Volvo S60t8 2020 Owner's Manual

Download
S60
T W I N E N G I N E
OWNER'S MANUAL
VÄLKOMMEN!
We hope your Volvo will give you many years of happy motoring. The vehicle is designed for the safety and comfort of you and your passengers. Volvo strives to design one of the world's safest pas­senger vehicles. Your Volvo is also designed to meet applicable safety and environmental requirements.
To increase your enjoyment of your Volvo, we recommend that you read the instructions and maintenance information contained in this
owner's manual. The owner's manual is also available as a mobile app (Volvo Manual) and on Volvo Cars support page (support.volvocars.com).
We also encourage everyone to always use seat belts in this and other vehicles. You should also not drive if you are under the influ­ence of alcohol or medicines or if your ability to drive is for some other reason impaired.
2
OWNER'S INFORMATION
Owner's information
16
Owner's Manual in the center display
17
Navigate in the Owner's Manual in the center display
18
Owner's manual in mobile devices
20
Volvo Cars support site
21
Using the Owner's Manual
21
The Owner's Manual and the envi­ronment
23
YOUR VOLVO
Contacting Volvo
26
Volvo ID
26
Creating and registering a Volvo ID
27
Drive-E ‒ purer driving pleasure
28
IntelliSafe – driver support and safety
29
Sensus - connection and enter­tainment
30
Software Updates
33
Data recording
33
Terms & Conditions for Services
35
Customer Privacy Policy
35
Important information on acces­sories and extra equipment
35
Accessory installation
36
Connecting equipment to the vehicle's data link connector
37
Technician certification
38
Viewing the Vehicle Identification Number (VIN)
38
Volvo Structural Parts Statement
39
Driver distraction
39
SAFETY
Safety
42
Safety during pregnancy
43
Occupant safety
43
Reporting safety defects
44
Recall information
45
Whiplash Protection System
46
Seat belts
47
Buckling and unbuckling seat belts
48
Seat belt tensioners
50
Resetting the electric seat belt tensioners*
51
Door and seat belt reminders
51
Airbags
52
Driver/passenger-side airbags
53
Occupant weight sensor
56
Side airbags
60
Inflatable curtain
60
Safety mode
61
Starting and moving the vehicle when it is in safety mode
62
Child safety
63
Child restraints
65
Infant seats
67
Convertible seats
69
Booster cushions
72

TABLE OF CONTENTS

3
Top tether anchors
73
Lower child seat attachment points
74
ISOFIXLATCH lower anchors
75
DISPLAYS AND VOICE CONTROL
Instruments and controls in left­hand drive vehicles
78
Instrument panel
80
Instrument panel settings
82
Fuel gauge
83
Hybrid gauge
83
Hybrid battery gauge
84
Trip computer
85
Displaying trip data in the instru­ment panel
87
Resetting the trip odometer
88
Displaying trip statistics in the center display
88
Trip statistics settings
89
Date and time
90
Ambient temperature sensor
90
Indicator symbols in the instru­ment panel
91
Warning symbols in the instru­ment panel
94
Instrument panel licenses
95
App menu in instrument panel
101
Handling the App menu in the instrument panel
102
Messages in the instrument panel
103
Handling messages in the instru­ment panel
104
Handling messages saved from the instrument panel
105
Center display overview
107
Handling the center display
109
Activating and deactivating the center display
112
Navigating in the center display's views
112
Handling tiles in the center display
116
Function view in the center display
119
Moving apps and buttons in the center display
121
Symbols in the center display sta­tus bar
121
Using the center display keyboard
123
Changing keyboard language in the center display
126
Entering characters, letters and words by hand in the center display
126
Changing the appearance of the center display
128
Turning off and adjusting the vol­ume of the center display system sounds
128
Changing system units of meas­urement
129
Changing system language
129
4
Changing settings in the center display's Top view
129
Opening contextual setting in the center display
130
Resetting user data when the vehicle changes owners
131
Resetting center display settings
131
Table of settings in the center display
132
Driver profiles
133
Selecting a driver profile
134
Changing a driver profile's name
134
Protecting a driver profile
135
Linking a remote key to a driver profile
135
Resetting driver profile settings
137
Messages in the center display
137
Handling messages in the center display
138
Handling messages saved from the center display
138
Head-up display*
139
Activating and deactivating the head-up display*
141
Head-up display settings*
141
Voice Control
142
Use voice recognition
143
Voice control for cellular phones
145
Voice control for radio and media
146
Voice control settings
147
LIGHTING
Lighting control and panel
150
Adjusting light functions via the center display
151
Adjusting the headlight pattern
152
Parking lights
152
Daytime running lights
153
Low beams
154
Using high beam
154
Active high beam
155
Using turn signals
156
Active Bending Lights*
157
Front fog lights/corner illumination*
157
Rear fog light
158
Brake lights
159
Emergency brake lights
159
Hazard warning flashers
160
Using home safe lighting
160
Welcome Light
160
Interior Lighting
161
Adjusting interior lighting
162
5
WINDOWS, GLASS AND MIRRORS
Windows, glass and mirrors
166
Pinch protection for windows and sun curtains
166
Reset procedure for pinch protection
167
Power windows
167
Operating the power windows
168
Using sun curtains*
169
Rearview/door mirrors
170
Adjusting the rearview mirror dim­ming function
170
Adjusting the door mirrors
171
Panoramic roof*
172
Operating the panoramic roof*
174
Auto closing the panoramic roof* sun curtain
176
Wiper blades and washer fluid
177
Using the windshield wipers
177
Using the rain sensor
178
Using the rain sensor's memory function
179
Using the windshield and head­light washers
179
SEATS AND STEERING WHEEL
Manual front seats
182
Power* front seats
183
Adjusting the power* front seats
183
Storing positions for seats, mir­rors and head-up display*
184
Using stored positions for seats, mirrors and head-up display*
185
Front seat massage* settings
186
Adjusting front seat massage set­tings*
187
Adjusting* front seat cushion length
188
Adjusting front seat side bolster settings*
189
Adjusting front seat lumbar support*
189
Adjusting the passenger seat from the driver's seat*
191
Folding down the rear seat backrests*
192
Adjusting the rear seat head restraints
193
Steering wheel controls and horn
194
Adjusting the steering wheel
195
CLIMATE CONTROL
Climate
198
Climate zones
198
Climate control sensors
198
Perceived temperature
199
Climate control system voice commands
199
Air quality
200
Clean Zone*
201
Clean Zone Interior Package*
201
Interior Air Quality System*
202
Activating and deactivating the air quality sensor*
202
Passenger compartment air filter
203
Air distribution
203
Adjusting air distribution
204
Opening, closing and directing air vents
204
Air distribution options
206
Climate system controls
209
Activating and deactivating power front seats*
210
Activating and deactivating the heated front seat*
211
Activating and deactivating the heated rear seats*
211
Activating and deactivating front seat ventilation*
211
6
Activating and deactivating the heated steering wheel*
212
Activating and deactivating auto­matic steering wheel heating*
212
Activating auto climate control
213
Activating and deactivating recir­culation
213
Activating and deactivating the recirculation timer setting
214
Activating and deactivating max defroster
214
Activating and deactivating the heated rear window and door mirrors
215
Automatically activating and deac­tivating the heated rear window and door mirrors
216
Setting the blower speed for the front seats
216
Setting the temperature for the front seats
217
Synchronize temperature
218
Activating and deactivating air conditioning
219
Parking climate
219
Preconditioning
220
Starting and stopping preconditioning
220
Preconditioning timer
221
Adding and editing timer settings for preconditioning
222
Activating and deactivating pre­conditioning timer
223
Deleting preconditioning timer settings
223
Climate comfort retaining function
224
Starting and switching off the cli­mate retaining function when parking
224
Parking climate symbols and mes­sages
226
Heater
227
Parking heater
227
Additional heater
227
Activating and deactivating the auxiliary heater
228
KEY, LOCKS AND ALARM
Lock indication
230
Lock confirmation settings
231
Remote key
232
Locking and unlocking using the remote key
234
Settings for remote and inside door unlock
235
Remote key range
235
Replacing the remote key's battery
236
Ordering additional remote keys
239
Red Key - restricted remote key*
240
Settings for Red Key*
241
Detachable key blade
242
Locking and unlocking with detachable key blade
243
Electronic immobilizer
244
Start and lock system type desig­nations
245
Keyless and touch-sensitive surfaces*
246
Keyless locking and unlocking*
247
Keyless unlock settings*
248
Keyless trunk lid unlock*
249
Antenna locations for the start and lock system
249
Locking and unlocking from inside the vehicle
250
7
Unlocking the trunk lid from inside the vehicle
251
Opening the trunk lid from inside the trunk
252
Activating and deactivating child safety locks
252
Automatic locking when driving
254
Opening and closing the trunk lid with foot movement*
254
Private Locking
255
Activating and deactivating pri­vate locking
255
Alarm
256
Arming and disarming the alarm
257
DRIVER SUPPORT
Driver support systems
260
Speed-dependent steering wheel resistance
260
Electronic Stability Control
261
Electronic Stability Control in sport mode
262
Activating or deactivating Sport mode for Electronic Stability Control
263
Electronic Stability Control sym­bols and messages
264
Distance Alert*
265
Activating or deactivating Dis­tance Alert
266
Distance Alert limitations
266
Cruise control
267
Selecting and activating cruise control
268
Deactivating cruise control
269
Cruise control standby mode
269
Adaptive Cruise Control*
270
Adaptive Cruise Control* controls and display
271
Selecting and activating Adaptive Cruise Control*
272
Deactivating Adaptive Cruise Control*
273
Adaptive Cruise Control* standby mode
274
Adaptive Cruise Control* limitations
275
Switching between cruise control and Adaptive Cruise Control* in the center display
276
Symbols and messages for Adap­tive Cruise Control*
277
Pilot Assist*
279
Pilot Assist* controls and display
281
Selecting and activating Pilot Assist*
282
Deactivating Pilot Assist*
283
Pilot Assist* standby mode
284
Temporarily deactivating steering assistance with Pilot Assist*
285
Pilot Assist* limitations
285
Pilot Assist* symbols and messages
287
Collision risk warning from driver support
288
Switching target vehicles with driver support
289
Adjusting set speed for driver support
290
Setting time interval to the vehicle ahead
291
Auto-hold braking with driver support
292
Drive mode for driver support
293
Curve Speed Assist (CSA)*
294
Activating or deactivating Curve Speed Assist (CSA)*
295
Curve Speed Assist (CSA)* limitations
295
8
Passing assistance
296
Using passing assistance
296
Radar sensor
297
Radar sensor type approval
298
Camera
300
Camera/radar sensor limitations
301
Recommended camera and radar sensor maintenance
305
City Safety™
306
City Safety sub-functions
307
Setting a warning distance for City Safety
309
Detecting obstacles with City Safety
310
City Safety in crossing traffic
312
Limitations of City Safety in cross­ing traffic
313
City Safety steering assistance for evasive maneuver
314
City Safety steering assistance limitations during evasive maneuvers
314
Automatic braking during delayed evasive maneuvers with City Safety
315
City Safety braking for oncoming vehicles
315
City Safety limitations
316
City Safety messages
319
Rear Collision Warning*
320
Rear Collision Warning* limitations
320
BLIS*
321
Activating or deactivating BLIS
322
BLIS limitations
323
BLIS messages
324
Cross Traffic Alert*
325
Activating or deactivating Cross Traffic Alert*
326
Cross Traffic Alert* limitations
326
Cross Traffic Alert* messages
328
Road Sign Information*
329
Activating or deactivating Road Sign Information*
330
Road Sign Information* display
330
Road Sign Information and Sensus Navigation*
331
Speed limit and speed camera warnings from Road Sign Information*
331
Activating or deactivating warn­ings from Road Sign Information*
332
Road Sign Information* limitations
333
Driver Alert Control
334
Activating or deactivating Driver Alert Control
335
Selecting guidance to a rest area if the Driver Alert Control warning has been given
335
Driver Alert Control limitations
336
Lane Keeping Aid
336
Activating or deactivating Lane Keeping Aid
338
Selecting type of assistance for Lane Keeping Aid
338
Lane Keeping Aid limitations
339
Lane Keeping Aid symbols and messages
340
Lane Keeping Aid display
342
Steering assistance at risk of collision
343
Activating or deactivating steering assistance during collision risks
344
Run-Off Mitigation with steering assistance
344
Steering assistance during colli­sion risks from oncoming traffic
345
Steering assistance during colli­sion risks from behind*
346
Steering assistance during colli­sion risks limitations
347
Symbols and messages for steer­ing assistance during collision risks
348
Park Assist*
349
Park Assist front, rear and sides*
350
Activating or deactivating Park Assist*
351
Park Assist limitations
351
Park Assist symbols and messages
353
9
Park Assist Camera*
354
Location and field of vision of Park Assist Cameras*
355
Park Assist Camera trajectory lines*
357
Park Assist sensor field
359
Activating Park Assist Camera
360
Park Assist Camera symbols and messages
362
Park Assist Pilot*
363
Types of parking with Park Assist Pilot*
364
Using Park Assist Pilot*
365
Leaving a parallel parking space with Park Assist Pilot*
368
Park Assist Pilot* limitations
368
Park Assist Pilot* messages
371
HYBRID INFORMATION
General information about Twin Engine
374
Charging the hybrid battery
375
Charging current
377
Charge cable
377
Charging cable residual current device
379
Charging cable temperature moni­toring
380
Opening and closing the charging socket cover
380
Initiating hybrid battery charging
380
Charging status in the vehicle's charging socket
382
Charging status in the charging cable's charging module
383
Charging status in the instrument panel
384
Stopping hybrid battery charging
386
Twin Engine symbols and mes­sages in the instrument panel
388
Long-term storage of vehicles with hybrid batteries
390
STARTING AND DRIVING
Starting the vehicle
392
Switching off the vehicle
394
Ignition modes
395
Selecting ignition mode
396
Brake functions
397
Brakes
397
Brake Assist System
399
Braking on wet roads
399
Braking on salted roads
400
Maintenance of the brake system
400
Parking brake
400
Activating and deactivating the parking brake
401
Settings for automatically activat­ing the parking brake
402
Parking on a hill
403
Parking brake malfunction
403
Auto-hold brakes
404
Activating and deactivating Auto­hold at a standstill
405
Hill Start Assist
405
Braking assist after a collision
406
Transmission
406
Automatic transmission
406
Gear selector positions for auto­matic transmissions
407
10
Using the steering wheel paddles* to shift
409
Shiftlock
410
The kickdown function
411
All Wheel Drive (AWD)
411
Drive systems
412
Starting and stopping the com­bustion engine in Twin Engine vehicles
413
Drive modes
413
Changing drive mode
417
Energy distribution in hybrid mode using map data*
418
Leveling control* and suspension
419
Adjusting suspension settings Polestar Engineered*
420
Economical driving
421
Factors affecting electric motor range
423
Hold and Charge functions
424
Preparing for a long trip
425
Winter driving
425
Driving through standing water
426
Opening/closing the fuel filler door
427
Refueling
428
Fuel
429
Octane rating
430
Emission controls
432
Overheating of engine and trans­mission
433
Battery drain
434
Jump starting using another battery
434
Driving with a trailer
436
Trailer Stability Assist*
438
Checking trailer lights
439
Towing using a towline
440
Attaching and removing the tow­ing eyelet
441
Recovery
442
HomeLink®*
442
Programming HomeLink®*
443
Using HomeLink®*
445
Type approval for HomeLink®*
446
Compass*
446
Activating and deactivating the compass*
447
Calibrating the compass*
447
AUDIO, MEDIA AND INTERNET
Audio, media and Internet
450
Sound settings
450
Sound experience*
451
Apps
452
Download apps
453
Updating apps
453
Deleting apps
454
Radio
454
Starting the radio
455
Changing waveband and radio station
456
Searching for a radio station
456
Storing radio channels in the Radio favorites app
457
Radio settings
458
RBDS
458
HD Radio™
459
Activating and deactivating the HD Radio™
460
HD Radio™ sub-channels
460
HD Radio™ limitations
461
SiriusXM® Satellite radio*
462
Using SiriusXM® Satellite radio*
463
Settings for SiriusXM® Satellite radio*
464
SiriusXM Travel Link®*
466
SiriusXM Travel Link®* - Weather
467
11
SiriusXM Travel Link®* - Notifications
468
SiriusXM Travel Link®* - Fuel
469
SiriusXM Travel Link®* - Sports
470
Media player
471
Playing media
472
Controlling and changing media
473
Media searches
474
Gracenote
®
475
CD player*
475
Video
476
Playing video
476
Playing DivX®
476
Video settings
477
Streaming media via Bluetooth
®
477
Connecting a device via Bluetooth
®
477
Playing media via the USB port
478
Connecting a device via the USB port
478
Technical specifications for USB devices
479
Compatible file formats for media
479
Apple® CarPlay®*
480
Using Apple® CarPlay®*
481
Settings for Apple® CarPlay®*
483
Tips for using Apple® CarPlay®*
483
Android Auto*
484
Using Android Auto*
485
Settings for Android Auto*
486
Tips for using Android Auto*
486
Phone
487
Connecting a phone to the car via Bluetooth for the first time
488
Connecting a phone to the car via Bluetooth automatically
490
Connecting a phone to the car via Bluetooth manually
490
Disconnecting a Bluetooth-con­nected phone
490
Switch between phones con­nected via Bluetooth
491
Disconnecting Bluetooth-con­nected devices
491
Handling phone calls
491
Handling text messages
492
Text message settings
493
Managing the phone book
494
Phone settings
494
Settings for Bluetooth devices
495
Internet-connected vehicle*
496
Connecting the vehicle to the Internet via a Bluetooth-connected phone
497
Connecting the vehicle to the Internet via a phone (Wi-Fi)
497
Connecting the vehicle to the Internet via vehicle modem (SIM card)
498
Vehicle modem settings
499
Sharing Internet from the vehicle via Wi-Fi hotspot (tethering)
500
No or poor Internet connection
501
Deleting Wi-Fi networks
501
Wi-Fi technology and security
502
Terms of use and data sharing
502
Activating and deactivating data sharing
503
Data sharing for services
503
Hard disk storage space
504
License agreement for audio and media
505
12
VOLVO ON CALL
Planning and scheduling vehicle charging with the Volvo On Call app
516
WHEELS AND TIRES
Tires
518
Tire direction of rotation
520
Tread wear indicator
521
Tire terminology
521
Tire sidewall designations
522
Uniform Tire Quality Grading
524
Checking tire pressure
525
Adjusting tire pressure
526
Recommended tire pressure
527
Tire pressure monitoring system*
527
Saving a new inflation pressure in the monitoring system*
529
Viewing tire pressure status in the center display*
530
Action when warned of low tire pressure
531
When changing wheels
532
Tool kit
532
Jack*
533
Wheel bolts
533
Removing a wheel
534
Installing a wheel
536
Spare wheel
537
Handling spare tires
538
Snow tires
539
Snow chains
540
Tire sealing system
541
Using the tire sealing system
542
Inflate tires with the compressor included in the tire sealing system
545
Determining the vehicle's permit­ted weight
546
13
LOADING, STORAGE AND PASSENGER COMPARTMENT
Passenger compartment interior
550
Tunnel console
551
Electrical outlets
552
Using the electrical outlets
554
Using the glove compartment
555
Sun visors
557
Cargo compartment
557
Loading recommendations
557
Roof loads and load carriers
558
Grocery bag holders
559
Load anchoring eyelets
560
Rear seat ski hatch*
560
MAINTENANCE AND SERVICE
Volvo's service program
562
Data transfer between vehicle and workshop over Wi-Fi
565
Download Center
565
Handling system updates via Download Center
566
Vehicle status
567
Scheduling service and repairs
567
Sending vehicle information to the workshop
568
Hoisting the vehicle
569
Climate control system service
571
Replacing a windshield with head­up display*
571
Opening and closing the hood
571
Engine compartment overview
573
Engine oil
574
Checking and filling engine oil
575
Refilling coolant
576
Replacing bulbs
578
Start battery
579
Hybrid battery
583
Battery symbols
584
Battery recycling
584
Fuses and fuseboxes
585
Replacing fuses
585
Fuses in the engine compartment
587
Fuses under the glove compartment
594
Fuses in the trunk
600
Cleaning the interior
605
Cleaning the center display
605
Cleaning the head-up display*
606
Cleaning fabric upholstery and ceiling liner
607
Cleaning the seat belt
607
Cleaning floor mats and inlay mats
607
Cleaning leather upholstery*
608
Cleaning the leather steering wheel
609
Cleaning interior plastic, metal and wood surfaces
609
Cleaning the exterior
610
Polishing and waxing
610
Hand washing
611
Automatic car washes
613
High-pressure washing
614
Cleaning the wiper blades
614
Cleaning exterior plastic, rubber and trim components
615
Cleaning rims
616
Corrosion protection
616
Paintwork
617
14
Touching up minor paint damage
617
Color codes
618
Replacing windshield wiper blades
619
Putting the wiper blades in service position
620
Filling washer fluid
621
SPECIFICATIONS
Type designations
624
Dimensions
627
Weights
629
Towing capacity and tongue weight
630
Engine specifications
631
Engine oil specifications
632
Coolant specifications
633
Transmission fluid specifications
633
Brake fluid specifications
633
Fuel tank volume
634
Air conditioning specifications
634
Approved tire pressure
635
INDEX
Index 637
OWNER'S INFORMATION

OWNER'S INFORMATION

16

Owner's information

Owner's information is available in several different formats, both digital and printed. The Owner's Manual is available on the vehi­cle's center display, as a mobile app and on Volvo Cars' support website. There is also a Quick Guide in the glove compartment, as well as a supplement to the Owner's Manual containing information about e.g. fuses, spec­ifications, etc. A printed Owner's Manual can be ordered.

Vehicle's center display

1
In the center display, pull down Top view and tap
Owner's manual. This gives
you access to visual naviga­tion with exterior and interior images of the vehicle. The information is searchable and
is divided into categories.

Mobile app

In App Store or Google Play, search for "Volvo Manual". Download the app to your smartphone or tablet and select your vehicle model. The app contains instructive
videos and offers visual navi­gation, including exterior and interior images of the vehicle. The contents are searchable and the sections are designed to be easy to navigate.

Volvo Cars support site

Go to support.volvocars.com and select your country. Owner's Manuals are availa­ble here for viewing online and in PDF format. The sup­port site also contains
instructive videos and addi­tional information and assistance concerning your vehicle and owning a Volvo. The website is available on most markets.

Printed information

The glove compartment con-
tains a printed supplement to
the Owner's Manual1, which
contains information on fuses
and specifications as well as
a summary of important and
practical information. There is also a printed Quick Guide with useful
information about the most commonly used features and functions in your vehicle.
Other printed information may also be provi­ded in the vehicle, depending on equipment level, market, etc.
A printed Owner's Manual and accompanying supplement can also be ordered. Contact a Volvo retailer to order.
1
For markets without Owner's Manuals in the center display, a complete printed manual is provided along with the vehicle.
OWNER'S INFORMATION
}}
17
CAUTION
The driver is always responsible for operat­ing the vehicle in a safe manner and adher­ing to all applicable laws and regulations. It is also important that the vehicle is oper­ated, maintained and serviced according to Volvo's recommendations provided in the owner's information.
If the information in the center display dif­fers from the printed information, the prin­ted information always takes precedence.
NOTE
Changing languages in the center display could mean that certain owner's informa­tion will not comply with national or local laws and regulations. Do not change to a language you do not speak well, as it can be difficult to find your way back through the menu.

Related information

•
Owner's Manual in the center display (p. 17)
•
Owner's manual in mobile devices (p. 20)
•
Volvo Cars support site (p. 21)
•
Using the Owner's Manual (p. 21)

Owner's Manual in the center display

A digital version of the Owner's Manual is available in the vehicle's center display2.
The digital Owner's Manual can be accessed from Top view and in certain cases, the con­textual Owner's Manual can also be accessed from Top view.
NOTE
The digital Owner's Manual is not available during driving.
OWNER'S MANUAL
Top view with button for Owner's Manual.
To open the Owner's Manual, pull down Top view in the center display and tap
Owner's
manual.
The information in the Owner's Manual can be accessed directly via the Owner's Manual start page or via its Top menu.
2
Available in most markets.
||
OWNER'S INFORMATION
18
Contextual Owner's Manual
Top view with button for contextual Owner's Manual.
The contextual Owner's Manual is a shortcut to an article in the Owner's Manual describing the active function displayed on the screen. When a contextual Owner's Manual is availa­ble, it will be shown to the right of
Owner's
manual in Top view.
Tap the contextual Owner's Manual to open an article in the Owner's Manual related to the information displayed on the screen. For example, tap
Navigation Manual to open
an article related to navigation. Certain apps in the vehicle only. For downloa-
ded third-party apps, it is e.g. not possible to access app-specific articles.

Related information

•
Navigate in the Owner's Manual in the center display (p. 18)
•
Navigating in the center display's views (p. 112)
•
Download apps (p. 453)

Navigate in the Owner's Manual in the center display

The digital Owner's Manual can be accessed from the center display's Top view. The con­tents are searchable and the sections are designed to be easy to navigate.
The Owner's Manual is accessed from Top view.
–
To open the Owner's Manual, pull down Top view in the center display and tap
Owner's manual.
There are a number of ways to find informa­tion in the Owner's Manual. The options can be accessed from the Owner's Manual start page and from the Top menu.
OWNER'S INFORMATION
}}
19

Opening the menu in the Top menu

–
Tap in the upper list in the Owner's Manual.
> A menu will open, displaying different
options for finding information:
Start page
Tap the symbol to return to the Owner's Manual start page.
Categories
The articles in the Owner's Manual are structured into main and sub-categories. The same article may appear in several relevant categories in order to help make them eas­ier to find.
1.
Tap
Categories.
> The main categories are listed.
2.
Tap a main category (
).
>
A list of sub-categories (
) and articles
(
) will appear.
3. Tap an article to open it. To go back, tap the left arrow.
Quick Guide
Tap the symbol to go to a page with links to a selection of useful articles about the vehicle's more commonly used features and functions. The articles can also be
accessed via categories, but have been collected here for quicker access. Tap an article to read it in its entirety.
Exterior and interior hotspots
Exterior and interior over-
views of the vehicle. Hot-
spots are provided for certain
functions, components, etc.
Tap a hotspot to come to a
relevant article.
1.
Press
Exterior or Interior.
> Exterior or interior images of the vehicle
are shown with hotspots. The hotspots lead to articles about the corresponding function, component, etc. Swipe the screen horizontally to scroll between the images.
2. Tap a hotspot. > The title of a relevant article will be dis-
played.
3. Tap the title to open the article.
To go back, tap the left arrow.
Favorites
Tap the symbol to go to arti­cles saved as favorites. Tap an article to read it in its entirety.
Saving or deleting favorite articles
Save an article as a favorite by tapping the at the upper right when the article is open. When an article has been saved as a favorite,
the star symbol will be filled in:
.
To remove an article from the list of favorites, tap its star again.
Video
Tap the symbol to go to brief instructive videos for various functions in the vehicle.
||
OWNER'S INFORMATION
20
Information
Tap the symbol for informa­tion about the current version of the Owner's Manual in your vehicle and other useful information.

Using the search function in the Top menu

1.
Tap in the Owner's Manual upper menu. A keyboard will appear at the bot­tom of the screen.
2. Enter a search word, e.g. "seat belt". > Suggested articles and categories will
be displayed as characters are entered.
3. Tap the article or category to read it.

Related information

•
Owner's Manual in the center display (p. 17)
•
Using the center display keyboard (p. 123)
•
Using the Owner's Manual (p. 21)

Owner's manual in mobile devices

The Owner's Manual is available as a mobile app3 and can be downloaded from the App Store and Google Play. The app is adapted for both smartphones and tablets.
The Owner's Manual can be downloaded as a mobile app from the App Store or Google Play. This QR code will take you directly to the app. You can also search for "Volvo manual" in the App Store or
Google Play. The app contains videos and exterior/interior
images of the vehicle. These images contain hotspots for various functions, components, etc., which lead directly to related information.
The contents are searchable and the sections are designed to be easy to navigate.
The mobile app is available on both App Store and Google Play.

Related information

•
Using the Owner's Manual (p. 21)
3
Certain mobile devices.
OWNER'S INFORMATION
}}
* Option/accessory.
21

Volvo Cars support site

Volvo Cars' website and support site contain additional information about your vehicle.

Online support

Go to support.volvocars.com to visit the site. The support site is available in most markets.
The site contains support for e.g. Internet­based services and functions, Volvo On Call, the navigation system* and apps. Videos and step-by-step instructions explain various pro­cedures, such as how to connect the vehicle to the Internet via a cellular phone.

Downloadable information

Maps
For vehicles equipped with Sensus Navigation maps can be downloaded from the support site.
Mobile apps
Beginning with model year 2014, the Owner's Manual is available as an app for certain Volvo models. The Volvo On Call app can also be downloaded from the support site.
Owner's manuals in PDF format
Owner's Manuals are available for download­ing in PDF format. Select the vehicle model and year to download the desired manual.

Contact

Contact information for customer support and your nearest Volvo retailer are available on the support site.

Related information

•
Contacting Volvo (p. 26)
•
Volvo ID (p. 26)

Using the Owner's Manual

To get to know your new vehicle, read the Owner's Manual before driving it for the first time.
Reading your Owner's Manual is a way to familiarize yourself with new features and functions, get advice on how to handle your vehicle in different situations, and to learn how to take advantage of everything your Volvo has to offer. Pay particular attention to the safety warnings provided in the Owner's Manual.
The intention of this owner's information is to explain all of the possible features, functions, options and accessories included in a Volvo vehicle. It is not intended as an indication or guarantee that all of these features, functions and options are included in every vehicle. Some terminology used may not exactly match terminology used in sales, marketing and advertising materials.
Volvo continuously works to develop and improve our products. Modifications can mean that information, descriptions and illustrations in the Owner's Manual differ from the equip­ment in the vehicle. We reserve the right to make changes without prior notice.
Do not remove this manual from the vehicle. If a problem should occur, you will not have the necessary information on where and how to get professional assistance.
© Volvo Car Corporation
||
OWNER'S INFORMATION
* Option/accessory.
22

Option/accessory

In addition to standard equipment, the Owner's Manual also describes options (fac­tory-installed equipment) and certain accesso­ries (extra retrofitted equipment).
All, at the time of publication known, options and accessories are marked with an asterisk: *.
The equipment described in the Owner's Man­ual is not available in all vehicles. Vehicles may be equipped differently depending on market requirements and national or local laws and regulations.
For more information on which equipment is standard and which is an option or accessory, please contact your Volvo retailer.

Decals

There are various types of decals affixed in the vehicle to communicate important information in a clear manner. The importance of these decals is explained as follows, in descending order of importance.
Risk of injury
Black ISO symbols on a yellow warning field, white text/image on a black message field. Used to indicate potential danger. Ignoring a warning of this type could result in serious injury or death.
Risk of damage
White ISO symbols and white text/image on a black or blue warning field and message field. Used to indicate potential danger. Ignoring a warning of this type could result in damage.
Information
White ISO symbols and white text/image on a black message field.
NOTE
The decals shown in the Owner's Manual do not claim to be exact reproductions of those found in the vehicle. The purpose is to show approximately how they look and about where they are located. The informa­tion that applies for your vehicle in particu­lar is found on the decal on the vehicle.
OWNER'S INFORMATION
23

Illustrations, images and video clips

Illustrations, images and video clips used in the Owner's Manual are sometimes generic and are intended to provide an overview or an example of a certain function or feature. They may vary depending on equipment level and market and may differ from the appearance of your vehicle.

Related information

•
Owner's Manual in the center display (p. 17)
•
Owner's manual in mobile devices (p. 20)
•
Volvo Cars support site (p. 21)

The Owner's Manual and the environment

The Owner's Manual is printed on paper from responsibly managed forests.
The Forest Stewardship Council (FSC)® sym­bol certifies that the paper pulp in the printed Owner's Manual comes from FSC®-certified forests or other responsibly managed sources.

Related information

•
Drive-E ‒ purer driving pleasure (p. 28)
YOUR VOLVO

YOUR VOLVO

26

Contacting Volvo

Use the following contact information if you would like to get in touch with Volvo in the United States or Canada.
In the USA:
Volvo Car USA, LLC Customer Care Center 1 Volvo Drive, P.O. Box 914 Rockleigh, New Jersey 07647 18004581552 www.volvocars.com/us
In Canada:
Volvo Car Canada Ltd. Customer Care Centre 9130 Leslie Street, Suite 101 Richmond Hill, Ontario L4B 0B9 18006638255 www.volvocars.com/ca

Volvo ID

Volvo ID is a personal ID that gives you access to a range of services using a single username and password.
NOTE
The available services can vary over time and depend on equipment level and mar­ket.
Examples of services:
•
Volvo On Call-app - check your vehicle using your phone. You can check fuel level, find the nearest gas station and lock the vehicle remotely.
•
Send to Car – send addresses from online map services directly to the vehicle.
•
Send a request for service and repairs directly from the vehicle. The booking will then be completed via email.
NOTE
If the username/password for a service (e.g. Volvo On Call) is changed, the change will also automatically be applied to other services.
The creation of a Volvo ID is initiated through the Volvo On Call app or from the vehicle and then completed by email.
When a Volvo ID is registered in the vehicle, additional services are available. Multiple Volvo IDs can be used for the same vehicle, and multiple vehicles can be linked to the same Volvo ID.

Related information

•
Creating and registering a Volvo ID (p. 27)
•
Scheduling service and repairs (p. 567)
YOUR VOLVO
* Option/accessory.
27

Creating and registering a Volvo ID

A Volvo ID can be created in two ways. If your Volvo ID was created with the Volvo On Call app, the Volvo IDmust also be registered to the vehicle to enable access to the Volvo ID services.
Creating a Volvo ID with the Volvo ID app
1. Download the Volvo ID app from
Download Center in the center display's
App view.
2. Start the app and register a personal email address.
3. Follow the instructions that will be sent automatically to this email address.
> A Volvo ID has now been created and is
automatically registered to the vehicle. The Volvo ID services can now be used.
Creating a Volvo ID using the Volvo On Call app
1
1. Download the latest version of the Volvo On Call app to your phone, via e.g. App Store, Windows Phone or Google Play.
2. Choose to create a Volvo ID.
3. The website for creating a Volvo ID will open. Fill in the requested information.
4. Check the box to accept the terms and conditions.
5. Press the button to create your Volvo ID.
6. An email will be sent to the address you have provided. Confirm that the address is correct.
> Your Volvo ID is now ready to be used.

Registering your Volvo ID to the vehicle

If your Volvo ID was created using the Volvo On Call app, follow these steps to register the ID to the vehicle:
1. If you have not already done so, download the Volvo ID app from
Download Center
in the center display's App view.
NOTE
To download apps the vehicle must be connected to the internet.
2. Start the app and enter your Volvo ID/ email address.
3. Follow the instructions that will be auto­matically sent to the email address con­nected to your Volvo ID.
> Your Volvo ID has now been registered
to the vehicle. The Volvo ID services can now be used.

Related information

•
Volvo ID (p. 26)
•
Download apps (p. 453)
•
Handling system updates via Download Center (p. 566)
•
Internet-connected vehicle* (p. 496)
1
Vehicles with Volvo On Call.
YOUR VOLVO
28

Drive-E ‒ purer driving pleasure

Volvo is committed to the well-being of its customers. As a natural part of this commit­ment, we care about the environment in which we all live. Concern for the environ­ment means an everyday involvement in reducing our environmental impact.
Volvo's environmental activities are based on a holistic view, which means we consider the overall environmental impact of a product throughout its complete life cycle. In this con­text, design, production, product use, and recycling are all important considerations. In production, Volvo has partly or completely phased out several chemicals including CFCs, lead chromates, asbestos, and cadmium; and reduced the number of chemicals used in our plants 50% since 1991.
Volvo was the first in the world to introduce into production a three-way catalytic converter with a Lambda sond, now called the heated oxygen sensor, in 1976. The current version of this highly efficient system reduces emissions of harmful substances (CO, HC, NOx) from the exhaust pipe by approximately 95 - 99% and the search to eliminate the remaining emis­sions continues. Volvo is the only automobile manufacturer to offer CFC-free retrofit kits for the air conditioning system of all models as far back as the 1975 model 240. Advanced elec­tronic engine controls and cleaner fuels are bringing us closer to our goal. In addition to
continuous environmental refinement of con­ventional gasoline-powered internal combus­tion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles.
When you drive a Volvo, you become our part­ner in the work to lessen the vehicle's impact on the environment. To reduce your vehicle's environmental impact, you can:
•
Maintain proper air pressure in your tires. Tests have shown decreased fuel econ­omy with improperly inflated tires.
•
Follow the recommended maintenance schedule in your Warranty and Service Records Information booklet.
•
Drive at a constant speed whenever possi­ble.
•
See a trained and qualified Volvo service technician as soon as possible for inspec­tion if the check engine (malfunction indi­cator) light illuminates, or stays on after the vehicle has started.
•
Properly dispose of any vehicle-related waste such as used motor oil, used batter­ies, brake pads, etc.
•
When cleaning your vehicle, please use genuine Volvo car care products. All Volvo car care products are formulated to be environmentally friendly.

Twin Engine vehicles

•
If possible, precondition the vehicle with the charging cable before driving.
•
If preconditioning is not possible in cold weather, use the seat and steering wheel heating primarily. Avoid heating the entire passenger compartment, which reduces the hybrid battery's charge level.
•
Choose the
Pure drive mode to help mini-
mize electric power consumption.
•
In hilly terrain, put the gear selector in mode B to utilize the electric motor's braking function when the accelerator pedal is released. This helps charge the hybrid battery.

Related information

•
Economical driving (p. 421)
•
Starting and stopping preconditioning (p. 220)
•
The Owner's Manual and the environment (p. 23)
•
Air quality (p. 200)
YOUR VOLVO
* Option/accessory.
29

IntelliSafe – driver support and safety

IntelliSafe is Volvo Cars' philosophy regarding vehicle safety. IntelliSafe consists of a num­ber of systems2 that are designed to help make driving safer, prevent accidents and protect passengers and other road users.
WARNING
The functions are supplementary aids – they cannot manage all situations in all conditions.
The driver is always responsible for ensur­ing that the vehicle is driven in a safe man­ner and in accordance with applicable traf­fic rules and regulations.

Support

IntelliSafe has the following functions designed to help the driver operate the vehicle more safely.
•
Active high beam
•
Tunnel detection
•
Pilot Assist
•
*Cross Traffic Alert
•
*Blind Spot Information
•
Park Assist*
•
Park Assist Pilot*
•
Park Assist Camera*
•
Road Sign Information*
•
Electronic Stability Control
•
Roll Stability Control
•
Cruise control
•
Adaptive Cruise Control*
•
Rear Collision Warning
•
Driver Alert Control
•
All Wheel Drive (AWD)
3

Prevention

IntelliSafe has the following functions designed to help the driver prevent accidents.
•
City Safety
•
Distance Alert*
•
Lane Keeping Aid
•
Collision Avoid. Assistance

Protection

IntelliSafe has the following interacting func­tions to help protect the driver and passengers in certain situations in the event of an acci­dent.
•
Whiplash Protection System
•
Seat belt with seat belt tensioner
•
Airbags
NOTE
Read the individual parts about each sys­tem to fully understand the functions and be notified of important warnings.

Related information

•
Active high beam (p. 155)
•
Safety (p. 42)
•
Driver support systems (p. 260)
2
Some of these systems are standard, while others are options. This may vary depending on market, vehicle model and model year.
3
All Wheel Drive
YOUR VOLVO
* Option/accessory.
30

Sensus - connection and entertainment

Sensus makes it possible to use apps and turn your vehicle into a Wi-Fi hotspot.

This is Sensus

Sensus provides an intelligent interface and Internet connection to the digital world. An intuitive navigation structure offers access to relevant assistance, information and entertain­ment when it is needed, without distracting the driver.
Sensus includes all of the solutions in the vehi­cle related to entertainment, Internet connec­tion and navigation*, and serves as the user interface between the driver and the vehicle. Sensus is what makes communication between you, the vehicle and the world around you possible.

Information when it's needed, where it's needed

The vehicle's displays present the right infor­mation at the right time. Information is pre­sented in different displays depending on how it should be prioritized by the driver.
YOUR VOLVO
}}
* Option/accessory.
31
Different types of information are shown in different displays depending on how the information should be prioritized.
Head-up display*
The head-up display presents information that the driver should react to immediately. For example, traffic warnings, speed informa-
tion and navigation messages*. Road sign information and incoming phone calls are also shown in the head-up display. These can be handled using the right-side steering wheel keypad or the center display.
Instrument panel
The instrument panel displays information such as speed, incoming phone calls or the
||
YOUR VOLVO
* Option/accessory.
32
track currently playing. It is controlled using the steering wheel keypads.
Center display
Many of the vehicle's main functions are con­trolled from the center display, a touchscreen that reacts to taps and other gestures. This minimizes the number of physical buttons and controls needed in the vehicle. The screen can also be operated while wearing gloves.
The center display is used to control e.g. the climate and entertainment systems and to adjust the power seats*. The information pre­sented in the center display can be handled by the driver or, in some situations, by a passen­ger.
Voice control system
The voice control system ena­bles the driver to control cer­tain vehicle functions without taking their hands off the wheel. The system can understand natural speech.
Use voice commands to e.g. play a song, make a phone call, increase the temperature in the passenger compartment or have a text message read aloud.

Related information

•
Head-up display* (p. 139)
•
Instrument panel (p. 80)
•
Center display overview (p. 107)
•
Voice Control (p. 142)
•
Internet-connected vehicle* (p. 496)
•
Sharing Internet from the vehicle via Wi-Fi hotspot (tethering) (p. 500)
YOUR VOLVO
}}
33

Software Updates

So that you as a Volvo customer shall have the best possible experience from your car, Volvo is continuously developing the systems in the cars and the services that you are offered.
You can update the software in your Volvo to the latest version when your car is serviced at an authorized Volvo dealer. With the latest software update, you can take advantage of available improvements, including those that came with previous software updates.
For more information about released updates and answers to frequently asked questions, please go to support.volvocars.com.
NOTE
Functionality after updating may vary depending on market, model, model year and options.

Related information

•
Sensus - connection and entertainment (p. 30)
•
Handling system updates via Download Center (p. 566)

Data recording

As part of Volvo's commitment to safety and quality, certain information is recorded regar­ding vehicle operation, functionality and inci­dents.
US market only:
EDR
This vehicle is equipped with an "Event Data Recorder" (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:
•
How various systems in your vehicle were operating;
•
Whether or not the driver and passenger safety belts were buckled/fastened;
•
How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
•
How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-
trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.
ASDR
This vehicle is equipped with an Active Safety Data Recorder (ASDR). This data recorder can record information related to the usage of the car, functional errors and active safety actuations (e.g. auto brake). The information saved is used by technicians for service and maintenance to diagnose and repair possible faults that has occurred in the vehicle and to fulfil certain legal requirements. The registered data can also, in congregated form, be used for research- and product development – purposes to continuously improve the safety and quality of Volvo Cars. For more information contact your local Volvo retailer.
||
YOUR VOLVO
34
Canadian market only:
This vehicle is equipped with an “Event Data Recorder” (EDR). The main purpose of the EDR is to register and record data in traffic accidents or accident-like situations, e.g. if an airbag deploys or if the vehicle hits an obstacle in the road. This data is recorded in order to help understand how the vehicle's systems perform in these types of situations. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, usually 30 seconds or less.
The EDR in this vehicle is designed to record data in traffic accidents or accident-like situa­tions such as:
•
How the various systems in the vehicle performed;
•
Whether the driver and passenger seat belts were tightened/buckled;
•
The driver's use of the accelerator/brake pedal;
•
How fast the vehicle was moving.
This data can help provide a better under­standing of the circumstances in which traffic accidents and injuries occur. The EDR records data only if a non-trivial accident situation occurs. EDR does not record any data during normal driving conditions. The system also never registers data on who is driving the vehi­cle or the geographical location of the acci-
dent or near-accident. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifia­ble information that is routinely acquired dur­ing an accident investigation. Special equip­ment and access to either the vehicle or the EDR is required to read this recorded data.
In addition to the EDR, the vehicle is equipped with a number of computers that continuously control and monitor the vehicle's performance. These computers may record data during nor­mal driving conditions, particularly if they detect a fault relating to the vehicle's opera­tion and functionality or upon activation of the vehicle's active driver support functions (e.g. City Safety or the auto-brake function).
Some of this recorded data is required by technicians performing service and mainte­nance in order to diagnose and rectify any faults that may have occurred in the vehicle. The recorded information is also needed to enable Volvo to fulfill legal and other regula­tory requirements. Information registered in the vehicle is stored in its computers until the vehicle is serviced or repaired.
In addition to the above, the recorded informa­tion may be used in aggregated form for research and product development purposes in order to continuously improve the safety and quality of Volvo vehicles.
Volvo will not provide this information to any third parties without the vehicle owner's con­sent. However, national legislation and regula­tions may require Volvo to disclose this type of information to law enforcement or other authorities that can claim a legal right to the information. Special technical equipment, which Volvo and workshops that have entered agreements with Volvo have access to, is required to read and interpret the recorded data. Volvo is responsible for ensuring that information provided to Volvo in conjunction with service and maintenance is stored and handled securely and in compliance with applicable legal requirements. For more infor­mation, please contact a Volvo retailer.

Related information

•
Contacting Volvo (p. 26)
•
Volvo Structural Parts Statement (p. 39)
YOUR VOLVO
}}
35

Terms & Conditions for Services

Volvo offers services that help enhance the vehicle's safety and comfort.
These services comprise everything from assistance in emergencies to navigation and various maintenance services.
Before using the services, it is important to read support information about terms and conditions for the services at www.volvocars.com.

Related information

•
Customer Privacy Policy (p. 35)

Customer Privacy Policy

Volvo respects and safeguards the personal privacy of everyone who visits our websites.
This policy refers to the handling of customer data and personal information. The purpose is to give current, past and potential customers a general understanding of:
•
The circumstances in which we collect and process your personal data.
•
The types of personal data we collect.
•
Why we collect your personal data.
•
How we process your personal data.
For more information on the policy, search for support information on www.volvocars.com.

Related information

•
Terms of use and data sharing (p. 502)
•
Terms & Conditions for Services (p. 35)
•
Data recording (p. 33)

Important information on accessories and extra equipment

Incorrectly connected or installed accessories or extra equipment may have an adverse effect on the vehicle's electronics.
We strongly recommend that Volvo owners use only genuine, Volvo-approved accessories, and that accessory installations be performed only by a trained and qualified Volvo service technician. Certain accessories only work when the associated software is installed in the vehicle's computer system.
The equipment described in the Owner's Man­ual is not available in all vehicles. Vehicles may be equipped differently depending on market requirements and national or local laws and regulations.
Optional or accessory equipment may not be available in all countries or markets. Please note that some vehicles may be equipped dif­ferently, depending on special legal require­ments. For more information on which equip­ment is standard and which is an option or accessory, please contact your Volvo retailer.
||
YOUR VOLVO
36
NOTE
Do not export your Volvo to another coun­try before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be dif­ficult or impossible to comply with these requirements. Modifications to the emis­sion control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.
WARNING
CALIFORNIA proposition 65
Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the state of Cali­fornia to cause cancer, and birth defects or other reproductive harm. In addition, cer­tain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of Cali­fornia to cause cancer, and birth defects or other reproductive harm.
WARNING
Certain components of this vehicle such as air bag modules, seat belt tensioners, adaptive steering columns, and button cell batteries may contain Perchlorate material. Special handling may apply for service or vehicle end of life disposal.
See www.dtsc.ca.gov/hazardouswaste/ perchlorate.
WARNING
The driver is always responsible for operat­ing the vehicle in a safe manner and for complying with current statutes and regu­lations.
It is also essential to maintain and service the vehicle according to Volvo's recom­mendations as stated in the owner's infor­mation and the service and warranty book­let.
If the on-board information differs from the printed owner's manual, the printed infor­mation always takes precedence.

Related information

•
Accessory installation (p. 36)
•
Connecting equipment to the vehicle's data link connector (p. 37)
•
Using the Owner's Manual (p. 21)

Accessory installation

We strongly recommend that Volvo owners use only genuine, Volvo-approved accesso­ries, and that accessory installations be per­formed only by a trained and qualified Volvo service technician. Certain accessories only work when the associated software is instal­led in the vehicle's computer system.
•
Genuine Volvo accessories are tested to ensure compatibility with the perform­ance, safety, and emission systems in your vehicle. Additionally, a trained and quali­fied Volvo service technician knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult a trained and qualified Volvo serv­ice technician before installing any acces­sory in or on your vehicle.
•
Accessories that have not been approved by Volvo may or may not be specifically tested for compatibility with your vehicle.
•
Any of your vehicle's performance and safety systems could be adversely affec­ted if you install accessories that Volvo has not tested, or if you allow accessories to be installed by someone unfamiliar with your vehicle.
•
Damage caused by unapproved or improperly installed accessories may not be covered by your new vehicle warranty. See your Warranty and Service Records Information booklet for more warranty
YOUR VOLVO
}}
37
information. Volvo assumes no responsi­bility for death, injury, or expenses that may result from the installation of non­genuine accessories.

Related information

•
Important information on accessories and extra equipment (p. 35)

Connecting equipment to the vehicle's data link connector

Incorrectly connected or installed software or diagnostic tools may have an adverse effect on the vehicle's electronics.
We strongly recommend that Volvo owners use only genuine, Volvo-approved accessories, and that accessory installations be performed only by a trained and qualified Volvo service technician. Certain accessories only work when the associated software is installed in the vehicle's computer system.
On-board Diagnostic (OBDII) socket under the dash­board on the driver's side.
NOTE
Volvo Cars takes no responsibility for the consequences of connecting non-author­ized equipment to the On-board Diagnostic (OBDII) socket. This socket should only be used by a trained and quali­fied Volvo service technician.

Type approval

USA
FCC ID: 2AGKKACUII06 This device complies with part 15 of the FCC
rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interfer­ence, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
WARNING
Changes or modifications not expressly approved by the party responsible for com­pliance could void the user's authority to operate the equipment.
||
YOUR VOLVO
38
Canada
IC: 20839ACUII06 This device complies with Industry Canada
license-exempt RSS standards. Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

Related information

•
Important information on accessories and extra equipment (p. 35)

Technician certification

In addition to Volvo factory training, Volvo supports certification by the National Insti­tute for Automotive Service Excellence (A.S.E.).
Certified technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These pro­fessional technicians are best able to analyze vehicle problems and perform the necessary maintenance procedures to keep your Volvo at peak operating condition.
Twin Engine vehicles
Technicians performing work on a vehicle with electrification should also have the necessary training and specialized certification required for performing repairs and/or maintenance on a vehicle with electrification.
WARNING
A number of electrical components in Twin Engine vehicles use high-voltage current and can be extremely dangerous if handled incorrectly. These components and any orange wiring in the vehicle may only be handled by trained and qualified Volvo service technicians.

Viewing the Vehicle Identification Number (VIN)

When contacting a Volvo retailer, about e.g. your Volvo On Call subscription, your Vehicle Identification Number (VIN4) may be needed.
1.
Tap
Settings in the Top view in the center
display.
2. Proceed to
System System
Information
Vehicle Identification
Number
.
> The vehicle identification number will
be displayed.
The VIN can also be found on the first page of the Warranty and Service Records Information booklet, on your registration card, or by look­ing at the dashboard through the windshield.
The VIN has a similar location on all models.
4
Vehicle Identification Number
YOUR VOLVO
}}
39

Volvo Structural Parts Statement

Volvo is one of the leading companies for car safety.
Volvo engineers and manufactures vehicles designed to help protect vehicle occupants in the event of a collision.
Volvos are designed to absorb the impact of a collision. This energy absorption system including, but not limited to, structural compo­nents such as bumper reinforcement bars, bumper energy absorbers, frames, rails, fender aprons, A-pillars, B-pillars and body panels must work together to maintain cabin integrity and protect the vehicle occupants.
The supplemental restraint system including but not limited to air bags, side curtain air bags, and deployment sensors work together with the above components to provide proper timing for air bag deployment.
Due to the above, Volvo Car USA does not support the use of aftermarket, alternative or anything other than original Volvo parts for collision repair.
Volvo Car USA also recommends using Volvo­approved replacement glass. The use of after­market glass, particularly a windshield, can have an adverse effect on collision avoidance and advanced lighting systems.
In addition Volvo does not support the use or re-use of structural components from an exist­ing vehicle that has been previously damaged.
Although these parts may appear equivalent, it is difficult to tell if the parts have been previ­ously replaced with non-OE parts or if the part has been damaged as a result of a prior colli­sion. The quality of these used parts may also have been affected due to environmental exposure.

Related information

•
Data recording (p. 33)

Driver distraction

A driver has a responsibility to do everything possible to ensure his or her own safety and the safety of passengers in the vehicle and others sharing the roadway. Part of this responsibility is avoiding distractions, includ­ing performing activities that are not directly related to controlling the vehicle in the driving environment.
Your new Volvo is, or can be, equipped with feature-rich entertainment and communica­tion systems. These include hands-free cellular telephones, navigation systems, and multipur­pose audio systems. You may also own other portable electronic devices for your own con­venience. When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction.
For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety. Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely. Distraction can lead to a serious acci­dent. In addition to this general warning, we offer the following guidance regarding specific new features that may be found in your vehi­cle:
||
YOUR VOLVO
40
WARNING
•
Never use a hand-held cellular tele­phone while driving. Some jurisdictions prohibit cellular telephone use by a driver while the vehicle is moving.
•
If your vehicle is equipped with a navi­gation system, set and make changes to your travel itinerary only with the vehicle parked.
•
Never program your audio system while the vehicle is moving. Program radio presets with the vehicle parked, and use your programmed presets to make radio use quicker and simpler.
•
Never use portable computers or per­sonal digital assistants while the vehi­cle is moving.

Related information

•
Audio, media and Internet (p. 450)
SAFETY

SAFETY

42

Safety

The vehicle is equipped with a number of safety systems that work together to help protect the vehicle's driver and passengers in the event of an accident.
The vehicle is equipped with a number of sen­sors that may react in the event of an accident and activate different safety systems, such as the airbag system and seat belt tensioners. Depending on the specific conditions of the accident, e.g. collisions at certain angles, over­turning or swerving, the systems react differ­ently to help provide good protection.
There are also mechanical safety systems such as the Whiplash Protection System. The vehicle is also built so that a large part of the force of a collision is distributed to the vehi­cle's members, pillars, floor, roof and other parts of the body.
After an accident, the vehicle's safety mode may be activated if any important function in the vehicle has been damaged.

Warning symbol in the instrument panel

The warning symbol in the instru­ment panel illuminates when the vehicle's electrical system is in igni-
tion mode II. The symbol will go out after approx. 6 seconds if no faults are detected in the vehicle's safety systems.
WARNING
If the warning symbol remains illuminated or switches on while driving and the mes­sage
SRS airbag Service urgent Drive to
workshop is displayed in the instrument
panel, this indicates that something in the safety system is not functioning properly. Volvo recommends contacting an author­ized Volvo workshop for repairs as soon as possible.
WARNING
Never attempt to alter or repair any of the vehicle's safety systems yourself. Incor­rectly performed repairs to any system could impair function and lead to serious injury. Volvo recommends contacting an authorized Volvo workshop.
If this dedicated warning symbol is not functioning, the general warning symbol will illuminate instead and the same message will be displayed
in the instrument panel.

Related information

•
Safety during pregnancy (p. 43)
•
Occupant safety (p. 43)
•
Reporting safety defects (p. 44)
•
Recall information (p. 45)
•
Seat belts (p. 47)
•
Airbags (p. 52)
•
Whiplash Protection System (p. 46)
•
Safety mode (p. 61)
•
Child safety (p. 63)
SAFETY
}}
* Option/accessory.
43

Safety during pregnancy

It is important that seat belts are worn cor­rectly during pregnancy and that pregnant drivers adjust their seating position accord­ingly.

Seat belt

The seat belt should fit closely against the shoulder, with the diagonal section between the breasts and to the side of the stomach.
The lap section of the seat belt should lie flat over the thighs and as far as possible under the stomach. Never let it ride upward. Remove unnecessary slack and make sure the seat belt fits as close as possible to the body. Make sure there are no twists in the seat belt.

Seating position

As pregnancy progresses, pregnant drivers should adjust the seat and steering wheel to a
position that allows them to retain full control of the vehicle (which means they should be able to easily reach the steering wheel and foot pedals). Try to maintain as much distance as possible between the stomach and the steering wheel.

Related information

•
Safety (p. 42)
•
Seat belts (p. 47)
•
Manual front seats (p. 182)
•
Power* front seats (p. 183)

Occupant safety

Safety is Volvo's cornerstone.

Volvo's concern for safety

Our concern for safety dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo vehicles long before it was fashionable or required by gov­ernment regulation.
We will not compromise our commitment to safety. We continue to seek out new safety features and to refine those already in our vehicles. You can help. We would appreciate hearing your suggestions about improving automobile safety. We also want to know if you ever have a safety concern with your vehi­cle. Call us in the U.S. at: 18004581552 or in Canada at: 18006638255.
||
SAFETY
44
Occupant safety reminders
How safely you drive doesn't depend on how old you are but rather on:
•
How well you see.
•
Your ability to concentrate.
•
How quickly you make decisions under stress to avoid an accident.
The following suggestions are intended to help you cope with the ever changing traffic environment.
•
Never drink and drive.
•
If you are taking any medication, consult your physician about its potential effects on your driving abilities.
•
Take a driver-retraining course.
•
Have your eyes checked regularly.
•
Keep your windshield and headlights clean.
•
Replace wiper blades when they start to leave streaks.
•
Take into account the traffic, road, and weather conditions, particularly with regard to stopping distance.
•
Never text while driving.
•
Refrain from using or minimize the use of a cell phone while driving.

Related information

•
Safety (p. 42)
•
Reporting safety defects (p. 44)
•
Recall information (p. 45)

Reporting safety defects

The following information will help you report any perceived safety-related defects in your vehicle.

Reporting safety defects in the U.S.

If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Volvo Car USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. How­ever, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Car USA, LLC. To contact NHTSA, you may either call the Auto Safety Hotline tollfree at
18883274236
SAFETY
}}
45
(TTY: 18004249153) or write to: NHTSA, U.S. Department of Trans­portation, Washington D.C. 20590.
You can also obtain other informa­tion about motor vehicle safety from http://www.safercar.gov, where you can also enter your vehicle's VIN (Vehicle Identification Number) to see if it has any open recalls.
Volvo strongly recommends that if your vehicle is covered under a serv­ice campaign, safety or emission recall or similar action, it should be completed as soon as possible. Please check with your local retailer or Volvo Car USA, LLC if your vehicle is covered under these conditions.
NHTSA can be reached at: Internet: http://www.nhtsa.gov Telephone: 1888DASH2DOT
(18883274236).

Reporting safety defects in Canada

If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans­port Canada in addition to notifying Volvo Car Canada Ltd.
Transport Canada can be contacted at:
18003330510 Teletypewriter (TTY): 613 9904500 Fax: 18199943372 Mailing Address: Transport Canada - Road
Safety, 80 rue Noël, Gatineau, (Quebec) J8Z 0A1

Related information

•
Safety (p. 42)
•
Occupant safety (p. 43)
•
Recall information (p. 45)
•
Viewing the Vehicle Identification Number (VIN) (p. 38)

Recall information

On our website, click the "Owner" tab in the upper left-hand side of the screen and then click on the heading "Recall Information". Enter the vehicle identification number (VIN), which can be found at the bottom of the wind­shield. If your vehicle has any open Recalls, they will be displayed on this page.
You can also enter the Vehicle Identification Number in the search field on the National Highway Traffic Safety Administration's (NHTSA) website at: www.nhtsa.gov.
Volvo customers in Canada
For any questions regarding open recalls for your vehicle, please contact your authorized Volvo retailer. If your retailer is unable to answer your questions, please contact Volvo Customer Relations at 8006638255, Mon­day through Friday, 8:30 A.M. to 5:00 P.M. EST or volvocars.com/ca. You may also write us at:
Volvo Car Canada Ltd. Customer Care Centre 9130 Leslie Street, Suite 101 Richmond Hill, Ontario L4B 0B9 www.tc.gc.ca
||
SAFETY
46

Related information

•
Safety (p. 42)
•
Reporting safety defects (p. 44)
•
Occupant safety (p. 43)

Whiplash Protection System

The Whiplash Protection System (WHIPS) is designed to help reduce the risk of whiplash­type injuries. The system consists of energy absorbing backrests and seat cushions as well as specially designed head restraints in the front seats.
WHIPS is activated in the event of a rear-end collision and adapted to the angle and speed of the collision and to the characteristics of the colliding vehicle.
When WHIPS is activated, the front seat backrests move rearward and the seat cush­ions move downward to change the seating positions of the driver and front seat passen­ger. This movement helps absorb some of the forces that could result in whiplash.
WARNING
WHIPS is a supplement to the seat belt. Always wear your seat belt.
WARNING
Do not attempt to alter or repair the seat or WHIPS on your own. Volvo recommends contacting an authorized Volvo workshop.
If the front seats have been subjected to severe stress, e.g. in a collision, the seats must be replaced. Even if the seats appear undamaged, some of their protective prop­erties may have been lost.
Do not place any objects on the floor behind or under the front seats or on the rear seat that could prevent WHIPS from functioning correctly.
SAFETY
}}
* Option/accessory.
47
WARNING
Do not squeeze box-like cargo between the rear seat cushion and the front seat back­rest.
If the rear seat backrests are folded down, cargo must be secured to prevent it from sliding forward against the front seat back­rests in the event of a collision.
WARNING
If a rear seat backrest is folded down or if a rear-facing child restraint is being used in the rear seat, the seat in front must be moved forward so that it does not come into contact with the backrest or child restraint.

Seating position

For WHIPS to provide good protection, the driver and passenger must be seated correctly and the system's function must not be impe­ded in any way.
Set the front seat to the correct seating posi­tion before starting to drive.
The driver and the front seat passenger should sit in the center of the seat with their heads as close as possible to the head restraints.

Related information

•
Safety (p. 42)
•
Manual front seats (p. 182)
•
Power* front seats (p. 183)
•
Rear Collision Warning* (p. 320)

Seat belts

Seat belts should always be worn by all occu­pants in your vehicle. Children should be properly restrained using an infant seat, adjustable child seat or booster cushion as determined by age, weight and height.
Most states and provinces make it mandatory for occupants of a vehicle to use seat belts.

Seat belt maintenance

Check periodically that the seat belts are in good condition. Use water and a mild deter­gent for cleaning. Check the seat belt mecha­nism's function as follows: attach the seat belt and pull rapidly on the strap.
||
SAFETY
48
WARNING
•
Never repair the belt yourself. Repairs should only be performed by a trained and qualified Volvo service technician.
•
Any device used to induce slack into the shoulder belt portion of the three­point belt system will have a detrimen­tal effect on the amount of protection available in the event of a collision.
•
The seat back should not be tilted too far back. The shoulder belt must be taut in order to function properly.
•
Do not use any type of child restraint in the front passenger seat. We recom­mend that children who have outgrown these devices sit in the rear seat with the seat belt properly fastened.

Related information

•
Safety (p. 42)
•
Seat belt tensioners (p. 50)
•
Buckling and unbuckling seat belts (p. 48)
•
Door and seat belt reminders (p. 51)

Buckling and unbuckling seat belts

Make sure that all passengers have buckled their seat belts before starting to drive.

Buckling seat belts

1. Pull out the belt slowly and make sure it is not twisted or damaged.
NOTE
The seat belt is equipped with a seat belt retractor that will lock up in the following situations:
•
if the belt is pulled out too quickly.
•
during braking and acceleration.
•
if the vehicle is leaning excessively.
•
when driving in turns.
•
if the automatic locking retractor/emer­gency locking retractor (ALRELR) is activated. Each seat belt (except for the driver's) is equipped with an ALR func­tion, which is designed to keep the seat belt taut when installing a child restraint. ALR is activated when the seat belt is pulled out as far as possible. If this is done, a sound from the seat belt retractor will be audible, which is nor­mal. The seat belt can now only be fed into the retractor, not pulled out. This function is automatically disabled when the seat belt is unbuckled and fully retracted.
SAFETY
}}
49
2. Buckle the seat belt by pushing the latch plate into the receptacle.
> A distinct "click" indicates that the belt
is locked into place.
WARNING
Always insert the seat belt latch plate into the belt buckle on the correct side. Failure to do so could cause the seat belts and belt buckles to malfunction in a collision. There is a risk of serious injury.
3. The height of the seat belts in the front seats can be adjusted.
Press the button on the seat belt holder and move the belt up or down.
Position the belt as high as possible with­out it chafing against the neck.
The belt should be positioned closely over the shoul­der (against the collarbone, not down over the arm).
4. Tighten the lap section of the seat belt over the hips by pulling the diagonal sec­tion upward toward the shoulder.
The lap section of the seat belt should be positioned low on the hips (not against the abdomen).
||
SAFETY
* Option/accessory.
50
WARNING
Never use a seat belt for more than one occupant. Never wear the shoulder portion of the belt under the arm, behind the back or otherwise out of position. Such use could cause injury in the event of an acci­dent. As seat belts lose much of their strength when exposed to violent stretch­ing, they should be replaced after any colli­sion, even if they appear to be undamaged.
WARNING
Do not use clips or fasten the belts around hooks or other parts of the interior. This will prevent the seat belt from fitting properly.
WARNING
Never damage the seat belts and never insert any foreign objects into the belt buckle. This may cause the seat belts and belt buckles to malfunction in a collision. There is a risk of serious injury.

Unbuckling seat belts

1. Press the red button on the seat belt receptacle and make sure the seat belt retracts fully into the retractor slot.
2. If it does not fully retract, guide the belt manually into the slot and make sure it does not hang loose.

Related information

•
Seat belts (p. 47)
•
Seat belt tensioners (p. 50)
•
Door and seat belt reminders (p. 51)

Seat belt tensioners

The vehicle is equipped with standard and electric* seat belt tensioners that can help tension the seat belt in a critical situation or collision.

Standard seat belt tensioners

All seat belts are equipped with a standard seat belt tensioner.
In a collision of sufficiently violent force, the seat belt tensioners will tension the seat belts in order to more effectively restrain the occu­pants.

Electric seat belt tensioners*

The driver's and front passenger's seat belts are equipped with electric seat belt tensioners.
The seat belt tensioners interact and can be activated in conjunction with the City Safety and Rear Collision Warning driver support sys­tems. In critical situations, such as if the vehi­cle brakes suddenly, begins to skid or runs off the road (e.g if the vehicle rolls into a ditch, lifts off the ground or hits an obstacle in the road), or if there is a risk of collision, the seat belts can be pulled taut by the seat belt ten­sioner's electric motor.
The electric seat belt tensioner helps to posi­tion the occupant more effectively in the seat, which reduces the risk of the occupant strik­ing the interior of the passenger compartment
SAFETY
}}
* Option/accessory.
51
and improves the effect of other safety sys­tems such as the airbags.
When a critical situation has passed, the seat belt and the electric seat belt tensioner are reset automatically. However, they can also be reset manually.
WARNING
Never attempt to alter or repair the seat belt on your own. Volvo recommends con­tacting an authorized Volvo workshop.
If the seat belt has been exposed to extreme forces, e.g. in conjunction with a collision, the entire seat belt must be replaced. Even if the seat belt appears undamaged, some of its protective proper­ties may have been lost. Also replace the seat belt if it is worn or damaged. The new seat belt must be type approved and intended for the same seating position as the replaced seat belt.

Related information

•
Seat belts (p. 47)
•
Buckling and unbuckling seat belts (p. 48)
•
Resetting the electric seat belt tensioners* (p. 51)
•
City Safety™ (p. 306)
•
Rear Collision Warning* (p. 320)

Resetting the electric seat belt tensioners*

The electric seat belt tensioners are designed to be reset automatically, but if the seat belt remains taut it can be reset manually.
1. Stop the vehicle in a safe location.
2. Unbuckle the seat belt and then rebuckle it.
> The seat belt and the electric seat belt
tensioner will be reset.
WARNING
Never attempt to alter or repair the seat belt on your own. Volvo recommends con­tacting an authorized Volvo workshop.
If the seat belt has been exposed to extreme forces, e.g. in conjunction with a collision, the entire seat belt must be replaced. Even if the seat belt appears undamaged, some of its protective proper­ties may have been lost. Also replace the seat belt if it is worn or damaged. The new seat belt must be type approved and intended for the same seating position as the replaced seat belt.

Related information

•
Seat belt tensioners (p. 50)
•
Seat belts (p. 47)

Door and seat belt reminders

This system is intended to remind occupants to buckle their seat belts and to alert the driver if a door, hood or other opening (trunk, sunroof, etc.) is open.

Graphics in the instrument panel

Graphics in the instrument panel with various types of warnings. The warning colors for the doors/trunk lid vary depending on the vehicle's speed.
The instrument panel graphic shows the seats where seat belts are buckled and not buckled.
The same graphic also indicates if the hood, trunk lid, fuel filler door or any door is open.
Confirm the graphic by briefly pressing the O button on the right-side steering wheel key­pad.
||
SAFETY
52

Seat belt reminder

Reminder light in ceiling console.
A seat belt reminder light illuminates in the ceiling console and a warning symbol is dis­played in the instrument panel.
The audible reminder varies depending on the vehicle's speed, driving time and distance driven.
A seat belt status graphic in the instrument panel indicates when the driver's or a pas­senger's seat belt is buckled or unbuckled.
Child seats are not included in the seat belt reminder system.
Front seats
An audible signal and an indicator light remind unbuckled occupants to fasten their seat belts.
Rear seat
The rear seat belt reminder has two functions:
•
To indicate which seat belts are buckled in the rear seats. This will also be displayed in an instrument panel graphic.
•
To provide audio and visual reminders if any seat belt in the rear seat is removed while the vehicle is in motion. The reminder will stop when the seat belt has been rebuckled.

Door/hood/trunk lid and fuel filler door reminder

If the hood, trunk lid, fuel filler door or any door is not properly closed, this will be indi­cated by a graphic in the instrument panel. Stop the vehicle safely and close the open door, hood, etc.
If the vehicle is moving at a speed under approx. 10 km/h (6 mph), the information symbol will illuminate in the instrument panel.
If the vehicle is moving at a speed above approx. 10 km/h (6 mph), the warning symbol will illuminate in the instrument panel.

Related information

•
Seat belts (p. 47)
•
Buckling and unbuckling seat belts (p. 48)

Airbags

The vehicle is equipped with airbags and inflatable curtains for the driver and passen­gers.
WARNING
•
If the airbag warning light stays on after the engine has started or if it illu­minates while you are driving, have the vehicle inspected by a trained and qualified Volvo service technician as soon as possible.
•
Never attempt to alter or repair any of the vehicle's safety systems yourself. Incorrectly performed repairs to any system could impair function and lead to serious injury. All work on these sys­tems should be performed by a trained and qualified Volvo service technician.
SAFETY
}}
53
WARNING
If your vehicle has become water-damaged in any way (e.g., soaked floor mats/stand­ing water on the floor of the vehicle), do not attempt to start the engine. This may cause airbag deployment, which could result in serious injury. Volvo recommends towing the vehicle directly to an authorized Volvo workshop.
Before attempting to tow the vehicle:
1. Switch off the ignition for at least 10 minutes and disconnect the battery.
2. Follow the instructions for manually overriding the shiftlock system.

Deployed airbags

WARNING
If any of the airbags have deployed:
•
Do not attempt to drive the vehicle. Have it towed to an authorized work­shop.
•
If necessary, seek medical attention.

Related information

•
Safety (p. 42)
•
Driver/passenger-side airbags (p. 53)
•
Side airbags (p. 60)
•
Inflatable curtain (p. 60)

Driver/passenger-side airbags

As a supplement to the seat belts, the vehicle is equipped with driver and passenger side front airbags.
Driver/passenger side front airbags.
In a frontal collision, the airbags help protect the driver's and passenger's head, neck, face and chest and the driver's knees and legs.
A collision of a sufficiently violent force will trigger the sensors and one or more airbags will inflate. The airbag helps cushion the initial impact of the collision for the passenger. The airbag deflates when compressed by the colli­sion. A small amount of powder will also be released from the airbag. This may appear to be smoke and is normal. The entire process, from inflation to deflation of the airbag, occurs within tenths of a second.
NOTE
The sensors react differently depending on the circumstances of the accident and whether or not the seat belt is used. This applies to all belt positions.
There may therefore be accident situations in which only one (or none) of the airbags are deployed. The sensors monitor the impact of the collision and react accord­ingly to deploy one, several or no airbags.
WARNING
The seat belt and the airbag work together. If the seat belt is not used or is used incor­rectly, the airbag may not provide the intended protection in a collision.
To help prevent injury in the event the air­bag is deployed, passengers should sit as upright as possible, with their feet on the floor and their backs against the seat back­rest.
WARNING
Volvo recommends contacting an author­ized Volvo workshop for repairs. Incorrectly performed repairs to the airbag system could impair function and lead to serious injury.
||
SAFETY
54

The front airbag system

The front airbag system includes gas genera­tors surrounded by the airbags, and decelera­tion sensors that activate the gas generators, causing the airbags to be inflated with nitro­gen gas.
As the movement of the seats' occupants compresses the airbags, some of the gas is expelled at a controlled rate to provide better cushioning. The belt tensioners minimize slack in the seat belts and are activated for occu­pants wearing their seat belts. The entire proc­ess, from inflation to deflation of the airbag, occurs within tenths of a second.
The location of the front airbags is indicated by SRS AIRBAG embossed on the steering wheel pad and above the glove compartment, and by decals on both sun visors and on the front and far right side of the dash.
The driver's side front airbag is folded and located in the steering wheel hub.
The knee airbag is folded on the underside of the dashboard on the driver's side. The text AIRBAG is embossed on the panel.
The passenger's side front airbag is folded behind a panel located above the glove com­partment.
WARNING
•
The airbags in the vehicle are designed to be a SUPPLEMENT to-not a replacement for-the three-point seat belts. For maximum protection, wear seat belts at all times. Be aware that no system can prevent all possible injuries that may occur in an accident.
•
Never drive with your hands on the steering wheel pad/airbag housing.
•
The front airbags are designed to help prevent serious injury. Deployment occurs very quickly and with considera­ble force. During normal deployment and depending on variables such as seating position, one may experience abrasions, bruises, swellings, or other injuries as a result of deployment of one or both of the airbags.
•
When installing any accessory equip­ment, make sure that the front airbag system is not damaged. Any interfer­ence in the system could cause mal­function.

Front airbag deployment

•
The front airbags are designed to deploy during certain frontal or front-angular colli­sions, impacts, or decelerations, depend­ing on the crash severity, angle, speed and object impacted. The airbags may also
deploy in certain non-frontal collisions where rapid deceleration occurs.
•
The airbag system's sensors, which trigger the front airbags, are designed to deter­mine if the collision is powerful enough to activate the belt tensioners and/or the air­bags.
However, not all frontal collisions activate the front airbags.
•
If the collision involves a nonrigid object (e.g., a snow drift or bush), or a rigid, fixed object at a low speed, the front airbags will not necessarily deploy.
•
Front airbags do not normally deploy in a side impact collision, in a collision from the rear or in a rollover situation.
•
The amount of damage to the bodywork does not reliably indicate if the airbags should have deployed or not.
SAFETY
}}
55
NOTE
•
Deployment of front airbags occurs only one time during an accident. In a collision where deployment occurs, the airbags and seat belt tensioners acti­vate. Some noise occurs and a small amount of powder is released. The release of the powder may appear as smoke-like matter. This is a normal characteristic and does not indicate fire.
•
Volvo's front airbags use special sen­sors that are integrated with the front seat buckles. The point at which the airbag deploys is determined by whether or not the seat belt is being used, as well as the severity of the col­lision.
•
Collisions can occur where only one of the airbags deploys. If the impact is less severe, but severe enough to pres­ent a clear injury risk, the airbags are triggered at partial capacity. If the impact is more severe, the airbags are triggered at full capacity.
WARNING
•
Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that occupants under 140 cm (4 feet 7 inches) in height who have outgrown these devices sit in the rear seat with the seat belt fastened. See also the Occupant Weight Sensor information.
•
Never drive with the airbags deployed. The fact that they hang out can impair the steering of your vehicle. Other safety systems can also be damaged.
•
The smoke and dust formed when the airbags are deployed can cause skin and eye irritation in the event of pro­longed exposure.
Should you have questions about any compo­nent in the SRS system, please contact a trained and qualified Volvo service technician or Volvo customer support:
In the United States
Volvo Car USA, LLC Customer Care Center 1 Volvo Drive P.O. Box 914 Rockleigh, New Jersey 07647
18004581552 www.volvocars.com/us
In Canada
Volvo Car Canada Ltd. Customer Care Centre 9130 Leslie Street, Suite 101 Richmond Hill, Ontario L4B 0B9 18006638255 www.volvocars.com/ca

Airbag decals

Airbag decal on the outside of both sun visors.
||
SAFETY
56
Passenger's side airbag decal.
WARNING
•
Children must never be allowed in the front passenger's seat.
•
Occupants in the front passenger's seat must never sit on the edge of the seat, sit leaning toward the instrument panel or otherwise sit out of position.
•
The occupant's back must be as upright as comfort allows and be against the seat back with the seat belt properly fastened.
•
Feet must be on the floor, e.g., not on the dash, seat or out of the window.
WARNING
•
No objects or accessory equipment, e.g. dashboard covers, may be placed on, attached to, or installed near the air bag cover (the area above the glove compartment) or the area affected by airbag deployment.
•
There should be no loose articles, such as coffee cups on the floor, seat, or dashboard area.
•
Never try to open the airbag cover on the steering wheel or the passenger's side dashboard. This should only be done by a trained and qualified Volvo service technician.
•
Failure to follow these instructions can result in injury to the vehicle's occu­pants.

Related information

•
Airbags (p. 52)
•
Occupant weight sensor (p. 56)

Occupant weight sensor

The Occupant Weight Sensor (OWS) is designed to meet the regulatory require­ments of Federal Motor Vehicle Safety Standard (FMVSS) 208 and is designed to disable (will not inflate) the passenger's side front airbag under certain conditions.
Occupant Weight Sensor (OWS) indicator light

Disabling the passenger's side front airbag

Volvo recommends that ALL occupants (adults and children) shorter than 140 cm (4 feet 7 inches) be seated in the back seat of any vehicle with a front passenger side airbag and be properly restrained for their size and weight.
The OWS works with sensors that are part of the front passenger's seat and seat belt. The sensors are designed to detect the presence
SAFETY
}}
57
of a properly seated occupant and determine if the passenger's side front airbag should be enabled (may inflate) or disabled (will not inflate).
The OWS will disable (will not inflate) the pas­senger's side front airbag when:
•
the front passenger's seat is unoccupied, or has small/medium objects in the front seat,
•
the system determines that an infant is present in a rear-facing infant seat that is installed according to the manufacturer's instructions,
•
the system determines that a small child is present in a forward-facing child restraint that is installed according to the manufac­turer's instructions,
•
the system determines that a small child is present in a booster seat,
•
a front passenger takes his/her weight off of the seat for a period of time,
•
a child or a small person occupies the front passenger's seat.
The OWS uses a PASSENGER AIRBAG OFF indicator lamp which will illuminate and stay on to remind you that the passenger's side front airbag is disabled. The PASSENGER AIRBAG OFF indicator lamp is located in the overhead console, near the base of the rear­view mirror.
NOTE
When the ignition is switched on, the OWS indicator light will illuminate for sev­eral seconds while the system performs a self-diagnostic test.
However, if a fault is detected in the system:
•
The OWS indicator light will stay on.
•
The SRS warning light will come on and stay on and a text message will be dis­played.
WARNING
If a fault in the system is detected and indi­cated as described, be aware that the pas­senger's side front airbag will not deploy in the event of a collision. In this case, the SRS system and Occupant Weight Sensor should be inspected by a trained and quali­fied Volvo service technician as soon as possible.
WARNING
•
Never try to open, remove or repair any components in the OWS system. This could cause the system to malfunction. Maintenance or repairs should only be carried out by an a trained and qualified Volvo service technician.
•
The front passenger's seat should not be modified in any way. This could reduce pressure on the seat cushion, which might interfere with the OWS system's function.
||
SAFETY
58
Passeng­er's seat occupancy status
OWS indi­cator light status
Passenger's side front airbag sta­tus
Seat unoccu­pied
OWS indi­cator light lights up
Passenger's side front air­bag disabled
Seat occu­pied by low weight occu­pant/object
A
OWS indi­cator light lights up
Passenger's side front air­bag disabled
Seat occu­pied by heavy occu­pant/object
OWS indi­cator light is not lit
Passenger's side front air­bag enabled
A
Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. Do not assume that the passenger's side front airbag is dis­abled unless the PASSENGER AIRBAG OFF indicator lamp is lit. Make sure the child restraint is properly installed. If there is any doubt as to the status of the passenger's side front airbag, move the child restraint to the rear seat.
The OWS is designed to enable (may inflate) the passenger's side front airbag in the event of a collision anytime the system senses that a person of adult size is sitting properly in the front passenger's seat. The PASSENGER AIR­BAG OFF indicator lamp will be off and remain off.
If a person of adult size is sitting in the front passenger's seat, but the PASSENGER AIR-
BAG OFF indicator lamp is on, it is possible that the person isn't sitting properly in the seat. If this happens:
•
Turn the vehicle off and ask the person to place the backrest in an upright position.
•
Have the person sit upright in the seat, centered on the seat cushion, with the person's legs comfortably extended.
•
Restart the vehicle and have the person remain in this position for about two minutes. This will allow the system to detect that person and enable the pas­senger's frontal airbag.
•
If the PASSENGER AIRBAG OFF indica­tor lamp remains on even after this, the person should be advised to ride in the rear seat.
This indicates limitations in OWS classifica­tion capability. It does not indicate OWS mal­function.

Modifications

If you are considering modifying your vehicle in any way to accommodate a disability, for example by altering or adapting the driver's or front passenger's seat(s) and/or airbag sys­tems, please contact Volvo at:
In the United States
Volvo Car USA, LLC Customer Care Center
1 Volvo Drive P.O. Box 914 Rockleigh, New Jersey 07647 18004581552
In Canada
Volvo Car Canada Ltd. Customer Care Centre 9130 Leslie Street, Suite 101 Richmond Hill, Ontario L4B 0B9 18006638255
SAFETY
59
WARNING
•
No objects that add to the total weight on the seat should be placed on the front passenger's seat. If a child is seated in the front passenger's seat with any additional weight, this extra weight could cause the OWS system to enable the airbag, which might cause it to deploy in the event of a col­lision, thereby injuring the child.
•
The seat belt should never be wrapped around an object on the front passeng­er's seat. This could interfere with the OWS system's function.
•
The front passenger's seat belt should never be used in a way that exerts more pressure on the passenger than normal. This could increase the pres­sure exerted on the weight sensor by a child, and could result in the airbag being enabled, which might cause it to deploy in the event of a collision, thereby injuring the child.
WARNING
•
Keep the following points in mind with respect to the OWS system. Failure to follow these instructions could adversely affect the system's function and result in serious injury to the occu­pant of the front passenger's seat.
•
The full weight of the front seat pas­senger should always be on the seat cushion. The passenger should never lift him/herself off the seat cushion using the armrest in the door or the center console, by pressing the feet on the floor, by sitting on the edge of the seat cushion, or by pressing against the backrest in a way that reduces pressure on the seat cushion. This could cause OWS to disable the front, passenger's side airbag.
WARNING
•
Do not place any type of object on the front passenger's seat in such a way that jamming, pressing, or squeezing occurs between the object and the front seat, other than as a direct result of the correct use of the Automatic Locking Retractor/Emergency Locking Retractor (ALRELR) seat belt.
•
No objects should be placed under the front passenger's seat. This could inter­fere with the OWS system's function.

Related information

•
Driver/passenger-side airbags (p. 53)
SAFETY
60

Side airbags

The side airbags, on the driver's and passen­ger sides, protect the chest and hip in a colli­sion.
The side airbags are located in the front seats' outer backrest frames and help protect the driver and front seat passenger.
A collision of a sufficiently violent force will trigger the sensors and one or more side air­bags will inflate. The side airbags inflate between the seat occupant and the door panel to help cushion the initial impact of the colli­sion. The airbag deflates when compressed by the collision. The side airbags are normally only deployed on the side of the vehicle impacted by the collision.
WARNING
Volvo recommends contacting an author­ized Volvo workshop for repairs. Incorrectly performed repairs to the side airbag sys­tem could impair function and lead to seri­ous injury.
WARNING
Do not place any objects in the area between the outer edges of the seats and the door panels, as this could impair the function of the side airbags.
Volvo recommends only using seat covers approved by Volvo. Other seat covers could prevent the side airbags from functioning properly.
WARNING
The side airbag is a supplement to the seat belt. Always wear your seat belt.

Related information

•
Airbags (p. 52)

Inflatable curtain

The inflatable curtain, Inflatable Curtain (IC), helps to prevent the driver and passengers from striking their heads on the inside of the vehicle during a collision.
The inflatable curtains are installed along both sides of the inside of the roof and help protect occupants in the vehicle's outer seats. IC AIRBAG is embossed on the panels.
A collision of a sufficiently violent force will trigger the sensors and the inflatable curtain will inflate.
SAFETY
}}
61
WARNING
Volvo recommends contacting an author­ized Volvo workshop for repair. Incorrectly performed repairs to the inflatable curtain system could impair function and lead to serious injury.
WARNING
Never hang or attach heavy objects in the handle in the ceiling. The hooks are only intended for lightweight garments (not for hard objects such as umbrellas).
Never screw or mount anything to the vehi­cle's headlining, door pillars or side panels. This could impair the intended protective properties. Volvo recommends only using Volvo original parts that are approved for placement in these areas.
WARNING
If objects are loaded higher than the upper edge of the side windows, leave a 10 cm (4 in.) space between the objects and the window. Objects placed closer to this could impede the function of the inflatable curtain concealed inside the headlining.
WARNING
The inflatable curtain is a supplement to the seat belt. Always wear your seat belt.

Related information

•
Airbags (p. 52)

Safety mode

Safety mode is a feature that is triggered after a collision if there is potential damage to an important function in the vehicle, such as the fuel lines, sensors for one of the safety systems, the brake system, etc.
If the vehicle has been involved in a collision, the text
Safety mode See Owner's manual
may appear in the instrument panel along with the warning symbol if the panel is undamaged and the vehicle's electrical system is intact. The message indicates that one or more of the vehicle's functions may be reduced.
WARNING
Never attempt to restart the vehicle if you smell fuel fumes when the message
Safety
mode See Owner's manual is displayed
in the instrument panel. Leave the vehicle immediately.
If safety mode has been set, it may be possi­ble to reset the system in order to start and move the vehicle a short distance, for exam­ple, if it is blocking traffic.
||
SAFETY
62
WARNING
Never attempt to perform repairs or reset electrical components on your own after the vehicle has been in safety mode. This could result in injury or prevent the vehicle from functioning properly. Volvo recom­mends having the vehicle inspected and reset to normal operating status by an authorized Volvo workshop after
Safety
mode See Owner's manual has been dis-
played.
WARNING
When the vehicle is in safety mode, it should not be towed behind another vehi­cle. It should be towed from the site on a tow truck. Volvo recommends towing the vehicle directly to an authorized Volvo workshop.

Related information

•
Safety (p. 42)
•
Starting and moving the vehicle when it is in safety mode (p. 62)
•
Recovery (p. 442)

Starting and moving the vehicle when it is in safety mode

If safety mode has been set, it may be possi­ble to reset the system in order to start and move the vehicle a short distance, for exam­ple, if it is blocking traffic.

Starting the vehicle when it is in safety mode

1. Check the vehicle for damage, particularly for fuel leakage. Make sure you do not detect any gasoline fumes.
If the damage to the vehicle is minor and there is no fuel leakage/fumes, you may attempt to start the engine.
WARNING
Never attempt to restart the vehicle if you smell fuel fumes when the message
Safety
mode See Owner's manual is displayed
in the instrument panel. Leave the vehicle immediately.
2. Switch off the ignition.
3. Then try to start the vehicle. > The vehicle's electrical system will per-
form a system check and then attempt to reset to normal operating mode. The message
Vehicle start System check,
wait will be displayed on the instru-
ment panel during the check. This may take up to a minute.
4.
When Vehicle start System check, wait is no longer displayed in the instrument panel, try again to start the vehicle.
CAUTION
If the message Safety mode See
Owner's manual is still displayed, the
vehicle should not be driven or towed behind another vehicle. If the vehicle needs to be moved, it must be towed on a tow truck. Even if no damage is apparent, there may be hidden damage that could make the vehicle impossible to control.
SAFETY
}}
63

Moving the vehicle when it is in safety mode

1.
If the message
Normal mode The
vehicle is now in normal mode is dis-
played after attempting to start the engine, the vehicle may be moved care­fully from its present position if, for exam­ple, it is blocking traffic.
2. Do not move the vehicle farther than abso­lutely necessary.
WARNING
When the vehicle is in safety mode, it should not be towed behind another vehi­cle. It should be towed from the site on a tow truck. Volvo recommends towing the vehicle directly to an authorized Volvo workshop.

Related information

•
Safety mode (p. 61)
•
Starting the vehicle (p. 392)
•
Recovery (p. 442)

Child safety

Children should always be seated safely when traveling in the vehicle.

General information

Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a vehicle.
Your vehicle is also equipped with ISOFIX LATCH attachments, which make it more con­venient to install child seats.
Some restraint systems for children are designed to be secured in the vehicle by lap belts or the lap portion of a lap-shoulder belt. Such child restraint systems can help protect children in vehicles in the event of an accident only if they are used properly. However, chil­dren could be endangered in a crash if the child restraints are not properly secured in the vehicle. Failure to follow the installation instructions for your child restraint can result in your child striking the vehicle's interior in a sudden stop.
Holding a child in your arms is NOT a suitable substitute for a child restraint system. In an accident, a child held in a person's arms can be crushed between the vehicle's interior and an unrestrained person. The child could also be injured by striking the interior, or by being
ejected from the vehicle during a sudden maneuver or impact. The same can also hap­pen if the infant or child rides unrestrained on the seat. Other occupants should also be properly restrained to help reduce the chance of injuring or increasing the injury of a child.
All states and provinces have legislation gov­erning how and where children should be car­ried in a vehicle. Find out the regulations exist­ing in your state or province. Recent accident statistics have shown that children are safer in rear seating positions than front seating posi­tions when properly restrained. A child restraint system can help protect a child in a vehicle. Here's what to look for when selecting a child restraint system:
It should have a label certifying that it meets applicable Federal Motor Vehicle Safety Standards (FMVSS 213) - or in Canada, CMVSS 213.
Make sure the child restraint system is approved for the child's height, weight and development - the label required by the stand­ard or regulation, or instructions for infant restraints, typically provide this information.
In using any child restraint system, we urge you to carefully look over the instructions that are provided with the restraint. Be sure you understand them and can use the device prop­erly and safely in this vehicle. A misused child restraint system can result in increased inju-
||
SAFETY
64
ries for both the infant or child and other occu­pants in the vehicle.
When a child has outgrown the child safety seat, you should use the rear seat with the standard seat belt fastened. The best way to help protect the child here is to place the child on a cushion so that the seat belt is properly located on the hips. Legislation in your state or province may mandate the use of a child seat or cushion in combination with the seat belt, depending on the child's age and/or size. Please check local regulations.
A specially designed and tested booster cush­ion and backrest can be obtained from your Volvo retailer. See also the article "Integrated booster cushion."
WARNING
•
Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children under 140 cm (4 feet 7 inches) in height who have outgrown these devices sit in the rear seat with the seat belt fastened.
•
Sedan models: Keep vehicle doors and trunk locked and keep remote controls out of a child's reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehi­cles.
•
On hot days, the temperature in the vehicle interior can rise very quickly. Exposure to these high temperatures for even a short period of time can cause heat-related injury or death. Small children are particularly at risk. Never leave children unattended in a vehicle.
Child seats should always be registered.

Volvo's recommendations

Why does Volvo believe that no child should sit in the front seat of a vehicle? It's quite sim­ple really. A front airbag is a very powerful
device designed, by law, to help protect an adult.
Because of the size of the airbag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly bel­ted or strapped into a child safety seat. Volvo has been an innovator in the field of safety since it was founded. And we have no inten­tion of resting on our laurels. But we need your help. Please remember to put your chil­dren in the back seat, and buckle them up.
WARNING
A child restraint should never be reused if:
•
The vehicle has been involved in a colli­sion, no matter how minor
•
Its history is unknown
•
It is older than the manufacturer's expi­ration date
SAFETY
}}
65
Volvo has some very specific recommendations
•
Always wear your seat belt.
•
Airbags are a SUPPLEMENTAL safety device which, when used with a three­point seat belt can help reduce serious injuries during certain types of accidents. Volvo recommends that you do not dis­connect the airbag system in your vehicle.
•
Volvo strongly recommends that everyone in the vehicle be properly restrained.
•
Volvo recommends that ALL occupants (adults and children) shorter than 140 cm (4 feet 7 inches) be seated in the rear seat of any vehicle with a front passenger side airbag.
•
Drive safely!

Related information

•
Safety (p. 42)
•
Child restraints (p. 65)
•
Activating and deactivating child safety locks (p. 252)

Child restraints

Suitable child restraints should always be used when children travel in the vehicle.

Child restraint systems

Infant seat
There are three main types of child restraint systems: infant seats, convertible seats and booster cushions. They are classified accord­ing to the child's age and size.
The child restraint should be secured using a three-point seat belt, ISOFIXLATCH anchors or top tether anchors.
Convertible seat
WARNING
A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag - not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated. If the severity of an accident were to cause the airbag to inflate, this could lead to serious injury or death to a child seated in this position.
||
SAFETY
66
Booster cushion
WARNING
Always refer to the child restraint manufac­turer's instructions for detailed information on securing the restraint.
WARNING
•
When not in use, keep the child restraint system secured or remove it from the passenger compartment to help prevent it from injuring passen­gers in the event of a sudden stop or collision.
•
A small child's head represents a con­siderable part of its total weight and its neck is still very weak. Volvo recom­mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil­dren should ride rearward facing, prop­erly restrained, as long as possible.
NOTE
Prolonged installation and use of the child restraint may damage the vehicle's interior. Volvo recommends using the kick guard accessory to help protect the vehicle's interior.
Automatic Locking Retractor/ Emergency Locking Retractor (ALR ELR)
To make child seat installation easier, each seat belt (except for the driver's belt) is equip­ped with a locking mechanism to help keep the seat belt taut.
When attaching the seat belt to a child seat:
1. Attach the seat belt to the child seat according to the child seat manufacturer's instructions.
2. Pull the seat belt out as far as possible.
3. Insert the seat belt latch plate into the buckle (lock) in the usual way.
4. Release the seat belt and pull it taut around the child seat.
A sound from the seat belt retractor will be audible at this time and is normal. The belt will now be locked in place. This function is auto­matically disabled when the seat belt is unlocked and the belt is fully retracted.
WARNING
Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children who have outgrown these devices sit in the rear seat with the seat belt prop­erly fastened.

Child restraint registration and recalls

Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall. To stay informed about child safety seat recalls, be sure to fill
SAFETY
}}
67
out and return the registration card that comes with new child restraints.
Child restraint recall information is readily available in both the U.S. and Canada. For recall information in the U.S., call the U.S. Government's Auto Safety Hotline at 18004249393 or go to http://www­odi.nhtsa.dot.gov/cars/problems/recalls/ register/childseat/index.cfm. In Canada, visit Transport Canada's Child Safety website at http://www.tc.gc.ca/roadsafety/childsafety/ menu.htm.

Related information

•
Child safety (p. 63)
•
Infant seats (p. 67)
•
Convertible seats (p. 69)
•
Booster cushions (p. 72)
•
Top tether anchors (p. 73)
•
Lower child seat attachment points (p. 74)
•
ISOFIXLATCH lower anchors (p. 75)

Infant seats

Suitable child restraints should always be used when children (depending on their age/ size) are seated in the vehicle.

Securing an infant seat with a seat belt

Do not place the infant seat in the front passenger's seat.
1. Place the infant seat in the rear seat of the vehicle.
2. Attach the seat belt to the infant seat according to the child restraint manufac­turer's instructions.
Route the seat belt through the infant seat.
WARNING
•
An infant seat must be in the rear-facing position only.
•
The infant seat should not be positioned behind the driver's seat unless there is adequate space for safe installation.
||
SAFETY
68
WARNING
A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag - not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated. If the severity of an accident were to cause the airbag to inflate, this could lead to serious injury or death to a child seated in this position.
3.
Fasten the seat belt.
Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct click is audible.
Pull out the shoulder section of the seat belt.
4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's automatic locking function.
NOTE
The locking retractor will automatically release when the seat belt is unbuckled and allowed to retract fully.
5. Press the infant seat firmly in place, let the seat belt retract and pull it taut. A sound from the seat belt retractor's automatic locking function will be audible at this time and is normal. The seat belt should now be locked in place.
Check that the infant seat is properly secured.
6. Press and pull the infant seat along the direction of the seat belt to check that it is properly held in place by the seat belt.
SAFETY
}}
69
WARNING
It should not be possible to move the child restraint more than 2.5 cm (1 in.) in any direction along the seat belt path.
When installing infant seats in the rear seat, Volvo recommends maintaining a distance of at least 50 mm (2 inches) from the front-most part of the infant seat to the rearmost part of the seat in front.
The infant seat can be removed by unbuckling the seat belt and letting it retract completely.

Related information

•
Child restraints (p. 65)
•
Convertible seats (p. 69)
•
Booster cushions (p. 72)
•
Top tether anchors (p. 73)
•
Lower child seat attachment points (p. 74)
•
ISOFIXLATCH lower anchors (p. 75)

Convertible seats

Suitable child restraints should always be used when children (depending on their age/ size) are seated in the vehicle.

Securing a convertible seat with a seat belt

Do not place the convertible seat in the front pas­senger's seat.
Convertible seats can be used in either a for­ward or rearward-facing position, depending on the age and size of the child.
||
SAFETY
70
Route the seat belt through the convertible seat.
WARNING
Always use a convertible seat that is suita­ble for the child's age and size. See the convertible seat manufacturer's recom­mendations.
1. Place the convertible seat in the rear seat of the vehicle.
WARNING
•
A small child's head represents a con­siderable part of its total weight and its neck is still very weak. Volvo recom­mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil­dren should ride rearward facing, prop­erly restrained, as long as possible.
•
Convertible child seats should be instal­led in the rear seat only.
•
A rear-facing convertible seat should not be positioned behind the driver's seat unless there is adequate space for safe installation.
2. Attach the seat belt to the convertible seat according to the child restraint manufac­turer's instructions.
Fasten the seat belt.
3. Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct click is audible.
4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's automatic locking function.
SAFETY
71
NOTE
The locking retractor will automatically release when the seat belt is unbuckled and allowed to retract fully.
5. Press the convertible seat firmly in place, let the seat belt retract and pull it taut. A sound from the seat belt retractor's auto­matic locking function will be audible at this time and is normal. The seat belt should now be locked in place.
Pull out the shoulder section of the seat belt.
6. Push and pull the convertible seat along the seat belt path to ensure that it is held securely in place by the seat belt.
WARNING
It should not be possible to move the child restraint more than 2.5 cm (1 in.) in any direction along the seat belt path.
The convertible seat can be removed by unbuckling the seat belt and letting it retract completely.
Ensure that the convertible seat is securely in place.
WARNING
A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag - not even if the "Passenger airbag off" symbol near the rear-view mirror is illuminated. If the severity of an accident were to cause the airbag to inflate, this could lead to serious injury or death to a child seated in this position.

Related information

•
Child restraints (p. 65)
•
Infant seats (p. 67)
•
Booster cushions (p. 72)
•
Top tether anchors (p. 73)
•
Lower child seat attachment points (p. 74)
•
ISOFIXLATCH lower anchors (p. 75)
SAFETY
72

Booster cushions

Suitable child restraints should always be used when children (depending on their age/ size) are seated in the vehicle.

Securing a booster cushion

Position the child correctly on the booster cushion.
Booster cushions are recommended for chil­dren who have outgrown convertible seats.
1. Place the booster cushion in the rear seat of the vehicle.
2. With the child properly seated on the booster cushion, attach the seat belt to or around the cushion according to the man­ufacturer's instructions.
3. Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct click is audible.
Positioning the seat belt.
4. Ensure that the seat belt is pulled taut and fits snugly around the child.
WARNING
•
The hip section of the three-point seat belt must fit snugly across the child's hips, not across the stomach.
•
The shoulder section of the three-point seat belt should be positioned across the chest and shoulder.
•
The shoulder belt must never be placed behind the child's back or under the arm.

Related information

•
Child restraints (p. 65)
•
Convertible seats (p. 69)
•
Infant seats (p. 67)
•
Top tether anchors (p. 73)
•
Lower child seat attachment points (p. 74)
•
ISOFIXLATCH lower anchors (p. 75)
SAFETY
}}
73

Top tether anchors

Your Volvo is equipped with child restraint top tether anchorages for all three seating positions in the rear seat. They are located on the rear parcel shelf.

Child restraint anchorages

Top tether anchors and symbols on the rear parcel shelf.
Securing a child seat
1. Place the child restraint on the rear seat.
2. Route the top tether strap under the head restraint and attach it to the anchor.
3. Attach the strap for the lower tether anchors in the lower ISOFIXLATCH attachment points. If the child restraint is not equipped with straps for the lower tether anchors, or if the child restraint is used on the center seating position, follow the instructions for attaching a child restraint using the automatic locking seat belt.
4. Firmly tension all straps.
Refer also to the child seat manufacturer's instructions for information on securing the child seat.
WARNING
•
Always refer to the recommendations made by the child restraint manufac­turer.
•
Volvo recommends that the top tether anchors be used when installing a for­ward-facing child restraint.
•
Never route a top tether strap over the top of the head restraint. The strap should be routed beneath the head restraint.
•
Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seat belts or harnesses. The anchorages are not able to withstand excessive forces on them in the event of collision if full harness seat belts or adult seat belts are instal­led to them. An adult who uses a belt anchored in a child restraint anchorage runs a great risk of suffering severe injuries should a collision occur.
•
Do not install rear speakers that require the removal of the top tether anchors or interfere with the proper use of the top tether strap.
||
SAFETY
74

Related information

•
Child restraints (p. 65)
•
Lower child seat attachment points (p. 74)
•
ISOFIXLATCH lower anchors (p. 75)

Lower child seat attachment points

The rear seats are equipped with lower child seat attachment points.
The lower child seat attachment points are intended for use with certain rear-facing child restraints.
Always follow the manufacturer's installation instructions when attaching a child seat to the lower child seat attachment points.

Location of child seat attachment points

Location of child seat attachment points in the rear seat.
The child seat attachment points in the rear seat are located on the rear section of the front seat floor rails.

Related information

•
Child restraints (p. 65)
•
Top tether anchors (p. 73)
•
ISOFIXLATCH lower anchors (p. 75)
SAFETY
}}
75
ISOFIXLATCH lower anchors
Lower anchors for ISOFIXLATCH-equipped child seats are located in the rear, outboard seats, hidden below the backrest cushions.
Using the ISOFIXLATCH lower child seat anchors
Location of the ISOFIXLATCH anchors
Symbols on the seat back upholstery mark the ISOFIXLATCH anchor positions as shown. To access the anchors, kneel on the seat cushion and locate the anchors by feel. Always follow your child seat manufacturer's installation instructions, and use both ISOFIXLATCH lower anchors and top tethers whenever pos­sible.
To access the anchors
1. Put the child restraint in position.
2. Kneel on the child restraint to press down the seat cushion and locate the anchors by feel.
3. Fasten the attachment on the child restraint's lower straps to the ISOFIX LATCH lower anchors.
4. Firmly tension the lower child seat straps according to the manufacturer's instruc­tions.
WARNING
Volvo's ISOFIXLATCH anchors conform to FMVSSCMVSS standards. Always refer to the child restraint system's manual for weight and size ratings.
NOTE
•
The rear center seat is not equipped with ISOFIXLATCH lower tether anchors. If a child restraint is used in this seat, attach the restraint's upper anchor strap (if equipped with these) to the top tether anchor point for this strap and secure the child restraint with the vehicle's center seat belt.
•
Always follow your child seat manufac­turer's installation instructions, and use both ISOFIXLATCH lower anchors and top tethers whenever possible.
Fasten the attachment correctly to the ISOFIX LATCH lower anchors.
WARNING
•
Be sure to fasten the attachment cor­rectly to the anchor (see the illustra­tion). If the attachment is not correctly fastened, the child restraint may not be properly secured in the event of a colli­sion.
•
The ISOFIXLATCH lower child restraint anchors are only intended for use with child seats positioned in the outboard seating positions. These anchors are not certified for use with any child restraint that is positioned in the center seating position. When securing a child restraint in the center seating position, use only the vehicle's center seat belt.
||
SAFETY
76

Related information

•
Child restraints (p. 65)
•
Top tether anchors (p. 73)
•
ISOFIXLATCH lower anchors (p. 75)
DISPLAYS AND VOICE CONTROL

DISPLAYS AND VOICE CONTROL

* Option/accessory.
78
Instruments and controls in left­hand drive vehicles
The overviews show the location of the vehi­cle's displays and controls.

Steering wheel and dashboard

Parking lights, daytime running lights, low beams, high beams, turn signals, rear fog light, trip computer reset
Steering wheel paddles for manual shift­ing*
Head-up display*
Instrument panel
Wipers and washers, rain sensor*
Right-side steering wheel keypad
Steering wheel adjustment
Horn
Left-side steering wheel keypad
Hood open
Display lighting, trunk lid unlock/open, halogen headlight height adjustment

Ceiling console

Front reading lights and courtesy lighting
Panoramic roof*
Ceiling console display ON CALL button
HomeLink®*

Center and tunnel console

Center display
Hazard warning flashers, defrosting, media
Gear selector
Start knob
Drive modes
Parking brake
Auto-hold brakes
DISPLAYS AND VOICE CONTROL
* Option/accessory.
79

Driver's door

Memory for power front seat settings*, door mirrors and head-up display*
Central locking
Power windows, door mirrors, electric child safety locks*
Controls for front seat

Related information

•
Manual front seats (p. 182)
•
Adjusting the power* front seats (p. 183)
•
Adjusting the steering wheel (p. 195)
•
Lighting control and panel (p. 150)
•
Starting the vehicle (p. 392)
•
Instrument panel (p. 80)
•
Center display overview (p. 107)
•
Transmission (p. 406)
DISPLAYS AND VOICE CONTROL
* Option/accessory.
80

Instrument panel

The instrument panel displays information related to the vehicle and driving.
The instrument panel contains gauges, indica­tors and monitoring and warning symbols. What is shown in the instrument panel varies depending on the equipment, settings and functions currently active.
The instrument panel is activated as soon as a door is opened, i.e. in ignition mode 0. The panel will power down after a short period of time if it is not used. To reactivate it, do one of the following:
•
Depress the brake pedal.
•
Activate ignition mode I.
•
Open one of the doors.
WARNING
If the instrument panel turns off, does not activate when the ignition is switched on, or part/all of the panel cannot be read, do not drive the vehicle. Consult a workshop immediately. Volvo recommends an authorized Volvo workshop.
WARNING
If the instrument panel is not functioning properly, information about brakes, airbags or other safety-related systems may not be displayed. The driver will then not be able to check the status of the vehicle systems or receive relevant warnings and informa­tion.
The illustration is generic - details may vary accord­ing to vehicle model.
Location in the instrument panel:
Left side In the center Right side
Speedometer Indicator and warning symbols
Tachometer/Hybrid gauge
A
Trip odometer Ambient temperature sensor Gear indicator
Odometer
B
Clock Drive Mode
Cruise control/speed limiter information Message (also graphics in some cases) Fuel gauge
Road sign information*
Door and seat belt status Hybrid battery gauge
– Hybrid battery's charge level Distance to empty tank
DISPLAYS AND VOICE CONTROL
* Option/accessory.
81
Left side In the center Right side
– Media player Distance to discharged battery
–
Navigation system map*
Current fuel consumption
– Phone App menu (activated using steering wheel keypad)
– Voice Control –
A
Depends on selected drive mode.
B
Total distance.

Dynamic symbol

Dynamic symbol in basic mode.
In the center of the instrument panel is a dynamic symbol that changes appearance according to the type of message displayed. The severity of the control or warning symbol is indicated by a red or amber-colored marking around the symbol.
Example with indicator symbol.
An animation may be used to change the sym­bol into a graphic image to depict the location of a problem or to clarify information.

Related information

•
Instrument panel settings (p. 82)
•
Warning symbols in the instrument panel (p. 94)
•
Indicator symbols in the instrument panel (p. 91)
•
Trip computer (p. 85)
•
Messages in the instrument panel (p. 103)
•
Handling the App menu in the instrument panel (p. 102)
•
Drive modes (p. 413)
DISPLAYS AND VOICE CONTROL
* Option/accessory.
82

Instrument panel settings

Display settings for the instrument panel can be set via the instrument panel's app menu and via the center display's Settings menu.

Settings via instrument panel's app menu

The illustration is generic - details may vary accord­ing to vehicle model.
The app menu will open and can be controlled using the right-side steering wheel keypad.
The app menu can be used to set what infor­mation will be displayed in the instrument panel
•
trip computer
•
media player
•
phone
•
navigation system*.

Settings via center display

Selecting type of information
1.
Tap
Settings in the center display's Top
view.
2. Tap
My Car Displays Driver Display
Information
.
3. Select a background:
•
Show no information in the background
•
Show information for current playing media
•
Show navigation even if no route is set
Select theme
1.
Tap
Settings in the center display's Top
view.
2. Tap
My Car Displays Display
Themes
.
3. Select a theme (appearance) for the instrument panel:
•
Glass
•
Minimalistic
•
Performance
•
Chrome Rings
Select language
1.
Tap
Settings in the center display's Top
view.
2. Tap
System System Languages and
Units
System Language to select lan-
guage. > A change made here will affect the lan-
guage in all displays.
The settings are personal and saved automati­cally in the active driver profile.

Related information

•
Instrument panel (p. 80)
•
Handling the App menu in the instrument panel (p. 102)
•
Changing settings in the center display's Top view (p. 129)
DISPLAYS AND VOICE CONTROL
}}
83

Fuel gauge

The fuel gauge in the instrument panel shows the fuel level in the tank.
The illustration is generic - details may vary accord­ing to vehicle model.
The beige area in the fuel gauge indicates the amount of fuel left in the tank.
When the fuel level is low and it is time to refuel, the fuel pump symbol will illuminate with an amber-colored light. The trip computer also indicates the approximate distance driven on the fuel remaining in the tank.

Related information

•
Instrument panel (p. 80)
•
Hybrid battery gauge (p. 84)
•
Refueling (p. 428)
•
Fuel tank volume (p. 634)

Hybrid gauge

In Hybrid and Pure drive modes, the instru­ment panel will display a hybrid gauge, which can help the driver achieve optimal driving economy.
The hybrid gauge shows the ratio between the electric motor's current power consumption and the remaining available power. This infor­mation is shown in various ways.

Symbols in the hybrid gauge

Indicates the current available power from the electric motor. A solid sym­bol indicates that the electric motor is being used.
A hollow symbol indicates that the electric motor is not being used.
Indicates the power level when the internal combustion engine starts. A solid symbol indicates that the inter­nal combustion engine is being used.
Indicates the power level when the internal combustion engine will start. A hollow symbol indicates that the internal combustion engine is not
being used.
Indicates that the hybrid battery is being charged, e.g. by lightly press­ing the brake pedal.

Driver-requested power

The hybrid gauge displays the amount of power requested (utilized) by the driver through pressure on the accelerator pedal. The higher the reading on the scale, the more power utilized in the current gear. The mark between the lightning symbol and the drop symbol indicates the point at which the com­bustion engine will start.
||
DISPLAYS AND VOICE CONTROL
84
For example:
The vehicle has been started, but is stationary and no power is being requested.
The electric motor cannot supply the requested power and the internal combustion engine will start.
The vehicle is generating current to recharge the bat­tery, e.g. during light braking or engine braking on a downslope.

Related information

•
Drive modes (p. 413)
•
Instrument panel (p. 80)
•
Brakes (p. 397)
•
Starting and stopping the combustion engine in Twin Engine vehicles (p. 413)

Hybrid battery gauge

The hybrid battery gauge shows how much current is left in the hybrid battery.
The current in the hybrid battery is used to power the electric motor, but can also be used to heat or cool the vehicle. The trip computer calculates an approximate driving distance with the remaining current in the hybrid bat­tery.
DISPLAYS AND VOICE CONTROL
}}
85

Symbols in the hybrid battery gauge

The symbol in the hybrid battery gauge indicates that the
Hold function is activated.
The symbol indicates that the Charge function is activated.

Related information

•
Instrument panel (p. 80)
•
Charging the hybrid battery (p. 375)
•
Hold and Charge functions (p. 424)

Trip computer

The vehicle's trip computer registers data while driving such as mileage, fuel consump­tion and average speed.
To help promote fuel-efficient driving, data is recorded on both current and average fuel consumption. Data from the trip computer can be displayed in the instrument panel.
Example of trip computer information in the instru­ment panel. The illustration is generic - details may vary according to vehicle model.
The trip computer includes the following gauges:
•

Trip odometer

•

Odometer

•

Current fuel consumption

•
Distance to empty tank
•
Distance to discharged battery
•
Tourist - alternative speedometer
Unit standards for distance, speed, etc. can be changed via system settings in the center dis­play.
Trip odometer
There are two trip odometers: TM and TA. TM can be reset manually and TA is reset
automatically if the vehicle is not used for four hours.
During a drive, the trip odometer registers data on:
•
Mileage
•
Driving time
•
Average speed
•
Average fuel consumption
The readings since the trip odometer's last reset are displayed.
Odometer
The odometer records the vehicle's total mile­age. This reading cannot be reset.
Current fuel consumption
This gauge shows the vehicle's fuel consump­tion at that moment. The reading is updated about once a second.
||
DISPLAYS AND VOICE CONTROL
86

Distance to empty tank

The trip computer calculates the dis­tance that can be driven on the fuel remaining in the tank.
This calculation is based on average fuel con­sumption during the last 30 km (20 miles) and the amount of fuel remaining in the tank.
When the gauge displays "----", there is not enough fuel remaining to calculate the remain­ing mileage. Refuel as soon as possible.
NOTE
The information will change based on your driving style.
An economical driving style will generally increase how far you can drive on a certain amount of fuel.

Distance to discharged battery

This gauge shows the approximate distance that can be driven with the remaining current in the hybrid bat­tery.
This calculation is based on average consump­tion with a normally loaded vehicle in normal driving conditions, and takes into account whether the air conditioning is on or off. Changing drive modes from
Hybrid to Pure
may increase the calculated distance because
Pure mode has reduced climate control set-
tings (ECO Climate). When the gauge displays "----", there is little
charge remaining in the battery and electric motor range cannot be reliably calculated.
NOTE
The information will change based on your driving style.
An economical driving style will generally increase how far you can drive on a certain amount of fuel.
Starting values for fully charged hybrid battery
Because it is difficult to predict driving style and other factors that affect the range of elec­tric motors, Volvo uses a starting value when the vehicle is fully charged. This starting value provides an "up to" amount instead of a pre­diction on the range of the electric current in the motor. The difference in starting value between
Hybrid and Pure is because the
vehicle is permitted to use more current from the hybrid battery in Pure mode, and because the vehicle switches to ECO Climate.
Mileage when using electric motor
To achieve the longest possible mileage when using the electric motor, the driver of an elec­tric vehicle also needs to think about conserv-
ing electricity. The more electricity consumers (stereo, heated windows/mirrors/seats, very cold air from climate control system, etc.) that are active, the shorter the potential mileage.
NOTE
In addition to high electrical consumption in the passenger compartment, rapid acceleration, sudden braking, high speeds, heavy loads, low ambient temperatures and driving up hills can reduce possible driving distance.

Tourist - alternative speedometer

The alternative digital speedometer makes it easier to drive in countries where speed limit signs are shown in a different measurement unit than the one shown in the vehicle's gauges.
When used, the digital speed is displayed in the opposite unit to that shown in the analog speedometer. If mph is used in the analog speedometer, the equivalent speed in km/h will be shown in the digital speedometer.

Related information

•
Displaying trip data in the instrument panel (p. 87)
•
Resetting the trip odometer (p. 88)
•
Displaying trip statistics in the center dis­play (p. 88)
DISPLAYS AND VOICE CONTROL
}}
87
•
Instrument panel (p. 80)
•
Changing system units of measurement (p. 129)

Displaying trip data in the instrument panel

Data recorded and calculated by the trip computer can be displayed on the instrument panel.
This data is stored in a trip computer app. You can choose which information the instrument panel will display in the app menu.
Open and navigate in the app menu1 using the right­hand steering wheel keypad.
App menu
Left/right
Up/down
Confirm
1. Open the app menu in the instrument panel by pressing (1).
(The App menu cannot be opened while there is an unacknowledged message in the instrument panel. The message must be acknowledged by pressing the O but­ton (4) before the App menu can be opened).
2. Navigate to the trip computer app by mov­ing left or right using (2).
> The top four menu rows show meas-
ured values for trip odometer TM. The next four menu rows show measured values for trip odometer TA. Scroll up or down in the list using (3).
1
The illustration is generic - details may vary according to vehicle model.
||
DISPLAYS AND VOICE CONTROL
88
3. Scroll down to the option buttons to choose which information to show in the instrument panel:
•
Odometer
•
Distance to empty tank
•
Distance to discharged battery
•
Tourist (alternative speedometer)
•
Mileage for trip odometer TM, TA or no display of mileage
•
Current fuel consumption, average fuel consumption for TM or TA, or no dis­play of fuel consumption
Select or clear a selection using the O but­ton (4). The change will apply immedi­ately.

Related information

•
Trip computer (p. 85)
•
Resetting the trip odometer (p. 88)

Resetting the trip odometer

Resetting the trip odometer using the left­side steering wheel lever.
–
Reset all information in trip odometer TM (i.e. mileage, average fuel consumption, average speed and driving time) by press­ing and holding the RESET button on the left-hand steering wheel lever.
Tapping the RESET button only resets the distance driven.
The TA trip odometer can not be manually reset. It resets automatically if the vehicle is not used for four hours or more.

Related information

•
Trip computer (p. 85)

Displaying trip statistics in the center display

Trip computer statistics can be displayed graphically in the center display, providing an overview that facilitates more fuel-efficient driving.
Open the Driver
performance app in the App
view to display trip statistics. Each bar in the graph repre-
sents a driving distance of 1
kilometers, 10 kilometers or 100 kilometers (or miles). The bars are added from the right as you drive. The bar at the far right shows the data for the current trip.
Average fuel consumption and total driving time are calculated from the most recent reset of the trip statistics.
Fuel and electricity consumption are shown in separate graphs. The electricity consumption shows "net" consumption, i.e. consumed cur­rent minus regenerated current generated by braking.
DISPLAYS AND VOICE CONTROL
89
Trip computer statistics2.

Related information

•
Trip statistics settings (p. 89)
•
Trip computer (p. 85)

Trip statistics settings

Trip statistics settings can be reset or adjusted.
1.
Open the
Driver performance app in the
App view to display trip statistics.
2.
Tap
Preferences to
•
change the graph scale. Select 1, 10 or 100 km/miles for the bar.
•
reset data after each trip. Performed when the vehicle remains stationary for more than 4 hours.
•
reset data for current trip.
Trip statistics, calculated average con­sumption, and total driving time are always reset simultaneously.
Unit standards for distance, speed, etc. can be changed via system settings in the center dis­play.

Related information

•
Displaying trip statistics in the center dis­play (p. 88)
•
Trip computer (p. 85)
•
Resetting the trip odometer (p. 88)
2
The illustration is generic - details may vary according to vehicle model.
DISPLAYS AND VOICE CONTROL
* Option/accessory.
90

Date and time

The clock is displayed in both the instrument panel and the center display.

Location of clock

Certain messages and other information may obscure the clock in the instrument panel.
In the center display, the clock is located on the upper right-hand side in the status bar.

Settings for date and time

–
Select Settings System Date and
Time
in the center display's Top view to
change settings for time and date format. Adjust the date and time by tapping the
up or down arrows on the touchscreen.
Automatic time for vehicles with GPS
When the vehicle is equipped with a naviga­tion system,
Auto Time is also available. The
time zone will then be automatically set to the vehicle's location. In some navigation systems, the current location must also be set to deter­mine the correct time zone. If
Auto Time is
not selected, the time and date can be adjusted using the up and down arrows on the touchscreen.
Daylight savings time
In some countries, the Auto Daylight Saving
Time setting can be selected to automatically
change to daylight savings time. For other countries, the Daylight Saving Time setting can be selected manually.

Related information

•
Instrument panel (p. 80)
•
Changing settings in the center display's Top view (p. 129)

Ambient temperature sensor

The ambient temperature is shown in the instrument panel.
The sensor detects the temperature outside the vehicle.
If the vehicle has been stationary, the sensor reading may be higher than the actual tem­perature.
When the ambient temperature is between –5 °C and +2 °C (23 °F and 36 °F), a snowflake symbol will illuminate to alert the driver of the
risk of slippery conditions. The symbol is also temporarily lit in the head-
up display* if the vehicle is equipped with one. Change the measurement standard for the
temperature sensor etc. via system settings in the center display's Top view.
DISPLAYS AND VOICE CONTROL
}}
91

Related information

•
Instrument panel (p. 80)
•
Changing system units of measurement (p. 129)

Indicator symbols in the instrument panel

The indicator symbols alert the driver that a function has been activated, that a system is running, or that a fault or error may have occurred.
Symbol Meaning
Information, see the message in the display
The information symbol illumi­nates and a message is displayed in the instrument panel if one of the vehicle's systems requires the driver's attention. The infor­mation symbol may also illumi­nate in combination with other symbols.
A
B
Fault in brake system
This symbol illuminates if there is a problem with the parking brake.
Symbol Meaning
A
B
Fault in ABS system
If this symbol is illuminated, the ABS system is malfunctioning. The vehicle's regular brakes will still work, but without the ABS function.
A
B
Auto-brake on
This symbol illuminates when the function is activated and the brakes or parking brakes are being used. The brakes hold the vehicle at a standstill after it has stopped.
||
DISPLAYS AND VOICE CONTROL
92
Symbol Meaning
Tire pressure system
This symbol illuminates to indi­cate low tire pressure. If there is a fault in the tire pressure sys­tem, the symbol will first flash for approximately 1 minute and then glow steadily. This may occur if the system cannot detect or alert the driver of low tire pressure as intended.
Emission control system
If this symbol illuminates after starting the engine, it could indi­cate a fault in the vehicle's emis­sion control system. Have the vehicle checked by a workshop. Volvo recommends contacting an authorized Volvo workshop.
Left/right turn signals
The symbol will flash when the turn signals are in use.
Symbol Meaning
Parking lights
This symbol illuminates when the parking lights are on.
Fault in headlight system
This symbol illuminates if a fault has been detected in the ABL (Active Bending Lights) function or another fault in the headlight system.
Active high beams on
This symbol lights up in blue when the active high beams are on.
Active high beams off
This symbol lights up in white when the active high beams are off.
High beams on
This symbol illuminates when the high beams are on or flashed.
Active high beams on
This symbol lights up in blue when the active high beams are on. Parking lights are on.
Symbol Meaning
Active high beams off
This symbol lights up in white when the active high beams are off. Parking lights are on.
High beams on
This symbol illuminates when the high beams and parking lights are on.
Front fog lights on
This symbol illuminates when the front fog lights are on.
Rear fog light on
This symbol illuminates when the rear fog light is on.
Rain sensor on
This symbol illuminates when the rain sensor is on.
Preconditioning on
This symbol illuminates when the engine block/passenger com­partment heater or air condition­ing are preconditioning the vehi­cle.
DISPLAYS AND VOICE CONTROL
93
Symbol Meaning
Stability system
This symbol flashes when the stability system is actively work­ing to stabilize the vehicle. If the symbol glows steadily, there is a fault in the system.
Stability system, Sport mode
This symbol illuminates when Sport mode is activated. Sport mode offers a more active driving experience. If the system detects that accelerator pedal, steering wheel and cornering movements are more active than in normal driving, it allows a certain level of controlled lateral movement of the rear wheels before interven­ing and stabilizing the vehicle.
Symbol Meaning
Lane Keeping Aid
White symbol: Lane Keeping Aid is on and lane marker lines are detected.
Gray symbol: Lane Keeping Aid is on but no lane marker lines are detected.
Amber-colored symbol: Lane Keeping Aid is alerting/interven­ing.
Lane Keeping Aid and rain sen­sor
White symbol: Lane Keeping Aid is on and lane marker lines are detected. The rain sensor is on.
Gray symbol: Lane Keeping Aid is on but no lane marker lines are detected. The rain sensor is on.
Reduced performance
In the event of a temporary fault in the driveline, the vehicle may go into a "limp home" mode with reduced power output to help avoid damage to the driveline.
A
Canadian models.
B
US models.

Related information

•
Instrument panel (p. 80)
•
Warning symbols in the instrument panel (p. 94)
DISPLAYS AND VOICE CONTROL
94

Warning symbols in the instrument panel

The warning symbols alert the driver that an important function is activated or that a seri­ous fault or error has occurred.
Symbol Meaning
WARNING
The red warning symbol illumi­nates to indicate that a fault has been detected that could affect safety or driveability. An explana­tory message will be simultane­ously displayed in the instrument panel. The warning symbol may also illuminate in combination with other symbols.
Seat belt reminder
This symbol will glow steadily or flash if the driver or front seat passenger has not fastened their seat belt or if anyone in the rear seat has removed their seat belt.
Symbol Meaning
Airbags
If this symbol remains illumi­nated or comes on while driving, a fault has been detected in one of the vehicle's safety systems. Read the message in the instru­ment panel. Volvo recommends contacting an authorized Volvo workshop.
A
B
Fault in brake system
If this symbol illuminates, the brake fluid level may be too low. Contact your nearest authorized workshop to have the brake fluid level checked and adjusted.
Symbol Meaning
A
B
Parking brake on
This symbol glows steadily when the parking brake is applied.
A flashing symbol indicates that a fault has occurred. Read the message in the instrument panel.
Low oil pressure
If this symbol illuminates while driving when the engine oil pres­sure is too low. Stop the engine immediately and check the engine oil level. Add oil if neces­sary. If the symbol illuminates and the oil level is normal, con­tact a workshop. Volvo recom­mends contacting an authorized Volvo workshop.
Generator not charging
This symbol illuminates during driving if a fault is detected in the electrical system. Contact a workshop. Volvo recommends contacting an authorized Volvo workshop.
DISPLAYS AND VOICE CONTROL
}}
95
Symbol Meaning
Collision risk
City Safety warns the driver if there is a risk of a collision with another vehicle, pedestrian, cyclist or large animal.
System error
This symbol illuminates during driving if a fault is detected in the drive system. An explanatory message will be simultaneously displayed in the instrument panel.
High engine temperature
The symbol will illuminate while driving when the engine tem­perature is too high. An explana­tory message will be simultane­ously displayed in the instrument panel.
A
Canadian models.
B
US models.

Related information

•
Indicator symbols in the instrument panel (p. 91)
•
Instrument panel (p. 80)

Instrument panel licenses

A license is an agreement on the right to con­duct a certain activity or the right to use someone else's right according to terms and conditions specified in the agreement. The following text is Volvo's agreement with the manufacturer or developer.
Boost Software License 1.0
Permission is hereby granted, free of charge, to any person or organization obtaining a copy of the software and accompanying documentation covered by this license (the "Software") to use, reproduce, display, distribute, execute, and transmit the Software, and to prepare derivative works of the Software, and to permit third-parties to whom the Software is furnished to do so, all subject to the following: The copyright notices in the Software and this entire statement, including the above license grant, this restriction and the following disclaimer, must be included in all copies of the Software, in whole or in part, and all derivative works of the Software, unless such copies or derivative works are solely in the form of machine-executable object code generated by a source language processor.
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE AND NON INFRINGEMENT. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR ANYONE DISTRIBUTING THE SOFTWARE BE LIABLE FOR ANY DAMAGES OR OTHER LIABILITY, WHETHER IN CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
||
DISPLAYS AND VOICE CONTROL
96
BSD 4-clause "Original" or "Old" License
Copyright (c) 1982, 1986, 1990, 1991, 1993 The Regents of the University of California. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must display the following acknowledgement: This product includes software developed by the University of California, Berkeley and its contributors.
4. Neither the name of the University nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE REGENTS AND CONTRIBUTORS ``AS IS'' AND ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
BSD 3-clause "New" or "Revised" License
Copyright (c) 20112014, Yann Collet. Redistribution and use in source and binary
forms, with or without modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following
disclaimer in the documentation and/or other materials provided with the distribution.
3. Neither the name of the organisation nor the names of its contributors may be used to endorse or promote products derive from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
DISPLAYS AND VOICE CONTROL
}}
97
BSD 2-clause “Simplified” license
Copyright (c) <YEAR>, <OWNER> All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS
OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
The views and conclusions contained in the software and documentation are those of the authors and should not be interpreted as representing official policies, either expressed or implied, of the FreeBSD Project.
FreeType Project License
1. 1 Copyright 19961999 by David Turner, Robert Wilhelm, and Werner Lemberg Introduction The FreeType Project is distributed in several archive packages; some of them may contain, in addition to the FreeType font engine, various tools and contributions which rely on, or relate to, the FreeType Project. This license applies to all files found in such packages, and which do not fall under their own explicit license. The license affects thus the FreeType font engine, the test programs, documentation and makefiles, at the very least. This license was inspired by the BSD, Artistic, and IJG (Independent JPEG Group) licenses, which all encourage inclusion and use of
free software in commercial and freeware products alike. As a consequence, its main points are that: o We don't promise that this software works. However, we are be interested in any kind of bug reports. (`as is' distribution) o You can use this software for whatever you want, in parts or full form, without having to pay us. (`royalty-free' usage) o You may not pretend that you wrote this software. If you use it, or only parts of it, in a program, you must acknowledge somewhere in your documentation that you've used the FreeType code. (`credits') We specifically permit and encourage the inclusion of this software, with or without modifications, in commercial products, provided that all warranty or liability claims are assumed by the product vendor. Legal Terms 0. Definitions Throughout this license, the terms `package', `FreeType Project', and `FreeType archive' refer to the set of files originally distributed by the authors (David Turner, Robert Wilhelm, and Werner Lemberg) as the `FreeType project', be they named as alpha, beta or final release. `You' refers to the licensee, or person using the project, where `using' is a generic term including compiling the project's source code as well as linking it to form a `program' or `executable'. This program is referred to as `a program using the FreeType engine'. This license applies
||
DISPLAYS AND VOICE CONTROL
98
to all files distributed in the original FreeType archive, including all source code, binaries and documentation, unless otherwise stated in the file in its original, unmodified form as distributed in the original archive. If you are unsure whether or not a particular file is covered by this license, you must contact us to verify this. The FreeType project is copyright (C) 19961999 by David Turner, Robert Wilhelm, and Werner Lemberg. All rights reserved except as specified below. 1. No Warranty THE FREETYPE ARCHIVE IS PROVIDED `AS IS' WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL ANY OF THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY DAMAGES CAUSED BY THE USE OR THE INABILITY TO USE, OF THE FREETYPE PROJECT. As you have not signed this license, you are not required to accept it. However, as the FreeType project is copyrighted material, only this license, or another one contracted with the authors, grants you the right to use, distribute, and modify it. Therefore, by using, distributing, or modifying the FreeType project, you indicate that you
understand and accept all the terms of this license.
2. Redistribution Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: o Redistribution of source code must retain this license file (`licence.txt') unaltered; any additions, deletions or changes to the original files must be clearly indicated in accompanying documentation. The copyright notices of the unaltered, original files must be preserved in all copies of source files. o Redistribution in binary form must provide a disclaimer that states that the software is based in part of the work of the FreeType Team, in the distribution documentation. We also encourage you to put an URL to the FreeType web page in your documentation, though this isn't mandatory. These conditions apply to any software derived from or based on the FreeType code, not just the unmodified files. If you use our work, you must acknowledge us. However, no fee need be paid to us.
3. Advertising The names of FreeType's authors and contributors may not be used to endorse or promote products derived from this software without specific prior written permission. We suggest, but do not require, that you use one or more of
the following phrases to refer to this software in your documentation or advertising materials: `FreeType Project', `FreeType Engine', `FreeType library', or `FreeType Distribution'.
4. Contacts There are two mailing lists related to FreeType: o freetype@freetype.org Discusses general use and applications of FreeType, as well as future and wanted additions to the library and distribution. If you are looking for support, start in this list if you haven't found anything to help you in the documentation. o devel@freetype.org Discusses bugs, as well as engine internals, design issues, specific licenses, porting, etc. o http://www.freetype.org Holds the current FreeType web page, which will allow you to download our latest development version and read online documentation. You can also contact us individually at: David Turner <david.turner@freetype.org> Robert Wilhelm <robert.wilhelm@freetype.org> Werner Lemberg <werner.lemberg@freetype.org>
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
