Extra caution must be exercised when working on vehicles equipped with SRS/SIPS bag/IC
in order to avoid:
1. Personal injuries when performing repair work.
2. Damage or malfunction of the SRS/SIPS bag/IC system.
Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may
affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo
workshop.
In case of doubt, consult the SRS and SIPS bag/IC service manual.
Is the vehicle equipped with SRS/SIPS bag/IC?
Vehicles with SRS are most easily recognised by the letters SRS in the centre of the steering
wheel. If the vehicle also has a passenger side airbag, the letters SRS are stamped on the
dashboard above the glove compartment. SRS vehicles from 1993 and onward also have
explosive seat belt tensioners. SIPS bags are only installed on SRS vehicles from 1995 and
onward. SIPS bag decals are located on the windscreen and seat compartment. Vehicles with
IC can be recognised by the letters IC on the C/D panel (4 door) or the B panel (5 door).
General recommendations
• Be especially careful when working on or around SRS, SIPS, and IC components.
• Make sure that no wires are pinched, frayed, or pierced.
• Never fit accessories by the sensors.
• Where applicable, work on the steering wheel, steering shaft, or steering gear must be done
in accordance with the methods in the SRS section of VA DIS.
• Certain components of the aforementioned systems must be grounded while working. Read
the appropriate sections in VADIS.
• Do not install any accessories in the areas between the A and B-pillars, the B and C-pillars,
and the C and D-pillars.
Test terminal
Data link connector in the passenger compartment.
Changes introduced up to and including June 2004
Any changes made to the vehicles after this date are not included in the
manual. If necessary refer to service bulletins.
Volvo models are sold in versions adapted for different markets. These
adaptations depend on factors such as legal requirements, taxation, and
market demands.
This manual may therefore include illustrations and text that do not apply to
the vehicles in your country.
Group 23= Fuel system
Group 26= Cooling system
Group 27= Engine controls
Group 32= Alternator and voltage regulator
Group 33= Starting system
Group 35= Lighting
Group 36= Additional electrical equipment
Group 37= Wiring and fuses
Group 38= Instruments
Group 39= Other
Group 43= Transmission
Group 59= Brake system
Group 64= Steering
Group 76= Shock absorbers
Group 83= Doors and openings
Group 84= Exterior decorative elements etc.
Group 85= Interior equipment
Group 87= Climate controls
Group 88= Internal equipment
Ignition switch symbols
X= Accessories (audio position)
S= Powered upon insertion of key
15= The switch remains connected during
start
15l= Contact is broken while starting
30= Constant power from the battery
50= Start
Countries/Markets
A= Austria
AUS= Australia
B= Belgium
CDN= Canada
CH= Switzerland
D= Germany
DK= Denmark
E= Spain
EU/OS= Markets outside USA and Canada
FIN= Finland
GB= Great Britain
ISR= Israel
J= Japan
KOR= Korea
N= Norway
NL= Netherlands
S= Sweden
USA= United States of America
WEU= Western Europe
Other
AMP= Amplifier
AUX= External equipment outlet AUX
AUDIO= Audio system
CEM= Central Electronic Module
DVD= External equipment outlet AUX
IR= IR transmitter
M2D= Control module M2D
RAS= Rear Audio Separation module (RAS)
REM= Rear Electronic Module
RSE= Rear Seat Entertainment module
(RSE)
TFT= TV display in head restraint
TV-Tuner= TV receiver
VGA= Voice Guide Amplifier module (VGA)
Colours
BL= Blue
BN= Brown
GN = Green
GR= Grey
LBL= Light Blue
LGN= Light Green
OR= Orange
P= Pink
R= Red
SB= Black
VO= Violet
W= White
Y= Yellow
TP3979202 S80 Premier 20054
How to use the wiring diagram 1:2
The descriptions below apply in general
to all wiring diagram manuals, although
not all sections are necessarily contained in this manual.
A. Component designation
Every component has a component designation that
consists of two parts.
The first part is a type number that describes the
type of component in question, for example 3/xx.
The second part of the designation is a serial number, for example x/2.
Combined these give a component designation, for
example 3/2.
At the end of the manual is a list of components,
where, with the help of the component designation,
you can read off the name of the compone nt, for
example, 3/2 = light switch.
List of type numbers
The list shows which type of component that respective type numbers refer to, for example, 3/x = switch,
6/x = electric motor, etc.
1Battery
2Relay
3Switch
4Control module
5Combined instrument panel
6Electric motor
7Sensor
8Actuator
9Heating element
10Light
11Fuse
15Electrical distribution rail/box
16Audio
17Service/diagnostics
18Contact reel
19Meter
20Ignition component/shunt
26Converter
27Optics
31Ground connection
53Junction point
54Connector
B. Junction points
The wiring diagrams contain numbered junction
points, for example 53/352.
This manual contains a sect ion with a list of junction
points. This list shows all the components which are
connected to each junction point.
The location of the junction points is shown in the
"Cable harness routing in vehicle" section.
C. Connectors
Connectors provide a bridge between two cable harnesses and are described in the "Connectors" section.
D: Electrical distribution
Operation of the fuses and relays is shown in the
"Electrical distribution" section.
E. Data communication
Today’s cars are equipp ed with CAN & MOS T ne tworks that transmit information. Connections to
these networks are shown in their entirety on the
respective wiring diagram. Complete information on
CAN & MOST communication can be found in the
section entitled "Control modules".
F. Abbreviations
A number of different abbreviations are used in the
manual. These are explained in the section "Ab breviations".
G. Component location
There is a section at the end of the manual in which
the appearance and location of components is
described in numerical order.
TP3979202 S80 Premier 20055
How to use the wiring diagram 2:2
A
4/28
TCM
B:1
B:13
B:2
CAN
B:14
15/20:13
Y-GRY-GRY-GR
MAN
3/10
2
1
SB
MAN
53/326
SB
31/96
15/24:2
REM
10/18
F
54/3LF
3
4/58
CAN
2/80
RMI4
4
5
1
2
3
A:14
A:16
B:3
B:1
SB
BDEC
30+
11
11D/3
2
4/56
CEM
D:2
A:1
3
1
53/601
31/72
D:3
B:17
CAN
B:18
BL
SB
31/73
53/615
10/4810/55
B:1
SB
BL
53/604
SB
= System voltage
11D/4
2
= Ground connection
via wiring
R
= Ground connection on
component/chassis
= Screened wire
= Junction point
= Twisted cable
= Electrical connection
= Variant
= CAN communication
= CAN high data signal
54/51
BL
12
BL
(CAN H)
= CAN low data signal
(CAN L)
10/17
B:3
= MOST communication
= LIN communication
= DIN cable, coaxial cable,
etc.
List of symbols
16/82
= Data communication
CAN
= CAN communication
= Connection with distribution
box
G
1
= Further connection to...
= Connector between
wiring harnesses
1
= Connector connected
to component
TP3979202 S80 Premier 20056
Electrical distribution 1:2
Overview S80 Premier
15/31
1
C4:1
A1:12
11A11 A11A
1
11B/1
C1:1
7
11A
22
1
1
1
11B/17
11B/18
11B/19
2
2
2
8
11A
2
1
1
1
1
1
11B/20
11B/21
11B/22
11B/23
11B/24
2
2
2
2
2
2/14
FMA3
1
3
2/32
FMA2
1
3
11B/14
6
11A
1
1
11B/15
11B/16
2
2
2/182
FST2
1
3
2
4
5
4
11A
1
1
1
11B/8
2
11B/10
11B/9
2
2
11B/4
3
2222
1
1
1
11B/5
11B/6
11B/7
2
2
2
2
11B/2
11
11B/3
2
2
1
22
5
11A
2
1
1
121
11B/11
11B/13
11B/12
2
2
2
C1:2
C3:1
C3:3
C4:2
A1:13
C4:9
A1:11
C4:10
A1:10
C6:2
R
R
CNG/LPG
R
20/16
1
2
SB
53/329
C2:1
15/30
C6:7
C6:3
A1:14
A1:7
A1:3
C5:13
A1:2
2
5
C6:4
C6:13
C4:6
A1:5
A1:1
C5:14
C3:4
C4:11
C3:2
C
BL-R
D
C6:12
17/17
R
R
E
C6:10
C4:16
1
2
C4:12
2/35
FMA4
3
5
A1:8
C4:15
C4:14
2
5
1
2
C4:8
2/91
FST1
3
45
C6:1
C4:5
C2:2
A
C4:3
BL
C4:4
R-W
B
C5:12
1
2
C5:15
3
C6:8
2/90
FST3
45
C6:9
1
2
C5:2
2/33
FMI2
3
5 45 4
C6:11
C6:6
2/22
FMI1
2
3
1
C5:11
A1:6
TP3979202 S80 Premier 20057
SB
53/397
BN
31/93
SB
F
Electrical distribution 2:2
Overview S80 Premier
ABDC
E
F
VO
VO
11
22
53/408
VO
3/1
VO
S
11C/2
5
37506
3/157:1
4
30
X
1515I
1
11C/3
4/9B:27/55
15
8
BL-R
11
1
1
11C/4
11C/5
11C/61111C/7
222
R-SB
222
16/65:1
BL-R
BL-R
BL-R
53/443
BL-R
Y
Y-W
11C/8
3/157:2
4/9B:28/56
1
11C/91111C/10
222
4/56
D:16
C:14
D:15
D:60
D:8
D:35
D:50
CEM
CAN
LIN
R
BL
R-W
BL-R
R
R
R
R
R
11
11C/1111C/1
11C/1311C/12
22
53/415
53/403
6/26A:1
31/53
R
6/25:1
1/1
-
12V
+
SB
SB
4/58
2/52
A:29
C:14
C:13
K:1
F
L
B
1
2534
REM
CAN
LIN
B:2
B:24
B:3
B:16
E:A
E:B
BL
11E
67
R
R
54/40D
2
1
R
R
2
245222322
R
R
R
R
R
11
11F / 1
11F / 2
11F / 3
22
R
R
11
1
R
1
2
R-W
54/40C
R
1
R
2
53/724
R
1
11F / 4
11F / 12
222
1
11F / 6
2
R
TP3979202 S80 Premier 20058
Fuses
Fuses by the battery
11E/1
11E/2
11E/3
11E/4
11E/5
11E/6
11E/7
11E Fuses by the battery
No.Fuse functionviaA
216/124Rear Seat Entertainment module (RSE)-40
TP3979202 S80 Premier 20059
Fuses
Fuses in auxiliary fuse box
1
2
3
4
5
6
7
8
9
10
11
12
1
3
2
4
11F Fuses in cargo compartment auxiliary fuse box
No.Fuse functionviaA
12/52Relay, 15l feed, rear
4/55Sun blind control modu l e
9/24Coolbox rear seat
11F/9:2Fuse
54/64:2Connector
53/GND5Junction point
54/36:1Connector
GR-R
GR
-
TP3979202 S80 Premier 200519
Connectors
54/274
54/274
10 pin grey
No.TV display harnessRear Seat Entertainment (RSE) harness
154/276Connector
254/276Connector
354/276Connector
454/276Connector
554/276Connector
654/276Connector
754/276Connector
854/276Connector
954/276Connector
1054/276Connector
W
BN
GN
Y
GR
P
BL
R
SB
VO
16/124:1Rear Seat Entertainment mod-
ule (RSE)
16/124:2Rear Seat Entertainment mod-
ule (RSE)
16/124:3Rear Seat Entertainment mod-
ule (RSE)
16/124:4Rear Seat Entertainment mod-
ule (RSE)
16/124:5Rear Seat Entertainment mod-
ule (RSE)
16/124:6Rear Seat Entertainment mod-
ule (RSE)
16/124:7Rear Seat Entertainment mod-
ule (RSE)
16/124:8Rear Seat Entertainment mod-
ule (RSE)
16/124:9Rear Seat Entertainment mod-
ule (RSE)
16/124:10Rear Seat Entertainment mod-
ule (RSE)
W
BN
GN
Y
GR
P
BL
R
SB
VO
TP3979202 S80 Premier 200520
Connectors
54/275 - 54/276
54/275
10 pin grey
No.TV display harnessRear Seat Entertainment (RSE) harness
154/277:1Connector
254/277:2Connector
354/277:3Connector
454/277:4Connector
554/277:5Connector
654/277:6Connector
754/277:7Connector
854/277:8Connector
954/277:9Connector
1054/277:10Connector
W
BN
GN
Y
GR
P
BL
R
SB
VO
16/124:11Rear Seat Entertainment mod-
ule (RSE)
16/124:12Rear Seat Entertainment mod-
ule (RSE)
16/124:13Rear Seat Entertainment mod-
ule (RSE)
16/124:14Rear Seat Entertainment mod-
ule (RSE)
16/124:15Rear Seat Entertainment mod-
ule (RSE)
16/124:16Rear Seat Entertainment mod-
ule (RSE)
16/124:17Rear Seat Entertainment mod-
ule (RSE)
16/124:18Rear Seat Entertainment mod-
ule (RSE)
16/124:19Rear Seat Entertainment mod-
ule (RSE)
16/124:20Rear Seat Entertainment mod-
ule (RSE)
W
BN
GN
Y
GR
P
BL
R
SB
VO
54/276
10 pin grey
No.TV displayTV display harness
116/81A:1TV display, LH head restraint
216/81A:2TV display, LH head restraint
316/81A:3TV display, LH head restraint
416/81A:4TV display, LH head restraint
516/81A:5TV display, LH head restraint
616/81A:6TV display, LH head restraint
716/81A:7TV display, LH head restraint
816/81A:8TV display, LH head restraint
916/81A:9TV display, LH head restraint
116/81B:1TV display, RH head restraint
216/81B:2TV display, RH head restraint
316/81B:3TV display, RH head restraint
416/81B:4TV display, RH head restraint
516/81B:5TV display, RH head restraint
616/81B:6TV display, RH head restraint
716/81B:7TV display, RH head restraint
816/81B:8TV display, RH head restraint
916/81B:9TV display, RH head restraint
