WMF Bistro User Manual
www.bvdm-online.de
SIMPLY MORE
IF YOU WANT MORE
WMF bistro!
Rear view Side view
Perfectly matched accessories make your work easier and make
your WMF bistro! even more powerful. Here, for example, the WMF
bistro! was provided with a Cup & Cool, a WMF cafemat!, two card
readers and a cup rack.
WMF bistro! technical data
Recommended daily output up to 300 cups up to 300 cups
Power supply 3.3 kW / 220 – 230 V 6.3 kW / 380 – 400 V
Energy loss per day in accordance
with DIN 18873-2, Basic Milk / Active Milk
Hourly output*
Espresso
Cappuccino
Café Crème
Chocolate (optional)
Total hot water output per hour
1 or 2 coffee bean hoppers approx. 1000 g approx. 1000 g
Chocolate container (optional) 500 to 1000 g, depends on the chocolate powder 500 to 1000 g, depends on the chocolate powder
Dimensions (width / height / depth) 453 mm /745 mm (with bean hopper) /554 mm 453 mm /745 mm (with bean hopper) /554 mm
Empty weight approx. 80 kg approx. 80 kg
Continuous sound pressure level (Lpa)*** < 70 dB (A) < 70 dB (A)
* Performance is dependent on the cup size, quality settings, spout, equipment and nominal power rating. The maximum
recommended daily output is based on the respective service concept shown. These average values are for your information. –
Have your tailored coffee-machine solution assembled by one of our trained WMF employees.
** The A-rated sound pressure level Lpa (slow) and Lpa (impulse) at the workplace of the staff using the machine is less than
70 dB (A) in every mode.
From 5° dKH (carbonate hardness), a WMF water filter is recommended.
2.02 / 2.28 kWh 2.02 / 2.28 kWh
240
240
150
120
24 litres 48 litres
240
240
150
120
ENERGY EFFICIENT
CERTIFIED BY
As quality pays for itself
The WMF bistro! is designed to meet the tough
demands of the catering sector, down to the last
detail.
A high-quality stainless steel brewer and professional grinding disks made from especially hardened
steel are solid arguments for longer life, even in
heavy use. From the coffee bean hopper to the
boiler, everything is dimensioned to cope with
high-volume demand in the shortest possible
time.
More power, even for the toughest of demands
The WMF bistro! has plenty of reserves of power,
for your peace of mind even at peak times.
Perfect coffee specialities in a matter of seconds,
two-cup portioning even for Latte Macchiato or
optional jug filling are no problem.
You will be impressed by MORE power and reliability, and your customers by MORE coffee quality
and taste.
CERT
If you want more!
www.wmf-coffeemachines.com
If you want more!
Every aspect of the WMF bistro! has been designed with performance in mind. Whether a stainless-steel brewing system, bean
hopper or boiler, everything is generously designed and sized, so that even high-volume requirements can be handled without any
problems in the shortest time and with top-quality results. And when it comes to the range of drinks on offer, it goes without saying
that the WMF bistro! is among the best on the market. Foamed-milk drinks can be prepared using different methods.
The Basic Milk version using the integrated milk foamer. The Active Milk version, whereby the machine automatically prepares milk
drinks and frothy milk drinks, whether hot or cold. Moreover, both versions can be combined with different steam systems.
Our new complete catalogue contains lots of additional information on the following topics:
- A performance overview showing all coffee machines
- Made-in-Germany production
- Milk and steam systems (Basic Milk, Easy Milk, Active Milk, Basic Steam, Easy Steam and Auto Steam)
- Additional equipment (such as cup racks, coolers, Cup&Cool, vending devices, etc.)
- Customer service (maintenance contracts, cleaning supplies, descaler, etc.)
- Speciality coffees (which specialities can be prepared with which coffee machines)
You can request the complete catalogue from our customer service centre using the
order number 63.8042.0391.
WMF AG Coffee Machines International
Eberhardstraße · D-73312 Geislingen/Steige, Germany
Phone: +49 73 31 - 257 257 · Telefax: +49 73 31 - 257 297
gastro-export@wmf.de · http://www.wmf-coffeemachines.com
3148 # 63 8049 0391 Printed in Germany 03.13
Technical data subject to change.
Errors an omissions anywhere in this leaflet reserved.
Print compensated
Id-No. 1326345
03.8400.XXXX
1 grinder, Chocolate container,
milk foamer, Plug+Clean
– 3,3 kW, Basic Milk
Examples of use
Fixmodell mit
Preisvorteil
03.8400.XXXX
2 grinders, Chocolate container,
milk foamer, illumination, steam output,
Plug+Clean – 6,3 kW, Basic Milk
03.8400.XXXX
2 grinders, Chocolate container,
milk foamer, illumination – 6,3 kW,
Basic Milk + Auto Steam
03.8400.XXXX
2 grinders, Chocolate container, milk
foamer for hot and cold milk and milk foam,
illumination – 6,3 kW, Active Milk
Ulm University Student Union Cafeteria
O.T. Bar, Stuttgart
Bakery Bayer, Neu-Ulm
WMF Communication Centre, Geislingen Alte Kanzlei, Stuttgart
ZERTIFIKAT
Die Zertifizierungsstelle
der TÜV SÜD Management Service GmbH
bescheinigt, dass das Unternehmen
WMF Württembergische Metallwarenfabrik AG
Eberhardstraße, D-73312 Geislingen
für den Geltungsbereich
Vertrieb und Marketing, Entwicklung,
Produktion und Kundendienst von
Kaffeemaschinen
ein Qualitätsmanagementsystem
eingeführt hat und anwendet.
Durch ein Audit, Bericht-Nr. 70015333
wurde der Nachweis erbracht, dass die Forderungen der
ISO 9001:2008
erfüllt sind. Dieses Zertifikat ist gültig bis 2015-07-24
Zertifikat-Registrier-Nr. 12 100 20187 TMS
München, 2012-07-25
QMS-TGA-ZM-07-92
ZERTIFIKAT
Die Zertifizierungsstelle
der TÜV SÜD Management Service GmbH
bescheinigt, dass das Unternehmen
WMF Württembergische Metallwarenfabrik AG
Eberhardstraße, D-73312 Geislingen
für den Geltungsbereich
Vertrieb und Marketing, Entwicklung,
Produktion und Kundendienst
von Kaffeemaschinen
ein Umweltmanagementsystem
eingeführt hat und anwendet.
Durch ein Audit, Bericht-Nr. 70015333
wurde der Nachweis erbracht, dass die Forderungen der
ISO 14001:2004
erfüllt sind. Dieses Zertifikat ist gültig bis 2015-07-22
Zertifikat-Registrier-Nr. 12 104 20187 TMS
München, 2012-07-23
EMS-TGA-ZM-07-92
FEATURES
IF YOU WANT MORE
We also value what‘s on the
inside
Solid components, such as the
stainless-steel brewing system
and the professional grinding
plates, are made from specially
hardened steel.
Hot chocolate and chociatto
Almost any creation involving
chocolate and coffee can be
produced with lots of fresh
milk.
Plug+Clean
The patented, optionally available plug+clean milk cleaning
system effortlessly cleans all
parts in contact with milk.
Hot water
is produced by the WMF bistro!
at the touch of a button for tea,
for example or even, at the same
time, speciality coffees.
Mixing the perfect milk
drink
In the Active Milk version, the
machine automatically prepares milk drinks and frothy milk
drinks, whether hot or cold.
Shown in full size
Height-adjustable spout
Fills containers ranging from
70 to 180 mm in height. For
breakfast service or office use,
it is also possible to dispense a
jug of coffee.
Automatic cleaning
at the touch of a button.
That saves time and cuts
operating costs.
No limits on the disposal of
coffee grounds - This is why
we have given the grounds
hopper on the WMF bistro!
truly generous dimensions. But
for anybody who feels that this
spacious hopper is still not big
enough, they can also choose
the optional grounds disposal
through the counter top.
Manual insert
On machines with 2 product
hoppers, it is possible to use a
third type of coffee (e.g., decaffeinated) via manual insert.
Clever key allocation
Key labelling is as simple as
product allocation. Just print
out and press on a new label.
Small, Medium, Large
Do you use different sized coffee
mugs? The practical SML function will help you to easily assign
predefined mug or cup sizes to
each required drink.
Reaching new heights
If you want to have even more
space under the WMF bistro!, the
10 cm high „feet“ – which are
sold separately – easily provide
even more „leg room“. And this
also means that the area below
the machine can be cleaned
effortlessly.
Mobile coffee enjoyment
A mobile station makes the
WMF bistro! even more flexible.
You can take your machine
almost anywhere with you.
All you need is a socket.
Filtered coffee
As an option, the WMF bistro!
can also use a special brewing
process to prepare filtered
coffee.
Great design
Subtle elegance by day and
dramatic effect by night. Any
RGB colour can be set and is
adjustable at any time. This
means that you can always use
the right colour to set the right
mood.
Quality management
For espresso, after the initial
extraction there is a preinfusion
and postextraction; café crème,
on the other hand, is brewed
directly. Factors like these are
stored in 5 quality levels, freely
selectable for each coffee.
Auxiliary Units
The cup rack, the Cup & Cool
or the vending units turn the
WMF bistro! into a team player,
even in self-service mode.
The intelligent WMF bistro!
Alter the cup volume of ground
coffee and all the other settings will be adjusted automatically. For consistently good
coffee.
The “Barista symbol“
The next brew can be made
stronger or weaker as the client
desires by means of this symbol
on the touch screen display.
Environmentally friendly
thanks to »Green WMF«
Reduced energy consumption,
fewer chemicals and nearly
complete recycling are just a
few points of the sustainable
WMF concept.
The “hot rinse option”
Press this symbol to preheat all
the parts in contact with the
coffee. Hot espresso right from
the very first cup and after
extended waiting periods.
Service
A worldwide service network
unique in the industry covering
more than 70 countries ensures
that you can always rely on your
WMF coffee machine.
Self-explanatory display
The display guides you through
the machine, step by step. It also
shows all the operating sequences as well as useful information.
ISO certifications
The WMF business division for
coffee machines is certified
in accordance with DIN 9001/
quality management and
DIN 14001 / environmental
management.
Permanent descaling
A WMF water filter extends
maintenance intervals, enhances
taste and prolongs the service life
of the machine.
