Vulcan VCD22 User Manual

OPERATION MANUAL
VCD & VCW SERIES CHIP WARMERS
MODELS: VCD22* ML-138037 VCD44 ML-138069 VCW26 VCW46
*Formerly VCD5
VULCAN 3600 NORTH POINT BLVD. DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC BALTIMORE, MD 21222
www.vulcanequipment.com
Vulcan ©2014 All Rights Reserved
F-38053 (08-14)
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
IMPORTANT FOR YOUR SAFETY
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL ELECTRICAL EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START­UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE
VICINITYOF THIS OR ANY OTHER APPLIANCE.
Improper installation, adjustment,
alteration, service, or maintenance can
cause property damage, injury, or death.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing equipment.
IN THE EVENT OF A POWER FAILURE,
DO NOT ATTEMPT TO OPERATE THIS DEVICE.
1
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
TABLE OF CONTENTS
IMPORTANT FOR YOUR SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION ALL MODELS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
UNPACKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LEGS INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION SPECIFIC TO MODELS VCD22 & VCD44 . . . . . . . . . . . . . . . . . . . . 4
ELECTRICAL REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ELECTRICAL CODES & STANDARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ELECTRICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
VCD22 & VCD44
OPERATION INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CLEANING INSTRUCTIONS . . . . . . ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
VCW26 & VCW46
OPERATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CLEANING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 8
STAINLESS STEEL CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
LOCKOUT / TAGOUT PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SERVICE & PARTS INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
GENERAL
INTRODUCTION
Vulcan Chip Warmers are produced with quality workmanship and material. Proper installation, usage, and maintenance of your warmer will result in many years of satisfactory performance.
It is suggested that you thoroughly read this entire manual and carefully follow all of the instructions provided.
INSTALLATION (ALL MODELS)
Before installing, verify that the electrical service agrees with the specifications on the rating plate located on the lower back corner of the warmer. If the supply and equipment requirements do not agree, do not proceed with unpacking and installation. Contact your Vulcan Customer Service Department immediately. (Page 11)
UNPACKING: The Warmer was inspected before leaving the factory. The transportation company assumes full responsibility for safe delivery upon acceptance of the shipment. Immediately after unpacking, check for possible shipping damage to the warmer.
If the warmer is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery.
Carefully unpack warmer and place in a work accessible area.
As with any piece of food service equipment, this Chip Warmer requires a minimum of care and maintenance. Recommended procedures are contained in this manual and should become a regular part of the operation of the unit.
1. Remove banding holding the carton to the pallet.
2. Carefully remove warmer from carton and place on floor or table.
3. Remove any and all packaging materials inside unit.
4. Peel off all vinyl protection film.
5. Thoroughly clean the warmer
as described in the cleaning instructions in this manual.
LEGS INSTALLATION:
To install legs, carefully tip Chip Warmer onto its side. Screw legs into pre-drilled holes. Return warmer to the upright position.
LOCATION:
For efficient warmer operation, choose a location that will provide easy loading and unloading without interfering with the final assembly of food orders.
The installation location must allow adequate clearances for servicing and proper operation.
3
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
INSTALLATION SPECIFIC TO MODELS VCD22 & VCD44
ACCESS PANEL POSITIONING:
1. Ensure that top Baffle notches are over carriage bolts.
2. Insert Access Panel onto the back of the Chip Warmer. (Fig. 1)
SCOOP HOLDER INSTALLATION: The Chip Scoop Holder will secure up to
a 6“ wide scoop.
1. On either the left or right side of
the Chip Warmer, loosen four side screws one revolution.
2. Position the Chip Scoop Holder.
(Fig. 3)
(Fig. 1)
3. On both sides of Access Panel, place clips into slots, then lock. (Fig. 2)
(Fig. 2)
(Fig. 3)
3. Tighten four side screws.
.
4
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
ELECTRICAL REQUIREMENTS
ELECTRICAL CODES & STANDARDS:
The warmer must be installed in accordance with:
In the United States of America:
1. State and Local Codes.
2. National Electrical Code, ANSI/ NFPA-70 (latest edition.) Copies may be obtained from: The National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
In Canada:
1. Local Codes.
2. Canadian Electrical Code, CSA C22.1 (latest edition.) Copies may be obtained from: The Canadian Standard Association, 178 Rexcale Blvd., Etobicoke, Ontario, Canada M9W 1R3.
ELECTRICAL CONNECTIONS:
The warmer is factory wired for 110/120 volt single phase operation. All 110/120 volt warmers are equipped with a 8 foot cord and NEMA 5-15 plug as standard equipment. Refer to wiring diagram in the back of this manual.
The cord and plug supplied is a suitable durable cord with a molded three-prong plug, and is provided with a proper strain relief.
All warmers are equipped with a three-prong plug. It is imperative that this plug must be connected into a properly grounded three-prong receptacle. If the receptacle is not the proper grounding type, contact an electrician. Do not remove the grounding prong from this plug.
Verify that the power source matches the Serial Data Plate located on the lower back corner of the warmer and the plug configuration before the connection is made. (Fig. 4)
SERIAL DATA PLATE
(Fig. 4.)
A separate disconnect switch or circuit breaker is recommended to be placed at a convenient location between the Chip Warmer and the electric power source.
To avoid damage to the power supply cord, cord retainer bushing, or electrical outlets, always check to be certain that the power cord is unplugged from the power source before moving the unit.
5
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
OPERATION
OPERATION INSTRUCTIONS (Models VCD22 & VCD44)
The Warmer and its
parts are hot. Be very careful when operating, cleaning, or servicing the warmer.
1. Switch Power Switch to ON position. Verify that switch illuminates. (Fig.5)
(Fig. 5)
2. The internal thermostat is factory preset to 180 F. The
blower fan circulates heated air through the perforated removable chip tray located at the bottom of the interior of the cabinet (under the chips.)
3. Open Top Door.
4. Pour chips into Baffle.
Do not overfill. The Top Door must be able to fully close.
VCD22 holds approx. 22 gallons and VCD44 holds approx. 44 gallons of chips.
5. Close Top Door.
6. After approx. 30 to 40 minutes, open Front Door to access warmed chips.
7. Use the Chip Scoop to remove desired amount of chips.
8. Close Front Door.
CLEANING INSTRUCTIONS (Models VCD22 & VCD44)
The Warmer and its parts are hot. Be very careful when operating,
cleaning, or servicing the warmer.
Always unplug electrical power supply before cleaning.
The inside of the Chip Warmer must be cleaned each day.
At the end of the day, switch Power Switch to OFF position.
ALLOW UNIT TO COOL DOWN
1. Remove Access Panel by
unlocking clips.
2. Place Access Panel away from
Chip Warmer.
3. Remove Top Door.
4. Remove all internal Baffles
through back opening.
5. Using a soft, clean cloth, clean
Top Door and Baffles with a solution of mild detergent and
warm water. Rinse with a soft cloth and warm water. Wipe dry with a soft dry cloth.
Never spray the unit with a hose.
6. Using a soft, clean cloth, clean the inside of the unit with a solution of mild detergent and warm water. Rinse with a soft cloth and warm water. Wipe dry with a soft dry cloth.
7. Replace Top Door and all internal Baffles.
8. Reattach Access Panel.
6
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
OPERATION INSTRUCTIONS (Models VCW26 & VCW46)
The Chip Warmer should be thoroughly cleaned before initial use.
The Warmer and its
parts are hot. Be very careful when operating, cleaning, or servicing the warmer.
1. Verify that the Chip Warmer is
connected to the correct power source.
2. The Lighted Power Switch is
located on right back side of the Chip Warmer. Switch power switch to ON position. Verify that the switch illuminates. (Fig. 6)
POWER SWITCH
(Fig.6)
The power switch is what turns the unit on and off.
3. The Thermostat knob is located in the back of the unit near the power switch. (Fig.7)
THERMOSTAT KNOB
(Fig.7)
Adjust the knob to the desired temperature setting. Once a desired temperature setting is determined, the knob can be left in this position until a temperature adjustment is needed.
4. Check the interior rear of warmer to ensure that it is heating. The blower fan circulates heated air through the perforated removable baffle located at the bottom of the interior of the cabinet (under the chips.) (Fig. 10)
5. Open Top Doors.
6. Pour chips into unit.
Do not overfill. The Top Doors must be able to fully close.
VCW26 holds approx. 26 gallons and VCW46 holds approx. 46 gallons of chips.
7. Close Top Doors.
8. After approx. 30 to 40 minutes,
open Front Door to access warmed chips.
9. Close Front Door after access.
SHUTDOWN
The Warmer and its parts are hot. Be very careful when operating, cleaning, or servicing the warmer.
At the end of the day:
1. Switch Power Switch to OFF position.
2. Clean unit following instructions in this manual.
7
VCW & VCD SERIES CHIP WARMER F-38053 (08-14)
CLEANING INSTRUCTIONS (Models VCW26 & VCW46)
The Warmer and its parts are hot. Be very careful when operating, cleaning, or servicing the warmer.
Always unplug electrical power supply before cleaning.
INTERIOR: The inside of the Chip Warmer must be cleaned each day.
1. Unplug electrical power supply.
2. Allow warmer to cool before cleaning.
3. Remove front panel by opening
clips on each side of panel. (Fig.8)
CLIP (Fig. 8)
Slide Front Panel downward past the upper lip and lift away and remove from Chip Warmer. (Fig. 9)
UPPER LIP
FRONT PANEL (Fig. 9)
4. Remove interior baffle at the bottom of the unit. A handle is located toward the back of the baffle. (Fig. 10)
INTERIOR BAFFLE (Fig. 10)
5. Using a soft, clean cloth, clean inside of warmer with a solution of mild detergent and warm water. Rinse with warm water, and wipe dry. Never spray the unit with a hose.
6. Replace baffle and front panel using a reverse of the removal instructions.
EXTERIOR:
Refer to “STAINLESS STEEL CARE.” HEAVY-DUTY CLEANING:
For heavy-duty cleaning, use warm water, a degreaser, and soft cloth. Never rub in a circular motion -- rub gently in the direction of the steel grain. Always rinse thoroughly. Never spray the unit with a hose.
8
