Whirlpool 8790 User Manual

EN

AKZM 8790

User and maintenance manual

Manuel d’utilisation et d’entretien

Handleiding voor gebruik en onderhoud

IMPORTANT SAFETY INSTRUCTIONS

YOUR SAFETY AND THAT OF OTHERS IS PARAMOUNT

This manual and the appliance itself provide important safety warnings, to be read and observed at all times.

This is the danger symbol, pertaining to safety, which alerts users to potential risks to themselves and others.
All safety warnings are preceded by the danger symbol and the following terms:

DANGER

WARNING

Indicates a hazardous situation which, if not avoided, will cause serious injury.

Indicates a hazardous situation which, if not avoided, could cause serious injury.

All safety warnings give specific details of the potential risk present and
indicate how to reduce risk of injury, damage and electric shock
resulting from improper use of the appliance. Carefully observe the
following instructions:

- The appliance must be disconnected from the power supply before
carrying out any installation work.

- Installation and maintenance must be carried out by a qualified
technician, in compliance with the manufacturer’s instructions and
local safety regulations. Do not repair or replace any part of the
appliance unless specifically stated in the user manual.

- Power cable replacement must be carried out by a qualified
electrician. Contact an authorized service centre.

- Regulations require that the appliance is earthed.

- The power cable must be long enough for connecting the
appliance, once fitted in its housing, to the main power supply.

- For installation to comply with current safety regulations, an all­pole disconnect switch with minimum contact gap of 3 mm must
be utilized.

- Do not use multiple plug adaptors if the oven is fitted with a plug.

- Do not use extension leads.

- Do not pull the power supply cable.

- The electrical components must not be accessible to the user after
installation.

- If the surface of the induction plate is cracked, do not use it and
switch off the appliance to avoid the possibility of electric shock
(only for models with induction function).

EN1

- Do not touch the appliance with any wet part of the body and do
not operate it when barefoot.

- This appliance is designed solely for use as a domestic appliance for
cooking food. No other type of use is permitted (e.g.: heating
rooms). The Manufacturer declines all responsibility for
inappropriate use or incorrect setting of the controls.

- This appliance can be used by children from 8 years and above and
persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made
by children without supervision.

- The accessible parts of the appliance may become very hot during
use. Young children should be kept away from the appliance and
supervised to ensure that they do not play with it.

- The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less
than 8 years old shall be kept away, unless continuously supervised.

- During and after use, do not touch the heating elements or interior
surfaces of the appliance - risk of burns. Do not allow the appliance
to come into contact with cloths or other flammable materials until
all the components have cooled sufficiently.

- At the end of cooking, exercise caution when opening the
appliance door, letting the hot air or steam exit gradually before
accessing the oven. When the appliance door is shut, hot air is
vented from the aperture above the control panel. Do not obstruct
the vent apertures.

- Use oven gloves to remove pans and accessories, taking care not to
touch the heating elements.

- Do not place flammable materials in or near the appliance: a fire
may break out if the appliance is inadvertently switched on.

- Do not heat or cook sealed jars or containers in the appliance.
The pressure that builds up inside might cause the jar to explode,
damaging the appliance.

- Do not use containers made of synthetic materials.

EN2

- Overheated oils and fats catch fire easily. Always remain vigilant
when cooking foods rich in fat and oil.

- Never leave the appliance unattended during food drying.

- If alcoholic beverages are used when cooking foods (e.g. rum,
cognac, wine), remember that alcohol evaporates at high
temperatures. As a result, there is a risk that vapours released by the
alcohol may catch fire upon coming into contact with the electrical
heating element.

- Never use steam cleaning equipment.

- Do not touch the oven during the pyrolysis cycle. Keep children
away from the oven during the pyrolysis cycle. Excess spillage must
be removed from the oven cavity before cleaning cycle (only for
ovens with Pyrolysis function).

- Only use the temperature probe recommended for this oven.

- Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the oven door glass since they can scratch the surface, which may
result in shattering of the glass.

- Ensure that the appliance is switched off before replacing the lamp
to avoid the possibility of electric shock.

- Do not use aluminium foil to cover food in the cooking vessel
(only for ovens with cooking vessel supplied).

- Use protective gloves to perform all unpacking and installation
operations.

Scrapping of household appliances

- This appliance is manufactured with recyclable or reusable materials. Dispose of it in accordance with local waste disposal
regulations. Before scrapping, cut off the power supply cable.

- For further information on the treatment, recovery and recycling of household electrical appliances, contact your
competent local authority, the collection service for household waste or the store where you purchased the appliance.

INSTALLATION

After unpacking the oven, make sure that it has not been damaged during transport and that the oven door closes properly. In
the event of problems, contact the dealer or your nearest After-sales Service. To prevent any damage, only remove the oven
from its polystyrene foam base at the time of installation.
To safely move the oven, use the handle provided in the accessories pack.

1. Insert the handle securely into the lateral holes (Fig. 1)

2. Lift the handle up as shown in Fig. 2

Fig. 1 Fig. 2

EN3

PREPARING THE HOUSING UNIT

• Kitchen units in contact with the oven must be heat resistant (min 90°C).

• Carry out all cabinet cutting work before fitting the oven in the housing and carefully remove all wood chips and sawdust.

• After installation, the bottom of the oven must no longer be accessible.

• For correct appliance operation, do not obstruct the minimum gap between the worktop and the upper edge of the oven.

ELECTRICAL CONNECTION (only in some models)

Make sure the power voltage specified on the appliance dataplate is the same as the mains voltage. The dataplate is on the front
edge of the oven (visible when the door is open).

• Power cable replacement (type H05 RR-F 3 x 1.5 mm
authorized service centre.

• The oven is programmed to operate with power absorption above 2.5 kW (indicated by “HIGH” in the settings) which is
compatible with a domestic power supply above 3kW. If the household has a lower power supply, the setting must be
lowered (“LOW” in the settings). The table below details the recommended electrical power settings for the various
countries.

Country Setting

Germany High
Spain Low
Finland High
France High
Italy Low
Holland High
Norway High
Sweden High
UK Low
Belgium High

2

) must be carried out by a qualified electrician. Contact an

GENERAL RECOMMENDATIONS

Before use:

- Remove protective cardboard pieces, protective film and adhesive labels from accessories, induction plate and cooking
vessel.

- Remove the accessories from the oven. Position the induction plate at the third level and plug it in.

- Place the cooking vessel on the induction plate and fill it in with 200g of water.

- Select the Top Finishing function and run the oven for approximately one hour to eliminate the smell and fumes from the
insulating materials and protective grease.

During use:

- Do not place heavy objects on the door as they could damage it.

- Do not cling to the door or hang anything from the handle.

- Do not cover the inside of the oven with aluminium foil.

- Never pour water into the inside of a hot oven; this could damage the enamel coating.

- Never drag pots or pans across the bottom of the oven as this could damage the enamel coating.

- Make sure that the electrical cables of other appliances do not touch hot parts of the oven or become trapped in the door.

- Do not expose the oven to atmospheric agents.

- Never pour water on the induction plate when inserted into the oven or when it is hot; this could damage the glass or the
enamel coating.

- Insert and remove the induction plate carefully in order to avoid accidental damage to the glass and/or electrical plug.

- Before using the oven in standard mode (without induction), completely remove the induction plate from the oven.
Leaving the induction plate in the oven could damage it.

After Use:

- Allow the induction plate to cool down before removal if cleaning is required. When the induction plate is removed from
the oven, ensure the supplied socket cover is used to prevent dirt entering the electrical socket (Fig. 1).

Fig. 1

EN4

SAFEGUARDING THE ENVIRONMENT

Disposal of packing material

The packing material is 100% recyclable and is marked with the recycle symbol ( ). The various parts of the packing must
therefore be disposed of responsibly and in full compliance with local authority regulations governing waste disposal.

Scrapping the product

- This appliance is marked in compliance with European Directive 2002/96/EC, Waste Electrical and Electronic Equipment
(WEEE).

- By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

- The symbol on the product or on the accompanying documentation indicates that it should not be treated as

domestic waste but must be taken to an appropriate collection centre for the recycling of electrical and electronic
equipment.

Energy saving

- Only pre-heat the oven if specified in the cooking table or your recipe.

- Use dark lacquered or enamelled baking moulds as they absorb heat far better.

- Switch the oven off 10/15 minutes before the set cooking time. Food requiring prolonged cooking will continue to cook even
once the oven is switched off.

DECLARATION OF CONFORMITY

- This oven, which is intended to come into contact with foodstuffs, complies with European Regulation ( ) n.1935/2004
and has been designed, manufactured and sold in conformity with the safety requirements of the “Low Voltage” directive
2006/95/CE (which replaces 73/23/CEE and subsequent amendments), the protection requirements of “EMC” 2004/108/CE.

TROUBLESHOOTING GUIDE

The oven does not work:

• Check for the presence of mains electrical power and if the oven is connected to the electrical supply.

• Turn off the oven and restart it to see if the fault persists.

The electronic programmer does not work:

• If the display shows the letter “ ” followed by a number, contact your nearest After-sales Service. Specify in this case the
number that follows the letter “ ”.

The induction plate does not work:

• The induction plate must be used on the third shelf position only; ensure it is correctly positioned and fully connected.

• Turn the oven off and then on again. Check if the fault persists.

AFTER-SALES SERVICE

Before calling the After-Sales Service:

1. See if you can solve the problem yourself with the help of the suggestions given in the “Troubleshooting guide“.

2. Switch the appliance off and back on again it to see if the fault persists.

If after the above checks the fault still occurs, get in touch with the nearest After-sales Service.

Always specify:

• a brief description of the fault;

• the type and exact model of the oven;

• the service number (number after the word Service on the rating plate), located on the right hand edge of the oven cavity
(visible when the oven door is open). The service number is also indicated on the guarantee booklet;

• your full address;

• your telephone number.

If any repairs are required, please contact an authorised After-sales Service (to guarantee that original spare parts will be used
and repairs carried out correctly).

EN5

CLEANING

WARNING

- Never use steam cleaning equipment.

- Only clean the oven when it is cool to the touch.

- Disconnect the appliance from the power supply.

Oven exterior

IMPORTANT: do not use corrosive or abrasive detergents. If any of these products accidentally comes into contact with
the appliance, clean immediately with a damp Microfibre cloth.

• Clean the surfaces with a damp Microfibre cloth. If it is very dirty, add a few drops of washing up detergent to the water.
Finish off with a dry cloth.

Oven interior

IMPORTANT: do not use abrasive sponges or metallic scrapers or scourers. Over time, these can ruin enamelled surfaces
and the oven door glass.

• After every use, allow the oven to cool then clean it preferably while it is still warm in order to remove built-up dirt and
stains caused by food residues (e.g. food with a high sugar content).

• Use proprietary oven detergents and follow the manufacturer’s instructions to the letter.

• Clean the door glass with a suitable liquid detergent. The oven door can be removed to facilitate cleaning (see MAINTENANCE).

• The top heating element of the grill (see MAINTENANCE) can be lowered (some models only) to clean the roof of the oven.

N.B.: during prolonged cooking of foods with a high water content (e.g. pizza, vegetables, etc.) condensation may form
on the inside of the door and around the seal. When the oven is cold, dry the inside of the door with a cloth or sponge.

Accessories:

• Soak the accessories in water with washing up detergent immediately after use, handling them with oven gloves if still hot.

• Food residues can be easily removed using a brush or sponge.

Induction Plate:

• When cool to the touch, use a sponge and suitable liquid detergent for ovens or hobs. Do not clean the induction plate in
a dishwasher.

Internal Electrical Socket:

• Remove the metallic plug cover; use a humidified sponge to clean the plug. Do not use metallic and/or sharp tools.

Cooking Vessel:

• Suitable for dishwashing. Alternatively, use soft sponge and suitable liquid detergent.

Cleaning the rear wall and catalytic side panels of the oven (if present):

IMPORTANT: do not use corrosive or abrasive detergents, coarse brushes, pot scourers or oven sprays which could
damage the catalytic surface and ruin its self-cleaning properties.

• Operate the oven empty with the fan-assisted function at 200°C for about one hour.

• Next, leave the appliance to cool down before removing any food residue with a sponge.

MAINTENANCE

WARNING

REMOVING THE DOOR
To remove the door:

1. Open the door fully.

2. Lift the catches and push them forwards as far as they will go (fig. 1).

3. Close the door as far as it will go (A), lift it up (B) and turn it (C) until it is released (D) (fig. 2).

To refit the door:

1. Insert the hinges in their seats.

2. Open the door fully.

3. Lower the two catches.

4. Close the door.

- Use protective gloves.

- Ensure the oven is cold before carrying out the following operations.

- Disconnect the appliance from the power supply.

Fig. 1 Fig. 2

EN6

REMOVING THE SIDE GRILLES

The accessory-holder grilles are equipped with two fixing screws (fig. 1) for optimum stability.

1. Remove the screws and fixing plates on the right and left with the aid of a coin or tool.

2. To remove the grilles, lift them up (1) and turn them (2) as shown in fig. 3.

Fig. 1 Fig. 2 Fig. 3

MOVING THE TOP HEATING ELEMENT (SOME MODELS ONLY)

1. Remove the side accessory holder grilles (Fig. 3).

2. Pull the heating element out a little (Fig. 4) and lower it (Fig. 5).

3. To reposition the heating element, lift it up, pulling it slightly towards you, making sure it comes to rest on the lateral
supports.

Fig. 4 Fig. 5 Fig. 6

REPLACING THE OVEN LAMP

To replace the rear lamp (if present):

1. Disconnect the oven from the power supply.

2. Unscrew the lamp cover (Fig. 6), replace the lamp (see note for lamp type) and screw the lamp cover back on.

3. Reconnect the oven to the power supply.

To replace the side lamp (if present):

1. Disconnect the oven from the power supply.

2. Remove the side accessory holder grilles, if present (Fig. 3).

3. Use a screwdriver to prise off the lamp cover (Fig. 7).

4. Replace the lamp (see note for lamp type) (Fig. 8).

5. Reposition the lamp cover, pushing it on firmly until it snaps into place (Fig. 9).

6. Refit the side accessory holder grilles.

7. Reconnect the oven to the power supply.

Fig. 7 Fig. 8 Fig. 9 Fig. 10

N.B.:

- Only use 25-40W/230V type E-14, T300°C incandescent lamps, or 20-40W/230 V type G9, T300°C halogen lamps.

- The lamp used in the appliance is specifically designed for electrical appliances and is not suitable for household room
illumination (Commission Regulation (EC) No 244/2009).

- Lamps are available from our After-sales Service.

IMPORTANT:

- If using halogen lamps, do not handle with bare hands since fingerprints can damage them.

- Do not use the oven until the lamp cover has been repositioned.

EN7
