Developing with VMware vCenter Orchestrator provides information and instructions for developing custom VMware® vCenter Orchestrator workflows and actions.

In addition, the documentation contains information about the Orchestrator elements that require scripting and provides JavaScript examples. Developing with VMware vCenter Orchestrator also provides instructions about how to create resources and packages.

Intended Audience

This information is intended for developers who want to create custom Orchestrator workflows and actions, as well as custom building blocks.

VMware, Inc.

Developing with VMware vCenter Orchestrator

8 VMware, Inc.

Developing Workflows 1

You develop workflows in the Orchestrator client interface. Workflow development involves using the workflow editor, the built-in Mozilla Rhino JavaScript scripting engine, and the Orchestrator and vCenter Server APIs.

Key Concepts of Workflows on page 11

Workflows consist of a schema, attributes, and parameters. The workflow schema is the main component of a workflow as it defines all the workflow elements and the logical connections between them. The workflow attributes and parameters are the variables that workflows use to transfer data. Orchestrator saves a workflow token every time a workflow runs, recording the details of that specific run of the workflow.

Phases in the Workflow Development Process on page 12

The process for developing a workflow involves a series of phases. You can follow a different sequence of phases or skip a phase, depending on the type of workflow that you are developing. For example, you can create a workflow without custom scripting.

Access Rights for the Orchestrator Client on page 12

By default, only members of the Orchestrator administrator LDAP group can access the Orchestrator client.

VMware, Inc.

Testing Workflows During Development on page 13

You can test workflows at any point during the development process, even if you have not completed the workflow or included an end element.

Creating and Editing a Workflow on page 13

You create workflows in the Orchestrator client and edit them in the workflow editor. The workflow editor is the IDE of the Orchestrator client for developing workflows.

Provide General Workflow Information on page 15

You provide a workflow name and desription, define attributes and certain aspects of workflow behavior, set the version number, check the signature, and set user permissions in the General tab in the workflow editor.

Defining Attributes and Parameters on page 16

After you create a workflow, you must define the global attributes, input parameters, and output parameters of the workflow.

Workflow Schema on page 19

A workflow schema is a graphical representation of a workflow that shows the workflow as a flow diagram of interconnected workflow elements. The workflow schema defines the logical flow of a workflow.

Developing with VMware vCenter Orchestrator

Obtaining Input Parameters from Users When a Workflow Starts on page 41

If a workflow requires input parameters, it opens a dialog box in which users enter the required input parameter values when it runs. You can organize the content and layout, or presentation, of this dialog box in Presentation tab in the workflow editor.

(Optional) Requesting User Interactions While a Workflow Runs on page 46

A workflow can sometimes require additional input parameters from an outside source while it runs. These input parameters can come from another application or workflow, or the user can provide them directly.

Calling Workflows Within Workflows on page 54

Workflows can call on other workflows during their run. A workflow can start another workflow either because it requires the result of the other workflow as an input parameter for its own run, or it can start a workflow and let it continue its own run independently. Workflows can also start a workflow at a given time in the future, or start multiple workflows simultaneously.

Running a Workflow on a Selection of Objects on page 61

You can automate repetitive tasks by running a workflow on a selection of objects. For example, you can create a workflow that takes a snapshot of all the virtual machines in a virtual machine folder, or you can create a workflow that powers off all the virtual machines on a given host.

Developing Long-Running Workflows on page 63

A workflow in a waiting state consumes system resources because it constantly polls the object from which it requires a response. If you know that a workflow will potentially wait for a long time before it receives the response it requires, you can add long-running workflow elements to the workflow.

Configuration Elements on page 68

A configuration element is a list of attributes you can use to configure constants across a whole Orchestrator server deployment.

Workflow User Permissions on page 69

Orchestrator defines levels of permissions that you can apply to groups to allow or deny them access to workflows.

Validating Workflows on page 70

Orchestrator provides a workflow validation tool. Validating a workflow helps identify errors in the workflow and checks that the data flows from one element to the next correctly.

Debugging Workflows on page 72

Orchestrator provides a workflow debugging tool. You can debug a workflow to inspect the input and output parameters and attributes at the start of any activity, replace parameter or attribute values during a workflow run in edit mode, and resume a workflow from the last failed activity.

Running Workflows on page 73

An Orchestrator workflow runs according to a logical flow of events.

Resuming a Failed Workflow Run on page 76

If a workflow fails, Orchestrator provides an option to resume the workflow run from the last failed activity.

Generate Workflow Documentation on page 78

You can export documentation in PDF format about a workflow or a workflow folder that you select at any time.

Use Workflow Version History on page 78

You can use version history to revert a workflow to a previously saved state. You can revert the workflow state to an earlier or a later workflow version. You can also compare the differences between the current state of the workflow and a saved version of the workflow.

10 VMware, Inc.

Restore Deleted Workflows on page 79

You can restore workflows that have been deleted from the workflow library.

Develop a Simple Example Workflow on page 79

Developing a simple example workflow demonstrates the most common steps in the workflow development process.

Develop a Complex Workflow on page 102

Developing a complex example workflow demonstrates the most common steps in the workflow development process and more advanced scenarios, such as creating custom decisions and loops.

Key Concepts of Workflows

Workflow Parameters

Workflows receive input parameters and generate output parameters when they run.

Chapter 1 Developing Workflows

Input Parameters

Most workflows require a certain set of input parameters to run. An input parameter is an argument that the workflow processes when it starts. The user, an application, another workflow, or an action passes input parameters to a workflow for the workflow to process when it starts.

For example, if a workflow resets a virtual machine, the workflow requires as an input parameter the name of the virtual machine.

Output Parameters

A workflow's output parameters represent the result from the workflow run. Output parameters can change when a workflow or a workflow element runs. While workflows run, they can receive the output parameters of other workflows as input parameters.

For example, if a workflow creates a snapshot of a virtual machine, the output parameter for the workflow is the resulting snapshot.

Workflow Attributes

Workflow elements process data that they receive as input parameters, and set the resulting data as workflow attributes or output parameters.

Read-only workflow attributes act as global constants for a workflow. Writable attributes act as a workflow’s global variables.

You can use attributes to transfer data between the elements of a workflow. You can obtain attributes in the following ways:

Define attributes when you create a workflow

Set the output parameter of a workflow element as a workflow attribute

Inherit attributes from a configuration element

VMware, Inc. 11

Developing with VMware vCenter Orchestrator

Workflow Schema

A workflow schema is a graphical representation that shows the workflow as a flow diagram of interconnected workflow elements. The workflow schema is the most important element of a workflow as it determines its logic.

Workflow Presentation

When users run a workflow, they provide the values for the input parameters of the workflow in the workflow presentation. When you organize the workflow presentation, consider the type and number of input parameters of the workflow.

Workflow Tokens

A workflow token represents a workflow that is running or has run.

A workflow is an abstract description of a process that defines a generic sequence of steps and a generic set of required input parameters. When you run a workflow with a set of real input parameters, you receive an instance of this abstract workflow that behaves according to the specific input parameters you give it. This specific instance of a completed or a running workflow is called a workflow token.

Workflow Token Attributes

Workflow token attributes are the specific parameters with which a workflow token runs. The workflow token attributes are an aggregation of the workflow's global attributes and the specific input and output parameters with which you run the workflow token.

Phases in the Workflow Development Process

Generally, you develop a workflow through the following phases.

1 Create a new workflow or create a duplicate of an existing workflow from the standard library.

2 Provide general information about the workflow.

3 Define the input parameters of the workflow.

4 Lay out and link the workflow schema to define the logical flow of the workflow.

5 Bind the input and output parameters of each schema element to workflow attributes.

6 Write the necessary scripts for scriptable task elements or custom decision elements.

7 Create the workflow presentation to define the layout of the input parameters dialog box that the users

see when they run the workflow.

8 Validate the workflow.

Access Rights for the Orchestrator Client

By default, only members of the Orchestrator administrator LDAP group can access the Orchestrator client.

The Orchestrator administrator can grant access to the Orchestrator client to other user groups by setting at least the View permission.

12 VMware, Inc.

To allow you to access the Orchestrator client, the administrator must either add you to the Orchestrator administrator LDAP group, or set View, Inspect, Edit, Execute, or Admin permissions to a group that you are a member of.

Testing Workflows During Development

You can test workflows at any point during the development process, even if you have not completed the workflow or included an end element.

By default, Orchestrator checks that a workflow is valid before you can run it. You can deactivate automatic validation during workflow development, to run partial workflows for testing purposes.

NOTE Do not forget to reactivate automatic validation when you finish developing the workflow.

Procedure

1 In the Orchestrator client menu, click Tools > User preferences.

2 Click the Workflows tab.

3 Deselect the Validate workflow before running it check box.

You deactivated automatic workflow validation.

Chapter 1 Developing Workflows

Creating and Editing a Workflow

You create workflows in the Orchestrator client and edit them in the workflow editor. The workflow editor is the IDE of the Orchestrator client for developing workflows.

You open the workflow editor by editing an existing workflow.

Create a Workflow on page 13

You can create workflows in the workflows hierarchical list of the Orchestrator client.

Edit a Workflow on page 14

You edit a workflow to make changes to an existing workflow or to develop a new empty workflow.

Edit a Workflow from the Standard Library on page 14

Orchestrator provides a standard library of workflows that you can use to automate operations in the virtual infrastructure. The workflows in the standard library are locked in the read-only state.

Workflow Editor Tabs on page 15

The workflow editor consists of tabs on which you edit the components of the workflows.

Create a Workflow

You can create workflows in the workflows hierarchical list of the Orchestrator client.

Procedure

1 Click the Workflows view.

2 (Optional) Right-click the root of the workflows hierarchical list, or a folder in the list, and select Add

folder to create a new workflow folder.

3 (Optional) Type the name of the new folder.

4 Right-click the new folder or an existing folder and select New workflow.

5 Name the new workflow and click OK.

A new empty workflow is created in the folder that you chose.

VMware, Inc. 13

Developing with VMware vCenter Orchestrator

What to do next

You can edit the workflow.

Edit a Workflow

You edit a workflow to make changes to an existing workflow or to develop a new empty workflow.

Procedure

1 Click the Workflows view.

2 Expand the workflows hierarchical list to navigate to the workflow that you want to edit.

3 To open the workflow for editing, right-click the workflow and select Edit.

The workflow editor opens the workflow for editing.

Edit a Workflow from the Standard Library

Orchestrator provides a standard library of workflows that you can use to automate operations in the virtual infrastructure. The workflows in the standard library are locked in the read-only state.

To edit a workflow from the standard library, you must create a duplicate of that workflow. You can edit duplicate workflows or custom workflows.

Procedure

1 Click the Workflows view.

2 (Optional) Right-click the root of the hierarchical list of workflow folders and select New folder to

create a folder to contain the workflow to edit.

3 Expand the Library hierarchical list of standard workflows to navigate to the workflow to edit.

4 Right-click the workflow to edit.

The Edit option is dimmed. The workflow is read-only.

5 Right-click the workflow and select Duplicate workflow.

6 Provide a name for the duplicate workflow.

By default, Orchestrator names the duplicate workflow Copy of workflow_name.

7 Click the Workflow folder value to search for a folder in which to save the duplicate workflow.

Select the folder you created in Step 2. If you did not create a folder, select a folder that is not in the library of standard workflows.

8 Click Yes or No to copy the workflow version history to the duplicate.

Option Description

Yes

The version history of the original workflow is replicated in the duplicate.

The version of the duplicate reverts to 0.0.0.

9 Click Duplicate to duplicate the workflow.

10 Right-click the duplicate workflow and select Edit.

The workflow editor opens. You can edit the duplicate workflow.

You duplicated a workflow from the standard library. You can edit the duplicate workflow.

14 VMware, Inc.

Chapter 1 Developing Workflows

Workflow Editor Tabs

The workflow editor consists of tabs on which you edit the components of the workflows.

Table 1‑1. Workflow Editor Tabs

Tab Description

General Edit the workflow name, provide a description of what the

workflow does, set the version number, see the user permissions, define the behavior of the workflow if the Orchestrator server restarts, and define the workflow's global attributes.

Inputs Define the parameters that the workflow requires when it

runs. These input parameters are the data that the workflow processes. The workflow's behavior changes according to these parameters.

Outputs Define the values that the workflow generates when it

completes its run. Other workflows or actions can use these values when they run.

Schema Build the workflow. You build the workflow by dragging

workflow schema elements from the workflow palette on the left side of the Schema tab. Clicking an element in the schema diagram allows you to define and edit the element's behavior in the bottom half of the Schema tab.

Presentation Define the layout of the user input dialog box that appears

when users run a workflow. You arrange the parameters and attributes into presentation steps and groups to ease identification of parameters in the input parameters dialog box. You define the constraints on the input parameters that users can provide in the presentation by setting the parameter properties.

Parameters References View which workflow elements consume the attributes and

parameters in the logical flow of the workflow. This tab also shows the constraints on these parameters and attributes that you define in the Presentation tab.

Workflow Tokens View details about each workflow run. This information

includes the workflow's status, the user who ran it, the business status of the current element, and the time and date when the workflow started and ended.

Events View information about each individual event that occurs

when the workflow runs. This information includes a description of the event, the user who triggered it, the type and origin of the event, and the time and date when it occurred.

Permissions Set the permissions to interact with the workflow for users

or groups of users.

Provide General Workflow Information

Prerequisites

Open a workflow for editing in the workflow editor.

VMware, Inc. 15

Developing with VMware vCenter Orchestrator

Procedure

1 Click the General tab in the workflow editor.

2 Click the Version digits to set a version number for the workflow.

The Version Comment dialog box opens.

3 Type a comment for this version of the workflow and click OK.

For example, type Initial creation if you just created the workflow.

A new version of the workflow is created. You can later revert the state of the workflow to this version.

4 Define how the workflow behaves if the Orchestrator server restarts by setting the Server restart

behavior value.

Leave the default value of Resume workflow run to make the workflow resume at the point at

which its run was interrupted when the server stopped.

Click Resume workflow run and select Do not resume workflow run (set as FAILED) to prevent

the workflow from restarting if the Orchestrator server restarts.

Prevent the workflow from restarting if the workflow depends on the environment in which it runs. For example, if a workflow requires a specific vCenter Server and you reconfigure Orchestrator to connect to a different vCenter Server, restarting the workflow after you restart the Orchestrator server causes the workflow to fail.

5 Type a detailed description of the workflow in the Description text box.

6 Click Save at the bottom of the workflow editor.

A green message at the bottom left of the workflow editor confirms that you saved your changes.

You defined aspects of the workflow behavior, set the version, and defined the operations that users can perform on the workflow.

What to do next

You must define the workflow attributes and parameters.

Defining Attributes and Parameters

After you create a workflow, you must define the global attributes, input parameters, and output parameters of the workflow.

Workflow attributes store data that workflows process internally. Workflow input parameters are data provided by an outside source, such as a user or another workflow. Workflow output parameters are data that the workflow delivers when it finishes its run.

Define Workflow Parameters on page 17

You can use input and output parameters to pass data into and out of the workflow.

Define Workflow Attributes on page 17

Workflow attributes are the data that workflows process.

Attribute and Parameter Naming Restrictions on page 18

You can use OGNL expressions to determine input parameters dynamically when a workflow runs. The Orchestrator OGNL parser uses certain keywords during OGNL processing that you cannot use in workflow attribute or parameter names.

16 VMware, Inc.

Chapter 1 Developing Workflows

Define Workflow Parameters

You can use input and output parameters to pass data into and out of the workflow.

You can define the parameters of a workflow in the workflow editor. The input parameters are the initial data that the workflow requires to run. Users provide the values for the input parameters when they run the workflow. The output parameters are the data the workflow returns when it completes its run.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 Click the appropriate tab in the workflow editor.

Click Inputs to create input parameters.

Click Outputs to create output parameters.

2 Right-click inside the parameters tab and select Add parameter.

3 Click the parameter name to change it.

The default name is arg_in_X for input parameters and arg_out_X for output parameters, where X is a number.

4 (Optional) To change the value of the parameter type, click the value and select one from the list of

available values.

The value for the parameter type is String by default.

5 Add a description for the parameter in the Description text box.

6 (Optional) If you decide that the parameter should be an attribute rather than a parameter, right-click

the parameter and select Move as attribute to change the parameter into an attribute.

You have defined an input or output parameter for the workflow.

What to do next

After you define the workflow's parameters, build the workflow schema.

Define Workflow Attributes

Workflow attributes are the data that workflows process.

NOTE You can also define workflow attributes in the workflow schema elements when you create the workflow schema. It is often easier to define an attribute when you create the workflow schema element that processes it.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 Click the General tab in the workflow editor.

The attributes pane appears in the bottom half of the General tab.

2 Right-click in the attributes pane and select Add Attribute.

A new attribute appears in the attributes list, with String as its default type.

VMware, Inc. 17

Developing with VMware vCenter Orchestrator

3 Click the attribute name to change it.

The default name is attX, where X is a number.

NOTE Workflow attributes must not have the same name as any of the workflow's parameters.

4 Click the attribute type to select a new type from a list of possible values.

The default attribute type is String.

5 Click the attribute value to set or select a value according to the attribute type.

6 Add a description of the attribute in the Description text box.

7 If the attribute is a constant rather than a variable, click the check box to the left of the attribute name to

make its value read-only.

The lock icon identifies the column of read-only check boxes.

8 (Optional) If you decide that the attribute should be an input or output parameter rather than an

attribute, right-click the attribute and select Move as INPUT/OUTPUT parameter to change the attribute into a parameter.

You defined an attribute for the workflow.

What to do next

You can define the workflow's input and output parameters.

Attribute and Parameter Naming Restrictions

Using a reserved OGNL keyword as a prefix to an attribute name does not break OGNL processing. For example, you can name a parameter trueParameter. Reserved keywords are not case-sensitive.

IMPORTANT The use of OGNL expressions in workflow presentations is deprecated as of Orchestrator 4.1. Using OGNL expressions in workflow presentations is not supported in releases of Orchestrator later than

4.1.

You cannot use the following keywords in workflow attribute and parameter names.

18 VMware, Inc.

Chapter 1 Developing Workflows

Table 1‑2. Forbidden Keywords in Attribute and Parameter Names

Forbidden Keyword Forbidden Keyword Forbidden Keyword

abstract

back_char_esc

back_char_literal

boolean

byte

char

char_literal

class

_classResolver

const

context

debugger

dec_digits

dec_flt

default

delete

digit

double

dynamic_subscript

enum

eof

esc

exponent

export

extends

false

final

flt_literal

flt_suff

ident

implements

import

int

int_literal

interface

_keepLastEvaluation

_lastEvaluation

letter

long

_memberAccess

native

package

private

public

root

short

static

string_esc

string_literal

synchronized

this

_traceEvaluations

true

_typeConverter

volatil

with

WithinBackCharLiteral

WithinCharLiteral

WithinStringLiteral

Workflow Schema

View Workflow Schema on page 20

You view the schema of a workflow in the Schema tab for that workflow in the Orchestrator client.

Building a Workflow in the Workflow Schema on page 20

Workflow schemas consist of a sequence of schema elements. Workflow schema elements are the building blocks of the workflow, and can represent decisions, scripted tasks, actions, exception handlers, or even other workflows.

Schema Elements on page 23

The workflow editor presents the workflow schema elements in menus in the Schema tab.

Schema Element Properties on page 26

Schema elements have properties that you can define and edit in the Schema tab of the workflow palette.

Links and Bindings on page 29

Links between elements determine the logical flow of the workflow. Bindings populate elements with data from other elements by binding input and output parameters to workflow attributes.

Decisions on page 34

Workflows can implement decision functions that define different courses of action according to a Boolean true or false statement.

Exception Handling on page 37

Exception handling catches any errors that occur when a schema element runs. Exception handling defines how the schema element behaves when the error occurs.

VMware, Inc. 19

Developing with VMware vCenter Orchestrator

Foreach Elements and Composite Types on page 38

You can insert a Foreach element in the workflow that you develop to run a subworkflow that iterates over arrays of parameters or attributes. To improve the understanding and readability of the workflow, you can group several workflow parameters of different types that are logically connected in a single type that is called a composite type.

View Workflow Schema

You view the schema of a workflow in the Schema tab for that workflow in the Orchestrator client.

Procedure

1 Navigate to a workflow in the workflow hierarchical list.

2 Click the workflow.

Information about that workflow appears in the right pane.

3 Select the Schema tab in the right pane.

You see the graphical representation of the workflow.

Building a Workflow in the Workflow Schema

You build workflows in the workflow editor by dragging schema elements from the workflow palette on the left of the workflow editor into the workflow schema diagram.

Edit a Workflow Schema

You build a workflow by creating a sequence of schema elements that define the logical flow of the workflow.

By default, all elements in the workflow schema are linked. Links between the elements are represented as arrows. When you add a new element to the workflow schema, you must drag it onto an arrow or an existing workflow element that is not linked to a next element. After you add workflow elements to the schema, you can delete existing links and create new links to define the logical flow of the workflow.

You can copy an element or a selection of elements from the schema of an existing workflow to the schema of the workflow that you are editing. See “Copy Workflow Schema Elements,” on page 21.

A workflow schema must have at least one End workflow element, but it can have several.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 Click the Schema tab in the workflow editor.

2 Drag a schema element from the Generic menu in the left pane, to the workflow schema.

3 Double-click the element you dragged to the workflow schema, type an appropriate name, and press

Enter.

You must provide elements with unique names in the context of the workflow.

You cannot rename Waiting timer, Waiting event, End workflow, or Throw exception elements.

4 (Optional) Right-click an element in the schema and select Copy.

20 VMware, Inc.

Chapter 1 Developing Workflows

5 (Optional) Right-click at an appropriate position in the schema and select Paste.

Copying and pasting existing schema elements is a quick way of adding similar elements to the schema. All of the settings of the copied element appear in the pasted element, except for the business state. Adjust the pasted element settings accordingly.

6 Drag schema elements from the Basic, Log, or Network menus to the workflow schema.

You can edit the names of the elements in the Basic, Log, or Network menus. You cannot edit their scripting.

7 Drag schema elements from the Generic menu to the workflow schema.

When you drag actions or workflows to the workflow schema, a dialog box in which you can search for the action or workflow to insert appears.

8 In the Filter text box, type the name or part of the name of the workflow or action to insert in the

workflow.

The workflows or actions that match the search appear in the dialog box.

9 Double-click a workflow or action to select it.

You inserted the workflow or action in the workflow schema.

10 Repeat this procedure until you have added all of the required schema elements to the workflow

schema.

What to do next

Define the properties of the elements you added to the workflow schema and link and bind them all together.

Copy Workflow Schema Elements

You can copy an element or a selection of elements from the schema of an existing workflow to the schema of the workflow that you are editing.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 Click the Schema tab in the workflow editor.

2 From the left pane, select the workflow from which you want to copy schema elements.

Click All Workflows and select the workflow from the hierarchical list of workflows.

Type the name of the workflow in the search text box and press Enter.

3 Right-click the selected workflow and select Open.

A window displaying the workflow's properties appears.

4 In the workflow's window, click the Schema tab.

5 Select one or more workflow schema elements, right-click the selection, and select Copy.

6 In the Schema tab of the workflow that you are editing, right-click and select Paste.

You copied workflow schema elements from one workflow to another.

What to do next

You must link and bind the copied schema elements to the existing workflow schema.

VMware, Inc. 21

Developing with VMware vCenter Orchestrator

Promote Input and Output Parameters

You can promote the input and output parameters of a child element to the parent workflow.

You can promote a custom attribute that you have defined on the General tab of the workflow editor. You can promote predefined attributes only by replacing an input parameter with an attribute of matching type.

NOTE If you promote a predefined attribute and assign a custom value to it, a duplicate attribute is created to avoid overwriting the value of the original attribute. The duplicate attribute retains the name of the original attribute and increments the numerical value at the end of the attribute's name.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 Click the Schema tab in the workflow editor.

2 Add a workflow or an action element to the workflow schema.

The following notification appears at the top of the schema pane.

Do you want to add the activity's parameters as input/output to the current workflow?

3 On the notification, click Setup.

A pop-up window with the available options appears.

4 Select the mapping type for each input parameter.

Option Description

Input

Skip

Value

The argument is mapped to an input workflow parameter.

The argument is mapped to a NULL value.

The argument is mapped to an attribute with a value that you can set from the Value column.

5 Select the mapping type for each output parameter.

Option Description

Output

Skip

Local variable

The argument is mapped to an output workflow parameter.

The argument is mapped to a NULL value.

The argument is mapped to an attribute.

6 Click Promote.

You promoted parameters to the parent workflow.

Modify Search Results

You use the Search text box to find elements such as workflows or actions. If a search returns a partial result, you can modify the number of results that the search returns.

When you use the search for an element, a green message box indicates that the search lists all the results. A yellow message box indicates that the search lists only partial results.

Procedure

1 (Optional) If you are editing a workflow in the workflow editor, click Save and Close to exit the editor.

22 VMware, Inc.

2 From the Orchestrator client menu, select Tools > User preferences.

3 Click the General tab.

4 Type the number of results for searches to return in the Finder Maximum Size text box.

5 Click Save and Close in the User Preferences dialog box.

You modified the number of results that searches return.

Schema Elements

The workflow editor presents the workflow schema elements in menus in the Schema tab.

You can use the schema elements available in the Schema tab to build a workflow.

Table 1‑3. Schema Elements and Icons

Schema Element Name Description Icon

Start Workflow The starting point of the workflow. All

workflows contain this element and it cannot be removed from the workflow schema. A workflow can have only one start element. Start elements have one output and no input.

Scriptable task General purpose tasks you define. You

write JavaScript functions in this element.

Chapter 1 Developing Workflows

Location in Workflow Editor

Always present in the

Schema tab

Generic workflow palette

Decision Boolean function. Decision elements take

one input parameter and return either true or false. The type of decision that the element makes, depends on the type of the input parameter. Decision elements allow the workflow to branch into different directions, depending on the input parameter the decision element receives. If the received input parameter corresponds to an expected value, the workflow continues along a certain route. If the input is not the expected value, the workflow continues on an alternative path.

Custom decision Boolean function. Custom decisions can

take several input parameters and process them according to custom scripts. Returns either true or false.

Decision activity Boolean function. A decision activity runs a

workflow and binds its output parameters to a true or a false path.

Generic workflow palette

VMware, Inc. 23

Developing with VMware vCenter Orchestrator

Table 1‑3. Schema Elements and Icons (Continued)

Schema Element Name Description Icon

User interaction Allows users to pass new input parameters

into the workflow. You can design how the user interaction element presents the request for input parameters and place constraints on the parameters that users can provide. You can set permissions to determine which users can provide the input parameters. When a running workflow arrives at a user interaction element, it enters a passive state and prompts the user for input. You can set a timeout period within which the users can answer. The workflow resumes according to the data the user passes to it, or returns an exception if the timeout period expires. While it is waiting for the user to respond, the workflow token is in the waiting state.

Waiting timer Used by long-running workflows. When a

running workflow arrives at a Waiting Timer element it enters a passive state. You set an absolute date at which the workflow resumes running. While it is waiting for the date, the workflow token is in the waiting-signal state.

Waiting event Used in long-running workflows. When a

running workflow arrives at a Waiting Event element it enters a passive state. You define a trigger event that the workflow awaits before it resumes running. While it is waiting for the event, the workflow token is in the waiting-signal state.

End workflow The end point of the workflow. You can

have multiple end elements in a schema, to represent the different possible outcomes of the workflow. End elements have one input with no output. When a workflow reaches an End Workflow element, the workflow token enters the completed state.

Thrown exception Creates an exception and stops the

workflow. Multiple occurrences of this element can be present in the workflow schema. Exception elements have one input parameter, which can only be of the String type, and have no output parameter. When a workflow reaches an Exception element, the workflow token enters the failed state.

Workflow note Allows you to annotate sections of the

workflow. You can stretch notes to delineate sections of the workflow. You can change the background color of the notes to differentiate between different workflow zones. Workflow notes provide visual information only, to help you understand the schema.

Location in Workflow Editor

Generic workflow palette

24 VMware, Inc.

Table 1‑3. Schema Elements and Icons (Continued)

Schema Element Name Description Icon

Action element Calls on an action from the Orchestrator

libraries of actions. When a workflow reaches an action element, it calls and runs that action.

Workflow element Starts another workflow synchronously. As

soon as a workflow reaches a workflow element in its schema, it runs that workflow as part of its own process. The original workflow does not continue until the called workflow completes its run.

Foreach element Runs a workflow on every element from an

array. For example, you can run the Raname Virtual Machine workflow on all virtual machines from a folder.

Asynchronous workflow

Starts a workflow asynchronously. When a workflow reaches an asynchronous workflow element, it starts that workflow and continues its own run. The original workflow does not wait for the called workflow to finish before continuing.

Schedule workflow Creates a task to run the workflow at a set

time, then the workflow continues its run.

Chapter 1 Developing Workflows

Location in Workflow Editor

Generic workflow palette

VMware, Inc. 25

Developing with VMware vCenter Orchestrator

Table 1‑3. Schema Elements and Icons (Continued)

Schema Element Name Description Icon

Nested workflows Starts several workflows simultaneously.

You can choose to nest local workflows and remote workflows that are in a different Orchestrator server. You can also run workflows with different credentials. The workflow waits until all the nested workflows complete before it continues its run.

Pre-Defined Task Noneditable scripted elements that

perform standard tasks that workflows commonly use. The following tasks are predefined:

Basic

Sleep

Change credential

Wait until date

Wait for custom event

Increase counter

Decrease counter

Log

System log

System warning

System error

Server log

Server warning

Server error

System+server log

System+server warning

System+server error

Network

HTTP post

HTTP get

Send custom event

Location in Workflow Editor

Generic workflow palette

Basic, Log, and Network

workflow palette

Schema Element Properties

Schema elements have properties that you can define and edit in the Schema tab of the workflow palette.

Edit the Global Properties of a Schema Element

You define the global properties of a schema element in the element's Info tab.

Prerequisites

Verify that the Schema tab of the workflow editor contains elements.

Procedure

1 Click the Schema tab in the workflow editor.

Select an element to edit by clicking the Edit icon ( ).

A dialog box that lists the properties of the element appears.

3 Click the Info tab.

26 VMware, Inc.

Chapter 1 Developing Workflows

4 Provide a name for the schema element in the Name text box.

This is the name that appears in the schema element in the workflow schema diagram.

5 From the Interaction drop-down menu, select a description.

The Interaction property allows you to select between standard descriptions of how this element interacts with objects outside of the workflow. This property is for information only.

6 (Optional) Provide a business status description in the Business Status text box.

The Business Status property is a brief description of what this element does. When a workflow is running, the workflow token shows the Business Status of each element as it runs. This feature is useful for tracking workflow status.

7 (Optional) In the Description text box, type a description of the schema element.

Schema Element Properties Tabs

You access the properties of a schema element by clicking on an element that you have dragged into the workflow schema. The properties of the element appear in tabs at the bottom of the workflow editor.

Different schema elements have different properties tabs.

Table 1‑4. Properties Tabs per Schema Element

Schema Element Property Tab Description Applies to Schema Element Type

Attributes Attributes that elements require

from an external source, such as the user, an event, or a timer. The attributes can be a timeout limit, a time and date, a trigger, or user credentials.

Decision Defines the decision statement.

The input parameter that the decision element receives either matches or does not match the decision statement, resulting two possible courses of action.

End Workflow Stops the workflow, either

because the workflow completed successfully, or because it encountered an error and returned an exception.

Exception How this schema element

behaves in the event of an exception.

External Inputs Input parameters that the user

must provide at a certain moment while the workflow runs.

User Interaction

Waiting Event

Waiting Timer

Decision

End

Exception

Action

Asynchronous Workflow

Exception

Nested Workflows

Predefined Task

Schedule Workflow

Scriptable Task

User Interaction

Waiting Event

Waiting Timer

Workflow

User Interaction

VMware, Inc. 27

Developing with VMware vCenter Orchestrator

Table 1‑4. Properties Tabs per Schema Element (Continued)

Schema Element Property Tab Description Applies to Schema Element Type

IN The IN binding for this

Info The schema element's general

OUT The OUT binding for this

Presentation Defines the layout of the input

Scripting Shows the JavaScript function

Visual Binding Shows a graphical

Workflows Selects the workflows to nest. Nested Workflows

element. The IN binding defines the way in which the schema element receives input from the element that precedes it in the workflow.

properties and description. The information the Info tab displays depends on the type of schema element.

element. The OUT binding defines the way in which the schema element binds output parameters to the workflow attributes or to the workflow output parameters.

parameters dialog box the user sees if the workflow needs user input while it is running.

that defines the behavior of this schema element. For Asynchronous Workflow, Schedule Workflow, and Action elements this scripting is readonly. For scriptable task and custom decision elements, you edit the JavaScript in this tab.

representation of how the parameters and attributes of this schema element bind to the parameters and attributes of the elements that come before and after it in the workflow. This is another representation of the element's IN and OUT bindings.

Action

Asynchronous Workflow

Custom Decision

Predefined Task

Schedule Workflow

Scriptable Task

Workflow

Action

Asynchronous Workflow

Custom Decision

Decision

Nested Workflows

Note

Predefined Task

Schedule Workflow

Scriptable Task

User Interaction

Waiting Event

Waiting Timer

Workflow

Action

Asynchronous Workflow

Predefined Task

Schedule Workflow

Scriptable Task

Workflow

User Interaction

Action

Asynchronous Workflow

Custom Decision

Predefined Task

Schedule Workflow

Scriptable Task

Action

Asynchronous Workflow

Predefined Task

Schedule Workflow

Scriptable Task

Workflow

28 VMware, Inc.

Chapter 1 Developing Workflows

Links and Bindings

Links between elements determine the logical flow of the workflow. Bindings populate elements with data from other elements by binding input and output parameters to workflow attributes.

To understand links and bindings, you must understand the difference between the logical flow of a workflow and the data flow of a workflow.

Logical Flow of a Workflow

The logical flow of a workflow is the progression of the workflow from one element to the next in the schema as the workflow runs. You define the logical flow of the workflow by linking elements in the schema.

The standard path is the path that the workflow takes through the logical flow if all elements run as expected. The exception path is the path that the workflow takes through the logical flow if an element does not run as expected.

Different styles of arrows in the workflow schema denote the different paths that the workflow can take through its logical flow.

A blue arrow denotes the standard path that the workflow takes from one element to the next.

A green arrow denotes the path that the workflow takes if a Boolean decision element returns true.

A red dotted arrow denotes the path that the workflow takes if a Boolean decision element returns

false.

A red dashed arrow denotes the exception path that the workflow takes if a workflow element does not

run correctly.

The following figure shows an example workflow schema that demonstrates the different paths that workflows can take.

Figure 1‑1. Different Workflow Paths Through the Logical Flow of the Workflow

VMware, Inc. 29

Developing with VMware vCenter Orchestrator

This example workflow can take the following paths through its logical flow.

Standard path, true decision result, no exceptions.

a The decision element returns true.

b The SnapVMsInResourcePool workflow runs successfully.

c The sendHtmlEmail action runs successfully.

d The workflow ends successfully in the completed state.

Standard path, false decision result, no exceptions.

a The decision element returns false.

b The operation the scriptable task element defines runs successfully.

c The sendHtmlEmail action runs successfully.

d The workflow ends successfully in the completed state.

true decision result, exception.

a The decision element returns true.

b The SnapVMsInResourcePool workflow encounters an error.

c The workflow returns an exception and stops in the failed state.

false decision result, exception.

a The decision element returns false.

b The operation the Scriptable task element defines encounters an error.

c The workflow returns an exception and stops in the failed state.

Element Links

Links connect schema elements and define the logical flow of the workflow from one element to the next.

Elements can usually set only one outgoing link to another element in the workflow and one exception link to an element that defines its exception behavior. The outgoing link defines the standard path of the workflow. The exception link defines the exception path of the workflow. In most cases, a single schema element can receive incoming standard path links from multiple elements.

The following elements are exceptions to the preceding statements.

The Start Workflow element cannot receive incoming links and has no exception link.

Exception elements can receive multiple incoming exception links, and have no outgoing or exception

links.

Decision elements have two outgoing links that define the paths the workflow takes depending on the

decision's true or false result. Decisions have no exception link.

End Workflow elements cannot have outgoing links or exception links.

Create Standard Path Links

Standard path links determine the normal run of the workflow.

When you link one element to another, you always link the elements in the order in which they run in the workflow. You always start from the element that runs first to create a link between two elements.

Prerequisites

Open a workflow for editing in the workflow editor.

30 VMware, Inc.

Chapter 1 Developing Workflows

Verify that the Schema tab of the workflow editor contains elements.

Procedure

1 Place the pointer on the element that you want to connect to another element.

A blue and a red arrow appear on the element's right.

2 Place the pointer on the blue arrow.

The blue arrow enlarges.

3 Left-click the blue arrow, hold down the left mouse button, and move the pointer to the target element.

A blue arrow appears between the two elements and a green rectangle appears around the target element.

4 Release the left mouse button.

The blue arrow remains between the two elements.

A standard path now links the elements.

What to do next

The elements are joined, but you have not defined the data flow. You must define the IN and OUT bindings to bind incoming and outgoing data to workflow attributes.

Data Flow of a Workflow

The data flow of a workflow is the manner in which workflow element input and output parameters bind to workflow attributes as each element of the workflow runs. You define the data flow of a workflow by using schema element bindings.

When an element in the workflow schema runs, it requires data in the form of input parameters. It takes the data for its input parameters by binding to a workflow attribute that you set when you create the workflow, or by binding to an attribute that a preceding element in the workflow set when it ran.

The element processes the data, possibly transforms it, and generates the results of its run in the form of output parameters. The element binds its resulting output parameters to new workflow attributes that it creates. Other elements in the schema can bind to these new workflow attributes as their input parameters. The workflow can generate the attributes as its output parameters at the end of its run.

The following figure shows a very simple workflow. The blue arrows represent the element linking and the logical flow of the workflow. The red lines show the data flow of the workflow.

VMware, Inc. 31

Developing with VMware vCenter Orchestrator

Figure 1‑2. Example of Workflow Data Flow

The data flows through the workflow as follows.

1 The workflow starts with input parameters a and b.

2 The first element processes parameter a and binds the result of the processing to workflow attribute c.

3 The first element processes parameter b and binds the result of the processing to workflow attribute d.

4 The second element takes workflow attribute c as an input parameter, processes it, and binds the

resulting output parameter to workflow attribute e.

5 The second element takes workflow attribute d as an input parameter, processes it, and generates

output parameter f.

6 The workflow ends and generates workflow attribute f as its output parameter, the result of its run.

32 VMware, Inc.

Chapter 1 Developing Workflows

Element Bindings

You must bind all workflow element input and output parameters to workflow attributes. Bindings set data in the elements, and define the output and exception behavior of the elements. Links define the logical flow of the workflow, whereas bindings define the data flow.

To set data in an element, generate output parameters from the element after processing, and handle any errors that might occur when the element runs, you must set the element binding.

IN bindings

Set a schema element's incoming data. You bind the element's local input parameters to source workflow attributes. The IN tab lists the element's input parameters in the Local Parameter column. The IN tab lists the workflow attributes to which the local parameter binds in the Source Parameter column. The tab also displays the parameter type and a description of the parameter.

OUT bindings

Change workflow attributes and generate output parameters when an element finishes its run. The OUT tab lists the element's output parameters in the Local Parameter column. The OUT tab lists the workflow attributes to which the local parameter binds in the Source Parameter column. The tab also displays the parameter type and a description of the parameter.

Exception bindings

Link to exception handlers if the element encounters an exception when it runs.

IN bindings read values from the bound source parameter. OUT bindings write values into the bound source

parameter.

You must use IN bindings to bind every attribute or input parameter you use in a schema element to a workflow attribute. If the element changes the values of the input parameters that it receives when it runs, you must bind them to a workflow attribute by using an OUT binding. Binding the element's output parameters to workflow elements lets other elements that follow it in the workflow schema to take those output parameters as their input parameters.

A common mistake when creating workflows is to not bind output parameter values to reflect the changes that the element makes to the workflow attributes.

IMPORTANT When you add an element that requires input and output parameters of a type that you have already defined in the workflow, Orchestrator sets the bindings to these parameters. You must verify that the parameters that Orchestrator binds are correct, in case the workflow defines different parameters of the same type to which the element can bind.

Define Element Bindings

After you link elements to create the logical flow of the workflow, you define element bindings to define how each element processes the data it receives and generates.

Prerequisites

Verify that you have a workflow schema in the Schema tab of the workflow editor, and that you have created links between the elements.

Procedure

Click the Edit icon (

A dialog box that lists the properties of the element appears.

VMware, Inc. 33

) of the element on which to set the bindings.

Developing with VMware vCenter Orchestrator

2 Click the IN tab.

The contents of the IN tab depend on the type of element you selected.

If you selected a predefined task, workflow, or action element, the IN tab lists the possible local

input parameters for that type of element, but the binding is not set.

If you selected another type of element, you can select from a list of input parameters and

attributes you already defined for the workflow by right-clicking in the IN tab and selecting Bind to workflow parameter/attribute.

If the required attribute does not exist yet, you can create it by right-clicking in the IN tab and

selecting Bind to workflow parameter/attribute > Create parameter/attribute in workflow.

3 If an appropriate parameter exists, choose an input parameter to bind, and click the Not set button in

the Source Parameter text box.

A list of possible source parameters and attributes to bind to appears.

4 Choose a source parameter to bind to the local input parameter from the list proposed.

5 (Optional) If you have not defined the source parameter to which to bind, you can create it by clicking

the Create parameter/attribute in workflow link in the parameter selection dialog box.

6 Click the OUT tab.

The contents of the OUT tab depend on the type of element you selected.

If you selected a predefined task, workflow, or action element, the OUT tab lists the possible local

output parameters for that type of element, but the binding is not set.

If you selected another type of element, you can select from a list of output parameters and

attributes you defined for the workflow by right-clicking in the OUT tab and selecting Bind to workflow parameter/attribute.

If the required attribute does not exist, you can create it by right-clicking in the IN tab and selecting

Bind to workflow parameter/attribute > Create parameter/attribute in workflow.

7 Choose a parameter to bind.

8 Click the Source Parameter > Not set button.

9 Choose a source parameter to bind to the input parameter.

10 (Optional) If you did not define the parameter to which to bind, you can create it by clicking the Create

parameter/attribute in workflow button in the parameter selection dialog box.

You defined the input parameters that the element receives and the output parameters that it generates, and bound them to workflow attributes and parameters.

What to do next

You can create forks in the path of the workflow by defining decisions.

Decisions

Workflows can implement decision functions that define different courses of action according to a Boolean

true or false statement.

Decisions are forks in the workflow. Workflow decisions are made according to inputs provided by you, by other workflows, by applications, or by the environment in which the workflow is running. The value of the input parameter that the decision element receives determines which branch of the fork the workflow takes. For example, a workflow decision might receive the power status of a given virtual machine as its input. If the virtual machine is powered on, the workflow takes a certain path through its logical flow. If the virtual machine is powered off, the workflow takes a different path.

34 VMware, Inc.

Chapter 1 Developing Workflows

Decisions are always Boolean functions. The only possible outcomes for each decision are true or false.

Custom Decisions

Custom decisions differ from standard decisions in that you define the decision statement in a script. Custom decisions return true or false according to the statement you define, as the following example shows.

if (decision_statement){ return true; }else{ return false; }

Create Decision Element Links

Decision elements differ from other elements in a workflow. They have only true or false output parameters. Decision elements have no exception linking.

Prerequisites

Verify that the Schema tab of the workflow editor contains elements, including at least one decision element that is not linked to other elements.

Procedure

1 Place the mouse pointer on a decision element to link it to two other elements that define two possible

branches in the workflow.

A blue arrow and a red arrow appear on the element's right.

2 Place the pointer on the blue arrow, and while keeping the left mouse button pressed, move the pointer

to the target element.

A green arrow appears between the two elements and the target element turns green. The green arrow represents the true path the workflow takes if the input parameter or attribute received by the decision element matches the decision statement.

3 Release the left mouse button.

The green arrow remains between the two elements. You have defined the path the workflow takes when the decision element receives the expected value.

4 Place the pointer on the decision element, hold down the left mouse button, and move the pointer to the

target element.

A dotted red arrow appears between the two elements and the target element turns green. The red arrow represents the false path that the workflow takes if the input parameter or attribute received by the decision element does not match the decision statement.

5 Release the left mouse button.

The dotted red arrow remains between the two elements. You have defined the path the workflow takes when the decision element receives unexpected input.

You have defined the possible true or false paths that the workflow takes depending on the input parameter or attribute the decision element receives.

What to do next

Define the decision statement. See “Create Workflow Branches Using Decisions,” on page 36.

VMware, Inc. 35

Developing with VMware vCenter Orchestrator

Delete a Linked Decision Element

When you delete a linked decision element from a workflow schema, you must specify which workflow paths to delete.

Prerequisites

Verify that the Schema tab of the workflow editor contains elements, including at least one decision element with true and false paths.

Procedure

1 Select the decision element and press Delete.

A dialog box with available options appears.

2 Select which decision branch to delete.

Option Description

Success branch

Failure branch

Both branches

None

3 Click OK.

The decision element and all elements that follow the true decision path are deleted from the workflow schema.

The decision element and all elements that follow the false decision path are deleted from the workflow schema.

The decision element and all elements that follow both decision paths are deleted from the workflow schema.

Only the decision element and its links are deleted from the workflow schema. All elements that follow both decision paths remain in the workflow schema.

Create Workflow Branches Using Decisions

Decision elements are simple Boolean functions that you use to create branches in workflows. Decision elements determine whether the input received matches the decision statement you set. As a function of this decision, the workflow continues its course along one of two possible paths.

Prerequisites

Verify that you have a decision element linked to two other elements in the schema in the workflow editor before you define the decision.

Procedure

Click the Edit icon ( ) of the decision element.

A dialog box that lists the properties of the decision element appears.

2 Click the Decision tab in the dialog box.

3 Click the Not Set (NULL) link to select the source input parameter for this decision.

A dialog box that lists all the attributes and input parameters defined in this workflow appears.

4 Select an input parameter from the list by double-clicking it.

5 If you did not define the source parameter to which to bind, create it by clicking the Create

attribute/parameter in workflow link in the parameter selection dialog box.

36 VMware, Inc.

Chapter 1 Developing Workflows

6 Select a decision statement from the drop-down menu.

The statements that the menu proposes are contextual, and differ according to the type of input parameter selected.

7 Add a value that you want the decision statement to match.

Depending on the input type and the statement you select, you might see a Not Set (NULL) link in the value text box. Clicking this link gives you a predefined choice of values. Otherwise, for example for Strings, this is a text box in which you provide a value.

You defined a statement for the decision element. When the decision element receives the input parameter, it compares the value of the input parameter to the value in the statement and determines whether the statement is true or false.

What to do next

You must set how the workflow handles exceptions.

Exception Handling

Exception handling catches any errors that occur when a schema element runs. Exception handling defines how the schema element behaves when the error occurs.

All elements in a workflow, except for decisions and start and end elements, contain a specific output parameter type that serves only for handling exceptions. If an element encounters an error during its run, it can send an error signal to an exception handler. Exception handlers catch the error and react according to the errors they receive. If the exception handlers you define cannot handle a certain error, you can bind an element's exception output parameter to an Exception element, which ends the workflow run in the failed state.

Exceptions act as a try and catch sequence within a workflow element. If you do not need to handle a given exception in an element, you do not have to bind that element's exception output parameter.

The output parameter type for exceptions is always an errorCode object.

Create Exception Bindings

Elements can set bindings that define how the workflow behaves if it encounters an error in that element.

Prerequisites

Verify that the Schema tab of the workflow editor contains elements.

Procedure

1 Place the pointer on the element for which you want to define exception binding.

A blue and a red arrow appear on the element's right.

2 Place the pointer on the red arrow until it enlarges, hold down the left mouse button, and drag the red

arrow to the target element.

A red dashed arrow links the two elements. The target element defines the behavior of the workflow if the element that links to it encounters an error.

3 Click the element that links to the exception handling element.

4 Click the Exceptions tab in the schema element properties tabs at the bottom of the Schema tab.

VMware, Inc. 37

Developing with VMware vCenter Orchestrator

5 Click the Not set button to set the Output Exception Binding value.

Select a parameter to bind to the exception output parameter from the exception attribute binding

dialog box.

Click Create parameter/attribute in workflow to create an exception output parameter.

6 Click the target element that defines the exception handling behavior.

7 Click the IN tab in the schema element properties tabs at the bottom of the Schema tab.

8 Right-click in the IN tab and select Bind to workflow parameter/attribute.

9 Select the exception output parameter and click Select.

10 Click the OUT tab for the exception handling element in the schema element properties tabs at the

bottom of the Schema tab

11 Define the behavior of the exception handling element.

Right-click in the OUT tab and select Bind to workflow parameter/attribute to select an output

parameter for the exception handling element to generate.

Click the Scripting tab and use JavaScript to define the behavior of the exception handling element.

You defined how the element handles exceptions.

What to do next

You must define how to obtain input parameters from users when they run the workflow.

Foreach Elements and Composite Types

Using Foreach Elements

A Foreach element runs a subworkflow iteratively over an array of input parameters or attributes. You can select the arrays over which the subworkflow is run, and can pass the values for the elements of such an array when you run the workflow. The subworkflow runs as many times as the number of elements that you have defined in the array.

If you have a configuration element that contains an array of attributes, you can run a workflow that iterates over these attributes in a Foreach element.

For example, suppose that you have 10 virtual machines in a folder that you want to rename. To do this, you must insert a Foreach element in a workflow and define the Rename virtual machine workflow as a subworkflow in the element. The Rename virtual machine workflow takes two input parameters, a virtual machine and its new name. You can promote these parameters as input to the current workflow, and as a result, they become arrays over which the Rename virtual machine workflow will iterate. When you run your workflow, you can specify the 10 virtual machines in the folder and their new names. Every time the workflow runs, it takes an element from the array of the virtual machines and an element from the array of the new names for the virtual machines.

Using Composite Types

A composite type is a group of more than one input parameter or attribute that are connected logically but are of different types. In a Foreach element, you can bind a group of parameters as a composite value. In this way, the Foreach element takes the values for the grouped parameters at once in every subsequent run of the workflow.

38 VMware, Inc.

Chapter 1 Developing Workflows

For example, suppose that you are about to rename a virtual machine. You need the virtual machine object and its new name. If you have to rename multiple virtual machines, you need two arrays, one for the virtual machines and one for their names. These two arrays are not explicitly connected. A composite type lets you have one array where each element contains both the virtual machine and its new name. In this way, the connection between those two parameters in case of multiple values is specified explicitly and not implied by the workflow schema.

NOTE You cannot run a workflow that contains composite types from an Orchestrator Web view or from the vSphere Web Client.

Define a Foreach Element

If you want to run a subworkflow multiple times by passing different values for its parameters or attributes in every subsequent run, you can insert a Foreach element in the parent workflow.

When you insert a Foreach element, you must select at least one array over which the Foreach element iterates. An array element can have different values for each subsequent workflow run.

If the subworkflow has output parameters, you should select the output parameters of the Foreach element in which to accumulate workflow outputs , so that the subworkflow can iterate over them as well.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 In the workflow editor, select the Schema tab.

2 From the Generic menu, drag a Foreach element in the workflow schema.

3 Select a workflow from the Chooser dialog box.

The following notification appears at the top of the schema pane.

Do you want to add the activity's parameters as input/output to the current workflow?

4 On the notification, click Setup.

A pop-up window with the available options appears.

5 Select the mapping type for each input parameter.

Option Description

Input

Skip

Value

The argument is mapped to an input workflow parameter.

The argument is mapped to a NULL value.

The argument is mapped to an attribute with a value that you can set from the Value column.

6 Select the mapping type for each output parameter.

Option Description

Output

Skip

Local variable

The argument is mapped to an output workflow parameter.

The argument is mapped to a NULL value.

The argument is mapped to an attribute.

7 Click Promote.

8 Right-click the Foreach element and select Synchronize > Synchronize presentation.

A confirmation dialog box appears.

VMware, Inc. 39

Developing with VMware vCenter Orchestrator

9 Click Ok to propagate the presentation of the Foreach element to the current workflow.

A dialog box displays information about the outcome of the operation.

10 On the Inputs tab, verify that the subworkflow's parameters are added as elements of type array.

11 On the Outputs tab, verify that the subworkflow's parameters are added as elements of type array.

You defined a Foreach element in your workflow. The Foreach element runs a workflow that takes as parameters every element from the array of parameters or attributes that you have defined.

For parameters or attributes that are not defined as arrays, the workflow takes the same value in every subsequent run.

Example: Rename Virtual Machines by Using a Foreach Element

You can use a Foreach element to rename several virtual machines at once. You have to insert a Foreach element in a workflow and promote the vm and the newName parameters as input to the current workflow. In this way, when you run the workflow, you specify the virtual machines to rename and the new names for the virtual machines. The virtual machines are included as elements in the array that you created for the vm parameter. The new names for the virtual machines are included in the array that you created for the

newName parameter.

Define a Composite Type in a Foreach Element

You can group multiple workflow parameters that are connected logically in a new type that is called a composite type. You can use a Foreach element to bind a group of parameters as a composite value to connect several arrays of parameters in a single array.

Prerequisites

Open a workflow for editing in the workflow editor.

Verify that you have a Foreach element in your workflow.

Procedure

1 Select the IN or the OUT tab of the Foreach element.

2 Select a local parameter that you want to group with other local parameters in a composite type.

3 Click Bind a group of parameters as composite value at the top of the IN or the OUT tab.

4 In the Bindings pane, select the parameters that you want to group as a composite type.

5 Select Bind as iterator.

You have set the Foreach element to iterate over an array of the composite type.

6 Click Accept.

You defined a composite type and made sure that the workflow will iterate over an array of this composite type. Parameters that are grouped as a composite type are named composite_type_name.parameter_name. For example, if you create a snapshots composite type, the parameters that are group in the type can be

snapshots.vm[in-parameter] or snapshots.name[in-parameter]. Every element from the array of the

composite type contains a single instance of every parameter that you grouped in the composite type.

Example: Rename Virtual Machines

Suppose that you want to rename 10 virtual machines at a time. For this, you insert a Foreach element in a workflow and select the Rename virtual machine workflow in the element. You create a composite type to connect the vm and the newName parameters explicitly. You bind the composite type as an iterator, thus creating a single array that contains both the vm and the newName parameter.

40 VMware, Inc.

Chapter 1 Developing Workflows

Obtaining Input Parameters from Users When a Workflow Starts

The way you organize parameters in the Presentation tab translates into the input parameters dialog box when the workflow runs, and in the dialog box that opens when you run a workflow from a Web view.

The Presentation tab also allows you to add descriptions of the input parameters to help users when they provide input parameters. You can also set properties and constraints on parameters in the Presentation tab to limit the parameters that users provide. If the parameters the user provides do not meet the constraints you set in the Presentation tab, the workflow will not run.

4.1.

Creating the Input Parameters Dialog Box In the Presentation Tab on page 41

You define the layout of the dialog box in which users provide input parameters when they run a workflow in the Presentation tab of the workflow editor.

Setting Parameter Properties on page 43

Orchestrator allows you to define properties to qualify the input parameter values that users provide when they run workflows. The parameter properties you define impose limits on the types and values of the input parameters the users provide.

Creating the Input Parameters Dialog Box In the Presentation Tab

You define the layout of the dialog box in which users provide input parameters when they run a workflow in the Presentation tab of the workflow editor.

The Presentation tab allows you to group input parameters into categories and to define the order in which these categories appear in the input parameters dialog box.

Presentation Descriptions

You can add an associated description for each parameter or group of parameters, which appears in the input parameters dialog box. The descriptions provide information to the users to help them provide the correct input parameters. You can enhance the layout of the description text by using HTML formatting.

Defining Presentation Input Steps

By default, the input parameters dialog box lists all the required input parameters in a single list. To help users enter input parameters, you can define nodes, called input steps, in the presentation tab. Input steps group input parameters of a similar nature. The input parameters under an input step appear in a distinct section in the input parameters dialog box when the workflow runs.

Defining Presentation Display Groups

Each input step can have nodes of its own called display groups. The display groups define the order in which parameter input text boxes appear within their section of the input parameters dialog box. You can define display groups independently of input steps.

VMware, Inc. 41

Developing with VMware vCenter Orchestrator

Create the Presentation of the Input Parameters Dialog Box

You create the presentation of the dialog box in which users provide input parameters when they run a workflow in the Presentation tab in the workflow editor.

Prerequisites

Open a workflow for editing in the workflow editor.

Verify that the workflow has a defined list of input parameters.

Procedure

1 In the workflow editor, click the Presentation tab.

By default, all of the workflow's parameters appear under the main Presentation node in the order in which you create them.

2 Right-click the Presentation node and select Create new step.

A New Step node appears under the Presentation node.

3 Provide an appropriate name for the step and press Enter.

This name appears as a section header in the input parameters dialog box when the workflow runs.

4 Click the input step and add a description in the General tab in the bottom half of the Presentation tab.

This description appears in the input parameters dialog box to provide information to the users to help them provide the correct input parameters. You can enhance the layout of the description text by using HTML formatting.

5 Right-click the input step you created and select Create display group.

A New Group node appears under the input step node.

6 Provide an appropriate name for the display group and press Enter.

This name appears as a subsection header in the input parameters dialog box when the workflow runs.

7 Click the display group and add a description in the General tab in the bottom half of the Presentation

tab.

This description appears in the input parameters dialog box. You can enhance the layout of the description text by using HTML formatting. You can add a parameter value to a group description by using an OGNL statement, such as ${#param}.

8 Repeat the preceding steps until you have created all the input steps and display groups to appear in

the input parameters dialog box when the workflow runs.

9 Drag parameters from under the Presentation node to the steps and groups of your choice.

You created the layout of the input parameters dialog box through which users provide input parameter values when the workflow runs.

What to do next

You must set the parameter properties.

42 VMware, Inc.

Chapter 1 Developing Workflows

Setting Parameter Properties

Every parameter can have several properties. You define an input parameter's properties in the Properties tab for a given parameter in the Presentation tab.

Parameter properties validate the input parameters and modify the way that text boxes appear in the input parameters dialog box. Some parameter properties can create dependencies between parameters.

Static and Dynamic Parameter Property Values

A parameter property value can be either static or dynamic. Static property values remain constant. If you set a property value to static, you set or select the property's value from a list that the workflow editor generates according to the parameter type.

Dynamic property values depend on the value of another parameter or attribute. You define the functions by which dynamic properties obtain values by using an object graph navigation language (OGNL) expression. If a dynamic parameter property value depends on the value of another parameter property value and the other parameter property value changes, the OGNL expression recalculates and changes the dynamic property value.

4.1.

Set Parameter Properties

When a workflow starts, it validates input parameter values from users against any parameter properties that you set.

Prerequisites

Open a workflow for editing in the workflow editor.

Verify that the workflow has a defined list of input parameters.

Procedure

1 In the workflow editor, click the Presentation tab.

2 Click a parameter in the Presentation tab.

The parameter's General and Properties tabs appear at the bottom of the Presentation tab.

3 Click the parameter's Properties tab.

4 Right-click in the Properties tab and select Add property.

A dialog box opens, presenting a list of the possible properties for a parameter of the type selected.

5 Select a property from the list presented in the dialog box and click OK.

The property appears in the Properties tab.

VMware, Inc. 43

Developing with VMware vCenter Orchestrator

6 Under Value, make the property value either static or dynamic by selecting the corresponding symbol

from the drop-down menu.

Option Description

7 If you set the property value to static, you select a property value according to the type of parameter for

which you are setting the properties.

8 If you set the property value to dynamic, you define the function to obtain the parameter property

value by using an OGNL expression.

The workflow editor provides help writing the OGNL expression.

Click the icon to obtain a list of all the attributes and parameters defined by the workflow that this expression can call upon.

Click the icon to obtain a list of all the actions in the Orchestrator API that return an output parameter of the type for which you are defining the properties.

Clicking items in the proposed lists of parameters and actions adds them to the OGNL expression.

Static property

Dynamic property

9 Click Save at the bottom of the workflow editor.

You defined the properties of the workflow's input parameters.

What to do next

Validate and debug the workflow.

Workflow Input Parameter Properties

You can set parameter properties to constrain the input parameters that users provide when they run workflows.

Different parameter types can have different properties.

Table 1‑5. Workflow Input Parameter Properties

Parameter Property Parameter Type Description

Maximum string length String Sets a maximum length for the

parameter.

Minimum string length String Sets a minimum length for the

parameter.

Matching regular expression String Validates the input using a regular

expression.

Maximum number value Number Sets a maximum value for the

parameter.

Minimum number value Number Sets a minimum value for the

parameter.

Number format Number Formats the input for the parameter.

Mandatory input All simple types Makes the parameter mandatory.

44 VMware, Inc.

Chapter 1 Developing Workflows

Table 1‑5. Workflow Input Parameter Properties (Continued)

Parameter Property Parameter Type Description

Predefined answers All simple types Pre-defines a list of possible values for

the property as an array of simple types. You either define the array manually or the property calls an action that returns an array of objects of the appropriate type.

Predefined list of elements Any simple or complex types Pre-defines a list of possible values for

the property as an array of simple or complex types. Calls an action that returns an array of objects of the appropriate type.

Show parameter input Any simple or complex types Shows or hides a parameter text box in

the presentation dialog box, depending on the value of a preceding Boolean parameter.

Hide parameter input Any simple or complex types Similar to Show parameter input, but

takes the negative value of a previous Boolean parameter.

Matching expression Any parameter type obtained from a

plug-in

Show in inventory Any parameter type obtained from a

plug-in

Specify a root object to be shown in the chooser. Root object is provided from a parameter or attribute.

Select as Any parameter type obtained from a

Default value Any simple or complex types Default value for this parameter.

Custom validation OGNL scriptable validation If the OGNL expression returns a

Data binding Any simple or complex types Binds to a property that you have

Authorized only Any parameter type obtained from a

Multi-lines text input Any simple or complex types Allows users to enter multiple lines of

Any parameter type obtained from a plug-in

plug-in

The input parameter matches a given expression.

If set, you can run the present workflow on any object of this type by right-clicking it in the inventory view and selecting Run workflow.

Specifies the root object if the selector for this parameter is a hierarchical list selector.

Use a list or hierarchical list selector to select the parameter.

string, the validation shows this string as the text of the error result.

already defined in another parameter.

Only authorized users can access this parameter.

text in the input parameters dialog box.

Predefined Constant Values for OGNL Expressions

You can use predefined constants when you create OGNL expressions to obtain dynamic parameter property values.

Orchestrator defines the following constants for use in OGNL expressions.

VMware, Inc. 45

Developing with VMware vCenter Orchestrator

Table 1‑6. Predefined OGNL Constant Values

Constant Value Description

${#__current}

${#__username}

${#__userdisplayname}

${#__serverurl}

${#__datetime}

${#__date}

${#__timezone}

Current value of the custom validation property or matching expression property

User name of the user who started the workflow

Display name of the user who started the workflow

URL containing the IP address of the server from which the user starts the workflow. The URL consists of the server IP address and a lookup port:

{ServerIP}:{lookupPort}

Current date and time

Current date, with time set to 00:00:00

Current timezone

(Optional) Requesting User Interactions While a Workflow Runs

For example, if a certain event occurs while a workflow runs, the workflow can request human interaction to decide what course of action to take. The workflow waits before continuing, either until the user responds to the request for information, or until the waiting time exceeds a possible timeout period. If the waiting time exceeds the timeout period, the workflow returns an exception.

The default attributes for user interactions are security.group and timeout.date. When you set the

security.group attribute to a given LDAP user group, you limit the permission to respond to the user

interaction request to members of that user group.

When you set the timeout.date attribute, you set a time and date until which the workflow waits for the information from the user. You can set an absolute date, or you can create a scripted workflow element to calculate a time relative to the current time.

Procedure

1 Add a User Interaction to a Workflow on page 47

You request input parameters from users during a workflow run by adding a User Interaction schema element to the workflow. When a workflow encounters a User Interaction element, it suspends its run and waits for the user to provide the data that it requires.

2 Set the User Interaction security.group Attribute on page 47

The security.group attribute of a user interaction element sets which users or groups of users have permission to respond to the user interaction.

3 Set the timeout.date Attribute to an Absolute Date on page 48

You set the timeout.date attribute for a user interaction to set how long the workflow waits for a user to respond to a user interaction.

4 Calculate a Relative Timeout for User Interactions on page 49

You can calculate in a Date object a relative time and date at which a user interaction times out.

5 Set the timeout.date Attribute to a Relative Date on page 50

You can set the timeout.date attribute of a User Interaction element to a relative time and date by binding it to a Date object. You define the object in a scripted function.

46 VMware, Inc.

Chapter 1 Developing Workflows

6 Define the External Inputs for a User Interaction on page 51

You specify the information that users must provide during a workflow run as the input parameters of a user interaction.

7 Define User Interaction Exception Behavior on page 52

If a user does not provide the input parameters within the timeout period, the user interaction returns an exception. You can define the exception behavior in a scripted function.

8 Create the Input Parameters Dialog Box for the User Interaction on page 53

Users provide input parameters during a workflow run in an input parameters dialog box, in the same way that they provide input parameters when a workflow first starts.

9 Respond to a Request for a User Interaction on page 54

Workflows that require interactions from users during their run suspend their run either until the user provides the required information or until the workflow times out.

Add a User Interaction to a Workflow

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Drag a User Interaction element to the appropriate position in the workflow schema.

2 Click the User Interaction element to display its properties tabs in the bottom half of the Schema tab.

Click the Edit icon ( ) of the User Interaction element.

4 Provide a name and a description for the user interaction in the Info tab and click Close.

5 Click Save.

You added a user interaction element to a workflow. When the workflow reaches this element, it waits for information from the user before continuing its run.

What to do next

Set the security.group attribute of the user interaction to limit permission to respond to the user interaction to a user or user group. See “Set the User Interaction security.group Attribute,” on page 47.

Set the User Interaction security.group Attribute

The security.group attribute of a user interaction element sets which users or groups of users have permission to respond to the user interaction.

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Add some elements and a user interaction to the workflow schema.

VMware, Inc. 47

Developing with VMware vCenter Orchestrator

Identify an LDAP user group to respond to the user interaction request.

Procedure

Click the Edit icon ( ) of the User Interaction element in the workflow schema.

2 Click the Attributes tab for the user interaction.

3 Click Not set for the security.group source parameter to set which users can respond to the user

interaction.

4 (Optional) Select NULL to allow all users to respond to the request for user interaction.

5 To limit the permission to respond to a specific user or user group, click Create parameter/attribute in

workflow.

The Parameter information dialog box opens.

6 Name the parameter.

7 Select Create workflow ATTRIBUTE with the same name to create the LdapGroup attribute in the

workflow.

8 Click Not set for the parameter value to open the LdapGroup selection box.

9 Type the name of the LDAP user group in the Filter text box.

10 Select the LDAP user group from the list and click Select.

For example, selecting the Administrators group means that only members of that group can respond to this request for user interaction.

You limited the permission to respond to the user interaction request.

11 Click OK to close the Parameter information dialog box.

You set the security.group attribute for the user interaction.

What to do next

Set the timer.date attribute to set the timeout period for the user interaction.

To set the timeout to an absolute date and time, see “Set the timeout.date Attribute to an Absolute

Date,” on page 48.

To create a function to calculate a timeout that is relative to the current date and time, see “Calculate a

Relative Timeout for User Interactions,” on page 49.

Set the timeout.date Attribute to an Absolute Date

You set the timeout.date attribute for a user interaction to set how long the workflow waits for a user to respond to a user interaction.

You set an absolute time and date in the Date object. When the time on the given date arrives, the workflow that is waiting for a user interaction times out and ends in the Failed state. For example, you can set the user interaction to timeout at midday on February 12th. To calculate a timeout that is relative to the current time and date, see “Calculate a Relative Timeout for User Interactions,” on page 49.

Prerequisites

Open a workflow for editing in the workflow editor.

Add a user interaction element to the workflow schema.

Set the security.group attribute for the user interaction.

48 VMware, Inc.

Chapter 1 Developing Workflows

Procedure

Click the Edit icon ( ) of the User Interaction element in the workflow schema.

2 Click the Attributes tab for the user interaction.

3 Click Not set for the timeout.date source parameter to set the timeout parameter value.

4 (Optional) Select NULL to allow the user interaction to set the workflow to wait indefinitely for the user

to respond to the user interaction.

5 Click Create parameter/attribute in workflow to set the workflow to fail after a timeout period.

The Parameter information dialog box opens.

6 Name the parameter.

7 Select Create workflow ATTRIBUTE with the same name to create a Date attribute in the workflow.

8 Click Not set for the parameter Value.

9 Use the calendar to select an absolute date and time until which the workflow waits for the user to

respond.

10 Click OK to close the calendar.

11 Click OK to close the Parameter information dialog box.

You set the timeout.date attribute to an absolute date. The workflow times out if the user does not respond to the user interaction before this time and date.

What to do next

Define the external input parameters that the user interaction requires from the user. See “Define the

External Inputs for a User Interaction,” on page 51.

Calculate a Relative Timeout for User Interactions

You can calculate in a Date object a relative time and date at which a user interaction times out.

You can set an absolute time and date in a Date object. When the time on the given date arrives, the request for a user interaction times out. Alternatively, you can create a workflow element that calculates and generates a relative Date object according to a function that you define. For example, you can create a relative Date object that adds 24 hours to the current time.

Prerequisites

Open a workflow for editing in the workflow editor.

Add a user interaction element to the workflow schema.

Set the security.group attribute for the user interaction.

Procedure

1 Drag a Scriptable task element from the Generic menu to the schema of a workflow, before the element

that requires the relative Date object for its timeout.date attribute.

Click the Edit icon ( ) of the Scriptable task element in the workflow schema.

3 Provide a name and description for the scripted workflow element in the Info properties tab.

Click the OUT properties tab, and click the Bind to workflow parameter/attribute icon (

VMware, Inc. 49

Developing with VMware vCenter Orchestrator

5 Click Create parameter/attribute in workflow to create a workflow attribute.

a Name the attribute timerDate.

b Select Date from the list of attribute types.

c Select Create workflow ATTRIBUTE with the same name.

d Leave the attribute value set to Not set, because a scripted function will provide this value.

e Click OK.

6 Click the Scripting tab for the scripted workflow element.

7 Define a function to calculate and generate a Date object named timerDate in the scripting pad in the

Scripting tab.

For example, you can create a Date object by implementing the following JavaScript function, in which the timeout period is a relative delay in milliseconds.

timerDate = new Date(); System.log( "Current date : '" + timerDate + "'" ); timerDate.setTime( timerDate.getTime() + (86400 * 1000) ); System.log( "Timer will expire at '" + timerDate + "'" );

The preceding example JavaScript function defines a Date object that obtains the current date and time by using the getTime method and adds 86,400,000 milliseconds, or 24 hours. The Scriptable Task element generates this value as its output parameter.

8 Click Close.

9 Click Save.

You created a function that calculates a time and date relative to the current time and date and generates a

Date object. A User Interaction element can receive this Date object as an input parameter to set the timeout

period until which it waits for input from the user. When the workflow arrives at the User Interaction element, it suspends its run and waits either until the user provides the required information, or for 24 hours before it times out.

What to do next

You must bind the Date object to the User Interaction element's timeout.date parameter. See “Set the

timeout.date Attribute to a Relative Date,” on page 50.

Set the timeout.date Attribute to a Relative Date

You can set the timeout.date attribute of a User Interaction element to a relative time and date by binding it to a Date object. You define the object in a scripted function.

If you create a relative Date object in a scripted function, you can bind the timeout.date attribute of a user interaction to this Date object. For example, if you bind the timeout.date attribute to a Date object that adds 24 hours to the current time, the user interaction times out after waiting for 24 hours.

Prerequisites

Add a user interaction element to the workflow schema.

Set the security.group attribute for the user interaction.

Create a scripted function that calculates a relative time and date and encapsulates it in a Date object in

the workflow. See “Calculate a Relative Timeout for User Interactions,” on page 49.

50 VMware, Inc.

Chapter 1 Developing Workflows

Procedure

Click the Edit icon ( ) of the User Interaction element in the workflow schema.

2 Click the Attributes tab for the user interaction.

3 Click Not set for the timeout.date source parameter to set the timeout parameter value.

4 Select the Date object that encapsulates a relative time and date that you defined in a scripted function

and click Select.

You set the timeout.date attribute to a relative date and time that a scripted function calculates.

What to do next

Define the external input parameters that the user interaction requires from the user. See “Define the

External Inputs for a User Interaction,” on page 51.

Define the External Inputs for a User Interaction

You specify the information that users must provide during a workflow run as the input parameters of a user interaction.

When a workflow reaches a user interaction element, it waits until a user provides the information that the user interaction requires as its input parameters.

Prerequisites

Add a user interaction element to the workflow schema.

Set the security.group attribute for the user interaction.

Set the timer.date attribute for the user interaction

Procedure

Click the Edit icon ( ) of the User Interaction element in the workflow schema.

2 Click the External inputs tab.

Click the Bind to workflow parameter/attribute icon (

) to define the parameters that the user must

provide in the user interaction.

4 (Optional) If you already defined the input parameters in the workflow, select the parameters from the

proposed list.

5 Click Create parameter/attribute in workflow to create a workflow attribute to bind to the input

parameter that the user provides.

6 Give the parameter an appropriate name.

7 Select the input parameter type from the list of types by searching for an object type in the Filter box.

For example, if the user interaction requires the user to provide a virtual machine as an input parameter, select VC:VirtualMachine.

8 Select Create workflow ATTRIBUTE with the same name to bind the input parameter that the user

provides to a new attribute in the workflow.

9 Leave the input parameter value set to Not set.

The user provides this value when they respond to the user interaction during the workflow run.

10 Click OK to close the Parameter information dialog box.

VMware, Inc. 51

Developing with VMware vCenter Orchestrator

You defined the input parameters that the user provides during a user interaction.

What to do next

Define the exception behavior if the user interaction encounters an error. See “Define User Interaction

Exception Behavior,” on page 52.

Define User Interaction Exception Behavior

If a user does not provide the input parameters within the timeout period, the user interaction returns an exception. You can define the exception behavior in a scripted function.

If you do not define the action for the workflow to take if the user interaction times out, the workflow ends in the Failed state. Defining the exception behavior is a good workflow development practice.

Prerequisites

Add a user interaction element to the workflow schema.

Set the security.group and timer.date attributes for the user interaction.

Define the external input parameters of the user interaction.

Procedure

Click the Edit icon ( ) of the User Interaction element in the workflow schema.

2 Click the Exception tab.

3 Click Not set for the output exception binding.

4 Click Create parameter/attribute in workflow to create an exception attribute to which to bind the user

interaction.

The Parameter information dialog box opens.

5 Create an errorCode attribute.

An errorCode attribute has the following default properties:

Name: errorCode

Type: string

Create: Create workflow ATTRIBUTE with the same name

Value: Type an appropriate error message.

6 Click OK to close the Parameter information dialog box.

7 Drag a scriptable task element over the user interaction element in the workflow schema.

A red dashed arrow, which represents the exception link, appears between the two elements. The scriptable task element binds automatically to the errorCode attribute from the user interaction.

8 Double-click the scriptable task element and provide an appropriate name.

For example, Log timeout.

9 In the Scripting tab of the scriptable task element, write a JavaScript function to handle the exception.

For example, to record the timeout in the Orchestrator log, write the following function:

System.log("No response from user. Timed out.");

52 VMware, Inc.

Chapter 1 Developing Workflows

10 Link and bind the scriptable task element that handles exceptions to the element that follows it in the

workflow.

For example, link and bind the scriptable task element to a Throw exception element to end the workflow with an error.

You defined the exception behavior if the user interaction times out.

What to do next

Create the dialog box in which users provide input parameters. See “Create the Input Parameters Dialog

Box for the User Interaction,” on page 53.

Create the Input Parameters Dialog Box for the User Interaction

Users provide input parameters during a workflow run in an input parameters dialog box, in the same way that they provide input parameters when a workflow first starts.

You create the layout of the dialog box in the Presentation tab of the user interaction element, not in the Presentation tab for the whole workflow. The Presentation tab of the whole workflow creates the layout of the input parameters dialog box that appears when you start a workflow. The Presentation tab of the user interaction element creates the layout of the input parameters dialog box that opens when a workflow arrives at a user interaction element during its run.

Prerequisites

Add a user interaction element to the workflow schema.

Set the security.group and timer.date attributes for the user interaction.

Define the external input parameters of the user interaction.

Define the exception behavior.

Procedure

Click the Edit icon ( ) of the User Interaction element in the workflow schema.

2 Click the Presentation tab of the user interaction element.

The Presentation tab shows the external input parameters that you created for the user interaction.

3 (Optional) Right-click the Presentation node in the Presentation tab and select Create new step.

Steps allow you to create sections in the dialog box, with descriptions and headings under which you can organize the input parameters.

4 (Optional) Right-click the Presentation node in the Presentation tab and select Create display group.

Display groups allow you to sort the order in which input parameters appear in the steps, and allow you to add sub-headers and instructions to the dialog box.

5 Click an input parameter in the list and add a description of the input parameter in the General tab for

that parameter.

The description text that you type appears as a label in the input parameters dialog box to inform the user of the information they must provide when they respond to the user interaction.

6 Define input parameter properties.

Input parameter properties allow you to qualify the input parameter values that users can provide, and to determine parameter values dynamically by using OGNL expressions.

7 Click Save and close to close the workflow editor.

VMware, Inc. 53

Developing with VMware vCenter Orchestrator

You created the input parameters dialog box in which users provide input parameters to respond to a user interaction during a workflow run.

What to do next

For information about creating the presentation steps and groups and setting input parameter properties, see “Creating the Input Parameters Dialog Box In the Presentation Tab,” on page 41.

Respond to a Request for a User Interaction

Workflows that require interactions from users during their run suspend their run either until the user provides the required information or until the workflow times out.

Workflows that require user interactions define which users can provide the required information and direct the requests for interaction.

Prerequisites

Verify that at least one workflow is in the Waiting for User Interaction state.

Procedure

1 From the drop-down menu in the Orchestrator client, select Run.

2 Click the My Orchestrator view in the Orchestrator client.

3 Click the Waiting for Input tab.

The Waiting for Input tab lists the workflows that are waiting for user inputs from you or from members of your user group that have permission.

4 Double-click a workflow that is waiting for input.

The workflow token that is waiting for input appears in the Workflows hierarchical list with the

following symbol:

5 Right-click the workflow token and select Answer.

6 Follow the instructions in the input parameters dialog box to provide the information that the workflow

requires.

You provided information to a workflow that was waiting for user input during its run.

Calling Workflows Within Workflows

Workflow Elements that Call Workflows on page 55

There are four ways to call other workflows from within a workflow. Each way of calling a workflow or workflows is represented by a different workflow schema element.

Call a Workflow Synchronously on page 57

Calling a workflow synchronously runs the called workflow as a part of the run of the calling workflow. The calling workflow can use the called workflow's output parameters as input parameters when it runs its subsequent schema elements.

54 VMware, Inc.

Chapter 1 Developing Workflows

Call a Workflow Asynchronously on page 58

Calling a workflow asynchronously runs the called workflow independently of the calling workflow. The calling workflow continues its run without waiting for the called workflow to complete.

Schedule a Workflow on page 59

You can call a workflow from a workflow and schedule it to start at a later time and date.

Prerequisites for Calling a Remote Workflow from Within Another Workflow on page 59

If the workflow that you develop calls another workflow that resides on a remote Orchestrator server, certain prerequisites must be fulfilled so that the remote workflow can run successfully.

Call Several Workflows Simultaneously on page 60

Calling several workflows simultaneously runs the called workflows synchronously as part of the run of the calling workflow. The calling workflow waits for all of the called workflows to complete before it continues. The calling workflow can use the results of the called workflows as input parameters when it runs its subsequent schema elements.

Workflow Elements that Call Workflows

There are four ways to call other workflows from within a workflow. Each way of calling a workflow or workflows is represented by a different workflow schema element.

Synchronous Workflows

Asynchronous Workflows

A workflow can start another workflow synchronously. The called workflow runs as an integral part of the calling workflow's run, and runs in the same memory space as the calling workflow. The calling workflow starts another workflow, then waits until the end of the called workflow's run before it starts running the next element in its schema. Usually, you call a workflow synchronously because the calling workflow requires the output of the called workflow as an input parameter for a subsequent schema element. For example, a workflow can call the Start virtual machine and wait workflow to start a virtual machine, and then obtain the IP address of this virtual machine to pass to another element or to a user by email.

A workflow can start a workflow asynchronously. The calling workflow starts another workflow, but the calling workflow immediately continues running the next element in its schema, without waiting for the result of the called workflow. The called workflows run with input parameters that the calling workflow defines, but the lifecycle of the called workflow is independent from the lifecycle of the calling workflow. Asynchronous workflows allow you to create chains of workflows that pass input parameters from one workflow to the next. For example, a workflow can create various objects during its run. The workflow can then start asynchronous workflows that use these objects as input parameters in their own runs. When the original workflow has started all the required workflows and run its remaining elements, it ends. However, the asynchronous workflows it started continue their runs independently of the workflow that started them.

To make the calling workflow wait for the result of the called workflow, either use a nested workflow or create a scriptable task that retrieves the state of the workflow token of the called workflow and then retrieves the result of the workflow when it completes.

VMware, Inc. 55

Developing with VMware vCenter Orchestrator

Scheduled Workflows

A workflow can call a workflow but defer starting that workflow until a later time and date. The calling workflow then continues its run until it ends. Calling a scheduled workflow creates a task to start that workflow at the given time and date. When the calling workflow has run, you can view the scheduled workflow in the Scheduler and My Orchestrator views in the Orchestrator client.

Scheduled workflows only run once. You can schedule a workflow to run recurrently by calling the Workflow.scheduleRecurrently method in a scriptable task element in a synchronous workflow.

Nested Workflows

A workflow can start several workflows simultaneously by nesting several workflows in a single schema element. All the workflows listed in the nested workflow element start simultaneously when the calling workflow arrives at the nested workflows element in its schema. Significantly, each nested workflow starts in a different memory space from the memory space of the calling workflow. The calling workflow waits until all the nested workflows have completed their runs before it starts running the next element in its schema. The calling workflow can thus use the results of the nested workflows as input parameters when it runs its remaining elements.

Propagate Workflow Changes to other Workflows

If you call a workflow from another workflow, Orchestrator imports the input parameters of the child workflow in the parent workflow at the moment you add the workflow element to the schema.

If you modify the child workflow after you have added it to another workflow, the parent workflow calls on the new version of the child workflow, but does not import any new input parameters. To prevent changes to workflows affecting the behavior of other workflows that call them, Orchestrator does not propagate the new input parameters automatically to the calling workflows.

To propagate parameters from one workflow to other workflows that call it, you must find the workflows that call the workflow, and synchronize the workflows manually.

Prerequisites

Verify that you have a workflow that another workflow or workflows call.

Procedure

1 Modify and save a workflow that other workflows call.

2 Close the workflow editor.

3 Navigate to the workflow you changed in the hierarchical list in the Workflows view in the

Orchestrator client.

4 Right-click the workflow, and select References > Find Elements that Use this Element.

A list of workflows that call this workflow appears.

5 Double-click a workflow in the list to highlight it in the Workflows view in the Orchestrator client.

6 Right-click the workflow, and select Edit.

The workflow editor opens.

7 Click the Schema tab in the workflow editor.

8 Right-click the workflow element for the changed workflow from the workflow schema and select

Synchronize > Synchronize Parameters.

9 Select Continue in the confirmation dialog box.

56 VMware, Inc.

Chapter 1 Developing Workflows

10 Save and close the workflow editor.

11 Repeat Step 5 to Step 10 for all the workflows that use the modified workflow.

You propagated a changed workflow to other workflows that call it.

Propagate the Input Parameters and Presentation of a Child Workflow to the Parent Workflow

If you develop a workflow that calls other workflows, you can propagate the input parameters and the presentation of the child workflows to the parent workflow.

Procedure

1 From the drop-down menu in the Orchestrator client, select Run.

2 Right-click the workflow that you want to modify and select Edit.

The workflow editor opens.

3 Select the Schema tab.

4 Right-click the element of the child workflow whose input parameters and presentation you want to

propagate to the parent workflow and select Synchronize > Synchronize Presentation.

5 In the confirmation dialog, select OK.

6 (Optional) Repeat Step 4 and Step 5 for all child workflows whose input parameters and presentation

you want to propagate to the parent workflow.

The input parameters of the child workflows are added to the input parameters of the parent workflow. The presentation of the parent workflow is extended with the presentations of the child workflows.

Call a Workflow Synchronously

You call workflows synchronously from another workflow by using the Workflow element.

Prerequisites

Open a workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Drag a Workflow element from the Generic menu to the appropriate position in the workflow schema.

The Choose workflow selection dialog box appears.

2 Search for ands select the workflow you want and click OK.

If the search returns a partial result, narrow your search criterion or increase the number of search results from the Tools > User preferences menu in the client.

3 Click the Workflow element to show its properties tabs in the bottom half of the Schema tab.

Click the Edit icon ( ) of the Workflow element in the workflow schema.

5 Bind the required input parameters to the workflow in the IN tab of the workflow schema element.

VMware, Inc. 57

Developing with VMware vCenter Orchestrator

6 Bind the required output parameters to the workflow in the OUT tab of the workflow schema

element's.

7 Define the exception behavior of the workflow in the Exceptions tab.

8 Click Close.

9 Click Save at the bottom of the workflow editor.

You called a workflow synchronously from another workflow. When the workflow reaches the synchronous workflow during its run, the synchronous workflow starts, and the initial workflow waits for it to complete before continuing its run.

What to do next

You can call a workflow asynchronously from a workflow.

Call a Workflow Asynchronously

Calling a workflow asynchronously runs the called workflow independently of the calling workflow. The calling workflow continues its run without waiting for the called workflow to complete.

You call workflows asynchronously from another workflow by using the Asynchronous Workflow element.

Prerequisites

Open a workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Drag an Asynchronous Workflow element from the Generic menu to the appropriate position in the

workflow schema.

The Choose workflow selection dialog box appears.

2 Search for and select the desired workflow from the list and click OK.

Click the Edit icon ( ) of the Asynchronous Workflow element in the workflow schema.

4 Bind the required input parameters to the workflow in IN tab of the asynchronous workflow element.

5 Bind the required output parameter in the OUT tab of the asynchronous workflow element.

You can bind the output parameter either to the called workflow, or to that workflow's result.

Bind to the called workflow to return that workflow as an output parameter

Bind to the workflow token of the called workflow to return the result of running the called

workflow.

6 Define the exception behavior of the asynchronous workflow element in the Exceptions tab.

7 Click Close.

8 Click Save at the bottom of the workflow editor.

You called a workflow asynchronously from another workflow. When the workflow reaches the asynchronous workflow during its run, the asynchronous workflow starts, and the initial workflow continues its run without waiting for the asynchronous workflow to finish.

What to do next

You can schedule a workflow to start at a later time and date.

58 VMware, Inc.

Chapter 1 Developing Workflows

Schedule a Workflow

You can call a workflow from a workflow and schedule it to start at a later time and date.

You schedule workflows in another workflow by using the Schedule Workflow element.

Prerequisites

Open a workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Drag a Schedule Workflow element from the Generic menu to the appropriate position in the

workflow schema.

2 Search for the workflow to call by typing part of its name in the text box.

3 Select the workflow from the list and click OK.

Click the Edit icon ( ) of the Schedule Workflow element in the workflow schema.

5 Click the IN property tab.

A parameter named workflowScheduleDate appears in the list of properties to define, together with the input parameters of the calling workflow.

6 Click Not set for the workflowScheduleDate parameter to set the parameter.

7 Click Create parameter/attribute in workflow to create the parameter and set the parameter value.

8 Click Not set for Value to set the parameter value.

9 Use the calendar that appears to set the date and time to start the scheduled workflow and click OK.

10 Bind the remaining input parameters to the scheduled workflow in the IN tab of the scheduled

workflow element.

11 Bind the required output parameters to the Task object in the OUT tab of the scheduled workflow

element.

12 Define the exception behavior of the scheduled workflow element in the Exceptions tab.

13 Click Close.

14 Click Save at the bottom of the workflow editor.

You scheduled a workflow to start at a given time and date from another workflow.

What to do next

You can call multiple workflows simultaneously from a workflow.

Prerequisites for Calling a Remote Workflow from Within Another Workflow

If the workflow that you develop calls another workflow that resides on a remote Orchestrator server, certain prerequisites must be fulfilled so that the remote workflow can run successfully.

All input parameters of the remote workflow must be resolvable on the remote Orchestrator server.

All output parameters of the remote workflow must be resolvable on the local Orchestrator server.

VMware, Inc. 59

Developing with VMware vCenter Orchestrator

To ensure that the parameters of the remote workflow are resolvable, the inventory objects that the workflow uses must be available both in the remote and the local Orchestrator servers. In case the remote workflow uses objects from a plug-in, the same plug-in must be available on both Orchestrator servers. The inventories of the remote plug-in and the local plug-in must be identical. In case the remote workflow uses system objects in Orchestrator, like workflows and actions, the same workflows and actions must exist in the inventories of the remote and the local Orchestrator servers.

For example, suppose that you insert the Rename virtual machine workflow in a Nested Workflow element in the Test workflow that you develop. You want to run the Rename virtual machine workflow in a remote Orchestrator server. When you run the Test workflow, the Rename virtual machine workflow is called within the run of the Test workflow. You specify a virtual machine to rename from the inventory of the local Orchestrator server. Because the Rename virtual machine workflow runs on the remote Orchestrator server, the same virtual machine must be available in the inventory of that server. Otherwise, the Rename virtual machine workflow cannot resolve its vm input parameter. Therefore, the vCenter Server plug-in on the local and the remote Orchestrator servers must be connected to the same vCenter Server instance.

Call Several Workflows Simultaneously

You call several workflows simultaneously from another workflow by using the Nested Workflows element. You can use nested workflows to run workflows with user credentials that are different from the credentials of the user of the calling workflow.

Prerequisites

Open a workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Drag a Nested Workflows element from the Action & Workflow menu to the appropriate position in

the workflow schema.

The Choose workflow selection dialog box appears.

2 Search for and select a workflow to start and click OK.

Click the Edit icon ( ) of the Nested Workflows element in the workflow schema.

4 Click the Workflows tab.

The workflow you selected in Step 2 appears in the tab.

5 Set the IN and OUT bindings for this workflow in the IN and OUT tabs in the right panel of the

Workflows schema element properties tab.

6 Click the Connection Info tab in the right panel of the Workflows schema element properties tab.

The Connection Info tab allows you to access workflows stored in a different server to the local one, using the appropriate credentials.

7 To access workflows on a remote server, select Remote and click Not set to provide a host name or IP

address for the remote server.

NOTE You can use the vCenter Orchestrator Multi-Node plug-in to call workflows on a remote server.

60 VMware, Inc.

Chapter 1 Developing Workflows

8 Define the credentials with which to access the remote server.

Select Inherit to use the same credentials as the user who runs the calling workflow.

Select Dynamic and click Not set to select a set of dynamic credentials that a parameter of the

credentials type defines elsewhere in the workflow.

Select Static and click Not set to enter the credentials directly.

9 Click the Add Workflow button in the Workflows tab to select more workflows to add to the nested

workflow element.

10 Repeat Step 2 to Step 8 to define the settings for each of the workflows you add.

11 Click the nested workflow element in the workflow schema.

The number of workflows nested in the element appears as a numeral on the nested workflows element.

You called several workflows simultaneously from a workflow.

What to do next

You can define long-running workflows.

Running a Workflow on a Selection of Objects

You can use one of the following methods to run a workflow on a selection of objects.

Run the Library > vCenter > Batch > Run a workflow on a selection of objects workflow.

Create a workflow that calls the Library > Orchestrator > Start workflows in a series or Start

workflows in parallel workflows.

Create a workflow that obtains an array of objects and runs a workflow on each object in the array in a

loop of workflow elements.

Run a workflow from JavaScript by calling the Workflow.execute() method in a For loop in a scripted

element in a workflow.

Which method you choose to run a workflow on a selection of objects depends on the workflow to run and can affect the performance of the workflow. For example, running the Run a workflow on a selection of objects workflow is the simplest way to run a workflow on multiple objects and requires no workflow development, but it can only run workflows that take a single input parameter.

Creating a workflow that calls the Start workflows in a series or Start workflows in parallel workflows allows you to run on multiple objects workflows that take more than one input parameter. The calling workflow must create a properties array to pass the input parameters to the Start workflows in a series or Start workflows in parallel workflow. These workflows are only for use in other workflows. Do not run them directly.

Running a workflow in a For loop in a scripted element is faster than running a workflow in a loop of workflow elements, but it is less flexible and limits the potential for reuse. Most importantly, running a workflow in a scripted loop loses the checkpointing that Orchestrator performs when it starts each element in a workflow run. As a consequence, if the Orchestrator server stops while the scripted loop is running, when the server restarts, the workflow will resume at the beginning of the scripted element, repeating the whole loop. If the Orchestrator server stops while running a workflow with a loop of workflow elements, the workflow will resume at the specific element in the loop that was running when the server stopped.

For more information about the Batch workflows, see Using VMware vCenter Orchestrator Plug-Ins.

VMware, Inc. 61

Developing with VMware vCenter Orchestrator

How to create a workflow that runs a workflow on an array of objects in a loop of workflow elements is demonstrated in “Develop a Complex Workflow,” on page 102.

How to run a workflow in a scripted For loop is demonstrated in “Workflow Scripting Examples,” on page 136.

Implement the Start Workflows in a Series and Start Workflows in Parallel Workflows

You can use the Start workflows in a series and Start workflows in parallel workflows to run a workflow on a selection of objects.

You cannot run the Start workflows in a series and Start workflows in parallel workflows directly. You must include them in another workflow that you create. To use the Start workflows in a series and Start workflows in parallel workflows to run a workflow on a selection of objects, you must obtain the objects on which to run the workflow. You pass these objects and any other input parameters that the workflow requires to the workflow as an array of properties. The Start workflows in a series and Start workflows in parallel workflows emit the results of running the workflow on the selection of objects as an array of

WorkflowToken objects.

You implement the Start workflows in a series and Start workflows in parallel workflows in the same way. The Start workflows in a series workflow runs the workflow on each object sequentially. The Start workflows in parallel workflow runs the workflow on all the objects simultaneously.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 In the workflow schema, add a scriptable task element or an action to obtain a list of objects on which to

run the workflow.

For example, to run a workflow on all the virtual machines in a virtual machine folder, you can add the

getAllVirtualMachinesByFolder action to the workflow.

2 Link the scripted element or action and bind the input and output of the scripted element or action to

workflow inputs or attributes.

For example, you can bind the vmFolder input of the getAllVirtualMachinesByFolder action to a workflow input parameter and the actionResult output to a workflow attribute in the calling workflow.

3 Add a scriptable task element to cast the list of objects into a properties array.

For example, if the objects on which to run the workflow are an array of virtual machines, allVMs, returned by the actionResult output of the getAllVirtualMachinesByFolder action, you can write the following script to cast the objects into a properties array.

propsArray = new Array();

for each (var vm in allVMs) { var prop = new Properties(); prop.put("vm", vm); propsArray.push(prop); }

4 Bind the inputs and outputs of the scriptable task element to workflow attributes.

In the example scriptable task element in Step 3, you bind the input to the allVMs array of virtual machines and you create the propsArray output attribute as an array of Properties objects.

5 Add a workflow element to the workflow schema.

62 VMware, Inc.

6 Select either of the Start workflows in a series or Start workflows in parallel workflows and link the

workflow element to the other elements.

7 Bind the wf input of the Start workflows in a series or Start workflows in parallel workflow to the

workflow to run on the objects.

For example, to remove any snapshots of all the virtual machines returned by the

getAllVirtualMachinesByFolder action, select the Remove all snapshots workflow.

8 Bind the parameters input of the Start workflows in a series or Start workflows in parallel workflow to

the array of Properties objects that contains the objects on which to run the workflow.

For example, bind the parameters input to the propsArray attribute defined in Step 4.

9 (Optional) Bind the workflowTokens output of the Start workflows in a series or Start workflows in

parallel workflow to an attribute in the workflow.

10 (Optional) Continue adding more elements that use the results of running the Start workflows in a

series or Start workflows in parallel workflow.

You created a workflow that uses either of the Start workflows in a series or Start workflows in parallel workflows to run a workflow on a selection of objects.

Developing Long-Running Workflows

Chapter 1 Developing Workflows

Every running workflow consumes a system thread. When a workflow reaches a long-running workflow element, the long-running workflow element sets the workflow into a passive state. The long-running workflow element then passes the workflow information to a single thread that polls the system for all longrunning workflow elements running in the server. Rather than each long-running workflow element constantly attempting to retrieve information from the system, long-running workflow elements remain passive for a set duration, while the long-running workflow thread polls the system on its behalf.

You set the duration of the wait in one of the following ways:

Set a timer, encapsulated in a Date object, that suspends the workflow until a certain time and date. You

implement long-running workflow elements that are based on a timer by including a Waiting Timer element in the schema.

Define a trigger event, encapsulated in a Trigger object, that restarts the workflow after the trigger

event occurs. You implement long-running workflow elements that are based on a trigger by adding a Waiting Event element or a User Interaction element in the schema.

Set a Relative Time and Date for Timer-Based Workflows

You can set the timer.date attribute of a Waiting Timer element to a relative time and date by binding it to a

Date object. You define the Date object in a scripted function.

When the time on the given date arrives, the long-running workflow that is based on a timer reactivates and continues its run. For example, you can set the workflow to reactivate at midday on February 12. Alternatively, you can create a workflow element that calculates and generates a relative Date object according to a function that you define. For example, you can create a relative Date object that adds 24 hours to the current time.

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

VMware, Inc. 63

Developing with VMware vCenter Orchestrator

Add some elements to the workflow schema.

Procedure

1 Drag a Scriptable task element from the Generic menu to the schema of a workflow, before the element

that requires the relative Date object for its timeout.date attribute.

Click the Edit icon ( ) of the Scriptable task element in the workflow schema.

3 Provide a name and description for the scripted workflow element in the Info properties tab.

Click the OUT properties tab, and click the Bind to workflow parameter/attribute icon ( ).

5 Click Create parameter/attribute in workflow to create a workflow attribute.

a Name the attribute timerDate.

b Select Date from the list of attribute types.

c Select Create workflow ATTRIBUTE with the same name.

d Leave the attribute value set to Not set, because a scripted function will provide this value.

e Click OK.

6 Click the Scripting tab for the scripted workflow element.

7 Define a function to calculate and generate a Date object named timerDate in the scripting pad in the

Scripting tab.

For example, you can create a Date object by implementing the following JavaScript function, in which the timeout period is a relative delay in milliseconds.

timerDate = new Date(); System.log( "Current date : '" + timerDate + "'" ); timerDate.setTime( timerDate.getTime() + (86400 * 1000) ); System.log( "Timer will expire at '" + timerDate + "'" );

8 Click Close.

9 Click Save.

You created a function that calculates and generates a Date object. A Waiting Timer element can receive this

Date object as an input parameter, to suspend a long-running workflow until the date encapsulated in this

object. When the workflow arrives at the Waiting Timer element, it suspends its run and waits for 24 hours before continuing.

What to do next

You must add a Waiting Timer element to a workflow to implement a long-running workflow that is based on a timer.

Create a Timer-Based Long-Running Workflow

If you know a workflow will have to wait for a response from an outside source for a predictable time, you can implement it as a timer-based long-running workflow. A timer-based long-running workflow waits until a given time and date before resuming.

You implement a workflow as a timer-based long-running workflow by using the Waiting Timer element.

64 VMware, Inc.

Chapter 1 Developing Workflows

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Drag a Waiting Timer element from the Generic menu to the position in the workflow schema at which

to suspend the workflow's run.

If you implement a scriptable task to calculate the time and date, this element must precede the Waiting Timer element.

Click the Edit icon ( ) of the Waiting Timer element in the workflow schema.

3 Provide a description of the reason for implementing the timer in the Info properties tab.

4 Click the Attributes properties tab.

The timer.date parameter appears in the list of attributes.

5 Click the timer.date parameter's Not set button to bind the parameter to an appropriate Date object.

The Waiting Timer selection dialog box opens, presenting a list of possible bindings.

Select a predefined Date object from the proposed list, for example one defined by a Scriptable

Task element elsewhere in the workflow.

Alternatively, create a Date object that sets a specific date and time for the workflow to await.

6 (Optional) Create a Date object that sets a specific date and time that the workflow awaits.

a Click Create parameter/attribute in workflow in the Waiting Timer selection dialog box.

The Parameter information dialog box appears.

b Give the parameter an appropriate name.

c Leave the type set to Date.

d Click Create workflow ATTRIBUTE with the same name.

e Click the Value property's Not set button to set the parameter value.

A calendar appears.

f Use the calendar to set a date and time at which to restart workflow.

g Click OK.

7 Click Close.

8 Click Save at the bottom of the workflow editor.

You defined a timer that suspends a timer-based long-running workflow until a set time and date.

What to do next

You can create a long-running workflow that waits for a trigger event before continuing.

VMware, Inc. 65

Developing with VMware vCenter Orchestrator

Create a Trigger Object

Trigger objects monitor event triggers that plug-ins define. For example, the vCenter Server plug-in defines these events as Task objects. When the task ends, the trigger sends a message to a waiting trigger-based long-running workflow element, to restart the workflow.

The time-consuming event for which a trigger-based long-running workflow waits must return a VC:Task object. For example, the startVM action to start a virtual machine returns a VC:Task object, so that subsequent elements in a workflow can monitor its progress. A trigger-based long-running workflow's trigger event requires this VC:Task object as an input parameter.

You create a Trigger object in a JavaScript function in a Scriptable Task element. This Scriptable Task element can be part of the trigger-based long-running workflow that waits for the trigger event. Alternatively, it can be part of a different workflow that provides input parameters to the trigger-based long-running workflow. The trigger function must implement the createEndOfTaskTrigger() method from the Orchestrator API.

IMPORTANT You must define a timeout period for all triggers, otherwise the workflow can wait indefinitely.

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Add some elements to the workflow schema.

In the workflow, declare a VC:Task object as an attribute or input parameter, such as a VC:Task object

from a workflow or workflow element that starts or clones a virtual machine.

Procedure

1 Drag a Scriptable Task element from the Generic menu into the schema of a workflow.

One of the elements that precedes the Scriptable Task must generate a VC:Task object as its output parameter.

Click the Edit icon ( ) of the Scriptable task element in the workflow schema.

3 Provide a name and description for the trigger in Info properties tab.

4 Click the IN properties tab.

Click the Bind to workflow parameter/attribute icon ( ).

The input parameter selection dialog box opens.

6 Select or create an input parameter of the type VC:Task.

This VC:Task object represents the time-consuming event that another workflow or element launches.

7 (Optional) Select or create an input parameter of the Number type to define a timeout period in

seconds.

8 Click the OUT properties tab.

Click the Bind to workflow parameter/attribute icon (

The output parameter selection dialog box opens.

66 VMware, Inc.

Chapter 1 Developing Workflows

10 Create an output parameter with the following properties.

a Create the Name property with the value trigger.

b Create the Type property with the value Trigger.

c Click Create ATTRIBUTE with same name to create the attribute.

d Leave the value as Not set.

11 Define any exception behavior in the Exceptions properties tab.

12 Define a function to generate a Trigger object in the Scripting tab.

For example, you could create a Trigger object by implementing the following JavaScript function.

trigger = task.createEndOfTaskTrigger(timeout);

The createEndOfTaskTrigger() method returns a Trigger object that monitors a VC:Task object named

task.

13 Click Close.

14 Click Save at the bottom of the workflow editor.

You defined a workflow element that creates a trigger event for a trigger-based long-running workflow. The trigger element generates a Trigger object as its output parameter, to which a Waiting Event element can bind.

What to do next

You must bind this trigger event to a Waiting Event element in a trigger-based long-running workflow.

Create a Trigger-Based Long-Running Workflow

If you know a workflow will have to wait for a response from an outside source during its run, but do not know how long that wait will last, you can implement it as a trigger-based long-running workflow. A trigger-based long-running workflow waits for a defined trigger event to occur before resuming.

You implement a workflow as a trigger-based long-running workflow by using the Waiting Event element. When the trigger-based long-running workflow arrives at the Waiting Event element, it will suspend its run and wait in a passive state until it receives a message from the trigger. During the waiting period, the passive workflow does not consume a thread, but rather the long-running workflow element passes the workflow information to the single thread that monitors all long-running workflows in the server.

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Define a trigger event that is encapsulated in a Trigger object.

Procedure

1 Drag a Waiting Event element from the Generic menu to the position in the workflow schema at which

you want to suspend the workflow's run.

The scriptable task that declares the trigger must immediately precede the Waiting Event element.

Click the Edit icon ( ) of the Waiting Event element in the workflow schema.

3 Provide a description of the reason for the wait in the Info properties tab.

VMware, Inc. 67

Developing with VMware vCenter Orchestrator

4 Click the Attributes properties tab.

The trigger.ref parameter appears in the list of attributes.

5 Click the trigger.ref parameter's Not set link to bind the parameter to an appropriate Trigger object.

The Waiting Event selection dialog box opens, presenting a list of possible parameters to which to bind.

6 Select a predefined Trigger object from the proposed list.

This Trigger object represents a trigger event that another workflow or workflow element defines.

7 Define any exception behavior in the Exceptions properties tab.

8 Click Close.

9 Click Save at the bottom of the workflow editor.

You defined a workflow element that suspends a trigger-based long-running workflow, that waits for a specific trigger event before restarting.

What to do next

You can run a workflow.

Configuration Elements

A configuration element is a list of attributes you can use to configure constants across a whole Orchestrator server deployment.

All the workflows, actions, policies, and Web views running in a particular Orchestrator server can use the attributes you set in a configuration element. Setting attributes in configuration elements lets you make the same attribute values available to all the workflows, actions, policies, and Web views running in the Orchestrator server.

If you create a package containing a workflow, action, policy, or Web view that uses an attribute from a configuration element, Orchestrator automatically includes the configuration element in the package. If you import a package containing a configuration element into another Orchestrator server, you can import the configuration element attribute values as well. For example, if you create a workflow that requires attribute values that depend on the Orchestrator server on which it runs, setting those attributes in a configuration element lets you to export that workflow so that another Orchestrator server can use it. Configuration elements therefore allow you to exchange workflows, actions, policies, and Web views between servers more easily.

NOTE You cannot import values of a configuration element attribute from a configuration element exported from Orchestrator 5.1 or earlier.

Create a Configuration Element

Configuration elements allow you to set common attributes across an Orchestrator server. All elements that are running in the server can call on the attributes you set in a configuration element. Creating configuration elements allows you to define common attributes once in the server, rather than individually in each element.

Procedure

1 Click the Configurations view.

2 Right-click a folder in the hierarchical list of folders and select New folder to create a new folder.

3 Provide a name for the folder and click Ok.

4 Right-click the folder you created and select New element.

68 VMware, Inc.

Chapter 1 Developing Workflows

5 Provide a name for the configuration element and click Ok.

The configuration element editor opens.

6 Increment the version number by clicking the version digits in the General tab and providing a version

comment.

7 Provide a description of the configuration element in the Description text box in the General tab.

8 Click the Attributes tab.

Click the Add attribute icon ( ) to create a new attribute.

10 Click the attribute values under Name, Type, Value, and Description to set the attribute name, type,

value, and description.

11 Click the Permissions tab.

Click the Add access rights icon ( ) to grant permission to access this configuration element to a group of users.

13 Search for a user group in the Filter text box and select the relevant user group from the proposed list.

14 Check the appropriate check boxes to set the access rights for the selected user group.

You can set the following permissions on the configuration element.

Permission Description

View

Inspect

Admin

Execute

Edit

15 Click Select.

16 Click Save and close to exit the configuration element editor.

You defined a configuration element that sets common attributes across an Orchestrator server.

What to do next

You can use the configuration element to provide attributes to workflows or actions.

Workflow User Permissions

Orchestrator defines levels of permissions that you can apply to groups to allow or deny them access to workflows.

View

The user can view the elements in the workflow, but cannot view the schema or scripting.

Users can view the configuration element, but cannot view the schemas or scripting.

Users can view the configuration element, including the schemas and scripting.

Users can set permissions on the elements in the configuration element and have all other permissions.

Users can run the elements in the configuration element.

Users can edit the elements in the configuration element.

Inspect

The user can view the elements in the workflow, including the schema and scripting.

Execute

VMware, Inc. 69

The user can run the workflow.

Developing with VMware vCenter Orchestrator

Edit

Admin

The Admin permission includes the View, Inspect, Edit, and Execute permissions. All the permissions require the View permission.

If you do not set any permissions on a workflow, the workflow inherits the permissions from the folder that contains it. If you do set permissions on a workflow, those permissions override the permissions of the folder that contains it, even if the permissions of the folder are more restrictive.

The user can edit the workflow.

The user can set permissions on the workflow and has all other permissions.

Set User Permissions on a Workflow

You set levels of permission on a workflow to limit the access that user groups can have to that workflow.

You can select the users and user groups for which to set permissions from the Orchestrator LDAP server.

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Add some elements to the workflow schema.

Procedure

1 Click the Permissions tab.

Click the Add access rights icon ( ) to define permissions for a new user group.

3 Search for a user group.

The search results contain all the user groups from the Orchestrator LDAP server that match the search.

4 Select a user group and select the appropriate check boxes to set the level of permissions for this user

group.

To allow a user from this user group to view the workflow, inspect the schema and scripting, run and edit the workflow, and change the permissions, you must select all check boxes.

5 Click Select.

The user group appears in the permissions list.

6 Click Save and close to exit the editor.

Validating Workflows

Orchestrator provides a workflow validation tool. Validating a workflow helps identify errors in the workflow and checks that the data flows from one element to the next correctly.

When you validate a workflow, the validation tool creates a list of any errors or warnings. Clicking an error in the list highlights the workflow element that contains the error.

If you run the validation tool in the workflow editor, the tool provides suggested quick fixes for the errors it detects. Some quick fixes require you to provide additional information or input parameters. Other quick fixes resolve the error for you.

Workflow validation checks the data bindings and connections between elements. Workflow validation does not check the data processing that each element in the workflow performs. Consequently, a valid workflow can run incorrectly and produce erroneous results if a function in a schema element is incorrect.

70 VMware, Inc.

Chapter 1 Developing Workflows

By default, Orchestrator always performs workflow validation when you run a workflow. You can change the default validation behavior in the Orchestrator client. See “Testing Workflows During Development,” on page 13. For example, sometimes during workflow development you might want to run a workflow that you know to be invalid, for testing purposes.

Validate a Workflow and Fix Validation Errors

You must validate a workflow before you can run it. You can validate workflows in either the Orchestrator client or in the workflow editor. However, you can only fix validation errors if you have opened the workflow for editing in the workflow editor.

Prerequisites

Verify that you have a complete workflow to validate, with schema elements linked and bindings defined.

Procedure

1 Click the Workflows view.

2 Navigate to a workflow in the Workflows hierarchical list.

3 (Optional) Right-click the workflow and select Validate workflow.

If the workflow is valid, a confirmation message appears. If the workflow is invalid, a list of errors appears.

4 (Optional) Close the Workflow Validation dialog box.

5 Right-click the workflow and select Edit to open the workflow editor.

6 Click the Schema tab.

7 Click the Validate button in the Schema tab toolbar.

If the workflow is valid, a confirmation message appears. If the workflow is invalid, a list of errors appears.

8 For an invalid workflow, click an error message.

The validation tool highlights the schema element in which the error occurs by adding a red icon to it. Where possible, the validation tool displays a quick fix action.

If you agree with the proposed quick fix action, click it to perform that action.

If you disagree with the proposed quick fix action, close the Workflow Validation dialog box and

fix the schema element manually.

IMPORTANT Always check that the fix that Orchestrator proposes is appropriate.

For example, the proposed action might be to delete an unused attribute, when in fact that attribute might not be bound correctly.

9 Repeat the preceding steps until you have eliminated all validation errors.

You validated a workflow and fixed the validation errors.

What to do next

You can run the workflow.

VMware, Inc. 71

Developing with VMware vCenter Orchestrator

Debugging Workflows

You can debug workflows from the standard workflow library and custom workflows. You can debug custom workflows while developing them in the workflow editor.

Debug a Workflow

You can debug elements of a workflow by adding breakpoints to the elements in the workflow schema.

When a breakpoint is reached, you have several options to continue the debugging process. When you debug an element from the workflow schema, you can view general information about the workflow run, modify the workflow variables, and view log messages.

Prerequisites

Procedure

1 Click the Workflows view.

2 Select a workflow from the workflow library and click the Schema tab.

3 To add breakpoints to the schema elements that you want to debug, right-click a workflow element and

select Toggle breakpoint.

You can enable or disable the toggled breakpoints.

Click the Debug workflow icon ( ).

If the workflow requires input parameters, you must provide them.

5 When the workflow run is paused after it reaches a breakpoint, select one of the available options.

Option Description

Resume

Step into

Step over

Step return

Resumes the workflow run until another breakpoint is reached.

Lets you step into a workflow element.

NOTE You cannot step into a nested workflow element when you debug a workflow in the workflow editor.

Steps over the current element in the schema and pauses the workflow run on the next element.

Exits the workflow element that you have stepped into.

6 (Optional) From the Breakpoints tab, modify the breakpoints.

You can enable, disable, or remove existing breakpoints.

7 (Optional) From the Variables tab, review the variables.

You can modify the values of some of the variables during the debugging process.

72 VMware, Inc.

Chapter 1 Developing Workflows

Example Workflow Debugging

You can debug a workflow from the standard workflow library.

For example, if you provide an incorrect recipient address, you can correct the value when you debug the Example interaction with email workflow.

Prerequisites

Configure the Mail plug-in in the Orchestrator configuration interface.

Procedure

1 Click the Workflows view.

2 In the workflows hierarchical list, open Library > Mail.

3 Select the Example interaction with email workflow and click the Schema tab.

4 Right-click the Email Send (Interaction) workflow element and select Toggle breakpoint.

Click the Debug workflow icon ( ).

6 Provide the required information.

a In the Destination address text box, type an incomplete recipient address.

For example, name@company.c.

b Select an LDAP group of users who are authorized to answer the query.

c Click Submit.

When the breakpoint is reached, click the Step into icon ( ).

8 On the Variables tab, verify the values.

9 In the toAddress text box, type the correct recipient address value.

For example, name@company.com.

Click the Resume icon (

The workflow uses the value that you provided during the debugging process and continues the workflow run.

Running Workflows

An Orchestrator workflow runs according to a logical flow of events.

When you run a workflow, each schema element in the workflow runs according to the following sequence.

1 The workflow binds the workflow token attributes and input parameters to the schema element's input

parameters.

) to continue the workflow run.

2 The schema element runs.

3 The schema element's output parameters are copied to the workflow token attributes and workflow

output parameters.

4 The workflow token attributes and output parameters are stored in the database.

5 The next schema element starts running.

VMware, Inc. 73

Developing with VMware vCenter Orchestrator

This sequence repeats for each schema element until the end of the workflow.

Workflow Token Check Points

When a workflow runs, each schema element is a check point. After each schema element runs, Orchestrator stores workflow token attributes in the database, and the next schema element starts running. If the workflow stops unexpectedly, the next time the Orchestrator server restarts, the currently active schema element runs again, and the workflow continues from the start of the schema element that was running when the interruption occurred. However, Orchestrator does not implement transaction management or a rollback function.

End of Workflow

The workflow ends if the current active schema element is an end element. After the workflow reaches an end element, other workflows or applications can use the workflow's output parameters.

Run a Workflow in the Workflow Editor

You can run a workflow while you are developing it.

Running a workflow in the workflow editor lets you verify that the workflow runs correctly without interrupting the development process. You can view log messages that provide information about the workflow run. If the workflow run returns unexpected results, you can modify the workflow and run it again without closing the workflow editor.

Prerequisites

Create a workflow.

Open the workflow for editing in the workflow editor.

Validate the workflow.

Procedure

1 Click the Schema tab.

2 Click Run.

3 (Optional) Review the messages in the Logs tab.

Run a Workflow

You can perform automated operations in vCenter Server by running workflows from the standard library or workflows that you create.

For example, you can create a virtual machine by running the Create simple virtual machine workflow.

Prerequisites

Verify that you have configured the vCenter Server plug-in. For details, see Installing and Configuring VMware vCenter Orchestrator.

Procedure

1 From the drop-down menu in the Orchestrator client, select Run or Design.

2 Click the Workflows view.

3 In the workflows hierarchical list, open Library > vCenter > Virtual machine management > Basic to

navigate to the Create simple virtual machine workflow.

4 Right-click the Create simple virtual machine workflow and select Start workflow.

74 VMware, Inc.

Chapter 1 Developing Workflows

5 Provide the following information into the Start workflow input parameters dialog box to create a

virtual machine in a vCenter Server connected to Orchestrator.

Option Action

Virtual machine name

Virtual machine folder

Size of the new disk in GB

Memory size in MB

Number of virtual CPUs

Virtual machine guest OS

Host on which to create the virtual machine

Resource pool

The network to connect to

Datastore in which to store the virtual machine files

Name the virtual machine orchestrator-test.

a Click Not set for the Virtual machine folder value.

b Select a virtual machine folder from the inventory.

The Select button is inactive until you select an object of the correct type, in this case, VC:VmFolder.

Type an appropriate numeric value.

Select an appropriate number of CPUs from the Number of virtual CPUs drop-down menu.

Click the Not Set link and select a guest operating system from the list.

Click Not set for the Host on which to create the virtual machine value and navigate through the vCenter Server infrastructure hierarchy to a host machine.

Click Not set for the Resource pool value and navigate through the vCenter Server infrastructure hierarchy to a resource pool.

Click Not set for the The network to connect to value and select a network.

Press Enter in the Filter text box to see all the available networks.

Click Not set for the Datastore in which to store the virtual machine value and navigate through the vCenter Server infrastructure hierarchy to a datastore.

6 Click Submit to run the workflow.

A workflow token appears under the Create simple virtual machine workflow, showing the workflow running icon.

7 Click the workflow token to view the status of the workflow as it runs.

8 Click the Events tab in the workflow token view to follow the progress of the workflow token until it

completes.

9 Click the Inventory view.

10 Navigate through the vCenter Server infrastructure hierarchy to the resource pool you defined.

If the virtual machine does not appear in the list, click the refresh button to reload the inventory.

The orchestrator-test virtual machine is present in the resource pool.

11 (Optional) Right-click the orchestrator-test virtual machine in the Inventory view to see a contextual

list of the workflows that you can run on the orchestrator-test virtual machine.

The Create simple virtual machine workflow ran successfully.

What to do next

You can log in vSphere Client and manage the new virtual machine.

VMware, Inc. 75

Developing with VMware vCenter Orchestrator

Resuming a Failed Workflow Run

If a workflow fails, Orchestrator provides an option to resume the workflow run from the last failed activity.

You can change the parameters of the workflow and attempt to resume it, or retain the parameters and make changes to external components that affect the workflow run. For example, if a workflow run fails due to a problem in a third-party system, you can make changes to the system and resume the workflow run from the failed activity, without changing the workflow parameters and without repeating the successful activities.

Set the Behavior for Resuming a Failed Workflow Run

You can set the behavior for resuming a failed run for each custom workflow. The default workflows in the library use the default system setting for resuming a failed workflow run.

You can change the default system behavior by modifying a configuration file. See “Set Custom Properties

for Resuming Failed Workflow Runs,” on page 77.

Prerequisites

Verify that you have permissions to edit the workflow.

Procedure

1 Click the Workflows view.

2 Expand the workflows hierarchical list to navigate to the workflow for which you want to set the

behavior.

3 Right-click the workflow and select Edit.

The workflow editor opens.

4 On the General tab, select an option from the Resume from failed behavior drop-down menu.

Option Description

System default

Enabled

Disabled

Follows the default behavior.

If a workflow run fails, a pop-up window displays an option to resume the workflow run.

If a workflow run fails, it cannot be resumed.

5 Click Save and close.

76 VMware, Inc.

Chapter 1 Developing Workflows

Set Custom Properties for Resuming Failed Workflow Runs

By default, Orchestrator is not set up to resume failed workflow runs. You can enable Orchestrator to resume failed workflow runs and set a custom timeout period after which failed workflow runs cannot be resumed.

Procedure

1 On the Orchestrator server system, navigate to the folder that contains configuration files.

Option Action

If you installed Orchestrator with the vCenter Server installer

If you installed the standalone version of Orchestrator

If you downloaded and deployed the virtual appliance

2 Open the vmo.properties configuration file in a text editor.

3 Set Orchestrator to resume failed workflow runs by editing the following line in the vmo.properties

file.

Go to

install_directory\VMware\Infrastructure\Orchestrator\appserver\conf.

Go to install_directory\VMware\Orchestrator\app-server\conf.

Go to /etc/vco/app-server/.

com.vmware.vco.engine.execute.resume-from-failed=true

4 Set a custom timeout period for resuming failed workflow runs by editing the following line in the

vmo.properties file.

com.vmware.vco.engine.execute.resume-from-failed.timeout-sec=<seconds>

The value you set overrides the default timeout setting of 86400 seconds.

5 Save the vmo.properties file.

6 Restart the Orchestrator server.

Resume a Failed Workflow Run

You can resume a workflow run from the last failed activity, if resuming a failed run is enabled for the workflow.

When the option for resuming a failed workflow run is enabled, you can change the parameters of the workflow and try to resume it by using the options in the pop-up window that appears after the workflow fails. You can also retain the parameters and make changes to external components that affect the workflow run. If you do not select an option, the workflow run times out and cannot be resumed. For modifying the timeout period, see “Set Custom Properties for Resuming Failed Workflow Runs,” on page 77.

Procedure

1 From the drop-down menu in the pop-up window, select Resume and click Next.

If you select Cancel, the workflow run cannot be resumed later.

2 (Optional) Modify the workflow parameters.

3 Click Submit.

VMware, Inc. 77

Developing with VMware vCenter Orchestrator

Generate Workflow Documentation

You can export documentation in PDF format about a workflow or a workflow folder that you select at any time.

The exported document contains detailed information about the selected workflow or the workflows in the folder. The information about each workflow includes name, version history of the workflow, attributes, parameter presentation, workflow schema, and workflow actions. In addition, the documentation also provides the source code for the used actions.

Procedure

1 From the drop-down menu in the Orchestrator client, select Run or Design.

2 Click the Workflows view.

3 Navigate to the workflow or workflow folder for which you want to generate documentation and right-

click it.

4 Select Generate documentation.

5 Browse to locate the folder in which to save the PDF file, provide a file name, and click Save.

The PDF file containing the information about the selected workflow, or the workflows in the folder, is saved on your system.

Use Workflow Version History

Orchestrator creates a new version history item for each workflow when you increase and save the workflow version. Subsequent changes to the workflow do not change the current saved version. For example, when you create a workflow version 1.0.0 and save it, the state of the workflow is stored in the version history. If you make any changes to the workflow, you can save the workflow state in the Orchestrator client, but you cannot apply the changes to workflow version 1.0.0. To store the changes in the version history, you must create a subsequent workflow version and save it. The version history is kept in the database along with the workflow itself.

When you delete a workflow, Orchestrator marks the element as deleted in the database without deleting the version history of the element from the database. This way, you can restore deleted workflows. See

“Restore Deleted Workflows,” on page 79.

Prerequisites

Open a workflow for editing in the workflow editor.

Procedure

1 Click the General tab in the workflow editor and click Show version history.

2 Select a workflow version and click Diff Against Current to compare the differences.

A window displays the differences between the current workflow version and the selected workflow version.

78 VMware, Inc.

3 Select a workflow version and click Revert to restore the state of the workflow.

CAUTION If you have not saved the current workflow version, it is deleted from the version history and

you cannot revert back to the current version.

The workflow state is reverted to the state of the selected version.

Restore Deleted Workflows

You can restore workflows that have been deleted from the workflow library.

Procedure

1 From the drop-down menu in the Orchestrator client, select Run or Design.

2 Click the Workflows view.

3 Navigate to the workflow folder in which you want to restore deleted workflows.

4 Right-click the folder and select Restore deleted workflows.

5 Select the workflow or workflows that you want to restore and click Restore.

The restored workflows appear in the selected folder.

Chapter 1 Developing Workflows

Develop a Simple Example Workflow

Developing a simple example workflow demonstrates the most common steps in the workflow development process.

The example workflow that you are about to create starts an existing virtual machine in vCenter Server and sends an email to the administrator to confirm that the virtual machine has started.

The example workflow performs the following tasks:

1 Prompts the user to select a virtual machine to start.

2 Prompts the user for an email address to which it can send notifications.

3 Checks whether the selected virtual machine is already powered on.

4 Sends a request to the vCenter Server instance to start the virtual machine.

5 Waits for vCenter Server to start the virtual machine, and returns an error if the virtual machine fails to

start or if starting the virtual machine takes too long.

6 Waits for vCenter Server to start VMware Tools on the virtual machine, and returns an error if the

virtual machine fails to start or if starting VMware Tools takes too long.

7 Verifies that the virtual machine is running.

8 Sends a notification to the provided email address, informing that the machine has started or that an

error occurred.

The ZIP file of Orchestrator examples available for download from the landing page of the Orchestrator documentation contains a complete version of the Start VM and Send Email workflow.

The process for developing the example workflow consists of several tasks.

Prerequisites

Before you attempt to develop the simple example workflow, read “Key Concepts of Workflows,” on page 11.

VMware, Inc. 79

Developing with VMware vCenter Orchestrator

Procedure

1 Create the Simple Workflow Example on page 81

You must begin the workflow development process by creating the workflow in the Orchestrator client.

2 Create the Schema of the Simple Workflow Example on page 82

You can create a workflow's schema in the workflow editor. The workflow schema contains the elements that the workflow runs and determines the logical flow of the workflow.

3 (Optional) Create the Simple Workflow Example Zones on page 84

You can emphasize different zones in workflow by adding workflow notes of different colors. Creating different workflow zones helps to make complicated workflow schema easier to read and understand.

4 Define the Parameters of the Simple Workflow Example on page 85

In this phase of workflow development, you define the input parameters that the workflow requires to run. For the example workflow, you need an input parameter for the virtual machine to power on, and a parameter for the email address of the person to inform about the result of the operation. When users run the workflow, they will be required to specify the virtual machine to power on and an email address.

5 Define the Simple Workflow Example Decision Bindings on page 86

You bind a workflow's elements together in the Schema tab of the workflow editor. Decision bindings define how decision elements compare the input parameters received to the decision statement, and generate output parameters according to whether the input parameters match the decision statement.

6 Bind the Action Elements of the Simple Workflow Example on page 87

You can bind a workflow's elements together in the workflow editor. Bindings define how the action elements process input parameters and generate output parameters.

7 Bind the Simple Workflow Example Scripted Task Elements on page 90

You bind a workflow's elements together in the Schema tab of the workflow editor. Bindings define how the scripted task elements process input parameters and generate output parameters. You also bind the scriptable task elements to their JavaScript functions.

8 Define the Simple Workflow Example Exception Bindings on page 97

You define exception bindings in the Schema tab in the workflow editor. Exception bindings define how elements process errors.

9 Set the Read-Write Properties for Attributes of the Simple Workflow Example on page 98

You can define whether parameters and attributes are read-only constants or writeable variables. You can also set limitations on the values that users can provide for input parameters.

10 Set the Simple Workflow Example Parameter Properties on page 98

You can set the parameter properties in the workflow editor. Setting the parameter properties affects the behavior of the parameter, and places constraints on the possible values for that parameter.

11 Set the Layout of the Simple Workflow Example Input Parameters Dialog Box on page 100

You create the layout or presentation of the input parameters dialog box in the workflow editor. The input parameters dialog box opens when users run a workflow that needs input parameters to run.

12 Validate and Run the Simple Workflow Example on page 101

After you create a workflow, you can validate it to discover any possible errors. If the workflow contains no errors, you can run it.

80 VMware, Inc.

Chapter 1 Developing Workflows

Create the Simple Workflow Example

You must begin the workflow development process by creating the workflow in the Orchestrator client.

Prerequisites

Verify that the following components are installed and configured on the system.

vCenter Server, controlling some virtual machines, at least one of which is powered off

Access to an SMTP server

A valid email address

For information about how to install and configure vCenter Server, see the vSphere Installation and Setup documentation. For information about how to configure Orchestrator to use an SMTP server, see Installing and Configuring VMware vCenter Orchestrator.

To write a workflow, you must have an Orchestrator user account with at least View, Execute, Inspect, Edit, and preferably Admin permissions on the server or on the workflow folder in which you are working.

Procedure

1 Click the Workflows view.

2 Right-click the root of the workflows list and select Add folder.

3 Name the new folder Workflow Examples and click OK.

4 Right-click the Workflow Examples folder and select New workflow.

5 Name the new workflow Start VM and Send Email and click OK.

The workflow editor opens.

6 In the General tab, click the version number digits to increment the version number.

Because this is the initial creation of the workflow, set the version to 0.0.1.

7 Click the Server restart behavior value in the General tab to set whether the workflow resumes after a

server restart.

8 Type a description of what the workflow does in the Description text box in the General tab.

For example, you can add the following description.

This workflow starts a virtual machine and sends a confirmation email to the Orchestrator administrator.

9 Click Save at the bottom of the General tab.

You created a workflow called Start VM and Send Email, but you did not define its functions.

What to do next

Create the workflow's schema.

VMware, Inc. 81

Developing with VMware vCenter Orchestrator

Create the Schema of the Simple Workflow Example

You can create a workflow's schema in the workflow editor. The workflow schema contains the elements that the workflow runs and determines the logical flow of the workflow.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

Open the workflow for editing in the workflow editor.

Procedure

1 Click the Schema tab in the workflow editor.

2 From the Generic menu, drag a decision element to the arrow that links the Start element and the End

element in the schema.

3 Double-click the decision element and change its name to VM powered on?.

The decision element corresponds to a boolean function that checks whether the virtual machine is already powered on.

4 From the Generic menu, drag an action element to the red arrow that links the decision element and an

End element.

The dialog box for action selection appears.

5 Type start in the Filter text box, select the startVM action from the filtered list of actions, and click

Select.

6 Drag the following action elements, one after the other, to the blue arrow that links the startVM action

element to an End element.

vim3WaitTaskEnd

Suspends the workflow run and pings an ongoing vCenter Server task at regular intervals, until that task is finished. The startVM action starts a virtual machine and the vim3WaitTaskEnd action makes the workflow wait while the virtual machine starts up. After the virtual machine starts, the

vim3WaitTaskEnd lets the workflow resume.

vim3WaitToolsStarted

Suspends the workflow run and waits until VMware Tools starts on the target virtual machine.

7 From the Generic menu, drag a scriptable task element to the blue arrow that links the

vim3WaitToolsStarted action element to an End element.

8 Double-click the scriptable task element and rename it to OK.

9 Drag another scriptable task element to the green arrow that links the VM powered on? decision element

to an End element , and name this scriptable task element Already started.

10 Modify the linking of the Already started scriptable task element.

a Drag the Already started scriptable task element to the left of the startVM action element.

b Delete the blue arrow that connects the Already started scriptable task element to an End element.

c Link the Already started scriptable task element to the vim3WaitToolsStarted action element with

a blue arrow.

82 VMware, Inc.

Chapter 1 Developing Workflows

11 From the Generic menu, drag the following scriptable task elements into the schema.

Drag a scriptable task element to the startVM action element and name the scriptable task element

Start VM Failed.

Drag a scriptable task element to the vim3WaitTaskEnd action element and name the scriptable task

element Timeout 1.

Drag a scriptable task element to the vim3WaitToolsStarted action element and name the scriptable

task element Timeout 2.

Drag a scriptable task element to the blue arrow that links the OK scriptable task element to an End

element, name the new scriptable task element Send Email, and drag it to the right of the OK scriptable task element.

Link the Start VM Failed, Timeout 1, and Timeout 2 scriptable task elements to the Send Email

scriptable task element with blue arrows.

Drag a scriptable task element to the Send Email scriptable task element, name the new scriptable

task element Send Email Failed, drag it to the right of the Timeout 2 scriptable task element, and link it to the End element with a blue arrow.

12 Drag the End element to the right of the Send Email scriptable task element.

13 Click Save at the bottom of the Schema tab.

The following figure shows the layout of the Start VM and Send Email workflow schema elements.

Figure 1‑3. Linking the Elements of the Start VM and Send Email Example Workflow

VMware, Inc. 83

Developing with VMware vCenter Orchestrator

What to do next

You can highlight different zones in the workflow.

(Optional) Create the Simple Workflow Example Zones

You can emphasize different zones in workflow by adding workflow notes of different colors. Creating different workflow zones helps to make complicated workflow schema easier to read and understand.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

Open the workflow for editing in the workflow editor.

Procedure

1 Drag a workflow note element from the Generic menu into the workflow editor.

2 Position the workflow note over the Already started scriptable task element.

3 Drag the edges of the workflow note to resize it so that it surrounds the Already started scriptable task

element.

4 Double-click the text and add a description.

For example, Path if virtual machine is already powered on.

5 Press Ctrl+E to select the background color.

6 Repeat the preceding steps to highlight other zones in the workflow.

Place a note over the vertical sequence of elements from the VM powered on? decision element to the

OK element. Add the description Start VM path.

Place a note over the startVM failed, both Timeout scriptable task elements and the Send Email

Failed scriptable task element. Add the description Error handling.

Place a note over the Send Email scriptable task element. Add the description Send email.

The following figure shows what the example workflow zones should look like.

84 VMware, Inc.

Figure 1‑4. Start VM and Send Email Example Workflow Zones

Chapter 1 Developing Workflows

What to do next

You must define the workflow's attributes and input and output parameters.

Define the Parameters of the Simple Workflow Example

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

Open the workflow for editing in the workflow editor.

Procedure

1 Click the Inputs tab in the workflow editor.

2 Right-click within the Inputs tab and select Add Parameter.

A parameter named arg_in_0 appears in the Inputs tab.

3 Click arg_in_0.

4 Type the name vm in the Choose Attribute Name dialog box and click OK.

VMware, Inc. 85

Developing with VMware vCenter Orchestrator

5 Click the Type text box and type vc:virtualm in the search text box in the parameter type dialog box.

6 Select VC:VirtualMachine from the proposed list of parameter types and click Accept.

7 Add a description of the parameter in the Description text box.

For example, type The virtual machine to power on.

8 Repeat Step 2 through Step 7 to create a second input parameter, with the following values.

Name: toAddress

Type: String

Description: The email address to send the result of this workflow to

9 Click Save at the bottom of the Inputs tab.

You defined the workflow's input parameters.

What to do next

Define the bindings between the element parameters.

Define the Simple Workflow Example Decision Bindings

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

“Define the Parameters of the Simple Workflow Example,” on page 85.

Open the workflow for editing in the workflow editor.

Procedure

On the Schema tab, click the Edit icon ( ) of the VM Powered On? decision element.

2 On the Decision tab, click the Not set (NULL) button and select vm as the decision element's input

parameter from the list of proposed parameters.

3 Select the state equals statement from the list of decision statements proposed in the drop-down menu.

A Not set button appears in the value text box, which presents you with a limited choice of possible values.

4 Select poweredOn.

5 Click Save at the bottom of the workflow editor's Schema tab.

You have defined the true or false statement against which the decision element will compare the value of the input parameter it receives.

What to do next

You must define the bindings for the other elements in the workflow.

86 VMware, Inc.

Chapter 1 Developing Workflows

Bind the Action Elements of the Simple Workflow Example

You can bind a workflow's elements together in the workflow editor. Bindings define how the action elements process input parameters and generate output parameters.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

“Define the Parameters of the Simple Workflow Example,” on page 85.

“Define the Simple Workflow Example Decision Bindings,” on page 86.

Open the workflow for editing in the workflow editor.

Procedure

On the Schema tab, click the Edit icon ( ) of the startVM action element.

2 Set the following general information on the Info tab.

Option Action

Interaction

Business Status

Description

Select No External interaction.

Select the check box and add the text Sending start VM.

Leave the text Start / Resume a VM. Return the start task.

3 Click the IN tab.

The IN tab displays the two possible input parameters available to the startVM action, vm and host.

Orchestrator automatically binds the vm parameter to vm[in-parameter] because the startVM action can only take a VC:VirtualMachine as an input parameter. Orchestrator detects the vm parameter you defined when you set the workflow input parameters and so binds it to the action automatically.

4 Set host to NULL.

This is an optional parameter, so you can set it to null. However, if you leave it set to Not set, the workflow cannot validate.

5 Click the OUT tab.

The default output parameter that all actions generate, actionResult, appears.

6 For the actionResult parameter, click Not set.

7 Click Create parameter/attribute in workflow.

The Parameter information dialog box displays the values that you can set for this output parameter. The output parameter type for the startVM action is a VC:Task object.

8 Name the parameter powerOnTask and provide a description.

For example, Contains the result of powering on a VM.

9 Click Create workflow ATTRIBUTE with the same name and click OK to exit the Parameter

information dialog box.

VMware, Inc. 87

Developing with VMware vCenter Orchestrator

10 Repeat the preceding steps to bind the input and output parameters to the vim3WaitTaskEnd and

vim3WaitToolsStarted action elements.

“Simple Workflow Example Action Element Bindings,” on page 88 lists the bindings for the

vim3WaitTaskEnd and vim3WaitToolsStarted action elements.

11 Click Save at the bottom of the workflow editor's Schema tab.

The action elements' input and output parameters are bound to the appropriate parameter types and values.

What to do next

Bind the scriptable task elements and define their functions.

Simple Workflow Example Action Element Bindings

Bindings define how the simple workflow example's action elements process input and output parameters.

When defining bindings, Orchestrator presents parameters you have already defined in the workflow as candidates for binding. If you have not defined the required parameter in the workflow yet, the only parameter choice is NULL. Click Create parameter/attribute in workflow to create a new parameter.

vim3WaitTaskEnd Action

The vim3WaitTaskEnd action element declares constants to track the progress of a task and a polling rate. The following table shows the input and output parameter bindings that the vim3WaitTaskEnd action requires.

Table 1‑7. Binding Values of the vim3WaitTaskEnd Action

Bind to Existing or

Parameter Name Binding Type

task

progress

IN Bind

IN Create

Create Parameter? Binding Values

Local Parameter: powerOnTask

Source parameter:

task[attribute]

Type: VC:Task

Description:

Contains the result of powering on a VM.

Local Parameter: progress

Source parameter:

progress[attribute]

Type: Boolean

Value: No (false)

Description:

Log progress while waiting for the vCenter Server task to complete.

88 VMware, Inc.

Table 1‑7. Binding Values of the vim3WaitTaskEnd Action (Continued)

Bind to Existing or

Parameter Name Binding Type

pollRate

actionResult

IN Create

OUT Create

Create Parameter? Binding Values

Chapter 1 Developing Workflows

Local Parameter: pollRate

Source parameter:

pollRate[attribute]

Type: number

Value: 2

Description:

Polling rate in seconds at which vim3WaitTaskEnd checks the advancement of the vCenter Server task.

Local Parameter:

actionResult[attribute]

Source parameter:

returnedManagedObject[attri bute]

Type: Any

Description:

The returned managed object from the waitTaskEnd action.

vim3WaitToolsStarted Action

The vim3WaitToolsStarted action element waits until VMware Tools have installed on a virtual machine, and defines a polling rate and a timeout period. The following table shows the input parameter bindings the

vim3WaitToolsStarted action requires.

The vim3WaitToolsStarted action element has no output, so requires no output binding.

VMware, Inc. 89

Developing with VMware vCenter Orchestrator

Table 1‑8. Binding Values of the vim3WaitToolsStarted Action

Parameter Name Binding Type

pollingRate

timeout

Bind to Existing or Create Parameter? Binding Values

IN Automatic binding

IN Bind

IN Create

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Value: Not editable, variable is

not a workflow attribute.

Description:

The virtual machine to start.

Local Parameter: pollRate

Source parameter:

pollRate[attribute]

Type: number

Description:

The polling rate in seconds at which vim3WaitTaskEnd checks the advancement of the vCenter server task.

Local Parameter: timeout

Source parameter:

timeout[attribute]

Type: number

Value: 10

Description:

The timeout limit that vim3WaitToolsStarted waits before throwing an exception.

Bind the Simple Workflow Example Scripted Task Elements

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

“Define the Parameters of the Simple Workflow Example,” on page 85.

“Define the Simple Workflow Example Decision Bindings,” on page 86.

Open the workflow for editing in the workflow editor.

Procedure

On the Schema tab, click the Edit icon (

) of the Already Started scriptable task element.

90 VMware, Inc.

2 Set the following general information in the Info tab.

Option Action

Interaction

Business Status

Description

Select No External interaction.

Select the check box and add the text VM already powered on.

Leave the text The VM is already powered on, bypassing startVM and waitTaskEnd, checking if the VM tools are up and running..

3 Click the IN tab.

Because this is a custom scriptable task element, no properties are predefined for you.

Click the Bind to workflow parameter/attribute icon ( ).

5 Select vm from the proposed list of parameters.

6 Leave the OUT and Exception tabs blank.

This element does not generate an output parameter or exception.

7 Click the Scripting tab.

8 Add the following JavaScript function.

//Writes the following event in the vCO database Server.log("VM '"+ vm.name +"' already started");

Chapter 1 Developing Workflows

9 Repeat the preceding steps to bind the remaining input parameters to the other scriptable task

elements.

“Simple Workflow Example Scriptable Task Element Bindings,” on page 91 lists the bindings for the

Start VM failed, both Timeout or Error, Send Email Failed, and the OK scriptable task elements.

10 Click Save at the bottom of the workflow editor's Schema tab.

You have bound the scriptable task elements to their input and output parameters and provided the scripting that defines their function.

What to do next

You must define the exception handling.

Simple Workflow Example Scriptable Task Element Bindings

Bindings define how the simple workflow example's scriptable task elements process input parameters. You also bind the scriptable task elements to their JavaScript functions.

Start VM Failed Scriptable Task

The Start VM Failed scriptable task element handles any exceptions that the startVM action throws by setting the content of an email notification about the failure to start the virtual machine, and writing the event in the Orchestrator log.

The following table shows the input and output parameter bindings that the Start VM Failed scriptable task element requires.

VMware, Inc. 91

Developing with VMware vCenter Orchestrator

Table 1‑9. Bindings of the Start VM Failed Scriptable Task Element

Parameter Name Binding Type

errorCode

body

Bind to Existing or Create Parameter? Binding Values

IN Bind

IN Create

OUT Create

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Description:

The virtual machine to power on.

Local Parameter: errorCode

Source parameter:

errorCode[attribute]

Type: string

Description:

Catch any exceptions while powering on a VM.

Local Parameter: body

Source parameter:

body[attribute]

Type: string

Description: The email body

The Start VM Failed scriptable task element performs the following scripted function.

body = "Unable to execute powerOnVM_Task() on VM '"+vm.name+"', exception found: "+errorCode; //Writes the following event in the vCO database Server.error("Unable to execute powerOnVM_Task() on VM '"+vm.name, "Exception found: "+errorCode);

Timeout 1 Scriptable Task Element

The Timeout 1 scriptable task element handles any exceptions that the vim3WaitTaskEnd action throws by setting the content of an email notification about the failure of the task, and writing the event in the Orchestrator log.

The following table shows the input and output parameter bindings that the Timeout 1 scriptable task element requires.

92 VMware, Inc.

Table 1‑10. Bindings of the Timeout 1 Scriptable Task Element

Bind to Existing or

Parameter Name Binding Type

errorCode

body

IN Bind

OUT Bind

Create Parameter? Binding Values

Chapter 1 Developing Workflows

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Description:

The virtual machine to start.

Local Parameter: errorCode

Source parameter:

errorCode[attribute]

Type: string

Description:

Catch any exceptions while powering on a VM.

Local Parameter: body

Source parameter:

body[attribute]

Type: string

Description: The email body

The Timeout 1 scriptable task element requires the following scripted function.

body = "Error while waiting for poweredOnVM_Task() to complete on VM '"+vm.name+"', exception found: "+errorCode; //Writes the following event in the vCO database Server.error("Error while waiting for poweredOnVM_Task() to complete on VM '"+vm.name, "Exception found: "+errorCode);

Timeout 2 Scriptable Task Element

The Timeout 2 scriptable task element handles any exceptions that the vim3WaitToolsStarted action throws by setting the content of an email notification about the failure of the task, and writing the event in the Orchestrator log.

The following table shows the input and output parameter bindings that the Timeout 2 scriptable task element requires.

VMware, Inc. 93

Developing with VMware vCenter Orchestrator

Table 1‑11. Bindings of the Timeout 2 Scriptable Task Element

Parameter Name Binding Type

errorCode

body

Bind to Existing or Create Parameter? Binding Values

IN Bind

OUT Bind

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Description:

The virtual machine to power on.

Local Parameter: errorCode

Source parameter:

errorCode[attribute]

Type: string

Description:

Catch any exceptions while powering on a VM.

Local Parameter: body

Source parameter:

body[attribute]

Type: string

Description: The email body

The Timeout 2 scriptable task element requires the following scripted function.

body = "Error while waiting for VMware tools to be up on VM '"+vm.name+"', exception found: "+errorCode; //Writes the following event in the vCO database Server.error("Error while waiting for VMware tools to be up on VM '"+vm.name, "Exception found: "+errorCode);

OK Scriptable Task Element

The OK scriptable task element receives notice that the virtual machine has started successfully, sets the content of an email notification about the successful start of the virtual machine, and writes the event in the Orchestrator log.

The following table shows the input and output parameter bindings that the OK scriptable task element requires.

Table 1‑12. Bindings of the OK Scriptable Task Element

Bind to Existing or

Parameter Name Binding Type

body

IN Bind

OUT Bind

Create Parameter? Binding Values

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Description:

The virtual machine to power on.

Local Parameter: body

Source parameter:

body[attribute]

Type: string

Description: The email body

94 VMware, Inc.

Chapter 1 Developing Workflows

The OK scriptable task element requires the following scripted function.

body = "The VM '"+vm.name+"' has started successfully and is ready for use"; //Writes the following event in the vCO database Server.log(body);

Send Email Failed Scriptable Task Element

The Send Email Failed scriptable task element receives notice that the sending of the email failed, and writes the event in the Orchestrator log.

The following table shows the input parameter bindings that the Send Email Failed scriptable task element requires.

Table 1‑13. Bindings of the Send Email Failed Scriptable Task Element

Bind to Existing or

Parameter Name Binding Type

toAddress

emailErrorCode

IN Bind

IN Create

Create Parameter? Binding Values

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Description:

The virtual machine to power on.

Local Parameter: toAddress

Source parameter:

toAddress[in-parameter]

Type: string

Description:

The email address of the person to inform of the result of this workflow

Local Parameter:

emailErrorCode

Source parameter:

emailErrorCode[attrbute]

Type: string

Description:

Catch any exceptions while sending an email

The Send Email Failed scriptable task element requires the following scripted function.

//Writes the following event in the vCO database Server.error("Couldn't send result email to '"+toAddress+"' for VM '"+vm.name, "Exception found: "+emailErrorCode);

Send Email Scriptable Task Element

The purpose of the Start VM and Send Email workflow is to inform an administrator when it starts a virtual machine. To do so, you must define the scriptable task that sends an email. To send the email, the Send Email scriptable task element needs an SMTP server, addresses for the sender and recipient of the email, the email subject, and the email content.

The following table shows the input and output parameter bindings that the Send Email scriptable task element requires.

VMware, Inc. 95

Developing with VMware vCenter Orchestrator

Table 1‑14. Bindings of the Send Email Scriptable Task Element

Parameter Name Binding Type

toAddress

body

smtpHost

fromAddress

subject

Bind to Existing or Create Parameter? Binding Values

IN Bind

IN Create

Local Parameter: vm

Source parameter: vm[inparameter]

Type: VC:VirtualMachine

Description:

The virtual machine to power on.

Local Parameter: toAddress

Source parameter:

toAddress[in-parameter]

Type: string

Description:

The email address of the person to inform of the result of this workflow

Local Parameter: body

Source parameter:

body[attribute]

Type: string

Description: The email body

Local Parameter: smtpHost

Source parameter:

smtpHost[attribute]

Type: string

Description:

The email SMTP server

Local Parameter: fromAddress

Source parameter:

fromAddress[attribute]

Type: string

Description:

The email address of the sender

Local Parameter: subject

Source parameter:

subject[attribute]

Type: string

Description:

The email subject

The Send Email scriptable task element requires the following scripted function.

//Create an instance of EmailMessage var myEmailMessage = new EmailMessage() ;

//Apply methods on this instance that populate the email message myEmailMessage.smtpHost = smtpHost; myEmailMessage.fromAddress = fromAddress; myEmailMessage.toAddress = toAddress; myEmailMessage.subject = subject; myEmailMessage.addMimePart(body , "text/html");

96 VMware, Inc.

Chapter 1 Developing Workflows

//Apply the method that sends the email message myEmailMessage.sendMessage(); System.log("Sent email to '"+toAddress+"'");

Define the Simple Workflow Example Exception Bindings

You define exception bindings in the Schema tab in the workflow editor. Exception bindings define how elements process errors.

The following elements in the workflow return exceptions: startVM, vim3WaitTaskEnd, Send Email, and

vim3WaitToolsStarted.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

“Define the Parameters of the Simple Workflow Example,” on page 85.

“Define the Simple Workflow Example Decision Bindings,” on page 86.

“Bind the Action Elements of the Simple Workflow Example,” on page 87.

“Bind the Simple Workflow Example Scripted Task Elements,” on page 90.

Open the workflow for editing in the workflow editor.

Procedure

On the Schema tab, click the Edit icon ( ) of the startVM action element.

2 Click the Exception tab.

3 Click the Not set button.

4 Select errorCode from the proposed list.

5 Repeat the preceding steps to set the exception binding to errorCode for both vim3WaitTaskEnd and

vim3WaitToolsStarted.

Click the Edit icon ( ) of the Send Email scriptable task element.

7 Click the Exception tab.

8 Click the Not set button.

9 Select emailErrorCode from the proposed list.

10 Click Save at the bottom of the workflow editor's Schema tab.

You have defined the exception binding for the elements that return exceptions.

What to do next

You must set the read and write properties on the attributes and parameters.

VMware, Inc. 97

Developing with VMware vCenter Orchestrator

Set the Read-Write Properties for Attributes of the Simple Workflow Example

You can define whether parameters and attributes are read-only constants or writeable variables. You can also set limitations on the values that users can provide for input parameters.

Setting certain parameters to read-only allows other developers to adapt the workflow or to modify it without breaking the workflow's core function.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

“Define the Parameters of the Simple Workflow Example,” on page 85.

“Define the Simple Workflow Example Decision Bindings,” on page 86.

“Bind the Action Elements of the Simple Workflow Example,” on page 87.

“Bind the Simple Workflow Example Scripted Task Elements,” on page 90.

“Define the Simple Workflow Example Exception Bindings,” on page 97.

Open the workflow for editing in the workflow editor.

Procedure

1 Click the General tab at the top of the workflow editor.

Under Attributes is a list of all the defined attributes, with check boxes next to each attribute. When you select these check boxes, you set attributes as read-only.

2 Select the check boxes to make the following attributes read-only constants:

progress

pollRate

timeout

smtpHost

fromAddress

subject

You have defined which of the workflow's attributes are constants and which are variables.

What to do next

Set the parameter properties and place constraints on the possible values for that parameter.

Set the Simple Workflow Example Parameter Properties

You can set the parameter properties in the workflow editor. Setting the parameter properties affects the behavior of the parameter, and places constraints on the possible values for that parameter.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

98 VMware, Inc.

“Define the Parameters of the Simple Workflow Example,” on page 85.

“Define the Simple Workflow Example Decision Bindings,” on page 86.

“Bind the Action Elements of the Simple Workflow Example,” on page 87.

“Bind the Simple Workflow Example Scripted Task Elements,” on page 90.

“Define the Simple Workflow Example Exception Bindings,” on page 97.

Open the workflow for editing in the workflow editor.

Procedure

1 Click the Presentation tab in the workflow editor.

The two input parameters you defined for this workflow are listed.

2 Click the (VC:VirtualMachine)vm parameter.

3 Add a description in the General tab in the bottom half of the screen.

For example, type The virtual machine to start.

4 Click the Properties tab in the bottom half of the screen.

On this tab, you can set the properties for the (VC:VirtualMachine)vm parameter.

Chapter 1 Developing Workflows

Click the Add property icon ( ).

6 From the list of proposed properties, select the Mandatory input property, click Ok, and set its value to

Yes.

When you enable this property, users cannot run the Start VM and Send Email workflow without providing a virtual machine to start.

Click the Add property icon ( ).

8 From the list of proposed properties, select Select value as, click Ok, and select list from the list of

possible values.

When you set this property, you set how the user selects the value of the (VC:VirtualMachine)vm input parameter.

9 Click the (string)toAddress parameter in the top half of the Presentation tab.

10 Add a description in the Description tab in the bottom half of the screen.

For example, type The email address of the person to notify.

Click the Properties tab for (string)toAddress and click the Add property icon (

12 From the list of proposed properties, select the Mandatory input property, click Ok, and set its value to

Yes.

Click the Add property icon ( ).

14 From the list of proposed properties, select Matching regular expression and click Ok.

This property allows you to set constraints on what users can provide as input .

15 Click the Value text box for Matching regular expression and set the constraints to

[a-zA-Z0-9_%-+.]+@[a-zA-Z0-9-.]+\.[a-zA-Z]{2,4}.

Setting these constraints limits user input to characters that are appropriate for email addresses. If the user tries to input any other character for the email address of the recipient when they start the workflow, the workflow does not start.

VMware, Inc. 99

Developing with VMware vCenter Orchestrator

You have made both parameters mandatory, defined how the user can select the virtual machine to start, and limited the characters that can be input for the recipient's email address.

What to do next

You must create the layout, or presentation, of the input parameters dialog box in which users specify a workflow's input parameter values when they run it.

Set the Layout of the Simple Workflow Example Input Parameters Dialog Box

You create the layout or presentation of the input parameters dialog box in the workflow editor. The input parameters dialog box opens when users run a workflow that needs input parameters to run.

The layout you define in the Presentation tab also defines the layout of the input parameter dialog boxes for workflows you run using a Web view.

Prerequisites

Complete the following tasks.

“Create the Simple Workflow Example,” on page 81.

“Create the Schema of the Simple Workflow Example,” on page 82.

“Define the Parameters of the Simple Workflow Example,” on page 85.

“Define the Simple Workflow Example Decision Bindings,” on page 86.

“Bind the Action Elements of the Simple Workflow Example,” on page 87.

“Bind the Simple Workflow Example Scripted Task Elements,” on page 90.

“Define the Simple Workflow Example Exception Bindings,” on page 97.

“Set the Read-Write Properties for Attributes of the Simple Workflow Example,” on page 98.

“Set the Simple Workflow Example Parameter Properties,” on page 98.

Open the workflow for editing in the workflow editor.

Procedure

1 Click the Presentation tab in the workflow editor.

2 Right-click the Presentation node in the presentation hierarchical list and select Create display group.

A New step node and a New group sub-node appear under the Presentation node.

3 Right-click New step and select Delete.

Because this workflow has only two parameters, you do not need multiple layers of display sections in the input parameters dialog box.

4 Double-click New group to edit the group name and press Enter.

For example, name the display group Virtual Machine.

The text you enter here appears as a heading in the input parameter dialog box when users start the workflow.

5 In the Description text box of the General tab at the bottom of the Presentation tab, provide a

description for the new display group.

For example, type Select the virtual machine to start.

The text you type here appears as a prompt in the input parameter dialog box when users start the workflow.

100 VMware, Inc.

VMware vCenter Orchestrator - 5.5.1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Developing with VMware vCenter Orchestrator

Developing Workflows 1

Key Concepts of Workflows

Workflow Parameters

Workflow Attributes

Workflow Schema

Workflow Presentation

Workflow Tokens

Phases in the Workflow Development Process

Access Rights for the Orchestrator Client

Testing Workflows During Development

Creating and Editing a Workflow

Create a Workflow

Edit a Workflow

Edit a Workflow from the Standard Library

Workflow Editor Tabs

Provide General Workflow Information

Defining Attributes and Parameters

Define Workflow Parameters

Define Workflow Attributes

Attribute and Parameter Naming Restrictions

Workflow Schema

View Workflow Schema

Building a Workflow in the Workflow Schema

Edit a Workflow Schema

Copy Workflow Schema Elements

Promote Input and Output Parameters

Modify Search Results

Schema Elements

Schema Element Properties

Edit the Global Properties of a Schema Element

Schema Element Properties Tabs

Links and Bindings

Logical Flow of a Workflow

Element Links

Create Standard Path Links

Data Flow of a Workflow

Element Bindings

Define Element Bindings

Decisions

Create Decision Element Links

Delete a Linked Decision Element

Create Workflow Branches Using Decisions

Exception Handling

Create Exception Bindings

Foreach Elements and Composite Types

Define a Foreach Element

Define a Composite Type in a Foreach Element

Obtaining Input Parameters from Users When a Workflow Starts

Creating the Input Parameters Dialog Box In the Presentation Tab

Create the Presentation of the Input Parameters Dialog Box

Setting Parameter Properties

Set Parameter Properties

Workflow Input Parameter Properties

Predefined Constant Values for OGNL Expressions

Add a User Interaction to a Workflow

Set the User Interaction security.group Attribute

Set the timeout.date Attribute to an Absolute Date

Calculate a Relative Timeout for User Interactions

Set the timeout.date Attribute to a Relative Date

Define the External Inputs for a User Interaction

Define User Interaction Exception Behavior

Create the Input Parameters Dialog Box for the User Interaction

Respond to a Request for a User Interaction

Calling Workflows Within Workflows

Workflow Elements that Call Workflows

Propagate Workflow Changes to other Workflows

Propagate the Input Parameters and Presentation of a Child Workflow to the Parent Workflow

Call a Workflow Synchronously

Call a Workflow Asynchronously

Schedule a Workflow

Prerequisites for Calling a Remote Workflow from Within Another Workflow

Call Several Workflows Simultaneously

Running a Workflow on a Selection of Objects

Implement the Start Workflows in a Series and Start Workflows in Parallel Workflows
