Welcome
Thank you for choosing Waves. In order to get the most out of your Waves processor, please take the time to read through this
manual.
In conjunction, we also suggest you become familiar with www.wavesupport.net There you will nd an extensive answer base, the
latest tech specs, detailed installation guides, new software updates, and current information on licensing and registration.
By signing up at www.wavesupport.net you will receive personalized information on your registered products, reminders when
updates are available, and more.
About Waves eMo Generator
Waves eMo Generator lets you generate common signals quickly and easily, with several simple and useful options. Use Pink Noise
to test and tune your live sound system. Use White Noise for SPL measurements. Use Sine Wave to sweep through entire frequency
ranges or even tune your instruments to middle A. In addition, you can quickly test the L-R wiring in your studio or live loudspeakers.
2
Components
eMo Generator includes two components:
• eMo Generator Mono
• eMo Generator Stereo
Features
In both components:
• Signal types: Pink, White, Sine
• Sine frequency is fully sweepable, with most-used frequency shortcuts
• Gain is fully sweepable, with gain shortcuts
• Touch-compatible
3
Stereo component only:
• Routing: Play the generated signal through left, right or both outputs
• Phase: Flips phase between left and right outputs
INTERFACE
7
On/O
1
Signal Type
2
Frequency*
3
Gain
4
1
Routing**
5
Phase**
6
WaveSystem Toolbar
7
2
3
5
4
6
* Frequency available when
SINE type is selected.
** Routing and Phase available in
Stereo component only.
4
Controls
eMo Generator ON button: Turns eMo Generator on and o.
Options: On, O
Default: O
SIGNAL TYPE: Selects the type of signal generated.
PINK: Generates pink noise at 20 Hz to 21 kHz; equal energy in all octaves
WHITE: Generates white noise at 20 Hz to 21 kHz; equal energy per hertz
SINE: Generates pure sine wave tone
Options: Sine, White, Pink
Default: Pink
5
FREQUENCY: Sweep through frequencies manually using the Frequency knob, type in the desired frequency, or use the shortcut
buttons to quickly jump to a predetermined frequency.
Frequency range: 20 to 21000 Hz
Default: 1000 Hz
Shortcut buttons: 100 Hz, 1 kHz, 10 kHz
Default: 1 kHz
GAIN: Adjust the output gain manually using the Gain knob, type in the desired value, or use the shortcut buttons to quickly jump
to a predetermined value.
Gain range: -120 to 0 dB
Default: -20 dB
Shortcut buttons: -6 dB, -12 dB, -20 dB
Default: -20 dB
ROUTING: Quickly routes the generated signal to the left output, the right output, or both. Available only in the Stereo component.
6
Options: L, L+R, R
Default: L+R
PHASE: Flips phase by 180 degrees between the left and right outputs. Available only in the Stereo component.
