VTech VT2030 User Manual

User’s manual

www.vtech.com/hk/tel

Table of contents

1. IMPORTANT SAFETY INSTRUCTIONS .......................1

2. SETTING UP THE TELEPHONE ...................................2

2.1 Package contents ..............................................................2

2.2 Location .............................................................................2

2.3 Setting up ..........................................................................3

2.3.1 Connecting the charger .....................................3

2.4 Installing and charging the battery pack ............................4

2.5 Setting date and time.........................................................5

2.5.1 Change the Date Format ...................................5

2.5.2 Change the Time Format...................................5

2.5.3 Set the Date and Time.......................................5

3. GETTING TO KNOW YOUR PHONE ............................7

3.1 Overview of the Handset ...................................................7

3.2 Handset LCD Display Icons and Symbols.........................8

3.3 Charger............................................................................10

3.4 Navigating the menus ......................................................10

3.5 Menu map........................................................................ 11

4. USING ADDITIONAL HANDSETS ..............................12

4.1 Registration .....................................................................12

4.2 Make an Internal Call.......................................................12

4.2.1 Intercom Another Handset...............................13

4.2.2 Intercom the Base ...........................................13

4.2.3 Call All Handsets and Base .............................13

4.2.4 Transfer an External Call from Handset to

5. TROUBLESHOOTING .................................................16

6. TECHNICAL SPECIFICATIONS.................................. 17

1. IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury,
including the following:

1. Read and understand all the instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water (for example, near a bath tub, kitchen sink, swimming pool).

5. Do not expose the telephone to direct sunlight or extreme cold environment. Do not put the telephone close to heating sources such as
radiators, cookers, etc.

6. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.

7. Unplug this product from the wall outlet and refer servicing to VTech under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If the product does not operate normally by following the operating instructions.

• If the product has been dropped and the cabinet has been damaged.

• If the product exhibits a distinct change in performance.

8. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

9. Do not use the telephone to report a gas leak in the vicinity of the leak.

10. Use only the supplied NiMH (Nickel Metal Hydride) batteries! The operation periods for the handsets are only applicable with the default
battery capacities.

11. The use of other battery types or non-rechargeable batteries/primary cells can be dangerous. These may cause interference and/or unit
damages. The manufacturer will not be held liable for damage arising from such non-compliance.

12. Do not use third party charging bays. The batteries may be damaged.

13. Please note the correct polarity while inserting the batteries.

14. Do not immerse batteries in water, do not place in fire.

If you have questions about this product, or having difficulty with setup or operation, call our Customer Service Centre.
Customer Service Hotline: [phone]

Setting up the telephone

2. SETTING UP THE TELEPHONE

2.1 Package contents

The package contains the following items:

･ 1 Handset ･ 1 Rechargeable battery pack
･ 1 Charger ･ 1 Chinese user’s manual
･ 1 AC power adapter ･ 1 English user’s manual

2.2 Location

For maximum coverage and reduce the interference, here are some guidelines you should consider when you place the base unit,

- place it at a convenient, high, and central location with no obstructions between the handset and base unit in an indoor environment.

- place it away from electronic appliances such as televisions, microwave ovens, radios, personal computers, wireless devices or other
cordless phones.

- avoid facing radio frequency transmitters, such as external antennas of mobile phone cell stations.

- avoid plugging it into the same circuit as other major household electrical appliances because of the potential interference. Try moving the
appliance or the base unit to another power outlet.

If the reception for a base unit location is not satisfactory, move it to another location for better reception.
Depending on the surrounding conditions as well as spatial and structural factors, the range may be reduced. The range indoors is normally
less than outdoors.

2.3 Setting up

2.3.1 Connecting the charger

1. Plug the power supply into the charger.

2. Plug the power supply cord into the wall outlet not controlled by a wall switch.

Note:
Always use the cables provided in the box.

Setting up the telephone

2.4 Installing and charging the battery pack

1. Slide off the battery compartment cover to remove it.

2. Place the supplied battery pack as indicated. Respect polarity.

3. Slide the battery compartment cover back.

4. Put the handset on the base and charge for 16 hours first time. A beep indicates that the handset is properly placed on the base or charger.

Notes:

1. Use only the supplied NiMH rechargeable battery pack.

2. If the handset will not be used for a long time, disconnect and remove the battery pack to prevent possible leakage.

Battery Door

Battery
