Whistler SWRA-3300 Installation Instructions

INSTALLATION INSTRUCTIONS
SWRA-3300
REAR ANTENNA FOR MODEL 3300 REMOTE RADAR DETECTOR
THE WHISTLER GROUP CORPORATE HEADQUARTERS
PRODUCT DEVELOPMENT CENTER
25 Industrial Ave. Chelmsford, MA 01824 TEL (978) 244-1400 FX (978) 244-1492
CUSTOMER RETURN CENTER
1201 N. Dixieland Rd. Rogers, AR 72756 Consumer Relations Tel (800) 531-0004 Email: info@whistlergroup.com
P/N 3300SWRA, © WHISTLER 2000
3300 Superwideband remote 10/4/00 9:38 AM Page 1
Dear Whistler Owner,
Congratulations on your purchase of the SWRA­3300 (Superwideband Remote Antenna), a new and innovative Whistler accessory for use with the Whistler 3300 remote radar laser detector.
Reflecting our continued commitment of providing leading edge products, the SWRA-3300 is designed for drivers interested in gaining increased rear detection range.
The SWRA-3300 delivers long range warning of all radar guns operating on X, K, and superwideband Ka frequencies when transmitted from behind.
To fully acquaint yourself with the operation of the SWRA-3300 and how it interacts with the front radar receiver, we recommend reading this entire manual.
Enjoy your Whistler SWRA-3300 and please drive safely. Sincerely,
THE WHISTLER GROUP
Topic Page
SWRA-3300 Receiver and Mounting Brackets 2
Mounting Fasteners 3-4
Tools Required 5
Installation Of Radar Antenna 6-10
Making The Connections 11
Control Panel Memory 12
Troubleshooting Guide 13
Warranty 14-16
Specifications 17
TABLE OF CONTENTS
3300 Superwideband remote 10/4/00 9:38 AM Page 3
2
WHISTLER SWRA-3300 COMPONENTS MOUNTING FASTENERS
3
Large L Bracket (1)
Small L Brackets (2)
45º Reflector (For use when mounting antenna
in vertical position.
)
Antenna Mounting Brackets And 45º Reflector
Bolt #10-32 x 1-1/4"
Bolt #10-32 x 1/2"
Nut #10-32
Lock Washer
Flat Washer
A
B
Sheet metal Screw #6 x 3/4"
C
D
E
F
G
4" Cable Tie
3300 Superwideband remote 10/4/00 9:38 AM Page 5
Reference Description/Use Qty.
A Bolt #10-32 x 1-1/4" 2
• Fastens Large L or Small L Bracket to vehicle support.
B Bolt #10-32 x 1/2" 2
• Fastens Small L to Large L Bracket (optional approach).
C Nut #10-32 4
• Use with #10-32 bolts.
D Lock Washer 4
• Use with #10-32 bolts.
E Flat Washer 2
• Use with #10-32 bolts.
F Sheetmetal Screw #6 x 3/4" 6
• Fastens Large L/Small L Bracket or 45º Reflector to radar antenna.
G 4" Cable Tie 4
• Secures cable from radar antenna at various locations in or under the vehicle.
Note: If mounting fasteners are missing from your package, please call 1-800-531-0004 for replacements.
5
MOUNTING FASTENERS
TOOLS REQUIRED
4
Tools Required For Installation
• Phillips or Blade Screwdriver
• 3/8" Open End Wrench
• Electric Drill
• Drill Bit: 13/64"
• Pencil
• Other Tools May Be Required Based On Your Vehicle Type Or Requirements For Customized Installation
3300 Superwideband remote 10/4/00 9:38 AM Page 7
7
6
INSTALLATION OF RADAR ANTENNA INSTALLATION OF RADAR ANTENNA
General Information
The radar antenna is waterproof and designed to be mounted at the front of your vehicle. In most vehicles the best mounting location is directly below or behind the bumper. Other locations which provide concealment and/or protection of the antenna such as on the rear deck (next to the third brake light) may be acceptable. Radar signals will pass through non-metallic materials such as fiberglass and plastic, however, be sure to mount the receiver away from any metal, as it will block the receiver’s antenna. Because the optimal location for mounting the antenna varies by vehicle type, the hardware supplied is designed to offer a wide variety of mounting options. We suggest choosing the option that enables the antenna to be securely fastened and provides the ANTENNA window adequate rearward visibility.
NOTE: Use of hardware that is not supplied or DRILLING into the case will cause damage to the receiver and void the warranty.
Antenna Mounting Brackets
There are two types of mounting brackets for the antenna: Large L (1) and Small L (2). The Large L bracket fastens to the antenna using two or more screws (#6 x 3/4"). Slide the screw through the hole on the flange of the antenna and then tighten into the metal bracket (do not over tighten). The Large L Bracket may be fastened to the antenna in a variety of positions as shown on page 7.
The layout of holes on the large L Bracket accommodates multiple antenna mounting positions.
This arrangement provides flexibility for fastening the antenna /bracket assembly to your vehicle in a manner that allows the antenna window (ANTENNA) to have a rearward looking view of the road behind.
The Small L Brackets (2) may also be fastened to the antenna in different positions as shown below:
The Small L Brackets may be fastened to any of the six holes on the antenna.
Use one #6 x 3/4" screw to fasten each Small L Bracket to the antenna. Again, do not over tighten the screws.
In some situations it may be advantageous to use both the Large L and Small L Brackets to install the antenna in a vehicle.
3300 Superwideband remote 10/4/00 9:38 AM Page 9
8
INSTALLATION OF RADAR ANTENNA INSTALLATION OF RADAR ANTENNA
9
Horizontal Mounting
When mounting the antenna in a horizontal position (or on an angle between), remember to keep the ANTENNA window as close to perpendicular as possible to the road surface (ANTENNA window should not be angled up toward the sky or down toward the road surface).
Mounting Vertical (with 45º Reflector)
For vehicles that do not have sufficient clearance behind the bumper (about 5") to mount the antenna in a horizontal position, the 45º Reflector should be used.
The 45º Reflector is attached to the antenna with two screws (#6 x 3/4") on the side of the antenna housing marked ANTENNA. Slide the screws through the corner holes on the flange of the antenna housing and then tighten into the metal reflector (do not over tighten).
Large L and Small L Brackets may be used in combination.
The Small L Brackets are fastened to the Large L Bracket using the #10-32 x 1/2" bolts, #10-32 nuts and lock washers.
To fasten the Large L or Small L Brackets to your vehicle, mark the supporting structure through the appropriate holes in the brackets, then drill the holes in the supporting structure with a 13/64" drill bit. Attach the bracket(s) to the supporting structure using two bolts (#10-32 x 1-1/4") and corresponding nuts, flat washers, and lock washers. You may also use 2 #6 sheet metal screws. Because rough road surfaces can cause excessive vibration or bouncing, be certain to fasten the bracket(s) securely to your vehicle.
Horizontal Or Vertical Mounting Of Antenna
The antenna can be attached to the vehicle in a horizontal or vertical position, or at any angle between these two points. Select the position that allows you to fasten the antenna to your vehicle in the most secure manner.
Radar antenna mounted in horizontal position.
Best mounting angle for optimum detection of all types of radar guns
3300 Superwideband remote 10/4/00 9:38 AM Page 11
10 11
INSTALLATION OF RADAR ANTENNA
Mount the antenna to the vehicle such that the ANTENNA window is facing the road surface, sky, right or left of the vehicle, and the reflector has an unobstructed view of the road ahead.
Radar antenna mounted(vertical) with 45º Reflector.
Mounted in this position, radar signals are reflected into the ANTENNA window.
This side facing rearward traffic
Signal
Antenna window
Antenna Cable To Control Panel
Once the antenna is installed, run the cable along the inside of the vehicle or under it to the engine compartment. If using the latter, find a location in the firewall where other wires (or the speedometer cable) enter the passenger compartment and feed the stereo jack connection through. Be careful not to interfere with or disconnect other wires, cables, or mechanical systems of your vehicle while routing the antenna cable. Also, keep the antenna cable away from any areas in the vehicle that may become hot. Four cable ties are provided to secure the antenna cable at various points on the vehicle.
Engaging SWRA
To engage the rear radar antenna:
1.Unplug power cable from the console or turn vehicle off if console is wired to a switched 12 volt source.
2. Plug the stereo jack connector (straight ended cable) at the end of the rear antenna cable into the RADAR 2 port on the back of the control panel.
3. Reapply power. Display reads:
Press Dark for Yes or City for No.
4. When radar is received from the rear the display reads:
MAKING THE CONNECTION
R2 ON?
K* 9
3300 Superwideband remote 10/4/00 9:38 AM Page 13
The SWRA-3300 is expertly engineered and designed to exacting quality standards to provide you with reliable, trouble-free operation. If your unit has been correctly installed following the guidelines in this manual, but is not operating optimally, please refer to the troubleshooting guide below.
PROBLEM: No display or audio.
• Check fuse in power cable, replace if necessary.
• Check fuse in fuse box, replace if necessary.
• Make sure power cable is properly grounded. PROBLEM: Display shows R1error.
• Warning communicates “loss of link” between control panel and front antenna (RADAR 1).
• Check antenna connection at back of control panel.
• Contact factory, if you suspect antenna is defective. PROBLEM: Display shows R2 error.
• Engage SWRA-3300. See page 11.
• Warning communicates “loss of link” between control panel and rear antenna (RADAR 2); occurs only if rear antenna has been installed.
• Check antenna connection at back of control panel.
• Contact factory is you suspect rear antenna is defective.
If difficulties occur which cannot be solved by information in this Troubleshooting Guide, please call Whistler Consumer Relations at 1-800-531-0004 before returning your unit for service, or you may email questions to us at info@whistlergroup.com. Please allow 3-5 days for email response.
12 13
TROUBLESHOOTING GUIDE
Memory For Feature Selected
Your preference for feature settings is maintained even when the unit is unplugged. If power to the Whistler is removed, the user selectable features are retained in memory.
3300 Superwideband remote 10/4/00 9:38 AM Page 15
14 15
WARRANTY WARRANTY
Consumer Warranty
This receiver has the same warranty as the main unit. The warranty is to the original purchaser only against all defects in materials and workmanship (this limited warranty is void if
the unit is abused, modified, installed improperly, if the housing and/or serial number have been removed). There
are no express warranties covering this product other than those set forth in this warranty. All expr ess or implied warranties for this product are limited. Whistler is not liable for damages of any type arising from the use, misuse, or operation of this product.
NOTE: This warranty does not include installation or reinstallation charges.
Service Under Warranty
During the warranty period, defective units will be repaired or replaced (with the same or a comparable model), at Whistler’s option, without charge to the purchaser when returned prepaid, with dated proof of purchase to the address below. Units returned without dated proof of purchase will be handled as described in section “Service Out Of Warranty.” Due to the specialized equipment necessary for testing a radar/laser receiver, there are no authorized service stations for Whistler brand detectors other than the factory.
When returning a unit for service under warranty, please follow these instructions:
1. Ship the unit in the original carton or in a suitable sturdy equivalent, fully insured, with return receipt requested, and shipping charges prepaid to:
Whistler Repair Dept.
1201 North Dixieland Rd.
Rogers AR 72756
IMPORTANT: Whistler will not assume r esponsibility for loss or damage incurred in shipping. Therefore, please ship your unit insured with return receipt requested.
2. Include with your unit the following information, clearly printed:
• Your name and street address (for shipping via UPS), and a daytime telephone number. (No P.O. Box please.)
• A detailed description of the problem (e.g., “Unit per forms self-test but does not respond to radar”).
• A copy of your dated proof of purchase or bill of sale.
3. Be certain your unit is returned with its serial number. For reference, please write your unit’s serial number in the following space: s/n __________________. Units without serial numbers are not covered under warranty.
IMPORTANT: To validate that your unit is within the warranty period, make sure you keep a copy of your dated proof of purchase.
3300 Superwideband remote 10/4/00 9:38 AM Page 17
16 17
WARRANTY SPECIFICATIONS
Service Out Of Warranty
Units will be repaired at “out of warranty” service rates when:
•The unit no longer belongs to the original owner.
•Dated proof of purchase is not supplied.
•The unit has been returned without its serial number.
•The unit has been abused, modified, installed improperly, or had its housing removed.
The minimum out of warranty service fee for your Whistler detector is $55.00 (U.S.). If you require out of warranty service, please return your unit as outlined in the section “Service Under Warranty” along with a certified check or money order for $55.00. Payment may also be made by MasterCard or VISA; personal checks are not accepted. In the event repairs cannot be covered by the minimum $55.00 service fee, you will be contacted by a Whistler technical service specialist who will outline options available to you. If you elect not to have your unit repaired/replaced, it will be returned to you along with your certified check or money order.
IMPORTANT: When returning your unit for service, be certain to include a daytime telephone number.
Consumer Relations
If you have questions concerning the operation of your Whistler detector, or require service during or after the warranty period, please call Consumer Relations at 1-800-531-0004. Representatives are available to answer your questions Monday
- Friday from 8:00 a.m. to 5:00 p.m. (CST), or contact us via email: info@whistlergroup.com.
• Dimensions:
Antenna: 1.4"H x 3.2"W x 4.2"L
• Weight:
Antenna: 7.5 oz.
• Radar Frequencies:
10.500 - 10.550 GHz (X Band)
24.050 - 24.250 GHz (K Band )
33.400 - 36.000 GHz (Ka Superwideband)
• Operating Temperature Range:
-20˚C to +80˚C (-4˚F to +176˚F)
• Power Requirements:
Operational 12 to 15 volts DC, 200mA nominal One or more U.S. patents apply:
#4,315,261; #5,146,227; #5,379,456; #5,666,120 and #5,990,821.
Specifications are subject to change without notice.
