Commercial Mower Owner’s Manual

For the Wright Z serial #31897 and higher until superseded

WARNING: READ THIS MANUAL BEFORE USING

For your safety and for proper operation and maintenance read carefully and keep readily available for future reference.

Revised 06/2007

Additional replacement owner’s manuals as well as illustrated parts lists are available from your authorized Wright Dealer for a nominal charge. Also check www.wrightmfg.com for the most up to date product literature. Please note the model number and serial number of your Wright product.

For reference please note the following information at the time of purchase:

SERIAL # _________________________

MODEL # _________________________

DATE OF PURCHASE ______________________

Wright Manufacturing Inc.

Foreword

Welcome to the progressive group of mowing professionals who use Wright mowers. We are focused on giving you advanced engineering and quality construction in each mower we build.

This manual explains the features and promotes safer use of the mower. Please read it in its entirety and follow the instructions carefully so that you can have many years of safe and productive operation with your Wright product.

For service, remember that your Wright dealer knows your mower best and is interested in your satisfaction. Your dealer can provide you with quality maintenance and other assistance that you may need.

Please provide this manual to anyone who may operate the mower for them to study before operation. Additionally, make the manual and service documents available to anyone to whom you may sell the mower in the future. It is important that the next owner receive this information also.

As Wright Manufacturing, Inc. is constantly seeking ways to improve its products, the mower you have may differ slightly from the information and specifications in this manual. Wright reserves the option to make changes at any time without notice, in the process of continually improving our products.

Wright Manufacturing, Inc.

SAFETY ALERT

This is the safety alert symbol. It is used throughout this manual and on the mower’s safety labels to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read these instructions carefully. It is essential that you read the instructions and safety precautions before you attempt to work on or use this unit.

WARNING

This symbol with the “WARNING” indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

This symbol with the word “CAUTION” indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

©1998-2005 Wright Manufacturing, Inc. All rights reserved. This material may not be reproduced or copied, in whole or part, without written permission from Wright Manufacturing, Inc. Grass Gobbler, Gobbler, Leaf Gobbler, Velke, Pro 1, X2, Stander, and Sentar are trademarks of Wright Manufacturing, Inc.

TABLE OF CONTENTS



PRE-DELIVERY SERVICE OF MOWER BY DEALER.............................................................

1

SAFETY INSTRUCTIONS.........................................................................................................

3

INTRODUCTION .........................................................................................................................

3

GENERAL SAFETY INSTRUCTIONS ..............................................................................................

3

OWNER/USER NOTICE ..............................................................................................................

3

USER QUALIFICATIONS..............................................................................................................

3

USER CLOTHING.......................................................................................................................

4

INSPECT MOWER BEFORE EACH USE.........................................................................................

4

REGULAR MOWER SAFETY MAINTENANCE ..................................................................................

4

WORK AREA CONDITIONS & INSPECTION ....................................................................................

4

INITIAL OPERATING SAFETY GUIDELINES ....................................................................................

5

OPERATION IN FORWARD DIRECTION .........................................................................................

5

OPERATION IN REVERSE ...........................................................................................................

6

ZERO-RADIUS TURN OPERATION ...............................................................................................

6

OPERATION ON SLOPES ............................................................................................................

6

FUEL SAFETY ...........................................................................................................................

7

HYDRAULIC SAFETY..................................................................................................................

7

REPLACEMENT PARTS ..............................................................................................................

7

OPERATING INSTRUCTIONS .................................................................................................

9

HOW TO START THE MOWER ......................................................................................................

9

Before starting the engine ..................................................................................................

9

Starting the engine .............................................................................................................

9

HOW TO DRIVE THE MOWER .......................................................................................................

9

HOW TO STOP AND PARK THE MOWER .....................................................................................

10

DRIVING THE MOWER OVER A CURB ........................................................................................

10

MOWING ON VARYING TERRAIN ...............................................................................................

10

HOW TO ADJUST NEUTRAL ......................................................................................................

11

HOW TO PERFORM THE TRACKING ADJUSTMENT.......................................................................

11

HOW TO TEST/USE THE BLADE CLUTCH/BRAKE SWITCH............................................................

11

HOW TO TEST THE OPERATOR PRESENCE CONTROL (OPC) SWITCH .........................................

11

SERVICE AND ADJUSTMENTS ...................................................................................................

12

Tire Maintenance and Pressure .......................................................................................

12

Height-of-Cut ....................................................................................................................

12

Belt Tension Adjustment...................................................................................................

12

How to Move the Mower if the Engine Won’t Start ...........................................................

12

Bleeding Air from the Hydraulic System ...........................................................................

12

Battery Service .................................................................................................................

12

Cleaning the Mower..........................................................................................................

13

MAINTENANCE INTERVAL CHART......................................................................................

15

MAINTENANCE RECORD......................................................................................................

16

* * This Page Intentionally Left Blank * *

Pre-Delivery Service of Mower by Dealer

If you are not completely familiar with the Safety Instruction Manual read it now before proceeding with the Pre-Delivery

WARNING Service of the mower. Only your authorized Wright dealer should perform the Pre-Delivery Service of the mower.

The Wright Z is shipped assembled and has been adjusted and tested at the factory. However, due to jostling during the shipping process and the delivery time lapse the following items need to be repeated again before starting the mower. After you have uncrated the mower, follow these procedures in the order indicated:

Remove spark plug wire from spark plug(s).

Inspect the mower for any damage, unusual conditions or missing parts. Seat may be detached for crating purposes. Make sure all hardware is present.

Inspect the mower for all of its decals, especially the warning decals. There should be one blade warning decal on each side of the deck, the “shield missing” under the blade belt covers, and the dash decal. The Park Brake and General Safety Decal should in place near the brake lever.

Check (and fill if necessary) engine oil level according to the engine manufacturer’s recommendation.

Check (and fill if necessary) hydraulic fluid level. The level should be about 1”-1.5” below the top of the oil fill. Use synthetic oil: Mobil1 15W-50.

Check rear tire pressure - 18 to 22 psi. is recommended. It should be even on both sides. Use the higher pressures for heavier operators. The front caster tires are a non-pneumatic style wheel, and do not require air pressure.

Check the battery to see that the cables are tight and connected properly. The battery is 12 volts and is a maintenance-free battery. Only charge the battery if it will not sufficiently start the mower.

Remove the blade belt covers and inspect the belt and idler arm for smooth operation.

Rotate the blade pulleys slightly to see if they rotate freely and all turn together. There will be resistance due to the clutch brake.

Replace the blade belt covers.

Check the Rapid-Hite deck height adjustment mechanism for proper operation. Pressing the lift pedal all the way down will engage the latch mechanism. Releasing pressure from the pedal should allow the latch to lock the deck in the transport position. Pressing on the pedal again should release the latch mechanism and allow the deck height to be set according to the location of the deck-height detent pin.

Lubricate all moving parts (see Maintenance Items section of this manual).

Fill fuel tank with regular unleaded gasoline. Turn fuel tank selector valve left or right, depending which tank is filled with gas. Note: the downward position is off. The fuel tank selector valve is located in the rear of the seat frame on the left side.

DO NOT START THE ENGINE AT THIS TIME. FOLLOW THE NEXT PROCEDURE BEFORE STARTING. The hydraulic system MUST be checked for proper operation before allowing wheels to operate on the ground.

Set the rear of the machine on jack stands or blocks to raise rear wheels off the ground two or three inches and check to be sure that the mower will not fall off the supports you devise. The stand(s) must be able to secure the mower from rolling off or away during the next procedures. Check under the mower deck for any debris or unusual conditions.

With hand controls in the neutral and outward position, apply the parking brake.

Open the manual bypass valves on front-side of each pump a half-a-turn counterclockwise. The pump bypass valves are accessible by lifting the seat tray.

Reattach spark plug wires to spark plugs.

1

Before starting the engine be ready to stop it if the wheels begin to turn with the brake on. (If this happens, check that the manual bypass valves on side of each pump are open at least a half-a-turn counterclockwise.)

Start the engine according to the engine manufacturer’s recommendation. Let the engine run at low RPM for several minutes to get the hydraulic fluid circulating through the pumps. It will be necessary to use a pair of locking pliers to activate the seat OPC plunger switch while standing beside the unit. Release the Parking Brake cautiously as the wheels may start to move. Now gradually tighten the manual bypass valves on the front of each pump one at a time and see if the wheels start to move. If the wheels move when the hand controls are in neutral position, adjust the pump neutral adjustment Allen screw. This procedure is described in the Operating instructions portion of this manual. The manual bypass valves on side of each pump should now be firmly closed. (Do not tighten these bypass valves with a wrench. Only hand tighten). Now try moving the hand control levers, one at a time, forward and backward. Check to see if the wheels move forward and backward according to position of the levers. If not, service the hand control system. If the wheels stop when the hand controls are in the neutral position, the parking brake should now be applied. Remove locking pliers from OPC, the blade testing will require that you are seated on the unit for your safety. Failure to comply could result in serious injury.

Before testing the blade clutch/brake operation, make sure the area is clear and there is nothing vulnerable to being thrown from under the mower. No one should be near the mower deck or in its line of discharge at this time or at any time. The discharge chute deflector should be in the down position. Move the engine throttle to ¾ speed setting. Note: the Blades will not operate in with the parking brake engaged.

Be sure that you are sitting on the operator seat and turn on the blade clutch switch. Run blades for a minute or so. Try engaging and disengaging the blades a few times about 10 seconds apart. If the blades do not start and stop in a short amount of time, service the blade brake system. With the blades on, now try lifting your weight off the operator seat to test the Operator Presence Control switch (OPC). The engine should die and the blades should begin to stop after a ½ second delay. The blades should come to a stop in several seconds. If not, service the OPC system. Try this a couple of times.

Disengage the blades, set the parking brake, shut off the engine and remove the mower from the stand(s).

Drive the mower around on a level parking lot. Be sure that the mower drives in a straight line when both hand controls are held to the full speed position. If not, see further in this manual for information on tracking adjustment.

As you drive the mower, listen for any unusual noises and test for irregular operation and adjust or service as necessary. Next, go over the safety information and operating procedures in this manual with the customer. Instruct the customer in proper operation and observe the customer during their initial operation on a level parking lot. Make sure the customer is familiar and comfortable with the basic operation and use of the mower.

Dealer: Please fill out and follow the instructions on the Product Registration Form and have the customer fill out their portion of the form. After the Product Registration Form is filled out and signed by the customer and a representative from your dealership, please send or fax it within 14 days to your Wright Manufacturing Distributor according to the directions on the Form. Give the customer their copy of the registration form and keep your copy for your records. The remaining copies of the forms should be mailed to your Wright Manufacturing Distributor. The limited warranty is not valid unless the mower is registered and all of the above steps are taken. Remember, the purchaser is both your and our customer and his satisfaction is very important. Thank you for supporting our products.

The mower is now ready for delivery to your customer

2

SAFETY INSTRUCTIONS

WRIGHT MOWER USERS & OWNERS: READ THIS MANUAL BEFORE USING

PLEASE BE CAREFUL!

WARNING

This symbol with the word “WARNING” indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

This symbol with the word “CAUTION” indicates a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.

Introduction

This mower is built to the highest standards in the industry. However, carelessness or operator error may result in serious bodily injury or death.

Accident and hazard prevention are dependent upon the awareness, concern, wisdom, and proper training of the personnel involved in the operation, transport, maintenance, and storage of the equipment. Make sure every operator is properly trained and thoroughly familiar with all of the information in this manual before operating the equipment.

General Safety Instructions

The Wright Z is designed with your safety in mind. It has the following safety systems with which you should become familiar:

The warning decals on the mower including the parking brake and general warning decal

The blade switch must be “off” before starting the engine

You must be seated with the Park brake on and control levers in neutral to start engine. Neutral refers to the outward lever position.

You must be seated to engage the blades

If you lift off the seat while the blades are running the engine will stop and the blades will brake in seconds

Spring loaded chute deflector helps reduce trajectory of thrown objects

Belt/pulley covers on cutter deck

Low center-of-gravity (CG) to improve stability on hills

WARNING

Owner/User Notice

The owner’s/user’s obligation is to instruct themselves and all potential users in the safe operation of this equipment and be sure they read and follow the instructions in this safety manual and other material provided by Wright Manufacturing, Inc. before using or allowing others to operate the equipment. Do not operate this unit unless you carefully read, understand and follow the operation and safety instructions contained in this manual and the warning decals provided on the unit. Do not allow other persons to use this unit unless you make sure they carefully read, understand and follow these instructions. Never allow children to operate or play on the unit.

WARNING

User Qualifications

This product is designed for use by physically fit, experienced, professional commercial mower operators who have a minimum of 160 hours of experience operating twelve horsepower and greater industrial mowers. Operators must be 18 years or older and weigh at least 120 pounds and no more than 300 pounds. They must have read and understood this manual. DO NOT allow children to operate the mower. Never allow passengers on the mower. DO NOT allow adults to operate the mower without proper instruction as mentioned above.

3
