WMF 5000 S Brochure

The new WMF 5000 S

More indulgence per hour.

Coffee to

go, go, go

Because indulgence now has pace. The new WMF 5000 S.

Florian Lehmann, President Global Coffee Machine Business

Speeding up quality

What inspired WMF to develop the fully­automated WMF 5000 S?

New technology makes us feel we can live life faster. We’re
no longer prepared to wait. We expect instant gratification –
the products we order, instantly delivered.

With the WMF 5000 S, it is precisely this need we are
addressing: we’ve developed a machine that packs the
performance capacity of a large, fully-automated coffee
machine into a slim, sleek appliance. With the WMF 5000 S,
we are offering a machine that not only makes fantastic
coffee, but produces consistently high quality faster – and
is easy to use, to boot.

Which particular features make the WMF 5000 S
so unique?

Our technical innovations play a key role here. The machine
benefits, for example, from a high-performance brewer that
is generally only used in large coffee machines. This reliably
ensures high-speed, top quality coffee over the long haul.
Equally, the Dynamic Milk system, which prepares hot and
cold milk, as well as a full range of hot and cold milk foam
consistencies, guarantees a completely natural milk flavour.
That’s how we satisfy every individual customer taste and
requirement.

Florian Lehmann,

President Global Coffee
Machine Business

“People today expect
their every desire to be
instantly fulfilled.”

Why should no business be without a
WMF 5000 S?

Quite simple. The WMF 5000 S has an inbuilt recipe for
success: The more indulgence created per hour, the greater
your daily turnover. And that should appeal to anyone
wanting to achieve business success through sheer love of
coffee.

Endless specialities.
In a flash.

Prepare top quality. More quickly.

Sheer indulgence –

It’s all about
speed and consistently

express delivery

Because today – every second counts

One of the biggest challenges is being able to respond
flexibly to peak service times. It’s not only a matter of staff
organisation but also machine capacity. The WMF 5000 S
ensures, for example, that during the morning rush hour on
the streets, customers are all quickly served and satisfied.
And that’s no longer down to staff, but a consistently top
quality, high-speed preparation process. These are of course
major success factors which facilitate higher turnover on
a daily basis.

Pace you can depend on

The WMF 5000 S is like a loyal team member you can always
depend on: pulling its weight and always fast enough when it
counts. At the same time, it’s intuitive and easy to use. Just as
staff aim to please customers with a friendly smile, this fully­automated team member gives you a perfectly tailored drink at
the touch of a button – for each and every customer.
The WMF 5000 S not only offers high performance, but can
be cleaned efficiently and thoroughly. Because, as we know,
nobody can afford to wait.

high quality.

Many people drink
their coffee on the
way to work – Where
every second counts!

Discover the new

Dynamic Milk provides hot and cold milk, hot and cold milk
foam – fully automated through the beverage spout. The
new cleaning process “Clean in Place” ensures time-saving
HACCP-compliant cleaning without having to remove the
milk foamer from the appliance and dismantle it.

Thanks to telemetry
capacity via the Remote
Data Access option, you
are able to access important
data virtually wherever and
whenever you want.

You can use the customer’s
time and attention whilst
their beverage is prepared
for on-screen advertising
in the self-service area.

In the self-service mode, the guest can request
a tour of beverage options via “Post Selection”.
The guest is then guided step-by-step through
the individual beverage options (cup size,
with or without caffeine…) until their desired
beverage is fully automatically prepared.
All beverage options can of course be
tailored to the individual customer.

Large, removable, lockable product
hoppers. The coffee bean hoppers are
dishwasher-proof. Ideal for easy cleaning.

Large touch display with clear menu
structure. The “digital operating manual”
is self-explanatory and provides information
about current operation status via the
automatic messages on the display.

Robust components, such as the heavy­duty brewer with its large holding capacity
of up to 19g of ground coffee and a high­performance pump, ensure a long service
life and peak performance.

WMF 5000 S

The Steam Jet brings every cup to the
correct temperature in a matter of seconds.

With its impressively sleek dimensions, this
head-turner makes room for additional
coffee machines or add-on-devices.

No more noisy coffee machines disrupting
conversations - noise emission has been
significantly reduced.

Automatic cleaning is activated via the
touch display. Inserting a cleaning tablet
is the only action required.

Premium materials such as stainless steel
side panels or lids emphasize the machine’s
professional appearance.

The illuminated side panels flash when action
is required (e.g. when the coffee beans need
refilling).

Data backup, software updates and cleaning
protocol downloads – download and set with
a USB stick, in line with HACCP-compliant
operation.

Thanks to the timer function, the coffee
machine can turn itself on and off at
times that suit you. Certain functions and
beverages can be activated/deactivated.
So, it’s easy to switch from served to self­service, from beverages with fresh milk to
topping powder etc.

Perfectly coordinated add-on and vending
devices alleviate labor and boost performance.

Milk can flexibly be supplied from either
left or right side, or underneath.

Rapid hot milk and foam at the push of a
button – or the classic way with Auto Steam
or Easy Steam.

Practical Small-Medium-Large functions
(SML) simply match each desired beverage
to the various predefined filling volumes.

You have the option of using keyboard layouts
with both a different button arrangement and
number of buttons, as well as various colours,
backgrounds and transparencies. This enables
users to select a single tier self-service layout
in the self-service area. You can also upload
and insert your own beverage images.

Technical specifications

706 mm

WMF 5000 S Easy Milk Dynamic Milk

Recommended daily /
max. hourly output

Nominal output /
Power supply

Hourly output according to
DIN 18873-2*
Espresso / 2 Espressi
Café Crème / 2 Café Crème
Cappuccino / 2 Cappuccini

Total hot water output / hour

Energy loss per day
according to DIN 18873-2

Hot milk beverages

Hot milk foam beverages

Cold milk beverages

Cold milk foam beverages

Cleaning system Easy Clean2 Clean in Place

Coffee bean hopper

Chocolate or topping hopper

Outer dimensions
(width / height / depth)

Water supply

Flow pressure for fixed water supply, min. 0.2 MPa (2.0 bar) at 2 Liters min.

Empty weight

Continuous sound pressure level

5

(LpA)

1

Performance has been determined by a machine with a fixe d water supply and is dependent on cup-size, quality set tings, discharge,

configuration and nominal output. The recommended maximum daily output is based on our cat alogued service concept. However,
these average value s serve merely as a guideline. Let our trained WMF team match the ideal cof fee machine design to your specific
needs.

2

Fully automated cleaning system using cleaning tablets and cleaning container. A blue cleaning container equipped with cleaning

tablet is connecte d up to the coffee machine in place of the milk container. The machine automatic ally dispenses water into the
cleaning c ontainer to dissolve the tablet, cleaning the milk system fully automatically and providing a thorough final rinse with both
water and steam. The foamer head need s to be manually cleaned once a week and submerged in cleaning fluid.

3

In principle, the cleaning sys tem Clean in Place functions just like Easy Clean. Although it also offers the advantage of no longer

having to additionally remove and manually clean the foamer head.

4

Height including bean hopper and with lock (without ke y).

5

The A-rated sound pressure level LpA (slow) and LpA (impulse) at service staff work stations is under 70 dB (A) in any operating mode.

Above 5° dKH (water hardnes s) a WMF water filter must be fitted.

1

up to 250 cups

2.75–3.25 kW /
220–240 V

144 / 220 cups
112 / 136 cups
144 / 220 cups

160 cups 180 cups 160 cups 180 cups

1.55 kWh 1.65 kWh

no

on the left or right 1100 g, centered 550g

120 0 g

325 mm / 7064 mm / 590 mm

Fixed water supply 3/8“, TW10 (e.g. angle valve)

ca. 37 kg

< 70 dB (A)

5.9–7.1 kW/
38 0– 415 V

2.75–3.25 kW /
220 –240 V

5.9–7.1 kW/
38 0– 415 V

3

The WMF 5000 S is now available
with the following milk and
steam systems:

325 mm 590 mm

WMF Photo

Accessories

530 mm

Cup&Cool Cup

Technical data

Nominal output /
Power supply

Outer dimensions
(width / height / depth)

Empty weight approx. approx. 31 kg approx. 27 kg

Removable milk container
capacity

Maximum inventory 45 to 186 cups 60 to 260 cups

Heatable shelf floors 3, Stainless steel 4, Stainless steel

530 mm

With thermostat

Suitable for self-service

Seperate on / off button

Illumination (can be set to
different colours)

Empty milk signal optional

Lockable

Removable seal

Sensor for milk temperature optional

Cup&Cool Cup

0.11 – 0.155 kW /
220 – 240 V

286 / 530 / 566 mm 286 / 530 / 539 mm

4.5 litres

0.13 – 0.155 kW /
220 – 240 V

Simu App 2.0

For Apple

New version available. Update NOW!
How do our WMF Coffee Machines look operated
at your premises? Simply take a look for yourself!

For Android

Further details available in our main WMF catalog 2015/16.

WMF Group GmbH Coffee Machines International
Eberhardstrasse 35 · D-73312 Geislingen/Steige, Germany
Phone: + 49 73 31 258 482 · Fax: [phone]
[e-mail] · www.wmf-coffeemachines.com

3280 # 63.8368.0391 Printed in Germany 07.15

All technical changes , typographical mistakes and error s reserved for the entire contents.
