Wolf PW483318O Quick Reference Guide

48" OUTDOOR PRO WALL HOOD

P W 4 8 3 3 1 8 O

FEATURES

Matches the same heavy-duty stainless-steel construction, handfinished hemmed edges, and welded seams of all Sub-Zero, Wolf, and Cove products

Select from internal, in-line, or remote blower options  (blower required)

Illuminates your cooking area with halogen lighting

Rely on a heat sentry that automatically turns on the blower or increases its speed when exhaust temperatures exceed

200 degrees Fahrenheit

ACCESSORIES

1100 CFM Inline Blower

1500 CFM Remote Blower

18" Duct Cover

30" Duct Cover

6" Duct Cover

801642-1200 CFM Remote Blower

814423-1200 CFM Internal Blower

Accessories available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

B L O W E R O P T I O N S

•1200 CFM Internal

•1100 CFM Inline

•1200 CFM Remote

•1500 CFM Remote

Specifications are subject to change without notice. This information was generated on June 1, 2020. Verify specifications prior to finalizing your cabinetry/enclosures.

48" OUTDOOR PRO WALL HOOD

PRODUCT SPECIFICATIONS		D I M E N S I O N S
Model	PW483318O
Dimensions	48"W x 18"H x 33"D
Electrical Supply	110/120 VAC, 60 Hz
Electrical Service	15 amp dedicated circuit
Discharge Location	Vertical
Discharge Dimensions	10" Round
Bottom of Hood to	36" to 42"
Countertop

ELECTRICAL

NOTE: Dimensions in parenthesis are in millimeters unless otherwise specified

Specifications are subject to change without notice. This information was generated on June 1, 2020. Verify specifications prior to finalizing your cabinetry/enclosures.
