VTech accessory handset User Manual
User’s manual
Accessor y handset for
use with VTech models
LS6315/LS6315 -2/
LS6315-3/LS6325/
LS6325-2 /LS6325-3/
LS6325-4/LS6325-5/
LS6326-4/LS6326-5
Model: LS6305
Congratulations
on purchasing your new VTech product. Before using this telephone, please
read the Important safety instructions on page 10 of this manual.
This manual has all the feature operations and troubleshooting necessary
to install and operate your new VTech telephone. Please review this manual
thoroughly to ensure proper installation and operation of this innovative and
feature rich VTech product. For support, shopping, and everything new at
VTech, visit our website at www.vtechphones.com.
www.vtechcanada.com.
The ENERGY STAR® program (www.energystar.gov) recognizes
and encourages the use of products that save energy and help
protect our environment. We are proud to mark this product with
the ENERGY STAR® label indicating it meets the latest energy
efciency guidelines.
In Canada, please visit
Table of contents
Getting started ............................................ 1
Parts checklist ...............................................1
Battery installation ........................................ 2
Battery charging ............................................ 3
Add and register a handset ........................... 4
Replace a handset ........................................ 5
Handset layout .............................................. 6
Appendix ...................................................... 9
Battery ........................................................... 9
Important safety instructions ....................... 10
Precautions for users of implanted
cardiac pacemakers ............................... 11
Operating range .......................................... 11
Maintenance ................................................ 12
About cordless telephones.......................... 13
The RBRC® seal .......................................... 13
Warranty ...................................................... 14
FCC, ACTA and IC regulations ................... 16
Technical specications .............................. 18
i
Getting started
Parts checklist
Your telephone contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.
Charg er and c harge r adapte r
Batte ryBatte ry compar tm ent c over
To purchase replacement batteries or power adapters, visit our website at
www.vtechphones.com or call 1 (800) 595-9511. In Canada, go to
www.vtechcanada.com or dial 1 (800) 267-7377.
Handset
User’s manu al
1
Getting started
Getting started
Battery installation
Install the battery as shown below.
If the battery compartment cover is on the handset, press on the grooved
1.
tab and slide the cover to remove.
Plug the battery connector securely into the socket inside the handset
2.
battery compartment, matching the color-coded label.
Place the battery with the label THIS SIDE UP facing up and the wires
3.
inside the battery compartment.
Align the cover at against the battery compartment, then slide it towards
4.
the center of the handset until it clicks into place.
Charge the handset by placing it in the telephone base or charger. The
5.
CHARGE light is on when the handset charges.
1
4
If the handset will not be used for a long time, disconnect and remove the
•
battery to prevent possible leakage.
To purchase replacement batteries, visit our website at
•
www.vtechphones.com or call 1 (800) 595-9511. In Canada, go to
www.vtechcanada.com or dial 1 (800) 267-7377.
2
5
CHARGE
light
3
2
Getting started
Battery charging
Once you have installed the battery, the screen indicates the battery status
(see the table below). If necessary, place the handset in the telephone base
or charger to charge the battery. For best performance, keep the handset in
the telephone base or charger when not in use. The battery is fully charged
after 16 hours of continuous charging. See the table on page 9 for battery
operating times.
If the screen is blank or shows Place in charger, you need to charge the
handset without interruption for at least 30 minutes to give the handset
enough charge to use the telephone for a short time. When the battery is low,
the handset shows Low battery and a ashing icon. If you are on a call in
low battery mode, the handset plays short beeps to alert you.
The following table summarizes the battery charge indicators and actions
to take.
Battery indicators Battery status Action
The screen is blank
or shows Place in
charger and ashes.
The screen shows
Low battery and
ashes.
The screen shows
HANDSET X.
If you do not plug in the battery into the handset and place it in the telephone base
or charger, the screen displays No battery.
Battery has very little or
no charge. The handset
cannot be used.
Battery has enough
charge to be used for a
short time.
Battery is charged. To keep the battery charged,
Charge without interruption (at
least 30 minutes).
Charge
without interruption
(about 30 minutes).
place it in the telephone base
or charger when not in use.
3
Getting started
Add and register a handset
Each newly purchased handset (LS6305) must be registered to the
telephone system (LS6315/LS6325/LS6326) before use. When rst
purchased, each handset shows
2.Then press # on handset
handset before registering it to the telephone base. For more details on
battery charging, see page 3.
To make registration easier, read all of the instructions on this page before
you begin.
To register a handset:
Place the unregistered handset in the telephone base or charger. If
1.
1.Press FIND HS on base 4sec and 2.Then press # on handset do not
appear alternately on the handset screen after a few seconds, remove the
handset and place it in the telephone base or charger again.
On the telephone base, press and hold
2.
/FIND HANDSET for about four seconds until the red
IN USE light on the telephone base turns on.
Remove the handset from the telephone base or
3.
charger and then press # (pound key). It displays
Registering...Please wait. It takes about 10 seconds
to complete the registration. The handset shows
HANDSET X Registered and you hear a beep when
the registration completes.
When the registration is complete, the newly registered
handset is assigned the next available handset registration
number. For instance, if you already have HANDSET 1, the
next registered handset will be HANDSET 2.
1.Press FIND HS on base 4sec and
alternately. You may need to charge the
If the registration fails, the handset displays Registration failed for a few
•
seconds, then 1.Press FIND HS on base 4sec and 2.Then press # on
handset alternately. To reset the handset, remove it from the telephone base
and place it back in. Try the registration process again.
You cannot register a handset if any other system handset is in use.
•
Only one handset can be registered at a time.
•
4
