VTech LS5145 User Manual
Congratulations
on purchasing your new VTech product.
Before using this telephone, please read the
Important safety instructions
on page 99 of this manual.
This manual has all the feature operations and troubleshooting necessary to install
and operate your new VTech telephone. Please review this manual thoroughly to
ensure proper installation and operation of this innovative and feature rich VTech
product. For support, shopping, and everything new at VTech, visit our website at
www.vtechphones.com. In Canada, please visit www.vtechcanada.com.
The BLUETOOTH® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by VTech Holdings
Limited is under license. VTech Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are
those of their respective owners.
www.vtechphones.com
i
Table of contents
Getting started . . . . . . . . . . . . . . . . . . . . . 1
Parts checklist . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . .
Telephone base installation . . . . . . . . . . . . . . .
Battery installation and charging . . . . . . . . . . . . .
Spare battery . . . . . . . . . . . . . . . . . . . . . . . 5
Expanding your telephone system . . . . . . . . . . . .
Adding new handsets. . . . . . . . . . . . . . . . . . .
Handset layout . . . . . . . . . . . . . . . . . . . . . . 8
Telephone base layout . . . . . . . . . . . . . . . . . . 9
Handset status icons
Telephone base status icons
Handset main menu . . . . . . . . . . . . . . . . . .
Telephone base main menu
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . 16
Introducing Bluetooth
Bluetooth at a glance . . . . . . . . . . . . . . . . . . 18
Bluetooth Setup. . . . . . . . . . . . . . . . . . . . . 19
Setting up cellular . . . . . . . . . . . . . . . . . . .
Setting up headset . . . . . . . . . . . . . . . . . . .
Managing your devices
Paired devices . . . . . . . . . . . . . . . . . . . . .
Renaming a paired device . . . . . . . . . . . . . . .
Deleting a paired device . . . . . . . . . . . . . . . .
Deleting all paired devices . . . . . . . . . . . . . . .
ii
. . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . 11
12
. . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . 16
20
21
. . . . . . . . . . . . . . . . . 23
23
23
24
25
www.vtechphones.com
Viewing device information
Active devices . . . . . . . . . . . . . . . . . . . . .
1
Replacing an active device
2
Removing an active device
3
Adding an active device . . . . . . . . . . . . . . . .
4
Changing the PIN (of the telephone base)
6
System setup . . . . . . . . . . . . . . . . . . . . . 30
Handset settings . . . . . . . . . . . . . . . . . . . .
7
Editing handset name . . . . . . . . . . . . . . . . .
Showing handset name . . . . . . . . . . . . . . . .
Keypad tone . . . . . . . . . . . . . . . . . . . . . . 32
Language . . . . . . . . . . . . . . . . . . . . . . . . 32
LCD contrast . . . . . . . . . . . . . . . . . . . . . . 33
Clearing voice mail . . . . . . . . . . . . . . . . . . .
Default settings
Deleting registration . . . . . . . . . . . . . . . . . .
Handset ringers
Ringer volume . . . . . . . . . . . . . . . . . . . . .
Ringer melody . . . . . . . . . . . . . . . . . . . . .
Selecting a ringer melody . . . . . . . . . . . . . . .
Deleting a ringer melody . . . . . . . . . . . . . . . .
Recording a new ringer
Handset pictures . . . . . . . . . . . . . . . . . . . .
Handset animations . . . . . . . . . . . . . . . . . .
Telephone base settings . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . 34
. . . . . . . . . . . . . . . . . . . . . 35
. . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . 27
. . . . . . . . . . . . . . . 28
. . . . . . . 29
. . . . . . . . . . . . . . . . . 38
26
28
30
31
31
33
34
36
37
37
37
39
40
41
Table of contents
Setting date. . . . . . . . . . . . . . . . . . . . . . . 42
Setting time
Keypad tone . . . . . . . . . . . . . . . . . . . . . . 43
Language . . . . . . . . . . . . . . . . . . . . . . . . 43
LCD contrast . . . . . . . . . . . . . . . . . . . . . . 44
Clearing voice mail . . . . . . . . . . . . . . . . . . .
Voice mail codes . . . . . . . . . . . . . . . . . . . .
Default settings
Deleting handsets . . . . . . . . . . . . . . . . . . .
Telephone base ringers . . . . . . . . . . . . . . . .
Ringer volume . . . . . . . . . . . . . . . . . . . . .
Ringer melody . . . . . . . . . . . . . . . . . . . . .
Answering system settings
Answer on/off . . . . . . . . . . . . . . . . . . . . . . 53
Announcement . . . . . . . . . . . . . . . . . . . . . 54
Recording an announcement . . . . . . . . . . . . .
Number of rings
Call screening . . . . . . . . . . . . . . . . . . . . .
Remote code . . . . . . . . . . . . . . . . . . . . . . 57
Message alert tone . . . . . . . . . . . . . . . . . . . 58
Telephone operation . . . . . . . . . . . . . . . . . 59
Making a HOME call . . . . . . . . . . . . . . . . . .
Receiving a HOME call
Call waiting on the HOME line . . . . . . . . . . . . .
Making a CELL call
. . . . . . . . . . . . . . . . . . . . . . . 42
45
45
. . . . . . . . . . . . . . . . . . . . . 47
48
49
50
51
. . . . . . . . . . . . . . . 52
55
. . . . . . . . . . . . . . . . . . . . . 56
57
60
. . . . . . . . . . . . . . . . . 62
63
. . . . . . . . . . . . . . . . . . . 64
www.vtechphones.com
Receiving a CELL call . . . . . . . . . . . . . . . . .
Call waiting on the CELL line
Adjusting the listening volume
Silencing the ringers . . . . . . . . . . . . . . . . . .
Mute . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Receiving a CELL call while on a HOME call . . . . .
Receiving a HOME call while on a CELL call . . . . .
Conferencing HOME and CELL calls . . . . . . . . .
Call waiting while on a conference call
Intercom . . . . . . . . . . . . . . . . . . . . . . . . 70
Voice mail
Phone book . . . . . . . . . . . . . . . . . . . . . . . 73
Creating a new phone book entry . . . . . . . . . . .
Searching for phone book entries . . . . . . . . . . .
Dialing a phone book entry
Editing a phone book entry
Deleting phone book entries . . . . . . . . . . . . . .
Information about caller ID with call waiting . . . . . .
Call log . . . . . . . . . . . . . . . . . . . . . . . . . 82
Call log information
Memory match . . . . . . . . . . . . . . . . . . . . . 83
Reviewing the call log . . . . . . . . . . . . . . . . .
Dialing a call log entry . . . . . . . . . . . . . . . . .
Dialing options . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . 72
. . . . . . . . . . . . . . . . . . . 83
. . . . . . . . . . . . . . 65
. . . . . . . . . . . . . 66
. . . . . . . . . 70
. . . . . . . . . . . . . . . 78
. . . . . . . . . . . . . . . 79
65
66
68
68
69
74
77
80
81
84
85
85
iii
Table of contents
Saving call log entries into the phone book . . . . . . 86
Deleting call log entries
Playing recorded messages in the call log
Clearing missed calls
Redial list . . . . . . . . . . . . . . . . . . . . . . . .
Saving redial entries into the phone book . . . . . . .
Dialing a redial entry . . . . . . . . . . . . . . . . . .
Editing a redial entry . . . . . . . . . . . . . . . . . .
Deleting redial entries . . . . . . . . . . . . . . . . .
Answering system . . . . . . . . . . . . . . . . . . 93
Answering system operation . . . . . . . . . . . . . .
Message announcements . . . . . . . . . . . . . . . 93
Playing answering system messages . . . . . . . . .
Options during playback . . . . . . . . . . . . . . . .
Deleting all messages . . . . . . . . . . . . . . . . . 95
Call screening (on the telephone base) . . . . . . . .
Call intercept . . . . . . . . . . . . . . . . . . . . . .
Recording a memo
Remote access . . . . . . . . . . . . . . . . . . . . . 97
Battery . . . . . . . . . . . . . . . . . . . . . . . . . 98
Important safety instructions . . . . . . . . . . . . 99
Troubleshooting. . . . . . . . . . . . . . . . . . . .100
Operating range . . . . . . . . . . . . . . . . . . . .114
Maintenance . . . . . . . . . . . . . . . . . . . . . .114
. . . . . . . . . . . . . . . . . 86
. . . . . . . 87
. . . . . . . . . . . . . . . . . . 88
89
90
91
91
92
93
94
94
96
96
. . . . . . . . . . . . . . . . . . . 96
About cordless telephones . . . . . . . . . . . . .115
Warranty . . . . . . . . . . . . . . . . . . . . . . . .115
FCC, ACTA and IC regulations . . . . . . . . . . . .117
The RBRC® seal . . . . . . . . . . . . . . . . . . . . 118
Technical specications . . . . . . . . . . . . . . . 119
Index . . . . . . . . . . . . . . . . . . . . . . . . . .120
iv
www.vtechphones.com
Getting started
Parts checklist
Remember to save your sales receipt and original packaging in case it is necessary to ship your
telephone for warranty ser vice. Make sure the telephone package includes the following:
1. Quick start guide
2. Handset
3. Telephone base
To purchase a
•
replacement
battery or
telephone base
power adapter,
visit our website at
www.vtechphones.
com or call
1 (800) 595-9511.
In Canada, go to
www.vtechcanada.
com or call
1 (800) 267-7377.
Getting started
Basic operation
4. Battery
7. User’s manual
5. Telephone line cord
www.vtechphones.com
6. Telephone base power adapter
1
Getting started
®
Installation
Install the telephone base close to a telephone jack and a power outlet not connected to a wall switch.
For optimum range and better reception, place the telephone base in a central and open location.
Depending on the environmental conditions, make sure that your Bluetooth enabled cellular phone
is within 12 feet of where you install the telephone base in order to maintain a reliable connection
between your Bluetooth cell phone, the telephone base, and a cell tower (see below).
Avoid placing the telephone base too close to:
Communication devices such as: personal computers, computer routers, television sets, VCRs,
•
wireless routers (wireless broadband, Wi-Fi, or 802.11) or other cordless telephones.
Excessive heat sources.
•
Noise sources such as a window with trafc outside, motors, microwave ovens, refrigerators, or
•
uorescent lighting.
Excessive dust sources such as a workshop or garage.
•
Excessive moisture.
•
Extremely low temperature.
•
Mechanical vibration or shock such as on top of a
•
washing machine or work bench.
Cell phone
2
Cell tower
www.vtechphones.com
Telephone base
Getting started
Telephone base installation
Install the telephone base as shown below. Make sure that the electrical outlet is not controlled by a
wall switch. Also, if you receive high speed internet through your telephone line (commonly referred
to as DSL), install a DSL lter to the telephone line between the telephone base and the telephone
wall jack. Contact your DSL ser vice provider for more information about DSL lters.
Electrical outlet
not controlled by
a wall switch
Telephone base
power adapter
Telephone wall jack
DSL lter (not included)
for DSL users
Telephone line cord
Use only the
•
power adapter
supplied with this
product. To order a
replacement power
adapter, visit our
website at www.
vtechphones.com
or call
1 (800) 595-9511.
In Canada, go to
www.vtechcanada.
com or call
1 (800) 267-7377.
The telephone
•
base power
adapter is intended
to be correctly
oriented in a
vertical or oor
mount position.
Getting started
Basic operation
Telephone base
www.vtechphones.com
3
Use only the
THIS SIDE UP
Battery Pack
BT5632 / BT5872
3.6V 550mAh Ni-MH
WARNING: DO NOT BURN OR PUNCTURE BATTERIES
MADE IN CHINA
THIS SIDE UP
Battery Pack
BT5632 / BT5872
3.6V 550mAh Ni-MH
WARNING: DO NOT BURN OR PUNCTURE BATTERIES
MADE IN CHINA
THIS SIDE UP
Battery Pack
BT5632 / BT5872
3.6V 550mAh Ni-MH
WARNING: DO NOT BURN OR PUNCTURE BATTERIES
MADE IN CHINA
THIS SIDE UP
Battery Pack
BT5632 / BT5872
3.6V 550mAh Ni-MH
WARNING: DO NOT BURN OR PUNCTURE BATTERIES
MADE IN CHINA
•
battery supplied
with this product
or equivalent.
To order a
replacement, visit
our website at
www.vtechphones.
com or call
1 (800) 595-9511.
In Canada, go to
www.vtechcanada.
com or call
1 (800) 267-7377.
4
Getting started
Battery installation and charging
Install the battery as shown below. After installing the battery, you can make and receive short calls,
but replace the handset in the telephone base when not in use. For optimal performance, charge the
handset battery for at least 16 hours before use. When fully charged, the handset battery provides
approximately four and a half hours of talk time and three days of standby time.
Press the
1.
tab and slide
the battery
compartment
cover
downwards.
2. Insert the plug
as indicated.
Make sure
it is plugged
securely and
matches the
color-coded
label inside
the battery
3. Place the
battery with
the label
THIS SIDE
UP facing
up and the
wires inside
the battery
compartment.
4. Align the cover
at against
the battery
compartment,
then slide it
upwards until
it clicks into
place.
compartment.
www.vtechphones.com
5. Charge the
handset by
placing it in
the telephone
base. The
handset charge
light will be on
when charging.
Charge light
Getting started
THIS SIDE UP
Battery Pack
BT5632 / BT5872
3.6V 550mAh Ni-MH
WARNING: DO NOT BURN OR PUNCTURE BATTERIES
MADE IN CHINA
THIS SIDE UP
Battery Pack
BT5632 / BT5872
3.6V 550mAh Ni-MH
WARNING: DO NOT BURN OR PUNCTURE BATTERIES
MADE IN CHINA
Spare battery (optional)
You can keep a charged spare battery (purchased separately) in the telephone base. The spare battery
compartment is located at the bottom of the telephone base. The charged spare battery allows you
to quickly replace a depleted handset battery, or in the event of a power failure, make and receive
short calls for up to three hours, depending on the amount of use.
To install and charge a spare battery:
3.
1.
Press the tab and slide
the battery compartment
cover out of the
telephone base to open.
2.
Insert the plug securely
matching the colorcoded label inside the
compartment. Place the
battery with the label
THIS SIDE UP facing up
and the wires inside the
compartment.
Position the battery
compartment cover
and slide it towards the
center of the telephone
base until it clicks into
place.
Use only
•
the supplied
rechargeable
battery or
compatible
replacement
(purchased
separately).
To order a
replacement, visit
our website at
www.vtechphones.
com or call
1 (800) 595-9511.
In Canada, go to
www.vtechcanada.
com or call
1 (800) 267-7377.
Getting started
Basic operation
When you have nished installing the spare battery, the battery charging icon will appear in the top
right corner of the telephone base display. It may take up to 24 hours for the spare battery to reach a
full charge. Once the spare battery is fully charged, you can keep it charged until needed.
www.vtechphones.com
5
Getting started
Expanding your telephone system
Your LS5145 telephone system can accommodate up to 12 cordless handsets. You can add new
handsets to your telephone system (LS5105, purchased separately), but each handset must be
registered with the telephone base before use. To register new handsets to your telephone system,
see page 7.
The LS5145 telephone
system comes with one
registered handset.
The handset provided is pre-registered as HANDSET 1. Additional handsets registered to the telephone
system will be assigned in sequential order. For instance, if the telephone system already has
HANDSET 1 and you wish to register another handset, the new handset will become HANDSET 2.
In normal operating conditions, up to four handsets can be used at the same time. For example, two
handsets can be on a HOME call and two handsets can be on a CELL call. However, while an active
handset is experiencing interference or losing signal due to range issues, you may not be able to use
the maximum of four handsets.
6
www.vtechphones.com
Up to 12 handsets (LS5105,
purchased separately)
can be registered to your
telephone system.
Getting started
Adding new handsets (optional)
Your telephone can accommodate up to 12 handsets (LS5105, purchased separately). Before using
a newly purchased handset (LS5105), it must be registered with the telephone base.
Before registering an additional handset, make sure that the handset battery
is installed and charged.
To register a new handset:
1. Place the unregistered handset in the telephone base.
2. Press the
3. Press the
press the
•
•
•
MENU softkey on the telephone base while in idle mode.
UP and DOWN NavKeys to highlight Register Handset, then
SELECT softkey.
Registering Handset will appear on the telephone base display, then
Registration in progress... will appear on the handset display.
The registration process may take up to 90 seconds to complete.
When the registration process is complete, the telephone base and handset
will generate a conrmation tone. The newly registered handset will be
assigned the next handset registration number. For instance, if you already
have one registered handset, HANDSET 1, the next registered handset will
be HANDSET 2.
12:00AM
Place in
Charger
12:00AM
Register handset:
Press MENU in the
base. Find 'Register
Handset' in the Main
Menu. Press SELECT.
12:00AM
Registration
in progress...
You must follow
•
the registration
process for each
handset you wish
to register to the
telephone base.
Getting started
Basic operation
www.vtechphones.com
7
Getting started
Handset layout
Softkeys (2)
Press to select a menu item
displayed just above the key.
HOME/FLASH
Press to make or answer a
home call.
Flashes rapidly when there is
an incoming home call.
Flashes slowly when a home
call is on hold.
During a home call, press to
receive an incoming call if call
waiting is activated (page 63).
(Speakerphone)
Press to activate the
handset speakerphone. The
speakerphone is on when the
is lit.
Press again to resume normal
handset use.
Charge light
On when the handset is
charging in the telephone
base.
8
Press to enter the main menu
(page 12).
When in the main menu,
press to select, save, or set a
desired setting.
During a HOME or CELL line
call, press to end the call.
While in a menu, press to
cancel an operation, back up
to the previous menu, or exit
the menu display.
Press to make or answer a
cell call.
Flashes rapidly when there is
an incoming cell call.
Flashes slowly when a cell
call is on hold.
www.vtechphones.com
MENU/SEL
OFF/CANCEL
CELL
NavKeys
Press the UP, DOWN ,
LEFT or RIGHT NavKeys
to navigate through the
menus, highlight items,
and change settings.
Quick launch keys
When in idle mode, press
one of the Nav Keys to
launch a handset feature.
• Intercom (LEFT)
• Messages (RIGHT)
Volume control
During a call or message
playback, press to turn
the volume of the handset
up or down.
• VOL (UP)
• VOL (DOWN)
Getting started
Telephone base layout
Getting started
Softkeys (3)
Press to select a menu item displayed just
above the key.
CANCEL
Press to cancel an operation and/or return to a
previous menu.
Press and hold to return to the idle screen.
HOME
Press to make or answer a home call using the
speakerphone.
On steady when in use.
Flashes rapidly when there is an incoming home call.
Flashes slowly when a home call is on hold.
MESSAGE light
Flashes when there are new answering
system messages or new voice mail.
Press to make or answer a cellular call
using the speakerphone.
On steady when in use.
Flashes rapidly when there is an
incoming cellular call.
Flashes slowly when a cellular call is
on hold.
www.vtechphones.com
CELL
NavKeys
Pre s s t h e U P , D OWN,
LEFT or RIGHT NavKeys to
navigate through the menus,
highlight items, and change
settings.
Answering system keys
When in idle mode, press
the answering system keys
to o pe ra te the answering
system.
• REPEAT (LEFT)
•
PLAY/SKIP (RIGHT)
Volume control
Dur ing a call or message
playback, press to turn the
volume of the telephone base
up or down.
• VOL (UP)
• VOL (DOWN)
Basic operation
9
Getting started
Handset status icons
12:00AM
1
1
10
Time - indicates the current time.
New answering system message - alternates with the time when you have a new answering system
message.
New voice mail message - alternates with the time when you have a new voice mail message.
HOME line - on steady when the HOME line is in use. Flashes slowly when a HOME call is on hold.
Flashes rapidly when there is an incoming HOME call.
CELL (cell phones 1 or 2) - depending on which cell phone is active, on steady when the CELL line is in use.
1
Flashes slowly when a CELL call is on hold. Flashes rapidly when there is an incoming CELL call.
2
Bluetooth Active Devices - the telephone base is searching for the Bluetooth device(s) on the Active
Devices list (page 26).
Connected Active Devices - indicates that the Bluetooth device 1 and/or 2 are connected and on
2
the Active Devices list. On steady means that the device is connected. Flashes when it is making a
connection with the device.
Disconnected Active Devices - a diagonal line through the device number (1 and/or 2) indicates the
2
device is disconnected from the telephone base.
Wireless Bluetooth headset telephone base.
Ringer off - on steady when the HOME, CELL1, and CELL2 ringers are off.
Flashes when one or two of the HOME, CELL1, or CELL2 ringers are off.
Battery status - shows the approximate battery charge level.
Flashes when the battery is low and animates when charging.
on steady when a Bluetooth headset is in use on the HOME line of the
www.vtechphones.com
Getting started
Telephone base status icons
12:00AM
ANS. OFF
122
1
Time - indicates the current time.
Answering system off - indicates that the answering system will not answer incoming calls (page 53).
HOME line - on steady when the HOME line is in use. Flashes slowly when a HOME call is on hold.
Flashes rapidly when there is an incoming HOME call.
CELL (cell phones 1 or 2) - depending on which cell phone is active, on steady when the CELL line is in use.
1
Flashes slowly when a CELL call is on hold. Flashes rapidly when there is an incoming CELL call.
2
Bluetooth Active Devices - the telephone base is searching for the Bluetooth device(s) on the Active
Devices list (page 26).
Connected Active Devices - indicates that the Bluetooth device 1 and/or 2 are connected and on the
Active Devices list. On steady means that the device is connected. Flashes when it is connecting to the
device.
Disconnected Active Devices - a diagonal line through the device number (1 and/or 2) indicates that the
2
device is disconnected from the telephone base.
Wireless Bluetooth headset when a headset is available to answer an incoming HOME call.
Ringer off - on steady when the HOME, CELL1 and CELL2 ringers are off. Flashes when one or two of
the HOME, CELL1, or CELL2 ringers are off.
Battery status (optional, see page 4) - On steady when fully charged. Animates when charging. Flashes
in the event of a power failure when the spare battery is used.
Getting started
Basic operation
on steady when a Bluetooth headset is in use on the HOME line. Flashes
www.vtechphones.com
11
Getting started
Handset main menu
To enter the main menu:
1. Press
2. Press the
To return to the idle mode,
Phone Book allows you to store and
search for names and numbers.
Phone Book
page 73
MENU/SEL when the handset is in the idle mode.
UP and DOWN NavKeys to select a handset feature menu, then press MENU/SEL to enter that menu.
press and hold OFF/CANCEL.
Phone Bo ok
Alice
Amy
Chris
Deborah
Jenny
Kristen
FIND NEW
1
Messages allows you to review your
answering system messages.
Messages
Messages
0 New M essages
10 Old Message s
PLAY DELETE
page 93
Call Log allows you to review your most
recent incoming calls.
Call Log
Call Log
VTech
1-800-5 95-9 511
Jan 9 10 :39A M
HOME
OPTI ONS DELE TE
page 82
12
Voice Mail allows you to access your
voice mail messages stored at your local
telephone company.
Voice Mail
page 72
www.vtechphones.com
12:00AM
Phone 0:15
98
*
OPTI ONS
MUTE
P
Getting started
Handset main menu (continued)
Getting started
Intercom allows you to page the
telephone base and other handsets.
Intercom
Intercom
Intercom
Global Pa ge
BASE
HANDSET 1
page 70
Settings allows you to change your
handset settings.
Settings
Settings
Settings
Edit Handset Name
Show Handset Name
Keypad Tone
Language
LCD Contrast
page 30
Ringers allows you to set up ringers
for the HOME and CELL lines.
Ringers
Ringers
Ringer for HOME
Ringer for CELL 1
Ringer for CELL 2
Record New Ring er
page 35
Pictures allows you to choose the
wallpaper.
Pictures
Pictur es
SET
page 39
www.vtechphones.com
Animations allows you to choose the
animated wallpaper.
Animations
An imat ions
Animations
SET
page 40
Basic operation
13
Getting started
Telephone base main menu
To enter the main menu:
1. Press the
2. Press the
To return to the idle mode,
Main Menu allows you to review
and setup features and settings.
Main Menu
Phone Book
Call Log
Messages
page 73
Phone Book allows you to
store and search for names and
numbers.
Phone Book 1
John Smith
Mary Brown
MENU softkey when the telephone base is in the idle mode.
UP and DOWN NavKeys to highlight a menu item, then press the SELECT softkey to enter that menu.
press and hold CANCEL.
SELECT
Call Log allows you to review your
most recent incoming calls.
Call Log
VTECH
1-800-595-9511
JUL 4 1:49PM
HOME
OPTIONS
DELETE
page 82
Messages allows you to review your
answering system messages.
Messages
1 New Message
2 Old Messages
Voice Mail allows you to access
your voice mail messages stored
at your telephone company.
9:35 PM
Speaker 2:35
98P
OPTIONS
page 72
Intercom allows you to page all
handsets or a specific handset.
Intercom
Global Page
HANDSET 1
*
FLASH MUTE
FIND NEW
SELECT
page 73
14
PLAY DELETE
page 93 page 70
www.vtechphones.com
SELECT
Getting started
Telephone base main menu (continued)
Getting started
Bluetooth allows you to set up and
manage your Bluetooth device(s).
Bluetooth
Set up Cellular
Set up Headset
Active Devices
SELECT
page 19
Answering System allows you to
review and change the answering
system settings.
Answering System
Answer On/Off
Announcement
Record Memo
SELECT
page 52
Settings allow you to change the
telephone base settings.
Settings
Set Date
Set Time
Keypad Tone
SELECT
page 41
Ringers allow you to set up ringers
for the HOME and CELL lines.
Ringers
Ringer for HOME
Ringer for CELL 1
Ringer for CELL 2
SELECT
page 49
www.vtechphones.com
Register Handset allows you to
register a new handset (LS5105,
purchased separately) with the
telephone base.
Main Menu
Settings
Ringers
Register Handset
SELECT
page 7
Basic operation
15
16
Bluetooth
Introducing Bluetooth
Your new LS5145 telephone system with Bluetooth wireless technology has the following features:
Pair up to eight Bluetooth enabled cell phones and/or headsets with the telephone base.
•
Connect a maximum of two cell phones to make and receive
•
be active on a call at a time.
Connect a Bluetooth enabled headset for making and receiving
•
Conference CELL and HOME calls.
•
Make and receive calls using your cell phone plan while utilizing the ease and comfort of your
•
home telephone system.
IMPORTANT INFORMATION
Refer to the user's manual of your cell phone or headset for more information about its Bluetooth
•
function.
Operate your Bluetooth device within 12 feet from the telephone base. Bluetooth technology
•
operates best within a short range. Keeping within 12 feet will maintain the connection quality of
the Bluetooth device with the telephone base.
Make sure that your cell phone has sufcient signal strength. You may need to move the cell phone
•
and telephone base to a location where the cell phone signal strength may be stronger.
Charge your Bluetooth cell phone while it is connected to the telephone base. Your cell phone's
•
battery will discharge faster while it is connected wirelessly to the telephone base.
Monitor your cell phone's usage because airtime is deducted from your cellular plan for the duration
•
of the CELL calls.
Refer to the Bluetooth setup section (page 19) to learn how to set up and manage your Bluetooth
device(s). Refer to the Telephone operation section (page 59) on how to operate your Bluetooth
devices with your new LS5145 telephone system with Bluetooth wireless technology. Refer to the
Troubleshooting section (page 100) if you experience difculty using the telephone system.
www.vtechphones.com
CELL calls. Only one cell phone can
HOME calls.
Bluetooth
Glossary of terms
Below are some terms used in this user’s manual to help you become familiar with using your Bluetooth
devices and your new LS5145 telephone system.
Active Devices list - A maximum of two paired devices (two cell phones or one cell phone and one
headset) on the Active Devices list can be connected to the telephone base, but only one cell phone
or headset can be on a call at a time.
Bluetooth cell phone - Refers to a Bluetooth enabled cell telephone.
CELL line - The communication service provided through your Bluetooth enabled cell telephone.
Connected - A Bluetooth device (cell phone or headset) can only be used when it is connected to
the telephone base. When a Bluetooth device is connected to the telephone base and active on the
Active Devices list, it will be ready for use.
Disconnected - An X in front of a device on the Active Devices list will appear and a diagonal line
will appear across devices 1 and/or 2 in the icon status bar when the corresponding Bluetooth device
is disconnected from the telephone base.
Discoverable mode - Before a Bluetooth device can be paired, it must be set in this mode. When
pairing your cell phone, the telephone base will be set in this mode. When pairing a headset, the
headset must be set in this mode. Depending on the manufacturer, this mode is sometimes referred
to as Find Me or Visibility.
HOME line - Your conventional telephone land line.
Paired Devices list - Once Bluetooth devices have been paired with the telephone base, they will
appear on the Paired Devices list. A maximum of eight devices can be paired with the telephone
base, but only two can be on the Active Devices list.
Bluetooth
www.vtechphones.com
17
Before using your
•
Bluetooth enabled
device(s) with the
telephone base,
make sure that
your Bluetooth
device(s) are not
connected to any
other device(s).
Pairing - This refers to the process of Bluetooth devices registering device information with each other.
The telephone base must be paired with a Bluetooth enabled cell phone or headset before the Bluetooth
device(s) can be used. Depending on the manufacturer, this is also referred to as Bonding.
PIN - By default, the PIN is 0000 for the telephone base and for most Bluetooth devices. PIN information
must be exchanged between Bluetooth devices before they can be used. This is also known as a
Passkey or Passcode.
Bluetooth at a glance
The telephone base allows you to pair up to eight Bluetooth devices. You can have a maximum of two
paired devices connected at anytime (two cell phones, or one cell phone and one headset), but only
one cell phone or headset can be on a call at a time.
Once you have paired a device with the telephone base, the pairing information will be stored on
the Paired Devices list (page 23). To use a paired device, it must be connected and on the Active
Devices list (page 26).
To learn more about managing your Bluetooth device(s), see the
(page 23). To help you set up your Bluetooth device(s), please follow the instructions in each section
and refer to the Troubleshooting section for help (page 100).
Managing your Devices section
IMPORTANT INFORMATION
Once you pair a device with the telephone base, you do not have to repeat the pairing procedure
•
again, unless you delete the device from the Paired Devices list (page 23).
Press CANCEL on the telephone base at anytime to return to a previous menu.
•
When adding, removing, or replacing a Bluetooth device on the
•
connected devices will temporarily disconnect until the action is complete. It may take up to two
minutes to reconnect.
Active Devices list, all
18
www.vtechphones.com
Bluetooth
Bluetooth Setup
To use a Bluetooth enabled cell phone or headset with your LS5145, you
must rst pair and connect your Bluetooth device(s) with the telephone base.
In the Bluetooth Setup section, you can setup a cell phone (page 20) and headset (page 21). In Managing your Devices section, you can view and modify the information about your Bluetooth device(s) (page 23).
To enter the Bluetooth menu:
1. Press the
2. Press the
the SELECT softkey. You can then select:
•
•
•
connect to your connected Bluetooth device(s) (page 26).
•
your paired devices (page 23).
•
While in the
Press CANCEL to return to a previous menu.
•
Press and hold CANCEL on the telephone base to return to the idle screen.
•
See the Troubleshooting section on page 100 if you experience difculty
pairing or connecting your Bluetooth device(s).
MENU softkey on the telephone base while in idle mode.
UP and DOWN NavKeys to highlight Bluetooth, then press
Set up Cellular - Set up a Bluetooth enabled cell phone (page 20).
Set up Headset - Set up a Bluetooth enabled headset (page 21).
Active Devices - Replace, remove, view the current status of, and
Paired Devices - Rename, delete, and view information about
Change PIN - Change the PIN of the telephone base (page 29).
Bluetooth menu:
Main Menu
Phone Book
Call Log
Messages
Main Menu
Voice Mail
Intercom
Bluetooth
Bluetooth
Set up Cellular
Set up Headset
Active Devices
SELECT
SELECT
SELECT
To learn how
•
to operate your
Bluetooth devices
with the telephone
base, see the
Telephone
operation section
(page 59).
Bluetooth
www.vtechphones.com
19
If you have any
Bluetooth
•
device(s) connected
to the telephone
base when pairing,
Connected
devices will
be temporarily
disconnected
will appear on the
display.
20
Setting up cellular
Before you begin, make sure that your Bluetooth enabled cell phone is not
connected to any other Bluetooth device. Refer to your cell phone user's
manual to learn how to search for or add new Bluetooth devices.
To pair and connect a cell phone:
1. Press the
2. Press the UP and DOWN NavKeys to highlight Bluetooth, then press
the SELECT softkey.
3. Press the SELECT softkey to enter the Set up Cellular menu.
• If a device is already connected to the telephone base, press the
4. Press the NEXT softkey to set the telephone base in discoverable mode.
5. Using your cell phone, turn on the Bluetooth feature and search for or
add new devices.
6. Once your cell phone nds the VTech LS5145 telephone base, select it.
7. Using your cell phone, enter the PIN of the telephone base (the default
PIN is 0000) to continue the pairing process.
8. Press the YES softkey on the telephone base to connect to your cell
phone when the pairing process is complete.
• If successful, Cellular setup completed will be displayed on the
• If you already have two devices on the Active Devices list, press
When a device is connected, the 1 and/or 2 status icons will appear
on the display.
MENU softkey on the telephone base while in idle mode.
OK softkey to temporarily disconnect the device(s) and continue
the pairing process.
telephone base.
the YES softkey to connect to your paired cell phone. You will then
be prompted to replace an existing device on the Active Devices list
(page 26).
www.vtechphones.com
Main Menu
Voice Mail
Intercom
Bluetooth
Bluetooth
Set up Cellular
Set up Headset
Active Devices
Set up Cellular
Set up Cellular
in Discoverable Mode
Set up Cellular
SELECT
SELECT
Set your Cellular to
search for devices,
then press NEXT
NEXT
VTech LS5145
PIN=0000
Pairing complete
Connect to
Cellular ?
Cellular setup
completed
HELPSTOP
NOYES
Setting up headset
Bluetooth
Before you begin, make sure that your Bluetooth enabled headset is not
connected to any other Bluetooth device. Refer to your headset user's
manual to determine the headset's PIN and how to set your headset in
discoverable mode.
To pair and connect a headset:
1. Using the telephone base, press the MENU softkey while in idle mode.
2. Press the UP and DOWN NavKeys to highlight Bluetooth, then press
the SELECT softkey to enter the Bluetooth menu.
3. Press the
• If a device is already connected to the telephone base, press the
OK softkey to temporarily disconnect the device(s) and continue
the pairing process.
4. Using your headset, set your headset in discoverable mode.
5. Using the telephone base, press the
base to search for your headset.
6. Once the telephone base nds your headset, select it and press the
PAIR softkey. If the telephone base cannot nd your headset, press
the FIND softkey to search again, and make sure that your headset is
in discoverable mode.
7. Enter the PIN of your headset, then press the
telephone base (for most headsets, the PIN is 0000).
SELECT softkey to enter the Set up Headset menu.
NEXT softkey on the telephone
DONE softkey on the
Main Menu
Voice Mail
Intercom
Bluetooth
Bluetooth
Set up Cellular
Set up Headset
Active Devices
Set up Headset
Headsets Found
FIND
Set up Headset
SELECT
SELECT
Set your Headset in
Discoverable mode,
then press NEXT
NEXT
Mary’s Headset
PAIR
Enter PIN:
0000
DONE
HELP
If you have
•
any device(s)
connected to the
telephone base
when pairing,
Connected
devices will
be temporarily
disconnected
will appear on
the display.
INFO
ERASE
Bluetooth
www.vtechphones.com
21
Setting up headset (continued)
8. When the pairing is complete, press the YES softkey to connect to
your headset.
• If successful,
telephone base display.
• If you already have one headset on the
press the YES softkey to connect to your paired headset. You will
then be prompted to replace the existing headset on the Active
Devices list (page 26).
When a device is connected, the
on the display.
Headset setup completed will appear on the
Active Devices list,
1 and/or 2 status icons will appear
Headset setup
completed
22
www.vtechphones.com
Managing your devices
Bluetooth
Once you have paired a Bluetooth device, you can rename, delete, and view
the device's information on the Paired Devices list.
Once a Bluetooth device is connected to the telephone base, you can replace
or remove the device from the
Active Devices list (page 26), and view the
Paired Devices
John’s Cell
Mary’s Cell
Mary’s Headset
RENAME
INFO
DELETE
device's status information (page 25).
Paired devices
All paired devices are stored on the Paired Devices list. Up to eight devices
(any combination of cell phones and headsets) can be paired with the
telephone base.
Rename Device
Edit Name
John’s Cell
Done
DONE
ERASE
If a device is successfully paired, the icon (for cell phone) or (for
headset) and the corresponding name of the device will be shown on the
Paired Devices list.
Renaming a paired device
1. Press the MENU softkey on the telephone base while in idle mode.
2. Press the
enter the Bluetooth menu.
3. Press the UP and DOWN NavKeys to highlight Paired Devices, then press the SELECT softkey.
4. Press the UP and DOWN NavKeys to highlight the name of the device to be renamed.
5. Press the
• Press the
• Press the
UP and DOWN NavKeys to highlight Bluetooth, then press the SELECT softkey to
RENAME softkey to rename a device.
LEFT and RIGHT NavKeys to move the cursor left and right.
ERASE softkey to delete the highlighted characters.
To use a paired
•
device, it must be
connected, and on
the Active Devices
list (page 26).
Only the rst 16
•
characters of the
device name is
shown on the
Paired Devices
list.
Bluetooth
www.vtechphones.com
23
Bluetooth
Renaming a paired device (continued)
• Use the dial pad to enter the name (up to 16 characters). See the character chart on page 74
for more information on how to enter a name.
6. Press the
DONE softkey to save the setting.
Deleting a paired device
If you already have the maximum of eight paired devices on the Paired
Devices list, and you want to add another device, you must rst delete a
paired device from the Paired Devices list.
To delete a paired device:
1. Press the
2. Press the
MENU softkey on the telephone base while in idle mode.
UP and DOWN NavKeys to highlight Bluetooth, then press
the SELECT softkey to enter the Bluetooth menu.
3. Press the
DOWN NavKey to highlight Paired Devices, then press the
SELECT softkey.
4. Press the
UP and DOWN NavKeys to highlight the name of the device
to be deleted.
5. Press the
6. Press the
DELETE softkey.
SELECT softkey to delete the selected device. Device Deleted
will appear on the display.
Paired Devices
John’s Cell
Mary’s Cell
Mary’s Headset
RENAME
Delete Options
Delete Device
Delete All Devices
INFO
SELECT
DELETE
24
www.vtechphones.com
Deleting all paired devices
Bluetooth
If you delete all paired devices, you will need to repeat the pairing process
to connect a device.
To delete all the paired devices:
1. Press the
2. Press the
MENU softkey on the telephone base while in idle mode.
UP and DOWN NavKeys to highlight Bluetooth, then press
the SELECT softkey to enter the Bluetooth menu.
3. Press the
DOWN NavKey to highlight Paired Devices, then press the
SELECT softkey.
4. Press the
5. Press the
DELETE softkey.
DOWN NavKey to highlight Delete All Devices, then press
the SELECT softkey.
6. Press the YES softkey to delete all the devices in the Paired Devices list.
Viewing device information
To view the information of a paired device:
1. Press the
2. Press the
the SELECT softkey to enter the Bluetooth menu.
3. Press the
SELECT softkey.
4. Press the UP and DOWN NavKeys to highlight a device, then press
the INFO softkey.
5. Press the
MENU softkey on the telephone base while in idle mode.
UP and DOWN NavKeys to highlight Bluetooth, then press
DOWN NavKey to highlight Paired Devices, then press the
BACK softkey to return to the Paired Devices list.
Delete Options
Delete Device
Delete All Devices
SELECT
Delete Device List
Delete all paired
Bluetooth devices?
Paired Devices
John’s
Mary’s Cell
Mary’s Headset
RENAME
Device Info
Cellular
John’s Cell
BLUETOOTH DEV. ADDR:
001A1A11AAAA
INFO
DELETE
NOYES
BACK
BACK
Bluetooth
www.vtechphones.com
25
Connected devices
Bluetooth
•
appear on the
Active Devices list
automatically.
Active devices
Only devices on the Active Devices list can establish a Bluetooth
connection with the telephone base. Although two paired devices can be
connected to the telephone base, only one Bluetooth cell phone or headset
can be on a call at a time.
Main Menu
Voice Mail
Intercom
Bluetooth
To enter the Active Devices list:
1. Press the
2. Press the
the SELECT softkey to enter the Bluetooth menu.
3. Press the
MENU softkey on the telephone base while in idle mode.
UP and DOWN NavKeys to highlight Bluetooth, then press
DOWN NavKey to highlight Active Devices, then press the
Bluetooth
Set up Cellular
Set up Headset
Active Devices
SELECT softkey.
On the Active Devices list, you may see the following status symbols:
X in front of the device indicates that it is disconnected.
•
in front of a device indicates that it is connected to the telephone base.
•
P
))) in front of a device indicates that the telephone base is trying to
•
connect to that device.
Active Devices
x 1 John’s Cell
P2 Mary’s Headset
CONNECT
While in the Active Devices list, you can select:
CONNECT - Press the CONNECT softkey to connect to a disconnected device.
•
DISCONN - Press the DISCONN softkey to disconnect a device.
•
INFO - Press the INFO softkey to view the current status and full name of a Bluetooth device.
•
OPTIONS - Press the OPTIONS softkey to replace or remove a device.
•
If you experience difculty, make sure that the device is on and not connected to any other Bluetooth
device. See the Troubleshooting section for more information (page 100).
SELECT
SELECT
INFO
OPTIONS
26
www.vtechphones.com
Loading...
