Wolf PW363318O Use & Care Guide
OUTDOOR WALL HOOD
USE AND CARE GUIDE
CLEANING, MAINTENANCE, AND MORE
OUTDOOR WALL HOOD
Contents
4 Safety Precautions
6 Hood Features
7 Hood Operation
9 Care Recommendations
10 Troubleshooting
11 Wolf Warranty
2 | Wolf Customer Care 800.222.7820
OUTDOOR WALL HOOD
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 6 for rating plate
location. For warranty purposes, you will also need the date
of installation and name of your authorized Wolf dealer.
Record this information below for future reference.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certied Service Name
Certied Service Number
Authorized Dealer
Dealer Number
If your product ever needs attention, be sure to use a
Wolf Factory Certied Service provider recommended
by our Customer Care Center, or select one from our list
of providers available at wolfappliance.com/locator. All
Factory Certied Service providers are carefully selected
and thoroughly trained by us.
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specied.
wolfappliance.com | 3
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
• Read this use and care guide carefully before using
your new ventilation hood to reduce the risk of re,
electric shock, or injury to persons.
• Ensure proper installation and servicing. This
appliance must be properly installed and grounded
by a qualied technician.
• Warranty service must be performed by Wolf
Factory Certied Service.
• Installation work and electrical wiring must be done
by qualied person(s) in accordance with all applicable codes and standards, including re-rated
construction codes and standards.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS, OBSERVE
THE FOLLOWING:
Use this unit only in the manner intended by
a)
the manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, unplug the
appliance or switch power off at service panel
and lock the service disconnecting means
to prevent power from being switched on
accidentally. When the service disconnecting
means cannot be locked, securely fasten a
prominent warning device, such as a tag, to
the service panel.
GENERAL SAFETY PRECAUTIONS
• Sufcient air is needed for proper combustion and
exhausting of gases through the ue (chimney) of
fuel burning equipment to prevent back drafting.
• Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the National Fire Protection Association
(NFPA), the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE),
and the local code authorities.
CAUTION
For general ventilating use only. Do not use to
exhaust hazardous or explosive materials and
vapors.
• Ducted fans must always be vented to the
outdoors.
• To reduce the risk of re, use only steel ductwork.
CAUTION
To reduce the risk of re and properly exhaust air,
be certain to duct air outside. Do not vent exhaust
air into spaces within walls or ceilings or into
attics, crawl spaces, or garages.
4 | Wolf Customer Care 800.222.7820
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
• Do not repair or replace any part of this appliance
unless specically recommended in this guide. All
other service should be performed by a qualied
technician.
• To avoid motor bearing damage and noisy or
unbalanced impellers, keep drywall spray, construction dust, etc. off power unit.
• When cutting or drilling into wall or ceiling, do not
damage electrical wiring or other hidden utilities.
• Please read the specication label on the ventila-
tion hood for further information and requirements.
WARNING
TO REDUCE THE RISK OF A RANGE TOP
GREASE FIRE:
Never leave surface units unattended at high
a)
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on
low or medium settings.
b) Always turn hood ON when cooking at high
heat or when ambéing food (i.e. Crepes
Suzette, Cherries Jubilee, Peppercorn Beef
Flambé).
c) Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan or lter.
d) Use proper pan size. Always use cookware
appropriate for the size of the surface element.
WARNING
TO REDUCE THE RISK OF INJURY TO
PERSONS IN THE EVENT OF A RANGE TOP
GREASE FIRE, OBSERVE THE FOLLOWING*:
SMOTHER FLAMES with a close-tting lid,
a)
cookie sheet, or metal tray, then turn off the
burner. BE CAREFUL TO PREVENT BURNS.
If the ames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN—You may
be burned.
c) DO NOT USE WATER, including wet dishcloths
or towels—a violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class ABC extin-
guisher, and you already know how to
operate it.
2) The re is small and contained in the area
where it started.
3) The re department is being called.
4) You can ght the re with your back to an
exit.
*Based on “Kitchen Fire Safety Tips” published by NFPA.
WARNING
PROPOSITION 65 FOR CALIFORNIA RESIDENTS
Cancer and Reproductive Harm—
www.P65Warnings.ca.gov
wolfappliance.com | 5
HOOD FEATURES
Outdoor Wall Hood Features
FEATURES
1
Product Rating Plate (inside hood shell)
2
Controls
3
Filters
4
Halogen Lighting
3
1
Outdoor Wall Hood
2
4
6 | Wolf Customer Care 800.222.7820
HOOD OPERATION
Hood Controls
The controls for the Outdoor Wall Hood are located under
the front edge of the hood. Refer to the illustration below.
LIGHTS
Use the ON/OFF switch on the right to turn the halogen
lights on or off.
BLOWER
The blower is operated using two controls. Use the ON/
OFF switch on the left to turn the blower on or off. When
the blower is on, the switch turns red and the speed control
knob operates the blower with innite control of the blower
speed. Turn the control knob clockwise to increase the
blower speed and counterclockwise to decrease the blower
speed.
LIGHTING
ON/OFF
BLOWER
SPEED
BLOWER
ON/OFF
Heat Sentry
The heat sentry feature automatically turns the blower on or
increases the blower speed when the exhaust temperature
exceeds 200°F
speed to the previous setting once the temperature drops
below 186°F
(95°C). It automatically adjusts the blower
(85°C).
Hood controls
wolfappliance.com | 7
HOOD OPERATION
Lighting
LIGHT BULBS
The Outdoor Wall Hood requires 50W, 120V, GU10 halogen
light bulbs, available through an authorized Wolf dealer. For
local dealer information, visit the nd a showroom section of
our website, wolfappliance.com.
A suction-cup-style light bulb changer is provided with
the hood. To remove a bulb, use the changer to rotate the
bulb clockwise one-quarter turn. Refer to the illustration
below.
LIGHT BULB
CHANGER
Filter Removal
The grease lters are dishwasher safe. Refer to Care
Recommendations on the following page.
Remove the center lter rst. To remove, press the lter
upward then rotate the bottom downward. Refer to the
illustration below. Remove the grease cups from the bottom
edge of the hood. Gloves should be worn when handling
the lters.
Reinstall the lters using the reverse procedure. Slide the
outer lters over slightly to reinstall the center lter.
IMPORTANT NOTE: Do not operate the ventilation hood
without the lters. This may damage the blower or other
internal components of the hood.
GREASE
CUP
SPRING
FILTER
Light bulb replacement
SIDE VIEW
Filters
8 | Wolf Customer Care 800.222.7820
CARE RECOMMENDATIONS
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner and apply with a soft lint-free cloth. To bring out the natural
luster, lightly wipe the surface with a water-dampened microber cloth followed by a dry polishing chamois.
Always follow the grain of stainless steel.
Control knobs Using a damp cloth, wipe with mild detergent or spray degreaser. Rinse and dry.
IMPORTANT NOTE: Do not spray cleaners directly on the control knobs.
Filters
Grease cups
The lters are dishwasher safe and are designed to t most dishwashers. Wipe the lters and grease cups
to remove excess grease before placing in the dishwasher.
wolfappliance.com | 9
TROUBLESHOOTING
Troubleshooting
OPERATION
Ventilation hood does not operate.
• Verify power is on.
• Verify electrical power to the hood and home circuit
breaker is on.
SERVICE
• Maintain the quality built into your product by contacting
Wolf Factory Certied Service. For the name of the nearest Wolf Factory Certied Service, check the Support &
Service section of our website, wolfappliance.com, or
call Wolf Customer Care at 800-222-7820.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate, located inside the left wall of
the hood shell. Refer to page 6 for rating plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer. This
information should be recorded on page 3 of this guide.
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.
10 | Wolf Customer Care 800.222.7820
