DT594 USER MANUAL(EN)

2-Wire Video Intercom System



Read this manual carefully before using the product, and keep it well for future use.

Introduction

The door station is designed with high resolution color CCD camera, it pro­vides wide angle of 1050 for DT 2-wire intercom system. The high white LED

for night view makes the door station working efciently at night.

The front panel is made of plexiglass or stainless steel with rainy cover for
better protection against water. One or two touch sensor call button can be se­lected. The large name label with white backlight is covered by a fully secured

and ameproof glass plate.

Parts and Function

35.6

Camera Lens

Night View LED

Speaker

Nameplate

Call Button

Microphone

92

178

22

Note:the door station support two call buttons to control two users.

Terminal Description

ON

T/R+ T/R-

1 2 3

ON

12

Connection line

Doorstation Code DIP

1 2

Lock Control Jumper

BUS(Blue&Green)
S2+(Red)

PL(White)

S1+(Yellow)
S1-(Black)

Rainy Cover

-2-

Lock Control Jumper:
Door Station Code DIP:
T/R+,T/R-:

USB-RS485 communication terminal.

Main Connect Port:

To select the lock type.

Total 4 door stations can be supported.

To connect the bus line and the electronic locks.
BUS(Blue&Green): Connect to the bus line, non-polarity.
PL(White): External lock power input, connect to the power positive(power +).

S1+(Yellow): The rst lock power(+) output.

S2+(Red): The second lock power(+) output.
S-(Black): Lock power(-) output.

Door Station Mounting

Mounting with rainy cover

1

2 3

Mounting without rainy cover

1 2 3

-3-

The location of the unit should keep away from snow,rain,and intensity light.

Installation Steps:

Installation height for door station usually is 145~160cm.

1. Use screws to fix the back panel and rainy cover(if mounting with rainy
cover) to the wall after connect the cable correctly.

2. Attach the front panel to the back panel, then use the screw to x it.

Adjusting Camera Angle

Use a screwdriver to loosen
the screw and then adjust the

angle of the camera ,then x

ON

12

the screw.

System Wiring and Connections

Basic one-to-one Connection

AC~

PC6

Bus PL S1+ S2+ S-

-

+

-4-

monitor

Multi Door Stations Connection

2# Camera3# Camera4# Camera

ID=01ID=11

ON

1 2

Bus PL S1+ S2+ S- Bus PL S1+ S2+ S- Bus PL S1+ S2+ S- Bus PL S1+ S2+ S-

ON

1 2

DIP=on,off,off

ID=10

ON

1 2

A B C D

DBC-4S

OFF

ON

Impedance

switch

Multi Monitors Connection

ON

1 2 3 4 5 6

Code=0, DIP-6=off

ON

1 2 3 4 5 6

Code=1, DIP-6=off

1# Camera

ID=00

ON

1 2

85~260VAC

AC~

PC6

ON

1 2 3 4 5 6

Code=14, DIP-6=off

monitors

ON

1 2 3 4 5 6

Code=15, DIP-6=on

monitor monitor monitor monitor

AC~

PC6

ID=00

ON

1 2

-5-

With DBC-4S Wiring Mode

ON

1 2 3 4 5 6

Code=15, DIP-6=on

ON

1 2 3 4 5 6

Code=13, DIP-6=on

ON

1 2 3 4 5 6

Code=3, DIP-6=on

ON

1 2 3 4 5 6

Code=1, DIP-6=on

monitor

monitor

monitor

monitor

ON

1 2 3 4 5 6

Code=14, DIP-6=on

ON

1 2 3 4 5 6

Code=12, DIP-6=on

ON

1 2 3 4 5 6

Code=2, DIP-6=on

ON

1 2 3 4 5 6

Code=0, DIP-6=on

monitor

monitor

monitor

monitor

AC~

Impedance

switch

Impedance

switch

OFF ON

DBC-4S

A B C D

DIP=on,off,off

OFF ON

DBC-4S

A B C D

DIP=on,off,off

-6-

PC6

ID=00

ON

1 2

Electric Lock Connection

Door Lock Controlled with Internal Power

Note:

1. Electronic lock of Power-on-to-unlock type should be used.

2. The door lock is limited to 12V, and holding current must be less than
250mA.

3. The door lock control is not timed from Exit Button(EB).

4. The

Unlock Mode

Parameter of Monitor must be set to 0 (by default).

connect one lock connect two locks

1 2 3

Connect one lock

Jumper position in

2-3

1 2 3

Connect two locks

Jumper position in

2-3

BUS PL S1+ S2+ S-

EB

*

LOCK

BUS PL S1+ S2+ S-

ST

1

EB

*

nd

2

EB

*

Door Lock Controlled with Dry Contact

Note:

1. The external power supply must be used according to the lock.

2. Setup the

Unlock Mode

of Monitor for different lock types.

• Power-on-to-unlock type:Unlock Mode=0 (by default)

• Power-off-to-unlock type:Unlock Mode=1

LOCK

LOCK

nd

2

ST

1

-7-

connect one lock connect two locks

Home

Installer
setup

Caliber
TouchScreen

Take off the Jumper

BUS PL S1+ S2+ S- BUS PL S1+ S2+ S-

POWER
SUPPLY

LOCK

5.2.3 Unlock parameter setting(set on monitor)

Manual
Monitor

Memory
Playback

1.Touch item on main
menu page.

Installation settings:

[0010]#:Remove all remote control
[0011]#:Add remote control

[8000]#:Set as master unit 0
[8001]#:Set as slaver unit 1
[8002]#:Set as slaver unit 2
[8003]#:Set as slaver unit 3
[8004]#:Set as guard unit
[8005]#:Set as not guard unit
[8006]#:Panel on as slaver unit called
[8007]#:Panel off as slaver unit called
[8008]#:Date format:MM/DD/YYYY
[8009]#:Date format:DD/MM/YYYY
[8010]#:Set lock mode to 0
[8011]#:Set lock mode to 1

[8021]~[8029]
#Set the lock time of 1~9s

Multi language settings:

---

Monitor

Album

Intercom

Multimedia

User Setup

09/30/2010 Thu.16:41

Code Number:[----]

1

4

7

Close

3

2

6

5

9

8

0

2.Touch the screen anywhere and
hold for 2s.

Cancel

Take off the Jumper

POWER

SUPPLY

H/W : --- a1.3
S/W: V17.11.418.00
Local addr: --­Unlock timing: --­Video standard: ­UI-CODE: --­MCM-VER.: --­Updated: ---

LOCK

LOCK

4.A digital keypad and setting

3.Touch Installer setup item

instructions will be shown.

Note:

1.must connect correctly before setting.

2.the parameter will be saved in door station automatically,so you need only
set on one monitor.

3.the above diagram is t for icon menu series monitors only, to text menu se­ries monitors,please refer to the corresponding user manual.

-8-

DIP Switches Setting

1 2 3 4 5 6

The DIP switch is designed to set the code
for door station and monitor, there are two
states for each DIP switch, please refer to

ON(1)

ON

OFF(0)

ON

=

=

the sketch map.

Door station DIP setting

Total 2 bits can be congured, bit-1 and bit-2 are used to assign ID code for door sta­tion.The switches can be modied either before or after installation.

Bit state Descriptions

1

1 2

ON

2

ON

ON

1 2

ON

1 2

Default setting, ID = 0(00), set to the rst Door Station.

ID = 1(10), set to the second Door Station.

ID = 2(01), set to the third Door Station.

ID = 3(11), set to the fourth Door Station.

Indoor monitor DIP setting

There are 6 bits in total. The DIP switches are used to congure the user code

for Monitors.
Bit-6 is an video impedance match switch, which have to be set to ON if match
the impedance, otherwise set to OFF.

Bit state Setting Bit state Setting

ON

Not match Match the video impedance

ON

1 2 3 4 5 6

Bit-1~Bit-5 are used to set user code. If the door station with one call button,
the user code should be set to 0~15. If the door station with two call buttons,
the user code should be set to 0~31.
Please refer to the following settings:

-9-

Bit state User code

Bit state User code Bit state User code

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

code=0

code=1

code=2

code=3

code=4

code=5

code=6

code=7

code=8

code=9

code=10

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

code=11

code=12

code=13

code=14

code=15

code=16

code=17

code=18

code=19

code=20

code=21

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

ON

1 2 3 4 5 6

code=22

code=23

code=24

code=25

code=26

code=27

code=28

code=29

code=30

code=31

-10-

Note:Monitors response button A must set the
user code from 0 to 15.and button B set the user
code from 16 to 31.

B

A A

Cables Requirements

The maximum distance of the wiring is limited in the DT system. Using dif­ferent cables may also affect the maximum distance which the system can
reach.

The farest monitor

monitor

with two or four monitors

monitor

When Monitor quantity < 20

Cable Usage A B C

2

2

60 60 30

80 80 40

Twisted cable 2x0.75 mm

Twisted cable 2x1 mm

When Monitor quantity > 20

Cable Usage A B C

2

Twisted cable 2x1 mm

Twisted cable 2x1.5 mm

70 30 20

2

70 50 30

AC~

monitor

C

PC6

DBC-4S

B

A

Note:If the monitor has been specied

the distance,refer to the parameter.

-11-

Specication

Power Supply : DC 24V (supplied by PC6);
Power Consumption: Standby 60mA; Working status 200mA;
Camera: 1/4 ACS 4T image sensor with DSP processor
Lock Power supply: 12Vdc, 300mA(Internal Power);
Working temperature: -10ºC ~ +45ºC
Dimension: 188(H)×110(W)×34(D)mm

Precautions

• Please clean the unit with soft cotton cloth, don't use the organic impregnant

or chemical clean agent. If necessary, please use a little pure water or dilute
soap water to clean the dust.

• The unit is weather resistant. However do not spray high pressure water on

access control keypad directly. Excessive moisture may cause problems with
the unit.

• You must use the right adaptor which is supplied by the manufacturer or ap­proved by the manufacturer.

• Pay attention to the high voltage inside the products, please refer service
only to a trained and qualied professional.

The design and specications can be changed without notice to the user. Right to
interpret and copyright of this manual are preserved.

DT-ENG-594-V1 P130422
