VIDEO INTERCOM SYSTEM

AT16/C5-AT16 USER MANUAL

TALK

MONITOR

VERSION 1.0

Precautions

●Slots or openings in the back of the monitor, are provided for ventilation and to ensure reliable operation of the video monitor or equipment and to protect if from overheating. These openings must not be blocked or covered. The monitor should never be placed near or over a radiator or heat register and should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.

●All parts should be protected from violence vibration. And not allow be impacting, knocking and dropping.

●For clean the LCD screen, using hands or wet cloth is forbidden.

●Please do the cleanness with soft cotton cloth, please do not use the organic or chemical clean impregnate. If necessary, please use pure water or dilute soap water to clean the dust.

●Image distortion may occur if the video door phone is mounted too close to magnetic field e. g. Microwaves, TV, computer etc.

●Please keep away the video door monitor from wet, high temperature, dust, and caustic and oxidation gas in order to avoid any unpredictable damage.

●Do NOT open the device in any condition, call the administrator for help if there is any problem or mulfunction happens.

Contents

1. Parts and Functions ....................................................................... 1

2. Basic Door Release Operation ...................................................... 2

3. Intercom Function ......................................................................... 2

4. Basic Setup Instructions ................................................................3

4.1 How to Enter Main Menu Page ............................................... 3

4.2 Ring Tone Settings ................................................................... 3

4.3 NO Disturb Mode .................................................................... 4

4.4 Date and Time Setting .............................................................. 4

4.5 Room Adress ............................................................................ 4

4.6 Restore to Default .................................................................... 5

5. Screen and Volume Adjustment .................................................... 5

6. Defense Alarm Operation(optional) .............................................. 6

7. Remote Control Function(optional) .............................................. 7

8. Specications ................................................................................ 8

The model you purchase maybe haven't all functions mentioned here, but



the functions contained in your product can be found in this manual.

1. Parts and Functions

8 9

Key Functions

1. Microphone

2. LCD screen

3. LED indicator

4. Call key

5. Monitor key

6. Navigation key

TALK

AT16 or C5-AT16 back view

MONITOR

3 4

5 6

●●Receives●sound●from●the●user.

●●Display●the●images●from●outdoor●station.Touch●operation.

●●Normally●light●on●when●power●on

●●Flash●when●receiving●signal●or●activating●No●disturb●mode

●●Press●to●activate●the●intercom●function●page.

●●Press●to●view●the●outside●condiction.

●●Scrolls●through● lists●and●moves●the●cursor●.●Also●adjust●the●ringer● volume.

AT16 hasn’t this terminal.

7. Unlock key

8. Talk key

9. Menu key

10. Speaker

11. Mounting Hook

12. Connection Port

●●Press●to●release●the●door●for●visitors●during●talking●or●monitoring.

●●Press●to●talk●with●the●visitors●while●receiving●a●call.

●●Press●to●open●a●list●of●actions●available●on●the●current●screen.

●●Output●sound●from●the●outdoor.

●●Used●to●hang●up●the●monitor●unit

●●Bus●line●terminal

2. Basic Door Release Operation

1. Input room numbers in Door Station of the building or main entrance, the Monitor rings, at the same time, the screen displays the visitor image.

2. Press talk with the visitor for 70 seconds. During communication, press to end the conversation. If nobody answers

the phone, the screen will be turned off automatically after 40 seconds.

3. During callin g or talkin g st ate, Press

UNLOCK

Button to open the door for the

visitor.

4. When the monitor is in standby mode, press

MONITOR

view.During monitoring,pressing Button can open the door.Press

Button, you can see the outside

UNLOCK

MONITOR

Button again to close the screen.

3. Intercom Function

When the monitor is in standby mode, press Button to enter Intercom Function page. (or select

item on main menu page). Use ▲ / ▼ Button to

move upward / downward to select the item you want,

press

1. Choose

Button to call.

Ca ll Gua rd U nit

item will sent a call message to the guard center and wait for calling back.

CALL

TALK

Button on monitor, you can

TALK

Intercom Function

Call Guard Unit

Direct Call Guard Unit

Intercom Call

Exit

Button again

2. Choose

Direct Call Guard Unit

center immediately.

will dail the guard

Intercom Call

: you can call the other users in the same network with you. Input the building code and room number by using ▲ / ▼ Button to increase / decrease the value; use Button to select next digit; After finish, press

Talk

Button to active the calling, a call message will be sent out, if the system is free, you will heard the feedback rings, you can talk with someone who answers the call.Press Button to return Intercom Function page.

4. Basic Setup Instructions

4.1 How to Enter Main Menu Page

1. Press

Button in standby mode, the date/time page will be showed. (the

date/time page will be closed in 3 minutes if no operation)

2. Press

Button again, main menu page will be showed.

4.2 Ring Tone Settings

Select can be selected.use

item on main menu page to enter setup page.There are 12 pieces ring tones

setup

/ Button to select last/next ring tone,it will perform

immediatelly.

Door S tation Tone

:set the ring tone calling from

outdoor station.

Door Bell Tone

Guard Unit Tone

:set the ring tone calling from door bell.

:set the ring tone calling from guard

unit.

Door Station Tone -- 01

Door Bell Tone -- 05

GuardUnit Tone -- 05

No Disturb Mode -- off

Installation...

Exit

4.3 NO Disturb Mode

If you don't want to be disturbed (for example, at night), set this item is on(use / button to choose on/off), any call from the outdoor station will be sent to the guard center, and the guard person will tell the visitor that you do not want to accept the visit.

4.4 Date and Time Setting

1. Select page,then use ▲ / ▼ button to select

item on main menu page to enter setup

setup

Installation...

item. A password will be asked before enter next sub menu.the password is 2412, Input the password by using ▲ / ▼ Button to increase / decrease the value; use Button to select next digit, and press button to return last page. After finish,press

Button to confirm and enter the sub menu page.

2. Select

Date and Time Set...

item. Input date and time by pressing the ▲ / ▼ Button to increase / decrease the value and pressing Button to select next digit,After finish,press

Button to save

and exit.and press button to exit and unsave.

4.5 Room Adress

Room adress is the number you input on door station to call the user. According to 4.4 , select

Room Adress...

item, 4 digits number are required for room adress.Input the number by pressing ▲ / ▼ Button to increase / decrease the value; use Button to select next digit.After finish,press

Button to save and exit.and press button to

exit and unsave.

Alarm In/Out Delay -- 40

Date And Time Set ...

Room Address...

Other Settings...

Information...

Exit

1 0 3 2

Time

2 0 1 0 0 3 3 1

Date

Room

6 6 6 6

4.6 Restore to Default

According to 4.4 , select will show the

hardware/software

Information...

information of the Monitor. Select item ,then press

button. All settings will be

restored to default.(Note that the restore to default

item, this item

version and voltage

Restore to default

Hardware Ver. A1.2

Software Ver. V8.9

Voltage 25.6

Manufacture AT16

Restore to default

Exit

operation will not change the time setting and the datas.)

5. Screen and Volume Adjustment

During monitoring or talking, press MENU Button,the Use ▲ / ▼ Button to select the adjustment item; use / Button to decrease / increase the value.

1. The first item is Scene mode selection: Total 4 screen modes can be selected in sequence:

User, Soft

that you can modify you modify

mode

item will be set to

2. The

Brightness

Bright.

and

Brightness

and

Note that only at

Brightness

User

Colour

colour.

colour

item, the

mode automatically.

item is for the image

User mode

whenever

quality setting, adjust the value to get the best image you like.

ADJUST MENU

Normal,

Scene

will be displayed.

user scene

Brightness

ＲＧＢ

Colour

Ring Volume

Talk Volume

５

４

２

６

3. The

Ring Volume

Talk Volume

and

items are ring tone and talking volume adjustment.

4. Note that all the modifications will be done immediately after the operation. Press "MENU" button to quit the adjust page.

6. Defense Alarm Operation(optional)

This system have auto-alarm function to ensure the security for the house owner. Total 4 different sensors were placed to protect different defense area. When the sensor was triggered, the monitor will sent out alarm sound immediately and will sent the alarm signal to the guard center at the same time. Note that your system may not have all the 4 sensors according to the system configuration.

Motion Sensor

Delay sensor, normally it will be placed on doors or windows. If the sensor is set, when the door or window is opened, the monitor will sent out alarm sound and sent the alarm signal to the guard center.

Smoke Sensor

24-hour sensor, this sensor is opened by the system by default. It can be placed on living room or kitchens. if any fire happened in the area, the monitor will sent out alarm sound and sent the alarm signal to the guard center.

1. Select item on main menu page to enter alarm function page as show on the right.

Infrared Sensor

Delay senso r, can be place d on living room or bedrooms. When the sensor is set, if some body invade into the defence area, the monitor wil l sent out alar m so und and sent the alarm signal to the guard center. You can set this sensor when nobody at home.

Emergency Help Button

24-hour sensor, this sensor is opened by the system by default. It can be pl aced any where suitable. if any fire happened in the area, the monitor will sent out the emergency help signal to the guard center.

2. Use ▲ / ▼ Button to select, press

Button to confirm. If the current state is Armed, the 'Disarm' icon is selectable, and vice versa.

Out-Delay Period:

after you arm the system, you will get into Out Delay Period, monitor will sent out short “Di” every 3 seconds; you will hear a long “Di~” at the end of the Out Delay Period, and the system is gotten into the protecting status. By default, the Out Delay Period is 40 seconds, users must get out off the room within 40 seconds, otherwise the system will treat the user as a invader and sent out the alarm signal.

In-Delay Period:

When the system is armed, the defence alarm are activated, to disarm the alarms. When you come into the room, you have 40 seconds to deactivate the sensors(by enter MAIN --> ALARM menu, select Disarm item); if you didn’t deactivate the sensors after 40 seconds, the monitor will sent out alarm sound and sent the alarm signal to the Guard Unit.

5. 40 seconds is the default setting for in-out delay time, it can be changed by the administrator.

7. Remote Control Function(optional)

According to 4.4 , select

Other Settings...

del remote page will be showed. this item is for adding and deleting Remote function.

[A] Button:

Work as Emergency Help Button, press and hold this button for 3s, the monitor will sent out the emergency help signal to the guard center.

[B] Button:

Arm button, press and hold this button for 1s will arm the system(same result as enter MAIN --> ALARM menu, select Arm item).

[C] Button:

Disarm button, press and hold this button

for 1s will disarm the system(same result as enter MAIN

--> ALARM menu, select Disarm item).

[D] Button:

Use this button to release the door.(same

result as press the Unlock button on monitor).

item . A add/

1. Add Remote

2. Del Remote

3. Exit

B C

D A

NOTE:

1. Remote control distance is normally up to 30 meters, and will extend if the built-in

telescopic antenna is taken out.

2. If the controlled distance is becoming shorter, or LED doesn't light on while pressing

any button, open the remote control unit and replace the battery with a new one.

8. Specications

●●Power●supply●for●indoor●monitor:●● ● DC●15~18V●(supplied●by●system)

●●Power●consumption:● ●● Standby●1W;●Working●status●5W

●●Monitor●screen:● ● 3.5●Inch●color●LCD

●●Display●Resolutions:● ● 320(R,●G,●B)●x●240●pixels

●●Video●signal:● ● 1Vp-p,●75Ω,●CCIR●standard

●●Wiring:● ● CAT5●cable,●polarity

●●Dimensions:● ● 220(H)×105(W)×20(D)mm

Please read this manual carefully before using the product you purchase, and keep it well for future use.We reserve the right to modify the specification in this manual at any time without notice.

VERSION 1.0
