Volvo S70 2000 User Manual

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

This manual deals with the operation and care of your Volvo.

Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts at all times in this (or any other) automobile. And, of course, please do not operate a vehicle if you may be affected by alcohol, medication or any impairment that could hinder your ability to drive.

Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels attached to the driver's door opening and on the left wheel housing in the engine compartment.

For further information please contact your retailer, or:

In the USA: In Canada:

Volvo Cars of North America Volvo Canada Ltd.

Customer Relations 175 Gordon Baker Road

P.O. Box 914 Willowdale, Ontario M2H 2N7

Rockleigh, New Jersey 07647-0914 800-663-8255

file:///K|/ownersdocs/2000/2000_SV70/00sv70_00.htm (1 of 6)12/30/2006 3:43:31 PM

2000 Volvo S & V70

800-458-1552 We also invite you to visit our Home Page on the Internet at:

http://www.volvocars.com

Contents

Chapter 1 - Occupant safety Chapter 2 - Instruments, switches and controls Chapter 3 - Body and interior Chapter 4 - Starting and driving Chapter 5 - Wheels and tires Chapter 6 - In case of an emergency Chapter 7 - Car care Chapter 8 - Volvo Service Chapter 9 - Specifications Chapter 10 - Audio systems HomeLink® Universal Transceiver (option) Index

General information

Important

Before you operate your car for the first time, please familiarize yourself with the BREAK-IN information on page 66. You should also be familiar with the information in the first three

file:///K|/ownersdocs/2000/2000_SV70/00sv70_00.htm (2 of 6)12/30/2006 3:43:31 PM

2000 Volvo S & V70

chapters of this manual.

Information contained in the balance of the manual is extremely useful and should be read after operating the vehicle for the first time.

The manual is structured so that it can be used for reference. For this reason, it should be kept in the car for ready access.

Do not export your Volvo to another country before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.

All information, illustrations and specifications contained in this manual are based on the latest product information available at the time of publication. Please note that some vehicles may be equipped differently, depending on special legal requirments and that optional equipment described in this manual may not be available in all markets.

Volvo reserves the right to make model changes at any time, or to change specifications or design, without notice and without incurring obligation.

CAUTION: Certain models have reduced ground clearance due to the design of the front spoiler. Please

observe caution when e.g., driving onto garage hoists, through drifted snow or when other road debris is encountered, or when parking near curbs.

Shiftlock (automatic transmission only)

When your car is parked, the gear selector is locked in the (P)ark position. To release the selector from this position, turn the ignition key to position II (or start the engine), depress the brake pedal, press the button on the front side of the gear selector and move the selector from (P)ark.

If it is necessary to manually override the shiftlock system:

· Turn the starting (ignition) key to position I

· Press firmly on the "SHIFTLOCK OVERRIDE" button located to the right of the base of the gear selector

· While holding the override button down, press the button on the front of the gear selector

· Move the selector from the (P)ark position.

Keylock (automatic transmission only)

file:///K|/ownersdocs/2000/2000_SV70/00sv70_00.htm (3 of 6)12/30/2006 3:43:31 PM

2000 Volvo S & V70

This means that when you switch off the ignition, the gear selector must be in the (P)ark position before the starting (ignition) key can be removed from the ignition switch.

Clutch interlock (manual transmission only)

The clutch must be fully depressed before you can start you car. If the clutch is not depressed, it will not be possible to start the engine.

Anti-lock Brake System (ABS)

The ABS system in your car performs a self-diagnostic test when the vehicle first reaches the speed of approximately 12 mph (20 km/h). The brake pedal will pulsate several times and a sound may be audible from the ABS control module. This is normal.

Fuel tank cover

The fuel tank cover is locked and must be popped open using the control on the driver's door (see illustration on

page 16).

Volvo and the environment

Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.

Volvo's environmental activities are based on a holistic view, which means we consider the overall environmental impact of a product throughout its complete life cycle. In this context, design, production, product use, and recycling are all important considerations.

In production, Volvo has partly or completely phased out several chemicals including freons, lead chromates, naphtanates, asbestos, mercury and cadmium; and reduced the amount of chemicals used in our plants 50% since 1991.

In use, Volvo was the first in the world to introduce into production a three-way catalytic converter with a Lambda sond, now called oxygen sensor, in 1976. The current version of this highly efficient system reduces emissions of harmful substances (CO, HC, NOx) from the exhaust pipe by approximately 95% and the search to eliminate the remaining emissions continues. Volvo is the only automobile manufacturer to offer CFC-free retrofit kits for the air conditioning system for all models as far back as the M/Y 1975 240. Advanced electronic engine controls, refined purification systems and cleaner fuels

file:///K|/ownersdocs/2000/2000_SV70/00sv70_00.htm (4 of 6)12/30/2006 3:43:31 PM

2000 Volvo S & V70

are bringing us closer to our goal.

After Volvo cars and parts have fulfilled their use, recycling is the next critical step in completing the life cycle. The metal content is about 75% of the total weight of a car, which makes the car among the most recycled industrial products. In order to have efficient and well controlled recycling, many Volvo variants have printed dismantling manuals, indicating the weight and material of individual components. For Volvo, all homogeneous plastic parts weighing more than 1.7 oz. (50 grams) are marked with international symbols that indicate how the component is to be sorted for recycling.

In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles.

When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment.

To reduce your vehicle's environmental impact, you can:

· Maintain proper air pressure in your tires. Tests have shown decreased fuel economy with improperly inflated tires

· Follow the recommended maintenance schedule

· Drive at a constant speed

· See an authorized Volvo retailer as soon as possible for inspection if the check engine (malfunction indicator) lamp illuminates, or stays on after the vehicle has started

· Properly dispose of any vehicle related waste such as used motor oil, used batteries, brake pads, etc.

· When cleaning your car, use Volvo's own car care products, all of which have systematically been adapted to the environment

For additional information regarding the environmental activities in

which Volvo Cars of North America, Inc. and Volvo Car Corporation are involved, visit our Internet Home Page at:

http://www.volvocars.com

Three-way catalytic converter

file:///K|/ownersdocs/2000/2000_SV70/00sv70_00.htm (5 of 6)12/30/2006 3:43:31 PM

2000 Volvo S & V70

Three-way catalytic converter cautions

· Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three-way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating conditions, such as engine overheating or backfiring. A properly tuned engine will help avoid malfunctions that could damage the three-way catalytic converter.

· Do not park your car over combustible materials, such as grass or leaves, which can come into contact with the hot exhaust system and cause such materials to ignite under certain wind and weather conditions.

· Excessive starter cranking (in excess of one minute), with an intermittently firing or flooded engine, can cause three-way catalytic converter or exhaust system overheating.

· Remember that tampering or unauthorized modifications to the engine or the vehicle may be illegal and can cause three-way catalytic converter or exhaust system overheating. This includes:

- Altering fuel injection setting or components.

- Altering emission system components or location or removing components.

- Repeated use of leaded fuel.

NOTE: Unleaded fuel is required for cars with three-way catalytic converters.

Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_00.htm (6 of 6)12/30/2006 3:43:31 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

Chapter 1 - Occupant safety

pg. 1 Occupant safety

Despite our strongest recommendations, and your best intentions, not wearing a seat belt is like believing "It'll never happen to me!". Volvo, the inventor of the three-point seat belt, urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height. Volvo also believes no child should sit in the front seat of a car.

Fact: In every state and province, some type of child-restraint legislation has been passed. Additionally, most states and provinces have already made it mandatory for occupants of a car to use seat belts.

So, urging you to "buckle up" is not just our recommendation - legislation in your state or province may mandate seat belt usage. The few seconds it takes to buckle up may one day allow you to say, "It's a good thing I was wearing my seat belt".

Seat belts 2

Volvo SRS 4

Side Impact Protection System - (SIPS) air bag 8

Whiplash Protection System (WHIPS) 9

Child safety 10

Occupant safety 16

Reporting Safety Defects 16

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (1 of 14)12/30/2006 3:43:32 PM

2000 Volvo S & V70

pg. 2 Seat belts

Seat belts

Always fasten the seat belts before you drive or ride.

Two lights above the rear view mirror will be illuminated for 4-8 seconds after the starting

(ignition) key is turned to the driving position. A chime will sound at the same time if the

driver has not fastened his seat belt. The rear seats are provided with self- retracting inertia

reel belts. The front seats are provided with single roller belts with tensioners.

To buckle:

Pull the belt out far enough to insert the latch plate into the receptacle (buckle for rear seats)

until a distinct snapping sound is heard. The seat belt retractor is normally "unlocked" and

you can move freely, provided that the shoulder belt is not pulled out too far. The retractor will lock up as follows:

· if the belt is pulled out rapidly

· during braking and acceleration

· if the vehicle is leaning excessively

· when driving in turns

For the seat belt to provide maximum protection in the event of an accident, it must be worn correctly. When wearing the seat belt remember:

· The belt should not be twisted or turned.

· The lap belt must be positioned low on the hips (not pressing against the abdomen).

· The shoulder section of the front seat belts adjusts automatically to the driver's height.

Make sure that the shoulder belt is rolled up into its retractor and that the shoulder and lap

belts are taut.

Before exiting the car, check that the seat belt retracts fully after being unbuckled. If necessary, guide the belt back into the retractor slot.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (2 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

NOTE: Legislation in your state or province may mandate seat belt usage.

Adjusting the shoulder belt

Lap portion of the seat belt should sit low

WARNING! Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision. The seat back should not be tilted too far back. The shoulder belt must be taut in order to function properly.

Spool-out

To make child seat installation easier, each seat belt buckle (except for the driver's belt) is equipped with a locking mechanism to help keep the lap section of the seat belt taut. Please refer to page 13 for more information on this function.

WARNING! Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children who have outgrown these devices sit in the rear seat with the seat belt properly fastened.

pg. 3 Seat belts, Center head restraint

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (3 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

During pregnancy

Pregnant women should always wear seat belts. Remember that the belt should always be positioned in such a way as to avoid any possible pressure on the abdomen. The lap portion of the belt should be located low, as shown in the above illustration.

WARNING! Never use a seat belt for more than one occupant. Never wear the shoulder

portion of the belt under the arm, behind the back or otherwise out of position. Such use could cause injury in the event of an accident. As the seat belts lose much of their strength when exposed to violent stretching, they should be replaced after any collision, even if they appear to be undamaged. Never repair the belt on your own; have this work done by an authorized Volvo retailer only.

Center head restraint

The center head restraint can be adjusted according to the passenger's height. The restraint should be carefully adjusted to support the occupant's head.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (4 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

To raise: Pull straight up

To lower: Pull forward and push down

pg. 4 Volvo SRS

Passenger side SRS hatch

As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.

The SRS system is indicated by the "SRS" embossed on the steering wheel pad and above the glove compartment, and by decals on both sun visors and on the far right side of the dash.

The airbags are folded and located in the steering wheel hub and above the glove compartment. They are designed to deploy during certain frontal or front-angular collisions, impacts, or decelerations, depending on the crash severity, angle, speed and object impacted. The airbags may also deploy in certain non-frontal collisions where rapid deceleration occurs.

The airbag system includes gas generators (1) surrounded by the airbags (2) and front seat belt tensioners for both of the front seats (4). To deploy the system, the sensor (3) activates the gas generators causing the airbags to be inflated with nitrogen gas. As the movement of the seats' occupants compresses the airbags, some of the gas is expelled at a controlled rate to provide better cushioning. Both seat belt tensioners also deploy, minimizing any seat belt slack.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (5 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

The entire process, including inflation and deflation of the airbags, takes approximately two-tenths of a second.

WARNING!

· As its name implies, SRS is designed to be a SUPPLEMENT to - not a replacement for - the threepoint belt system. For maximum protection, wear seat belts at all times. Be aware that no system can prevent all possible injuries that may occur in an accident.

· When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible.

pg. 5 Volvo SRS

A self-diagnostic system incorporated in the sensor monitors the SRS. If a fault is detected, the "SRS" warning light will illuminate. The light is included in the warning/indicator light cluster in the instrument panel. Normally, the SRS warning lamp should light up when the ignition is switched on and should go out after 5 seconds or when the engine is started. Check that this light is functioning properly every time the car is started.

The following items are monitored by the self-diagnostic system:

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (6 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

· Sensor unit

· Cable harness

· Gas generator igniters

WARNING!

Never drive an SRS equipped car with your hands on the steering wheel pad / airbag housing.

No objects, accessory equipment or stickers may be placed on, attached to or installed near the SRS cover in the center of the steering wheel, the SRS cover above the glove compartment or the area affected by airbag deployment.

If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo retailer for inspection as soon as possible.

The above is a sample of the label found on all seat belts equipped with tensioners, located on the front seat belts near the lower anchorage point.

The above is a sample of the decal which can be found on the driver's door pillar.

There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (7 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

airbags and seatbelt tensioners. This service must be performed by an authorized Volvo retailer.

Should you have any questions about the SRS system, please contact

your authorized Volvo retailer or Volvo Customer Support:

Customer Relations

In the USA: In Canada: Volvo Cars of North America Volvo Canada Ltd. 175 Gordon Baker Road P.O. Box 914 Willowdale, Ontario M2H 2N7 Rockleigh, New Jersey 07647-

0914

800-663-8255

800-458-1552

pg. 6 Volvo SRS

SRS texts on inside of both sun visors

SRS texts on outside of both sun visors

SRS texts on the passenger's dash

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (8 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

SRS text at far right of instrument panel

NOTE: Deployment of SRS components occurs only one time during an accident. In a collision where deployment occurs, the air bags and seat belt tensioners activate. Some noise occurs and a small amount of powder is released. The release of the powder may appear as smoke-like matter. This is a normal characteristic and does not indicate fire.

NOTE: NOTE: Volvo's dual-threshold air bags use special sensors that are integrated with the front seat buckles. The point at which the air bag deploys is determined by whether or not the seat belt is being used, as well as, the severity of the collision. Collisions can occur where only one of the airbags deploys.

WARNING!

· Children must never be allowed in the front passenger seat. Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a front passenger side airbag. See page 12 for guidelines.

· Occupants in the front passenger's seat must never sit on the edge of the seat, sit leaning toward the instrument panel or otherwise sit out of position. The occupant's back must be as upright as comfort allows and be against the seat back with the seat belt properly fastened.

· Feet must be on the floor, e.g. not on the dash, seat or out of the window.

· No objects or accessory equipment, e.g. dash covers, may be placed on, attached to or installed near the SRS hatch (the area above the glove compartment) or the area affected by airbag deployment (see illustration).

· There should be no loose articles, e.g. coffee cups, on the floor, seat or dash area.

· Never try to open the SRS cover on the steering wheel or the passenger side SRS seam. This should only be done by an authorized Volvo service technician.

· Failure to follow these instructions can result in injury to the vehicle occupants in an accident.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (9 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

pg. 7 Volvo SRS

NOTE: The information on this page does not pertain to the Side Impact Protection System airbags.

When are the airbags deployed?The SRS system is designed to deploy during certain frontal or

frontangular collisions, impacts, or decelerations, depending on the crash severity, angle, speed and object impacted. The SRS sensor is designed to react to both the impact of the collision and the inertial forces generated by it and to determine if the intensity of the collision is sufficient for the airbags to be deployed.

WARNING! The SRS is designed to help prevent serious injury. Deployment occurs very quickly and with considerable force. During normal deployment and depending on variables such as seating position, one may experience abrasions, bruises, swellings, or other injuries as a result of airbag(s) deployment.

If the airbags have been deployed, we recommend the following:

· Have the car towed to an authorized Volvo retailer. Never drive with the airbags deployed.

· Have an authorized Volvo retailer replace the SRS system components.

· Use only new, Genuine Volvo Parts when replacing SRS components (airbags, seat belts, tensioners, etc.).

When are the airbags NOT deployed?

Not all frontal collisions activate the SRS system. If the collision involves a nonrigid object (e.g., a snow drift or bush), or a rigid, fixed object at a low speed, the SRS system will not necessarily deploy. Front airbags do not normally deploy in a side impact collision, in a collision from the rear or in a rollover situation. The amount of damage to the bodywork does not reliably indicate if the airbags should have deployed or not.

Seat belts the heart of the Volvo safety system

The heart of the Volvo safety system is the threepoint seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.

The SRS system is a supplement to the seat belts.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (10 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

WARNING! If your car has been subjected to flood conditions (e.g. soaked carpeting/standing water on the floor of the vehicle) or if your car has become flooddamaged in any way, do not attempt to start the vehicle or put the key in the ignition before disconnecting the battery (see below). This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.

Automatic transmission only:

Before attempting to tow the car, use the following procedure to override the shiftlock system to move the gear selector to the neutral position.

· Disconnect the battery

· Wait at least one minute

· Insert the key in the ignition and turn it to position 1

· Press firmly on the shiftlock override button (located near the base of the gear selector).

· While holding the override button down, move the gear selector from the park position.

WARNING! Never drive with the airbags deployed. The fact that they hang out can impair the steering of your car. Other safety systems can also be damaged. The smoke and dust formed when the airbags are deployed can cause skin and eye irritation in the event of prolonged exposure.

pg. 8 Volvo Side Impact Protection System (SIPS) airbag

1 - Airbag, 2 - cable, 3 - sensor unit,

SIPS airbag

As an enhancement to the structural Side Impact Protection System built into your car, the car is also equipped with Side Impact Protection System (SIPS) airbags. The SIPS airbag system consists of airbag modules built into the sides of both front seat backrests (1), cables (2) from these modules to the electronic sensor units (3).

The SIPS airbag system is designed to help increase occupant protection in the event of certain side

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (11 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

impact collisions. The SIPS airbags are designed to deploy only during certain sideimpact collisions, depending on the crash severity, angle, speed and point of impact. The airbags are not designed to deploy in all side impact situations.

NOTE: SIPS airbag deployment (one airbag) occurs only on the side of the vehicle affected by the impact.

WARNING!

· The SIPS airbag system is a supplement to the Side Impact Protection System and the threepoint seat belt system. It is not designed to deploy during collisions from the front or rear of the car or in rollover situations.

· The use of seat covers on the front seats may impede SIPS airbag deployment.

· No objects, accessory equipment or stickers may be placed on, attached to or installed near, the SIPS airbag system or in the area affected by SIPS airbag deployment (see illustration to the right above).

· Never try to open or repair any components of the SIPS airbag system. This should only be done by an authorized Volvo service technician.

· For best protection from the SIPS airbag system, both front seat occupants should sit in an upright position with the seat belt properly fastened.

SIPS airbag decal

WARNING!

· Never drive with the airbags deployed. The fact that they hang out can impair the steering of your car. Other safety systems can also be damaged. The smoke and dust formed when the airbags are deployed can cause skin and eye irritation in the event of prolonged exposure.

· If your car has been subjected to flood conditions (e.g. soaked carpeting/standing water on the floor of the vehicle) or if your car has become flooddamaged in any way, do not attempt to start the vehicle or put the key in the ignition before disconnecting the battery. This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.

pg. 9 Whiplash Protection System (WHIPS)

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (12 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

Whiplash Protection System (WHIPS) - front seats only

The WHIPS system consists of specially designed hinges and brackets on the front seat backrests and head restraints designed to help absorb some of the energy generated in a collision from the rear ("rearended").

In the event of a collision of this type, the hinges and brackets of the front seat backrests are designed to change position slightly to allow the backrest/head restraint to help support the occupant's head before moving slightly rearward. This movement helps absorb some of the forces that could result in the whiplash effect.

Do not wedge boxes, suitcases, etc. behind front seats

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (13 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

WARNING!

· Boxes, suitcases, etc. wedged behind the front seats (see illustration above) could impede the function of the WHIPS system.

· The WHIPS system is designed to supplement the other safety systems in your car. For this system to function properly, the three-point seat belt must be worn. Please be aware that no system can prevent all possible injuries that may occur in an accident.

· If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced. Do not attempt to service any component in the WHIPS system yourself.

· If the rear seat backrests are folded down, cargo must be secured to prevent it from sliding forward against the front seat backrests in the event of a collision from the rear. This could interfere with the action of the WHIPS system.

· The WHIPS system is designed to function in certain collisions from the rear, depending on the crash severity, angle and speed.

· Occupants in the front seats must never sit out of position. The occupant's back must be as upright as comfort allows and be against the seat back with the seat belt properly fastened.

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01a.htm (14 of 14)12/30/2006 3:43:33 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

pg. 10 Child safety

1 - Sedan 2 - Wagon

Integrated booster cushion-center position

Integrated booster cushions, center and outboard positions (optional)

Volvo's own integrated booster cushions have been specially designed to help safeguard a child seated in the rear seat. When using an integrated booster cushion, the child must be secured with the vehicle's threepoint seat belt. The booster cushions are approved for children weighing between 33 and 80 lbs (15 and 36 kg) and between 38 and 54 in (97 and 137 cm) in height.

Integrated booster cushion - outboard positions

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (1 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

The child should be properly seated on the booster cushion. The head restraint should be carefully adjusted to support the child's head (only center position). The hip section of the threepoint seat belt must fit snugly across the child's hips, not across the stomach. The shoulder section of the threepoint seat belt should be positioned across the chest and shoulder (see illustration). The shoulder belt must never be placed behind the child's back or under the arm.

head restraint-center position

For small children, the booster cushion backrest can be tilted back slightly by raising the center head restraint above the upper edge of the booster cushion backrest (3) and tilting the backrest (4). For taller children, it is essential that the head restraint be adjusted properly to help support the child's head (see

page 3).

pg. 11 Child safety

Integrated booster cushion-center position

Storing the center booster cushion

To store (fold up):

· Fold down the booster cushion backrest to the seat section (A)

· Snap the backrest snap to the fastener on the seat (B)

· Fold up the booster cushion unit (C)

NOTE: The booster cushion must be folded down as one unit. If the backrest is not strapped to the seat section of the cushion, the backrest hinges may lock.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (2 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

Integrated booster cushion - outboard positions

Outboard integrated booster cushions - Raising

1. Pull the handle at the front of the cushion forward. 2. With both hands push the cushion rearward. 3. Push the cushion until it locks in place.

Integrated booster cushion - outboard positions

Outboard integrated booster cushions - Lowering

1. Pull the handle at the front of the cushion forward.2. Push the cushion forward/downward.

NOTE: The booster cushion must be completely lowered before the rear seat backrest can be folded down.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (3 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

WARNING! Failure to follow the instructions on these pages will increase the risk of your child being injured during a sudden stop or collision. In the event of a collision while the integrated booster cushion was occupied, the entire booster cushion and seat belt must be replaced. The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo retailer only. The booster cushion should be cleaned while in place in the vehicle if possible. If not, please consult your Volvo retailer.

pg. 12 Child safety

Auxiliary seat - A-fold up,B-fold down

Auxiliary seat (optional)

If all the seats are occupied, a rear-facing auxiliary seat in the cargo area of wagon models can be used.

This seat is designed for two children, each weighing between 50 88 lbs. (23 - 40 kg) with a total seat capacity of 176 lbs. (80 kg) and up to 59 inches (150 cm) in height.

WARNING! Both rear seat backrests must be up when the auxiliary seat is being used. Do not use a booster cushion or child seat in conjunction with the auxiliary seat.

The luggage net should be retracted and the child safety lock in the tailgate should be open to allow access to the cargo area.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (4 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

WARNING! The exhaust pipe will still be hot when the engine is turned off. Take care that children do not burn themselves when they get into or out of the car.

pg. 13 Child safety

A-Lap section of belt locked in place, B-Lap section functions normally

Keeping child seats in place (spool-out)

To make child seat installation easier, each seat belt buckle (except for the driver's belt) is equipped with a locking mechanism to help keep the lap section of the seat belt taut.

When attaching the seat belt to a child seat:

· Make sure the red lock button is moved to the right (see illustration A above). A coin, etc. can be used to move the button.

· Attach the seat belt to the child seat according to the child seat manufacturer's instructions.

· Pull the lap section of the seat belt taut.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (5 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

The lap section of the seat belt cannot be loosened as long as the red lock button is in the right position. The lap section of the seat belt can be adjusted when the lock button is in the left position (see illustration B).

NOTE: Before exiting the car, check that the seat belt retracts fully after being unbuckled. If necessary, guide the belt back into the retractor slot. When not in use, the child restraint should be secured with the seat belt to help prevent movement during a sudden stop.

Important!

Why Volvo believes no child should sit in the front seat of a car.

It's quite simple really. A front air bag is a very powerful device designed, by law, to help protect an adult. Because of the size of the air bag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat. Volvo has been an innovator in safety for over fifty years, and we'll continue to do our part. But we need your help. Please remember to put your children in the back seat, and buckle them up.

Volvo has some very specific recommendations:

· Always wear your seat belt.

· Air bags are a SUPPLEMENTAL safety device which when used in conjunction with a three-point seat belt can help reduce serious injuries during certain types of severe accidents. Volvo recommends that you do not disconnect the air bag system in your vehicle.

· Volvo strongly recommends that ALL children sit in the rear seat of any vehicle and that they be properly restrained.

· A child should NEVER sit in the front passenger seat of any vehicle equipped with a front passenger side airbag.

· Volvo recommends that ALL occupants (adults and children) shorter than four feet seven inches (140 cm) be seated in the back seat of any vehicle with a front passenger side airbag.

Drive safely!

pg. 14 Child safety

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (6 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

Sedan

Child Restraint Anchorages

Volvo cars can or are fitted with Child Restraint Top Tether Anchorages in the rear seat.

Sedans: There are three predrilled anchorage points under the rear window shelf which are not visible from the passenger compartment. Wagons: The anchorage points are on the rear seat backrest and are hidden by plastic covers. The backrest must be folded down to access the center anchorage point.

UNTIHE Wagon

A 10 mm spacer, B anchorage plate, C 5/16" UNC bolt

Installing the top tether

Sedans: The predrilled holes for the child restraint anchorages are underneath the rear window shelf and

can be accessed from the trunk or by lowering the rear seat backrests. Wagons: Remove the plastic cover from the anchorage point you intend to use.

On either model, refer to the child seat manufacturer's instructions for securing the seat.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (7 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

WARNING! Child Restraint Anchorages are designed to withstand only those loads imposed by correctly fitted Child Restraints. Under no circumstances are they to be used for adult seat belts or harnesses. The anchorages are not able to withstand excessive forces on them in the event of collision if full harness seat belts or adult seat belts are installed to them. An adult who uses a belt anchored in a Child Restraint Anchorage runs a great risk of suffering severe injuries should a collision occur. Do not install rear speakers which would require the removal of the top tether anchors or interfere with the proper use of the top tether strap.

pg. 15 Child safety

Child safety

Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car.

Restraint systems for children are designed to be secured in the vehicle by lap belts or the lap portion of a lapshoulder belt. Such child restraint systems can help protect children in cars in the event of an accident only if they are used properly. However, children could be endangered in a crash if the child restraints are not properly secured in the vehicle. Failure to follow the installation instructions for your child restraint can result in your child striking the vehicle's interior in a sudden stop.

Holding a child in your arms is NOT a suitable substitute for a child restraint system. In an accident, a child held in a person's arms can be crushed between the vehicle's interior and an unrestrained person. The child could also be injured by striking the interior, or by being ejected from the vehicle during a sudden maneuver or impact. The same can also happen if the infant or child rides unrestrained on the seat. Other occupants should also be properly restrained to help reduce the chance of injuring or increasing the injury of a child.

All states and provinces have legislation governing how and where children should be carried in a car. Find out the regulations

existing in your state or province. Recent accident statistics have shown that children are safer in rear seating positions than front seating positions when properly restrained. A child restraint system can help protect a child in a vehicle. Here's what to look for when selecting a child restraint system:

· It should have a label certifying that it meets applicable Federal Motor Vehicle Safety Standards (FMVSS 213) or in Canada, CMVSS 213.

· Make sure the child restraint system is approved for the child's height, weight and development the label required by the standard or regulation, or instructions for infant restraints, typically provide this information.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (8 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

· In using any child restraint system, we urge you to look carefully over the instructions that are provided with the restraint. Be sure you understand them and can use the device properly and safely in this vehicle. A misused child restraint system can result in increased injuries for both the infant or child and other occupants in the vehicle.

· If your child restraint requires a top tether strap, consult your authorized Volvo retailer for top tether anchorage and installation information.

When a child has outgrown the child safety seat, you should use the rear seat with the standard seat belt fastened. The best way to help protect the child here is to place the child on a cushion so that the seat belt is properly located on the hips (see

page 10 ).

A specially designed and tested booster cushion (not available in Canada ) for children between 50 - 80 lbs (22.7 - 36 kg) and 46 - 54" (117 - 137 cm) can be obtained from your Volvo retailer.

If necessary, an auxiliary seat for children is available for use in the luggage compartment of station wagon models. This seat is designed for two children, each weighing between 50 - 88 lbs. (23 - 40 kg) and up to 59 inches (150 cm) in height.

WARNING!

· When using the auxiliary seat for children, both sections of the rear seat backrest must be secured in the upright position.

· Do not use a booster cushion or child seat in conjunction with the auxiliary seat.

pg. 16 Occupant safety

Seat belt maintenance

Check periodically that the seat belts are in good condition. Use water and a mild detergent for cleaning. Check seat belt mechanism function as follows: Attach the seat belt and pull rapidly on the strap.

Volvo Concern for Safety

Safety is the cornerstone for Volvo. Our concern dates back to 1927 when the first Volvo rolled off the production line. Threepoint seat belts (a Volvo invention), safety cages, and energyabsorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation. We will not compromise our commitment to safety. We continue to seek out new safety features and to refine those already in our cars. You can help. We would appreciate hearing your suggestions about improving automobile safety. We also want to know if you ever have a safety concern with your car. Call us in the U.S. at: 800-458-1552 or in Canada at: 800-663-8255.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (9 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

Occupant safety

How safely you drive doesn't depend on how old you are but rather on:

· How well you see.

· Your ability to concentrate.

· How quickly you make decisions under stress to avoid an accident.

The tips listed below are suggestions to help you cope with the ever changing traffic environment.

· Never drink and drive.

· If you are taking any medication, consult your physician about its potential effects on your driving abilities.

· Take a driverretraining course

· Have your eyes checked regularly

· Keep your windshield and headlights clean.

· Replace wiper blades when they start to leave streaks.

· Take into account the traffic, road, and weather conditions, particularly with regard to stopping distance.

Reporting Safety Defects in the U.S.

If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Volvo Cars of North America. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline tollfree at 18004249393 (or 202-3660123 in Washington, D.C. area) or write to: NHTSA, U.S. Department of Transportation, Washington D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline.

Volvo strongly recommends that if your vehicle is covered under a service campaign, safety or emission recall or similar action, it should be completed as soon as possible. Please check with your local retailer or Volvo Cars of North America, Inc. if yout vehicle is covered under these conditions.

pg. 17

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (10 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_01b.htm (11 of 11)12/30/2006 3:43:33 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

Chapter 2 - Instruments, switches and controls

pg. 18 Instruments, switches and controls

pg. 19 Instruments, switches and controls

The pages in this section provide detailed descriptions of the vehicle's instruments and controls. Note that vehicles may be equipped differently, depending on special legal requirements.

Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (1 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

1 Air vents

2 Headlights, parking lights

3 Instrument illumination

4 Rear fog light

5 Front fog lights (optional)

6 Space for additional equipment 7 Space for additional equipment

8 Instruments

1920

9 TRACS/STC (optional)

10 Trip computer (optional)

3032

11 Electrically operated sun roof (optional)

12 Rear window demister/heated door mirrors

13 Air mix

14 Air vents

15 Passenger side air bag (SRS) hatch

4-6

16 Air vents

17 Hood release

18 Turn signals, high/low beams/exterior courtesy lights

Cruise control

19 Adjustable steering wheel

20 Windshield wiper/washer

Tailgate wiper/washer (wagons)

21 Heated front seats (optional)

22 Auxiliary socket

23 Audio systems

141

24 Heating and ventilation controls

3741

25 Hazard warning flashers

26 Ashtray

27 Coin holder

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (2 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

Shiftlock release button (automatic transmission only)

110

29 Gear selector shift positions

7276

30 Winter mode selector

74,76

31 Parking brake

32 Horn/SRS

4-7

33 Trunk/tailgate open control

34 Power window controls

35 Power mirror controls

36 Fuel tank open control

37 Central locking button

Some of the items listed on this page are available on certain models only.

pg. 20 Instruments

1 Fuel gauge

Fuel tank capacity:

18 US gal. (68 liters) - Front Wheel Drive

17.4 US gal (66 liters) - All Wheel Drive When the warning light comes on there is approximately 1.8

US gal. (8 liters) of fuel remaining. See "Refueling" for additional information.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (3 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

2 Temperature gauge

Do not drive the car with the pointer in the red range. The pointer should be approximately midway

on the gauge face when driving. If the pointer approaches the red range repeatedly, check coolant level.

3 Speedometer

4 Clock, ambient temperature sensor, trip computer (certain models)

5 Trip odometer

Used for measuring shorter distances. The last digit indicates 1/10 mile/kilometer.

6 Odometer

7 Trip odometer reset button

8 Tachometer

Reads thousands of engine rpm. Do not drive for long with the needle in the red section. The engine has an inbuilt function preventing too high a rotation speed. When this function operates, you may discern some pulsation, which in that case is quite normal.

NOTE: Digital displays showing Clock, Trip Odometer and Odometer will go off 30 minutes after the ignition has been switched off. To view these displays again, turn the ignition key to position I.

pg. 21 Indicator and warning lights

1 Turn signal, left

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (4 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

2 Turn signal, right

3 Cruise control

4 Low washer fluid level

If the lamp glows continuously when the engine is running, there is only about 1/2 - 1 US qt. remaining in the washer fluid reservoir.

5 Low fuel level

When the lamp glows, only about 1.8 US gals. (8 liters) of fuel remain. If the ignition is switched on while refuelling, the gauge may read inaccurately for up to 45 minutes.

6 Rear fog light

7 High beams

8 Trunk/tailgate open

9 Bulb failure warning sensor

10 (Not in use)

11 Electronic Throttle System (ETS)

12 SRS

13 Generator not charging

14 Low engine oil pressure

15 Brake warning light

16 Parking brake applied

17 ABS-system

18 Transmission mode: Indicates "W" if winter/wet driving mode is active, or indicates currently selected low gear.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (5 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

19 Low coolant level

20 Traction Control (TRACS)/ Stability and Traction Control (STC) Systems (option)

21 Malfunction indicator lamp

(See

page 22 for more information)

22 Service reminder indicator

pg. 22 Warning lights

The warning lights described on pages 20 and 21 should never stay on when driving

When the ignition key is turned on and before the engine starts, all of the warning lights should go on to test the function of the bulbs. Should a light not go off after the engine has started, the system indicated should be inspected. However, the parking brake reminder light will not go off until the parking brake has been fully released.

Supplemental Restraint System (SRS)

If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.

Malfunction indicator lamp

If the lamp comes on (or stays on after the vehicle has started), the engine diagnostic system has detected a possible fault in the emission control system. Although driveability may not be affected, see an authorized Volvo retailer as soon as possible for inspection.

NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Malfunction Indicator Lamp may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (6 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

Oil pressure warning light

If the light comes on while driving, stop the car and then stop the engine immediately and check the engine oil level. See

page 124. If the light stays on after restart, have the car towed to the nearest

authorized Volvo retailer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.

Parking brake reminder light

This light will be on when the parking brake (hand brake) is applied. The parking brake lever is situated between the front seats.

Canadian models are equipped with this warning light:

Cruise Control

This light will be on when cruise control is engaged. Cruise control will automatically disengage when the ignition is switched off.

Brake failure warning light

If the light comes on while driving or braking, stop immediately, open the hood and check the brake fluid level in the reservoir. See

page 131 for reservoir position.

Canadian models are equipped with this warning light:

WARNING! If the fluid level is below the MIN mark in either section of the reservoir: DO NOT DRIVE. Tow the car to a Volvo retailer and have the brake system checked and any leakage repaired.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (7 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

Fault in ETC (Electronic Throttle Control system)

If this lamp comes on, there is a fault in the engine control system and driveability will be affected. Switch the ignition off and then on again. If the light remains on, the system should be inspected by an authorized Volvo retailer.

pg. 23 Warning lights

TRACS disengaged (option)

If the TRACS (TRAction Control System) is manually disengaged with the switch on the dashboard (see page 27), the warning light will come on. This will also come on to indicate a TRACS malfunction, and when the brakes overheat, although it goes out again at the normal temperature level. If the lamp remains on, the system should be checked by an authorized Volvo retailer. This lamp should not be confused with the ON/OFF indicator lamp above the switch.

STC disengaged (option)

The indicator light () in the instrument panel will be ON when you have switched the Stability and Traction Control system (STC) OFF using the button on the dashboard (see page 25). The light will also come on if there is a fault in the STC system or to indicate that the brakes have overheated. The light will go out when the brake temperature returns to normal.

The symbol will flash when STC is actively regulating power to the drive wheels. Normal power may be reduced at this time. This is normal as power is momentarily reduced to help keep the drive wheels from losing traction and spinning.

Coolant level sensor

If this light comes on while driving, the coolant level is low. The coolant level in the expansion tank should be checked immediately and topped up if necessary. The cooling system should be inspected by

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (8 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

an authorized Volvo retailer.

Mode "W" engaged

The lamp will light up when the Winter/Wet starting mode is engaged or if gears "4-1" or "L" are selected.

If the warning lamp begins to flash, this means that there is a fault in the automatic gearbox. Contact Your Volvo retailer.

Generator warning light

If the light comes on while the engine is running, have the charging system checked.

Service reminder indicator

This light will come on at 7,500 mile (12,000 km) intervals, after 750 hours of driving or after 12 months, whichever occurs first. It is a reminder to the driver that the service interval has been exceeded. The light will stay on for 2 minutes after start until reset by the servicing retailer.

Bulb failure warning light

The light will come on if any of the following bulbs are defective:

· one of the low beam headlights

· one of the tail lights

· one of the brake lights when the brake pedal is depressed.

Check the fuse and bulb. See sections "Replacing bulbs" and "fuses.

Should the warning light come on after a defective outside bulb has been replaced, the corresponding bulb on the other side of the car should also be replaced.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (9 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

Anti-lock Brake system (ABS)

If the warning lamp lights up there is a malfunction of the ABS system (the standard braking system will however function). The vehicle should be driven to a Volvo retailer for inspection.

See

page 83 for additional information.

Canadian models are equipped with this warning light:

pg. 24 Headlights, Parking lights, Exterior courtesy lights, Turn signals

Headlights and parking lights

All lights off *

Parking lights on *

Headlights and parking lights are on if starting (ignition ) switch is in positions I or II.

If the headlight switch is in the position

all lights will go out when the starting switch is switched off.

With the headlight switch in position

the parking lights will stay on (headlights off) with the daytime

running light screw (A) in position .

The high beams can only be switched on if the headlight switch is in position

Switch from high to low beams and vice versa by moving the turn signal switch lever on the left side of steering column towards the steering wheel.

* See

page 26 for information on Daytime running lights.

Exterior courtesy lights

When you leave your car at night, you can make use of the exterior courtesy lighting function:

· Remove the key from the ignition switch.

· Pull the direction indicator lever towards the steering wheel (as when using the headlight flasher

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (10 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

function).

The low beam headlights will now remain on for 30 seconds to light your way.

Turn signals

1 Lane change position. In maneuvers such as lane changing, the driver can flash the turn signals by

moving the turn signal lever to the first stop and holding it there. The lever will return to the neutral position when released.

2 Signal lever engaged for normal turns.

3 High beam/low beam switch (headlights on).

Move the lever towards the steering wheel and release it.

Headlight flasher (headlights off).

Move the lever towards the steering wheel. The headlight high beam will be on until the lever is released.

NOTE: A defective turn signal bulb will cause the turn signal indicator and remaining signal lights to flash more rapidly than normal.

pg. 25 Windshield wipers/washers, Ignition switch/steering wheel lock

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (11 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

Windshield wipers/washers

1 Intermittent wiper

With the switch in this position, the wipers will sweep approximately every seventh second.

2 "Single sweep" position:

The switch returns automatically when released.

3 Wipers, normal speed

4 Wipers, high speed

5 Windshield wiper/washer, headlight wiper/washer (certain models)

The wipers will make 23 sweeps across the windshield and headlights (certain models) after the lever is released.

O Locked position: Remove the key to lock the steering wheel*

WARNING! Never turn the key to position O while driving or when the car is being towed.

I Intermediate position: Certain accessories, radio, etc. on, daytime running lights off.

II Drive position: Key position when engine is running.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (12 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

III Starting position: Release the key when the engine starts. The key returns automatically to the Drive position.

* On cars equipped with an automatic transmission the gear selector must also be in the (P)ark position.

Starting (ignition) switch/steering wheel lock

If you find it difficult to insert the key in the ignition or to move the steering wheel, the steering wheel lock might be under tension. Turn the wheel back and forth slightly to free the ignition key.

In order to reduce car theft, make sure the steering wheel locks before leaving the car.

A chime will sound if the starting key is left in the ignition lock and the front door on the driver's side is opened.

pg. 26 Instrument illumination, Fog lights

1 - Instrument illumination To increase the brightness: move the thumbwheel up. To decrease the brightness: move the thumbwheel down.

2 - Rear fog light *

The rear fog light (located in the driver's side tail light cluster) is considerably brighter than the normal tail lights and should be used only when the atmospheric conditions, such as fog, rain, snow, smoke or dust reduce the daytime or nighttime visibility of other vehicles to less than 500 ft (150 meters).

For the rear fog light to function, the low beam headlights must be switched on.

* By design, there is one rear fog light only, located in the driver's side tail light cluster.

3 - Front fog lights (option)

The front fog lights, located in the front spoiler, will only function in combination with the low beam headlights.

4 - Space for optional equipment

5 - Space for optional equipment

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (13 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02a.htm (14 of 14)12/30/2006 3:43:35 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

pg. 27 TRACS, Sun roof, Trip computer, Hazard warning flashers, Demister

6 - TRAction Control System (TRACS)/Stability and Traction control (STC) - option

See

page 84 for more information on these systems.

7 - Trip computer - option

Turn the dial to the desired function. For more information, see pages 30-32.

8 - Electrically operated sun roof - option

See

page 54 for operating instructions.

9 - Rear window demister, heated side-view mirrors

Press the switch to start heating the rear window and side-view mirrors. The control light in the switch will illuminate.

A timer switches off the system after approximately 12 minutes. The control light will go out

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (1 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

correspondingly.

Hazard warning flashers

The four-way flasher (located above the ashtray) should be used to indicate that the vehicle has become a traffic hazard.

NOTE: Regulations regarding the use of the hazard warning flasher may vary from state to state.

pg. 28 Daytime running lights, Tailgate wiper/washer (wagons)

Automatic daytime running lights

Screw A in the illustration (available on U.S. models only) is used to control the automatic daytime running lights when the headlight switch is in position 0.

The low beams, tail lights, parking lights and license plate lights will come on automatically when the ignition is switched on.

To adjust, press in the screw with a small screwdriver and turn to one of the following positions:

Automatic daytime running lights

The daytime running lights will also function when the headlight switch is in position

and switch A is

in this position.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (2 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

All lights off (daytime running light function disabled)

NOTE: The daytime running light function may only be disabled (turned off) in the U.S. Canadian law

mandates the use of daytime running lights.

Tailgate wiper/washer (wagons)

Tailgate window wiper/washer The tailgate window wiper/washer is operated by a switch at the end of the wiper lever.

1. The wiper operates continuously.

2. Intermittent position: the wiper strokes approximately every 10 seconds.

3. Tailgate washer (note that the wiper also operates when this button is depressed):

after the button is released the wiper strokes 23 additional times before stopping.

pg. 29 Clock, Ambient temperature sensor (certain models)

Resetting the clock

The digital clock can be reset by pressing one of the two buttons (A and B) with a pointed object such as the tip of a pen.

h = hours

m = minutes

Maintain the pressure on the buttons for more than four seconds to change the time more quickly.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (3 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

NOTE: Digital displays showing the Clock will go off 30 minutes after the ignition has been switched off. To view this display again, turn the ignition key to position I.

Ambient temperature sensor

This sensor indicates the temperature slightly above the road surface and represents air temperature where road icing may occur. An amber indicator light (C) in the "snowflake" symbol lights up when the temperature is in the range of 23 - 36° F (-5 - +2° C). Please note that this light does not indicate a fault with your car.

At low speeds or when the car is not moving, the temperature readings may be slightly higher than the actual ambient temperature due to the heat generated by the engine.

Display alternatives

If buttons A and B are pressed down simultaneously, it is possible to shift between four different display alternatives:

Press 1st time: 12 hour clock and °F

Press 2nd time: 24 hour clock and °F

Press 3rd time: 12 hour clock and °C

Press 4th time: 24 hour clock and °C

pg. 30 Trip computer (certain models)

Trip computer

The trip computer offers six functions which are presented in a single display. The cursor indicates the selected function. The trip computer's clock is shown permanently in the left-hand field. Refer to the previous page for more detailed information regarding the clock function.

The following data is monitored by the computer:

· Average speed

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (4 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

· Current fuel consumption

· Average fuel consumption

· Ambient temperature *

· Tripmeter

· Driving distance on current fuel reserve

Trip computer controls

Select one of the trip computer's six functions by using control B. The Reset button (C) is used to reset the following functions:

· Average speed

· Average fuel consumption

· Trip meter

Rotate the control to the required position and press the button for at least two seconds to reset the selected function.

NOTE: If pressure is maintained on the button for another three seconds, all three of the functions mentioned above will be reset.

* Warning light A in the illustration above. See

page 32 for more details.

pg. 31 Trip computer (certain models)

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (5 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

Average speed Ø mph (Canada: km/h)

Average speed since the function was last reset. When the ignition is switched off, the average speed is stored in memory and is used as the basis for the new figure when the engine is started again. It can be reset by pressing the reset button on the trip computer control.

Current fuel consumption mpg (Canada: L/100 km)

Continuous information on current fuel consumption, calculated once per second. When the car is not moving, the display shows "---".

Average fuel consumption Ø mpg (Canada: L/100 km)

Average fuel consumption since the function was last reset. When the ignition is switched off, the average fuel consumption figure is stored in memory and remains in memory until it is reset using the button on the trip computer control.

pg. 32 Trip computer (certain models)

Ambient temperature

Shows the ambient temperature just above the road surface while driving. When the temperature is in the range 2336° F (5 - +2° C), the ambient temperature sensor activates an indicator light in the "snowflake" symbol to help alert the driver of possible slippery driving conditions. Please note that this light does not indicate a fault with your car.

At low speeds or when the car is not moving, the temperature readings may be slightly higher than the actual ambient temperature due to the heat generated by the engine.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (6 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

Tripmeter in miles (Canada: km)

Shows the distance driven since the function was last reset. This value is stored in memory until it is reset using the reset button on the trip computer control.

Driving distance on current fuel reserve mile 0 (Canada: km)

Shows the approximate distance which can be driven on the fuel remaining in the tank, calculated on the basis of the average fuel consumption during the last 12 miles (20 km) driven and the amount of fuel remaining in the tank at the time of the reading.

When the quantity of fuel drops to below approximately

1.8 US gals. (8 liters), a warning light in the instrument panel comes on. When the driving distance on the current fuel reserve is less than 12 miles (20 km), the display shows "—".

pg. 33 Cruise control

Cruise control

The cruise control switches are located on the turn signal lever. The indicator light on the instrument panel (see page 19) will come on when cruise control is engaged.

To engage and set the desired speed:

1. Set switch (B) to ON.

2. Accelerate to the desired cruise speed.

3. Press the + or - area of the SET button (A) to set the desired speed.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (7 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

NOTE: The cruise control cannot be engaged at speeds below 22 mph (35 km).

Braking

This will automatically disengage the cruise control. The previously selected cruise speed is retained in the memory and by momentarily setting the switch to the RESUME position, that speed will be reengaged.

If the cruise control is already engaged, the cruising speed can be increased or decreased by depressing the SET button (A) towards either + or -. One short press on the button corresponds to a speed change of approx. 1 mph (1.6 km/h). When the button is released, the vehicle will maintain the current speed.

If the actual speed falls below 70% of the set speed or if the wheels spin or lock, the cruise control will disengage automatically.

NOTE: (AUTOMATIC TRANSMISSION) When driving up steep hills with the cruise control engaged, the transmission may shift intermittently.

Acceleration

Momentary acceleration, such as for passing, does not interrupt cruise control operation. The previously selected speed will be maintained without having to set the switch to RESUME.

To disengage the cruise control system:

Set switch (B) to OFF, depress the brake pedal or move the gear selector to position N.

Switching off the starting (ignition) switch will automatically disengage the cruise control system.

On cars equipped with manual transmissions, the cruise control can also be disengaged by depressing the clutch.

WARNING! The cruise control should not be used in heavy traffic or when driving on wet or slippery roads. Do not use or resume cruise control in reverse gear.

NOTE: When the ignition is switched off, any information stored in the cruise control memory is erased.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (8 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02b.htm (9 of 9)12/30/2006 3:43:38 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

pg. 34 Heated front seats (certain models), Parking brake

Heated front seats

The heated front seats can be switched on and off as required. When switched on, the system senses the ambient temperature and regulates the level of heat applied. When the optimum temperature is reached, the heating switches off automatically. While driving, the seat heating for the passenger seat should be switched off when the seat is not occupied.

Parking brake lever

Parking brake (hand brake)

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (1 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

The lever is situated between the front seats. The brake is applied to the rear wheels.

WARNING! Always use the parking brake (hand brake) when parking. On hills, also turn the front wheels toward the curb. The indicator light in the instrument panel will light up even if the parking brake is only applied slightly. Be sure to pull the lever up sufficiently.

pg. 35 Ashtrays, Auxiliary socket

Ashtray

Front ashtray

To open the front ashtray, press lightly on the panel.

To empty the front ashtray:

· Put the gear selector (aut. transmission) in position L.

· Grasp the front edge of the ashtray and pull it straight out.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (2 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

Rear seat auxiliary socket* and ashtray

Rear ashtray

To open the rear ashtray, pull it straight out.

To empty the rear ashtray, pull it out, lift up the rear edge and remove.

Front auxiliary socket*

Auxiliary socket

This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The key must be in position I (or higher) for the auxiliary socket to function.

NOTE: The "OBD II" terminal, a connector for diagnostic equipment, is located under the cover of the storage compartment between the front seats. This terminal is intended for use by authorized service technicians only.

* The auxiliary sockets can also be used as cigarette lighters, which are available at your Volvo retailer.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (3 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

pg. 36 Steering wheel adjustment

Steering wheel adjustment

Both the height and the reach of the steering wheel can be adjusted to a comfortable position for the driver. Pull down the lever on the left of the steering column. Adjust the steering wheel to a suitable position and press the lever back into place to lock the steering wheel in the new position. Check that the steering wheel is locked in the new position.

WARNING! Never adjust the steering wheel while driving.

pg. 37 Heating, ventilation and air conditioning

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (4 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

BHeating and air conditioning

Your Volvo is equipped with a heating system combined with air conditioning. Depending on which function you select, warm or cool/cold air is distributed to the different parts of the passenger compartment. A slight amount of condensation may be emitted from the air vents when the air conditioning is initially switched on. This can occur when both humidity and ambient temperature are high and is normal.

Air mix (fresh air)

The center panel vents have an air mix function which allows fresh air to enter the passenger compartment when the vents are open (position A). This function is designed to allow you to direct cool air toward your face while directing warmer air to the rest of the passenger compartment.

To warm/cool the compartment as quickly as possible, the air mix control should be in the closed

position.

Air vents (dash)

A Open B Closed C Directing air flow horizontally D Directing air flow vertically

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (5 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

Refrigerant

Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a. This substance will not deplete the ozone layer. The system contains 1.63 lbs (0.75 kg) R134a and uses ZXL 100PG (type PAG) oil.

NOTE: All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only.

pg. 38 Heating, ventilation and air conditioning (standard unit)

* When the function selector is in the defrost setting, the A/C will automatically be ON if recirculation is

not on and the blower control is not in position 0.

Function selector

Air through panel vents

Defrost. Air to windshield and side windows.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (6 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

Air to floor, windshield and side windows.

Air through floor vents.

Bi-level. Air through floor and panel vents.

NOTE: If your windows begin to fog or mist, check that the recirculation function is NOT engaged.

Faults in the A/C system

The RECIRCULATION and AC lights will flash for approximately 20 seconds if a fault is detected in the A/C ssystem. If this flashing recurs the next time the system is switched on, the climate control unit should be checked by an authorized Volvo retailer.

pg. 39 Heating, ventilation and air conditioning (standard unit)

Maximum heating:

Close the center panel vents. When the passenger compartment has become sufficiently warm, set the blower control to the fourth position, adjust the temperature and open the side air vents.

Maximum cooling:

Open the vents. The A/C and recirculation should be ON. Adjust the temperature with the temperature selectors to raise the temperature if necessary.

The recirculation function should not be used for more than 15 minutes.

To demist/defrost the windows:

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (7 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

Set the function selector to

and the blower control to the highest position. The A/C will be ON if recirculation is not on. When the windows have cleared, set the blower control to the second position and the function selector to the desired position. Always keep the air intake grille at the base of the windshield under the rear edge of the hood free of snow.

Additional information

The air conditioning system will function best if it is always left on.

· Water under the vehicle in hot weather can be the result of condensation from the air conditioning system and is quite normal.

· The air conditioning system functions only at temperatures above 32° F (0° C).

· Use the RECIRCULATION function if the outside air is contaminated with exhaust gases, smoke, etc or to heat/cool the car quickly. In this position, very little air is drawn into the passenger compartment from the outside. Do not leave the system in this mode for more than 10-15 minutes since the air inside the car will become stale. The temperature can be controlled with the temperature selectors.

· If the panel vents are open, a certain amount of air will always flow through, regardless of the position the function selector is in. To increase the flow of air to either the floor or the windows, close the panel vents and open the outer vents.

· The panel vents may emit some condensation when the air conditioning is initially switched on and is quite normal. This may occur if the ambient temperature and humidity are high.

· The air conditioning is momentarily disengaged during full-throttle acceleration.

pg. 40 Heating, ventilation and air conditioning (Electronic Climate Control) - option

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (8 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

Function selector

AUT Air distribution automatically regulated

Air through panel vents

Defrost. Air to windshield and side windows. Recirculation will not function regardless of button

setting.

Air to floor, windshield and side windows.

Air through floor vents.

Bi-level. Air through floor and panel vents.

* Pressing the ON section of the button for more than 3 seconds activates a timer function. Recirculation will then always operate for 5 minute periods, after which the button will flash to indicate that Recirculation has automatically switched off. Pressing the OFF button at any time during the 5

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (9 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

minute period will allow fresh air into the passenger compartment. Press the ON button again for more than 3 seconds to return the button to its original function (i.e., Recirculation will remain on until the OFF button is pressed). ** When the function selector is in the defrost setting, the A/C system is always ON and the blower will function at its highest speed if it is in the AUT position.

pg. 41 Heating, ventilation and air conditioning (Electronic Climate Control) - option

Automatic setting

Set the mode selector and blower control to AUT and select the desired temperature. If the driver's side temperature selector is set to either the max heating or max cooling position, the blower will run at its maximum speed.

Optimum defrosting

Set the function selector to

and move the blower control to the position AUT (as far to the left as possible). The A/C system will be on at this time even if the AC OFF button is depressed and the blower will run at its maximum speed. When the windows have cleared, set the function selector in the AUT position.

Additional information

· The air conditioning system will function best if it is always left on.

· Always keep the air intake grille at the base of the windshield under the rear edge of the hood free of snow.

· Water under the vehicle in hot weather can be the result of condensation from the air conditioning system and is quite normal.

· The air conditioning is disengaged when the blower is set at 0 and the speed of the vehicle is less than 20 mph (30 km/h).

· The air conditioning system functions only at temperatures above 32° F (0° C).

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (10 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

· RECIRCULATION: Use this function if the outside air is contaminated with exhaust gases, smoke, etc or to heat/cool the car quickly. When Recirculation is activated, very little air is drawn into the passenger compartment from the outside. If your windows begin to fog or mist, check that the recirculation function is NOT engaged.

NOTE: When driving with the sun roof or windows open, to help maintain stable passenger compartment temperature, use the blower control to manually regulate the blower speed.

· If the panel vents are open, a certain amount of air will always flow through, regardless of the position the function dial is in. To increase the flow of air to either the floor or the windows, close the panel vents and open the outer vents.

· The panel vents may emit some condensation when the air conditioning is initially switched on and is quite normal.

This may occur if the ambient temperature and humidity are high.

· The sunlight sensor (located at the top center of the dashboard) should not be covered in any way as this could cause incorrect information to be sent to the ECC system.

· The air conditioning is momentarily disengaged during full-throttle acceleration.

Difficult weather conditions

When driving in very humid conditions, heavy rain, sleet, etc., it may be better to use the manual rather than the automatic setting to defrost the windows. Set the mode selector to "Defrost"

or "Defrost/

floor" and the fan speed to mid-range. Also shut the center air vents.

Faults in the ECC system

The RECIRCULATION ON and AC OFF lights will flash for approximately 20 seconds if a fault is detected in the ECC system. If this flashing recurs the next time the system is switched on, the climate control unit should be checked by an authorized Volvo retailer.

pg. 42 Electrically operated windows

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (11 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

A- left front B- right front C- left rear D- right rear E- Cutout switch, rear windows F- central locking button (see

page 43)

Electrically operated windows

The electrically operated windows are controlled by switches in the driver's door as shown in the illustration above. The starting (ignition) switch must be ON (intermediate position I) for the electrically operated windows to function.

To lower: press down on the front edge of the button

To raise: pull up on the front edge of the button.

NOTE:

· Auto-down function (driver's window only): The window can be opened completely by pressing the front part of the switch lightly and releasing it immediately. The window can be stopped by pressing the button again. If the button is held down, the window will be lowered until the button is released.

· The power window motors have an overload protecting circuit breaker which is activated when an object blocks a window. Should this occur, remove the object and wait 20 seconds for the circuit breaker to reset.The power windows should then function.

Cutout switch for rear windows

If your car is equipped with electrically operated rear door windows, this function can be disabled by a switch located on the driver's door (see illustration).

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (12 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

ON The rear door windows can be raised or lowered with the respective door switches as well as with the switches on the driver's door armrest.

OFF The rear door windows cannot be raised or lowered with the respective door switches but instead

only with the corresponding switches on the driver's door armrest.

WARNING!

· Remove the ignition key when children are left unattended in the vehicle.

· Make sure that childrens' hands are clear before raising the windows.

· Never leave children unattended in the car.

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_02c.htm (13 of 13)12/30/2006 3:43:39 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

Chapter 3 - Body and interior

pg. 43 Body and interior

The seats, sun roof, mirrors, etc. are described on the following pages.

Keys

Doors and locks

Remote keyless entry system

Alarm

Trunk/tailgate

Child safety locks

Front seats

5152

Rear/side view mirrors

Interior lights, Vanity mirror

Sun roof

Hood

Storage compartments

Trunk light, Spare tire, Jack

Cargo space lighting, Spare tire, Jack (wagon)

Folding rear seat (sedan)

Folding rear seat (wagon)

6061

Removing seat cushions

Concealed storage bin/Bumper cover (wagon), Avoiding battery drain

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (1 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Luggage net/Side cargo net (wagon)

Securing cargo

Folding front seat, Long load storage

pg. 44 Keys

NOTE:

· As an added anti-theft measure, new keys have been developed which may take slightly longer to copy or replace if the original keys are misplaced. Duplicate keys may be ordered from your Volvo retailer.

· The key number codes are stamped on a separate tag supplied with the keys. This tag should be separated from the key ring and kept in a safe place.

Immobilizer (start inhibitor)

Each of the keys supplied with your car contains a coded transmitter and receiver (transponder). The code in the key is transmitted to an antenna in the ignition switch where it is compared to the code stored in the start inhibitor module. The car can only be started if a properly coded key is used.

If you misplace a key, take the other keys to an authorized Volvo retailer. The existing code in the start inhibitor module and all the keys will be erased as an antitheft measure and a new code will be

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (2 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

programmed in.

NOTE:

Not more than one of the keys for your car should be kept on the same key ring. This could cause conflicting signals to be transmitted to the ignition switch, making it impossible to start the car.

This device complies with part 15 of the FCC rules. Operation is subject to the following condition: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

pg. 45 Doors and locks

Doors and locks

Your car is equipped with a central locking system.

The key, used on the driver's door, the remote control, or central locking button, will lock/unlock all doors, trunk/tailgate.

Turn the key once to unlock the driver's door only.

Turn the key again (within 10 seconds) to unlock all doors, trunk/tailgate.

One turn with the key towards lock in the drivers door locks all doors, trunk/tailgate.

Use the switch on the front door armrests to lock/unlock the car from the inside.

Check the action of the buttons on the other doors to verify their correct function (lock/ unlock).

WARNING! If the doors are locked while driving, this may hinder rapid access to the occupants of the car in the event of an accident. (Also see information on "Child safety locks").

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (3 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Central locking button (on both front doors)

Central locking button

The central locking buttons on both front door armrests can be used to lock or unlock all doors and trunk/ tailgate and set the alarm if your car is so equipped. This switch functions even if a door/trunk/tailgate is open.

Lock: Press the left side of the button.

Unlock: Press the right side of the button.

Note: To help prevent accidentally locking the keys in the car, the central locking system is designed to

unlock the driver's door immediately if the key is left in the ignition switch and the car is locked using the lock button on the door. A sound from the lock will be audible at this time.

Please note that this function will not unlock the doors if the engine is running.

pg. 46 Remote keyless entry system

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (4 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Remote keyless entry system

Your car is equipped with a remote control transmitter. This transmitter uses a radio frequency which will allow "keyless" entry into the passenger compartment or the trunk. You will be supplied with two coded key ring transmitters, which will enable you to lock/unlock all doors and the trunk/tailgate from a distance of 10-15 feet (3-5 meters).

On vehicles equipped with an alarm, the alarm will also be activated/deactivated by this system.

The car can also be locked/unlocked with the key.

As an extra security precaution in certain situations (valet parking, etc.), Volvo recommends that the transmitter not be included when the keys are given to anyone. The service key can be used instead. If one of the transmitters is misplaced, contact the nearest authorized Volvo retailer for assistance.

Using the remote control

· Press the LOCK button once to lock all doors and trunk/tailgate.

· Press the UNLOCK button once to unlock the driver's door only. Press this button again (within 10 seconds) to unlock all doors, trunk/tailgate.

· Press the OPEN trunk/tailgate button twice within 3 seconds to pop open the trunk or unlock the tailgate. NOTE: To avoid leaving your keys in the car, make a habit of always locking the car with the remote control. This device complies with FCC rules Part 15. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference that may be received, including interference that may cause undesired operation.

NOTE: If only the driver's door is unlocked, the lock will automatically reengage (re-lock) and the alarm will reset after 2 minutes unless the door has been opened.

The lock/unlock and alarm features can also be utilized by using the keys. See section: Doors and Locks

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (5 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

on page 45.

If the alarm LED glows continuously for 5 seconds, this indicates a fault in the system or that a door is not properly closed.

WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. On cars equipped with an alarm, the alarm would be activated and would sound when one of the doors is opened. The doors must not be locked using the remote transmitter while the vehicle is occupied. In case of an accident, this may hinder rapid access to the occupants of the vehicle. The alarm will also sound on models equipped with this feature.

pg. 47 Alarm (certain models)

LED alarm status indicator

Alarm

The radio signal emitted from the transmitter, which is used to set/unset the alarm, is a "rolling code" signal. This means that the signal is changed randomly for each transmission and is intended to help prevent unauthorized recording of the code.

When armed (set), the alarm continuously monitors a number of points on the car. The following conditions will set off the alarm:

· The hood is opened

· The trunk/tailgate is opened

· A door is opened

· The ignition switch is tampered with

· The car is lifted or towed (if the car is equipped with the optional inclination sensor)

· The battery is disconnected (if the car is equipped with the optional backup battery siren). The alarm

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (6 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

will sound for ten 30 second intervals, with a 5 second pause between intervals. This function cannot be interrupted.

Arming (setting) the alarm

Press the LOCK button on the remote control, lock the car using the key in the driver's door or press the central lock button on one of the front doors with the door open. One long flash of the turn signals will confirm that the alarm is set.

Disarming the alarm

Press the UNLOCK button on the remote control or unlock the doors with the key.

Turning off (stopping) the alarm

If the alarm is sounding, it can be stopped by pressing the UNLOCK button on the remote control or by unlocking the driver's door with the key.

If the alarm is stopped with the remote control, this will be confirmed by two short flashes from the turn signals.

Visual alarm signal

The visual alarm signal is given by flashing all turn signals and turning on the interior lighting for approximately 5 minutes.

Audible alarm signal

An audible alarm signal is given either by a separate alarm horn or by the optional back-up siren. One alarm cycle lasts for 30 seconds.

"Panic" function

In an emergency situation, this feature can be used to attract attention.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (7 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Activate the "panic" function by pressing the red panic button on the remote control for at least 3 seconds or by pressing this button twice within 3 seconds. The turn signals will flash, the interior lights will go on and the alarm will sound.

The function can be turned off by pressing any of the buttons on the remote control or will stop automatically after 25 seconds.

NOTE: This button will NOT unlock the car.

pg. 48 Alarm

LED alarm status signals

The status of the alarm system is indicated by the red LED at the top center of the dash:

· LED off - the alarm is not armed (set)

· LED flashes once per second - the alarm is armed (set)

· LED flashes rapidly before the ignition is switched on - the alarm has been triggered

· LED flashes rapidly for 15 seconds after the ignition has been switched on - a fault has been detected in the alarm system. Contact a Volvo retailer.

Automatic reset function

If only the driver's door is unlocked with the remote control, the lock will automatically reengage (relock) and the alarm will reset after 2 minutes unless the door has been opened.

Temporarily disconnecting the alarm sensor(s)

In certain situations it may be desirable to disconnect the optional alarm sensors, particularly the inclination sensor, if, for example, you drive your car onto a ferry where the rocking of the boat could trigger the alarm.

To temporarily disconnect the sensor(s) from the alarm system:

· With all doors closed, switch off the ignition and remove the key from the ignition switch

· Press the locking (left) side of the central locking button on the driver's door for at least 3 seconds

· The doors will first lock and then unlock after 3 seconds to confirm that the sensors have been disconnected

The car can then be locked in the usual way to set the alarm.

NOTE: The sensors will automatically be reconnected to the alarm system the next time the ignition is switched on.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (8 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Batteries

Each remote transmitter is powered by a three-volt battery, type CR 2016. If the range of the transmitter is noticeably reduced, this indicates that the battery is weak and should be replaced.

Replacement: Remove the battery cover on the back of the transmitter with a coin. Replace the battery. Reinstall the cover, making sure it is secured tightly to help protect the transmitter.

CAUTION: Do not attempt to service or repair any components of the alarm system yourself. This should only be done by an authorized Volvo retailer.

pg. 49 Trunk/Tailgate

Unlocking the trunk/tailgate

The trunk/tailgate locks are incorporated in the central locking system and are locked or unlocked when the driver's door is locked/unlocked.

The trunk can be unlocked by:

· Pressing the button on the remote control (A) twice

· Using the master key in the trunk

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (9 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

· Using the trunk/tailgate control on the driver's door (B)

Refer to

page 44 for information on the remote control locking system.

Disconnecting the trunk lock

The trunk lock can also be disconnected from the central locking system by turning the key counterclocKWise as shown below:

Withdraw the key in the horizontal position ***

The trunk is now always locked. The optional folding rear seatback can also be locked from the trunk (see page 57). This feature can be used for e.g., valet parking. If you give only the service key to the driver, it will not be possible to gain access to the trunk. Please be aware that this setting may preclude access to the spare tire and jack.

To reconnect the lock to the central locking system:

Withdraw the key in the vertical position

*** In this position, the trunk cannot be opened with the control on the driver's door or the remote control.

Unlocking tailgate from the inside

Tailgate lock button

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (10 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

If the doors and tailgate are locked, the tailgate can be unlocked from the inside by pulling up the lock button (see illustration). This unlocks the tailgate only. Please note that this button will only function

if the child safety lock in the tailgate is disengaged (see

page 50).

WARNING!

Do not drive with the tailgate open! Poisonous exhaust gases may enter via the open tailgate.

pg. 50 Child safety locks (sedan/wagon)

Location and setting of child safety lock

Child safety locks (sedan/wagon)

The controls are located on the rear door jambs.

A The door cannot be opened from the inside. Normal operation from the outside.

B The door lock functions normally.

WARNING!

Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the buttons in position A.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (11 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Child safety lock in tailgate

Child safety lock (wagon - certain models)

The tailgate incorporates a safety catch which is located to the side of the lock.

A The tailgate cannot be opened from the inside.

B The tailgate functions normally.

NOTE: You must use the end of a key, screwdriver, etc. to move the child safety lock.

WARNING!

Remember, in the event of an accident, the tailgate cannot be opened from the inside when the safety catch is in position A.

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03a.htm (12 of 12)12/30/2006 3:43:40 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

pg. 51 Front seats

1 Height adjustment (manual)

The front section of both front seats can be adjusted to eight different height settings and the rear section of both seats can be adjusted to nine different height settings.

Front lever = adjustment of front section

Rear lever = adjustment of rear section

WARNING!

Do not adjust the seat while driving. The seat should be adjusted so that the brake pedal can be depressed fully. In addition, position the seat as far rearward as comfort and control allow. The seat rails on the floor must not be obstructed in any way when the seat is moved.

2 Forward-rearward seat adjustment (manual)

Pull the control upward, then slide the seat forward or rearward to the desired position. Make sure that the seat is properly secured when you release the control.

Folding front seat

The passenger's seat backrest has a quick forward release mechanism which can be used when long loads are carried. See

page 63.

3 Backrest tilt (manual)

Rotate the control counterclocKWise to tilt the backrest rearward and clocKWise to tilt the backrest forward.

4 Lumbar support *

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (1 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Firm: turn clockwise. Soft: turn counterclockwise.

* Driver's seat only on certain models

Electrically operated seats with memory function (certain models)

Power seat control panel

A Seat front (raise/lower) B Forward - rearward C Seat rear (raise/lower) D Backrest tilt

WARNING! The power driver's seat is operable with the ignition OFF. Therefore, children should never be left unattended in the car.

Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel.

To adjust the passenger's seat, the ignition key must be in position I or II.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (2 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Refer to the following page for information on programming the memory function.

pg. 52 Electrically operated driver's seat, Rear/side-view mirrors

Programming the memory

Three seat positions can be programmed. To program a seat position:

1 Adjust the seat to the desired position.

2 Depress the MEM button.

3 Press button 1 to program the current position of the seat.

Buttons 2 and 3 can be programmed in the same way. To move the seat to a programmed position, depress button 1, 2 or 3 until the seat stops. If the button is released before the seat has reached the programmed position, the seat will stop as a safety precaution.

NOTE: The seat has an overload protector which engages if an object blocks the movement of the seat. If this happens, remove the object and wait 20 seconds before operating the seat again.

Rear-view mirror

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (3 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

A Normal position

B Night position, reduces glare from following headlights

CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface.

WARNING!

The mirrors should always be adjusted prior to driving. Objects seen in the wide-angle right side-view mirror are closer than they appear to be.

Selector button

Adjustment control

Electrically operated side-view mirrors

The mirror control switches are located on the driver's door armrest. Press the left side of the selector button and then use the adjustment control to adjust the driver's door mirror. Press the right side of the selector button before adjusting the passenger door mirror.

A Horizontal adjustment

B Vertical adjustment

pg. 53 Interior lights, Vanity mirror

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (4 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Front courtesy lights

The front courtesy lighting consists of two reading lights for the front seat occupants.

Front and rear reading lights always on

Front and rear reading lights always off

Front and rear reading lights come on when a door is opened

Left or right reading light illuminates if the center switch is in position .

The courtesy lights remain illuminated for 30 seconds after the doors have been closed but will be switched off if the ignition is turned on or the doors are locked.

Reading lights, rear seat

There are two reading lights for the rear seat passengers. These are turned on/off by using the adjacent switches.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (5 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

Light is on if the front switch is in position .

Light turns on if any door is opened.

Vanity mirrors

The light illuminates when the cover is opened.

The driver's side vanity mirror will only illuminate if the ignition key is in position I.

pg. 54 Sun roof (option)

Ventilation position

Sliding sun roof

Electrically operated sun roof

The switch for operating the sun roof is located on the instrument panel. The starting

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (6 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

(ignition) key must first be turned to position II. On certain models, the sun roof is equipped with a onetouch, AUTO-open function.

· AUTO-open: Press the lower section of the switch once to automatically open the sun roof to the "comfort position" *. Press again to open the sun roof completely.

The AUTO-open function can be stopped at any time by pressing the switch.

· To close the sun roof: Depress the upper section of the switch until the sun roof has closed completely.

Sun visor

· To open the rear edge of the sun roof (ventilation position): With the sun roof closed, depress the upper section of the switch. To close, depress the lower section of the switch until the sun roof has closed completely.

· To slide open the sun roof : Depress the lower section of the switch until the sun roof has opened to the position you prefer or hold the switch until the sun roof reaches the "comfort position" *. Depress the lower section of the switch again to open the sun roof completely.

Sun visor: The sun roof also features a sliding sun visor. The visor slides back automatically when the sun roof is opened and also slides back slightly when the sun roof is opened to the ventilation position. The visor must be closed manually.

CAUTION: Do not close the sun visor when the sun roof is in the ventilation position as this could damage the mechanism. NOTE:

The electrically operated sun roof has an overload protecting circuit breaker (fuse no. 37) which is activated when an object blocks the sun roof. Should this occur, remove the object and wait 20 seconds for the circuit breaker to reset. The sun roof should then function normally. Also check fuse no. 35.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (7 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

WARNING! The sun roof must never be obstructed in any way when in operation.

* A position where the sun roof is not quite fully open. This position helps alleviate "rumbling" wind noise.

pg. 55 Hood

Hood release lever under dashboard

Hood release control under grille

To open the hood

· Pull the lever located under the left side of the dash to release the hood locks.

· Lift the hood slightly.

· Pull the release control on the inside of the lower edge of the grille toward you and lift the hood.

WARNING! Check that the hood locks properly when closed.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (8 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

The hood normally opens to an angle of 57°. The hood can be opened to the vertical position by rotating the hinge catches (see illustrations). The catches will return to their normal positions when the hood is closed.

Ensure adequate clearance in low-roof garages to avoid damaging the hood.

pg. 56 Storage compartments

WARNING! Packages on the rear window shelf can obscure vision and may become dangerous projectiles in the event of a sudden stop or an accident.

1 Compartment in hat shelf (sedan)

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (9 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

2 Pocket on rear of front seat 3 Glove compartment 4 Compartment between front seats/Cup holder (certain models) 5 Shelf under glove cmpartment 6 Compartment in door (certain models) 7 Clip for parking receipts 8 Pocket in seat front (certain models) 9 Coin holder 10 Rear cup holder

pg. 57 Trunk light, Spare tire, Jack (sedan)

Trunk light

A Light always off

B Light is on when the trunk lid is open

Spare tire

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (10 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

The spare tire is located under the carpet in a special well under the floor of the trunk. The jack is placed inside the wheel rim.

WARNING! Make sure that the jack is properly secured in the wheel rim with the securing bracket. The belt must also be threaded though the slot in the securing bracket (see illustration) and properly fastened to help keep the spare wheel/jack in place in the event of a sudden stop.

NOTE: See

pages 94-95 for information on how the jack should be used.

Contents | Top of Page

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03b.htm (11 of 11)12/30/2006 3:43:40 PM

2000 Volvo S & V70

2 0 0 0

VOLVO

S & V70

pg. 58 Cargo space lighting, Spare tire, Jack (wagon)

Cargo space lighting

There is an extra courtesy light at the rear of the cargo space.

A The light is always OFF.

B Light comes on when the tailgate is opened.

Spare tire and jack

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (1 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

The spare tire and the jack are located beneath the floor mat in the large storage bin.

NOTE: See

pages 94-95 for information on how the jack should be used.

pg. 59 Folding rear seat (sedan)

Folding rear seat

The rear seat is split into two sections so that each section can be folded independently.

· Lift the rear seat belts to the fixed section of the backrest. The center seat belt can also be folded across the fixed part of the backrest so that it does not get in the way if the right-hand backrest is folded down (see illustration above).

· Pull the catch forward and fold the backrest down.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (2 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

Locking levers

The two red levers on the rear side of the backrests can be used to bypass the folding

mechanism and prevent the backrests from being folded down from inside the car. Push the levers down to lock the backrests in the upright position. This function can be used to limit access to the trunk.

· When folding the backrests up, make sure the seat belts return to their normal positions.

WARNING! When the backrest is returned to the upright position, check that it is properly locked in place.

NOTE: If the backrest is folded down for prolonged periods, the seat belt locks could be covered (i.e., with a towel) to help avoid marks on the backrest upholstery.

pg. 60 Folding rear seat (wagon)

Seat cushion strap

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (3 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

Folding rear seat (wagon)

The rear seat is split into two sections so that each section can be folded independently.

· Straighten front seat backrests if they are tilted too far to the rear.

· Pull the strap to lift the rear seat cushion and swing the cushion up and toward the back of the front seats.

· The outboard head restraints must be lowered before the backrest is folded down (see inset illustration above): 1 - pull straight up, 2 - fold forward.

· Push the center head restraint straight down if it has been raised.

· Move the backrest release lever rearward and fold the backrest down.

Release lever - backrest

· Check that the hooks under the seat cushions engage the holes on the top edge of the backrest.

When the backrest is raised, the outboard head restraints must be returned to their normal positions.

Hooks fit into holes

The backrest must lock into place. The red lock indicator will not be visible if the seat has locked

into place correctly.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (4 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

The seat belts must be correctly positioned when the seat is returned to the normal position.

WARNING! When the rear seat is folded down, do not place heavy objects against the backs of the front seats. This places a severe strain on the folded down backrest of the rear seat. Be sure to secure cargo. Cargo must not be stacked higher than the top of seatbacks. This will reduce the possibility of luggage, etc. becoming projectiles during sudden maneuvers, rapid braking or an accident.

pg. 61 Folding rear seat, Removing seat cushions (wagon)

WARNING! The red lock indicator is VISIBLE (A) when the backrest is NOT locked in position and not visible (B) when the backrest is correctly locked in place. When the backrest is in the upright position, it must always be correctly locked in place.

Removing seat cushions

The seat cushion can be easily removed to provide a slightly larger cargo storage area.

· Fold the seat cushion toward the back of the front seats

· Release the red catches

· Disconnect the connector for the rear seat heating (certain models)

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (5 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

· Fold the cushion back to a nearly horizontal position

· Lift out the cushion

WARNING! Do not place extremely heavy articles against the front seats, as the backrest which is folded down is then placed under severe strain. Be sure to secure cargo. Hard and sharp articles could otherwise damage the front seat backrest and/ or cause injury to passengers in the event of rapid braking or a collision.

pg. 62 Concealed storage bin (wagon), Bumper cover (wagon), Avoiding battery drain

The lid of the storage compartment is hinged in the middle

Concealed storage bin

The storage compartment under the floor of the cargo space is hinged in the middle and can be locked with a key.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (6 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

Bumper cover (certain models)

A bumper cover is located in the concealed storage bin. This cover can be folded out when loading/ unloading the cargo compartment to protect your clothing and to help protect the bumper from scratches.

The bumper cover can also be used to protect the floor of the storage bin from muddy shoes, etc. if the optional auxiliary child seat is being used.

The bumper cover is attached by a velcro strip and can easily be removed for cleaning.

To avoid battery drain

The courtesy lights and the warning lights in the rear of the doors come on when a door is opened.

• To avoid battery drain when the doors are opened for prolonged periods, these lights can be switched off by pressing the lock mechanism (A) located in the rear facing side of the driver's door.

• To return the lights to their normal function, pull the door handle out before closing the door (B) and use a small screwdriver to push the lock mechanism back to its original position.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (7 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

pg. 63 Luggage net, Side cargo net - wagon (certain models)

Luggage net (option)

The luggage net helps prevent cargo from being thrown forward should the vehicle stop suddenly or be involved in an accident.

The net unreels from the rear upper edge of the rear seat backrest and must be accessed from the cargo compartment.

1 Open the cover on the passenger side seat back and pull the luggage net toward you.

2 Hook the rod onto the bracket on the right side ceiling (A).

Pull out the left side of the rod and attach it to the bracket on the driver's side ceiling (B).

3 Unreel the driver's side luggage net.

4 Hook it to the rod.

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (8 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

Make sure the nets are securely attached to the hooks under the covers and pulled taut.

Use the reverse procedure to retract the net.

NOTE: The luggage net can also be used when the rear seat is folded down. However, extra brackets (optional) must be installed on the upper rear door hand grips.

WARNING! If your car is equipped with an auxiliary child seat in the cargo compartment, the cargo net must be retracted before using the child seat. Otherwise, in the event of a sudden stop or accident, the child could be injured and the net could hinder rapid access to the cargo compartment.

Side cargo net

To install the side cargo net, slide the rounded hook on the net through the cargo eyelet (1), slide the wire frame of the net into the clips provided and press the lower wire into the hole in the floor (2) and secure the upper rear corner of the cargo net in the clip (3).

WARNING! Never use this net to secure sharp or heavy objects. In such cases, tie down the object using the cargo eyelets in the cargo compartment. The net should not be used if the optional auxiliary child seat is occupied. The side cargo net should only be used in combination with the luggage net.

pg. 64 Securing cargo

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (9 of 12)12/30/2006 3:43:41 PM

2000 Volvo S & V70

Eyelets in trunk (sedans)

Securing cargo

As a safety precaution, your car is equipped with two eyelets in the trunk (four in the cargo space on wagons) to which straps can be attached to secure luggage.

WARNING! The eyelets are not to be used as passenger restraints or as anchorages for child restraints. See page

14.

Wagons only:

Unless the station wagon is equipped with Volvo's auxiliary seat for children (option) passengers should not ride in the rear cargo area.

Eyelets in cargo area (wagons)

Wagons only:

If the optional auxiliary seat for children is in use, fold this seat down before folding down

file:///K|/ownersdocs/2000/2000_SV70/00sv70_03c.htm (10 of 12)12/30/2006 3:43:41 PM

Volvo S70 2000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
