Vtech Artificial Intelligence Learning User Manual

User's Manual

COMPACT NOTEBOOK

Dear Parent,

At VTech ®, we know that every child has a unique set of strengths and interests. That’s why we created the Artificial Intelligence Learning™ Series - a sophisticated set of learning tools that track your child’s activity and respond by tailoring the learning experience specifically to your child’s needs.

Every product in the Artificial Intelligence Learning™ Series actually keeps a record of your child’s performance, and adjusts the subjects and skill levels accordingly. The programs will accelerate the skill level in a strong subject, and focus on subject areas that require more work. All the while, your child is learning through engaging, arcade-style games in which fun and learning are seamlessly joined.

All the Artificial Intelligence Learning™ Series products feature hi-tech, ergonomic designs, stereo sound, large LCD screens and a plug-in mouse or touch screen - features that add a new level of sophistication to your child’s learning experience. Also, all the products were designed with portability in mind, so that kids can bring the learning fun anywhere, anytime.

At VTech ®, we are committed to creating fun learning toys that foster a child’s intellectual and social development. We thank you for trusting VTech ® with the important job of helping your child learn and succeed!

Sincerely,

Your Friends at VTech ®

To learn more about the Artificial Intelligence Learning™

Series and other VTech ® toys, visit www.vtechkids.com

INTRODUCTION

Thank you for buying the VTech® Artificial Intelligence Learning™ Compact Notebook.

The VTech® Compact Notebook is your child’s fun, sophisticated entry into the world of hi-tech learning. With its engaging, arcade-style games, your child will be entertained while getting a head start on subjects such as English, math, and science. Plus, our unique Artificial Intelligence Learning™ system keeps track of your child’s progress, and tailors the learning specifically to his or her needs.

Lock

Right speaker

Volume button LCD screen Contrast button Left speaker

On/Off button

Basic buttons

Mouse

Keyboard

Mouse pad

Cursor pad

Cartridge

INSTRUCTIONS & ACTIVITIES

INCLUDED IN THIS PACKAGE

•Compact Notebook learning unit

•Bonus cartridge 1 - Which Sign?

• Bonus cartridge 2 - Music Mixer

•VTech® roller ball mouse

•Mouse pad

•Instruction manual

WARNING:

All packing materials such as tape, plastic sheets, wire ties and tabs are not part of this toy and should be discarded for your child’s safety.

INTRODUCTION

GETTING STARTED

Please remove the protective strip from the backup battery cover by pulling on the plastic tab to avoid losing saved information. The backup battery cover is located on the bottom of the Compact Notebook.

Battery door

Plastic tab

Pull

BATTERY INSTALLATION

1. Make sure the Compact Notebook is turned OFF.

2. Locate the battery cover on the bottom of the

Compact Notebook and open it.

3. Insert 4 “AA” size batteries as illustrated.

WE DO NOT RECOMMEND USING RECHARGEABLE

BATTERIES IN THIS UNIT.

4. Close the battery cover.

NOTE: The use of new, alkaline batteries is recommended for maximum performance.

IMPORTANT!!!

When replacing the 4 “AA” size batteries, make sure the backup battery is in place, or the Compact Notebook is plugged into the wall outlet with a 9V adaptor. Otherwise, you will lose all the information stored in the following applications: Phone Book, Music Composer, Personal Profile, and Progress Report.

BACKUP BATTERY INSTALLATION

Your Compact Notebook comes installed with a backup battery. To avoid damage to the Compact Notebook from leaky batteries, replace the backup battery at least once a year. To replace the backup batteries:

1. Make sure your Compact Notebook is turned OFF.

2. Locate the backup battery cover on the bottom of your

Compact Notebook.

3. Use a screwdriver to unscrew the cover and open it.

4. Insert 1 CR-2032 battery as illustrated, following the plus

(+)and minus (–) signs.

5.Replace the battery cover and screw it back on.

NOTE: While replacing the backup battery, the 4 “AA” size batteries must be kept in the unit, or the Compact Notebook should be plugged into the wall outlet with a 9V adaptor. Otherwise, you will lose all the information stored in the following applications: Phone Book, Music Composer, Personal Profile, and Progress Report.

INSTRUCTIONS & ACTIVITIES

BATTERY NOTICE

•	Install batteries correctly observing the polarity (+, –) signs to avoid leakage.
•	Do	not	mix old and new batteries.
•	Do	not	use batteries of different types.

•Remove batteries from equipment when the unit will not be in use for a long time.

•	Do	not	dispose of batteries	in fire.
•	Do	not	attempt to recharge	ordinary batteries.

•The supply terminals are not to be short-circuited.

•Only batteries of the same or equivalent type as recommended are to be used.

AC ADAPTOR

Use the VTech® adaptor or any standard adaptor complying with 9V 300mA

AC center-positive							adaptor.
AC center-positive							adaptor.

CONNECTING THE ADAPTOR

1. Make sure the unit is OFF.

2. Locate the adaptor jack on the back of the unit.

3. Insert the adaptor plug into the unit’s adaptor jack.

4.Plug the adaptor into a wall outlet.

5.Turn the unit ON.

NOTE: When the toy is not in use for long periods of time, unplug the adaptor.

STANDARD FOR ADAPTORS

• The adaptor is not intended for use by children under 3 years old.

• Only use the recommended adaptor with the toy.

• The adaptor is not a toy.

•Never clean a plugged-in toy with liquid.

•Never use more than 1 adaptor.

•Do not leave the toy plugged in for extended periods of time.

NOTICE TO PARENTS

Regularly examine the adaptor, checking for damage to the cord, plug, transformer or other parts. Do not use the adaptor if there is any damage to it.

IN THE U.S.A. : Many retailers carry this type of adaptor. However, if you are unable to find one locally, the VTech® AC adaptor is perfectly suited to operate your VTech® Compact Notebook. For information on how to purchase a VTech® AC adaptor, call our Consumer Services Department at 800-521-2010 in the U.S., or 1-800-267-7377 in Canada.

INSTRUCTIONS & ACTIVITIES

MOUSE

Mouse button

Mouse door

Use the mouse only on a clean, flat surface, so that the roller ball is not damaged and the cursor moves freely across the screen. Use only a mouse that is compatible with VTech® products.

CONNECTING THE MOUSE

1.Make sure the unit is OFF.

2.Locate the mouse jack on the back of the unit.

3.Plug the mouse into the mouse jack.

USING THE MOUSE

1.Move the mouse in the direction you want the cursor to move.

2.Click on the mouse button to make a selection.

CLEANING THE MOUSE

1. Following the arrows, use a screwdriver to open the cover on the bottom of the mouse.

2. Take the ball out of the mouse and use a dry cloth to clean the mouse and the ball.

3. Place the ball back into the mouse, place the cover back onto the mouse and screw the cover closed.

CARTRIDGE

Make sure the unit is turned OFF. Insert the cartridge into the cartridge slot on the right side of the unit. Turn the unit ON and press the Cartridge button to begin play.

INSTRUCTIONS & ACTIVITIES
