vtech CTM-A2415 User Manual

Analog Contemporary Series

CTM-A2415

Cordless 1-line Hotel Phone

CTM-A2415HC

Cordless Accessory Handset and Charging Base

Master User ‘s Guide

Important safety instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of ﬁre, electric shock and injury, including the following:

1. This product should be installed by a qualiﬁed technician.

2. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS).

3. Read and understand all instructions.

4. Follow all warnings and instructions marked on the product.

5. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

6. Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or swimming pool, or in a wet basement or shower.

7. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.

8. Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided.

9. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply on the premises, consult your dealer or local power company.

10. Do not allow anything to rest on the

power cord. Do not install this product where the cord may be walked on.

11. Never push objects of any kind into this product through the slots in the telephone base or handset because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product.

12. To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the telephone base or handset other than speciﬁed access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.

13. Do not overload wall outlets and extension cords.

14. Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled onto the product.

• If the product has been exposed to rain or water.

• If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operation instructions. Improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation.

EN - 2

• If the product has been dropped and the

CAUTIONS

telephone base and/or handset has been damaged.

• If the product exhibits a distinct change in performance.

15. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning.

20. In wall mounting position, make sure to mount the telephone base on the wall by aligning the eyelets with the mounting studs of the wall plate. Then slide the telephone base down on both mounting studs until it locks into place. Refer to the full instructions in Installation in the user’s manual.

English

16. Do not use the telephone to report a gas leak in the vicinity of the leak. Under certain circumstances, a spark may be created when the adapter is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing concentrations of ﬂammable or ﬂame-supporting gases, unless there is adequate ventilation. A spark in such an environment could create a ﬁre or explosion. Such environments might include: medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc.

• Keep small metallic objects such as pins and staples away from the handset receiver.

• There may be a risk of explosion if a wrong type of handset battery is used (CTM-A2415, CTM-A2415HC). Use only the supplied rechargeable battery (BT164392/BT264392) or replacement battery (BT264392). Dispose of used batteries according to the information in The RBRC® seal in this user guide.

SAVE THESE INSTRUCTIONS

17. Only put the handset of your telephone next to your ear when it is in normal talk mode.

18. The power adapters are intended to be correctly oriented in a vertical or ﬂoor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

19. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a ﬁre. They may explode. Check with local codes for possible special disposal instructions.

EN - 3

Table of contents

FCC, ACTA and IC regulations 31

Energy-saving charging mode 34

Important safety instructions 2 Parts check list 5 Telephone layout

Cordless 1-line CTM-A2415 Base 6

Cordless 1-line CTM-A2415 and CTM-A2415HC Handset 7

Cordless 1-line CTM-A2415HC Charging Stand 8

Installation

Cordless 1-line - CTM-A2415 8

Connection

Cordless 1-line - CTM-A2415 11

Cordless Accessory Handset & Charging stand

- CTM-A2415HC 12

Set up

Maintenance 34

Disclaimer and Limitation of Liability 35

Technical speciﬁcation

Cordless 1-line - CTM-A2415 36

Cordless Accessory Handset & Charging Stand

- CTM-A2415HC 36

Cordless 1-line - CTM-A2415 13

Cordless Accessory Handset & Charging stand

- CTM-A2415HC 13

Operate

Cordless 1-line - CTM-A2415 16

Cordless Accessory Handset & Charging stand

- CTM-A2415HC 16

Appendix

CTM-A2415 Base battery 18

CTM-A2415HC Handset battery 18

Troubleshooting 20

VTech Hospitality Limited Warranty Program 27

Precautions for users of implanted cardiac pacemakers 29

Operating range 29

About cordless telephones 29

The RBRC® seal 30

EN - 4

Parts check list

Items contained in the respective cordless telephone package:

Model

name

Cordless 1-line

Model

number

CTM-A2415

Telephone base

with faceplate

and overlay |

Charging Base

Parts included

Cordless

handset

and

Handset

battery

Telephone line

cord with Power

connector

Base

Stand

| Wall

Mount

Bracket

English

Power

adapter

Cordless 1-line accessory handset & charging base

CTM-

A2415HC

-- --

EN - 5

Telephone layout

Cordless 1-line CTM-A2415 Base

1 MESSAGE WAITING LED 2 Wall mount clip 3 Faceplate slot with Speed dial keys

(Programmable)

SPD5 SPD6 SPD7 SPD8 REPLACE BATTERY LED

4 VOL + | VOL - (VOLUME +/-) 5 SPEAKER 6 CHARGE LED

7 FIND HS (FIND HANDSET)

8 Grooves for Mounting bracket 9 Voicemail voltage detection

10 Battery compartment with cover

11 Grooves for Base stand 12 Telephone jack 13 Base battery ON pinhole

EN - 6

Cordless 1-line CTM-A2415 and CTMA2415HC Handset

English

1 TALK | FLASH 2 OFF 3 Numeric dial keys 4 SPEAKER

Speed Dial keys (Programmable)

SPD1 SPD2

6 Handset battery ON pinhole

7 Handset earpiece

EMERGENCY (Programmable)

MUTE

10 MESSAGES (Programmable)

11 LOW BATTERY LED 12 Microphone 13 Handset screw cover

14 -/VOLUME/+ 15 Speakerphone 16 MESSAGE WAITING LED

EN - 7

Cordless 1-line CTM-A2415HC Charging Stand

Installation

Cordless 1-line - CTM-A2415

Installation option - install base stand for desktop

To mount the base stand

1. Align the grooves with the base stand.

2. Slide down to secure the stand.

1 Charging poles 2 CHARGE LED

To unmount the base stand

Simply slide up and lift the telephone base from the base stand.

EN - 8

Installation option - converting from desktop to wall mount position

To mount the telephone base on the wall

1. Unmount the base stand. Put the cordless handset aside. On the telephone base, press the wall mount clip upward and rotate a half turn (180°). Slide back the clip.

English

• It locks into place with the protruding edge pointing towards the upper edge of the telephone base. This protruding edge holds the cordless handset when the phone is mounted on the wall.

2. Turn the telephone base over with the bottom side facing up. Press the tabs of the mounting bracket as the direction indicated into the grooves on the telephone base until they lock securely.

Protruding

edge

Mounting

bracket

3. Mount the telephone base on the wall by positioning the eyelets on the telephone base and the mounting bracket against the mounting studs. Then slide the telephone base down on both mounting studs until it locks into place.

4. Replace the handset on the telephone base cradle.

EN - 9

Eyelets

Replace telephone base battery

THIS SIDE UP

installation

Replace a handset battery installation

The telephone base battery is pre-installed. To replace the telephone base battery, follow as shown below.

1. Remove the screw with cross head screwdriver. Gently open the battery compartment cover.

The handset battery is pre-installed. To replace the handset battery, follow as shown below.

1. Use a narrow object to pry open the screw cover and remove the screw with cross head screwdriver. Then, insert a 5 mm standard ﬂat head screwdriver in the provided slot and gently open the handset cover.

2. Remove the used battery from the comparment. Plug the new battery connector securely into the socket inside the base battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

3. To replace the handset cover, align all the tabs on the base compartment battery cover against the corresponding grooves, then install the screw.

2. Unplug the battery connector from the socket and then remove the battery from the handset battery compartment.

3. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

THIS SIDE UP

EN - 10

Made in China / Fabriqué en chine CR1535 NE PAS INCINÉRER OU PERCER LES PILES.

DO NOT BURN OR PUNCTURE BATTERIES.

WARNING / AVERTISSEMENT :

THIS SIDE UP / CE CÔTÉ VERS LE HAUT

BT183342/BT283342 (2.4V 400mAh Ni-MH)

Battery Pack / Bloc-piles :

4. To replace the handset cover, align all

CAUTIONS

CAUTION

the tabs on the handset cover against the corresponding grooves on the handset, then ﬁrmly push downward until all the tabs lock in the grooves. Then install the screw.

by a wall switch, and the telephone line cord is plugged ﬁrmly into the power adapter and the telephone wall jack.

3. Bent a small paperclip and gently insert it to the Base battery ON pinhole and Handset battery ON pinhole to turn on the base and the handset.

English

• There may be a risk of explosion if a wrong type of handset battery is used. Use only the supplied rechargeable battery (BT164392/BT264392) or replacement battery (BT264392). To order a replacement, call 1-888-907-2007.

• FCC ID is shown on the back of the cordless handset body after the handset cover is removed.

• Dispose of used batteries according to the information in The RBRC® seal.

Connection

Cordless 1-line - CTM-A2415

Telephone base installation

The telephone comes ready for desktop use.

• Without turning on the battery, the base and the handset cannot be charged.

• Charge the base to enable battery backup feature.

• The battery is fully charged after 12 hours of continuous charging. For best performance, keep the cordless handset in the telephone base when not in use.

4. Press SPEAKER on the telephone base. Listen for a dial tone, and then press SPEAKER again to hang up.

Use only the supplied cable and power adapter. The supplied cable is not designed for use in any other IT devices. Misuse it on your other IT devices shall be prohibited. To order a replacement, call 1-888-907-2007.

1. Install the telephone base as shown below.

Telephone

wall jack

Telephone line cord

Power

cord

connector

If you have High Speed Internet Access service, a DSL ﬁlter (not included) is required.

2. When the telephone base has been initially installed, make sure the power adapter is securely plugged into an outlet not controlled

EN - 11

Cordless Accessory Handset & Charging

CAUTION

Handset registration

stand - CTM-A2415HC

Charger base installation

The telephone comes ready for desktop use.

1. Install the charger base as shown below.

• Make sure the power adapter is securely plugged into an outlet not controlled by a wall switch.

Place the cordless handset on the telephone base cradle. Handset registration happens automatically the ﬁrst time a cordless handset is placed on the telephone base.

When the registration process completes, the MESSAGE WAITING LED ﬂashes once and you hear 3 rising beeps as conﬁrmation.

Each telephone base accommodates up to 4 cordless handsets. When you already have 4 registered handsets, you can replace one of them by a new handset if any one of the 4 registered handsets is disconnected from the base. For example, it is out of range, or its battery is removed or depleted. The previous registered handset is then deregistered from the telephone base.

Handset deregistration

2. Bent a small paperclip and gently insert it to the Handset battery ON pinhole to turn on the handset.

• Without turning on the battery, the handset cannot be charged.

• The battery is fully charged after 12 hours of continuous charging. For best performance, keep the cordless handset in the charging base when not in use.

3. Press /SPEAKER on the handset. Listen for a dial tone, and then press /SPEAKER again to hang up.

Use only the supplied power adapter. The supplied power adapter is not designed for use in any other IT devices. Misuse it on your other IT devices shall be prohibited. To order a replacement, call 1-888-907-2007.

When a registered cordless handset is idle, press *331734#. You hear a conﬁrmation tone when the deregistration process completes.

When a registered cordless handset is idle, place it on another telephone base. This cordless handset automatically registers to the new telephone base.

Handset battery charging

The batteries must be fully charged before using the cordless base and the handset for the ﬁrst time. The CHARGE LED turns on when the cordless handset is charging on the telephone base or charging base. The battery is fully charged after 12 hours of continuous charging. For best performance, keep the cordless handset in the telephone base or charging base when not in use.

EN - 12
