White Rodgers BNP125, BNP150C, BNP125C, 1E65-140 Installation Instructions & User Manual

Line Voltage Non- Programmable Thermostat
Installation Instructions & User Guide
Congratulations on the purchase of your
White-Rodgers™ thermostat!
Save these instructions for future use!
Questions? Contact White-RodgersTM Customer Service at 1-877-654-9394
For BNP125, BNP150C, BNP125C, 1E65-140
37-7460A
WARNING WARNING
Before installing and operating this product, the owner and/or installer must read, understand and follow these instructions and keep them handy for future reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this product. Moreover, the following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially fatal electric shocks. All electric
connections must be made by a qualied electrician, according to the electric and
building codes effective in your region. Do NOT connect this product to a supply
source other than 120 VAC or 240 VAC, and do not exceed the load limits specied.
Protect the heating system with the appropriate circuit breaker or fuse. You must
regularly clean dirt accumulations on the thermostat. Do NOT use uid to clean
thermostat air vent. Do not install thermostat in a wet place. However, installing it in isolated walls is allowed.
Note:
When a part of the product specication must be changed to improve operability or other functions, priority is given to the product specication itself. In such instances,
the instruction manual may not entirely match all the functions of the actual product.
Therefore, the actual product and packaging, as well as the name and illustration, may differ from the manual.
The screen/LCD display shown as an example in this manual may be different from the actual screen/LCD display.
1
1. Description
This thermostat can be used to control electric heating units such as electric baseboards, convectors, or aeroconvectors. It keeps the temperature of a room at the requested set point with a high degree of accuracy. This product is designed for installations with electrical current - with a resistive load - ranging from 1.25 A to 12.5 A (120/240 VAC). It possesses a user-friendly interface. Furthermore, it gives you the possibility to control the temperature of a room with great precision.
This thermostat is not compatible with the following installations:
• electrical current higher than 12.5 A with a resistive load (3000 W @ 240 VAC and 1500 W @ 120 VAC);
• electrical current lower than 1.25 A with a resistive load (300 W @ 240 VAC and 150 W @ 120 VAC); and
• central heating system.
Parts supplied:
• one (1) thermostat;
• wall mounting plate located at the back of the thermostat;
• two (2) mounting screws;
• two (2) solderless connectors suitable for copper wires.
2
2. Installation
Selection of the thermostat location The thermostat must be mounted on a connection box on a wall facing the heating unit, at around 1.5 m (5 feet) above the
oor level, on a section of the wall exempt from pipes or air ducts.
Do not install the thermostat in a location where temperature measurements could be altered. For example:
• close to a window, on an external wall, or close to a doorleading outside;
• exposed directly to the light or heat of the Sun, a lamp, a replace or any other heat source;
• close or in front of an air outlet;
• close to concealed ducts or a chimney; and
• in a location with poor air ow (e.g. behind a door), or with frequent air drafts
conditions (e.g. head of stairs).
Thermostat mounting and connection
1. Cut off power supply on lead wires at the electrical
panel in order to avoid any risk of electric shock.
2. Ensure that the air vents of the thermostat are clean and clear of any obstruction.
3
3. Using a screwdriver, loosen the screw retaining the mounting base of the thermostat until you feel a loose (do not completely remove the screw).
Then, remove the mounting base at the back of the thermostat by tilting it
downward, then towards you.
4. Align and secure the mounting base to the connection box using the two screws supplied.
4
5. Take the wires from the wall through the hole at the base of the mounting base and connect them using the supplied solderless connectors. When making the connection with aluminum wire, make sure that you are using connectors
identied CO/ALR. Please note that the thermostat wires do not have polarity.
Therefore, the way they are connected is not important.
2-wire installation
4-wire installation
5
6. Place all the wires into the connection box.
7. Align the little slots located on the top of the thermostat with those on the the mounting base and secure the thermostat to the mounting base. Note that you can also position the thermostat on the left or the right side of the junction box (see the illustrations below). Then, tighten the screw at the bottom of the unit.
8. Turn on the power.
9. Set the thermostat to the desired setting (see the following section).
6
3. Operation
Powering on for the first time
When powering on for the rst time, the thermostat is initially set to Day mode . The temperature is displayed in Celsius and is set at 21 degrees by default.
Temperature set points
The gures displayed above the pictogram indicate the temperature set point. It
can be displayed in degrees Celsius or Fahrenheit (see “Display in degrees Celsius/ Fahrenheit”).
ambient temperature/ timer
heating power used indicator
automatic mode
lock mode
fan mode
top button
pictograms
frost-free warning
day mode
night mode
bottom button
7
To adjust the set point, just press down the top button to increase the value, or the bottom button to decrease it. Set points can be adjusted by increments of 0.5°C (1°F). To quickly scroll through the set point values, press and hold down the button. The minimum set point is 3°C (37°F), and the maximum set point is 30°C (86°F). In Day mode, you can turn off the thermostat by lowering the set point below 3°C. The set point value displayed will be OFF, and heating system start up will be impossible.
Day mode and Night mode
The thermostat includes a Day mode and a Night mode , both of them having their own independently adjustable and recorded set point. When switching from one mode to the other, the system will automatically use the temperature set point corresponding to the Day/Night mode selected. The standard factory set point adjustment is 21°C (70°F) for the Day mode, and 18°C (64°F) for the Night mode.
The current Day/Night mode selection is indicated on the display by the Sun or Moon icon. In order to manually switch from one mode to the other, simultaneously press down the two buttons and release them immediately.
8
Night mode timer
The Night mode features a timer that automatically returns to the Day mode after a selectable time period. This timer allows the temporary use of a temperature set point. The standard factory adjustment of the timer is 8 hours. With this adjustment, the thermostat automatically returns to Day mode 8 hours after being switched to the Night mode. For example, if you want a night temperature lower than the day
temperature, both Day/Night mode set points will rst have to be set at the desired
temperatures. Before bedtime, the Night mode temperature set point will be activated by switching manually to the Night mode. The timer is set for the duration of the night. The thermostat will automatically return to the Day mode at the end of the night, and the Day mode temperature set point, which is higher, will become effective at this time.
Night mode timer adjustment procedure
1. If necessary, adjust the Day/Night mode set points at the desired temperatures. If needed, switch from one mode to the other by simultaneously pressing down the two buttons and releasing them immediately.
2. From the Night mode, simultaneously press down the two buttons for more than 3 seconds until the moon icon blinks.
3. If needed, adjust the timer by pressing down the top button to increase the value, or the bottom button to decrease it. The adjustment range is from 1 hour to 999 hours. To quickly scroll through timer values, press and hold down the button.
4. When the adjustment is completed, release the buttons and wait for 5 seconds to exit the adjustment function.
9
NOTE:
The Night mode timer will be automatically reinitialized to the latest recorded
value when switching from the Day mode to the Night mode. It is not necessary to readjust the timer every time you switch to the Night mode. The timer is also reinitialized when this value is adjusted. Once the timer has completed its cycle and when the thermostat is in the Day mode, you must manually return to the Night mode. If you want to automatically return to the Night mode, the Automatic mode must be selected.
Automatic mode
The Automatic mode, which is associated to the Night mode timer, allows alternating between the Day/Night modes and the two corresponding set points over a 24-hour period. Once activated, this mode allows an automatic return to the Night mode after
24 hours. The Automatic mode allows you to dene two periods in a single day with
different set points.
For example, if the Automatic mode is activated and the Night mode timer is set at 8 hours, the thermostat will be operating in the Night mode for 8 hours at the night temperature set point. Then, it will return to the Day mode for 16 hours operating at the day temperature set point. At the end of the 24-hour cycle, the thermostat will return to the Night mode, and the cycle will start over. The 24-hour cycle starts with the Night mode as soon as the Automatic mode is activated. The Automatic mode activation should be made when you want to return to the Night mode. The normal course of a cycle in the Automatic mode is as follows:
1- Night mode: activated for the duration of the Night mode timer cycle. It returns to
the Day mode when the timer cycle is completed.
2- Day mode: activated for the remaining time of the 24-hour cycle. It returns to the
Night mode at the end of the 24- hour cycle.
10
Adjustment procedure of the Automatic mode
1. If necessary, adjust the Day/Night set point at the desired temperatures. If needed, switch from one mode to the other by simultaneously pressing down the two buttons and releasing them immediately.
2. From the Night mode, simultaneously press down the two buttons for more than 3 seconds. If needed, adjust the timer by pressing down the top button to increase the value, or the bottom button to decrease it. The Night mode timer adjustment range is from 1 hour to 23 hours in the Automatic mode. To quickly scroll through the timer values, press and hold the bottom button.
NOTE:
If you set the timer to any value exceeding 23 hours, it will be impossible to
activate the Automatic mode and if it was activated, the Automatic mode will be deactivated.
3. Activate the Automatic mode by simultaneously pressing down the two buttons for at least 3 seconds. The Automatic mode icon will appear. If the Automatic mode was already activated, the same procedure should be used to deactivate it.
4. When the adjustment is completed, release the buttons and wait for 5 seconds to exit the adjustment function.
11
NOTE: It is always possible to manually change the Day/ Night mode during a 24-hour
cycle. However, any manual return to the Night mode will re-initialize the Night
mode timer to the latest value recorded, which modies the cycle in progress. In
all cases, at the end of the 24-hour cycle, the thermostat will return to the Night mode and start a new cycle. It is thus not necessary to readjust the Automatic mode when a manual change is made to the Day/Night mode.
When turning back on after being powered off (because of a power failure, for
example), the automatization of the Day/Night modes is deactivated, and, if previously activated, the pictogram that corresponds to this mode will blink. The blinking will stop as soon as you press down a button.
12
Display in degrees Celsius/Fahrenheit
The thermostat can display the ambient temperature and the set point in degrees Celsius (standard factory setting) or Fahrenheit.
Selection procedure for degree Celsius/Fahrenheit display (for model with backlight)
1. From the Day mode, simultaneously press down the two buttons for 8 seconds (note that the backlight will blink after 3 seconds, but you must hold down the buttons). The Celcius/Fahrenheit symbol will blink after 8 seconds. Release the buttons.
2. Press down the top button to switch from the degrees Celsius to the degrees Fahrenheit, and conversely. The degree Celsius or Fahrenheit symbol will be displayed.
3. When the adjustment is completed, release the buttons and wait for 5 seconds to exit the adjustment function.
Selection procedure for degree Celsius/Fahrenheit display (for model without backlight)
1. From the Day mode, simultaneously press down the two buttons for 3 seconds. The Celsius/Fahrenheit symbol will blink after 3 seconds. Release the buttons.
2. Press down the top button to switch from the degrees Celsius to the degrees Fahrenheit, and conversely. The degree Celsius or Fahrenheit symbol will be displayed.
3. When the adjustment is completed, release the buttons and wait for 5 seconds to exit the adjustment function.
Heating Power Indicator
