VTech v 2656 User Manual

Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool).
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect it from overheating, these openings must not be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it.
9. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing cabinet parts other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the appliance is subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM1
1
Important Safety Instructions
12. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating instructions, because improper adjustment of other controls may result in damage and will often require extensive work by an authorized technician to restore the product to normal operation.
E. If the product has been dropped and the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lighting.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
VTECH COMMUNICATIONS INC.
CUSTOMER SERVICE at 1-800-595-9511. In Canada, call VTech Telecommunications, Ltd. at 1-800-267-7377.
SAVE THESE INSTRUCTIONS
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM2
2
Introduction
The v 2656 is an advanced cordless telephone that operates in the 2.4GHz frequency range. Your v 2656 is capable of supporting up to a maximum of 4 Handsets. Using additional Handsets, 2 people can be conferenced on a call, while two other extensions can be talking internally, using the Intercom feature.
This manual is designed to familiarize you with the v 2656 cordless telephone. We strongly recommend you read the manual before using your phone.
To order additional Handsets (model v 2600), battery packs, or headsets, call VTech Communications Inc at 1-800-595-9511.
IMPORTANT
Please record the Base ID#(BS ID) printed on the underside of the v 2656 Base in the space below. Please be certain to include all 15 digits/characters.
Base ID#
STOP!!
If you have questions about this product, or if you’re having difficulty with setup or operation, do not return your phone to the store. Call our Customer Support Center at
1-800-595-9511
In Canada, call
1-800-267-7377
3
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM3
Parts Check List
1. Base Unit
2. Handset
3. AC Power Adapter
5. Battery Pack
6. Wall Mounting Bracket
7. User's Manual
4. Telephone Cord
To purchase replacement battery packs, call Vtech Communications, Inc. at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377.
G
A
E
P
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM4
4
The Handset Layout
1. Antenna
2. Earpiece
3. Scroll Keys
4. Headset Jack (2.5mm)
5. On (Flash)
6. Dialing Keys (0-9, *, #)
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM5
7. Handsfree Speakerphone
8. LCD Display
9. Select /Menu
10. Off (Clear)
11. Intercom
12. Microphone
5
The Base Unit Layout
1. Record/Memo
2. Time/Set
3. Change
4. Menu
5. Charge Contacts
6. Delete
7. Page
8. Charging Indicator
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM6
9. In Use Indicator
10. Repeat/Slow key
11. Answer ON/OFF key
12. Skip/Quick key
13. Volume Keys
14. Mailbox Keys
15. DC Connector
16. Telephone Jack
6
Setup
Connecting Power to Base Unit
Plug the AC power adapter into an electrical outlet, and the DC connector into the jack on the bottom of the Base Unit.
CAUTION: Use only the VTech power supply provided with your VTech Unit.
IMPORTANT: FOR MAXIMUM PERFORMANCE OF YOUR CORDLESS TELEPHONE SYSTEM:
1. Choose a central location for your Base Unit.
2. Install your Base Unit and Extension Handsets away from electronic equipment, such as personal computers, television sets and microwave ovens.
3. In locations where there are multiple cordless telephones, separate base units as much as possible.
4. Install your telephone equipment away from heat sources and sunlight.
5. Avoid excessive moisture, dust or extreme cold.
G
A
E
P
Getting Started
91-005358-050-000 v2656.pmd 8/5/2004, 4:50 PM7
7
Installation of Battery Pack in Handset
Follow the steps below:
1. Remove the battery cover by pressing on the indent and sliding downward.
Getting Started
The original Handset that is shipped with your v 2656 system will be automatically registered to the Base. This Handset is HANDSET 1.
2. Align the two holes in plug with the socket pins. Insert the plug into socket. Place the battery pack into the compartment with the wires in one of the bottom corners of the battery pack.
3. Replace the battery cover by sliding it upwards.
4. If the new battery pack is not already charged, place the Handset in the Base unit, or a remote charging stand, and allow it to charge for 12 hours. After initial charge, a maintenance charge of 8 hours should be sufficient.
Setup
As you register additional Handsets to the system, they will be assigned extension numbers in the following order: HANDSET 2, HANDSET 3, and finally HANDSET 4.
After a Handset battery pack is installed, the Handset will automatically begin
SEARCHING FOR BASE (if previously registered), or it will prompt you to ENTER BASE ID to register the new Handset.
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM8
8
Charging Of Handset Battery Pack
The Handset of your v 2656 cordless telephone is powered by a rechargeable battery pack. It charges automatically whenever the Handset is in the Base Unit. Maximum talk time on a full charge is 7.5 hours. Maximum standby time is 5 days.
You should charge the battery pack for 12 hours when you first receive your phone. You'll know the battery pack needs charging when:
The low battery message is displayed:
The handset seems completely dead, the LCD is completely clear and does not activate when you press the keys.
IMPORTANT:
1. Do not dispose of a battery pack in a fire, the cell may explode.
2. Do not open or mutilate the battery pack. Toxic substances may be released, causing harm to eyes or skin.
3. Exercise care in handling battery packs in order to prevent an accidental short of the charge contacts, potentially causing the battery pack to overheat.
4. Do not dispose of this battery pack into household garbage. Please refer to the following information concerning proper battery recycling.
Getting Started
Connecting to phone line
Plug one end of the telephone line cord into the jack on the bottom of the Base unit. Plug the other end of this cord into the wall jack.
Checking for dial tone
After the battery is charged press ON on the Handset. The Phone icon will appear on the Handset display, and you will hear dial tone. If not, see
In Case of Difficulty.
9
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM9
Wall Mounting
The Wall Mount bracket is designed for use on standard Wall Mount plates only.
1. Line up the tabs on the wall mount adapter with the holes on the bottom
of the base unit. Snap the wall mount bracket firmly in place.
2. Plug the AC adapter into an electrical outlet, and the DC connector to
the jack on the bottom of the Base Unit. If the handset battery pack has
Getting Started
not been charged previously, place the handset in the base unit cradle, and allow it to charge for 12 hours.
3. Connect the telephone line cord to the jack on the bottom of the base
unit, and the other end to the wall jack.
4. Mount the base unit on the wall. Position the base unit so the mounting
studs will fit into the holes on the wall mount bracket. Slide base unit down on the mounting studs until it locks into place.
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM10
10
Registration of Additional Handsets
Registration and Operation of the v 2600 Accessory Handset
Your v 2656 system can operate up to 4 Handsets. The VTech accessory Handset consists of the following:
Setup of the v 2600 Accessory Handset
1. Plug the AC power adapter into
an electrical outlet.
2. Install the battery, as desciribed
previously.
Getting Started
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM11
11
Enter Base ID Code
1. After charging the Handset, if
the screen displays
SEARCHING FOR BASE,
Getting Started
press NEW. You will see ENTER BASE ID. If the screen already
says ENTER BASE ID, go to step 2.
2. Enter the 15 digit Base Unit ID
code, located on the underside of the Base Unit.
Registration of Additional Handsets
3. Press
OK
. The Handset will
display: PLEASE WAIT!! Then put the Handset onto the cradle.
4. Wait approximately 15 seconds.
The Handset will display:
FOUND BASE
If the Handset displays: BASE BUSY TRY LATER, this
indicates that the system is in use. Wait until the Base Unit is in the idle (on hook) mode, and repeat steps 2 to 4.
NOTE: Occasionally, it may take longer than 15 seconds for the Handset to confirm registration to the Base Unit. This is normal.
Congratulations! You can now enjoy the benefits of your multi-Handset system.
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM12
12
Handset Icons
Handset and Base Indicators
Icon
M
H
E
Description
Line In Use indicator On steady with no number next to it when a parallel set is in use. On steady with one or more numbers next to it, indicating which extensions are using the line. For example, 12 indicates that Handset 1 and Handset 2 are on an outside call.
Intercom indicator On steady with the extension numbers currently on an
intercom call. For example, 1 and Handset 2 are on an intercom call.
Battery indicator Cycles (Low, Medium, and High) when Handset battery is charging. Flashes when a low battery condition is detected.
Mute indicator On steady when the Handset microphone is muted.
Hold indicator On steady when the line is on hold.
Enhanced Mode indicator On steady when active Handset and Base are in Enhanced mode.
Handset Registration indicator
is displayed when a Handset is either not registered, or
is searching for a Base unit.
12 indicates that the Handset
Basic Operation
Base LEDS
LED
In Use
Mailbox/Stop
Charging
ON/OFF
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM13
Description
• Lights when line is being used by a Handset of the v 2656 system.
• Glows when there are only old messages in the mailbox.
• Flashes when there are new messages in the mailbox.
• Is not illuminated when a mailbox is empty.
• Lights whenever the handset is placed in the base unit charging cradle.
• Lights when the answering machine is on.
13
Soft Menu Functions
The v 2656 has an advanced design that uses a menu structure and soft keys to access all of the built-in features.
Example of the idle mode display:
RDL (Redial)
Press RDL to display the last 5 telephone numbers dialed. The number on top line is the most recent number dialed.
Use the
To dial the number, you can simply press the ON or
To erase (or save) the number, select this option to delete (or save) it.
MENU
With the Handset in the idle (OFF) mode, press the MENU key to access the
Basic Operation
following options:
CALLS LOG (CALLER ID)
HANDSET SETTINGS
• RANGE EXTENDER
TONE/PULSE
REGISTER
Use the
scroll keys to select the desired number.
SPEAKER
scroll keys to select the desired option, then press OK.
key.
Caller ID - Call Waiting ID
Your v 2656 is capable of displaying the name and/or number of the party calling before you answer the phone (Caller ID). It is also capable of displaying Caller ID information in conjunction with a Call Waiting alert signal (Call Waiting Caller ID). With Call Waiting Caller ID, the Caller ID data is displayed so you can decide whether to answer the incoming call, or continue with your current conversation.
NOTES ABOUT CALLER ID & CALL WAITING CALLER ID
These are subscription services, provided by most regional telephone service providers. You must subscribe to these services to get the benefits of these features. If you do not subscribe to Caller ID services, you can still use your
v 2656 and the other features it offers.
Due to regional incompatibilities, Caller ID information may not be available for every call you receive. In addition, the calling party may intentionally block their name and phone number from being sent.
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM14
14
Calls Log (Caller ID)
From the idle (OFF) mode, press use the scroll keys to select CALLS LOG, then press
ID information of the most recently received call will be displayed. For example:
To scroll to other records, use the
scroll keys.
To dial the number displayed, you can simply press the
You can also press the the following options ( DEL, OPT#, SAVE):
DEL : Select this option to delete THIS
OPT# : Select this option to display up to four possible dialing strings of the
ON
or ALL records in Caller ID memory.
number stored in Caller ID memory. If a number is provided in the Caller ID data, the possible options to choose from will be either 7, 8, 10, or 11 digits. For example, if the original number in Caller ID memory was 808-880-8808, then the display options will be:
Use the make selection, and then press
DIAL, ON
the number.
SAVE : Select this option to save the displayed Caller ID record into
Memory. Only Caller ID records with telephone numbers can be saved into Memory. If you need to modify the number after saving, see To Edit a Number/Name, on page 21.
OK
or
SPEAKER
CID
or
SPEAKER
MENU
. The Caller
key.
key to access
keys to
to dial
,
Basic Operation
Your v 2656 stores the 50 most recent Caller ID and Call Waiting ID records in its memory. As new records are stored, the oldest records are automatically deleted to make room. Therefore, you do not have to manually delete CID records.
15
91-005358-050-000 v2656.pmd 8/5/2004, 4:51 PM15
