West Bend JB15897 Owner's Manual

J

ELLY BELLY™ COTTON CANDY MAKER

Instruction Manual

Register this and other Focus Electrics products through our website:

www.registerfocus.com

Important Safeguards ............................................................................................... 2

Before Using for the First Time ................................................................................ 3

Using Your Cotton Candy Maker .............................................................................. 3

Helpful Hints ............................................................................................................. 4

Cleaning Your Cotton Candy Maker ......................................................................... 5

Warranty ................................................................................................................... 6

SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

™, ™,  2012 Jelly Belly Candy Company, Fairfield, CA 94533 USA

Manufactured and Distributed by Focus Electrics, LLC Authorized Licensee,

West Bend, WI 53095 USA

www.focuselectrics.com

IMPORTANT SAFEGUARDS

To prevent personal injury or property damage, read and follow all instructions
and warnings.

When using electrical appliances, basic safety precautions should always be
followed including:

• Read all instructions.

• Do not touch hot surfaces. Use handles or knobs.

• To protect against fire, electric shock, and injury to persons do not immerse

cord, plugs, or other electric parts in water or other liquids.

• Close supervision is necessary when this appliance is used by or near children.

• Always unplug from outlet when not in use and before cleaning. Allow to cool

before putting on or taking off parts and before cleaning.

• Do not operate any appliance with a damaged cord or plug, after the appliance
malfunctions, or has been damaged in any manner. For service information see
warranty page.

• The use of accessory attachments not recommended by Focus Electrics may
cause fire, electric shock, or injury.

• Do not use this appliance outdoors.

• Do not let cord hang over the edge of the table or counter, or touch hot surfaces.

• Do not place on or near a hot gas or electric burner, or in a heated oven.

• Always plug cord into wall outlet. To disconnect, turn any control to “OFF,” then

remove plug from wall outlet.

• Do not use appliance for other than intended use.

• Extreme caution must be used when moving an appliance while hot.

• Do not attempt to repair this appliance yourself.

• A short power-supply cord is provided to reduce risks resulting from becoming

entangled in or tripping over a longer cord.

• Longer extension cords are available, but care must be exercised in their use.
While use of an extension cord is not recommended, if you must use one,
ensure that the marked electrical rating of the extension cord is equal to or
greater than that of the appliance. If the plug is of the grounded type, the
extension cord must be a grounding-type 3-wire cord. To avoid pulling, tripping
or entanglement, position the extension cord so that it does not hang over the
edge of the counter, table or other area where it can be pulled on by children or
tripped over.

• This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not attempt to modify the plug
in any way.

2

• Do not use an outlet or extension cord if the plug fits loosely or if the outlet or
extension cord feels hot.

• Avoid contact with moving parts.

• Keep hands and utensils out of collection bowl while making cotton candy.

• Use only cotton candy cones for collecting cotton candy.

• For household use only.

SAVE THESE INSTRUCTIONS

Flossing Rim

Center Well

Inside: Spinner

“ON/OFF” Switch

Please check all packaging material carefully before discarding. Many
accessory parts are contained within the packaging material.

Wash bowl assembly (collection bowl, flossing rim, and connecting ring), measuring
scoop, and extractor head in warm, soapy water. Rinse thoroughly and dry. Ensure
that the extractor head is completely dry before adding sugar. Do not place the
heating base in water or any other liquid.

1. Place the collection bowl on the base and gently push down to “snap” in place.

2. Place appliance on dry, level, heat-resistant surface, away from any edge. Press

Shaft

B

EFORE USING FOR THE FIRST TIME

U

SING YOUR COTTON CANDY MAKER

Assemble the collection bowl and flossing rim by aligning the holes in the
flossing rim to the pegs on the collection bowl. Place the connecting ring over
the flossing rim and press down until it clicks in place.

down on the base of the cotton candy maker to secure the suction feet. Place
extractor head onto the spinner shaft. Make sure that the pegs on the spinner
shaft are fully engaged in the slots of the extractor head.

Suction Feet

Connecting Ring

Extractor Head

Measuring Scoop

Collection Bowl

Heating Base

3

3. With the “ON/OFF” switch set in the "OFF" ( O ) position, plug the cord into a
120 volt, AC electric outlet only.

4. Set the “ON/OFF” switch to “ON” ( l ) and let run for a minimum of 5 minutes
to preheat. The extractor head will be spinning.

5. When preheated, set the “ON/OFF” switch to “OFF” ( O ) and wait until the
extractor head comes to a complete stop. Add one level tablespoon of sugar to
the center well of the extractor head. To level sugar in the extractor head, gently
tap the flossing rim a couple times. Do not use a heaping tablespoon, over fill
chamber, or get sugar on the top of the extractor head. Note: Be sure that you
have the bowl assembly assembled to the heating base before heating or
attempting to extract floss.

6. Set the “ON/OFF” switch to “ON” ( l ). Some sugar may be ejected from the
extractor as it spins.

7. When you begin to see a web of cotton
candy forming around the flossing rim,
begin collecting it with a cotton candy
cone. This is best achieved by:

A. Hold the cone vertically and rotate

the cone while circling the bowl.

B. Once some cotton candy is collected,

hold the cone horizontally then roll
the cone while going back and forth
over the rim. Be careful not to touch
the spinning extractor head with cone
or collected candy.

8. When all sugar has been dispensed, set
the “ON/OFF” switch to “OFF” ( O ) and
let the extractor head come to a complete
stop. If more candy is desired, repeat steps 4 - 7. Candy will be extracted more
quickly during this cycle. If no more candy is desired, unplug and let appliance
cool completely before cleaning.

• A small amount of smoke and/or odor may occur upon heating due to
the release of manufacturing oils – this is normal.

• Some minor expansion/contraction sounds may occur during heating
and cooling – this is normal.

H

ELPFUL HINTS

• Regular granulated sugar can be used as well as flossing sugars made
specifically for cotton candy. Flossing sugar will produce the best results.

• Artificial sweeteners or sugar-free candies cannot be used for making cotton
candy. Artificial sweeteners burn in the extractor head and do not floss.

• Hard candies can be used to create cotton candy. Crush candies finely and use
in place of sugar in the extractor head. Do not use more than 1 tbsp. crushed
candy to make cotton candy.

• Flavor extracts (like those used to make candies) can be used to produce
flavored floss. Add no more than  tsp. flavor extract to the sugar in the
extractor head chamber then, follow steps to make cotton candy.

• Pre-sweetened drink mixes may be mixed with sugar to create flavored floss.
Avoid drink mixes sweetened with artificial sweeteners. These will burn and clog
the extractor head. Use ½ tsp. drink mix with 2 ½ tsp. sugar to make cotton
candy.

4

• Never use extra fine granulated or “free flowing” sugars in your cotton candy
maker. These sugars will clog the extractor head.

• When collecting cotton candy, rest the cone against the flossing rim while you
turn it. This will help collect candy without touching the extractor head.

• The Cotton Candy maker must be preheated for a minimum of five minutes
before use. If it is not preheated, the sugar will not melt and your extractor head
will clog.

• Clean the cotton candy maker after 2 or 3 cycles to keep the extractor head
from clogging and to ensure optimal results. If extractor head is not cleaned
every couple cycles, it will stop producing floss and results will be poor.

• Between cycles, use a cone or wooden spoon to push any unspun sugar down
into the collection bowl. This will prevent the cotton candy getting stuck along
the rim before it can be collected.

C

LEANING YOUR COTTON CANDY MAKER

1. When done making cotton candy, or to clean between batches, unplug the

cotton candy maker and let it cool for 15 minutes.

2. Remove extractor head and soak in hot, soapy water. Rinse and spin by

hand to remove as much water as possible, towel dry exterior. If necessary,
use a dish cloth to remove any sugar stuck on the extractor head. Do not
use any abrasive scrubbers, as damage to the finish may occur.

3. With dry hands, plug appliance into wall outlet, place extractor head back

on heating base, set the “ON/OFF” switch to “ON” ( l ), and let spin for 15­20 seconds. Set the “ON/OFF” switch to “OFF” ( O ), unplug, and remove
extractor head again, towel dry exterior and set aside. This removes most
excess water from inside the extractor head.

4. Remove the bowl assembly from the heating base. Wash in warm, soapy

water, rinse and dry thoroughly. Reassemble appliance. Bowl assembly
parts can be washed in a dishwasher, top rack only. Do not place the
extractor head in the dishwasher. Do not place the heating base in water or
any other liquid.

This appliance has no user serviceable parts.

5

P

RODUCT WARRANTY

Appliance 1 Year Limited Warranty

Focus Electrics, LLC (“Focus Electrics”) warrants this appliance from failures in the material
and workmanship for one (1) year from the date of original purchase with proof of purchase,
provided the appliance is operated and maintained in conformity with the provided Instruction
Manual. Any failed part of the appliance will be repaired or replaced without charge at Focus
Electrics’ discretion. This warranty applies to indoor household use only.

This warranty does not cover any damage, including discoloration, to any non-stick surface of
the appliance. This warranty is null and void, as determined solely by Focus Electrics if the
appliance is damaged through accident, misuse, abuse, negligence, scratching, or if the
appliance is altered in any way.

THIS WARRANTY IS IN LIEU OF ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, PERFORMANCE, OR
OTHERWISE, WHICH ARE HEREBY EXCLUDED. IN NO EVENT SHALL FOCUS
ELECTRICS BE LIABLE FOR ANY DAMAGES, WHETHER DIRECT, INDIRECT,
INCIDENTAL, FORSEEABLE, CONSEQUENTIAL, OR SPECIAL, ARISING OUT OF OR IN
CONNECTION WITH THIS APPLIANCE.

If you think the appliance has failed or requires service within its warranty period, please
contact the Focus Electrics Customer Service Department at [phone], or e-mail us at
[e-mail]. A receipt proving the original purchase date will be required for all
warranty claims, hand written receipts are not accepted. You may also be required to return
the appliance for inspection and evaluation. Return shipping costs are not refundable. Focus
Electrics is not responsible for returns lost in transit.

Replacement parts, if available, may be ordered directly from Focus Electrics, LLC several
ways. Order online at www.focuselectrics.com, e-mail [e-mail], over the
phone by calling [phone], or by writing to:

Focus Electrics, LLC
Attn: Customer Service
P. O. Box 2780
West Bend, WI 53095

To order with a check or money order, please first contact Customer Service for an order total.
Mail your payment along with a letter stating the model or catalog number of your appliance,
which can be found on the bottom or back of the unit, a description of the part or parts you are
ordering, and the quantity you would like. Your check should be made payable to Focus
Electrics, LLC.

Your state/province’s sales tax and a shipping fee will be added to your total charge. Please
allow two weeks for processing and delivery.

This manual contains important and helpful information regarding the safe use and care of your
new Focus Electrics product. For future reference, attach dated sales receipt for warranty proof
of purchase and record the following information:

Date purchased or received as gift: _______________________________________________
Where purchased and price, if known: _____________________________________________
Item number and Date Code (shown bottom/back of product):___________________________

Valid only in USA and Canada

R

EPLACEMENT PARTS

L5863 03/12 Focus Electrics, LLC. Printed in China

6
