Weed Eater 545117525, EBV 215 User Manual
R Tra de ma rk
Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l’outil au détaillant.
1-800-554-6723
www.weedeater.com
Instruction Manual
Manual de Instrucciones
Manuel d’Instructions
EBV 215
FOR HOUSEHOLD USE ONLY
PARAUSOCASEROSOLAMENTE
POUR UTILISATION À DES FINS
DOMESTIQUES SEULEMENT
ENGLISH ESPAÑOL
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Veuillez lire le manuel d’instructions et bien respecter tous les
avertissements et toutes les instructions de sécurité. Tout défaut
de le faire pourrait entraîner des blessures graves.
WEED EATER
1030 Stevens Creek Road
Augusta, GA 30907
Mississauga, Ontario L5V 3E4
545117525 8/8/06
WEED EATER
5855 Terry Fox Way
FRANÇAIS
SAFETY RULES
Y
IMPORTANT WARNINGSAND
SAFET
INSTRUCTIONS
WARNING:
When using electric gardening appli ances, basic saf ety pr ecauti ons should al ways be
followed to reduce the risk of fire, electric shock, and serious injury. The warnings and
safety instructions in this manual must be followed to reduce the risk of fire, electric
shock, or injury, and to provide reasonable safety and efficiency in using this unit. The
operator is responsible for following the warnings and instructions in this manual and on
the unit. Read the entire instruction manual before assembling and using the unit! Restrict the use of this unit to persons who read, understand, and follow the warnings and
instructions in this manual and on the unit. Never allow children to use this unit. Do not
allow the unit to be used as a toy. Close attention is necessary when used near children.
Always disconnect unit from power source before servicing, cleaning, performing maintenance, or storing. Nonconforming replacement components or the removal of safety
devices may cause damage to the unit and possible injury to the operator or bystanders.
Use only accessories and replacement parts as recommended. Use only for jobs explained in this manual.
OPERATOR SAFETY
S Always wear safety glasses or similar eye
protection when operating, servicing, or
performing maintenance on your unit.
Wearing eye protection can help to prevent rocks or debris from being blown or
ricocheting into eyes and face which can
result in blindness or serious injury.
S Always wear a respirator or face mask
when working with the unit in dusty environments.
S Dress safely in long pants. Do not go
barefoot or wear short pants or sandals.
S Do not operate the unit when you are
tired, ill, upset, or if you are under the influence of alcohol, drugs, or medication.
S Secure hair so it is above shoulder length.
Keep loose hair, loose clothing, fingers,
and all other parts of the body away from
openings and moving parts. Hair, jewelry,
loose clothing, or clothing with loosely
hanging straps, ties, tassels, etc., can be
caught in moving parts.
ELECTRICAL SAFETY
WARNING:
Avoid a dangerous environment. T o reduce the risk of electrical shock, do not
use in rain, in damp or wet locations, or
around swimming pools, hot tubs, etc. Do
not expose to snow,rain, or water to avoid
the possibility of electrical shock. Do not
use on wet surfaces. Do not handle extension cord pl ug or unit with wet hands.
Avoid dangerous situations. Do not use in
the presence of flammable liquids or
gases to avoid creati ng a fire or explosion
and/or causing damage to unit . Do not
abuse cord.Never carry the unit by the extension cord or yank extension cord to disconnect unit. To unplug, grasp the plug,
not the cord. Do not use cord as a handle,
close a door on cord, or pull cord around
sharp edges or corners. Turn off all controls before unplugging. Do not expose
cords to heat,oil, or water . Do not use with
damaged cord or plug. If unit is not working as it should, has been dropped, damaged, left outdoors, or dropped into water,
return it to your authorized service dealer
for repair. Unplug the unit from the power
source when not in use, before servicing,
cleaning, performing maintenance, or
storing. Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair and
anything that may reduce air flow.
S Use only a voltage supply as shown on
the nameplate of the unit.
S Avoid dangerous environments. Do not
use in unventilated areas or where dust or
explosive vapors can build up.
S T o reduce the risk of electrical shock, this
unit has a polarized plug (one blade is
wider than the other) and will require the
use of a polarized extension cord. The
appliance plug will fit into a polarized extension cord only one way. If the plug
does not fit fully into the extension cord,
reverse the plug. If the plug still does not
fit, obtain a correct polarized extension
cord. A polarized extension cord will require the use of a polarized wall outlet.
This plug will fit into the polarized wall outlet only one way. If plug does not fit fully
into the wall outlet, reverse the plug. If it
2
still does not fit, contact a qualified electrician to install the proper wall outlet. Do not
change the equipment plug, extension
cord receptacle, or extension cord plug in
any way.
S T o reduce the risk of electrical shock, use
extension cords specifically marked as
suitable for outdoor appliances. The electrical rating of the cord must not be less
than the rating of the unit. The cord must
be marked with the suffix “W-A” (in Canada, “W”). Make sure your extension cord
is in good condition. Inspect extension
cord before use and replace if damaged.
An undersized extension cord will cause
a drop in line voltage resulting in loss of
power and overheating. If in doubt, use
the next heavier gauge. The smaller the
gauge number, the heavier the cord.
(NOTE: The correct size to be used depending on the cord length is shown in
this manual. See
CORD
in the ASSEMBLY section).
S Do not use multiple cords.
S Keep the extension cord clear of operator
and obstacles at all times.
S Tie cord to cord retainer and connect to
recessed plug as shown in this manual to
prevent damage to unit and/or extension
cordandtoreducethepossibilityofthe
extension cord disconnecting from the
unit during operation.
S Do not attempt to repair unit. Inspect the
insulation and connectors on the unit
and extension cord before each use. If
there is any damage, do not use until
damage is repaired by your authorized
service dealer.
S Do not use the unit if the switch does not
turn the unit on and off properly. Have the
unit repaired by your authorized service
dealer.
S Avoid accidental starting. Be sure the
switch is in the
your hand and fingers away from the
switch while connecting the unit to the
power source or when carrying a unit connected to the power source.
S Avoid any body contact with any
grounded conductor, such as metal
fences, or pipes, to avoid the possibility of
electric shock.
S Ground Fault Circuit Interrupter (GFCI)
protection should be provided on the circuit or outlet to be used for this unit. Receptacles are available having built-in
GFCI protection and may be used for this
measure of safety.
S Stop the motor immediately if you are ap-
proached.
SELECT AN EXTENSION
OFF position and keep
DOUBLE INSULATION
CONSTRUCTION
This unit is double insulated to help protect against electric shock. Double insulation construction consists of two separate
“layers” of electrical insulation instead of
grounding. Tools and appliances built with
a double insulation system are not intended to be grounded. No grounding
means is provided on this unit, nor should
a means of grounding be added to this
unit. As a result, the extension cord used
with your unit can be plugged into any
standard 120 volt electrical outlet. Safety
precautions must be observed when operating any electrical tool. The double insulation system only provides added protection against injury r esulti ng fr om an
internal electrical insulation failure.
WARNING:
All electrical repairs to this unit, including
housing, switch, motor, etc., must be diagnosed and repaired by qualif i ed service
personnel. Replacement parts for a
double insulated appliance must be identical to the parts they replace. A double insulated appliance is marked with the
words “double insulation” or “double insulated”. The symbol
square) may also be marked on the appliance. Failure to have the unit repaired
by an authorized service dealer can
cause the double insulation construction
to become ineffective and result in serious
injury.
UNIT/MAINTENANCE SAFETY
S Do not set the unit on any surface except
a clean, hard area while the unit is running. Debris such as gravel, sand, dust,
grass, etc., could be picked up by the air
intake and thrown out through the discharge opening, damaging the unit, property , or causing serious injury to bystanders or operator.
S Do not overreach or use from unstable
surfaces such as ladders, trees, steep
slopes, rooftops, etc. Use extra care
when cleaning on stairways. Keep firm
footing and balance at all times. Keep
hands out of tubes.
S Inspect the entire unit before each use for
worn, loose, missing, or damaged parts.
Do not use until the unit is in proper working order.
S This unit is double insulated. See the
DOUBLE INSULA T I ON CONSTR UCT ION
section. Have all internal service performed by qualified service repair personnel to avoid creating a hazard or voiding
your warranty.
(square within a
3
