-XDSL-01XN.book Page 15 Tuesday, Novem ber 5, 2002 3:22 PM
Section 2. AC Input Power
WARN I N G
Disconnect AC power from the unit before removing the connector cover. Live line
voltages may be exposed when the cover is removed.
WARN I N G
A safety ground wire must be connected to the unit as shown in Figure 2.1 to ensure
operator safety.
CAUTION
When the power switch is turned on, output voltage or current previously set may be
applied to loads, depending on the supply configuration.
AC Input Power
Front Panel
Release 1.0 15
TM-XDSL-01XN.book Page 16 Tuesday, Novem ber 5, 2002 3:22 PM
AC Input Power
AC Input Connector
AC Input Connector
The AC input connector is a standard wire clamp terminal block with 3-phase
connectors and a chassis ground connector. The safety ground wire, alternatively,
may be connected to the chassis using a ring tongue on the ground stud as shown in
Figure 2.1.
Ground Connection
3-Phase Terminal Block Connectors
Figure 2.1 AC Input Connector
AC Input Wire
The manufacturer recommends the AC input wire specified in Table 2.1. This must
be permanently connected to an approved AC distribution box with suitably rated
over-current protection. If you require a special cord, contact the manufacturer.
Table 2.1 AC Wire Specification for 6000 Watt units
AC Input Voltage Range Wire
190–242Vac, 47–63Hz,
3-phase, 4 wire (standard)
342–500Vac, 47–63Hz,
3-phase, 4 wire (HV-Input)
16 Operating Manual for XDC Series Slave Power Supply
4 x 10 AWG (3 wire plus safety ground), stranded
copper, 60
cable diameter, rated for 25A.
4 x 14 AWG (3 wire plus safety ground), stranded
copper, 60
cable diameter, rated for 13A.
°C minimum, 300V, 0.800 in. maximum
°C minimum, 600V, 0.800 in. maximum
TM-XDSL-01XN.book Page 17 Tuesday, Novem ber 5, 2002 3:22 PM
AC Wire Input Connection
See Figure 2.2, on page 18.
To connect the AC input wires:
1. Ensure that the AC input cord is de-energized, and that the power switch on the
front of the power supply is OFF.
2. Strip approximately 6.25 in. (160 mm) from the jacket of the AC wire. Strip
0.55 in. (14 mm) at the end of each wire.
3. Undo the 2 screws for the AC wiring strain relief/cover on the rear panel.
Remove the cover.
4. Undo the strain relief screws. Insert the AC input cable through the strain relief
until the outer cable jacket is flush with the inside of the strain relief. Tighten the
strain relief cable clamp screws.
AC Input Power
AC Wire Input Connection
5. Insert the ground wire (green) 0.55 in. (14 mm) into the left-most terminal
location, and tighten securely
1
. (The safety ground wire may alternatively be
connected to the chassis ground stud next to the terminal block, using a suitably
sized ring terminal).
6. Route the AC wires to the input terminal block by connecting the red, black, and
white wires to the remaining 3 cable clamp connectors. There is no set order for
connecting the wires. Any of the 3-phase wires can be connected to any of the 3
line input connectors. To connect each wire, loosen the terminal screw, insert the
stripped wire 0.55 in. (14 mm) into the terminal, and tighten the screw securely
7. Reinstall the AC input strain relief/cover, routing wires inside the cover to
prevent pinching.
8. Connect the free end of the cable to the AC source, checking that the voltage is
within the approved input range for the supply.
9. Energize the AC input.
It is now safe to turn the power supply on.
1
.
1. Torque maximum 2 Nm/16 lb. in.
Release 1.0 17
TM-XDSL-01XN.book Page 18 Tuesday, Novem ber 5, 2002 3:22 PM
AC Input Power
AC Wire Input Connection
Figure 2.2 Attaching the AC Input Wires
18 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 19 Tuesday, Novem ber 5, 2002 3:22 PM
Section 3. Current Sharing
Overview
Power supplies equipped with the CANbus interface will allow current sharing
between units connected in parallel. Current sharing can use a maximum of 5
supplies, including the master. All power supplies must be the same model. Every
unit must have a unique address, if they do not then they will automatically readdress
themselves.The slave units are shipped with the current share feature already
enabled.
Current Sharing
Overview
No DisplayNo DisplayNo DisplayNo Display
Figure 3.1Connections for Current Share Operation
Theory of
Operation
Power supplies may be connected in parallel to supply a large current to a load.
Typically, because of differences in the load connections, each power supply may
provide different amounts of current to the load. The function of current sharing is
to even out the current provided by each power supply.
When multiple power supplies are configured for current sharing, the master supply
will make small changes to the slave’s voltage and current settings to equalize the
current draw from each.
Note: Slave units will not current share with master units with firmware previous to
version 5.000.
Release 1.0 19
TM-XDSL-01XN.book Page 20 Tuesday, Novem ber 5, 2002 3:22 PM
Current Sharing
Overview
CANbus
Setup
The CANbus port is a one male, one female DB9 connector to support “daisy chain”
connections. The CAN (Controller Area Network) is an ISO standard (ISO11898)
for a serial communication network. Table 3.1 describes the pin functions. Pins 1, 4,
8, and 9 are not used. The CANbus is part of the optional GPIB/CANbus interface
card, which is required for communication between the master unit and its slave
units.
Table 3.1 CANbus Pins
Pin # Function
1 Not used
2 CANLO
3 Ground
4 Not used
5 Ground
6 Ground
7CANHI
8 Not used
9 Not used
Setup
1. Connect power supplies to be controlled via the CANbus network. Parallel male
DB9 to female DB9 cables (N-1) are required. Each slave unit is shipped with
one male-female DB9 8 in. ribbon cable. Connect the CAN interface cards in
series, linking the first power supply to the second using one cable, and then the
second to the third using a second cable and the second CAN port. A single
ribbon cable with multiple connectors may be used instead of several cables for
ease of connection. Terminate the bus at both ends with 120 ohm, 1/4 Watt
resistors (included) across the CAN HI and CAN LO signals (Pins 2 and 7). See
Table 3.1, “CANbus Pins,” on page 20.
2. The master power supply may be connected to a PC via RS-232 or GPIB.
3. Turn the power supplies on one at a time, starting with the master, and check that
the green “Power ON” LED on each slave unit is lit. As each slave is turned on,
it will automatically configure itself with a sequential unique address. The
address is retained in non-volatile memory.
Note: Only the first 4 slave units powered on will current share.
Note: Only units with the same output ratings will current share.
20 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 21 Tuesday, Novem ber 5, 2002 3:22 PM
Current Sharing
Overview
Current Share
Configuration
Setup
Current
Sharing
Network
Units are programmed in a mode such that it is already in current sharing mode on
power up. This feature is not user-modifiable. Please contact the manufacturer for
assistance if you wish to change this.
Most configurable settings available on a master 6kW unit are disabled on the slave
units for protection. All the queries are still available.
To set up multiple supplies for current share operation, follow these steps:
1. Power down the units. Connect the CAN ports of all paralleled units as explained
in “CANbus Setup”.
2. Make load connections. It is recommended to keep load cables the same length
if possible. See Figure 3.1.
3. Power up the master.
4. Power up the slaves one at a time.
5. Set the voltage and current on the master, then enable the output.
Release 1.0 21
TM-XDSL-01XN.book Page 22 Tuesday, Novem ber 5, 2002 3:22 PM
Current Sharing
Operation
Operation
There can only be one master unit and 4 slave units current sharing. All other units
will not current share. Units must have the same output ratings or they will not
current share.
Once a current sharing network is setup, you may adjust the voltage setpoint on the
master. The master will automatically adjust the setpoints of the slave units to
equalize the current output of all units. You may also disable or enable the output of
the master, automatically disabling or enabling the output of all slaves.
When a slave’s output is disabled for any reason, the master will disable the entire
current sharing network.
You may use local or remote (RS-232, GPIB, multichannel or analog) control to
operate the master.
Slaves will be operating under remote control from the master and in local lockout.
Hence, they will only respond to remote queries.
Errors A master or slave will be disabled from current sharing (set to "No share") if:
Specifications
The current limit setpoint on the master is still the current limit for a single unit, not
the current limit for the entire current sharing network. Please see the operating
manual shipped with your master unit (full digital controlled front panel unit).
Power supplies may not enter calibration mode while current sharing, or enter
current share operation while in calibration mode. To enter calibration mode, turn off
all other units on the CANbus network.
• there is more than one master connected to the CANbus, (Error +1811)
• there are more than 4 slaves, (Error +1822), or
• the model does not match that of the master’s, (Error +1822).
Max units on bus 49
Max current share units 5
Max cable length 40m
Bus speed 700 kbits/sec.
Termination 120 ohm, 1/4 Watt
Connections parallel male DB9 to female DB9 cable
22 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 23 Tuesday, Novem ber 5, 2002 3:22 PM
Appendix A. Specifications and Characteristics
Notes
• These specifications are represented over the full operating temperature range.
• Nominal line input voltage assumed unless otherwise stated.
• All sense lines are configured for default local operation.
• All specifications are subject to change without notice.
• Unless otherwise noted, these specifications are for single units, not multiple
configurations.
Release 1.0 23
TM-XDSL-01XN.book Page 24 Tuesday, Novem ber 5, 2002 3:22 PM
Specifications and Characteristics
Electrical Specifications—Summary
Electrical Specifications—Summary
Table A .1Specifications for 10V to 60V Models
Models 10-600 20-300 30-200 40-150 60-100
Output Ratings:
Output Voltage
Output Current
Output Power
Line Regulation:
Voltage (0.01% of Vmax)
Current (0.05% of Imax)
Load Regulation:
Voltage (0.05% of Vmax + 5 mV)
Current (0.1% of Imax + 20 mA)
Output Noise (0–20 MHz):
Voltage (p–p) 75 mV 75 mV 75 mV 75 mV 100 mV
Output Ripple (rms):
Voltage
Current
5
OVP Adjustment Range:
(0% to 103% of Vmax) 0–10.3 V 0–20.6 V 0–30.9 V 0–41.2 V 0–61.8 V
Efficiency:
1. Minimum output voltage is <0.3% of rated voltage at zero output setting.
2. Minimum output current is <0.2% of rated current at zero output setting when measured with rated load resistance.
3. For input voltage variation over the AC input voltage range, with constant rated load.
4. For 0–100% load variation, with constant nominal line voltage.
5. Current mode noise is measured from 10% to 100% of rated output voltage, full current, unit in CC mode.
6. Typical efficiency at nominal input voltage and full output power.
1
2
3
4
6
0–10 V
0–600 A
6000 W
1mV
300 mA
10 mV
620 mA
10 mV
3100 mA
0–20 V
0–300 A
6000 W
2mV
150 mA
15 mV
320 mA
10 mV
1600 mA
0–30 V
0–200 A
6000 W
3mV
100 mA
20 mV
220 mA
12 mV
1000 mA
0–40 V
0–150 A
6000 W
4mV
75 mA
25 mV
170 mA
15 mV
750 mA
0–60 V
0–100 A
6000 W
6mV
50 mA
35 mV
120 mA
15 mV
450 mA
0.85 0.87 0.87 0.87 0.89
Table A .2Drift Specifications for 10V to 60V Models
Models 10–600 20–300 30–200 40–150 60–100
Drift (30 minutes):
Voltage (0.04% of Vmax)
Current (0.6% of Imax)
Drift (8 hours):
Voltage (0.02% of Vmax)
Current (0.04% of Imax)
Temperature Coefficient:
Voltage (0.04% of Vmax/°C)
Current (0.06% of Imax/°C)
1. Maximum drift over 30 minutes with constant line, load, and temperature, after power on.
2. Maximum drift over 8 hours with constant line, load, and temperature, after 30 minute warm-up.
3. Change in output per °C change in ambient temperature, with constant line and load.
24 Operating Manual for XDC Series Slave Power Supply
1
4mV
3600 mA
2
2mV
240 mA
3
4mV
360 mA
8mV
1800 mA
4mV
120 mA
8mV
180 mA
12 mV
1200 mA
6mV
80 mA
12 mV
120 mA
16 mV
900 mA
8mV
60 mA
16 mV
90 mA
24 mV
600 mA
12 mV
40 mA
24 mV
60 mA
TM-XDSL-01XN.book Page 25 Tuesday, Novem ber 5, 2002 3:22 PM
Table A .3Specifications for 80V to 600V Models
Models 80–75 100–60 150–40 300–20 600–10
Output Ratings:
Output Voltage
Output Current
1
2
Output Power
Line Regulation:
3
Voltage (0.01% of Vmax)
Current (0.05% of Imax)
Load Regulation:
4
Voltage (0.05% of Vmax + 5 mV)
Current (0.1% of Imax + 20 mA)
Output Noise (0–20 MHz):
Voltage (p–p) 100 mV 100 mV 150 mV 250 mV 350 mV
Output Ripple (rms):
Voltage
Current
5
OVP Adjustment Range:
(0% to 110% of Vmax) 0–88 V 0–110 V 0–165 V 0–330 V 0–660 V
Efficiency:
1. Minimum output voltage is <0.3% of rated voltage at zero output setting.
2. Minimum output current is <0.2% of rated current at zero output setting when measured with rated load resistance.
3. For input voltage variation over the AC input voltage range, with constant rated load.
4. For 0–100% load variation, with constant nominal line voltage.
5. Current mode noise is measured from 10% to 100% of rated output voltage, full current, unit in CC mode.
6. Typical efficiency at nominal input voltage and full output power.
6
Specifications and Characteristics
Electrical Specifications—Summary
0–80 V
0–75 A
6000 W
8mV
37.5 mA
45 mV
95 mA
15 mV
320 mA
0–100 V
0–60 A
6000 W
10 mV
30 mA
55 mV
80 mA
20 mV
230 mA
0–150 V
0–40 A
6000 W
15 mV
20 mA
80 mV
60 mA
20 mV
120 mA
0–300 V
0–20 A
6000 W
30 mV
10 mA
155 mV
40 mA
30 mV
50 mA
0–600 V
0–10 A
6000 W
60 mV
5mA
305 mV
30 mA
80 mV
25 mA
0.89 0.90 0.90 0.91 0.91
Table A .4Drift Specifications for 80V to 600V Models
Models 80–75 100–60 150–40 300–20 600–10
Drift (30 minutes):
Voltage (0.04% of Vmax)
Current (0.6% of Imax)
Drift (8 hours):
Voltage (0.02% of Vmax)
Current (0.04% of Imax)
Temperature Coefficient:
Voltage (0.04% of Vmax/°C)
Current (0.06% of Imax/°C)
1. Maximum drift over 30 minutes with constant line, load, and temperature, after power on.
2. Maximum drift over 8 hours with constant line, load, and temperature, after 30 minute warm-up.
3. Change in output per °C change in ambient temperature, with constant line and load.
Release 1.0 25
1
32 mV
450 mA
2
16 mV
30 mA
3
32 mV
45 mA
40 mV
360 mA
20 mV
24 mA
40 mV
36 mA
60 mV
240 mA
30 mV
16 mA
60 mV
24 mA
120 mV
120 mA
60 mV
8mA
120 mV
12 mA
240 mV
60 mA
120 mV
4mA
240 mV
6mA
TM-XDSL-01XN.book Page 26 Tuesday, Novem ber 5, 2002 3:22 PM
Specifications and Characteristics
AC Line Input Specifications
AC Line Input Specifications
The input to the power supply requires the following specifications.
AC Line Input
Voltage
Operating
Ranges
Table A .5AC Line Input Specifications
Operating Range
nominal 208V
nominal 400V
(Standard)
rms
(with HV-Input option)
rms
Frequency Range 47 to 63 Hz
Maximum Peak In-rush Current at turn on 35 A
Minimum Power Factor
nominal 208V
nominal 400V
(Standard)
rms
(with HV-Input option)
rms
Operating Current
nominal 208V
Maximum
3
Typical
rms
2
(Standard)
Operating Current
nominal 400V
Maximum
5
Typical
1. At nominal input voltage and maximum power
2. At 190V
3. At 208V
4. At 342V
5. At 400V
input voltage, 55°C ambient temperature and maximum power
ac
input voltage, 25°C ambient temperature and maximum power
ac
input voltage, 50°C ambient temperature and maximum power
ac
input voltage, 25°C ambient temperature and maximum power
ac
(with HV-Input option)
rms
4
190 to 242 V
342 to 500 V
rms
1
3 φ (3 wire + safety ground)
ac
3 φ (3 wire + safety ground)
ac
0.95
0.9
24 A
20 A
13 A
11 A
26 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 27 Tuesday, Novem ber 5, 2002 3:22 PM
Output Performance Specifications
These specifications define the electrical performance specifications of the power
supply output. These specifications apply to both local and remote sense
configurations, except where noted. These specifications apply to all programming
sources, except where noted. These specifications are for single units, unless
otherwise indicated.
Rated Output Range
Voltage 0–100%
Current 0–100%
Efficiency
• Typical 89% efficiency at nominal line voltage and ambient temperature.
• Minimum 82% efficiency. Specific minimum efficiency limits are model
dependent.
Specifications and Characteristics
Output Performance Specifications
Load Regulation
Voltage 5 mV + 0.05% of Vmax
Current 20 mA + 0.1% of Imax
Power 1% of Pmax
Line Regulation
Voltage 0.01% of Vmax
Current 0.05% of Imax
Power 1% of Pmax
Programming Range for Voltage, Current, and Power
Voltage and Current From 0–103% of the rated maximum output
Power From 3–103% of the rated maximum output
OVP Programming Range
• 0–103% of maximum rated voltage
Release 1.0 27
TM-XDSL-01XN.book Page 28 Tuesday, Novem ber 5, 2002 3:22 PM
Specifications and Characteristics
Output Performance Specifications
Typical Programming Resolution
Remote Digital Interface
Voltage
Current
Power
Over Voltage Protection
Typical Measurement Resolution
Remote Digital Interface
Voltage
Current
Power
0.002% of Vmax
0.002% of Imax
0.05% of Pmax
0.002% of Vmax
0.002% of Vmax
0.002% of Imax
0.05% of Pmax
Programming Accuracy
Remote Digital Interface
Voltage Programming
Current Programming
Power Programming
Over voltage
Programming
Readback Accuracy
Remote Digital Interface
Voltage Readback
Current Readback
Power Readback
30 Minute Drift
Voltage 0.04% of Vmax
Current 0.6% of Imax
Power 1% of Pmax
2
1
0.1% of Vmax
0.5% of Imax
0.5% of Pmax
0.1% of Vmax
0.15% of Vmax
0.5% of Imax
0.5% of Pmax
1. Accuracy specifications apply for settings in range of 1% to 100% of rated output
2. At 25°C ±5°C, with full power load
28 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 29 Tuesday, Novem ber 5, 2002 3:22 PM
Specifications and Characteristics
Output Performance Specifications
8 Hour Drift Temperature Stability
Voltage 0.02% of Vmax
Current 0.04% of Imax
Power 0.1% of Pmax
Temperature Coefficients
Remote Digital Interface
Voltage Programming
Current Programming
Power Programming
Voltage Readback
Current Readback
Power Readback
0.04% of Vmax
0.06% of Imax/°C
0.1% of Pmax/°C
0.04% of Vmax/°C
0.06% of Imax/°C
0.1% of Pmax/°C
Switching Frequency
Typical 31 kHz; 62 kHz output ripple
Rise Time
5 to 95% step in output voltage.
Load Condition Time (Max)
No Load 100 ms
Full Load 100 ms
1
/°C
Fall Time
For a programmed 95% to 5% step in output voltage.
Load Condition Time (Max)
No Load
Full Load 50 ms
1. Fall time is ≤ 4s for 300 V and 600 V units.
1
3s
Time Delay From Power On Until Output Stable
5 s maximum
(Within regulation envelope)
1. At 25°C ±5°C after 30 minutes full load operation
Release 1.0 29
TM-XDSL-01XN.book Page 30 Tuesday, Novem ber 5, 2002 3:22 PM
Specifications and Characteristics
Output Performance Specifications
Time Delay From Output Enable Until Output Stable
2 s maximum
(Within regulation envelope)
Output Hold-Up Time – Power Off
Minimum 4 ms (at full load)
Output Hold-Up Time – Source Interruption
Minimum 4 ms with output deviation less than 5% of maximum output voltage after
source interruption.
Transient Response Time
1
Time to recover within 0.75% of rated output of previous level after step change in
load current between 50% and 100%.
Mode Time
Voltage Mode 3 ms stand alone unit
1. 96 ms typical in current sharing configuration
1
Mode Crossover
Maximum deviation as a percentage of rated output voltage.
CV – CC Overshoot 1%
Peak–Peak and RMS Noise Bandwidth Limits
The frequency range for Peak to Peak measurements is 10 Hz–20 MHz.
The frequency range for RMS measurements is 10 Hz–100 kHz.
Maximum Remote Sense Line Drop Compensation
Minimum 3.8 V for each line, 5 V typical
Isolation
AC Input to Output 1350 V
AC Input to Chassis 1350 V
Output to Chassis 600 V
ac
ac
ac
1. Time for the output voltage to recover within 0.75% of rated output of its previous level
after a step change in load current of up to 50% - 100% and 100% to 50% of rated
output
30 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 31 Tuesday, Novem ber 5, 2002 3:22 PM
Environmental Specification
Operating Altitude Up to 6,500 feet (2,000 m)
Storage Altitude Up to 50,000 feet (15,000 m)
Installation Category
Pollution Degree
Thermal
Specification
Operating Temperature Range 0°C–50°C
Storage Temperature Range –40°C–+85°C
1. Consult the factory for operation below 0°C and above
50°C.
Specifications and Characteristics
Environmental Specification
II (IEC 1010-1)
2 (IEC 1010-1)
1
Humidity
Specification
Operating Humidity Range < 95% RH, Non-condensing
Storage Humidity Range < 95% RH, Non-condensing
International Approvals
CE-marked units meet: EN61010-1, EN50081-2 and EN500082-2.
CSA C/US certified to C22.2 No 1010.1 and UL3111-1.
Meets USA EMC standard: FCC, part 15, class A.
Meets Canadian ECMC standard: ICES-001.
Release 1.0 31
TM-XDSL-01XN.book Page 32 Tuesday, Novem ber 5, 2002 3:22 PM
Specifications and Characteristics
Mechanical Specification
Mechanical Specification
Weight Approx. 75 lb. (34 kg) for 10 V-600 A unit, without packaging
Size
Figure A.1 Power Supply Dimensions
32 Operating Manual for XDC Series Slave Power Supply
TM-XDSL-01XN.book Page 33 Tuesday, Novem ber 5, 2002 3:22 PM
TM-XDSL-01XN.book Page 34 Tuesday, Novem ber 5, 2002 3:22 PM
Xantrex Technology Inc.
8999 Nelson Way
Burnaby, British Columbia
Canada V5A 4B5
604 422 2777 Tel
604 420 2145 Fax
800 670 0707 Toll Free North America
customerservice@xantrex.com
www.xantrex.com
TM-XDSL-01X N
PRINTED IN CANADA
Loading...
