Waring WMB400X Part List
Unit Information
120 Volts – 60 Hz – 1200 Watts - 10 Amps
Produce up to 100 1" thick waffles per hour
Beep signals when unit is ready and when
waffle is cooked
®
4
2
5
1
6
M
INI BELGIAN
W
AFFLEMAKER
POWER
ON
READY
OFF
037508
WMB400X Unit Assembly
(without Drip Tray)
2
3
1
32
31
Mini Belgian Waffle Maker with
Replaceable Plates
WMB400X
Fill Line
®
35
36
34
+
032364
Cup
032350
Drip Pan
22
21
20
19
23
4
24
6
25
5
M
INI
B
ELGIAN
W
AFFLEMAKER
7
ON
READY
POWER
OFF
11
8
10
9
12
13
14
15
26
NEMA 5-15
16
17
18
20
19
30
27
28
29
Graphic By: Sandra A. Montysko Revised January 20, 2020 Approved 1/20/2020 Page 1 of 3
Catalog/Model
WMB400X
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790
Tele. 1-800-269-6640
Illustration# Part# Description
1 037507 Mini Belgian Waffle Plate (1 top - 1 bottom)
2 037357 Screw (1 top plate - 1 bottom plate)
3 037356 Screw (5 top plate - 5 bottom plate)
4 037493 Screw (10 top inner plate - 10 bottom inner plate)
5 032352 Knob
6 016236 Hex Nut
7 032356 Washer
8 036241 Connector Pole
9 035316 Darkness Control Board
10 032359 Screw (3 required)
11 032368 Toggle Switch
12 012409 Small Crimp Connector
019123 Large Crimp Connector (2 required)
(short tape)
(4 required)
www.waringcommercialproducts.com
Fax 860-496-9017
13 013731 Wire Tie (7 required)
14 037490 PCB Board
15 032359 Screw
(4 required)
16 030638 Power Board Shield
17 037492 15.5" Red Lead Assembly
(2 required)
18 037491 8" Green Lead Assembly
19 035298 Ground Screw
(2 required)
20 032751 Ground Spring Washer (2 required)
21 032371 Cord Plate
22 033494 Cord Set
23 035476 Strain Relief
24 037494 Green Light with Leads
25 037495 Red Light with Leads
26 032351 Bottom Plate
27 032353 Foot
28 032354 Foot Washer (4 required)
29 032355 Screw (4 required)
30 032750 Bottom Plate Screw (4 required)
Page 2 of 3 Revised January 20, 2020
(4 required)
