DUE TO CONSTANT FACTORY IMPROVEMENTS, THE PRODUCT PICTURED MIGHT DIFFER
SLIGHTLY FROM THE PRODUCT IN THIS BOX.
IMPORTANT SAFEGUARDS
TABLE OF CONTENTS / ÍNDICE / TABLE DES MATIÈRES
COMPONENT LIST
PROTECTIVE TAPE
CLEANING INSTRUCTIONS
VACUUM CHAMBER SEALS
COOLING FAN
THERMAL OVERLOAD PROTECTOR
LIMIT SWITCH
OTHER CONSUMER SAFETY INFORMATION
THERMAL OVERLOAD PROTECTION
CONTROL BUTTONS
OPERATING INSTRUCTIONS
PREPARING VAC BAGS FROM A ROLL
SERVICE INSTRUCTIONS
REPLACING THE FUSE
STORAGE LIFESPAN GUIDELINES
FOOD SAFETY
WARRANTY
3
4-5
6
6
7
7
7
7
8
8
9
9-10
11
11-12
12
13
14
16
SALVAGUARDIAS IMPORTANTES
LISTA DE COMPONENTES
CINTA PROTECTORA
INSTRUCCIONES DE LIMPIEZA
SELLOS DE LA CÁMARA DE VACÍO
VENTILADOR DE REFRIGERACIÓN
PROTECTOR DE SOBRECARGA TÉRMICA
INTERRUPTOR DE LÍMITE
OTRA INFORMACIÓN DE SEGURIDAD PARA EL CLIENTE
PROTECCIÓN DE SOBRECARGA TÉRMICA
BOTONES DEL CONTROL
INSTRUCCIONES DE FUNCIONAMIENTO
PREPARACIÓN DE BOLSAS AL VACÍO DE UN ROLLO
INSTRUCCIONES DE MANTENIMIENTO
REEMPLAZO DEL FUSIBLE
PAUTAS SOBRE LA VIDA EN ALMACENAMIENTO
SEGURIDAD DE LOS ALIMENTOS
INFORMACIÓN DE GARANTÍA WESTON
PRÉCAUTIONS IMPORTANTES
DESCRIPTION DE LA PIÈCE
RUBAN PROTECTEUR
INSTRUCTIONS DE NETTOYAGE
GARNITURE DU CANAL D’ASPIRATION
VENTILATEUR
LIMITEUR DE SURCHARGE
INTERRUPTEUR DE POSITION
AUTRES RENSEIGNEMENTS DE SÉCURITÉ AU CONSOMMATEUR
PROTECTION CONTRE UNE SURCHARGE TERMIQUE
TOUCHES DE COMMANDE
MODE D’EMPLOI
FABRICATION D’UN SAC SUR MESURE AVEC UN ROULEAU
INSTRUCTIONS D’ENTRETIEN
REMPLACEMENT DU FUSIBLE
GUIDE DE CONSERVATION DES ALIMENTS EMBALLÉS
SÉCURITÉ ALIMENTAIRE
INFORMATION SUR LA GARANTIE
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of re, electric shock, and/or injury to persons,
including the following:
1. Read all instructions.
2. ALWAYS DISCONNECT Vacuum
Sealer from power source before
servicing, changing accessories or
cleaning the unit.
3. Plug the Vacuum Sealer into a
standard 120 Volt, 60 Hz wall outlet.
Avoid using extension cords.
4. DO NOT USE the Vacuum Sealer
if the Power Cord, Plug or any other
parts are damaged. If the Power Cord
or the Vacuum Sealer is damaged,
call Customer Service. DO NOT
ATTEMPT TO REPLACE THE CORD.
Be sure to not allow the Power Cord to
drape into your work area. Check that
all parts are operating properly, and
perform the intended functions. Check
for any other conditions that may
affect the operation.
5. NEVER use any accessories or
parts from other manufacturers. Doing
so will VOID YOUR WARRANTY and
may cause re, electrical shock or
injury.
6. Reduce risk of unintentional
starting. Make sure the Power
Switch is in the “OFF” position before
attaching to the power source.
9. TO PROTECT AGAINST RISK
OF ELECTRICAL SHOCK: DO
NOT SUBMERGE THE VACUUM
SEALER INTO WATER OR LIQUID.
BE SURE THE VACUUM SEALER
IS DISCONNECTED FROM THE
POWER SOURCE BEFORE
CLEANING. Follow the “Cleaning
Instructions” in this booklet. NEVER
rinse appliance Vacuum Sealer under
tap.
10. NEVER LEAVE THE VACUUM
SEALER UNATTENDED. Be safe,
DISCONNECT the Vacuum Sealer
from power source before leaving
the work area. Close supervision is
necessary when any appliance is used
near children. This appliance is NOT to
be used by children.
11. DO NOT let the Power Cord hang
over edge of work surface.
12. Be sure the Vacuum Sealer is on
a stable work surface. Be sure all the
Vacuum Sealer Feet are stable.
13. DO NOT use the Vacuum Sealer
outdoors.
14. DO NOT use the Vacuum Sealer
while under the inuence of drugs,
medications or alcohol.
ENGLISH INSTRUCTIONS
7. KEEP FINGERS CLEAR of the
Heat Sealing Bar and Seal Bar Tape
AT ALL TIMES, these areas become
HOT. Doing so may cause serious
injury.
8. DO NOT take this appliance
apart; doing so will VOID YOUR
WARRANTY and may result in
personal injury.
SAVE THESE INSTRUCTIONS
15. The Vacuum Sealer is ONLY
intended to be used with VACUUM
BAGS. For best results, only use the
recommended vacuum bags. DO
NOT USE HOUSEHOLD BAGS! Any
other uses of the Vacuum Sealer,
other than the uses described in this
booklet, could potentially damage the
appliance and void the warranty!
3
Power Cord
Storage
9
ENGLISH INSTRUCTIONS
7 / 10
Vacuum
Lid
12
5
Pro-Series Vacuum Sealer
13
Maintenance Kit Sold Separately
Model No. 08-0501-W
P
O
T
S
R
E
W
O
P
L
A
E
S
L
UA
N
A
M
M
U
U
C
A
V
L
A
T
E
R
S
TA
S
L
O
O
C
8
1
6 / 11
2
4
3
Power Cord Port
4
COMPONENT LIST
DIAGRAM NUMBERPART DESCRIPTION
1POWER CORD
2POWER INDICATOR SWITCH
3FUSE HOLDER
410-AMP BUSS FUSE
5RUBBER FOOT (6)
6SEAL BAR HEATING ELEMENT WITH
SCREWS
7VACUUM LID SEAL BAR ASSEMBLY
8VACUUM LID HANDLE WITH SCREWS
9INTERNAL COOLING FAN
1010MM UPPER SEAL BAR TAPE
1115MM LOWER SEAL BAR TAPE (2)*
*NOTE ONE EXTRA PIECE OF SEAL BAR TAPE IS
INCLUDED WITH THE ORIGINAL UNIT AS A SPARE.
12OVAL VACUUM CHAMBER SEAL (2)
13MAINTENANCE KIT
(SOLD SEPARATELY: INCLUDES 2
OVAL VACUUM CHAMBER SEALS, (1)
10MM UPPER SEAL BAR TAPE, (1)
15MM LOWER SEAL BAR TAPE
ENGLISH INSTRUCTIONS
If any components of this unit are broken, the unit does not operate properly or you
need a replacement instruction manual, visit us on the web at
WestonSupply.com
Or call Weston Brands, LLC Toll Free at 1-800-814-4895
Monday thru Friday 8:00am-5:00pm ET. Outside the U.S. call 001-216-901-6801
5
PROTECTIVE TAPE
There are two (2) factory installed
strips of Seal Bar Tape on the Vacuum Sealer.
DO NOT REMOVE THE TAPE!
ENGLISH INSTRUCTIONS
SEAL BAR TAPE
DO NOT
REMOVE!
OVAL VACUUM CHAMBER SEALS
DO NOT REMOVE!
The Seal Bar Heating Element and Vacuum Lid Seal are each covered
with Seal Bar Tape to protect vacuum bags during sealing Figure 1.
DO NOT remove the Seal Bar Tape. See the “Service Instructions”
section of this manual for information on replacing the Seal Bar Tape,
if necessary.
*NOTE one extra piece of Seal Bar Tape is included with the original unit as a
spare.
FIGURE 1
CLEANING INSTRUCTIONS
w WARNING
. NEVER IMMERSE the Vacuum Sealer in water or other liquid.
. Make sure the Vacuum Sealer has completely cooled before cleaning it.
. Wipe clean all outside surfaces including the Plastic Vacuum Chamber and
Vacuum Lid with a damp cloth or paper towel. Most household spray cleaners
are safe to use. Avoid spraying directly into the vent on the left side of the
unit. DO NOT use abrasive cleansers! Abrasive cleansers will spoil the
clarity of the Vacuum Lid.
. Be careful while cleaning not to peel or damage the strips of Seal Bar Tape
covering the Seal Bar Heating Element and Vacuum Lid Seal.
. Dry all surfaces and close the Vacuum Lid before storing the Vacuum
Sealer.
6
Electrical Shock Hazard. Before cleaning, assembling, or
disassembling the vacuum sealer, make sure the vacuum sealer
is unplugged.
VACUUM CHAMBER SEALS
There are two factory-installed Oval Vacuum Chamber Seals on the Vacuum
Sealer. When the Vacuum Lid is closed and downward force applied, they form
an airtight seal so the Vacuum Chamber can be evacuated.
The Oval Vacuum Chamber Seals may wear over time and require replacement.
See the “Service Instructions” section of this manual for information on replacing
the Oval Vacuum Chamber Seals, if necessary.
COOLING FAN
The Vacuum Sealer has an Internal Cooling Fan that runs whenever the
unit is plugged in and turned on. To save energy, turn the unit “OFF”
and unplug the Power Cord when not in use.
THERMAL OVERLOAD PROTECTOR
The Vacuum Sealer will automatically shut down if it overheats. If this occurs,
turn the unit off and open the Vacuum Lid. Resume normal operation after the
unit cools about 20 minutes.
To help prevent overheating, wait at least 20 seconds between cycles with the
Vacuum Lid open. Avoid touching the Seal Bar Tape. The Seal Bar Tape will
remain hot for a brief period of time after each sealing cycle.
LIMIT SWITCH
The Vacuum Sealer is equipped with a switch to prevent actuation of the Seal
Bar Heating Element in manual mode when the Vacuum Lid is open. When the
Vacuum Lid is closed, heat made by the Seal Bar Heating Element is absorbed
by the vacuum bag and Vacuum Lid Seal.
ENGLISH INSTRUCTIONS
When the Vacuum Lid is open, there is no means to dissipate the heat and unit
damage may occur.
NOTE: The Vacuum Sealer is ONLY intended to be used with VACUUM BAGS.
For best results, only use the recommended vacuum bags with an embossed or mesh
lining. DO NOT USE HOUSEHOLD BAGS! Any other uses of the Vacuum Sealer, other than the uses described in this booklet, could potentially damage the
appliance and void the warranty!
7
OTHER CONSUMER SAFETY INFORMATION
w WARNING
grounded (3-prong) plug to reduce the risk of electric shock. The plug fits only
one way into a grounded outlet. Do not defeat the safety purpose of the plug
by modifying the plug in any way or by using an adapter. If the plug does not
fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician
replace the outlet.
The length of the cord used on this appliance was selected to reduce the
hazards of becoming tangled in or tripping over a longer cord. If a longer cord
is necessary, an approved extension cord may be used. The electrical rating of
the extension cord must be equal to or greater than the rating of the appliance.
Care must be taken to arrange the extension cord so that it will not drape over
the countertop or tabletop where it can be pulled on by children or accidentally
ENGLISH INSTRUCTIONS
tripped over.
Electrical Shock Hazard: This appliance is provided with a
THERMAL OVERLOAD PROTECTION
The vacuum sealer will automatically shut off if it overheats. If this occurs,
unplug the unit and open the vacuum lid. Resume normal operation after the
unit cools or about 20 minutes.
Always allow 20 seconds minimum for cool down between operations.
• This allows the heat-seal bar to cool down.
• Placing a new bag in the unit and closing the lid when the
heat-seal bar is still hot will cause the bag to prematurely melt together
before vacuum seal operation.
w CAUTION
Burn Hazard. Avoid touching the heat-seal bar.
8
CONTROL BUTTONS
STOP BUTTON
Pressing the Stop Button stops to halt the vacuuming process Figure 3.
MANUAL SEAL BUTTON
Press the Manual Seal Button during the vacuuming process to initiate the seal
(before the preset vacuum pressure is reached) Figure 3.
START BUTTON
Press the Start Button to initiate the vacuuming process (the Vacuum Sealer
will automatically seal the bag when a preset vacuum pressure is reached)
Figure 3.
Rec on n ec t with Re al Food
PRO-2100
VACUUM
SEALER
U.S. P atented
QUICK REFERENCE GUIDE
AUTOMATIC VACUUM SEAL
1. PLUG power cord into 120-Volt outlet
2. Turn the POWER SWITCH to the “ON” position
3. Place VACUUM BAG OPEN END into VACUUM CHAMBER (See Instruction Book for Details)
4. CLOSE LID – APPLY PRESSURE to HANDLE – push START button
5. The machine will VACUUM and SEAL automatically*
MANUAL SEAL MODE
MANUAL SEAL MODE is used to disengage the vacuum pump and engage the sealing function manually
1. Follow steps 1-4 of the Automatic Vacuum Seal Instructions
2. When the desired vaccum is reached, press the MANUAL SEAL BUTTON
3. The machine will begin sealing the bag*
* The Sealing Time is pre-set to 3 seconds. The Cooling Time is pre-set to 3 seconds.
THIS IS ONLY A QUICK REFERENCE GUIDE. THOROUGHLY READ AND UNDERSTAND
THE SUPPLIED INSTRUCTION MANUAL BEFORE USING THIS APPLIANCE.
POWER
VACUUM
SEAL
COOL
FIGURE 3
STOP
MANUAL SEAL
START
OPERATING INSTRUCTIONS
w WARNING
· CAUTION: The Seal Bar Heating Element and Vacuum Lid Seal get HOT! Avoid
touching them. Be careful while loading bags into the Vacuum Chamber.
Electrical Shock Hazard. Before cleaning, assembling, or
disassembling the vacuum sealer, make sure the vacuum sealer
is unplugged.
ENGLISH INSTRUCTIONS
· DO NOT try to open the Vacuum Lid before the vacuum has released or unit
damage may occur.
· Wait at least 20 seconds between cycles to avoid overheating the unit.
· DO NOT allow liquids, powder or other small substances to be sucked into the
Vacuum Port or unit damage may occur. Press the “Stop” Button to hault the
vacuum process. Use the “Manual Seal” Button when vacuum sealing liquids.
· The Vacuum Sealer is ONLY intended to be used with VACUUM BAGS.
For best results, only use the recommended vacuum bags. DO NOT USE
HOUSEHOLD BAGS! Any other uses of the Vacuum Sealer, other than the
uses described in this booklet, could potentially damage the appliance and void
the warranty.
1. Make sure the Vacuum Sealer is in the “OFF” position. Attach the Vacuum
Sealer to the power supply.
2. Turn the Vacuum Sealer “ON”.
3. The “POWER” Light on the display, “POWER INDICATOR” Switch both will
illuminate and the Internal Cooling Fan will run.
4. Open the Vacuum Lid.
9
5. Fill a vacuum bag with the product you want to seal. Leave at least 2” (5 cm)
of space between the open end of the bag and product Figure 4.
6. Load the open end of the bag into the Lower Vacuum Chamber. Center the
bag in the Lower Vacuum Chamber. Place the bag close to, but do not cover, the
Vacuum Port. Be careful not to touch either strip of Seal Bar Tape which may be
HOT from a previous heating cycle.
7. Close the Vacuum Lid. Make sure there are no folds or creases in the bag in
the sealing area.
8. Press down on the Vacuum Lid Handle to form a tight seal.
9. Press the “START” Button to initiate the vacuuming process (the “VACUUM”
Light will illuminate). Release the Vacuum Lid Handle at the rst sign of bag
collapse. The Vacuum Sealer will automatically seal the bag when a preset
vacuum pressure is reached in the Vacuum Chamber. Sealing lasts for 3
seconds (the “SEAL” Light will illuminate).
ENGLISH INSTRUCTIONS
10. To manually seal a bag press the Manual Seal Button at any time during the
vacuuming process.
11. You can stop the vacuuming process at any time by pressing the “STOP”
Button.
12. Sealing is complete when the Vacuum Chamber releases after a 3 second
cooling period (the “COOL” Light will illuminate). The release is audible.
13. Open the Vacuum Lid and remove the bag. DO NOT try to open the Vacuum
Lid before the vacuum has released or unit damage may occur. Wait at least 20
seconds before sealing another bag to avoid overheating the unit.
14. Turn the Vacuum Sealer “OFF” and unplug the Power Cord when you are
done.
Leave 2”
(5 cm)
Space
NOTE: The Vacuum Sealer is ONLY intended to be used with VACUUM BAGS. For
best results, only use the recommended vacuum bags with an embossed or mesh lining.
DO NOT USE HOUSEHOLD BAGS! Any other uses of the Vacuum Sealer, other
than the uses described in this booklet, could potentially damage the appliance and void
the warranty!
10
FIGURE 4
Bag in Center of
Vacuum Chamber
Vacuum
Port
PREPARING VAC BAGS FROM A ROLL
1. Make sure the Vacuum Sealer is in the “OFF” position. Attach the Vacuum
Sealer to the power supply.
2. Turn the Vacuum Sealer “ON”.
3. The “POWER” Light on the display, “POWER INDICATOR” Switch both will
illuminate and the Internal Cooling Fan will run.
4. Open the Vacuum Lid.
5. Cut a vacuum bag to the length you want from a roll.
6. Place either open end of the bag against the outer face of the Oval Vacuum
Chamber Seal in the Vacuum Chamber (not in the Vacuum Chamber).
7. Close the Vacuum Lid. The bag end should be sandwiched between the
Vacuum Lid Seal and Seal Bar Heating Element. Make sure there are no wrinkles
or creases in the bag in the sealing area.
8. Press and hold the Vacuum Lid Handle down. You may need to continue
holding the bag.
9. Press the “START” Button (this will engage the Pump and the Heating Element).
Press the Manual Seal Button to seal the vacuum bag.
10. Sealing is complete when the Vacuum Chamber releases after a 3 second
cooling period (the “COOL” Light will illuminate). The release is audible.
11. Open the Vacuum Lid and remove the bag. DO NOT try to open the Vacuum
Lid before the vacuum has released or unit damage may occur. Wait at least 20
seconds before sealing another bag to avoid overheating the unit.
12. Turn the Vacuum Sealer “OFF” and unplug the Power Cord when you are
done.
ENGLISH INSTRUCTIONS
SERVICE INSTRUCTIONS
w WARNING
Some parts of the Vacuum Sealer may need replacing after repeated use. A
Vacuum Sealer Maintenance Kit (Sold Separately Model No. 08-0501-W) may be
necessary for the Vacuum Sealer to properly function.
REPLACING THE OVAL VACUUM CHAMBER SEALS:
1. Turn “OFF” the Vacuum Sealer and remove the Power Cord from the electrical
outlet.
2. Make sure the unit is completely cool.
3. Open the Vacuum Lid.
4. Remove the Oval Vacuum Chamber Seal from the groove on the underside of
the Vacuum Lid.
5. Remove the Oval Vacuum Chamber Seal from the groove in the Plastic Vacuum
Chamber.
Electrical Shock Hazard. Before cleaning, assembling, or
disassembling the vacuum sealer, make sure the vacuum sealer
is unplugged.
11
6. Set a new Oval Vacuum Chamber Seal on the groove in the Plastic Vacuum
Chamber. Work the seal into the groove.
7. Position a new Oval Vacuum Chamber Seal near the groove in the Vacuum Lid.
Work the seal into the groove.
REPLACING THE SEAL BAR TAPE:
*NOTE one extra piece of Seal Bar Tape is included with the original unit as a spare.
1. Turn “OFF” the Vacuum Sealer and remove the Power Cord from the electrical
outlet.
2. Make sure the unit is completely cool.
3. Open the Vacuum Lid.
4. Pick at either end of the Seal Bar Tape covering the Seal Bar Heating Element until
it lifts slightly. Grasp the loose end and slowly pull the Seal Bar Tape back over itself
until fully removed.
ENGLISH INSTRUCTIONS
5. Repeat step 4 for the Seal Bar Tape covering Vacuum Lid Seal. DO NOT remove
the Seal.
6. Remove the backing from a new wide strip of Seal Bar Tape for the Seal Bar Heating
Element. Be careful not to allow the Seal Bar Tape to contact anything including itself
while the adhesive side is exposed.
7. Hold one end of the Seal Bar Tape in each hand. Stick the left end of the Seal Bar
Tape to the at area on the Plastic Vacuum Chamber just left of the Seal Bar Heating
Element. Apply the Seal Bar Tape from left to right over the Seal Bar Heating Element
until done. Make sure there are no wrinkles or folds in the Seal Bar Tape once applied.
The Seal Bar Tape should fully cover the Seal Bar Heating Element.
8. Remove the backing from a new narrow strip of Seal Bar Tape for the Vacuum Lid
Seal. Stick the left end of the Seal Bar Tape onto the left end of the Seal. The Seal Bar
Tape and Seal ends should be ush. Apply the Seal Bar Tape from left to right over
the Vacuum Lid Seal until done. Make sure there are no wrinkles or folds in the Seal
Bar Tape once applied. The Seal Bar Tape should fully cover the Vacuum Lid Seal.
REPLACING THE FUSE
If the Vacuum Sealer does not operate when it is plugged in
and turned on, try any or all of the following:
1. Make sure the Fuse is not blown. The Fuse is located on
the right side of the unit directly above the Power Cord Port.
Turn “OFF” and unplug the Vacuum Sealer. Twist off and
remove the Fuse Cap. Remove and check the Fuse. The
thin metal band in the center of the Fuse should be clean and
unbroken. If it is burned and/or broken, replace it with a new
Fuse (10 Amp). Replace the Fuse Cap.
2. Make sure the Connector at the end of the Power Cord is
plugged completely into the Power Cord Port.
3. Make sure the Power Cord is not damaged. DO NOT use
a damaged Power Cord. Call the Customer Service line for
information on part replacement.
4. Try connecting the Power Cord Plug to another electrical
outlet.
12
FIGURE 5
STORAGE LIFESPAN GUIDELINES
. IMPORTANT NOTE: Vacuum packaging is NOT a substitute for refrigeration.
Vacuum packed perishable foods still require refrigeration.
. NEVER thaw frozen foods at room temperature. Thaw frozen foods in a
refrigerator or microwave oven.
. In general, the colder the temperature at which foods are stored, the longer the
shelf life.
. Handle vacuum sealer bags with care. Avoid damaging them. A damaged bag
will not hold a seal.
. Only use information in the following chart as a guideline! Refer to the “Vacuum
Packaging Guidelines” and “Food Safety” sections of this manual. Actual storage
life spans may vary. Check all food for spoilage before use.
FOOD STORAGE NORMAL VACUUM
TYPE LOCATION LIFE PACKED
LIFE
LARGE CUTS OF MEAT Freezer 6 months 2-3 years
GROUND MEAT Freezer 4 months 1 year
FISH Freezer 6 months 2 years
For best results, freeze meats & sh for 1-2 hours before vacuum packing to help prevent moisture
COFFEE BEANS Room temperature 4 weeks 16 months
COFFEE BEANS Freezer 6-9 months 2-3 years
FLOUR, RICE, SUGAR Room Temperature 6 months 1-2 years
For best results, powder or grainy substances should be kept in their original container or bag, then placed in a
BERRIES strawberries, raspberries, blackberries Refrigerator 1-3 days 1 week
BERRIES cranberries, huckleberries, blueberries Refrigerator 3-6 days 2 weeks
To prevent berries from being crushed by the vacuum sealer, it is best to freeze item before packing. Spread the berries out on a
cookie sheet to allow them to freeze individually. Berries frozen in a large block will be difcult to vacuum seal due to the
CHEESE Refrigerator 1-2 weeks 4-8 months
If vacuum packed cheese is used often, make sure the vacuum bag is long enough to allow for repeated sealing. For shredded
cheese, place a paper towel inside the vacuum bag, on top of the cheese to prevent the cheese from being
COOKIES, CRACKERS, BREADS with periodical opening Room Temperature 1-2 weeks 3-6 weeks
PASTA, GRAINS, DRIED BEANS Room Temperature 6 months 1-1/2 years
NUTS Room Temperature 6 months 2 years
Dried foods with sharp edges should be wrapped in a paper towel or other matter to prevent the sharp edges from puncturing the vacuum bag.
LETTUCE Refrigerator 3-6 days 2 weeks
VEGETABLES Freezer 8 months 2 1/2 years
To maximize the taste of vegetables, blanch them before vacuum packaging. Blanching cooks the vegetables very briey, sealing
in the avor, color and texture, leaving the vegetables cooked but still crisp. Vegetables can be blanched in boiling water in the microwave,
most vegetables only require 2-3 minutes (corn on the cob requires 6-11 minutes). Then immerse the vegetables in cold water to
and juices from interfering with the seal of the vacuum bag.
vacuum bag for sealing to prevent interfering with the seal of the vacuum bag.
many small air pockets that would form between the berries.
sucked into the Vacuum Sealer or interfering with the sealing of the bag.
Freeze soft airy foods for 1-2 hours prior vacuum packing, to retain shape & texture.
Wash & thoroughly dry leafy vegetables before vacuum packaging.
stop the cooking process. Dry the vegetables, then vacuum pack.
Table adapted from Dr. G.K.York, Dept. of Food Science & Tech, U of California, Davis.
ENGLISH INSTRUCTIONS
13
FOOD SAFETY
There are basic rules to follow when handling food.
They are COOK, SEPARATE, CLEAN, and CHILL.
COOK
It’s crucial to cook food to a safe internal temperature to destroy bacteria that is present.
The safety of hamburgers and other foods made with ground meat has been receiving a lot
of attention lately, and with good reason. When meat is ground, the bacteria present on the
surface is mixed throughout the ground mixture. If this ground meat is not cooked to at least
160oF to 165oF (71oC to 74oC), bacteria will not be destroyed and there’s a good chance you
will get sick.
Solid pieces of meat like steaks and chops don’t have dangerous bacteria like E. coli on the
inside, so they can be served more rare. Still, any beef cut should be cooked to an internal
temperature of at least 145oF (63oC) (medium rare). The safe temperature for poultry is 165oF
(75oC) and solid cuts of pork should be cooked to 145oF (63oC).
ENGLISH INSTRUCTIONS
SEPARATE
Foods that will be eaten uncooked and foods that will be cooked before eating MUST
ALWAYS be separated. Cross-contamination occurs when raw meats or eggs come in
contact with foods that will be eaten uncooked. This is a major source of food poisoning.
Always double-wrap raw meats and place them on the lowest shelf in the refrigerator so
there is no way juices can drip onto fresh produce. Then use the raw meats within 1-2 days
of purchase, or freeze for longer storage. Defrost frozen meats in the refrigerator, not on the
counter.
When grilling or cooking raw meats or sh, make sure to place the cooked meat on a clean
platter. Don’t use the same platter you used to carry the food out to the grill. Wash the utensils
used in grilling after the food is turned for the last time on the grill, as well as spatulas and
spoons used for stir-frying or turning meat as it cooks.
Make sure to wash your hands after handling raw meats or raw eggs. Washing hands with
soap and water, or using a pre-moistened antibacterial towelette is absolutely necessary after
you have touched raw meat or raw eggs. Not washing hands and surfaces while cooking is a
major cause of cross-contamination.
CLEAN
Wash your hands and work surfaces frequently when you are cooking. Washing with soap
and warm water for at least 15 seconds, then dry with a paper towel.
CHILL
Chilling food is very important. The danger zone where bacteria multiply is between 40oF and
140oF (4oC and 60oC). Your refrigerator should be set to 40oF (4oC) or below; your freezer should
be 0oF (-18oC) or below. Simple rule: serve hot foods hot, cold foods cold. Use chang dishes
or hot plates to keep food hot while serving. Use ice water baths to keep cold foods cold. Never
let any food sit at room temperature for more than 2 hours - 1 hour if the ambient temperature
is 90oF (32oC) or above. When packing for a picnic, make sure the foods are already chilled
when they go into the insulated hamper. The hamper won’t chill food - it just keeps food cold
when properly packed with ice. Hot cooked foods should be placed in shallow containers and
immediately refrigerated so they cool rapidly. Make sure to cover foods after they are cool.
NOTE: Special considerations must be made when using venison or other wild game, since it
can become heavily contaminated during eld dressing. Venison is often held at temperatures
that could potentially allow bacteria to grow, such as when it is being transported. Refer to
the USDA Meat and Poultry Department for further questions or information on meat and
food safety.
14
Loading...
+ 33 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
