VMware vCloud Director - 1.5 Administrator’s Guide

vCloud Director Administrator's Guide

vCloud Director 1.5

This document supports the version of each product listed and supports all subsequent versions until the document is replaced by a new edition. To check for more recent editions of this document, see http://www.vmware.com/support/pubs.

EN-000636-00

vCloud Director Administrator's Guide

You can find the most up-to-date technical documentation on the VMware Web site at:

http://www.vmware.com/support/

The VMware Web site also provides the latest product updates.

If you have comments about this documentation, submit your feedback to:

docfeedback@vmware.com

Copyright © 2010, 2011 VMware, Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. VMware products are covered by one or more patents listed at

http://www.vmware.com/go/patents.

VMware is a registered trademark or trademark of VMware, Inc. in the United States and/or other jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.

VMware, Inc.

3401 Hillview Ave. Palo Alto, CA 94304 www.vmware.com

2 VMware, Inc.

vCloud Director Administrator's Guide

Getting Started with vCloud Director 9

Overview of vCloud Director Administration 9

Preparing the System 12

Create a Microsoft Sysprep Deployment Package 12

Replace a Microsoft Sysprep Deployment Package 13

Set User Preferences 14

Change a System Administrator Password 14

Adding Resources to vCloud Director 15

Adding vSphere Resources 15

Adding Cloud Resources 17

Creating and Provisioning Organizations 23

Understanding Leases 23

Create an Organization 24

Allocate Resources to an Organization 28

Adding Networks to an Organization 32

Creating a Published Catalog 35

Enable Catalog Publishing 35

Create a Published Catalog 36

Upload a vApp Template 36

Import a vApp Template from vSphere 37

Upload a Media File 37

Import a Media File from vSphere 38

Publish a Catalog 38

Managing Cloud Resources 39

Managing Provider vDCs 39

Managing Organization vDCs 43

Managing External Networks 49

Managing Organization Networks 50

Managing Network Pools 66

Managing Cloud Cells 67

Managing vSphere Resources 69

Managing vSphere vCenter Servers 69

Managing vSphere ESX/ESXi Hosts 71

VMware, Inc. 3

vCloud Director Administrator's Guide

Managing vSphere Datastores 72

Managing Stranded Items

Managing Organizations 75

Enable or Disable an Organization 75

Delete an Organization 75

Modify an Organization Name 76

Modify an Organization Full Name and Description 76

Modify Organization LDAP Options 76

Modify Organization Catalog Publishing Policy 77

Modify Organization Email Preferences 78

Modify Organization Lease, Quota, and Limit Settings 78

Add a Catalog to an Organization 79

Managing Organization Resources 79

Managing Organization Users and Groups 80

Managing Organization vApps and Virtual Machines 80

Managing System Administrators and Roles 83

Add a System Administrator 83

Import a System Administrator 84

Enable or Disable a System Administrator 84

Delete a System Administrator 84

Edit System Administrator Profile and Contact Information 84

Send an Email Notification to Users 85

Delete a System Administrator Who Lost Access to the System 85

Import an LDAP Group 85

Delete an LDAP Group 86

Change an LDAP Group Description 86

Roles and Rights 86

Create a Role 86

Copy a Role 87

Edit a Role 87

Delete a Role 87

Managing System Settings 89

Modify General System Settings 89

General System Settings 90

Configure SMTP Settings 91

Configure System Notification Settings 91

Configuring Blocking Tasks and Notifications 92

Configuring the System LDAP Settings 93

Customize the vCloud Director Client UI 96

Configure the Public Web URL 97

Configure the Public Console Proxy Address 98

Configure the Public REST API Base URL 98

Configure the Account Lockout Policy 98

4 VMware, Inc.

Monitoring vCloud Director 101

Viewing Tasks and Events 101

Monitor and Manage Blocking Tasks

View Usage Information for a Provider vDC 103

View Usage Information for an Organization vDC 103

Using vCloud Director's JMX Service 104

Viewing the vCloud Director Logs 104

vCloud Director and Cost Reporting 104

Monitoring Quarantined Files 105

Contents

103

Roles and Rights 107

Predefined Roles and Their Rights 107

Index 111

VMware, Inc. 5

vCloud Director Administrator's Guide

6 VMware, Inc.

vCloud Director Administrator's Guide

The VMware vCloud Director Administrator's Guide provides information to the vCloud Director system administrator and organizations, and monitor the system.

Intended Audience

This book is intended for anyone who wants to configure and manage a vCloud Director installation. The information in this book is written for experienced system administrators who are familiar with Linux, Windows, IP networks, and VMware vSphere.

about how to add resources to the system, create and provision organizations, manage resources

VMware, Inc. 7

vCloud Director Administrator's Guide

8 VMware, Inc.

Getting Started with vCloud Director 1

The first time you log in to the vCloud Director Web console, the Home tab guides you through the steps to configure your installation.

You can also set your user preferences and create a Microsoft Sysprep deployment package to support guest customization in vCloud Director virtual machines.

This chapter includes the following topics:

“Overview of vCloud Director Administration,” on page 9

“Log In to the Web Console,” on page 11

“Preparing the System,” on page 12

“Create a Microsoft Sysprep Deployment Package,” on page 12

“Replace a Microsoft Sysprep Deployment Package,” on page 13

“Set User Preferences,” on page 14

“Change a System Administrator Password,” on page 14

Overview of vCloud Director Administration

VMware vCloud Director is a software product that provides the ability to build secure, multi-tenant clouds by

pooling virtual infrastructure resources into virtual datacenters and exposing them to users through Web-

based portals and programmatic interfaces as a fully-automated, catalog-based service.

The VMware vCloud Director Administrator's Guide provides information about adding resources to the system, creating and provisioning organizations, managing resources and organizations, and monitoring the system.

vSphere Resources

vCloud Director relies on vSphere resources to provide CPU and memory to run virtual machines. In addition, vSphere datastores provide storage for virtual machine files and other files necessary for virtual machine operations. vCloud Director also utilizes vSphere distributed switches and vSphere port groups to support virtual machine networking.

You can use these underlying vSphere resources to create cloud resources.

Cloud Resources

Cloud resources are an abstraction of their underlying vSphere resources. They provide the compute and memory resources for vCloud Director virtual machines and vApps. A vApp is a virtual system that contains one or more individual virtual machines, along with parameters that define operational details. Cloud resources also provide access to storage and network connectivity.

VMware, Inc. 9

vCloud Director Administrator's Guide

Cloud resources include provider and organization virtual datacenters, external networks, organization networks, resources.

and network pools. Before you can add cloud resources to vCloud Director, you must add vSphere

Provider Virtual Datacenters

A provider virtual datacenter (vDC) combines the compute and memory resources of a single vCenter Server resource pool with the storage resources of one or more datastores available to that resource pool.

You can create multiple provider vDCs for users in different geographic locations or business units, or for users with different performance requirements.

Organization Virtual Datacenters

An organization virtual datacenter (vDC) provides resources to an organization and is partitioned from a provider vDC. Organization vDCs provide an environment where virtual systems can be stored, deployed, and operated. They also provide storage for virtual media, such as floppy disks and CD ROMs.

A single organization can have multiple organization vDCs.

vCloud Director Networking

vCloud Director supports three types of networks.

External networks

Organization networks

vApp networks

Some organization networks and all vApp networks are backed by network pools.

External Networks

An external network is a logical, differentiated network based on a vSphere port group. Organization networks can connect to external networks to provide Internet connectivity to virtual machines inside of a vApp.

Only system administrators create and manage external networks.

Organization Networks

An organization network is contained within a vCloud Director organization and is available to all the vApps in the organization. An organization network allows vApps within an organization to communicate with each other. You can connect an organization network to an external network to provide external connectivity. You can also create an isolated organization network that is internal to the organization. Certain types of organization networks are backed by network pools.

Only system administrators can create organization networks. System administrators and organization administrators can manage organization networks, although there are some limits to what an organization administrator can do.

vApp Networks

A vApp network is contained within a vApp and allows virtual machines in the vApp to communicate with each other. You can connect a vApp network to an organization network to allow the vApp to communicate with other vApps in the organization and outside of the organization, if the organization network is connected to an external network. vApp networks are backed by network pools.

Most users with access to a vApp can create and manage their own vApp networks. Working with vApp networks is described in the VMware vCloud Director User's Guide.

10 VMware, Inc.

Chapter 1 Getting Started with vCloud Director

Network Pools

A network pool is a group of undifferentiated networks that is available for use within an organization vDC. A network pool is backed by vSphere network resources such as VLAN IDs, port groups, or Cloud isolated networks. all vApp networks. Network traffic on each network in a pool is isolated at layer 2 from all other networks.

Each organization vDC in vCloud Director can have one network pool. Multiple organization vDCs can share the same network pool. The network pool for an organization vDC provides the networks created to satisfy the network quota for an organization vDC.

Only system administrators can create and manage network pools.

vCloud Director uses network pools to create NAT-routed and internal organization networks and

Organizations

vCloud Director supports multi-tenancy through the use of organizations. An organization is a unit of administration for a collection of users, groups, and computing resources. Users authenticate at the organization level, supplying credentials established by an organization administrator when the user was created or imported. System administrators create and provision organizations, while organization administrators manage organization users, groups, and catalogs. Organization administrator tasks are described in the VMware vCloud Director User's Guide.

Users and Groups

An organization can contain an arbitrary number of users and groups. Users can be created by the organization administrator or imported from a directory service such as LDAP. Groups must be imported from the directory service. Permissions within an organization are controlled through the assignment of rights and roles to users and groups.

Catalogs

Organizations use catalogs to store vApp templates and media files. The members of an organization that have access to a catalog can use the catalog's vApp templates and media files to create their own vApps. A system administrator can allow an organization to publish a catalog to make it available to other organizations. Organizations administrators can then choose which catalog items to provide to their users.

Log In to the Web Console

You can access the vCloud Director user interface by using a Web browser.

For a list of supported browsers, see the VMware vCloud Director Installation and Configuration Guide.

Prerequisites

You must have the system administrator user name and password that you created during the system setup.

Procedure

1 Open a Web browser and navigate to https://

hostname.domain.tld

/cloud.

For hostname.domain.tld, provide the fully qualified domain name associated with the primary IP address of the vCloud Director server host. For example, https://cloud.example.com/cloud.

2 Type the system administrator user name and password and click Login.

vCloud Director displays a list of the next tasks you should perform.

VMware, Inc. 11

vCloud Director Administrator's Guide

Preparing the System

The Home

tab in the vCloud Director Web console provides links to the tasks required to prepare the system

for use. Links become active after you complete prerequisite tasks.

For more information about each task, see Table 1-1.

Table 1-1. Quick Start Tasks

Task For More Information

Attach a vCenter “Attach a vCenter Server,” on page 15

Create a Provider Virtual Datacenter “Create a Provider Virtual Datacenter,” on page 17

Create an External Network “Add an External Network,” on page 18

Create a Network Pool “Network Pools,” on page 19

Create an Organization “Create an Organization,” on page 24

Allocate Resources to an Organization “Create an Organization vDC,” on page 43

Add a Network to an Organization “Creating Organization Networks,” on page 50

Add a Catalog to an Organization “Add a Catalog to an Organization,” on page 79

Create a Microsoft Sysprep Deployment Package

Before vCloud Director can perform guest customization on virtual machines with certain Windows guest operating systems, you must create a Microsoft Sysprep deployment package on each cloud cell in your installation.

During

installation, vCloud Director places some files in the sysprep folder on the vCloud Director server host.

Do not overwrite these files when you create the Sysprep package.

Prerequisites

Access to the Sysprep binary files for Windows 2000, Windows 2003 (32- and 64-bit), and Windows XP (32and 64-bit).

Procedure

1 Copy the Sysprep binary files for each operating system to a convenient location on a vCloud Director

server host.

Each operating system requires its own folder.

NOTE Folder names are case-sensitive.

Guest OS Copy Destination

Windows 2000 SysprepBinariesDirectory /win2000

Windows 2003 (32-bit) SysprepBinariesDirectory /win2k3

Windows 2003 (64-bit) SysprepBinariesDirectory /win2k3_64

Windows XP (32-bit) SysprepBinariesDirectory /winxp

Windows XP (64-bit) SysprepBinariesDirectory /winxp_64

SysprepBinariesDirectory represents a location you choose to which to copy the binaries.

12 VMware, Inc.

Chapter 1 Getting Started with vCloud Director

2 Run the /opt/vmware/cloud-director/deploymentPackageCreator/createSysprepPackage.sh

SysprepBinariesDirectory command.

For example, /opt/vmware/cloud-

director/deploymentPackageCreator/createSysprepPackage.sh /root/MySysprepFiles.

Use the service vmware-vcd restart command to restart the cloud cell.

4 If you have multiple cloud cells, copy the package and properties file to all cloud cells.

scp /opt/vmware/cloud-director/guestcustomization/vcloud_sysprep.properties /opt/vmware/cloud-director/guestcustomization/windows_deployment_package_sysprep.cab

next_cell_IP

root@

:/opt/vmware/cloud-director/guestcustomization

5 Restart each cloud cell to which you copy the files.

Replace a Microsoft Sysprep Deployment Package

If you already created a Microsoft Sysprep deployment package and you need to generate a new one, you must replace the existing Sysprep package on each cloud cell in your installation.

Prerequisites

Access to the Sysprep binary files for Windows 2000, Windows 2003 (32- and 64-bit), and Windows XP (32and 64-bit).

Procedure

1 Use the service vmware-vcd stop command to stop the first cloud cell.

2 Copy the new Sysprep binary files for each operating system to a convenient location on a vCloud Director

server host.

Each operating system requires its own folder.

NOTE Folder names are case-sensitive.

Guest OS Copy Destination

Windows 2000 SysprepBinariesDirectory /win2000

Windows 2003 (32-bit) SysprepBinariesDirectory /win2k3

Windows 2003 (64-bit) SysprepBinariesDirectory /win2k3_64

Windows XP (32-bit) SysprepBinariesDirectory /winxp

Windows XP (64-bit) SysprepBinariesDirectory /winxp_64

SysprepBinariesDirectory represents a location you choose to which to copy the binaries.

3 Run the /opt/vmware/cloud-director/deploymentPackageCreator/createSysprepPackage.sh

SysprepBinariesDirectory command.

For example, /opt/vmware/cloud-

director/deploymentPackageCreator/createSysprepPackage.sh /root/MySysprepFiles.

4 Use the service vmware-vcd restart command to restart the cloud cell.

5 If you have multiple cloud cells, stop each cell and copy the package and properties file to each cell.

scp /opt/vmware/cloud-director/guestcustomization/vcloud_sysprep.properties /opt/vmware/cloud-director/guestcustomization/windows_deployment_package_sysprep.cab root@

next_cell_IP

:/opt/vmware/cloud-director/guestcustomization

6 Restart each cloud cell to which you copy the files.

VMware, Inc. 13

vCloud Director Administrator's Guide

Set User Preferences

You can set certain display and system alerts preferences that take effect every time you log in to the system.

Procedure

In the title bar of the Web console, click Preferences.

2 Click the Defaults tab.

3 Select the page to display when you log in.

4 Select the number of days or hours before a runtime lease expires that you want to receive an email

notification.

5 Select the number of days or hours before a storage lease expires that you want to receive an email

notification.

6 Click OK.

Change a System Administrator Password

You can change the password for your system administrator account.

You can change the password of local (non-LDAP) users only.

Procedure

1 Click Preferences in the title bar of the Web console.

2 Click the Change Password tab.

3 Type your current password and then type your new password twice and click OK.

14 VMware, Inc.

Adding Resources to vCloud Director 2

vCloud Director derives its resources from an underlying vSphere virtual infrastructure. After you register vSphere resources in vCloud Director, you can allocate these resources for organizations within the vCloud Director installation to use.

This chapter includes the following topics:

“Adding vSphere Resources,” on page 15

“Adding Cloud Resources,” on page 17

Adding vSphere Resources

vCloud vSphere datastores provide storage for virtual machine files and other files necessary for virtual machine operations.

For information about vCloud Director system requirements and supported versions of vCenter Server and ESX/ESXi see the VMware vCloud Director Installation and Configuration Guide.

Director relies on vSphere resources to provide CPU and memory to run virtual machines. In addition,

Attach a vCenter Server

Attach a vCenter Server to make its resources available for use with vCloud Director. After you attach a vCenter Server, you can assign its resource pools, datastores, and networks to a provider virtual datacenter.

Prerequisites

An instance of vShield Manager is installed and configured for vCloud Director. For more information, see the VMware vCloud Director Installation and Configuration Guide.

Procedure

1 Open the Attach New vCenter Wizard on page 16

Open the Attach New vCenter wizard to start the process of attaching a vCenter Server to vCloud Director.

2 Provide vCenter Server Connection and Display Information on page 16

To attach a vCenter Server to vCloud Director, you must provide connection information and a display name for the vCenter Server.

3 Connect to vShield Manager on page 16

vCloud Director requires vShield Manager to provide network services. Each vCenter Server you attach to vCloud Director requires its own vShield Manager.

4 Confirm Settings and Attach the vCenter Server on page 16

Before you attach the new vCenter Server, review the settings you entered.

VMware, Inc. 15

vCloud Director Administrator's Guide

Open the Attach New vCenter Wizard

Open the Attach New vCenter wizard to start the process of attaching a vCenter Server to vCloud Director.

Procedure

Click the Manage & Monitor tab and then click vCenters in the left pane.

2 Click the Attach New vCenter button.

The Attach New vCenter wizard launches.

Provide vCenter Server Connection and Display Information

To attach a vCenter Server to vCloud Director, you must provide connection information and a display name for the vCenter Server.

Procedure

1 Type the host name or IP address of the vCenter Server.

2 Select the port number that vCenter Server uses.

The default port number is 443.

3 Type the user name and password of a vCenter Server administrator.

The user account must have the Administrator role in vCenter.

4 Type a name for the vCenter Server.

The name you type becomes the display name for the vCenter Server in vCloud Director.

5 (Optional) Type a description for the vCenter Server.

6 Click Next to save your choices and go to the next page.

Connect to vShield Manager

vCloud Director requires vShield Manager to provide network services. Each vCenter Server you attach to vCloud Director requires its own vShield Manager.

Procedure

1 Type the host name or IP address of the vShield Manager to use with the vCenter Server that you are

attaching.

2 Type the user name and password to connect to vShield Manager.

The default user name is admin and the default password is default. You can change these defaults in the vShield Manager user interface.

3 Click Next to save your choices and go to the next page.

Confirm Settings and Attach the vCenter Server

Before you attach the new vCenter Server, review the settings you entered.

Procedure

1 Review the settings for the vCenter Server and vShield Manager.

2 (Optional) Click Back to modify the settings.

3 Click Finish to accept the settings and attach the vCenter Server.

16 VMware, Inc.

Chapter 2 Adding Resources to vCloud Director

vCloud Director attaches the new vCenter Server and registers its resources for provider virtual datacenters to use.

What to do next

Assign a vShield for VMware vCloud Director license key in the vCenter Server.

Assign a vShield License Key in vCenter

After

you attach a vCenter Server to vCloud Director, you must use the vSphere Client to assign a vShield for

VMware vCloud Director license key.

Prerequisites

The vSphere Client must be connected to the vCenter Server system.

Procedure

1 From a vSphere Client host that is connected to the vCenter Server system, select Home > Licensing.

2 For the report view, select Asset.

3 Right-click the vShield-edge asset and select Change license key.

4 Select Assign a new license key and click Enter Key.

5 Enter the license key, enter an optional label for the key, and click OK.

Use the vShield for VMware vCloud Director license key you received when you purchased vCloud Director. You can use this license key in multiple vCenter Servers.

6 Click OK.

Adding Cloud Resources

Cloud resources are an abstraction of their underlying vSphere resources and provide the compute and memory resources for vCloud Director virtual machines and vApps, and access to storage and network connectivity.

Cloud resources include provider and organization virtual datacenters, external networks, organization networks, and network pools. Before you can add cloud resources to vCloud Director, you must add vSphere resources.

For more information about organization virtual datacenters, see “Allocate Resources to an Organization,” on page 28.

For more information about organization networks, see “Adding Networks to an Organization,” on page 32.

Provider Virtual Datacenters

A provider virtual datacenter (vDC) combines the compute and memory resources of a single vCenter Server resource pool with the storage resources of one or more datastores connected to that resource pool.

A provider vDC is the source for organization vDCs.

Create a Provider Virtual Datacenter

You can create a provider vDC to register vSphere compute, memory, and storage resources for vCloud Director to use. You can create multiple provider vDCs for users in different geographic locations or business units, or for users with different performance requirements.

A provider vDC can only include a single resource pool from a single vCenter Server.

VMware, Inc. 17

vCloud Director Administrator's Guide

If you plan to add a resource pool that is part of a cluster that uses vSphere HA, make sure you are familiar with

how vSphere HA calculates slot size. For more information about slot sizes and customizing vSphere HA

behavior, see the VMware vSphere Availability Guide.

Prerequisites

Verify that at least one vCenter Server is attached with an available resource pool to vCloud Director. The resource pool must be in a vCenter cluster that is configured to use automated DRS. The vCenter Server must have the vShield for VMware vCloud Director license key.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Click New Provider vDC.

3 Type a name and optional description.

You can use the name and description fields to indicate the vSphere functions available to the provider vDC, for example, vSphere HA.

4 Select the latest supported hardware version and click Next.

This selection determines the latest supported hardware version for virtual machines in organization vDCs based on this provider vDC. Hardware Version 8 requires ESX/ESXi 5.0 hosts. If this provider vDC will use a resource pool that contains ESX/Esxi 5.0 and ESX/ESXi 4.x hosts, select Hardware Version 7.

5 Select a vCenter Server and resource pool and click Next.

If the vCenter Server has no available resource pools, no resource pools appear in the list.

6 Select one or more datastores, click Add, and click Next.

vCloud Director does not support the use of read-only datastores with provider vDCs. In most cases, readonly datastores do not appear in the list, but some read-only NFS datastores might appear. Do not add these datastores to your provider vDC.

Use only shared storage because vSphere DRS cannot migrate virtual machines on local storage.

7 Type the root user name and password for the ESX/ESXi hosts and click Next.

8 Click Finish to create the provider vDC.

External Networks

An external network is a logical, differentiated network based on a vSphere port group. An external network provides the interface to the Internet for virtual machines connected to external organization networks.

For more information about organization networks, see “Understanding Organization Networks,” on page 32.

Add an External Network

Add an external network to register vSphere network resources for vCloud Director to use. You can create organization networks that connect to an external network.

Prerequisites

A vSphere port group is available. If the port group uses VLAN, it can use only a single VLAN. Port groups with VLAN trunking are not supported.

Procedure

1 Click the Manage & Monitor tab and click External Networks in the left pane.

18 VMware, Inc.

Chapter 2 Adding Resources to vCloud Director

2 Click the Add Network button.

Select a vCenter Server and a vSphere port group and click Next.

4 Type the network settings and click Next.

5 Type a name and optional description for the network and click Next.

6 Review the network settings and click Finish.

What to do next

You can now create an organization network that connects to the external network.

Network Pools

A network pool is a group of undifferentiated networks that is available for use within an organization vDC to create vApp networks and certain types of organization networks.

A network pool is backed by vSphere network resources such as VLAN IDs, port groups, or Cloud isolated networks. vCloud Director uses network pools to create NAT-routed and internal organization networks and all vApp networks. Network traffic on each network in a pool is isolated at layer 2 from all other networks.

Add a Network Pool That Is Backed by VLAN IDs

You can add a VLAN-backed network pool to register vSphere VLAN IDs for vCloud Director to use. A VLANbacked network pool provides the best security, scalability, and performance for organization networks.

Prerequisites

Verify that a range of VLAN IDs and a vSphere distributed switch are available in vSphere. The VLAN IDs must be valid IDs that are configured in the physical switch to which the ESX/ESXi servers are connected.

CAUTION The VLANs must be isolated at the layer 2 level. Failure to properly isolate the VLANs can cause a disruption on the network.

Procedure

Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Click Add Network Pool.

3 Select VLAN-backed and click Next.

4 Type a range of VLAN IDs and click Add.

You can create one network for each VLAN ID.

5 Select a vCenter Server and vSphere distributed switch and click Next.

6 Type a name and optional description for the network and click Next.

7 Review the network pool settings and click Finish.

What to do next

You can now create an organization network that is backed by the network pool or associate the network pool with an organization vDC and create vApp networks.

VMware, Inc. 19

vCloud Director Administrator's Guide

Add a Network Pool That Is Backed by Cloud Isolated Networks

You

can create a network pool that is backed by cloud isolated networks. A cloud isolated network spans hosts,

provides traffic isolation from other networks, and is the best source for vApp networks.

An isolation-backed network pool does not require preexisting port groups in vSphere.

Prerequisites

Verify that a vSphere distributed switch is available.

Procedure

1 Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Click Add Network Pool.

3 Select VCD Network Isolation-backed and click Next.

4 Type the number of networks to create from the network pool.

5 (Optional) Type a VLAN ID.

6 Select a vCenter Server and a vSphere distributed switch and click Next.

7 Type a name and optional description for the network and click Next.

8 Review the network pool settings and click Finish.

vCloud Director creates cloud isolated networks in vSphere as they are needed.

What to do next

You can now create an organization network that is backed by the network pool or associate the network pool with an organization vDC and create vApp networks. You can also increase the network pool MTU. See “Set

the MTU for a Network Pool Backed by Cloud Isolated Networks,” on page 21.

Add a Network Pool That Is Backed by vSphere Port Groups

You can add a network pool that is backed by port groups to register vSphere port groups for vCloud Director to use. Unlike other types of network pools, a network pool that is backed by port groups does not require a vSphere distributed switch.

CAUTION The port groups must be isolated from all other port groups at the layer 2 level. The port groups must

be physically isolated or must be isolated by using VLAN tags. Failure to properly isolate the port groups

can cause a disruption on the network.

Prerequisites

Verify that one or more port groups are available in vSphere. The port groups must be available on each ESX/ESXi host in the cluster, and each port group must use only a single VLAN. Port groups with VLAN trunking are not supported.

Procedure

Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Click Add Network Pool.

3 Select vSphere Port Group-backed and click Next.

4 Select a vCenter Server and click Next.

20 VMware, Inc.

Chapter 2 Adding Resources to vCloud Director

5 Select one or more port groups, click Add, and click Next.

You can create one network for each port group.

Type a name and optional description for the network and click Next.

7 Review the network pool settings and click Finish.

What to do next

You can now create an organization network that is backed by the network pool or associate the network pool with an organization vDC and create vApp networks.

Set the MTU for a Network Pool Backed by Cloud Isolated Networks

You can specify the maximum transmission units (MTU) that vCloud Director uses for a network pool that is backed by Cloud isolated networks. The MTU is the maximum amount of data that can be transmitted in one packet before it is divided into smaller packets.

When you configure the virtual machine guest operating system and the underlying physical infrastructure with the standard MTU (1500 bytes), the VMware network isolation protocol fragments frames. To avoid frame fragmentation, increase the MTU to at least 1524 bytes for the network pool and the underlying physical network. You can increase the network pool MTU up to, but not greater than, the MTU of the physical network.

If your physical network has an MTU of less than 1500 bytes, decrease the MTU of the network pool to match the underlying physical network.

Prerequisites

Verify that you have a network pool backed by cloud isolated networks. Before you increase the MTU for a network pool, you must ensure that the physical switch infrastructure supports an MTU of greater than 1500, also known as jumbo frames.

Procedure

1 Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Right-click the network pool name and select Properties.

3 On the Network Pool MTU tab, type the MTU and click OK.

vCloud Director modifies the MTU for the network pool and all other network pools that use the same vSphere distributed switch.

VMware, Inc. 21

vCloud Director Administrator's Guide

22 VMware, Inc.

Creating and Provisioning

Organizations 3

Organizations provide resources to a group of users and set policies that determine how users can consume those resources. Create an organization for each group of users that requires its own resources, policies, or both.

This chapter includes the following topics:

“Understanding Leases,” on page 23

“Create an Organization,” on page 24

“Allocate Resources to an Organization,” on page 28

“Adding Networks to an Organization,” on page 32

Understanding Leases

Creating an organization involves specifying leases. Leases provide a level of control over an organization's storage and compute resources by specifying the maximum amount of time that vApps can be running and that vApps and vApp templates can be stored.

The goal of a runtime lease is to prevent inactive vApps from consuming compute resources. For example, if a user starts a vApp and goes on vacation without stopping it, the vApp continues to consume resources.

A runtime lease begins when a user starts a vApp. When a runtime lease expires, vCloud Director stops the vApp.

The

goal of a storage lease is to prevent unused vApps and vApp templates from consuming storage resources. A vApp storage lease begins when a user stops the vApp. Storage leases do not affect running vApps. A vApp template storage lease begins when a user adds the vApp template to a vApp, adds the vApp template to a workspace, downloads, copies, or moves the vApp template.

When a storage lease expires, vCloud Director marks the vApp or vApp template as expired, or deletes the vApp or vApp template, depending on the organization policy you set.

For more information about specifying lease settings, see “Configure Organization Lease, Quota, and Limit

Settings,” on page 27.

Users can configure email notification to receive a message before a runtime or storage lease expires. See “Set

User Preferences,” on page 14 for information about lease expiration preferences.

VMware, Inc. 23

vCloud Director Administrator's Guide

Create an Organization

Creating an organization involves specifying the organization settings and creating a user account for the organization administrator.

Procedure

1 Open the New Organization Wizard on page 24

Open the New Organization wizard to start the process of creating an organization.

2 Name the Organization on page 25

Provide a descriptive name and an optional description for your new organization.

3 Specify the Organization LDAP Options on page 25

can use an LDAP service to provide a directory of users and groups for the organization. If you do

You not specify an LDAP service, you must create a user account for each user in the organization. LDAP options can only be set by a system administrator and cannot be modified by an organization administrator.

4 Add Local Users to the Organization on page 26

Every organization should have at least one local, non-LDAP, organization administrator account, so that users can log in even if the LDAP service is unavailable.

5 Set the Organization Catalog Publishing Policy on page 26

A catalog provides organization users with a library of vApp templates and media that they can use to create vApps and install applications on virtual machines.

6 Configure Email Preferences on page 26

vCloud Director requires an SMTP server to send user notification and system alert emails. An organization can use the system email settings or use its own email settings.

7 Configure Organization Lease, Quota, and Limit Settings on page 27

Leases, quotas, and limits constrain the ability of organization users to consume storage and processing resources. Use these settings to prevent users from depleting or monopolizing an organization's resources.

8 Confirm Settings and Create the Organization on page 27

Before you create the organization, review the settings you entered.

Open the New Organization Wizard

Open the New Organization wizard to start the process of creating an organization.

Procedure

1 Click the Manage & Monitor tab and then click Organizations in the left pane.

2 Click the New Organization button.

The New Organization wizard starts.

24 VMware, Inc.

Chapter 3 Creating and Provisioning Organizations

Name the Organization

Provide a descriptive name and an optional description for your new organization.

Procedure

Type an organization name.

This name provides a unique identifier that appears as part of the URL that members of the organization use to log in to the organization.

2 Type a display name for the organization.

This name appears in the browser header when an organization member uses the unique URL to log in to vCloud Director. An administrator or organization administrator can change this name later.

3 (Optional) Type a description of the organization.

4 Click Next.

Specify the Organization LDAP Options

You can use an LDAP service to provide a directory of users and groups for the organization. If you do not specify an LDAP service, you must create a user account for each user in the organization. LDAP options can only be set by a system administrator and cannot be modified by an organization administrator.

For more information about entering custom LDAP settings, see “Configuring the System LDAP Settings,” on page 93.

Procedure

1 Select the source for organization users.

Option Description

Do not use LDAP

VCD system LDAP service

Custom LDAP service

Organization administrator creates a local user account for each user in the organization. You cannot create groups if you choose this option.

Use the vCloud Director system LDAP service as the source for organization users and groups.

Connect the organization to its own private LDAP service.

Provide any additional information that your selection requires.

Option Action

Do not use LDAP

VCD system LDAP service

Custom LDAP service

Click Next.

(Optional) Type the distinguished name of the organizational unit (OU) to use to limit the users that you can import into the organization and click Next. If you do not enter anything, you can import all users in the system LDAP service into the organization.

NOTE Specifying an OU does not limit the LDAP groups you can import.

can import any LDAP group from the system LDAP root. However, only

You users who are in both the OU and the imported group can log in to the organization.

Click Next and enter the custom LDAP settings for the organization.

VMware, Inc. 25

vCloud Director Administrator's Guide

Add Local Users to the Organization

Every

organization should have at least one local, non-LDAP, organization administrator account, so that users

can log in even if the LDAP service is unavailable.

Procedure

1 Click Add.

2 Type a user name and password.

3 Assign a role to the user.

4 (Optional) Type the contact information for the user.

5 Select Unlimited or type a user quota for stored and running virtual machines and click OK.

These quotas limit the user's ability to consume storage and compute resources in the organization.

6 Click Next.

Set the Organization Catalog Publishing Policy

A catalog provides organization users with a library of vApp templates and media that they can use to create vApps and install applications on virtual machines.

Generally, catalogs should only be available to users in a single organization, but a system administrator can allow the organization administrator to publish their catalogs to all organizations in the vCloud Director installation.

Procedure

1 Select a catalog publishing option.

Option Description

Cannot publish catalogs

Allow publishing catalogs to all organizations

The organization administrator cannot publish catalogs for users outside of the organization.

The organization administrator can publish catalogs for users in all organizations.

Click Next.

Configure Email Preferences

vCloud Director requires an SMTP server to send user notification and system alert emails. An organization can use the system email settings or use its own email settings.

Procedure

1 Select an SMTP server option.

Option Description

Use system default SMTP server

Set organization SMTP server

The organization uses the system SMTP server.

The organization uses its own SMTP server. Type the DNS host name or IP

and port number of the SMTP server. (Optional) Select the Requires

address authentication check box and type a user name and password.

26 VMware, Inc.

Chapter 3 Creating and Provisioning Organizations

2 Select a notification settings option.

Option Description

Use system default notification settings

Set organization notification settings

The organization uses the system notification settings.

The organization uses its own notification settings. Type an email address that appears as the sender for organization emails, type text to use as the subject prefix for organization emails, and select the recipients for organization emails.

(Optional) Type a destination email address and click Test Email Settings to verify that all SMTP server settings are configured as expected.

4 Click Next.

Configure Organization Lease, Quota, and Limit Settings

For more information about leases, see “Understanding Leases,” on page 23.

Procedure

1 Select the lease options for vApps and vApp templates.

Leases provide a level of control over an organization's storage and compute resources by specifying the maximum amount of time that vApps can run and that vApps and vApp templates can be stored. You can also specify what happens to vApps and vApp templates when their storage lease expires.

2 Select the quotas for running and stored virtual machines.

Quotas determine how many virtual machines each user in the organization can store and power on in the organization's virtual datacenters. The quotas that you specify act as the default for all new users added to the organization.

3 Select the limits for resource intensive operations.

Certain vCloud Director operations, for example copy and move, are more resource intensive than others. Limits prevent resource intensive operations from affecting all the users in an organization and also provide a defense against denial-of-service attacks.

4 Select the number of simultaneous VMware Remote Console connections for each virtual machine.

You might want to limit the number of simultaneous connections for performance or security reasons.

NOTE This setting does not affect Virtual Network Computing (VNC) or Remote Desktop Protocol (RDP) connections.

5 (Optional) Select the Account lockout enabled check box, select the number of invalid logins to accept

before locking a user account, and select the lockout interval.

Click Next.

Confirm Settings and Create the Organization

Before you create the organization, review the settings you entered.

Procedure

1 Review the settings for the organization.

2 (Optional) Click Back to modify the settings.

VMware, Inc. 27

vCloud Director Administrator's Guide

3 Click Finish to accept the settings and create the organization.

What to do next

Allocate resources to the organization.

Allocate Resources to an Organization

You

allocate resources to an organization by creating an organization vDC that is partitioned from a provider

vDC. A single organization can have multiple organization vDCs.

Prerequisites

You must have a provider vDC before you can allocate resources to an organization.

Procedure

1 Open the Allocate Resources Wizard on page 28

Open the Allocate Resources wizard to start the process of creating an organization vDC for an organization.

2 Select a Provider vDC on page 29

An organization vDC obtains its compute and storage resources from a provider vDC. The organization vDC provides these resources to vApps and virtual machines in the organization.

3 Select an Allocation Model on page 29

The allocation model determines how and when the provider vDC compute and memory resources that you allocate are committed to the organization vDC.

4 Configure the Allocation Model on page 29

Configure the allocation model to specify the amount of provider vDC resources to allocate to the organization vDC.

5 Allocate Storage on page 30

An organization vDC requires storage space for vApps and vApp templates. You can allocate storage from the space available on provider vDC datastores.

6 Select Network Pool on page 31

A network pool is a group of undifferentiated networks that is used to create vApp networks and NATrouted or internal organization networks.

7 Name the Organization vDC on page 31

You can provide a descriptive name and an optional description to indicate the vSphere functions available for your new organization vDC.

8 Confirm Settings and Create the Organization vDC on page 31

Before you create the organization vDC, review the settings you entered.

What to do next

Add a network to the organization.

Open the Allocate Resources Wizard

Open the Allocate Resources wizard to start the process of creating an organization vDC for an organization.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

28 VMware, Inc.

Chapter 3 Creating and Provisioning Organizations

2 Right-click the organization name and select Allocate Resources from the menu.

The Allocate Resources wizard starts.

Select a Provider vDC

organization vDC obtains its compute and storage resources from a provider vDC. The organization vDC

provides these resources to vApps and virtual machines in the organization.

Procedure

1 Select a provider vDC.

The provider vDC list displays information about available resources and the networks list displays information about networks available to the selected provider vDC.

2 Click Next.

Select an Allocation Model

The allocation model determines how and when the provider vDC compute and memory resources that you allocate are committed to the organization vDC.

Procedure

1 Select an allocation model.

Option Description

Allocation Pool

Pay-As-You-Go

Reservation Pool

Only a percentage of the resources you allocate are committed to the organization vDC. You can specify the percentage, which allows you to overcommit resources.

Resources are only committed when users create vApps in the organization vDC. You can specify a percentage of resources to guarantee, which allows

to overcommit resources. You can make a Pay-As-You-Go organization

you vDC elastic by adding multiple resource pools to its providor vDC.

All of the resources you allocate are immediately committed to the organization vDC. Users in the organization can control overcommitment by specifying reservation, limit, and priority settings for individual virtual machines.

Click Next.

Configure the Allocation Model

Configure the allocation model to specify the amount of provider vDC resources to allocate to the organization vDC.

Procedure

1 Select the allocation model options.

Not all of the models include all of the options.

Option Action

CPU allocation

CPU resources guaranteed

VMware, Inc. 29

Enter the maximum amount of CPU, in GHz, to allocate to virtual machines running in the organization vDC.

Enter the percentage of CPU resources to guarantee to virtual machines running in the organization vDC. You can overcommit resources by guaranteeing less than 100%.

vCloud Director Administrator's Guide

Option Action

Memory allocation

Memory resources guaranteed

vCPU Speed

Maximum number of VMs

Click Next.

Example: Configuring an Allocation Model

When you create an organization vDC, vCloud Director creates a vSphere resource pool based on the allocation model settings you specify. See Table 3-1, Table 3-2, and Table 3-3.

Table 3-1. How Allocation Pool Settings Affect Resource Pool Settings

Allocation Pool Setting

CPU Allocation 25 GHz CPU Limit 25 GHz

CPU % Guarantee 10% CPU Reservation 2.5 GHz

Memory Allocation 50 GB Memory Limit 50 GB

Memory % Guarantee 20% Memory Reservation 10 GB

Enter the maximum amount of memory, in GB, to allocate to virtual machines running in the organization vDC.

Enter the percentage of memory resources to guarantee to virtual machines running in the organization vDC. You can overcommit resources by guaranteeing less than 100%.

Enter the vCPU speed in GHz. Virtual machines running in the organization vDC are assigned this amount of GHz per vCPU.

Enter the maximum number of virtual machines that can be created in the organization vDC.

Allocation Pool Value Resource Pool Setting Resource Pool Value

Table 3-2. How Pay-As-You Go Settings Affect Resource Pool Settings

Pay-As-You-Go Setting

CPU % Guarantee 10% CPU Reservation, CPU Limit 0.00 GHz, Unlimited

Memory % Guarantee 100% Memory Reservation, Memory

Pay-As-You-Go Value Resource Pool Setting Resource Pool Value

0.00 GB, Unlimited

Limit

Resource pools created to support Pay-As-You-Go organization vDCs will always have no reservations or limits.

Pay-As-You-Go settings only affect overcommitment. A 100% guarantee means no overcommitment is

possible. The lower the percentage, the more overcommitment is possible.

Table 3-3. How Reservation Pool Settings Affect Resource Pool Settings

Reservation Pool Setting

CPU Allocation 25 GHz CPU Reservation, CPU Limit 25 GHz, 25 GHz

Memory Allocation 50 GB Memory Reservation, Memory

Reservation Pool Value Resource Pool Setting Resource Pool Value

50 GB, 50 GB

Limit

Allocate Storage

An organization vDC requires storage space for vApps and vApp templates. You can allocate storage from the space available on provider vDC datastores.

Thin provisioning can help avoid over-allocating storage and save storage space. For a virtual machine with a thin virtual disk, ESX/ESXi provisions the entire space required for the disk's current and future activities. ESX/ESXi commits only as much storage space as the disk needs for its initial operations.

30 VMware, Inc.

Chapter 3 Creating and Provisioning Organizations

Fast provisioning saves time by using vSphere linked clones for certain operations. See “Fast Provisioning of

Virtual Machines,” on page 82.

IMPORTANT Fast provisioning requires vCenter Server 5.0 and ESXi 5.0 hosts. If the provider vDC on which the organization vDC is based contains any ESX/ESXi 4.x hosts, you must disable fast provisioning. If the provider 8 hosts, powering on virtual machines may fail. Make sure that datastores are connected to a maximum of 8 hosts.

Procedure

2 (Optional) Select the Enable thin provisioning check box to enable thin provisioning for virtual machines

3 (Optional) Deselect the Enable fast provisioning check box to disable fast provisioning for virtual

4 Click Next.

vDC on which the organization vDC is based contains any VMFS datastores connected to more than

Enter the amount of storage to allocate.

in the organization vDC.

machines in the organization vDC.

Select Network Pool

A network pool is a group of undifferentiated networks that is used to create vApp networks and NAT-routed or internal organization networks.

Procedure

1 Select a network pool or select None.

If you select None, you can add a network pool later.

2 Enter the maximum number of networks that the organization can provision from the network pool.

3 Click Next.

Name the Organization vDC

You can provide a descriptive name and an optional description to indicate the vSphere functions available for your new organization vDC.

Procedure

1 Type a name and optional description.

2 Click Next.

Confirm Settings and Create the Organization vDC

Before you create the organization vDC, review the settings you entered.

Procedure

1 Review the settings for the organization vDC.

2 (Optional) Click Back to modify the settings.

3 Click Finish to accept the settings and create the organization vDC.

When you create an organization vDC, vCloud Director creates a resource pool in vSphere to provide CPU and memory resources.

VMware, Inc. 31

vCloud Director Administrator's Guide

Adding Networks to an Organization

a network to an organization to enable its virtual machines to communicate with each other or to provide

Add access to the Internet. A single organization can have multiple organization networks.

Understanding Organization Networks

An organization network allows virtual machines in the organization to communicate with each other and to access the Internet. Organization networks require an external network, a network pool, or both.

Table 3-4 describes the types of organization network.

Table 3-4. Types of Organization Networks and Their Requirements

Organization Network Type Description Requirements

External organization network - direct connection

External organization network - NAT-routed connection

Internal organization network

Accessible by multiple organizations. Virtual machines belonging see traffic on this network.

This network provides direct layer 2 connectivity to machines outside of the organization. Machines outside of this organization can connect to machines within the organization directly.

Accessible only by this organization. Only virtual machines within this organization can connect to this network.

This network also provides controlled access to an external network. System administrators and organization administrators can configure network address translation (NAT) and firewall settings to make specific virtual machines accessible from the external network.

Accessible only by this organization. Only virtual machines within this organization can connect to and see traffic on this network.

This network provides an organization with an isolated, private network that multiple vApps can connect to. This network provides no connectivity to machines outside this organization. Machines outside of this organization have no connectivity to machines within the organization.

to different organizations can connect to and

External network

External network and network pool

Network pool

Add an External Direct Organization Network

You

can add an external direct organization network that multiple organizations can access. You typically use

the external network to connect to the Internet. The organization connects directly to this network.

Prerequisites

Verify that you have an external network.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Add Networks.

32 VMware, Inc.

3 Select the type of setup and network type and click Next.

You can create an external direct organization network by using either method.

Option Network Type

Typical

Advanced

Select the external network check box and select direct connection from the drop-down menu.

Select External organization network - direct connection.

Select an external network and click Next.

You can deselect the Only use networks accessible by this organization check box to view external networks that are not currently available to the organization through its organization vDCs. When you deselect this check box, you can select an arbitrary network and later create an organization vDC that can access the network.

5 Type a name and optional description and click Next.

6 Review the settings for the organization network.

Click Finish to accept the settings and create the organization network, or click Back to modify the settings.

Add an External NAT-Routed Organization Network

Chapter 3 Creating and Provisioning Organizations

You can add an external NAT-routed organization network that only this organization can access. An external NAT-routed organization network provides NAT connectivity to machines outside this organization, which provides more control of what is accessible.

Prerequisites

Verify that you have an external network and a network pool.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Add Networks.

3 Select the type of setup and network type and click Next.

You can create an external routed organization network using either method.

Option Network Type

Typical

Advanced

Select the external network check box and select Routed connection from the drop-down menu.

Select External organization network - NAT-routed connection.

Select an external network and network pool and click Next.

5 (Optional) Deselect the Only use networks accessible by this organization check box to view external

networks and network pools that are not currently available to the organization through its organization vDCs.

When you deselect this check box, you can select an arbitrary network or network pool and later create an organization vDC that can access it.

6 Use the default network settings or type your own settings and click Next.

7 (Optional) Type an external IP address for the network to use for NAT services, click Add, and click

Next.

This setting is only available in advanced setup. You can add more than one external IP address.

VMware, Inc. 33

vCloud Director Administrator's Guide

8 Type a name and optional description and click Next.

Review the settings for the organization network.

Click Finish to accept the settings and create the organization network, or click Back to modify the settings.

What to do next

If you added external IP addresses, you can set how they are mapped. See “Configure Port Forwarding for an

Organization Network,” on page 56.

Add an Internal Organization Network

You can add an internal organization network to which multiple vApps can connect and that only this organization can access.

Prerequisites

Verify that you have a network pool.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Add Networks.

3 Select the type of setup and network type and click Next.

You can create an internal organization network by using either method.

Option Network Type

Typical

Advanced

Select the internal network check box.

Select Internal organization network.

Select a network pool and click Next.

You can deselect the Only use networks accessible by this organization check box to view network pools that are not currently available to the organization through its organization vDCs. When you deselect this check box, you can select an arbitrary network pool and later create an organization vDC that can access it.

5 Use the default network settings or type your own settings and click Next.

6 Type a name and optional description and click Next.

7 Review the settings for the organization network.

Click Finish to accept the settings and create the organization network, or click Back to modify the settings.

34 VMware, Inc.

Creating a Published Catalog 4

You can publish a catalog to make a set of vApp templates or media files available to all of the organizations in a vCloud Director installation.

Organizations catalog items as the building blocks to create their own vApps.

When you publish a catalog, the items in the catalog become available to all of the organizations in the vCloud Director installation. The administrators of each organization can then choose which catalog items to provide to their users.

Before you can create a published catalog, you must create and provision an organization to contain the catalog.

This chapter includes the following topics:

“Enable Catalog Publishing,” on page 35

“Create a Published Catalog,” on page 36

“Upload a vApp Template,” on page 36

“Import a vApp Template from vSphere,” on page 37

“Upload a Media File,” on page 37

“Import a Media File from vSphere,” on page 38

“Publish a Catalog,” on page 38

use catalogs to store vApp templates and media files. The members of an organization can use

Enable Catalog Publishing

Before you can publish an organization's catalogs, you must enable catalog publishing for the organization.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 On the Catalog Publishing tab, select Allow publishing catalogs to all organizations and click OK.

VMware, Inc. 35

vCloud Director Administrator's Guide

Create a Published Catalog

can create a published catalog to contain uploaded and imported vApp templates and media files to make

You available to all organizations. An organization can have multiple catalogs and control access to each catalog individually.

Prerequisites

Verify that you have an organization that allows catalog publishing.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click Catalogs and select My Organization's Catalogs in the left pane.

4 On the Catalogs tab, click New.

5 Type a catalog name and optional description and click Next.

6 Click Next.

7 Select Publish to all organizations and click Next.

8 Review the catalog settings and click Finish.

Upload a vApp Template

You can upload an OVF package as a vApp template to make the template available to other users. vCloud Director supports OVF 1.0 and OVF 1.1.

vCloud Director supports OVFs based on the Open Virtualization Format (OVF) Specification. If you upload an OVF that includes deployment options, those options are preserved in the vApp template.

You can quarantine files that users upload to vCloud Director so that you can process the files before you accept them. For example, you can scan the files for viruses. See “Quarantine Uploaded Files,” on page 105.

Prerequisites

Verify that the following conditions exist:

The organization to which you are uploading the OVF package has a catalog and an organization vDC.

The computer from which you are uploading has Java Plug-in 1.6.0_10 or later installed.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click Catalogs and select My Organization's Catalogs in the left pane.

4 On the vApp Templates tab, click Upload.

5 Click Browse, browse to the location of the OVF package, select it, and click Open.

6 Type a name and optional description for the vApp template.

7 Select an organization vDC and catalog and click Upload.

What to do next

Make sure that vSphere Tools is installed on the virtual machines in the vApp. vSphere Tools is required to support guest customization. See the VMware vCloud Director User's Guide.

36 VMware, Inc.

Import a vApp Template from vSphere

You can import a virtual machine from vSphere and save it as a vApp template in a catalog that is available to other users.

Prerequisites

Verify that you are a vCloud Director system administrator.

Procedure

Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click Catalogs and select My Organization's Catalogs in the left pane.

4 On the vApp Templates tab, click Import from vSphere.

5 Select a vCenter Server and a virtual machine.

6 Type a name and optional description for the vApp template.

7 Select an organization vDC and catalog.

8 Choose whether to move or copy the virtual machine to the catalog.

Chapter 4 Creating a Published Catalog

9 Choose whether to mark the vApp template as a Gold Master in the catalog.

If you mark a vApp template as a Gold Master, this information appears in the list of vApp templates.

10 Click OK.

What to do next

Check that vSphere Tools is installed on the virtual machines in the vApp. vSphere Tools is required to support guest customization. See the VMware vCloud Director User's Guide.

Upload a Media File

You can upload an ISO or FLP file to make the media available to other users.

You can quarantine files that users upload to vCloud Director so that you can process the files before you accept them. For example, you might want to scan the files for viruses. See “Quarantine Uploaded Files,” on page 105.

Prerequisites

Verify that the computer from which you are uploading has Java Plug-in 1.6.0_10 or later installed.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click Catalogs and select My Organization's Catalogs in the left pane.

4 On the Media tab, click Upload.

5 Click Browse, browse to the location of the media file, select it, and click Open.

6 Type a name and optional description for the media file.

7 Select an organization vDC and catalog and click Upload.

VMware, Inc. 37

vCloud Director Administrator's Guide

Import a Media File from vSphere

You can import a media file from a vSphere datastore and save it in a catalog available to other users.

Prerequisites

must be a vCloud Director system administrator. You must know which datastore contains the media file

You and the path to that file.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click Catalogs and select My Organization's Catalogs in the left pane.

4 On the Media tab, click the Import from vSphere button.

5 Type a name and optional description for the media file.

6 Select the source vCenter Server and datastore and type the path to the media file.

7 Select an organization vDC and catalog.

8 Click OK.

Publish a Catalog

You can publish a catalog to make its vApp templates and media files available to all organizations in the installation.

Prerequisites

Verify that the organization that contains the catalog allows catalog publishing.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click Catalogs and select My Organization's Catalogs in the left pane.

4 On the Catalogs tab, right-click the catalog name and select Publish.

5 On the Publishing tab, select Publish to all organizations and click OK.

The catalog and all of its contents appear under Public Catalogs for all organizations in the vCloud Director installation.

38 VMware, Inc.

Managing Cloud Resources 5

Provider vDCs, organization vDCs, external networks, organization networks, and network pools are all considered information about their relationships with each other.

This chapter includes the following topics:

Managing Provider vDCs

After you create a provider vDC, you can modify its properties, disable or delete it, and manage its ESX/ESXi hosts and datastores.

cloud resources. After you add cloud resources to vCloud Director, you can modify them and view

“Managing Provider vDCs,” on page 39

“Managing Organization vDCs,” on page 43

“Managing External Networks,” on page 49

“Managing Organization Networks,” on page 50

“Managing Network Pools,” on page 66

“Managing Cloud Cells,” on page 67

Enable or Disable a Provider vDC

You can disable a provider vDC to prevent the creation of organization vDCs that use the provider vDC resources.

When you disable a provider vDC, vCloud Director also disables the organization vDCs that use its resources. Running vApps and powered on virtual machines continue to run, but you cannot create or start additional vApps or virtual machines.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Enable or Disable.

Delete a Provider vDC

You can delete a provider vDC to remove its compute, memory, and storage resources from vCloud Director. The resources remain unaffected in vSphere.

Prerequisites

Disable the provider vDC.

VMware, Inc. 39

vCloud Director Administrator's Guide

Disable and delete all organization vDCs and organization networks that use the provider vDC.

Procedure

Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Delete.

3 Click Yes.

Modify a Provider vDC Name and Description

As your vCloud Director installation grows, you might want to assign a more descriptive name or description to an existing provider vDC.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Properties.

3 Type a new name or description and click OK.

You can use the name and description fields to indicate the vSphere functionality available to the provider vDC, for example, vSphere HA.

Enable or Disable a Provider vDC Host

You can disable a host to prevent vApps from starting up on the host. Virtual machines that are already running on the host are not affected.

To perform maintenance on a host, migrate all vApps off of the host or stop all vApps and then disable the host.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

3 Click the Hosts tab.

4 Right-click the host name and select Enable Host or Disable Host.

vCloud Director enables or disables the host for all provider vDCs that use its resources.

Prepare or Unprepare a Provider vDC Host

When you add an ESX/ESXi host to a vSphere cluster that vCloud Director uses, you must prepare the host before a provider vDC can use its resources. You can unprepare a host to remove it from the vCloud Director environment.

For information about moving running virtual machines from one host to another, see “Move Virtual Machines

from one ESX/ESXi Host to Another,” on page 71.

You cannot prepare a host that is in lockdown mode. After you prepare a host, you can enable lockdown mode.

Prerequisites

Before you can unprepare a host, you must disable it and ensure that no virtual machines are running on the host.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

40 VMware, Inc.

Chapter 5 Managing Cloud Resources

2 Right-click the provider vDC name and select Open.

Click the Hosts tab.

4 Right-click the host name and select Prepare Host or Unprepare Host.

vCloud Director prepares or unprepares the host for all provider vDCs that use its resources.

Upgrade an ESX/ESXi Host Agent for a Provider vDC Host

vCloud Director installs agent software on each ESX/ESXi host in the installation. If you upgrade your ESX/ESXi hosts, you also need to upgrade your ESX/ESXi host agents.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

3 Click the Hosts tab.

4 Right-click the host name and select Upgrade Host.

vCloud Director upgrades the host agent. This upgrade affects all provider vDCs that use the host.

Repair a Provider vDC ESX/ESXi Host

If the vCloud Director agent on an ESX/ESXi host cannot be contacted, try to repair the host.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

3 Click the Hosts tab.

4 Right-click the host name and select Repair Host.

vCloud Director repairs the host. This operation affects all provider vDCs that use the host.

Enable or Disable a Provider vDC Datastore

When you disable a datastore, you cannot start vApps associated with the datastore or create vApps on the datastore.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

3 Click the Datastores tab.

4 Right-click the datastore name and select Enable or Disable.

vCloud Director enables or disables the datastore for all provider vDCs that use its resources.

Add Storage Capacity to a Provider vDC

You can add storage capacity to a provider vDC by adding one or more datastores.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

VMware, Inc. 41

vCloud Director Administrator's Guide

3 Click the Datastores tab.

Click Add/Remove.

5 Select a datastore from the list, click Add, and click OK.

Use only shared storage because vSphere DRS cannot migrate virtual machines on local storage.

vCloud Director adds the datastore for the provider vDC to use.

Add a Resource Pool to a Provider vDC

You can add additional resource pools to a provider vDC so that pay-as-you-go organization vDCs that the provider vDC provides can expand.

When compute resources are backed by multiple resource pools, they can expand as needed to accommodate more virtual machines.

Prerequisites

Verify that There is one or more available resource pool exists in the same vCenter datacenter as the provider vDC's primary resource pool.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

3 Click the Resource Pools tab.

4 Click Add Resource Pool.

5 Select the resource pool to add and click Finish.

vCloud Director adds a resource pool for the provider vDC to use, making all pay-as-you-go organization vDCs backed by the provider vDC elastic.

Configure Low Disk Space Warnings for a Provider vDC Datastore

You can configure low disk space warnings on a datastore to receive an email from vCloud Director when the datastore reaches a specific threshold of available capacity. These warnings alert you to a low disk situation before it becomes a problem.

Procedure

1 Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Open.

3 Click the Datastores tab.

4 Right-click the datastore name and select Properties.

5 Select the disk space thresholds for the datastore.

You can set two thresholds, yellow and red. When vCloud Director sends an email alert, the message indicates which threshold was crossed.

6 Click OK.

vCloud Director sets the thresholds for all provider vDCs that use the datastore. vCloud Director sends an email alert when the datastore crosses the threshold.

42 VMware, Inc.

Send an Email Notification to Provider vDC Users

You can send an email notification to all users who own objects in the provider vDC, for example, vApps or media files. You can send an email notification to let users know about upcoming system maintenance, for example.

Prerequisites

Verify that you have a valid connection to an SMTP server.

Procedure

Click the Manage & Monitor tab and click Provider vDCs in the left pane.

2 Right-click the provider vDC name and select Notify.

3 Type the email subject and message and click Send Email.

Managing Organization vDCs

After you create an organization vDC, you can modify its properties, disable or delete it, and manage its allocation model, storage, and network settings.

Chapter 5 Managing Cloud Resources

Create an Organization vDC

Create an organization vDC to allocate resources to an organization. An organization vDC is partitioned from a provider vDC. A single organization can have multiple organization vDCs.

Prerequisites

You must have a provider vDC before you can allocate resources to an organization.

Procedure

1 Open the New Organization vDC Wizard on page 44

Open the New Organization vDC wizard to start the process of creating an organization vDC.

2 Select an Organization for the Organization vDC on page 44

You can create an organization vDC to provide resources to any organization in the vCloud Director system. An organization can have more than one organization vDC.

3 Select a Provider vDC on page 44

An organization vDC obtains its compute and storage resources from a provider vDC. The organization vDC provides these resources to vApps and virtual machines in the organization.

4 Select an Allocation Model on page 45

The allocation model determines how and when the provider vDC compute and memory resources that you allocate are committed to the organization vDC.

5 Configure the Allocation Model on page 45

Configure the allocation model to specify the amount of provider vDC resources to allocate to the organization vDC.

6 Allocate Storage on page 46

An organization vDC requires storage space for vApps and vApp templates. You can allocate storage from the space available on provider vDC datastores.

7 Select Network Pool on page 47

A network pool is a group of undifferentiated networks that is used to create vApp networks and NATrouted or internal organization networks.

VMware, Inc. 43

vCloud Director Administrator's Guide

8 Name the Organization vDC on page 47

You can provide a descriptive name and an optional description to indicate the vSphere functions available for your new organization vDC.

9 Confirm Settings and Create the Organization vDC on page 47

Before you create the organization vDC, review the settings you entered.

Open the New Organization vDC Wizard

Open the New Organization vDC wizard to start the process of creating an organization vDC.

Procedure

Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Click the New vDC button.

Select an Organization for the Organization vDC

You can create an organization vDC to provide resources to any organization in the vCloud Director system. An organization can have more than one organization vDC.

Procedure

1 Select an organization.

2 Click Next.

Select a Provider vDC

An organization vDC obtains its compute and storage resources from a provider vDC. The organization vDC provides these resources to vApps and virtual machines in the organization.

Procedure

1 Select a provider vDC.

The provider vDC list displays information about available resources and the networks list displays information about networks available to the selected provider vDC.

2 Click Next.

44 VMware, Inc.

Chapter 5 Managing Cloud Resources

Select an Allocation Model

The allocation model determines how and when the provider vDC compute and memory resources that you allocate are committed to the organization vDC.

Procedure

Select an allocation model.

Option Description

Allocation Pool

Pay-As-You-Go

Reservation Pool

Click Next.

Only a percentage of the resources you allocate are committed to the organization vDC. You can specify the percentage, which allows you to overcommit resources.

Resources are only committed when users create vApps in the organization vDC. You can specify a percentage of resources to guarantee, which allows

to overcommit resources. You can make a Pay-As-You-Go organization

you vDC elastic by adding multiple resource pools to its providor vDC.

Configure the Allocation Model

Configure the allocation model to specify the amount of provider vDC resources to allocate to the organization vDC.

Procedure

1 Select the allocation model options.

Not all of the models include all of the options.

Option Action

CPU allocation

CPU resources guaranteed

Memory allocation

Memory resources guaranteed

vCPU Speed

Maximum number of VMs

Click Next.

Enter the maximum amount of CPU, in GHz, to allocate to virtual machines running in the organization vDC.

Enter the percentage of CPU resources to guarantee to virtual machines running in the organization vDC. You can overcommit resources by guaranteeing less than 100%.

Enter the maximum amount of memory, in GB, to allocate to virtual machines running in the organization vDC.

Enter the percentage of memory resources to guarantee to virtual machines running in the organization vDC. You can overcommit resources by guaranteeing less than 100%.

Enter the vCPU speed in GHz. Virtual machines running in the organization vDC are assigned this amount of GHz per vCPU.

Enter the maximum number of virtual machines that can be created in the organization vDC.

Example: Configuring an Allocation Model

When you create an organization vDC, vCloud Director creates a vSphere resource pool based on the allocation model settings you specify. See Table 5-1, Table 5-2, and Table 5-3.

VMware, Inc. 45

vCloud Director Administrator's Guide

Table 5-1. How Allocation Pool Settings Affect Resource Pool Settings

Allocation Pool Setting

CPU Allocation 25 GHz CPU Limit 25 GHz

CPU % Guarantee 10% CPU Reservation 2.5 GHz

Memory Allocation 50 GB Memory Limit 50 GB

Memory % Guarantee 20% Memory Reservation 10 GB

Table 5-2. How Pay-As-You Go Settings Affect Resource Pool Settings

Pay-As-You-Go Setting

CPU % Guarantee 10% CPU Reservation, CPU Limit 0.00 GHz, Unlimited

Memory % Guarantee 100% Memory Reservation, Memory

Resource pools created to support Pay-As-You-Go organization vDCs will always have no reservations or limits.

Pay-As-You-Go settings only affect overcommitment. A 100% guarantee means no overcommitment is

possible. The lower the percentage, the more overcommitment is possible.

Allocation Pool Value Resource Pool Setting Resource Pool Value

Pay-As-You-Go Value Resource Pool Setting Resource Pool Value

0.00 GB, Unlimited

Limit

Table 5-3. How Reservation Pool Settings Affect Resource Pool Settings

Reservation Pool Setting

CPU Allocation 25 GHz CPU Reservation, CPU Limit 25 GHz, 25 GHz

Memory Allocation 50 GB Memory Reservation, Memory

Reservation Pool Value Resource Pool Setting Resource Pool Value

50 GB, 50 GB

Limit

Allocate Storage

An organization vDC requires storage space for vApps and vApp templates. You can allocate storage from the space available on provider vDC datastores.

Fast provisioning saves time by using vSphere linked clones for certain operations. See “Fast Provisioning of

Virtual Machines,” on page 82.

vDC on which the organization vDC is based contains any VMFS datastores connected to more than

Procedure

Enter the amount of storage to allocate.

2 (Optional) Select the Enable thin provisioning check box to enable thin provisioning for virtual machines

in the organization vDC.

3 (Optional) Deselect the Enable fast provisioning check box to disable fast provisioning for virtual

machines in the organization vDC.

4 Click Next.

46 VMware, Inc.

Chapter 5 Managing Cloud Resources

Select Network Pool

network pool is a group of undifferentiated networks that is used to create vApp networks and NAT-routed

or internal organization networks.

Procedure

1 Select a network pool or select None.

If you select None, you can add a network pool later.

2 Enter the maximum number of networks that the organization can provision from the network pool.

3 Click Next.

Name the Organization vDC

You can provide a descriptive name and an optional description to indicate the vSphere functions available for your new organization vDC.

Procedure

1 Type a name and optional description.

2 Click Next.

Confirm Settings and Create the Organization vDC

Before you create the organization vDC, review the settings you entered.

Procedure

1 Review the settings for the organization vDC.

2 (Optional) Click Back to modify the settings.

3 Click Finish to accept the settings and create the organization vDC.

When you create an organization vDC, vCloud Director creates a resource pool in vSphere to provide CPU and memory resources.

Enable or Disable an Organization vDC

You can disable an organization vDC to prevent the use of its compute and storage resources by other vApps and virtual machines. Running vApps and powered on virtual machines continue to run, but you cannot create or start additional vApps or virtual machines.

Procedure

1 Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Right-click the organization vDC name and select Enable or Disable.

Delete an Organization vDC

You can delete an organization vDC to remove its compute, memory, and storage resources from the organization. The resources remain unaffected in the source provider vDC.

Prerequisites

Disable the organization vDC and move or delete all of its vApps, vApp templates, and media.

VMware, Inc. 47

vCloud Director Administrator's Guide

Procedure

Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Right-click the organization vDC name and select Delete.

3 Click Yes.

Modify an Organization vDC Name and Description

As your vCloud Director installation grows, you might want to assign a more meaningful name or description to an existing organization vDC.

Procedure

1 Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Right-click the organization vDC name and select Properties.

3 On the General tab, type a new name and description and click OK.

You can use the name and description fields to indicate the vSphere functions available to the organization vDC, for example, vSphere HA.

Edit Organization vDC Allocation Model Settings

You cannot change the allocation model for an organization vDC, but you can change some of the settings of the allocation model that you specified when you created the organization vDC.

Procedure

1 Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Right-click the organization vDC name and select Properties.

3 On the Allocation tab, enter the new allocation model settings and click OK.

These settings only affect vApps that you start from this point on. vApps that are already running are not affected. The usage information that vCloud Director reports for this organization vDC will not reflect the new settings until all running vApps are stopped and started again.

Edit Organization vDC Storage Settings

After you create and use an organization vDC, you might decide to provide it with more storage resources from its source provider vDC. You can also enable or disable thin provisioning and fast provisioning for the organization vDC.

For information on fast provisioning, see “Fast Provisioning of Virtual Machines,” on page 82.

Procedure

1 Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Right-click the organization vDC name and select Properties.

3 On the Storage tab, enter the new storage settings and click OK.

IMPORTANT Fast provisioning requires vCenter Server 5.0 and ESXi 5.0 hosts. If the provider vDC on which the organization vDC is based contains and ESX/ESXi 4.x hosts, you must disable fast provisioning.

48 VMware, Inc.

Edit Organization vDC Network Settings

You

can change the maximum number of provisioned networks in an organization vDC and the network pool

from which the networks are provisioned.

Procedure

1 Click the Manage & Monitor tab and click Organization vDCs in the left pane.

2 Right-click the organization vDC name and select Properties.

3 On the Network Pool tab, enter the new network settings and click OK.

Managing External Networks

After you create an external network, you can modify its name, description, and network specification, add IP addresses to its IP address pool, or delete the network.

Modify an External Network Name and Description

As your vCloud Director installation grows, you might want to assign a more descriptive name or description to an existing external network.

Chapter 5 Managing Cloud Resources

Procedure

1 Click the Manage & Monitor tab and click External Networks in the left pane.

2 Right-click the external network name and select Properties.

3 On the Name and Description tab, type a new name and description and click OK.

Modify an External Network Specification

If the network specification for an external network changes, you can modify its network settings.

Procedure

1 Click the Manage & Monitor tab and click External Networks in the left pane.

2 Right-click the external network name and select Properties.

3 On the Network Specification tab, modify the network settings and click OK.

You cannot modify the network mask or default gateway. If you need an external network with a different netmask or gateway, create one.

Add IP Addresses to an External Network IP Pool

If an external network is running out of IP addresses, you can add more addresses to its IP Pool.

Procedure

1 Click the Manage & Monitor tab and click External Networks in the left pane.

2 Right-click the external network name and select Properties.

3 On the Network Specification tab, type an IP address or a range of IP addresses in the text box and click

Add.

4 Click OK.

VMware, Inc. 49

vCloud Director Administrator's Guide

Delete an External Network

Delete an external network to remove it from vCloud Director.

Prerequisites

Before you can delete an external network, you must delete all of the organization networks that rely on it.

Procedure

Click the Manage & Monitor tab and click External Networks in the left pane.

2 Right-click the external network name and select Delete Network.

Managing Organization Networks

Only a system administrator can add, reset, and delete an organization network.

System administrators and organization administrators can modify organization network properties, configure organization network services, and view IP address allocations.

Creating Organization Networks

Add a network to an organization to enable its virtual machines to communicate with each other or to provide access to the Internet. A single organization can have multiple organization networks.

Table 5-4 describes the types of organization network.

Table 5-4. Types of Organization Networks and Their Requirements

Organization Network Type Description Requirements

External organization network - direct connection

External organization network - NAT-routed connection

Internal organization network

Accessible by multiple organizations. Virtual machines belonging see traffic on this network.

This network provides direct layer 2 connectivity to machines outside of the organization. Machines outside of this organization can connect to machines within the organization directly.

Accessible only by this organization. Only virtual machines within this organization can connect to this network.

Accessible only by this organization. Only virtual machines within this organization can connect to and see traffic on this network.

to different organizations can connect to and

External network

External network and network pool

Network pool

50 VMware, Inc.

Chapter 5 Managing Cloud Resources

Create an External Direct Organization Network

You can create an external direct organization network that multiple organizations can access. You typically use the external network to connect to the Internet. The organization connects directly to this network.

Prerequisites

An external network.

Procedure

Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Click Add Network.

The Create Organization Network wizard starts.

3 Select an organization and click Next.

4 Select the type of setup and network type and click Next.

You can create an external direct organization network using either method.

Option Network Type

Typical

Advanced

Select an external network and click Next.

Select the external network check box and select direct connection from the drop-down menu.

Select External organization network - direct connection.

You can deselect the Only use networks accessible by this organization check box to view external networks that are not currently available to the organization through its organization vDCs. When you deselect this check box, you can choose an arbitrary network and later create an organization vDC that can access the network.

6 Type a name and optional description and click Next.

7 Review the settings for the organization network.

Click Finish to accept the settings and create the organization network, or click Back to modify the settings.

Create an External NAT-Routed Organization Network

You can create an external NAT-routed organization network that only this organization can access. An external NAT-routed organization network provides NAT connectivity to machines outside this organization for better control on what is accessible.

Prerequisites

Verify that your organization has an external network and a network pool.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Click Add Network.

The Create Organization Network wizard starts.

3 Select an organization and click Next.

VMware, Inc. 51

vCloud Director Administrator's Guide

4 Select the type of setup and network type and click Next.

You can create an external routed organization network using either method.

Option Network Type

Typical

Advanced

Select an external network and network pool and click Next.

You can deselect the Only use networks accessible by this organization check box to view external networks and network pools that are not currently available to the organization through its organization vDCs. When you deselec this check box, you can choose an arbitrary network or network pool and later create an organization vDC that can access the network or network pool

6 Use the default network settings or type your own and click Next.

7 (Optional) Type an external IP address for the network to use for NAT services, click Add, and click

Next.

This setting is available only in advanced setup. You can add more than one external IP address.

8 Type a name and optional description and click Next.

Select the external network check box and select routed drop-down menu.

Select External organization network - NAT-routed connection.

connection from the

9 Review the settings for the organization network.

Click Finish to accept the settings and create the organization network, or click Back to modify the settings.

What to do next

If you added external IP addresses, you can specify how they are mapped. See “Configure Port Forwarding

for an Organization Network,” on page 56.

Create an Internal Organization Network

You can create an internal organization network that only this organization can access. The new network provides the organization with an internal network to which multiple vApps can connect.

Prerequisites

Verify that you have a network pool.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Click Add Network.

3 Select an organization and click Next.

4 Select the type of setup and network type and click Next.

You can create an internal organization network using either method.

Option Network Type

Typical

Advanced

Select the internal network check box.

Select Internal organization network.

52 VMware, Inc.

Chapter 5 Managing Cloud Resources

5 Select a network pool and click Next.

You

can deselect the Only use networks accessible by this organization check box to view network pools

that are not currently available to the organization through its organization vDCs. When you deselect this check box, you can choose an arbitrary network pool and later create an organization vDC that can access it.

6 Use the default network settings or type your own and click Next.

7 Type a name and optional description and click Next.

8 Review the settings for the organization network.

Click Finish to accept the settings and create the organization network, or click Back to modify the settings.

Configuring Network Services

You can configure network services, such as DHCP, firewalls, network address translation (NAT), and VPN for certain organization networks. Organization administrators can also configure some network services for their organization networks.

Table 5-5 lists the network services that vCloud Director provides to each type of organization network.

Table 5-5. Network Services Available by Network Type

Network Type DHCP Firewall NAT VPN

External organization network - direct connection

External organization network - NATrouted connection

Internal organization network X

X X X X

Configure DHCP for an Organization Network

You can configure certain organization networks to provide DHCP services to virtual machines in the organization.

When you enable DHCP for an organization network, connect a NIC on virtual machine in the organization to

that network, and select DHCP as the IP mode for that NIC, vCloud Director assigns a DHCP IP address to

the virtual machine when you power it on.

Both system administrators and organization administrators can configure DHCP.

Prerequisites

An external NAT-routed organization network or an internal organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the DHCP tab and select Enable DHCP.

4 Type a range of IP addresses or use the default range.

vCloud Director uses these addresses to satisfy DHCP requests. The range of DHCP IP addresses cannot overlap with the static IP pool for the organization network.

5 Set the default lease time and maximum lease time or use the default values.

6 Click OK.

VMware, Inc. 53

vCloud Director Administrator's Guide

vCloud Director updates the network to provide DHCP services.

Enable the Firewall for an Organization Network

You can configure certain organization networks to provide firewall services. You can enable the firewall on an organization network to enforce firewall rules on incoming traffic, outgoing traffic, or both.

You

can deny all incoming traffic, deny all outgoing traffic, or both. You can also add specific firewall rules to allow or deny traffic that matches the rules to pass through the firewall. These rules take precedence over the generic rules to deny all incoming or outgoing traffic. See “Add a Firewall Rule for an Organization

Network,” on page 54.

System administrators and organization administrators can enable firewalls.

Prerequisites

Verify that you have an external NAT-routed organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the Firewall tab and select Enable firewall.

4 Select the default firewall action.

5 (Optional) Select the Log check box to log events related to the default firewall action.

6 Click OK.

Add a Firewall Rule for an Organization Network

You can add firewall rules to an organization network that supports a firewall. You can create rules to allow or deny traffic that matches the rules to pass through the firewall.

For a firewall rule to be enforced, you must enable the firewall for the organization network. See “Enable the

Firewall for an Organization Network,” on page 54.

When you add a new firewall rule to an organization network, it appears at the bottom of the firewall rule list. For information about setting the order in which firewall rules are enforced, see “Reorder Firewall Rules for

an Organization Network,” on page 55.

System administrators and organization administrators can add firewall rules.

Prerequisites

Verify that you have an external NAT-routed organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the Firewall tab and click Add.

4 Type a name for the rule.

5 Select the traffic direction.

6 Type the source IP address and select the source port.

For incoming traffic, the source is the external network. For outgoing traffic, the source is the organization

network.

54 VMware, Inc.

Chapter 5 Managing Cloud Resources

7 Type the destination IP address and select the destination port.

For incoming traffic, the destination is the organization network. For outgoing traffic, the destination is

the external network.

Select the protocol.

9 Select the action.

A firewall rule can allow or deny traffic that matches the rule.

10 Select the Enabled check box.

11 (Optional) Select the Log network traffic for firewall rule check box.

If you enable this option, vCloud Director sends log events to the syslog server for connections affected

by this rule. Each syslog message includes logical network and organization UUIDs.

12 Click OK and click OK again.

Reorder Firewall Rules for an Organization Network

Firewall rules are enforced in the order in which they appear in the firewall list. You can change the order of the rules in the list.

When you add a new firewall rule to an organization network, it appears at the bottom of the firewall rule list. If you want to enforce the new rule before an existing rule, make sure to reorder the rules.

Prerequisites

A routed organization network with two or more firewall rules.

Procedure

1 Click Administration.

2 Select Cloud Resources > Networks.

3 Right-click the organization network name and select Configure Services.

4 Click the Firewall tab.

5 Drag and drop the firewall rules to establish the order in which the rules are applied.

6 Click OK.

Enable IP Masquerading for an Organization Network

You can configure certain organization networks to provide IP masquerade services. You can use IP masquerading on an organization network to hide the internal IP addresses of virtual machines from the external network.

When you enable IP masquerade, vCloud Director translates a virtual machine's private, internal IP address to a public IP address for outbound traffic.

Both system administrators and organization administrators can enable IP masquerade.

Prerequisites

Verify that you have an external NAT-routed organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the NAT Mapping tab and select Enable IP Masquerade.

VMware, Inc. 55

vCloud Director Administrator's Guide

4 Click OK.

Add External IP Addresses to an Organization Network

Before you can configure NAT mapping for an organization network, you must add one or more external IP addresses.

Only a system administrator can add external IP addresses to an organization network.

Prerequisites

An external NAT-routed organization network.

Procedure

Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the NAT - External IPs tab.

4 Type an IP address and click Add.

The IP address must be routable on the external network and unique across internal networks.

5 Click OK.

What to do next

Configure NAT mapping using the external IP address.

Configure Port Forwarding for an Organization Network

You can configure certain organization networks to provide port forwarding. Port forwarding provides external access to services running on virtual machines on the organization network.

When you configure port forwarding, vCloud Director maps an external IP address and a port to a service running on a port on a virtual machine for inbound traffic.

When you add a new port forwarding rule to an organization network, it appears at the bottom of the NAT mapping rule list. For information about how to set the order in which NAT mapping rules are enforced, see

“Reorder NAT Mapping Rules for an Organization Network,” on page 57.

Both system administrators and organization administrators can configure port forwarding.

Prerequisites

Verify that you have an external NAT-routed organization network and an external IP address.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the NAT Mapping tab and click Add.

4 Select Port Forwarding and configure the port forwarding rule.

a Select an external IP address.

b Select an external port.

c Type the IP address of the destination virtual machine.

If the virtual machine is fenced, type its external IP address.

If the virtual machine is not fenced, type its internal IP address.

56 VMware, Inc.

Chapter 5 Managing Cloud Resources

d Select an internal port.

Select a protocol for the type of traffic to forward.

f Click OK.

5 Click OK.

Configure IP Translation for an Organization Network

You can configure certain organization networks to provide IP tanslation.

When you add a new IP translation rule to an organization network, it appears at the bottom of the NAT mapping rule list. For information about how to set the order in which NAT mapping rules are enforced, see

“Reorder NAT Mapping Rules for an Organization Network,” on page 57.

When you create an IP translation rule for a network, vCloud Director adds a DNAT and SNAT rule to the vShield Edge associated with the network's port group. The DNAT rule translates an external IP address to an internal IP address for inbound traffic. The SNAT rule translates an internal IP address to an external IP address for outbound traffic. If the network is also using IP masquerade, the SNAT rule takes precedence.

Both system administrators and organization administrators can configure IP translation.

Prerequisites

An external NAT-routed organization network and an external IP address.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the NAT Mapping tab and click Add.

4 Select IP Translation and configure the rule.

a Select an external IP address.

b Type the IP address of the destination virtual machine.

If the virtual machine is fenced, type its external IP address.

If the virtual machine is not fenced, type its IP address.

c Click OK.

5 Click OK.

Reorder NAT Mapping Rules for an Organization Network

NAT mapping rules are enforced in the order in which they appear in the NAT mapping list. An organization administrator can change the order of the rules in the list.

When you add a new NAT mapping rule, such as IP translation or port forwarding. to an organization network, the rule appears at the bottom of the NAT mapping rule list. To enforce the new rule before an existing rule, reorder the rules.

Prerequisites

Verify that you have a routed organization network with two or more NAT mapping rules.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

VMware, Inc. 57

vCloud Director Administrator's Guide

3 Click the NAT Mapping tab.

Click and drag the rules to establish the order in which the rules are applied.

5 Click OK.

Enable Site-to-Site VPN for an Organization Network

You can enable site-to-site VPN for an organization network and then create a secure tunnel to another network.

vCloud Director supports site-to-site VPN between organization networks in the same organization, organization networks in different organizations (including organization networks in different instances of vCloud Director), and remote networks.

Both system administrators and organization administrators can enable site-to-site VPN.

Prerequisites

An external NAT-routed organization network.

vShield Manager 5.0.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the Site-to-Site VPN tab and select Enable site-to-site VPN.

4 (Optional) Type a public IP address.

If the external network to which the organization network is routed is behind a NAT device, you must

provide a publicly accessible IP address that faces the Internet.

5 Click OK.

What to do next

Create a VPN tunnel to another network.

Create a VPN Tunnel Within an Organization

You can create a VPN tunnel between two organizations networks in the same organization.

Both system administrators and organization administrators can create VPN tunnels.

If there is a firewall between the tunnel endpoints, you must configure it to allow the following IP protocols and UDP ports:

IP Protocol ID 50 (ESP)

IP Protocol ID 51 (AH)

UDP Port 500 (IKE)

UDP Port 4500

Prerequisites

At least two external NAT-routed organization networks with non-overlapping IP subnets and site-to-site

VPN enabled on both networks.

vShield Manager 5.0.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

58 VMware, Inc.

Chapter 5 Managing Cloud Resources

2 Right-click the organization network name and select Configure Services.

Click the Site-to-Site VPN tab and click Add.

4 Type a name and optional description.

5 Select a network in this organization from the drop-down menu and select a peer network.

6 Review the tunnel settings and click OK.

vCloud Director configures both peer network endpoints.

Create a VPN Tunnel Between Organizations

You can create a VPN tunnel between two organizations networks in different organizations. The organizations can be part of the same vCloud Director installation or a different installation.

Both system administrators and organization administrators can create VPN tunnels.

If there is a firewall between the tunnel endpoints, you must configure it to allow the following IP protocols and UDP ports:

IP Protocol ID 50 (ESP)

IP Protocol ID 51 (AH)

UDP Port 500 (IKE)

UDP Port 4500

Prerequisites

An external NAT-routed organization network in each of the organizations. The organization networks

must have non-overlapping IP subnets and site-to-site VPN enabled.

vShield Manager 5.0.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the Site-to-Site VPN tab and click Add.

4 Type a name and optional description.

5 Select a network in another organization from the drop-down menu.

6 Click Connect to another organization, type the login information for the peer organization, and click

Continue.

Option Description

vCloud URL

Organization

Username

Password

The base URL of the vCloud instance that contains the peer organization. For example, https://www.example.com. Do not include /cloud or /cloud/org/

The organization name that is used as the unique identifier in the organization URL. For example, if the organization URL is https://www.example.com/cloud/org/myOrg, type myOrg.

The user name of an organization administrator or system administrator that has access to the organization.

The password associated with the user name.

orgname

in the URL.

Select a peer network.

VMware, Inc. 59

vCloud Director Administrator's Guide

8 Review the tunnel settings and click Connect.

vCloud Director configures both peer network endpoints.

Create a VPN Tunnel to a Remote Network

You can create a VPN tunnel between an organization network and a remote network.

Both system administrators and organization administrators can create VPN tunnels.

If there is a firewall between the tunnel endpoints, you must configure it to allow the following IP protocols and UDP ports:

IP Protocol ID 50 (ESP)

IP Protocol ID 51 (AH)

UDP Port 500 (IKE)

UDP Port 4500

Prerequisites

An external NAT-routed organization network and a routed remote network that uses IPSec.

vShield Manager 5.0.

Procedure

Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 Click the Site-to-Site VPN tab and click Add.

4 Type a name and optional description.

5 Select a remote network from the drop-down menu.

6 Type the peer settings.

7 Review the tunnel settings and click OK.

vCloud Director configures the organization peer network endpoint.

What to do next

Manually configure the remote peer network endpoint.

Enable Static Routing for an Organization Network

You can configure certain organization networks to provide static routing services. After you enable static routing on an organization network, you can add static routes to allow traffic between different vApp networks routed to the organization network.

Prerequisites

Verify that you have a routed organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 On the Static Routing tab, select Enable static routing and click OK.

60 VMware, Inc.

Chapter 5 Managing Cloud Resources

What to do next

Create static routes. See “Add Static Routes Between vApp Networks Routed to the Same Organization

Network,” on page 61 and “Add Static Routes Between vApp Networks Routed to Different Organization Networks,” on page 62.

Add Static Routes Between vApp Networks Routed to the Same Organization Network

You

can add static routes between two vApp networks that are routed to the same organization network. Static routes allow traffic between the networks.

Static routes only function when the vApps included in the routes are running. If the vApp includes static routes and you change the parent network of a vApp, delete a vApp, or delete a vApp network, the static routes no longer function and you must remove them manually.

Prerequisites

Verify that the networks have the following configurations:

vShield 5.0.

A routed organization network.

Static routing is enabled on the organization network.

Two vApp networks are routed to the organization network.

The vApp networks are in vApps that were started at least once.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 On the Static Routing tab, click Add.

4 Type a name, network address, and next hop IP.

The network address is for the first vApp network to which you want to add a static route. The next hop

IP is the external IP address of that vApp network's router.

5 Select Within this network and click OK.

6 Click OK.

7 Repeat steps Step 3 through Step 6 to add a route to the second vApp network.

Example: Static Routing Example

vApp Network 1 and vApp Network 2 are both routed to Org Network Shared. You can create static routes on the organization network to allow traffic between the vApp networks. You can use information about the vApp networks to create the static routes.

Table 5-6. Network Information

Network Name Network Specification Router External IP Address

vApp Network 1 192.168.1.0/24 192.168.0.100

vApp Network 2 192.168.2.0/24 192.168.0.101

Org Network Shared 192.168.0.0/24 NA

VMware, Inc. 61

vCloud Director Administrator's Guide

On Org Network Shared, create a static route to vApp Network 1 and another static route to vApp Network

Table 5-7. Static Routing Settings

Static Route to Network Route Name Network Next Hop IP Address Route

vApp Network 1 tovapp1 192.168.1.0/24 192.168.0.100 Within this network

vApp Network 2 tovapp2 192.168.2.0/24 192.168.0.101 Within this network

What to do next

Create firewall rules to allow traffic on the static routes. See “Add a Firewall Rule for an Organization

Network,” on page 54.

Add Static Routes Between vApp Networks Routed to Different Organization Networks

An organization administrator can add static routes between two vApp networks that are routed to different organization networks. Static routes allow traffic between the networks.

You cannot add static routes between overlapping networks or fenced vApps. After you add a static route to an organization network, configure the network firewall rules to allow traffic on the static route. For vApps with static routes, select the Always use assigned IP addresses until this vApp or associated networks are deleted check box.

Static

routes only function when the vApps included in the routes are running. If a vApp includes static routes and you change the parent network of the vApp, delete the vApp, or delete a vApp network, the static routes cannot function and you must remove them manually.

Prerequisites

Verify that vCloud Director has the following configurations:

vShield 5.0.

Two organization networks routed to the same external network.

Static routing is enabled on both organization networks.

A vApp network is routed to each organization network.

The vApp networks are in vApps that were started at least once.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Configure Services.

3 On the Static Routing tab, click Add.

4 Type a name, network address, and next hop IP address.

The network address is for the vApp network to which you want to add a static route. The next hop IP address is the external IP address of the router for the organization network to which that vApp network is routed.

5 Select To external network and click OK.

6 Click Add.

62 VMware, Inc.

Chapter 5 Managing Cloud Resources

7 Type a name, network address, and next hop IP address.

The network address is for the vApp network that is routed to this organization network. The next hop IP address is the external IP address of the router for that vApp network.

Select Within this network and click OK.

9 Repeat steps Step 3 through Step 8 to add static routes to the second organization network.

Example: Static Routing Example

vApp Network 1 is routed to Org Network 1. vApp Network 2 is routed to Org Network 2. You can create static routes on the organization networks to allow traffic between the vApp networks. You can use information about the vApp networks and organization networks to create the static routes.

Table 5-8. Network Information

Network Name Network Specification Router External IP Address

vApp Network 1 192.168.1.0/24 192.168.0.100

vApp Network 2 192.168.11.0/24 192.168.10.100

Org Network 1 192.168.0.0/24 10.112.205.101

Org Network 2 192.168.10.0/24 10.112.205.100

On Org Network 1, create a static route to vApp Network 2 and another static route to vApp Network 1. On Org Network 2, create a static route to vApp Network 1 and another static route to vApp Network 2.

Table 5-9. Static Routing Settings for Org Network 1

Static Route to Network Route Name Network Next Hop IP Address Route

vApp Network 2 tovapp2 192.168.11.0/24 10.112.205.100 To external network

vApp Network 1 tovapp1 192.168.1.0/24 192.168.0.100 Within this network

Table 5-10. Static Routing Settings for Org Network 2

Static Route to Network Route Name Network Next Hop IP Address Route

vApp Network 1 tovapp1 192.168.1.0/24 10.112.205.101 To external network

vApp Network 2 tovapp2 192.168.11.0/24 192.168.10.100 Within this network

What to do next

Create firewall rules to allow traffic on the static routes. See “Add a Firewall Rule for an Organization

Network,” on page 54.

Reset an Organization Network

If the network services, such as DHCP settings, firewall settings, and so on, that are associated with an organization network are not working as expected, you can reset the network.

Before you delete a provider vDC, reset the organization networks that depend on it.

No network services are available while an organization network resets.

Prerequisites

Verify that you have an external NAT-routed organization network or an internal organization network.

VMware, Inc. 63

vCloud Director Administrator's Guide

Procedure

Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Reset Network.

3 Click Yes.

View vApps and vApp Templates That Use an Organization Network

You can view a list of the all the vApps and vApp templates that include virtual machines with a NIC connected to an organization network. You cannot delete an organization network with connected vApps or vApp templates.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Select an organization network, right-click, and select Connected vApps.

3 Click OK.

Delete an Organization Network

You can delete an organization network to remove it from the organization.

Prerequisites

Verify that no virtual machines are connected to the organization network. See “View vApps and vApp

Templates That Use an Organization Network,” on page 64.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Delete.

View IP Use for an Organization Network

You can view a list of IP addresses that are currently in use in an organization network IP pool.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select IP Allocations.

Add IP Addresses to an Organization Network IP Pool

If an organization network is running out of IP addresses, you can add more addresses to its IP Pool.

Prerequisites

An external NAT-routed organization network or an internal organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Properties.

3 On the Network Specification tab, type an IP address or a range of IP addresses in the text box and click

Add.

4 Click OK.

64 VMware, Inc.

Chapter 5 Managing Cloud Resources

Modify an Organization Network Name and Description

your vCloud Director installation grows, you might want to assign a more descriptive name or description

to an existing organization.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Properties.

3 On the Name and Description tab, type a new name and optional description and click OK.

Modify an Organization Network DNS Settings

You can change the DNS settings for certain types of organization networks.

Prerequisites

An external NAT-routed organization network or an internal organization network.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Right-click the organization network name and select Properties.

3 On the Network Specification tab, type the new DNS information and click OK.

View Syslog Server Settings for an Organization Network

You can view the syslog server settings for a routed organization network.

vCloud Director supports logging events related to firewall rules to a syslog server that a system administrator specifies.

If an organization network lacks syslog server settings and you think that it should have them, or if the settings are not what you expected, synchronize the network with the most current syslog server settings. See “Apply

Syslog Server Settings to an Organization Network,” on page 65.

Prerequisites

Verify that you have an external NAT-routed organization network.

Verify that you are an organization administrator.

Procedure

1 Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Select an organization network, right-click, and select Properties.

3 Click the Syslog Server Settings tab.

Apply Syslog Server Settings to an Organization Network

You can apply syslog server settings to a routed organization network to enable firewall rule logging.

Apply syslog server settings to any organization network that was created before the initial creation of those settings. Apply the syslog server settings to an organization network any time the settings are changed.

VMware, Inc. 65

vCloud Director Administrator's Guide

If you are unsure whether an organization network's syslog settings are up-to-date, you can view the organization network's syslog settings. See “View Syslog Server Settings for an Organization Network,” on page 65.

Prerequisites

Verify that you have an external NAT-routed organization network.

Procedure

Click the Manage & Monitor tab and click Organization Networks in the left pane.

2 Select an organization network, right-click, and select Synchronize syslog server settings.

3 Click Yes.

Managing Network Pools

After you create a network pool, you can modify its name or description or delete it. Depending on the type of network pool, you can also add port groups, Cloud isolated networks, and VLAN IDs.

Modify a Network Pool Name and Description

As your vCloud Director installation grows, you might want to assign a more descriptive name or description to an existing network pool.

Procedure

1 Click the Manage & Monitor tab and then click Network Pools in the left pane.

2 Right-click the network pool name and select Properties.

3 On the General tab, type a new name or description and click OK.

Add a Port Group to a Network Pool

You can add port groups to a network pool that is backed by port groups.

Prerequisites

Verify that you have a network pool that is backed by a port group

Verify that you have an available port group in vSphere

Procedure

1 Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Right-click the network pool name and select Properties.

3 On the Network Pool Settings tab, select a port group, click Add, and click OK.

Add Cloud Isolated Networks to a Network Pool

You can add Cloud isolated networks to a VCD network isolation-backed network pool.

Prerequisites

A VCD network isolation-backed network pool

Procedure

1 Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Right-click the network pool name and select Properties.

66 VMware, Inc.

Chapter 5 Managing Cloud Resources

3 On the Network Pool Settings tab, type the number of VCD isolated networks and click OK.

Add VLAN IDs to a Network Pool

You can add VLAN IDs to a network pool that is backed by a VLAN.

Prerequisites

Verify that your system includes the following items:

A network pool that is backed by a VLAN

Available VLAN IDs in vSphere

Procedure

Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Right-click the network pool name and select Properties.

3 On the Network Pool Settings tab, type a VLAN ID range and click Add.

4 Select a vSphere distributed switch and click OK.

Delete a Network Pool

Delete a network pool to remove it from vCloud Director.

Prerequisites

Verify that the following conditions exist:

No organization vDC is associated with the network pool.

No vApps use the network pool

No NAT-routed or internal organization networks use the network pool.

Procedure

1 Click the Manage & Monitor tab and click Network Pools in the left pane.

2 Right-click the network pool name and select Delete.

3 Click Yes.

Managing Cloud Cells

You manage cloud cells mostly from the vCloud Director server host on which the cell resides, but you can delete a cloud cell from the vCloud Director Web console.

Table 5-11 lists the basic commands for controlling a cloud cell.

Table 5-11. Cloud Cell Commands

Command Description

service vmware-vcd start

service vmware-vcd restart

service vmware-vcd stop

Starts the cell

Restarts the cell

Stops the cell

When you stop a cell, you may want to display a maintenance message to users that attempt to access that cell using a browser or the vCloud API. See “Turn On Cloud Cell Maintenance Message,” on page 68.

VMware, Inc. 67

vCloud Director Administrator's Guide

Adding Cloud Cells

add cloud cells to a vCloud Director installation, install the vCloud Director software on additional Cloud

Director server hosts in the same vCloud Director cluster.

For more information, see the VMware vCloud Director Installation and Configuration Guide.

Delete a Cloud Cell

If you want to remove a cloud cell from your vCloud Director installation, in order to reinstall the software, or for some other reason, you can delete the cell.

You can also delete a cell if it becomes unreachable.

Prerequisites

You must stop the cell using the service vmware-vcd stop command.

Procedure

1 Click the Manage & Monitor tab and click Cloud Cells in the left pane.

2 Right-click the cell name and select Delete.

vCloud Director removes information about the cell from its database.

Turn On Cloud Cell Maintenance Message

If you want to stop a cell and let users know that you are performing maintenance, you can turn on the maintenance message.

When the maintenance message is turned on, users that attempt to log in to the cell from browser will see a message stating that the cell is down for maintenance. Uses that attempt to reach the cell using the vCloud API will receive a similar message.

Procedure

1 Stop the cell using the service vmware-vcd stop command.

2 Run the /opt/vmware/cloud-director/bin/vmware-vcd-cell maintenance command.

Users cannot access the cell using a browser or the vCloud API.

Turn Off Cloud Cell Maintenance Message

When you are finished performing maintenance on a cell and ready to restart the cell, you can turn off the maintenance message.

Procedure

1 Run the /opt/vmware/cloud-director/bin/vmware-vcd-cell stop command.

2 Start the cell using the service vmware-vcd start command.

Users can now access the cell using a browser or the vCloud API.

68 VMware, Inc.

Managing vSphere Resources 6

After you add vSphere resources to the vCloud Director system, you can perform some management functions from vCloud Director. You can also use the vSphere Client to manage these resources.

vSphere and ports.

This chapter includes the following topics:

resources include vCenter servers, resource pools, ESX/ESXi hosts, datastores, and network switches

“Managing vSphere vCenter Servers,” on page 69

“Managing vSphere ESX/ESXi Hosts,” on page 71

“Managing vSphere Datastores,” on page 72

“Managing Stranded Items,” on page 73

Managing vSphere vCenter Servers

After you attach a vCenter Server to vCloud Director, you can modify its settings, reconnect to the vCenter Server, and enable or disable it.

Register vCloud Director with a vCenter Server

You can register vCloud Director with the vCenter Servers it uses.

After you register vCloud Director, it appears as an extension in the vSphere Client Soultions Manager tab. In addition, the vSphere Client sets the Managed By property for vCloud Director-managed virtual machines, which protects those virtual machines from being modified using the vSphere Client.

Procedure

1 Click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Refresh.

3 Click Yes.

Modify vCenter Server Settings

If the connection information for a vCenter Server changes, or if you want to change how its name or description appears in vCloud Director, you can modify its settings.

Procedure

1 Click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Properties.

VMware, Inc. 69

vCloud Director Administrator's Guide

3 On the General tab, type the new settings and click OK.

Reconnect a vCenter Server

If vCloud Director loses it connection to a vCenter Server, or if you change the connection settings, you can try to reconnect.

Procedure

Click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Reconnect vCenter.

3 Read the informational message and click Yes to confirm.

Enable or Disable a vCenter Server

You can disable a vCenter Server to perform maintenance.

Procedure

1 Click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Disable or Enable.

3 Click Yes.

Remove a vCenter Server

You can remove a vCenter Server to stop using its resources with vCloud Director.

Prerequisites

Before you can remove a vCenter server, you must disable it and delete all of the provider vDCs that use its resource pools.

Procedure

1 Click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Detach.

3 Click Yes.

Prepare and Upgrade a vCenter Server Attached to vCloud Director

Before you upgrade a vCenter Server that is attached to vCloud director, you must prepare the server by disabling it in vCloud Director.

Familiarize yourself with the vSphere Upgrade documentation.

Procedure

1 In the vCloud Director web console, click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Disable.

3 Click Yes.

4 Upgrade vCenter Server.

5 In the vCloud Director web console, right-click the vCenter Server name and select Enable.

6 Click Yes.

70 VMware, Inc.

What to do next

Chapter 6 Managing vSphere Resources

vCloud Director with the upgraded server. See “Register vCloud Director with a vCenter Server,” on

Modify vShield Manager Settings

If the connection settings for the vShield Manager for a vCenter Server change, or if you want to use a different vShield Manager, you can modify its settings.

Procedure

1 Click the Manage & Monitor tab and click vCenters in the left pane.

2 Right-click the vCenter Server name and select Properties.

3 On the vShield Manager tab, type the new settings and click OK.

Managing vSphere ESX/ESXi Hosts

You can prepare hosts for use with vCloud Director, enable or disable hosts, upgrade, and repair hosts.

Enable or Disable an ESX/ESXi Host

You can disable a host to prevent vApps from starting up on the host. Virtual machines that are already running on the host are not affected.

To perform maintenance on a host, migrate all vApps off of the host or stop all vApps and then disable the host.

Procedure

1 Click the Manage & Monitor tab and click Hosts in the left pane.

2 Right-click the host name and select Enable Host or Disable Host.

vCloud Director enables or disables the host for all provider vDCs that use its resources.

Move Virtual Machines from one ESX/ESXi Host to Another

You can move all the virtual machines from one ESX/ESXi host to other hosts in the same cluster. This ability is useful to unprepare a host, or to perform maintenance on a host without affecting running virtual machines.

Prerequisites

Disable the host.

Procedure

1 Click the Manage & Monitor tab and click Hosts in the left pane.

2 Right-click the host name and select Redeploy all VMs.

3 Click Yes.

vCloud Director puts the host into maintenance mode and moves all of its virtual machines to other hosts in the same cluster.

VMware, Inc. 71

vCloud Director Administrator's Guide

Prepare or Unprepare an ESX/ESXi Host

When you add an ESX/ESXi host to a vSphere cluster that vCloud Director uses, you must prepare the host before a provider vDC can use its resources. You can unprepare a host to make it unavailable for use in the vCloud Director environment.

For information about moving virtual machines from one host to another, see “Move Virtual Machines from

one ESX/ESXi Host to Another,” on page 71.

You

cannot prepare a host that is in lockdown mode. After you prepare a host, you can enable lockdown mode.

Prerequisites

Disable the host and ensure that no virtual machines are running on the host.

Procedure

1 Click the Manage & Monitor tab and click Hosts in the left pane.

2 Right-click the host name and select Prepare Host or Unprepare Host.

3 If you are preparing a host, type a user name and password and click OK.

vCloud Director prepares or unprepares the host for all provider vDCs that use its resources.

Upgrade an ESX/ESXi Host Agent

vCloud Director installs agent software on each ESX/ESXi host in the installation. If you upgrade your ESX/ESXi hosts, you also need to upgrade your ESX/ESXi host agents.

Procedure

1 Click the Manage & Monitor tab and click Hosts in the left pane.

2 Right-click the host name and select Upgrade Host.

Repair an ESX/ESXi Host

If the vCloud Director agent on an ESX/ESXi host cannot be contacted, try to repair the host.

Procedure

1 Click the Manage & Monitor tab and click Hosts in the left pane.

2 Right-click the host name and select Repair Host.

Managing vSphere Datastores

You can enable or disable vSphere datastores in the vCloud Director system, configure low disk space warnings for datastores, and remove datastores from the vCloud Director system.

The only way to add a datastore to vCloud Director is to add it to a provider vDC. See “Add Storage Capacity

to a Provider vDC,” on page 41.

Enable or Disable a Datastore

You can enable or disable a datastore that has been added to a provider vDC. You must disable a datastore before you can remove it from vCloud Director.

When you disable a datastore, you cannot start vApps that are associated with the datastore or create vApps on the datastore.

72 VMware, Inc.

Chapter 6 Managing vSphere Resources

Procedure

Click the Manage & Monitor tab and click Datastores in the left pane.

2 Right-click the datastore name and select Enable or Disable.

vCloud Director enables or disables the datastore for all provider vDCs that use its resources.

Remove a Datastore

You can remove a datastore from vCloud Director to prevent provider vDCs from using its storage resources.

Prerequisites

Verify that the datastore is disabled and removed from all of the provider vDCs that use it.

Procedure

1 Click the Manage & Monitor tab and click Datastores in the left pane.

2 Right-click the datastore name and select Remove.

3 Click Yes.

vCloud Director removes the datastore.

Configure Low Disk Space Warnings for a Datastore

Procedure

1 Click the Manage & Monitor tab and click Datastores in the left pane.

2 Right-click the datastore name and select Properties.

3 On the General tab, select the disk space thresholds for the datastore.

You can set two thresholds, yellow and red. When vCloud Director sends an email alert, the message indicates which threshold was crossed.

4 Click OK.

vCloud Director sends an email alert when the datastore crosses a threshold.

Managing Stranded Items

When you delete an object in vCloud Director and that object also exists in vSphere, vCloud Director attempts to delete the object from vSphere. In some situations, vCloud Director may not be able to delete the object in vSphere, in which case, the object becomes stranded.

You can view a list of stranded items and try again to delete them, or you can use the vSphere Client to delete the stranded objects in vSphere.

Delete a Stranded Item

You can delete a stranded item to try to remove an object from vSphere that you already deleted from vCloud Director.

Procedure

1 Click the Manage & Monitor tab and click Stranded Items in the left pane.

VMware, Inc. 73

vCloud Director Administrator's Guide

2 Right-click a stranded item and select Delete.

Click Yes.

vCloud Director attempts to delete the stranded item from vSphere.

4 Refresh the page display.

If the delete operation is successful, vCloud Director removes the item from the stranded items list.

What to do next

If the delete operation is unsuccessful, you can force delete the item. See “Force Delete a Stranded Item,” on page 74.

Force Delete a Stranded Item

If vCloud Director cannot delete a stranded item, you can force delete it to remove it from the stranded items list. The stranded item continues to exist in vSphere.

Before you force delete a stranded item, try to delete it. See “Delete a Stranded Item,” on page 73.

Procedure

1 Click the Manage & Monitor tab and click Stranded Items in the left pane.

2 Right-click a stranded item and select Force Delete.

3 Click Yes.

vCloud Director removes the item from the stranded items list.

74 VMware, Inc.

Managing Organizations 7

After you create an organization, you can modify its properties, enable or disable it, or delete it.

This chapter includes the following topics:

“Enable or Disable an Organization,” on page 75

“Delete an Organization,” on page 75

“Modify an Organization Name,” on page 76

“Modify an Organization Full Name and Description,” on page 76

“Modify Organization LDAP Options,” on page 76

“Modify Organization Catalog Publishing Policy,” on page 77

“Modify Organization Email Preferences,” on page 78

“Modify Organization Lease, Quota, and Limit Settings,” on page 78

“Add a Catalog to an Organization,” on page 79

“Managing Organization Resources,” on page 79

“Managing Organization Users and Groups,” on page 80

“Managing Organization vApps and Virtual Machines,” on page 80

Enable or Disable an Organization

Disabling an organization prevents users from logging in to the organization and terminates the sessions of currently logged in users. Running vApps in the organization continue to run.

system administrator can allocate resources, add networks, and so on, even after an organization is disabled.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Enable or Disable.

Delete an Organization

Delete an organization to permanently remove it from vCloud Director.

Prerequisites

Before you can delete an organization, you must disable it and delete or change ownership of all objects that the organization users own.

VMware, Inc. 75

vCloud Director Administrator's Guide

Procedure

Click the Manage & Monitor tab and click Organization in the left pane.

2 Right-click the organization name and select Delete.

3 Click Yes.

Modify an Organization Name

As your vCloud Director installation grows, you might want to assign a more descriptive name to an existing organization.

Prerequisites

You must disable the organization before you can rename it.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 On the General tab, type a new organization name and click OK.

The internal organization URL changes to reflect the new name.

Modify an Organization Full Name and Description

As your vCloud Director installation grows, you might want to assign a more descriptive full name or description to an existing organization.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 On the General tab, type a new full name or description and click OK.

Modify Organization LDAP Options

You can use an LDAP service to provide a directory of users and groups to import into an organization. If you do not specify an LDAP service, you must create a user account for each user in the organization. LDAP options can only be set by a system administrator and cannot be modified by an organization administrator.

For more information about entering custom LDAP settings, see “Configuring the System LDAP Settings,” on page 93.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 Click the LDAP Options tab.

76 VMware, Inc.

Chapter 7 Managing Organizations

4 Select the new source for organization users.

Option Description

Do not use LDAP

VCD system LDAP service

Custom LDAP service

Organization administrator creates a local user account for each user in the organization. You cannot create groups if you select this option.

Use the LDAP service for the vCloud Director system as the source for organization users and groups.

Connect the organization to its own private LDAP service.

Provide any additional information required by your selection.

Option Action

Do not use LDAP

VCD system LDAP service

Custom LDAP service

Click OK.

(Optional) Type the distinguished name of the organizational unit (OU) to use to limit the users that you can import into the organization and click OK. If you do not enter anything, you can import all users in the system LDAP service into the organization.

NOTE Specifying an OU does not limit the LDAP groups you can import.

can import any LDAP group from the system LDAP root. However, only

You users who are in both the OU and the imported group can log in to the organization.

Click the Custom LDAP tab, type the custom LDAP settings for the organization, and click OK.

System

administrators and organization administrators who are currently logged in cannot import users and groups using the modified LDAP options until the cache for their current session expires or they log out and log in again.

Modify Organization Catalog Publishing Policy

A catalog provides organization users with a library of vApp templates and media that they can use to create vApps. Generally, catalogs should only be available to users in a single organization, but a system administrator can allow the organization administrator to publish a catalog to all organizations in the vCloud Director installation.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 Click the Catalog Publishing tab.

4 Select a catalog publishing option and click OK.

Option Description

Cannot publish catalogs

Allow publishing catalogs to all organizations

For

users who are currently logged in to the organization, changes to the catalog publishing policy do not take

effect until the cache for their current session expires or they log out and log in again.

Organization administrator cannot publish any catalogs for users outside of the organization.

Organization administrator can publish a catalog for users in all organizations.

VMware, Inc. 77

vCloud Director Administrator's Guide

Modify Organization Email Preferences

vCloud Director requires an SMTP server to send user notification and system alert emails. You can modify the settings you specified when you created the organization.

Procedure

Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 Click the Email Preferences tab.

4 Select an SMTP server option.

Option Description

Use system default SMTP server

Set organization SMTP server

Select a notification settings option.

Organization uses the system SMTP server.

Organization uses its own SMTP server. If you select this option, type the DNS host name or IP address and port number of the SMTP server. (Optional) Select the Requires authentication check box and type a user name and password.

Option Description

Use system default notification settings

Set organization notification settings

Organization uses the system notification settings.

Organization uses its own notification settings. If you select this option, type

email address that appears as the sender for organization emails, type text

an to use as the subject prefix for organization emails, and select the recipients for organization emails.

(Optional) Type a destination email address and click Test Email Settings to verify that all SMTP server settings are configured as expected.

7 Click OK.

Modify Organization Lease, Quota, and Limit Settings

Leases, quotas, and limits constrain the ability of organization users to consume storage and processing resources. You can modify these settings to prevent users from depleting or monopolizing an organization's resources.

For more information about leases, see “Understanding Leases,” on page 23.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Properties.

3 Click the Policies tab.

4 Select the lease options for vApps and vApp templates.

Leases provide a level of control over an organization's storage and compute resources by specifying the maximum amount of time that vApps can be running and that vApps and vApp templates can be stored. You can also specify what happens to vApps and vApp templates when their storage lease expires.

78 VMware, Inc.

5 Select the quotas for running and stored virtual machines.

Quotas determine how many virtual machines each user in the organization can store and power on in the organization's virtual datacenters. The quota you specify acts as a default for all new users added to the organization.

Select the limits for resource intensive operations.

7 Select the number of simultaneous connections for each virtual machine and click OK.

Add a Catalog to an Organization

You can add a catalog to an organization to contain its uploaded and imported vApp templates and media files. An organization can have multiple catalogs and control access to each catalog individually.

Prerequisites

Verify that you have an organization in which to create a catalog.

Procedure

Chapter 7 Managing Organizations

1 Click the Home tab and click Add another catalog to an organization.

2 Select an organization name and click Next.

3 Type a catalog name and optional description and click Next.

4 Select the publishing option and click Next.

Option Description

Do not publish this catalog to other organizations

Publish to all organizations

The items added to the catalog are only available within the organization.

The items added to the catalog are available to all of the organizations in the vCloud Director installation. The administrators of each organization can choose which catalog items to provide to their users.

Review the catalog settings and click Finish.

Managing Organization Resources

vCloud Director organizations obtain their resources for one or more organization vDCs. If an organization needs more resources, you can add a new organization vDC or modify an existing organization vDC. You can take resources away from an organization by removing or modifying an organization vDC.

For more information about adding an organization vDC, see “Create an Organization vDC,” on page 43.

For information about removing an organization vDC, see “Delete an Organization vDC,” on page 47.

For information about modifying the resources available to an existing organization vDC, see “Edit

Organization vDC Allocation Model Settings,” on page 48, and “Edit Organization vDC Storage Settings,” on

page 48.

VMware, Inc. 79

vCloud Director Administrator's Guide

Managing Organization Users and Groups

When you create an organization, you can add one or more local users to the organization. After you create the organization, you, or an organization administrator, can add local users, LDAP users, and LDAP groups to the organization.

more information about adding users and groups to an organization, see the VMware vCloud Director User's

For Guide.

Managing Organization vApps and Virtual Machines

Some tasks related to managing organization vApps and virtual machines can only be performed by a system administrator. For example, system administrators can add vSphere virtual machines to an existing vApp, create a vApp based on a vSphere virtual machine, and place a vApp in maintenance mode.

For more information about working with vApps in an organization, see the VMware vCloud Director User's Guide.

Add a vSphere Virtual Machine to a vApp

A system administrator can import a vSphere virtual machine into an existing vCloud Director vApp.

Prerequisites

You must be logged in to vCloud Director as a system administrator and the organization containing the vApp must have an available organization vDC.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click the My Cloud tab and click vApps in the left pane.

4 Right-click the vApp name and select Open.

5 On the Virtual Machines tab, click the Actions button and select Import from vSphere.

6 Select a vCenter Server and a virtual machine.

7 Type a name and optional description for the virtual machine.

8 Select whether to copy or move the source virtual machine.

9 Click OK.

Create a vApp Based on a vSphere Virtual Machine

A system administrator can import a vSphere virtual machine to an organization as a vCloud Director vApp.

Prerequisites

Verify that you are logged in to vCloud Director as a system administrator and that the organization has an available organization vDC.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click the My Cloud tab and click vApps in the left pane.

80 VMware, Inc.

Chapter 7 Managing Organizations

4 Click Import from vSphere.

Select a vCenter Server and a virtual machine.

6 Type a name and optional description for the vApp and select a destination organization vDC.

7 Select whether to copy or move the source virtual machine.

8 Click OK.

Place a vApp in Maintenance Mode

A system administrator can place a vApp in maintenance mode to prevent non-administrator users from changing the state of the vApp. This is useful, for example, when you want to back up a vApp using a thirdparty backup solution.

When a vApp is in maintenance mode, non-system administrator users cannot perform any actions that modify the state of the vApp or its virtual machine. They can view information about the vApp and its virtual machines and access the virtual machine consoles.

Placing a vApp in maintenance mode does not affect any currently running tasks that involve the vApp.

Prerequisites

You must be logged in to vCloud Director as a system administrator.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click the My Cloud tab and click vApps in the left pane.

4 Right-click the vApp name and select Enter Maintenance Mode.

5 Click Yes.

The status of the vApp changes to In Maintenance Mode. The vApp remains in maintenance mode until you select Exit Maintenance Mode.

Force Stop a Running vApp

A system administrator can force stop a running vApp when an organization user is unable to do so.

In some cases, a user may be unable to stop a running vApp. If traditional methods for stopping the vApp fail, you can force stop the vApp to prevent the user from getting billed.

Force stopping a vApp does not prevent the vApp from consuming resources in vSphere. After you force stop a vApp in vCloud Director, use the vSphere Client to check the status of the vApp in vSphere and take the necessary action.

Prerequisites

You must be logged in to vCloud Director as a system administrator.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click the My Cloud tab and click vApps in the left pane.

4 Right-click the running vApp and select Force Stop.

5 Click Yes.

VMware, Inc. 81

vCloud Director Administrator's Guide

Fast Provisioning of Virtual Machines

Fast provisioning saves time by using linked clones for virtual machine provisioning operations.

A linked clone is a duplicate of a virtual machine that uses the same base disk as the original, with a chain of delta disks to track the differences between the original and the clone. If fast provisioning is disabled, all provisioning operations result in full clones.

A linked clone cannot exist on a different vCenter datacenter or datastore than the original virtual machine. vCloud and datastores for virtual machines associated with a vApp template. A shadow virtual machine is an exact copy of the original virtual machine. The shadow virtual machine is created on the datacenter and datastore where the linked clone is created. You can view a list of shadow virtual machines associated with a template virtual machine. See “View Shadow Virtual Machines Associated With a Virtual Machine,” on page 82.

Fast provisioning is enabled by default on organization vDCs. Fast provisioning requires vCenter 5.0 and ESXi

5.0 hosts. If the provider vDC on which the organization vDC is based contains ESX/ESXi 4.x hosts, you must disable fast provisioning. See “Edit Organization vDC Storage Settings,” on page 48.

Director creates shadow virtual machines to support linked clone creation across vCenter datacenters

View Shadow Virtual Machines Associated With a Virtual Machine

Shadow virtual machines support linked clones of virtual machines that are associated with vApp templates across vCenter datacenters and datastores.

A shadow virtual machine is an exact copy of the original virtual machine that vCloud Director creates on the datacenter and datastore where a linked clone is created. See “Fast Provisioning of Virtual Machines,” on page 82.

Procedure

1 Click the Manage & Monitor tab and click Organizations in the left pane.

2 Right-click the organization name and select Open.

3 Click the My Cloud tab and click VMs in the left pane.

4 Right-click the virtual machine and select Properties.

5 Click the Shadow VMs tab.

This tab appears only for virtual machines that have associated shadow virtual machines.

vCloud Director shows a list of shadow virtual machines associated with the virtual machine. This list includes the name in vCenter of each shadow virtual machine, the datastore that each shadow virtual machine exists on, and the vCenter server that the shadow virtual machine belongs to.

82 VMware, Inc.

Managing System Administrators and

Roles 8

You can add system administrators to vCloud Director individually, or as part of an LDAP group. You can also add and modify the roles that determine what rights a user has within their organization.

This chapter includes the following topics:

“Add a System Administrator,” on page 83

“Import a System Administrator,” on page 84

“Enable or Disable a System Administrator,” on page 84

“Delete a System Administrator,” on page 84

“Edit System Administrator Profile and Contact Information,” on page 84

“Send an Email Notification to Users,” on page 85

“Delete a System Administrator Who Lost Access to the System,” on page 85

“Import an LDAP Group,” on page 85

“Delete an LDAP Group,” on page 86

“Change an LDAP Group Description,” on page 86

“Roles and Rights,” on page 86

“Create a Role,” on page 86

“Copy a Role,” on page 87

“Edit a Role,” on page 87

“Delete a Role,” on page 87

Add a System Administrator

You can add a system administrator to vCloud Director by creating a system administrator account. System administrators have full rights to vCloud Director and all of its organizations.

Procedure

Click the Administration tab and click Users in the left pane.

2 Click New.

3 Type the account information for the new user and click OK.

VMware, Inc. 83

vCloud Director Administrator's Guide

Import a System Administrator

To add a user with system administrator rights, you can import an LDAP user as a system administrator. System administrators have full rights to vCloud Director and all of its organizations.

Prerequisites

Verify that you have a valid connection to an LDAP server.

Procedure

Click the Administration tab and click Users in the left pane.

2 Click Import from LDAP.

3 Type a full or partial name in the text box and click Search Users.

4 Select the users to import and click Add.

5 Click OK.

Enable or Disable a System Administrator

You can disable a system administrator user to prevent that user from logging in to vCloud Director. To delete a system administrator, you must first disable their account.

Procedure

1 Click the Administration tab and click Users in the left pane.

2 Right-click the user name and select Enable Account or Disable Account.

Delete a System Administrator

You can remove a system administrator from the vCloud Director system by deleting their account.

Prerequisites

Disable the system administrator account.

Procedure

1 Click the Administration tab and click Users in the left pane.

2 Right-click the user name and select Delete.

3 Click Yes.

Edit System Administrator Profile and Contact Information

You can change the password and contact information for a system administrator account.

You can only edit account information for non-LDAP users.

Procedure

1 Click the Administration tab and click Users in the left pane.

2 Right-click the user name and select Properties.

3 Type the new information for the user account and click OK.

84 VMware, Inc.

Chapter 8 Managing System Administrators and Roles

Send an Email Notification to Users

You can send an email notification to all users in the entire installation, all system administrators, or all organization administrators. You can send an email notification to notify users about upcoming system maintenance, for example.

Prerequisites

Verify that you have a valid connection to an SMTP server.

Procedure

Click the Administration tab and click Users in the left pane.

2 Click Notify.

3 Select the recipients.

4 Type the email subject and message and click Send Email.

Delete a System Administrator Who Lost Access to the System

You can view a list of user accounts that lost access to the system when their LDAP group was deleted from vCloud Director. You can decide whether or not to add the user back into the system and then delete the user from the Lost & Found.

To add a user that was mistakenly removed from the system when their LDAP group was deleted, see “Add

a System Administrator,” on page 83 and “Import a System Administrator,” on page 84.

Procedure

1 Click the Administration tab and click Lost & Found in the left pane.

2 Right-click the user name and select Delete User.

Import an LDAP Group

To add a group of users with system administrator rights, you can import an LDAP group as system administrators. System administrators have full rights to vCloud Director and all of its organizations.

Prerequisites

Verify that you have a valid connection to an LDAP server.

Procedure

1 Click the Administration tab and click Groups in the left pane.

2 Click Import from LDAP.

3 Type a full or partial name in the text box and click Search Groups.

4 Select the groups to import and click Add.

5 Click OK.

VMware, Inc. 85

vCloud Director Administrator's Guide

Delete an LDAP Group

You can remove a group of system administrators from the vCloud Director system by deleting their LDAP group.

you delete an LDAP group, users who have a vCloud Director account based solely on their membership

When in that group are stranded and cannot log in. See “Delete a System Administrator Who Lost Access to the

System,” on page 85.

Procedure

1 Click the Administration tab and click Groups in the left pane.

2 Right-click the group name and select Delete.

3 Click Yes to confirm the deletion.

Change an LDAP Group Description

You can add or modify the description of an LDAP group to provide more information about the group.

Procedure

1 Click the Administration tab and click Groups in the left pane.

2 Right-click the group name and select Properties.

3 Type a description for the group and click OK.

Roles and Rights

vCloud Director uses roles and rights to determine what actions a user can perform in an organization. vCloud Director includes a number of predefined roles with specific rights.

System administrators and organization administrators must assign each user or group a role. The same user can have a different role in different organizations. System administrators can also create roles and modify existing ones.

For information about the predefined roles and their rights, see “Predefined Roles and Their Rights,” on page 107.

Create a Role

If the existing roles do not meet your needs, you can create a role and assign rights to the role. When you create a role, it becomes available to all of the organizations in the system.

Procedure

1 Click the Administration tab and click Roles in the left pane.

2 Click New.

3 Type a name and optional description for the role.

4 Select the rights for the role and click OK.

86 VMware, Inc.

Copy a Role

To create a role based on an existing role, you can copy a role and modify its rights.

Procedure

Click the Administration tab and click Roles in the left pane.

2 Right-click a role and select Copy to.

3 Type a name and optional description for the role.

4 Select the rights for the role and click OK.

Edit a Role

You can modify the name, description, and rights of a role.

Procedure

1 Click the Administration tab and click Roles in the left pane.

2 Right-click a role and select Properties.

3 Edit the name and optional description for the role.

Chapter 8 Managing System Administrators and Roles

4 Select the new rights for the role and click OK.

For users who are currently logged in, changes to their role do not take effect until the cache for their current session expires or they log out and log in again.

Delete a Role

You can delete a role from the system. You cannot delete the System Administrator role or a role that is in use.

Prerequisites

Assign a new role to all users with the role you want to delete.

Procedure

1 Click the Administration tab and click Roles in the left pane.

2 Right-click a role and select Delete.

3 Click Yes to confirm the deletion.

VMware, Inc. 87

vCloud Director Administrator's Guide

88 VMware, Inc.

Managing System Settings 9

A vCloud Director system administrator can control system-wide settings related to LDAP, email notification, licensing, and general system preferences.

This chapter includes the following topics:

“Modify General System Settings,” on page 89

“General System Settings,” on page 90

“Configure SMTP Settings,” on page 91

“Configure System Notification Settings,” on page 91

“Configuring Blocking Tasks and Notifications,” on page 92

“Configuring the System LDAP Settings,” on page 93

“Customize the vCloud Director Client UI,” on page 96

“Configure the Public Web URL,” on page 97

“Configure the Public Console Proxy Address,” on page 98

“Configure the Public REST API Base URL,” on page 98

“Configure the Account Lockout Policy,” on page 98

Modify General System Settings

vCloud Director includes general system settings related to login policy, session timeouts, and so on. The default settings are appropriate for many environments, but you can modify the settings to meet your needs.

For more information, see “General System Settings,” on page 90.

Procedure

Click the Administration tab and click General in the left pane.

2 Modify the settings and click Apply.

VMware, Inc. 89

vCloud Director Administrator's Guide

General System Settings

vCloud Director includes general system settings that you can modify to meet your needs.

Table 9-1. General System Settings

Name Category Description

Synchronization Start Time LDAP Synchronization Time of day to start LDAP synchronization.

Synchronization Interval LDAP Synchronization The number of hours between LDAP synchronisations.

Activity log history to keep Activity Log Number of days of log history to keep before deleting it.

Activity log history shown Activity Log Number of days of log history to display.

Display debug information Activity Log Enable this setting to display debug information in the

IP address release timeout Networking Number of seconds to keep released IP addresses on hold

Allow Overlapping External Networks

Default syslog server settings for networks

Provider Locale Localization Select a locale for provider activity, including log entries,

Idle session timeout Miscellaneous Amount of time the vCloud Director application remains

Maximum session timeout Miscellaneous Maximum amount of time the vCloud Director

Host refresh frequency Miscellaneous How often vCloud Director checks whether its ESX/ESXi

Host hung timeout Miscellaneous Select the amount of time to wait before marking a host as

Transfer session timeout Miscellaneous Amount of time to wait before failing a paused or canceled

Chargeback Event History to Keep Miscellaneous Number of days of chargeback event history to keep

Chargeback Event Cleanup Start Time

Provide default vApp names Miscellaneous Select the check box to generate default names for vApps.

Type 0 to never delete logs.

Type 0 to show all activity.

vCloud Director task log.

before making them available for allocation again. This default setting is 2 hours (7200 seconds) to allow old entries to expire from client ARP tables.

Networking Select the check box to add external networks that run on

the same network segment.

this setting only if you are using non-VLAN-based

Enable methods (for example, VMware vShield Manager) to isolate your external networks.

Networking Type IP addresses for up to two Syslog servers for

networks to use. This setting does not apply to Syslog servers used by cloud cells.

email alerts, and so on.

active without user interaction.

application remains active.

hosts are accessible or inaccessible.

hung.

upload task, for example upload media or upload vApp template. This timeout does not affect upload tasks that are in progress.

before deleting it.

Miscellaneous Time of day to start chargeback event history cleanup.

90 VMware, Inc.

Table 9-1. General System Settings (Continued)

Name Category Description

Chapter 9 Managing System Settings

Enable upload quarantine with a timeout of __ seconds

Verify vCenter certificates Miscellaneous Select the check box to allow vCloud Director to

Configure SMTP Settings

vCloud Director requires an SMTP server to send user notifications and system alert emails to system users. Organizations can use the system SMTP settings, or use custom SMTP settings.

Procedure

Click the Administration tab and click Email in the left pane.

2 Type the DNS host name or IP address of the SMTP mail server.

3 Type the SMTP server port number.

4 (Optional) If the SMTP server requires a user name, select the Requires authentication check box and

type the user name and password for the SMTP account.

5 Type an email address to appear as the sender for vCloud Director emails.

Miscellaneous Select the check box and enter a timeout number

representing the amount of time to quarantine uploaded files.

For more information about working with quarantined files, see “Monitoring Quarantined Files,” on page 105.

communicate only with trusted vCenter servers. Click Browse to locate the JCEKS keystore and type the keystore password.

vCloud Director uses the sender's email address to send runtime and storage lease expiration alerts.

6 Type text to use as the subject prefix for vCloud Director emails.

7 (Optional) Type a destination email address to test the SMTP settings and click Test SMTP settings.

8 Click Apply.

Configure System Notification Settings

vCloud Director sends system alert emails when it has important information to report. For example, vCloud Director sends an alert when a datastore is running out of space. You can configure vCloud Director to send email alerts to all system administrators or to a specified list of email addresses.

Organizations can use the system notification settings, or use custom notification settings.

Prerequisites

A valid connection to an SMTP server.

Procedure

1 Click the Administration tab and click Email in the left pane.

2 Select the recipients of system alert emails and click Apply.

VMware, Inc. 91

vCloud Director Administrator's Guide

Configuring Blocking Tasks and Notifications

Blocking tasks and notifications allow a system administrator to configure vCloud Director to send AMQP messages triggered by certain events.

of these messages are simply notifications that the event has occurred. These are known as notifications.

Some Others publish information to a designated AMQP endpoint indicating that a requested action has been blocked pending action by a client program bound to that endpoint, and are known as blocking tasks.

A system administrator can configure a system-wide set of blocking tasks that are subject to programmatic action by an AMQP client.

Configure an AMQP Broker

You must configure an AMQP broker if you want vCloud Director to send AMQP messages triggered by certain events.

Procedure

1 Click the Administration tab and click Blocking Tasks in the left pane.

2 Click the Settings tab.

3 Type the DNS host name or IP address of the AMQP host.

Type the AMQP port.

The default port is 5672.

4 Type the exchange.

5 Type the vHost.

6 To use SSL, select the SSL check box and choose one of the certificate options.

Option Action

Accept all certificates

SSL Certificate

SSL Keystore

Type a user name and password to connect to the AMQP host.

8 Click Test AMQP Connection to test the settings.

9 Click Apply.

10 (Optional) Select the Enable Notifications check box at the top of the page to publish audit events to the

AMQP broker.

Select the check box.

Click Browse to locate the SSL certificate.

Click Browse to locate the SSL keystore. Type the keystore password.

Configure Blocking Task Settings

You can specify status text, timeout settings, and default actions for blocking tasks. The settings apply to all organizations in the installation.

Procedure

1 Click the Administration tab and click Blocking Tasks in the left pane.

2 Click the Settings tab.

3 Type the text to appear as the status of a task that is pending extension processing.

4 Select the default extension timeout.

92 VMware, Inc.

5 Select the default timeout action.

Click Apply.

Enable Blocking Tasks

You can configure certain tasks to be enabled for blocking tasks.

Procedure

1 Click the Administration tab and click Blocking Tasks in the left pane.

2 Click the Blocking Tasks tab.

3 Select the tasks to enable for blocking extensions

4 Click Apply.

Configuring the System LDAP Settings

You can configure vCloud Director to create user accounts and authenticate user credentials against an LDAP server. Instead of manually creating user accounts, you can import LDAP users and groups by pointing the installation to an LDAP server.

After you connect vCloud Director to an LDAP server, you can import system administrators from the groups and users in the LDAP directory. You can also use the system LDAP settings to import users and groups to an organization, or you can specify separate LDAP settings for each organization. An LDAP user cannot log in to vCloud Director until you import them to the system or an organization.

Chapter 9 Managing System Settings

When an imported LDAP user logs in to vCloud Director, vCloud Director checks the credentials of the user against the LDAP directory. If the credentials are accepted, vCloud Director creates a user account and logs the user in to the system.

vCloud Director does not support hierarchical domains for LDAP authentication.

vCloud Director cannot modify the information in your LDAP directory. You can add, delete, or modify LDAP users or groups only in the LDAP directory itself.

You can control how often vCloud Director synchronizes user and group information with the LDAP directory.

LDAP Support

vCloud Director supports various combinations of operating system, LDAP server, and authentication method.

Table 9-2 displays a list of what vCloud Director supports.

Table 9-2. Supported Combinations of Operating System, LDAP Server, and Authentication Method

Operating System LDAP Server Authentication Method

Windows 2003 Active Directory Simple

Windows 2003 Active Directory Simple SSL

Windows 2003 Active Directory Kerberos

Windows 2003 Active Directory Kerberos SSL

Windows 2008 Active Directory Simple

Windows 7 (2008 R2) Active Directory Simple

Windows 7 (2008 R2) Active Directory Simple SSL

Windows 7 (2008 R2) Active Directory Kerberos

Windows 7 (2008 R2) Active Directory Kerberos SSL

VMware, Inc. 93

vCloud Director Administrator's Guide

Table 9-2. Supported Combinations of Operating System, LDAP Server, and Authentication Method (Continued)

Operating System LDAP Server Authentication Method

Linux OpenLDAP Simple

Linux OpenLDAP Simple SSL

Configure an LDAP Connection

You

can configure an LDAP connection to provide vCloud Director and its organizations with access to users

and groups on the LDAP server.

Prerequisites

In order to use Kerberos as your authentication method, you must add a realm. See “Add a Kerberos

Realm,” on page 95.

Procedure

1 Click the Administration tab and click LDAP in the left pane.

2 Type the host name or IP address of the LDAP server.

For Kerberos authentication, use the fully qualified domain name (FQDN).

3 Type a port number.

For LDAP, the default port number is 389. For LDAP over SSL (LDAPS), the default port number is 636.

4 Type the base distinguished name (DN).

The base DN is the location in the LDAP directory where vCloud Director connects. VMware recommends connecting at the root. Type the domain components only, for example, DC=example, DC=com.

To connect to a node in the tree, type the distinguished name for that node, for example,

OU=ServiceDirector, DC=example, DC=com. Connecting to a node limits the scope of the directory available

to vCloud Director.

5 Select the SSL check box to use LDAPS and choose one of the certificate options.

Option Action

Accept all certificates

SSL Certificate

SSL Keystore

Select the check box.

Click Browse to locate the SSL certificate.

Click Browse to locate the SSL keystore. Type and confirm the keystore password.

Select an authentication method.

Option Description

Simple

Kerberos

Simple authentication consists of sending the LDAP server the user's DN and password. If you are using LDAP, the LDAP password is sent over the network in clear text.

Kerberos issues authentication tickets to prove a user's identity. If you select Kerberos, you must select a realm.

94 VMware, Inc.

Chapter 9 Managing System Settings

7 Type a user name and password to connect to the LDAP server.

If anonymous read support is enabled on your LDAP server, you can leave these text boxes blank.

Authentication Method User Name Description

Simple

Kerberos

Type the full LDAP DN.

Type the name in the form of user@REALM.com.

Click Apply.

What to do next

You can now add LDAP users and groups to the system and to organizations that use the system LDAP settings.

Add a Kerberos Realm

vCloud Director requires a realm to use Kerberos authentication for an LDAP connection. You can add one or more realms for the system and its organizations to use. The system and each organization can only specify a single realm.

Prerequisites

You must select Kerberos as the authentication method before you can add a realm.

Procedure

1 Click the Administration tab and click LDAP in the left pane.

2 Click Edit All Realms.

3 (Optional) On the Realm tab, select Allow lower-case realms to allow realm names that include lower-

case letters.

4 On the Realm tab, click Add.

5 Type a realm and its Key Distribution Center (KDC) and click OK.

If you did not choose to allow lower-case realms, the realm name must be all capital letters. For example,

REALM.

6 On the DNS tab, click Add.

7 Type a DNS, select a realm, and click OK.

You can use the period (.) as a wildcard character in the DNS. For example, type .example.com.

8 Click Close and click Apply.

What to do next

You can now select a realm for the system LDAP settings or an organization's LDAP settings.

Test LDAP Settings

After you configure an LDAP connection, you can test its settings to make sure that user and group attributes are mapped correctly.

Prerequisites

You must configure an LDAP connection before you can test it.

Procedure

1 Click the Administration tab and click LDAP in the left pane.

VMware, Inc. 95

vCloud Director Administrator's Guide

2 Click Test LDAP Settings.

Type the name of a user in the LDAP directory and click Test.

4 Review the attribute mapping and click OK.

What to do next

You can customize LDAP user and group attributes based on the results of the test.

Customize LDAP User and Group Attributes

LDAP attributes provide vCloud Director with details about how user and group information is defined in the LDAP directory. vCloud Director maps the information to its own database. Modify the syntax for user and group attributes to match your LDAP directory.

Prerequisites

Verify that you have an LDAP connection

Procedure

1 Click the Administration tab and click LDAP in the left pane.

2 Modify the user and group attributes and click Apply.

Synchronize vCloud Director with the LDAP Server

vCloud Director automatically synchronizes its user and group information with the LDAP server on a regular basis. You can also manually synchronize with the LDAP server at any time.

For automatic synchronization, you can specify how often and when to synchronize. See “Modify General

System Settings,” on page 89.

Prerequisites

Verify that you have a valid LDAP connection.

Procedure

1 Click the Administration tab and click LDAP in the left pane.

2 Click Synchronize LDAP.

Customize the vCloud Director Client UI

You can customize the branding of the vCloud Director client UI and some of the links that appear on the vCloud Director Home login screen.

For a sample .css template with information about the styles that vCloud Director supports for custom themes, see http://kb.vmware.com/kb/1026050.

vCloud Director uses its default logo, or the logo that you upload, in the login screen, the header, and the footer. The login screen shows the logo in an area that ranges from a minimum of 48x48 pixels to a maximum of 60x150 pixels. You can upload logos that are smaller than 48x48 or larger than 60x150 and vCloud Director scales them to fit in the display area and maintain the aspect ratio of the uploaded image. The file size for an uploaded image cannot exceed 16384 bytes. The header and footer scale the logo to an appropriate size and maintain the aspect ratio of the original.

The file must be in the PNG, JPEG, or GIF format.

Procedure

1 Click the Administration tab and click Branding in the left pane.

96 VMware, Inc.

Chapter 9 Managing System Settings

2 Type a company name.

This name appears in the title bar for system administrators and in the footer for all users.

To select a custom logo, click Browse, select a file, and click Open.

4 To select a custom theme, click Browse, select a .css file, and click Open.

5 Type a URL that links to a Web site that provides information about your vCloud Director installation.

For example, http://www.example.com. Users can follow the link by clicking the company name in the footer of the client UI.

6 Type a URL that links to a Web site that provides support for this vCloud Director installation.

The Support link on the Home tab of all vCloud Director organizations opens this URL.

7 Type a URL that links to a Web site that allows users to sign up for a vCloud Director account.

This link appears on the vCloud Director login page.

8 Type a URL that links to a Web site that allows users to recover their password.

This link appears on the vCloud Director login page.

9 Click Apply.

Revert to System Default Logo

If you uploaded a custom logo for vCloud Director, you can revert to the system default logo.

Prerequisites

Verify that you uploaded a custom logo.

Procedure

1 Click the Administration tab and click Branding in the left pane.

2 Select Revert back to system default logo and click Apply.

Revert to System Default Theme

If you applied a custom theme to vCloud Director, you can always revert to the system default theme.

Prerequisites

Verify that you previously applied a custom theme.

Procedure

1 Click the Administration tab and click Branding in the left pane.

2 Select Revert back to system default theme and click Apply.

Configure the Public Web URL

If your vCloud Director installation includes multiple cloud cells running behind a load balancer or NAT, or if the cloud cells do not have publicly-routable IP addresses, you can set a public web URL.

During the initial configuration of each cloud cell, you specified an HTTP service IP address. By default, vCloud Director uses that address to construct the organization URL that organization users access to log in to the system. To use a different address, specify a public web URL.

Procedure

1 Click the Administration tab and click Public Addresses in the left pane.

VMware, Inc. 97

vCloud Director Administrator's Guide

2 Type the public web URL.

Click Apply.

When you create an organization, its organization URL includes the public web URL instead of the HTTP service IP address. vCloud Director also modifies the organization URLs of existing organizations.

Configure the Public Console Proxy Address

During the initial configuration of each cloud cell, you specified a remote console proxy IP address. By default, vCloud Director uses that address when a user attempts to view a virtual machine console. To use a different address, specify a public console proxy address.

Procedure

1 Click the Administration tab and click Public Addresses in the left pane.

2 Type the hostname or IP address for the public console proxy address.

This can be the address of the load balancer or some other machine that can route traffic to the remote console proxy IP.

3 Click Apply.

Remote console session tickets sent to the HTTP service IP address return the public console proxy address.

Configure the Public REST API Base URL

During the initial configuration of each cloud cell, you specified an HTTP service IP address. By default, vCloud Director uses that address in the XML responses from the REST API and as the upload target for the transfer service (for uploading vApp templates and media). To use a different address, specify a public REST API base URL.

Procedure

1 Click the Administration tab and click Public Addresses in the left pane.

2 Type the hostname or IP address for the public REST API base URL.

This can be the address of the load balancer or some other machine that can route traffic to the HTTP service IP.

3 Click Apply.

XML responses from the REST API include the base URL and the transfer service uses the base URL as the upload target.

Configure the Account Lockout Policy

You can enable account lockout to prevent a user from logging in to the Web console after a certain number of failed attempts. By default, the settings you specify apply to all organizations in the installation, but a system administrator or organization administrator can override the settings for a specific organization.

Procedure

1 Click the Administration tab and click Password Policy in the left pane.

98 VMware, Inc.

Chapter 9 Managing System Settings

2 Select

the Account lockout enabled check box, the System Administrator account can lockout check box,

or both.

3 Select the number of invalid logins to accept before locking an account.

4 Select the lockout interval.

5 Click Apply.

VMware, Inc. 99

vCloud Director Administrator's Guide

100 VMware, Inc.

VMware vCloud Director - 1.5 Administrator’s Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

vCloud Director Administrator's Guide

Getting Started with vCloud Director 1

Overview of vCloud Director Administration

Log In to the Web Console

Preparing the System

Create a Microsoft Sysprep Deployment Package

Replace a Microsoft Sysprep Deployment Package

Set User Preferences

Change a System Administrator Password

Adding Resources to vCloud Director 2

Adding vSphere Resources

Attach a vCenter Server

Open the Attach New vCenter Wizard

Provide vCenter Server Connection and Display Information

Connect to vShield Manager

Confirm Settings and Attach the vCenter Server

Assign a vShield License Key in vCenter

Adding Cloud Resources

Provider Virtual Datacenters

Create a Provider Virtual Datacenter

External Networks

Add an External Network

Network Pools

Add a Network Pool That Is Backed by VLAN IDs

Add a Network Pool That Is Backed by Cloud Isolated Networks

Add a Network Pool That Is Backed by vSphere Port Groups

Set the MTU for a Network Pool Backed by Cloud Isolated Networks

Understanding Leases

Create an Organization

Open the New Organization Wizard

Name the Organization

Specify the Organization LDAP Options

Add Local Users to the Organization

Set the Organization Catalog Publishing Policy

Configure Email Preferences

Configure Organization Lease, Quota, and Limit Settings

Confirm Settings and Create the Organization

Allocate Resources to an Organization

Open the Allocate Resources Wizard

Select a Provider vDC

Select an Allocation Model

Configure the Allocation Model

Allocate Storage

Select Network Pool

Name the Organization vDC

Confirm Settings and Create the Organization vDC

Adding Networks to an Organization

Understanding Organization Networks

Add an External Direct Organization Network

Add an External NAT-Routed Organization Network

Add an Internal Organization Network

Creating a Published Catalog 4

Enable Catalog Publishing

Create a Published Catalog

Upload a vApp Template

Import a vApp Template from vSphere

Upload a Media File

Import a Media File from vSphere

Publish a Catalog

Managing Cloud Resources 5

Managing Provider vDCs

Enable or Disable a Provider vDC

Delete a Provider vDC

Modify a Provider vDC Name and Description

Enable or Disable a Provider vDC Host

Prepare or Unprepare a Provider vDC Host

Upgrade an ESX/ESXi Host Agent for a Provider vDC Host

Repair a Provider vDC ESX/ESXi Host

Enable or Disable a Provider vDC Datastore

Add Storage Capacity to a Provider vDC

Add a Resource Pool to a Provider vDC

Configure Low Disk Space Warnings for a Provider vDC Datastore

Send an Email Notification to Provider vDC Users

Managing Organization vDCs

Create an Organization vDC
