Westcott 6251 Instructions

Quick Start Guide

Included Items

Solix LED Diffusion Cap Barndoors

AC Power Supply & Cable PowerStrap by Tether Tools Travel Case with Removable

Foam Insert & Shoulder Strap

Setup

The Solix was designed with simplicity and functionality in mind. Complete the following steps to
prepare your Solix for operation.

1. Loosen the light stand receptacle knob and place the Solix on your preferred stand or arm.
Tighten the knob to secure.

2. Loosen the large tilting knob and adjust the Solix’s angle into preferred position. Tighten the knob
to secure in place.

3. Insert the AC power cord into the cord receptacle on the power supply unit.

4. Insert the power supply cable into the power input receptacle on the back of the Solix. Twist the

cable’s locking nut onto the Solix to secure. If you find it difficult to secure the locking nut, the
cable’s barrel may not be fully inserted into the Solix. Gently press the nut towards the Solix to
secure the connection.

5. Ensure all connections are secure. Then, plug the AC power cord into your wall outlet.

6. Utilize the PowerStrap to secure the Solix’s power supply unit to your stand or arm.

Usage

Power the Solix on and off by pressing the rear dial. This dial also controls the Solix’s output. Twist
the dial clockwise to increase output and counter-clockwise to decrease output. Output level is
displayed on the Solix’s digital screen.
