Vox DA15 User Manual
Owner’s Manual
1E
IMPORTANT SAFETY
INSTRUCTIONS
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Mains powered apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as vases, shall
be placed on the apparatus.
•Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet. (for U.S.A. and Canada)
• Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for
long periods of time.
•Turning off the power switch does not completely isolate this product
from the power line so remove the plug from the socket if not using it
for extended periods of time.
• Install this product near the wall socket and keep the power plug
easily accessible.
•WARNING—This apparatus shall be connected to a mains socket
outlet with a protective earthing connection.
• Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
•Do not install this equipment on the far position from wall outlet and/
or convenience receptacle.
• Do not install this equipment in a confined space such as a box for
the conveyance or similar unit.
• Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
The lightning flash with arrowhead symbol
within an equilateral triangle, is intended
to alert the user to the presence of
uninsulated "dangerous voltage" within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the product.
THE FCC REGULATION WARNING (for U.S.A.)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
ncrease the separation between the equipment and receiver.
•I
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user’s authority to operate this equipment.
CE mark for European Harmonized Standards
CE mark which is attached to our company’s products of
AC mains operated apparatus until December 31, 1996
means it conforms to EMC Directive (89/336/EEC) and CE
mark Directive (93/68/EEC).
And, CE mark which is attached after January 1, 1997 means
it conforms to EMC Directive (89/336/EEC), CE mark Directive
(93/68/EEC) and Low Voltage Directive (73/23/EEC).
Also, CE mark which is attached to our company’s products
of Battery operated apparatus means it conforms to EMC
Directive (89/336/EEC) and CE mark Directive (93/68/EEC).
* Company names, product names, and names of formats
etc. are the trademarks or registered trademarks of their
respective owners.
Table of Contents
Introduction....................................................................................... 4
Welcome aboard! ............................................................................ 4
Main features................................................................................... 4
Signal path ...................................................................................... 4
Quick Start ........................................................................................ 5
Setup ............................................................................................... 5
Checking out the preset programs .................................................. 5
Switching between the channels of a program................................ 5
Creating your own sounds............................................................... 6
The Guitarist’s Guided Panel Tour ................................................. 7
A. Top Panel.............................................................................................. 7
B. Rear Panel .......................................................................................... 10
About the three operating modes ................................................. 11
Preset mode (selecting a preset program) .................................... 11
Channel Select mode (selecting a channel program) ................... 11
Manual mode................................................................................. 12
Creating and storing your own program...................................... 13
Creating your own program........................................................... 13
Adjusting the noise reduction ........................................................ 14
Storing your program..................................................................... 15
Checking the settings of a program (original values) .................... 15
Restoring the factory settings........................................................ 16
Using the VFS2 dual foot switch................................................... 17
Sound Styles and Effects .............................................................. 18
STYLES......................................................................................... 18
Effects ........................................................................................... 20
Troubleshooting ............................................................................. 24
Specifications ................................................................................. 26
Programmer’s Cheat Sheet ........................................................... 27
3
Introduction
W
ELCOME
hanks for choosing the VOX DA15. To ensure a long and trouble-free relationship with
your new amp, please read this manual carefully, use the amp as directed and keep
T
M
• The amplifier provides eleven distinctive sound styles that can be used in various
• Eleven high-quality effects are built in and seven are multi effects that let you use two
•You can store your favorite sounds as a program to CH1 or CH2. You can switch
• In Manual mode the sound you hear will reflect the physical settings of the knobs.
• If you connect the optional VFS2 dual foot switch, you can use it to switch programs
S
Your guitar sound passes through the following sections.
(You can refer to “The Guitarist’s Guided Panel Tour” while you read the explanation that
follows.)
the manual for future reference.
AIN
FEATURES
musical genres.
effects simultaneously plus Noise Reduction.
between these settings from the top panel, or by using the optional VFS2 foot switch
connected to the rear panel (Channel Select mode). In addition, there’s one preset program for each of the 11 sound types (Preset mode).
or bypass effects.
IGNAL
ABOARD
PATH
!
Speaker
Effect
AUTO WAH / COMP
4
Pre Amp model
Choose one of 11 types
Effect
MODULATION
DELAY / REVERB
Master Vol
Power Amp
O
Quick Start
nce you’ve satisfied your primal urge to play, I’d like to suggest you give this manual a chance — it’s been written by a fellow guitar nut and this amp boasts some
killer bells ‘n’ whistles that will warrant your interest. In short, it’ll be worth your
while, we promise. This said, here’s the “Quick Start” — enjoy! I look forward to taking you
through the amp in more detail once you’re done...
HINT: If you’re not sure of the location of a control or switch referred to in this Quick Start
section, you can refer to the illustrations in the section entitled “The Guitarist’s Guided
Panel Tour” (page 7).
ETUP
S
1. Turn the MASTER volume control on the amp all the way down.
2. Plug one end of the supplied power cord into the AC power connector on
the rear panel, and plug the other end into a wall outlet.
3. Plug your guitar into the INPUT jack on the top panel.
4. Turn on the POWER switch.
5. Slowly raise the MASTER volume to a desired level.
HECKING
C
1. Press the top panel PRESET button.
The PRESET LED will light which means you’re in Preset mode.
2. Turn the STYLE selector switch to select a sound style.
For each sound style you select, a preset containing a typical sound for that type
will be automatically selected. The GAIN, VOLUME, TREBLE, MIDDLE, BASS,
and effect settings will be switched automatically.
WITCHING
S
1. Press the top panel CH (Channel) button.
The CH1 or CH2 LED will light, and the program assigned to the corresponding
channel will be recalled (Channel Select mode).
2. CH1 and CH2 will alternate each time you press the CH button.
OUT
THE
BETWEEN
PRESET
THE
PROGRAMS
CHANNELS
OF
A
PROGRAM
HINT: You can store your favorite settings in each channel of the program. For details,
see “Storing your program” (page 15).
5
C
REATING
1. Press the top panel MANUAL button.
The MANUAL LED will light which means you’re in Manual mode.
HINT: You can also create your own sounds in Preset mode or Channel Select mode.
However, the process is a bit easier to understand in Manual mode, since the positions of
all knobs (except the EDIT 1 knob) are exactly what you’re hearing. In other words, what
you see is what you get!
2. Use the STYLE selector switch to select a style, and adjust the GAIN, VOLUME, TREBLE, MIDDLE, and BASS.
3. If you want to use an effect, use the EFFECTS selector to select an effect
type, and use the EDIT 1 knob to adjust the depth of the effect. For modulation-type effects like CHORUS or TREMOLO, or the DELAY/REVERB effect,
just press the TAP button twice to set the modulation speed or the delay/
reverb time to the corresponding interval — it doesn’t get much easier than
that!
If you don’t want to use an effect, press the BYPASS button. You can edit more
effect parameters but you’ll have to read the manual to find out how.
4. When you’ve come up with a sound you like, write it as described in “Storing your program” (page 15).
YOUR
OWN
SOUNDS
6
The Guitarist’s Guided Panel Tour
In this chapter we’re going to take a look at the top and rear panels of your amp.
A. Top Panel
2
1
1. I
NPUT
This is where you plug in your guitar.
2. A
Here’s where you make your settings.
SECTION
MP
SECTION
STYLE selector switch
This switch selects a sound style.
slightly-distorted bluesy sounds, crunchy rhythm sounds, and high-gain lead
sounds.
Preset mode (when the PRESET LED is lit) lets you select preset programs that
contain typical sound and effect setting(s) for each sound style.
GAIN
This adjusts the preamp gain. Higher settings will give you more distortion
VOLUME
This adjusts the volume.
4
3 5
The eleven sound styles include clean sounds,
7
TREBLE, MIDDLE, and BASS
This trio of knobs allows you to dial in the exact amount of high, mid, and low frequencies. Also, as you’d expect (and hope!), the exact manner in which each one
of these controls behaves and also interacts with the others is dependant on the
type of sound selected. Turn to the “Sound Styles and Effects” section (page 18)
for more information.
MASTER
This adjusts the overall volume. This setting will vary the amount of distortion created by the power amp.
NOTE: The MASTER volume control is NOT programmable.
NOTE: The GAIN control also affects the amount of distortion. For some settings,
there may be virtually no distortion.
FFECT
3. E
Here you can make settings for effects and noise reduction. For details on each effect,
refer to “Sound Styles and Effects” (page 18).
EFFECTS
Selects the type of effect. You can use the TAP button, EDIT 1 knob and Bypass
button to adjust the parameters of each effect. When you select an effect type, the
effect parameters will be initialized and Effect Bypass will be defeated.
EDIT 1
Use this to adjust the parameters of each effect. By using this knob in conjunction
with the TAP and BYPASS buttons as described below, you can adjust three different parameters.
If the BYPASS LED is lit the effect is bypassed.If you want to adjust the noise
reduction sensitivity you can hold down the TAP button and turn the EDIT 1 knob
simultaneously.
SECTION
•Turn EDIT 1 (without pressing a button) (EDIT 1)
•Turn EDIT 1 while pressing TAP (EDIT 2)
•Turn EDIT 1 while pressing BYPASS (EDIT 3)
NOTE: You can’t adjust the effect parameters while the BYPASS LED is lit.
TAP (EDIT 2) and LED
This button enables you to set the speed of a modulation-type effect such as
CHORUS or FLANGER, or set DELAY times or REVERB lengths; simply press
the button twice at the desired interval.
The LED blinks at the specified speed or time.
HINT: To set the time to exactly match the tempo of a song, press the TAP button several times along with the song.
8
HINT: You can also adjust the speed or time, by holding down the TAP button and
turning the EDIT 1 knob. (This is the EDIT 2 mode)
NOTE: If the BYPASS LED is lit, you won’t be able to use the TAP switch to set the
time. (The TAP LED will be dark.)
BYPASS (EDIT 3) and LED
If you don’t want to use an effect, press this button to turn the effect off (i.e.,
bypassed). If the effect is bypassed, this LED will be lit.
NOTE: You can’t adjust the effect parameters if the BYPASS LED is lit.
HINT: While the effect is bypassed, you can adjust the noise reduction sensitivity by
holding down the TAP button and turning the EDIT 1 knob.
HINT: The bypass setting is remembered even when you switch modes, switch programs or turn off the power.
HINT: The Bypass button can be used to modify effect parameters (EDIT 3). Press
and hold Bypass and simultaneously turn the EDIT 1 knob. See the chart on page 20
for what parameters can be controlled.
4. PRESET/MANUAL/CHANNEL SECTION
PRESET and LED
This button puts your amp into Preset mode and you can use the STYLE selector
to select a “typical” setting for each type of amp sound. If the PRESET LED is lit,
you’re in Preset mode!
MANUAL and LED
This button puts your amp into Manual mode which means the physical position of
each knob (except for the EDIT 1 knob) determines exactly what you will hear.
This means that the amp will operate just like a conventional guitar amp. If the
MANUAL LED is lit, you’re in Manual mode.
CH (Channel), CH1/CH2 LEDs
This button switches between the two channels and the LED of the selected channel will light. In Preset or Manual mode, the CH1 and CH2 LEDs will be dark. If
from either of these modes you then press this CH button, you’ll switch to Channel
Select mode, and the channel (CH1 or CH2) that you selected most recently will
become active.
WRITE button
Use this button to save a new program into CH1 or CH2. Refer to “Storing your
program” (page 15).
5. POWER SWITCH
When the power is on, the indicator located above the switch will be lit.
9
Loading...
