Volvo S80 2015 5 User Manual

W E B E D I T I O N

O W N E R ' S M A N U A L

WELCOME TO THE WORLD-WIDE FAMILY OF VOLVO OWNERS.

We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual.

We also urge you and your passengers to wear seat belts at all times in this (or any other) vehicle. And, of course, please do not operate a vehicle if you may be affected by alcohol, medication or

any impairment that could hinder your ability to drive.

Your Volvo is designed to meet all applicable federal safety and emission standards. If you have any questions regarding your vehicle, please contact your Volvo retailer or see the section "Contacting Volvo" in this manual's "Introduction" chapter for information on getting in touch with Volvo in the United States and Canada.

01 Introduction

On-board owner's manual........................ 11

Owner's information.................................. 13

Contacting Volvo....................................... 13

About this manual..................................... 14

Change of ownership................................ 18

Crash event data....................................... 18

Volvo Structural Parts Statement.............. 19

Information on the Internet....................... 20

Volvo ID..................................................... 20

Open Source Software Notice.................. 21

Volvo and the environment....................... 21

Important warnings................................... 22

Volvo On Call Roadside Assistance.......... 23

Technician certification............................. 24

02 Safety

Occupant safety........................................ 26

Recall information..................................... 26

Reporting safety defects........................... 27

Seat belts – general.................................. 28

Seat belts – buckling/unbuckling.............. 29

Seat belt reminder..................................... 30

Seat belts – pregnancy............................. 30

Supplemental Restraint System (SRS)..... 31

Front airbags............................................. 32

Occupant Weight Sensor.......................... 36

Side impact protection (SIPS) airbags...... 39

Inflatable Curtain (IC)................................ 41

Whiplash Protection System (WHIPS)...... 42

Crash mode – general information............ 44

Crash mode – starting the vehicle............ 45

Crash mode – moving the vehicle............. 45

Child safety............................................... 45

Child restraints.......................................... 47

Infant seats............................................... 49

Convertible seats...................................... 51

Booster cushions...................................... 53

ISOFIX/LATCH lower anchors.................. 54

Top tether anchors.................................... 56

Child safety locks...................................... 57

Contents

* Option/accessory, for more information, see Introduction.

03 Instruments and controls

Instrument overview ................................. 59

Information displays – introduction........... 62

Eco Guide* and Power Meter*.................. 65

Information displays – indicator symbols. 66 Information displays – warning symbols... 68

My Car – introduction............................... 70

Information displays – ambient tempera-

ture sensor................................................ 71

Information displays – trip odometer and

clock......................................................... 72

Inserting/removing remote key................. 72

Ignition modes.......................................... 73

Front seats................................................ 74

Front seats – folding backrest*................. 75

Front seats – power seat.......................... 75

Key memory – power driver's seat* and

door mirrors.............................................. 77

Rear seats – head restraints..................... 78

Rear seats – folding backrest................... 80

Steering wheel.......................................... 81

Electrically heated* steering wheel........... 82

Lighting panel........................................... 82

High/low beam headlights........................ 83

Active high beams (AHB)*......................... 84

Tunnel detection (models with the rain

sensor* only)............................................. 85

Active Bending Lights (ABL)*.................... 85

Auxiliary lights*.......................................... 86

Instrument and "theater" lighting.............. 86

Parking lights............................................ 87

Rear fog lights........................................... 87

Hazard warning flashers........................... 88

Turn signals............................................... 88

Front interior lighting................................. 89

Rear interior lighting.................................. 90

Home safe lighting.................................... 90

Approach lighting...................................... 91

Windshield wipers..................................... 91

Rain sensor*.............................................. 92

Windshield washer.................................... 92

Tailgate wiper/washer............................... 93

Power windows......................................... 94

Sun shades*.............................................. 95

Power door mirrors................................... 96

Power door mirrors – automatic tilting/

retraction................................................... 97

Heated windshield*, rear window and

door mirror defrosters............................... 98

Interior rearview mirror.............................. 98

Digital compass*....................................... 99

Power moonroof – introduction.............. 100

Power moonroof – operation.................. 101

HomeLink® Wireless Control System* –

introduction............................................. 102

HomeLink® Wireless Control System* –

programming........................................... 103

Volvo Sensus.......................................... 105

Information display – menu controls....... 106

Information display – menu overview..... 107

Information display – messages............. 107

Trip computer – introduction ................. 108

Trip computer – functions, analog instru-

ment panel.............................................. 110

Trip computer – functions, digital instru-

ment panel.............................................. 113

Trip computer – Supplementary informa-

tion.......................................................... 115

Trip computer – Trip statistics................ 116

Contents

* Option/accessory, for more information, see Introduction.

04 Climate

Climate – general information................. 118

Climate – sensors................................... 119

Air quality................................................ 119

Interior Air Quality System (IAQS)*.......... 120

Climate – menu settings......................... 120

Air distribution – general......................... 121

Electronic climate control (ECC)............. 122

Heated seats........................................... 123

Ventilated seats....................................... 124

Temperature and blower control............ 124

Automatic climate control....................... 125

Air conditioning....................................... 125

Max. defroster and electrically heated

windshield*.............................................. 126

Air distribution – function........................ 127

Air distribution – recirculation................. 128

Air distribution – table............................. 129

05 Loading and storage

Storage spaces....................................... 132

Tunnel console........................................ 133

Tunnel console – 12-volt sockets........... 133

Glove compartment................................ 134

Vanity mirror............................................ 134

12-volt socket in the trunk*..................... 134

Loading – general................................... 135

Ski hatch................................................. 135

Loading – roof load carriers.................... 136

Load anchoring eyelets........................... 137

Grocery bag holder................................. 137

06 Locks and alarm

Remote key and key blade..................... 139

Remote key – loss................................... 139

Key memory............................................ 140

Locking/unlocking confirmation.............. 140

Immobilizer (start inhibitor)...................... 141

Remote key – functions.......................... 142

Remote key – range................................ 143

Detachable key blade – general informa-

tion.......................................................... 143

Detachable key blade – detaching/rein-

serting..................................................... 143

Detachable key blade – unlocking.......... 144

Valet locking............................................ 145

Remote key – replacing the battery........ 146

Keyless drive*– locking/unlocking.......... 147

Keyless drive* – unlocking with key

blade....................................................... 148

Keyless drive* – key memory.................. 149

Keyless drive* – messages..................... 149

Keyless drive* – antenna locations......... 150

Locking/unlocking – from the outside..... 151

Manual locking........................................ 151

Locking/unlocking – from inside............. 152

Locking/unlocking – glove compartment 153

Contents

* Option/accessory, for more information, see Introduction.

Locking/unlocking – trunk....................... 153

Alarm – general information.................... 155

Alarm indicator........................................ 155

Alarm – arming/disarming....................... 156

Alarm signal............................................ 156

Alarm – turning off................................... 157

Alarm-related functions........................... 157

07 Driver support

Active chassis* (Four C).......................... 159

Stability system – introduction................ 159

Stability system – operation.................... 160

Stability system – symbols and mes-

sages....................................................... 161

Adjustable steering force*....................... 163

Road Sign Information (RSI)* – introduc-

tion.......................................................... 163

Road Sign Information (RSI) – operation 164 Road Sign Information (RSI) – limitations 164

Cruise control (CC) – introduction.......... 165

Cruise control (CC) – engaging and set-

ting speed............................................... 165

Toggling between ACC and CC (stand-

ard Cruise Control).................................. 167

Cruise control (CC) – deactivating.......... 167

Adaptive Cruise Control – introduction... 168

Adaptive Cruise Control – function......... 169

Adaptive Cruise Control – engaging....... 171

Adaptive Cruise Control – setting speed 172 Adaptive Cruise Control – setting time

interval..................................................... 173

Adaptive Cruise Control – deactivating.. 173 Adaptive Cruise Control – passing

another vehicle........................................ 175

Adaptive Cruise Control (ACC) – Queue

Assist...................................................... 175

Radar sensor........................................... 177

Adaptive Cruise Control – limitations...... 177

Adaptive Cruise Control – symbols and

messages................................................ 179

Adaptive Cruise Control – troubleshoot-

ing........................................................... 181

Distance Alert – introduction................... 182

Distance Alert – operation....................... 182

Distance Alert – limitations...................... 183

Distance Alert – symbols and messages 185

City Safety – introduction........................ 186

City Safety – function.............................. 187

City Safety – operation............................ 188

City Safety – limitations.......................... 188

City Safety – troubleshooting.................. 189

City Safety – symbols and messages..... 191

City Safety – Laser sensor...................... 192

Collision warning – introduction.............. 193

Collision warning* – function................... 195

Collision warning* – operation................ 196

Collision warning* – Cyclist detection..... 197

Collision warning* – Pedestrian detec-

tion.......................................................... 198

Contents

* Option/accessory, for more information, see Introduction.

Collision warning* – limitations............... 199

The camera’s limitations......................... 201

Collision warning – troubleshooting........ 202

Collision warning – symbols and mes-

sages....................................................... 204

Driver Alert System................................. 206

Driver Alert Control (DAC) – introduction 206

Driver Alert Control (DAC) – operation.... 207

Driver Alert Control (DAC) – function...... 207

Driver Alert Control (DAC) – limitations... 208 Driver Alert Control (DAC) – symbols and

messages................................................ 209

Lane Departure Warning (LDW) – intro-

duction.................................................... 211

Lane Departure Warning (LDW) – opera-

tion.......................................................... 211

Lane Departure Warning (LDW) - limita-

tions........................................................ 213

Lane Departure Warning (LDW) – sym-

bols and messages................................. 214

Park assist – introduction....................... 216

Park assist – function.............................. 216

Park assist – operation........................... 218

Park assist – limitations.......................... 219

Park assist – troubleshooting.................. 220

Rear Park Assist Camera (PAC) – intro-

duction.................................................... 220

Rear Park Assist Camera (PAC) – func-

tion.......................................................... 221

Rear Park Assist Camera (PAC) – opera-

tion.......................................................... 221

Rear Park Assist Camera (PAC) – guiding

and marker lines...................................... 222

Rear Park Assist Camera (PAC) – limita-

tions........................................................ 224

BLIS* – introduction................................ 224

BLIS* – function...................................... 225

BLIS* – operation.................................... 226

BLIS* – limitations................................... 226

BLIS* – messages................................... 227

08 Starting and driving

Starting the engine.................................. 230

Switching off the engine......................... 232

Engine Remote Start (ERS)* – introduc-

tion.......................................................... 232

Engine Remote Start (ERS)* – starting the

engine..................................................... 233

Engine Remote Start (ERS)* – switching

off the engine.......................................... 233

Jump starting.......................................... 234

Transmission – general information........ 235

Transmission – positions........................ 235

Transmission – Geartronic...................... 237

Transmission – shiftlock override........... 239

Start/Stop – Hill Start Assist (HSA)......... 240

Start/Stop – introduction........................ 240

Start/Stop – function............................... 240

Start/Stop – Auto-stop exceptions......... 241

Start/Stop – Auto-start exceptions......... 242

Start/Stop – settings............................... 243

Start/Stop – symbols and messages...... 244

ECO*....................................................... 245

All Wheel Drive (AWD)............................. 247

Brakes – general..................................... 247

Brakes – symbols ................................... 249

Contents

Anti-lock braking system (ABS).............. 249

Brake lights............................................. 250

Emergency Brake Assistance (EBA)....... 250

Parking brake – general information....... 251

Parking brake – applying........................ 251

Parking brake – releasing........................ 252

Parking brake – symbols and messages 254

Driving through water.............................. 255

Engine and cooling system..................... 255

Conserving electrical current.................. 256

Before a long distance trip...................... 256

Driving in cold weather........................... 257

Refueling – fuel requirements................. 257

Refueling – octane rating........................ 258

Refueling – opening/closing fuel filler

door......................................................... 260

Refueling – opening/closing fuel cap...... 260

Emission controls – heated oxygen sen-

sors......................................................... 261

Economical driving.................................. 262

Towing a trailer....................................... 263

Trailer Stability Assist (TSA).................... 265

Towing the vehicle.................................. 265

Towing eyelet.......................................... 266

Towing by tow truck............................... 267

09 Wheels and tires

Tires – general information...................... 270

Tires – storage and age.......................... 271

Tires – tread wear indicator.................... 272

Tires – tire economy................................ 272

Changing a wheel – direction of rotation 273

Changing a wheel – removing wheel...... 273

Changing a wheel – spare wheel............ 275

Changing a wheel – taking out spare

wheel....................................................... 276

Changing a wheel – installing wheel....... 277

Tire inflation – general information.......... 277

Tire inflation – checking pressure........... 278

Tire specifications................................... 279

Tire inflation – pressure table.................. 282

Loading specifications............................ 283

Loading specifications – load limit.......... 283

Tire specifications – terminology............ 284

Tire specifications – Uniform Tire Quality

Grading................................................... 285

Snow chains............................................ 286

Snow tires/studded tires......................... 287

Tire pressure monitoring - introduction.. 287 Tire Pressure Monitoring System (TPMS)

– general information.............................. 288

Contents

* Option/accessory, for more information, see Introduction.

Tire Pressure Monitoring System (TPMS)

– changing wheels.................................. 289

Tire Pressure Monitoring System (TPMS)

– recalibrating......................................... 290

Tire Pressure Monitoring System (TPMS)

– activating/deactivating......................... 290

Tire Pressure Monitoring System (TPMS)

– messages............................................. 291

Tire Monitor - introduction...................... 292

Calibrating Tire Monitor.......................... 292

Tire Monitor status information............... 293

Tire Monitor – messages......................... 293

Self-supporting run flat tires (SST).......... 294

Tire sealing system* – general informa-

tion.......................................................... 295

Tire sealing system* – overview.............. 297

Tire sealing system* – sealing hole......... 298

Tire sealing system – checking inflation

pressure.................................................. 300

Tire sealing system* – inflating tires........ 300

Tire sealing system* – sealing compound

container................................................. 301

10 Maintenance and servicing

Maintenance – introduction.................... 303

Maintenance – owner maintenance........ 304

Maintenance – hoisting........................... 305

Onboard Diagnostic System................... 306

Booking service and repairs .................. 306

Maintenance – opening/closing hood..... 308

Engine compartment – overview............ 309

Engine compartment – engine oil........... 310

Engine compartment – coolant............... 312

Engine compartment – brake fluid.......... 313

Engine compartment – power steering

fluid......................................................... 314

Bulbs – introduction................................ 315

Bulbs – headlight housing....................... 316

Bulbs – cover.......................................... 317

Bulbs – low beam, Halogen.................... 317

Bulbs – high beam, Halogen................... 318

Bulbs – extra high beam......................... 318

Bulbs – front turn signals........................ 319

Bulbs – front side marker lights.............. 320

Bulbs – taillight housing.......................... 320

Bulbs – license plate lighting.................. 321

Bulbs – trunk lighting.............................. 322

Bulbs – vanity mirror lighting.................. 322

Bulbs – specifications............................. 322

Wiper blades – service position.............. 323

Wiper blades – windshield...................... 324

Engine compartment – washer fluid....... 325

Battery – symbols................................... 325

Battery – handling................................... 326

Battery – maintenance............................ 327

Battery – changing.................................. 328

Fuses – introduction............................... 329

Fuses – engine compartment................. 330

Fuses – glove compartment................... 334

Fuses – cargo area/trunk........................ 337

Fuses – engine compartment cold zone

(Start/Stop only)...................................... 338

Washing the car...................................... 340

Automatic car wash................................ 341

Polishing and waxing.............................. 341

Cleaning the interior................................ 342

Touching up paintwork........................... 344

Contents

11 Specifications

Label information.................................... 346

Dimensions............................................. 349

Weights................................................... 351

Engine specifications.............................. 352

Oil specifications..................................... 354

Oil volume............................................... 355

Coolant – specification and volume........ 356

Transmission oil – specification and vol-

umes....................................................... 356

Brake fluid – specification and volume... 356

Power steering – specification................ 357

Washer fluid – specification and volume 357 Fuel tank volume – specification and vol-

ume......................................................... 357

Air conditioning – specification and vol-

ume......................................................... 358

Battery specifications............................. 359

Symbols – general information............... 360

Warning symbols.................................... 360

Indicator symbols.................................... 361

Information symbols............................... 362

Information symbols – ceiling console.... 363

Information symbols – center console.... 363

12 Index

Index....................................................... 364

I N T R O D U C T I O N

01 Introduction

}}

On-board owner's manual

The owner's manual can be displayed on the center console screen and you can carry out searches for the information that you require.

To open the owner's manual, press the MY CAR button on the center console, press OK/ MENU and select

Owner's manual.

For basic information, see "Infotainment operating the system." The following sections also provide more detailed information.

The on-board owner's manual start page

There are four ways of finding information articles in the on-board owner's manual:

•

Searching: search for an article.

•

Categories: All of the articles are sorted

by category.

•

Favorites: Quick access to frequently

read articles.

•

Quick Guide: A selection of articles cov-

ering commonly used functions.

Select the symbol in the lower right-hand corner for additional information about the onboard owner's manual.

NOTE

•

The on-board owner's manual cannot be accessed while the vehicle is moving.

•

Specifications regarding your vehicle are not found in the on-board information. This information is listed in the printed owner's manual.

Searching for information

Searching using the text wheel

List of characters

Switching between character entry modes (see the following table)

Surf history

Use the text wheel to enter a web address.

1. Turn TUNE to the desired letter and press OK/MENU to confirm. The number/letter keys on the center console can also be used.

2. Continue to the next letter, etc. The results of the search will be displayed in the phone book.

01 Introduction

3. To switch from letter entry mode to the entry mode for numbers or special characters, or to go view surf history, turn TUNE to one of the selections (see the explanation in the following table) in the list for switching character entry mode (2) and press OK/MENU.

123/A BC

Toggle between letters and numbers by pressing OK/MENU.

This leads to surf history. Turn TUNE to select a web address and press OK/MENU to go to the website.

Go to the website by pressing

OK/MENU.

a|A

Toggle between upper and lower case letters by pressing OK/ MENU.

| | }

Switch from the text wheel to the

Address: field. Use TUNE to

move the cursor and erase characters by pressing EXIT. Press OK/MENU to return to the text wheel.

The number/letter keys on the center console can also be used to edit the

Address: field.

Press EXIT briefly to erase a single character. Press and hold EXIT to erase all characters.

Pressing a number key on the center console while the text wheel is displayed (see the previous illustration) will display a list of characters. Press the desired key repeatedly to enter the desired letter and continue to the next letter, etc.

To enter a number, press and hold the button.

Favorites

Articles that have been marked as favorites can be found here. For information about marking an article as a favorite, see "Navigating in an article" below.

Turn TUNE to navigate in the list of favorites and press OK/MENU to open an article. Press EXIT to return to the previous view.

Quick Guide

This is a selection of articles that will help you become familiar with some of the vehicle's most common functions. These articles can also be found in their respective categories but are listed here for quick access.

Turn TUNE to navigate in the Quick Guide and press OK/MENU to open an article. Press EXIT to return to the previous view.

Navigating in an article

Home: Returns you to the owner's man-

ual start page.

Favorites: Add/remove an article from the list of favorites. This can also be done by pressing the FAV button on the center console keypad.

Highlighted link: takes you to the linked article.

Important information: if the article contains warnings, cautions or notes, sym-

01 Introduction

bols for these types of information and the number of such texts in the article will be displayed here.

Turn TUNE to navigate among the links or scroll in an article. When you have scrolled to the beginning/end of an article, you can return to the start page or a favorite by scrolling one additional step up/down. Press OK/ MENU to activate a selection or highlighted link. Press EXIT to return to the previous view.

Related information

•

Information on the Internet (p. 20)

Owner's information

Your vehicle is equipped with a screen on which you can display information about your vehicle's features and functions. The printed owner's manual supplements the on-board information and contains important texts, the latest updates and instructions that can be useful in situations when it is not practical to read the information on the screen.

Changing the language used for the on-board information could mean that some of the information displayed may not comply with national or local statutes and regulations.

WARNING

The driver is always responsible for operating the vehicle in a safe manner and for complying with current statutes and regulations.

It is also essential to maintain and service the vehicle according to Volvo's recommendations as stated in the owner's information and the service and warranty booklet.

If the on-board information differs from the printed owner's manual, the printed information always takes precedence.

Contacting Volvo

In the USA:

Volvo Cars of North America, LLC

Customer Care Center

1 Volvo Drive,

P.O. Box 914

Rockleigh, New Jersey 07647

1-800-458-1552

www.volvocars.com/us

In Canada:

Volvo Cars of Canada

National Customer Service

9130 Leslie Street, Suite 101

Richmond Hill, Ontario L4B 0B9

1-800-663-8255

www.volvocars.com/ca

Related information

•

About this manual (p. 14)

•

Important warnings (p. 22)

•

Crash event data (p. 18)

•

Volvo Structural Parts Statement (p. 19)

01 Introduction

About this manual

Reading your owner's manual is a good way to familiarize yourself with the features and systems in your vehicle.

•

Before you operate your vehicle for the first time, we recommend that you look through the information found in the chapters "Your Driving Environment" and "During Your Trip."

•

Information contained in the balance of the manual is extremely useful and should be read after operating the vehicle for the first time.

•

The manual is structured so that it can be used for reference. For this reason, it should be kept in the vehicle for ready access.

On-board owner's manual

When the printed manual refers to the onboard owner's manual, this pertains to the information displayed on the center console screen.

There are four ways of finding information articles in the on-board owner's manual:

•

Searching: search for an article.

•

Categories: All of the articles are sorted

by category.

•

Favorites: Quick access to frequently

read articles.

•

Quick Guide: A selection of articles cov-

ering commonly used functions.

Select the symbol in the lower right-hand corner for additional information about the onboard owner's manual.

NOTE

•

The on-board owner's manual cannot be accessed while the vehicle is moving.

•

Specifications regarding your vehicle are not found in the on-board information. This information is listed in the printed owner's manual.

The owner's manual in mobile devices

NOTE

The owner's manual mobile app can be downloaded at www.volvocars.com.

The mobile app also contains videos and searchable content, and provides easy navigation between the various articles.

Footnotes

Certain pages of this manual contain information in the form of footnotes at the bottom of the page. This information supplements the text that the footnote number refers to (a letter is used if the footnote refers to text in a table).

Display texts

There are several displays in the driver’s field of vision that show messages generated by various systems and functions in the vehicle. These texts are indicated in the Owner’s Manual by being in slightly larger type than the surrounding text and are printed in gray, (for example:

Change doors unlock

setting).

Decals

There are various types of decals in the vehicle whose purpose is to provide important information in a clear and concise way. The importance of these decals is explained as follows, in descending order of importance.

01 Introduction

}}

Risk of injury

G031590

Black ISO symbols on a yellow warning background, white text/image on a black background. Decals of this type are used to indicate potential danger. Ignoring a warning of this type could result in serious injury or death.

Risk of damage to the vehicle

G031592

White ISO symbols and white text/image on a black or blue warning background and space for a message. If the information on decals of this type is ignored, damage to the vehicle could result.

Information

G031593

White ISO symbols and white text/image on a black background. These decals provide general information.

NOTE

The decals shown in the Owner’s Manual are examples only and are not intended to be reproductions of the decals actually used in the vehicle. The purpose is to give an indication of how they look and their approximate location in the vehicle. The applicable information for your particular vehicle can be found on the respective decals in the vehicle.

01 Introduction

Types of lists used in the owner's information

Procedures

Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual.

If there is a series of illustrations associated with step-by-step instructions, each step in the procedure is numbered in the same way as the corresponding illustration.

Lists in which letters are used can be found with series of illustrations in cases where the order in which the instructions are carried out is not important.

Arrows with or without numbers are used to indicate the direction of a movement.

Arrows containing letters are used to indicate movement.

If there are no illustrations associated with a step-by-step list, the steps in the procedure are indicated by ordinary numbers.

Position lists

Red circles containing a number are used in general overview illustrations in which certain components are pointed out. The corresponding number is also used in the position list's description of the various components.

Bullet lists

Bullets are used to differentiate a number of components/functions/points of information that can be listed in random order.

For example:

•

Coolant

•

Engine oil

Continues on next page

} }This symbol can be found at the lower

right corner to indicate that the current topic continues on the following page.

Continuation from previous page

|| This symbol can be found at the upper left

corner to indicate that the current topic is a continuation from the previous page.

Options and accessories

Optional or accessory equipment described in this manual is indicated by an asterisk.

Optional or accessory equipment may not be available in all countries or markets. Please note that some vehicles may be equipped differently, depending on special legal requirements.

Contact your Volvo retailer for additional information.

NOTE

•

All information, illustrations and specifications contained in this owner's information are based on the latest product information available at the time of publication.

•

Volvo reserves the right to make model changes at any time, or to change specifications or design without notice and without incurring obligation.

•

Do not export your Volvo to another country before investigating that country's applicable safety and emission control requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.

WARNING

If your vehicle is involved in an accident, unseen damage may affect its drivability and safety.

01 Introduction

WARNING

CALIFORNIA proposition 65

Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the state of California to cause cancer, and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.

WARNING

Certain components of this vehicle such as air bag modules, seat belt pretensioners, adaptive steering columns, and button cell batteries may contain Perchlorate material. Special handling may apply for service or vehicle end of life disposal.

See www.dtsc.ca.gov/hazardouswaste/ perchlorate.

Shiftlock

When your vehicle is parked, the gear selector is locked in the P (Park) position. To release the selector from this position, the ignition must be in mode II (p. 73) or the engine must be running. Depress the brake pedal, press the button on the front side of the gear selector and move the selector from

P (Park).

Anti-lock Brake System (ABS)

The ABS system performs a brief self-diagnostic test when the engine has been started and driver releases the brake pedal. Another automatic test may be performed when the vehicle first reaches a speed of approximately 6 mph (10 km/h). The brake pedal will pulsate several times and a sound may be audible from the ABS control module. This is normal.

Fuel filler door

Press the button on the light switch panel (see the illustration in Refueling – opening/ closing fuel filler door (p. 260)) when the vehicle is at a standstill to unlock the fuel filler door. It will relock when closed and there will be an audible click.

Points to keep in mind

•

Do not export your Volvo to another country before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.

•

All information, illustrations and specifications contained in this manual are based on the latest product information available at the time of publication. Please note that some vehicles may be equipped differently, depending on special legal

requirements. Optional equipment described in this manual may not be available in all markets.

•

Some of the illustrations shown are generic and may not depict the exact model for which this manual is intended.

•

Volvo reserves the right to make model changes at any time, or to change specifications or design without notice and without incurring obligation.

Related information

•

Information on the Internet (p. 20)

•

Volvo and the environment (p. 21)

•

Important warnings (p. 22)

01 Introduction

Change of ownership

When the vehicle changes owners, all personal settings should be reset to the factory defaults.

To reset, press the MY CAR button in the center console followed by OK/MENU and

select

Settings Reset to factory settings.

User data e.g., for apps, the web browser and for personal settings in menus such as the climate system and vehicle settings should be reset to factory defaults.

For vehicles equipped with the optional Volvo On Call with Sensus Connect (VOC), personal settings stored in the vehicle should be deleted, see Changing ownership of a vehicle with Volvo On Call.

Related information

•

Volvo ID (p. 20)

Crash event data

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:

•

How various systems in your vehicle were operating;

•

Whether or not the driver and passenger safety belts were buckled/fastened;

•

How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,

•

How fast the vehicle was traveling.

These data can help provide a better understanding of the circumstances in which crashes and injuries occur.

NOTE

EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.

To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

Furthermore, your vehicle is equipped with a number of computers whose task is to continuously control and monitor the vehicle’s operation. They can also register information during normal driving conditions if they detect a fault relating to the vehicle’s operation and functionality. Some of the stored information is required by technicians when carrying out service and maintenance to enable them to diagnose and rectify any faults that have occurred in the vehicle and to enable Volvo to fulfill legal and other regulatory requirements. This information may be stored in the vehicle’s computers for a certain period of time.

01 Introduction

}}

Volvo will not contribute to spreading the above-mentioned information to third parties without the consent of the vehicle’s owner. However, due to national legal requirements and regulations, Volvo may be compelled to provide information of this type to authorities such as law enforcement agencies or others who may assert a legal right to obtain such information.

Volvo and service and repair facilities with agreements with Volvo have access to the special technical equipment required in order to read and interpret the information stored by the vehicle’s computers. Volvo is responsible for ensuring that the information transmitted to Volvo during service and maintenance is stored and handled in a secure manner and that this handling is done in accordance with applicable legal requirements. For additional information, contact:

For additional information, contact:

In the United States

Volvo Cars of North America, LLC

Customer Care Center

1 Volvo Drive, P.O. box 914

Rockleigh, New Jersey 07647

1-800-458-1552

www.volvocars.com/us

In Canada

Volvo Cars of Canada

National Customer Service

9130 Leslie Street

Richmond Hill, Ontario L4B 0B9

1-800-663-8255

www.volvocars.com/ca

Related information

•

Information on the Internet (p. 20)

•

Contacting Volvo (p. 13)

Volvo Structural Parts Statement

Volvo has always been and continues to be a leader in automotive safety.

Volvo engineers and manufactures vehicles designed to help protect vehicle occupants in the event of a collision.

Volvos are designed to absorb the impact of a collision. This energy absorption system including, but not limited to, structural components such as bumper reinforcement bars, bumper energy absorbers, frames, rails, fender aprons, A-pillars, B-pillars and body panels must work together to maintain cabin integrity and protect the vehicle occupants.

The supplemental restraint system including but not limited to air bags, side curtain air bags, and deployment sensors work together with the above components to provide proper timing for air bag deployment.

Due to the above, Volvo Cars of North America does not support the use of aftermarket, alternative or anything other than original Volvo parts for collision repair.

In addition Volvo does not support the use or re-use of structural components from an existing vehicle that has been previously damaged. Although these parts may appear equivalent, it is difficult to tell if the parts have been previously replaced with non-OE parts or if the part has been damaged as a result of a prior collision. The quality of these used

01 Introduction

* Option/accessory, for more information, see Introduction.

parts may also have been affected due to environmental exposure.

Related information

•

Important warnings (p. 22)

•

Information on the Internet (p. 20)

•

Contacting Volvo (p. 13)

Information on the Internet

Additional information regarding your vehicle can be found at www.volvocars.com.

In order to read a QR code, a QR reader is necessary, which is available as an app for a number of different cell phones and can be downloaded from the App Store or Google Play.

QR code

Related information

•

About this manual (p. 14)

•

Contacting Volvo (p. 13)

Volvo ID

This is your personal ID that can be used to access a number of services

Creating a Volvo ID

To create a Volvo ID, provide your personal email address and then follow the instructions provided in the email that you will receive from Volvo. This can be done from:

•

From an Internet-connected vehicle: Enter your email address in the app that requires a Volvo ID and follow the instructions provides or press the Internet con-

nect (

) button on the center console

and select

Apps, Settings and follow the

instructions provided.

•

Volvo On Call (VOC*): download the latest version of the VOC app and create a Volvo ID on the start page.

These services vary and may be subject to change. Consult your Volvo retailer.

01 Introduction

}}

Open Source Software Notice

The systems in your Volvo contain certain free/open source and other software.

This product uses certain free / open source and other software originating from third parties, that is subject to the GNU General Public License version 2 and 3 (GPLv2/ GPLv3), GNU Lesser General Public License version 3 (LGPLv3), The FreeType Project License (“FreeType License”) and other different and/or additional copyright licenses, disclaimers and notices. The links how to access the exact terms of GPLv2, GPLv3, LGPLv3, and the other open source software licenses, disclaimers, acknowledgements and notices are provided to you below. Please refer to the exact terms of the relevant License, regarding your rights under said licenses. Volvo Car Corporation (VCC) offers to provide the source code of said free/open source software to you for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling, upon written request. Please contact your nearest Volvo retailer.

This offer is valid for a period of at least three (3) years from the date of the distribution of this product by VCC / or for as long as VCC offers spare parts or customer support.

This product includes software under following licenses:

GPL v2 : http://www.gnu.org/licenses/oldlicenses/gpl-2.0.html

•

Linux kernel (merge between MontaVista

2.6.31 kernel and kernel from L2.6.31_MX51_ER_1007 BSP)

•

uBoot (based on v2009.08)

•

busybox (based on version 1.13.2.)

GCC runtime library exception: http:// www.gnu.org/licenses/gcc-exception.html

•

libgcc_s.so.1

LGPL v3: http://www.gnu.org/licenses/ lgpl.html

•

Libc.so.6, libpthread.so.0, Librt.so.1

The FreeType Project License: http:// www.freetype.org/FTL.TXT

•

libfreetype.so.6 (version 2.4.3)

Related information

•

About this manual (p. 14)

Volvo and the environment

Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Concern for the environment means an everyday involvement in reducing our environmental impact.

Volvo's environmental activities are based on a holistic view, which means we consider the overall environmental impact of a product throughout its complete life cycle. In this context, design, production, product use, and recycling are all important considerations. In production, Volvo has partly or completely phased out several chemicals including CFCs, lead chromates, asbestos, and cadmium; and reduced the number of chemicals used in our plants 50% since 1991.

Volvo was the first in the world to introduce into production a three-way catalytic converter with a Lambda sond, now called the heated oxygen sensor, in 1976. The current version of this highly efficient system reduces emissions of harmful substances (CO, HC, NOx) from the exhaust pipe by approximately 95 – 99% and the search to eliminate the remaining emissions continues. Volvo is the only automobile manufacturer to offer CFCfree retrofit kits for the air conditioning system of all models as far back as the 1975 model 240. Advanced electronic engine controls and cleaner fuels are bringing us closer to our goal. In addition to continuous environ-

01 Introduction

mental refinement of conventional gasolinepowered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles.

When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment. To reduce your vehicle's environmental impact, you can:

•

Maintain proper air pressure in your tires. Tests have shown decreased fuel economy with improperly inflated tires.

•

Follow the recommended maintenance schedule in your Warranty and Service Records Information booklet.

•

Drive at a constant speed whenever possible.

•

See a trained and qualified Volvo service technician as soon as possible for inspection if the check engine (malfunction indicator) light illuminates, or stays on after the vehicle has started.

•

Properly dispose of any vehicle-related waste such as used motor oil, used batteries, brake pads, etc.

•

When cleaning your vehicle, please use genuine Volvo car care products. All Volvo car care products are formulated to be environmentally friendly.

FSC

The FSC® (Forest Stewardship Council®) symbol indicates that the wood pulp used in this publication comes from FSC® certified forests and other responsible sources.

Related information

•

Economical driving (p. 262)

•

Tires – tire economy (p. 272)

Important warnings

Please keep the following warnings in mind when operating/servicing your vehicle.

Driver distraction

A driver has a responsibility to do everything possible to ensure his or her own safety and the safety of passengers in the vehicle and others sharing the roadway. Avoiding distractions is part of that responsibility.

Driver distraction results from driver activities that are not directly related to controlling the vehicle in the driving environment. Your new Volvo is, or can be, equipped with many feature-rich entertainment and communication systems. These include hands-free cellular telephones, navigation systems, and multipurpose audio systems. You may also own other portable electronic devices for your own convenience. When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction.

For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety. Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely. Distraction can lead to a serious accident. In addition to this general warning, we offer the following guidance regarding specific newer features that may be found in your vehicle:

01 Introduction

•

Never use a hand-held cellular telephone while driving. Some jurisdictions prohibit cellular telephone use by a driver while the vehicle is moving.

•

If your vehicle is equipped with a navigation system, set and make changes to your travel itinerary only with the vehicle parked.

•

Never program your audio system while the vehicle is moving. Program radio presets with the vehicle parked, and use your programmed presets to make radio use quicker and simpler.

•

Never use portable computers or personal digital assistants while the vehicle is moving.

Accessory installation

•

We strongly recommend that Volvo owners install only genuine, Volvo-approved accessories, and that accessory installations be performed only by a trained and qualified Volvo service technician.

•

Genuine Volvo accessories are tested to ensure compatibility with the performance, safety, and emission systems in your vehicle. Additionally, a trained and qualified Volvo service technician knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult a trained and qualified Volvo service technician before installing any accessory in or on your vehicle.

•

Accessories that have not been approved by Volvo may or may not be specifically tested for compatibility with your vehicle. Additionally, an inexperienced installer may not be familiar with some of your car's systems.

•

Any of your car's performance and safety systems could be adversely affected if you install accessories that Volvo has not tested, or if you allow accessories to be installed by someone unfamiliar with your vehicle.

•

Damage caused by unapproved or improperly installed accessories may not be covered by your new vehicle warranty. See your Warranty and Service Records Information booklet for more warranty information. Volvo assumes no responsibility for death, injury, or expenses that may result from the installation of nongenuine accessories.

Related information

•

About this manual (p. 14)

•

Volvo Structural Parts Statement (p. 19)

Volvo On Call Roadside Assistance

Your new Volvo comes with a four year ON CALL roadside assistance.

Additional information, features, and benefits of this program are described in a separate information package in your glove compartment.

If you require assistance, dial:

In the U.S. 1-800-638-6586 (1-800-63VOLVO)

In Canada 1-800-263-0475

NOTE

Some vehicles may be equipped with Volvo On Call with Sensus Connect, which will allow access to the call center and additional features directly from the vehicle. This is in addition to the Volvo On Call Roadside Assistance program mentioned above.

Volvo On Call with Sensus Connect will be a customer pay subscription offer after an initial complimentary trial period.

Related information

•

Information on the Internet (p. 20)

01 Introduction

Technician certification

In addition to Volvo factory training, Volvo supports certification by the National Institute for Automotive Service Excellence (A.S.E.).

Certified technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These professional technicians are best able to analyze vehicle problems and perform the necessary maintenance procedures to keep your Volvo at peak operating condition.

S A F E T Y

02 Safety

Occupant safety

Safety is Volvo's cornerstone.

Volvo's concern for safety

Our concern for safety dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo vehicles long before it was fashionable or required by government regulation.

We will not compromise our commitment to safety. We continue to seek out new safety features and to refine those already in our vehicles. You can help. We would appreciate hearing your suggestions about improving automobile safety. We also want to know if you ever have a safety concern with your vehicle. Call us in the U.S. at: 1-800-458-1552 or in Canada at: 1-800-663-8255.

Occupant safety reminders

How safely you drive doesn't depend on how old you are but rather on:

•

How well you see.

•

Your ability to concentrate.

•

How quickly you make decisions under stress to avoid an accident.

The following suggestions are intended to help you cope with the ever changing traffic environment.

•

Never drink and drive.

•

If you are taking any medication, consult your physician about its potential effects on your driving abilities.

•

Take a driver-retraining course.

•

Have your eyes checked regularly.

•

Keep your windshield and headlights clean.

•

Replace wiper blades when they start to leave streaks.

•

Take into account the traffic, road, and weather conditions, particularly with regard to stopping distance.

•

Never send text messages while driving.

•

Refrain from using or minimize the use of a cell phone while driving.

Related information

•

Recall information (p. 26)

•

Reporting safety defects (p. 27)

Recall information

Information regarding recalls or other service campaigns is available on our website at www.volvocars.com/us/.

On our website, select the tab YOUR VOLVO and the heading RECALL INFORMATION will be displayed at the lower left side of the screen. Enter your Vehicle Identification Number for your vehicle (found at the base of the windshield). If your vehicle has any open Recalls, they will be displayed on this page.

Volvo customers in Canada

For any questions regarding open recalls for your vehicle, please contact your authorized Volvo retailer. If your retailer is unable to answer your questions, please contact Volvo Customer Relations at 905 695-9626, Monday through Friday, 8:30 A.M. to 5:00 P.M. EST or by e-mail at vclcust@volvocars.com. You may also write us at:

Volvo Cars of Canada

National Customer Service

9130 Leslie Street, Suite 101

Richmond Hill, Ontario L4B 0B9

Related information

•

Occupant safety (p. 26)

•

Reporting safety defects (p. 27)

02 Safety

Reporting safety defects

The following information will help you report any perceived safety-related defects in your vehicle.

Reporting safety defects in the U.S.

If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Volvo Cars of North America, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America, LLC. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at

1-888-327-4236

(TTY: 1-800-424-9153) or write to: NHTSA, U.S. Department of Transportation, Washington D.C. 20590.

You can also obtain other information about motor vehicle safety from:

http://www.safercar.gov

Volvo strongly recommends that if your vehicle is covered under a service campaign, safety or emission recall or similar action, it should be completed as soon as possible. Please check with your local retailer or Volvo Cars of North America, LLC if your vehicle is covered under these conditions.

NHTSA can be reached at:

Internet:

http://www.nhtsa.gov

Telephone:

1-888-DASH-2-DOT (1-888-327-4236).

Reporting safety defects in Canada

If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans-

port Canada in addition to notifying Volvo Cars of Canada Corp.

Transport Canada can be contacted at:

1-800-333-0510

Teletypewriter (TTY): 613 990-4500

Fax: 1-819-994-3372

Mailing Address: Transport Canada - Road Safety, 80 rue Noël, Gatineau, (Quebec) J8Z 0A1

Related information

•

Occupant safety (p. 26)

•

Recall information (p. 26)

02 Safety

Seat belts – general

Seat belts should always be worn by all occupants of your vehicle. Children should be properly restrained, using an infant, car, or booster seat determined by age, weight and height.

Volvo also believes no child should sit in the front seat of a vehicle.

Adjusting the seat belt

Most states and provinces make it mandatory for occupants of a vehicle to use seat belts.

Seat belt pretensioners

All seat belts are equipped with pretensioners that reduce slack in the belts. These pretensioners are triggered in situations where the front or side impact airbags deploy, and in certain impacts from the rear. The front seat belts also include a tension reducing device which, in the event of a collision, limits the

peak forces exerted by the seat belt on the occupant.

Seat belt maintenance

Check periodically that the seat belts are in good condition. Use water and a mild detergent for cleaning. Check seat belt mechanism function as follows: attach the seat belt and pull rapidly on the strap.

WARNING

Never use a seat belt for more than one occupant. Never wear the shoulder portion of the belt under the arm, behind the back or otherwise out of position. Such use could cause injury in the event of an accident. As seat belts lose much of their strength when exposed to violent stretching, they should be replaced after any collision, even if they appear to be undamaged.

WARNING

•

Never repair the belt yourself; have this work done by a trained and qualified Volvo service technician only.

•

Any device used to induce slack into the shoulder belt portion of the threepoint belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.

•

The seat back should not be tilted too far back. The shoulder belt must be taut in order to function properly.

•

Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children who have outgrown these devices sit in the rear seat with the seat belt properly fastened.

Related information

•

Seat belts – buckling/unbuckling (p. 29)

•

Seat belt reminder (p. 30)

•

Seat belts – pregnancy (p. 30)

+ 346 hidden pages
