A. Refrigerator Compartment

1.Lighting

2.Shelves / Shelf area

2a. Depending on the model:

-Wire grid shelf with "Smart shelf"

-Plastic "dual shelf"

3.Cooler compartment (depending on the model)

4.Rating plate

5.Crisper drawer/drawers

6.Divider (depending on the model)

7.Fan with antibacterial filter (depending on the model)

8.Separator

9.Removable bottle holder

10.Door trays

B. Freezer Compartment

11.Upper basket (freezing zone)

12.Ice tray

13.Storage basket for frozen food items

14.The freezer door trays for pizza or other frozen products with a short storage time (depending on the model)

C. Control panel

Note: The number and type of shelves, as well as configuration of accessories may vary, depending on the model. All shelves and door trays are removable. Attention: The appliance accessories are not suitable for washing in a dishwasher.

The fridge-freezer is turned on by means of the thermostat located in the upper section of the housing or on the front panel. The thermostat adjusts temperature in both compartments.

The control panel functions

The thermostat knob (depending on the model)

Adjusting temperature inside the appliance:

Knob in position 0/Off: the appliance is turned off. Knob in position 1-min: minimum cooling intensity. Knob in position 7-max: maximum cooling intensity.

Recommended thermostat position is Med.

Note: The internal temperatures are affected by the room temperature, frequency of opening the doors, as well as location of the appliance. Adjust the thermostat knob depending on these factors.

Fan (depending on the model)

The fan gives more even temperature distribution inside the refrigerator compartment, allowing better preservation of stored food

Important:

Do not obstruct the air intake area (7a) with food items.

Fan with a button

To fit the fan press the button (7b). It is advisable to activate the fan when the ambient air temperature is over 27 ÷ 28°C or if you perceive drops of water on the glass shelves or in the severe humidity conditions.

Important:

The fan will run ONLY when the compressor is in operation.Remember to turn off the fan when there is a lower ambient air temperature.

Fan without a button

An electronic system automatically turn on and turn off the fan.

Important:

The fan will run ONLY when the compressor is in operation.

The anti-bacterial filter ensures a higher level of hygiene in your refrigerator through continuous purifying of circulating air from bacteria. Remove it from the box (found in the crisper drawer (item 5) and insert into the grille (item 7c). Replace the filter every 6 months.

1.Remove the filter together with the grille and dispose as a whole.

2.Replace the filter and the grille with the new ones.

3.The replacement procedure is attached with the filter. Our After-sales Service can supply this type of filter.

Light - how to replace the bulb

Before replacing the bulb, remove the power plug from the mains socket. Next:

1.Hold the diffuser as shown and squeeze it slightly.

2.Slide it towards the rear of the appliance

3.Unscrew the light bulb as illustrated in the picture.
