VIZIO VA User Guide
VIZIO VA SERIES User Manual
Dear VIZIO Customer,
Congratulations on your new VIZIO High Definition LCD Television purchase. This User Manual
covers the following models: M190VA, M220VA and M260VA in black color and M190VA-W,
M220VA-W and M260VA-W in white color; for specific difference between the models please refer to
the specification sheets in Chapter 11. Thank you for your support. For maximum benefit of your set,
please read these instructions before making any adjustments, and retain them for future reference.
We hope you will experience many years of enjoyment from your new VIZIO HDTV High Definition
Television.
For assistance, please call 877-MYVIZIO (877-698-4946) or e-mail us at www.VIZIO.com.
To purchase or inquire about accessories and installation services for your VIZIO HDTV, please visit
our website at
www.VIZIO.com or call toll free at (888) 849-4623.
We recommend you register your VIZIO HDTV either at our website
www.VIZIO.com or fill out and
mail your registration card. For peace of mind and to protect your investment beyond the standard
warranty, VIZIO offers on-site extended warranty service plans. These plans give additional coverage
during the standard warranty period. Visit our website or call us to purchase a plan.
Write down the serial number located on the back of your HDTV for easy reference when obtaining
warranty support:
Serial #: _____________________ Purchase Date _____________________
VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.
HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc.
MEETS VALUE AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION. © 2008 VIZIO INC. ALL RIGHTS
RESERVED.
and are trademarks of SRS Labs, Inc.
This product qualifies for ENERGY STAR in the “factory default (Home Use)” setting and this is the setting in which
power savings will be achieved. Changing the factory default picture setting or enabling other features will increase
power consumption that could exceed the limits necessary to qualify for Energy Star rating.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES
USED ARE FOR ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION
Version 2/3/2010 1
www.VIZIO.com
VIZIO VA SERIES User Manual
Important Safety Instructions
Your HDTV is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent your HDTV from being damaged, the following
instructions should be observed for the installation, use, and maintenance of your HDTV. Read
the following safety instructions before operating your HDTV. Keep these instructions in a safe
place for future reference.
• To reduce the risk of electric shock or component damage, switch off the power before
connecting other components to your HDTV.
• Unplug the power cord before cleaning your HDTV. A damp cloth is sufficient for cleaning your
HDTV. Do not use a liquid or a spray cleaner for cleaning your HDTV. Do not use abrasive
cleaners.
• Always use the accessories recommended by the manufacturer to insure compatibility.
• When moving your HDTV from an area of low temperature to an area of high temperature,
condensation may form in the housing. Wait before turning on your HDTV to avoid causing fire,
electric shock, or component damage.
• Use only with the cart, stand, tripod, bracket, or table specified by manufacturer or sold with your
HDTV. When a cart is used, use caution when moving the cart/HDTV combination to avoid injury
from tip-over. Do not place your HDTV on an unstable cart, stand, or table. If your HDTV falls, it
can injure a person and cause serious damage to your HDTV. Use only a cart or stand
recommended by the manufacturer or sold with your HDTV.
• A distance of at least 3 feet should be maintained between your HDTV and any heat source, such
as a radiator, heater, oven, amplifier etc. Do not install your HDTV close to smoke. Operating
your HDTV close to smoke or moisture may cause fire or electric shock.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure
reliable operation of your HDTV and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your HDTV in a bookcase or cabinet unless proper
ventilation is provided.
• Never push any object into the slots and openings on your HDTV cabinet. Do not place any
objects on the top of your HDTV. Doing so could short circuit parts causing a fire or electric shock.
Never spill liquids on your HDTV.
• Your HDTV should be operated only from the type of power source indicated on the label. If you
are not sure of the type of power supplied to your home, consult your dealer or local power
company.
• Do not apply pressure or throw objects at your HDTV. This may compromise the integrity of the
display. The manufacturer’s warranty does not cover user abuse or improper installations.
• The power cord must be replaced when using different voltage than the voltage specified. For
more information, contact your dealer.
• Your HDTV is equipped with a three-pronged grounded plug (a plug with a third grounding
pin). This plug will fit only into a grounded power outlet. This is a safety feature. If your outlet
does not accommodate the three-pronged, have an electrician install the
correct outlet, or use an adapter to ground your HDTV safely. Do not
defeat the safety purpose of the grounded plug.
• When connected to a power outlet, power is always flowing into your
HDTV. To totally disconnect power, unplug the power cord.
• The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of un-isolated, dangerous voltage
within the inside of your HDTV that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
• The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and servicing instructions in the literature
accompanying your HDTV.
2
www.VIZIO.com
VIZIO VA SERIES User Manual
• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
• The wall socket should be installed near your HDTV and easily accessible.
• Only power of the marked voltage can be used for your HDTV. Any other voltage than the
specified voltage may cause fire or electric shock
• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power
cord during electrical storms.
• Unplug your HDTV during a lightning storm or when it will not be used for long period of time.
This will protect your HDTV from damage due to power surges.
• Do not attempt to repair or service your HDTV yourself. Opening or removing the back cover may
expose you to high voltages, electric shock, and other hazards. If repair is required, contact your
dealer and refer all servicing to qualified service personnel.
• Keep your HDTV away from moisture. Do not expose your HDTV to rain or moisture. If water
penetrates into your HDTV, unplug the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.
• Do not use your HDTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug
the power cord and contact your dealer immediately. Do not try to repair your HDTV yourself.
• Avoid using dropped or damaged appliances. If your HDTV is dropped and the housing is
damaged, the internal components may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your HDTV may cause fire or electric shock.
• Do not install your HDTV in an area with heavy dust or high humidity. Operating your HDTV in
environments with heavy dust or high humidity may cause fire or electric shock.
• Follow instructions for moving your HDTV. Ensure that the power cord and any other cables are
unplugged before moving your HDTV.
• When unplugging your HDTV, hold the power plug, not the cord. Pulling on the power cord may
damage the wires inside the cord and cause fire or electric shock. When your HDTV will not be
used for an extended period of time, unplug the power cord.
• To reduce risk of electric shock, do not touch the connector with wet hands.
• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to
leak which can damage the remote control or injure the operator.
• If any of the following occurs, contact the dealer:
o The power cord fails or frays.
o Liquid sprays or any object drops into your HDTV.
o Your HDTV is exposed to rain or other moisture.
o Your HDTV is dropped or damaged in any way.
o The performance of your HDTV changes substantially.
Version 2/3/2010 3
www.VIZIO.com
VIZIO VA SERIES User Manual
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the
grounding electrode.
Lightning Protection
For added protection of the TV during a
lightning storm or when it is left unattended
or unused for long periods of time, unplug the
TV from the wall outlet and disconnect the
antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such power
lines or circuits.
Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.
FCC Bulletin for New TV Owners
The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your local
television stations may switch sooner. After the switch, analog-only television sets that receive TV
programming through an antenna will need a converter box to continue to receive over-the-air TV. Watch
your local stations to find out when they will turn off their analog signal and switch to digitalonly broadcasting. Analog-only TVs should continue to work as before to receive low power,
Class A or translator television stations and with cable and satellite TV services, gaming consoles,
VCRs, DVD players, and similar products.
For additional information, please contact the parties listed below, as appropriate:
FCC (US Federal Communications Commission)
http://www.fcc.gov/
Phone: 1-888-CALL-FCC (1-888-225-5322)
TTY: 1-888-TELL-FCC (1-888-835-5322)
Fax: 1-866-418-0232
E-mail: fccinfo@fcc.gov
NTIA (National Telecommunications and Information Administration)
http://www.ntia.doc.gov/
Listings of US Television Stations: http://www.high-techproductions.com/usTVstations.htm
Note: Your HDTV comes with a built-in tuner capable of processing digital broadcasts. No extra
converter box is needed.
1-888-DTV-2009
4
www.VIZIO.com
VIZIO VA SERIES User Manual
Table of Contents
Important Safety Instructions ..................................................................................................................... 2
Television Antenna Connection Protection ............................................................................................... 4
FCC Bulletin for New TV Owners .............................................................................................................. 4
CHAPTER 1 SETTING UP YOUR HDTV ..................................................................................................... 8
Attaching the TV Stand.............................................................................................................................. 8
Unpack the TV and stand base: ............................................................................................................................. 8
Attach the TV stand base: ...................................................................................................................................... 8
Detach the TV stand base: ..................................................................................................................................... 9
Wall Mounting Your HDTV ........................................................................................................................ 9
CHAPTER 2 BASIC CONTROLS AND CONNECTIONS .......................................................................... 10
Front Panel .............................................................................................................................................. 10
Side Control Panel ................................................................................................................................... 10
Rear Panel Connections.......................................................................................................................... 11
Side Panel Connections .......................................................................................................................... 12
CHAPTER 3 VIZIO REMOTE CONTROL .................................................................................................. 13
Installing the Batteries ............................................................................................................................. 13
Remote Control Range ............................................................................................................................ 13
VIZIO Remote Control Precautions ......................................................................................................... 13
Remote Control Buttons .......................................................................................................................... 14
CHAPTER 4 GETTING STARTED ............................................................................................................. 15
CHAPTER 5 USING YOUR HDTV FOR THE FIRST TIME ....................................................................... 16
Select Input Source ................................................................................................................................. 16
Watching a TV Program .......................................................................................................................... 16
Viewing Digital TV Program Information ................................................................................................. 17
INFO Button ......................................................................................................................................................... 17
CHAPTER 6 CONNECTING EQUIPMENT ................................................................................................ 18
Which Video Connection Should I Use ? ................................................................................................ 18
Connecting Your DVD Player .................................................................................................................. 22
Using HDMI (Best) ............................................................................................................................................... 22
Connecting Coaxial (RF) ......................................................................................................................... 24
Using Your Antenna or Digital Cable for Standard TV or Digital TV ..................................................................... 24
Connecting Your VCR or Video Camera ................................................................................................. 24
Connecting a Home Theater System ...................................................................................................... 25
Connecting a Computer........................................................................................................................... 25
CHAPTER 7 YOUR HDTV SETTINGS ...................................................................................................... 26
Using the HDTV Settings Menu .............................................................................................................. 26
TV Menu .................................................................................................................................................. 26
Timer Menu ............................................................................................................................................. 26
Photo Menu ............................................................................................................................................. 26
Wide Menu .............................................................................................................................................. 26
Audio Menu ............................................................................................................................................. 27
Picture Menu ........................................................................................................................................... 27
Parental Menu ......................................................................................................................................... 27
Help Menu ............................................................................................................................................... 27
CC (Closed Caption) Menu ..................................................................................................................... 27
CHAPTER 8 ADJUSTING YOUR HDTV SETTINGS ................................................................................ 28
TV Settings .............................................................................................................................................. 28
Version 2/3/2010 5
www.VIZIO.com
VIZIO VA SERIES User Manual
Input ..................................................................................................................................................................... 28
PC Settings .......................................................................................................................................................... 29
Timer Menu ............................................................................................................................................. 30
Photo Menu ............................................................................................................................................. 30
Wide Menu .............................................................................................................................................. 31
Audio Menu ............................................................................................................................................. 33
Picture Menu ........................................................................................................................................... 34
Parental Menu ......................................................................................................................................... 36
Help Menu ............................................................................................................................................... 38
System Info .......................................................................................................................................................... 38
CC (Closed Caption) Menu ..................................................................................................................... 38
CHAPTER 9 MAINTENANCE AND TROUBLESHOOTING ..................................................................... 39
Cleaning the TV and Remote Control ..................................................................................................... 39
Troubleshooting Guide ............................................................................................................................ 39
Telephone & Technical Support .............................................................................................................. 42
Compliance .............................................................................................................................................. 42
FCC Class B Radio Interference Statement ........................................................................................... 43
CHAPTER 10 SPECIFICATIONS .............................................................................................................. 44
Preset PC Resolutions ......................................................................................................................................... 47
CHAPTER 11 WARRANTY ........................................................................................................................ 49
Index ........................................................................................................................................................ 51
6
www.VIZIO.com
VIZIO VA SERIES User Manual
Opening the Package
Your HDTV and its accompanying accessories are carefully packed in a cardboard carton that has been
designed to protect it from transportation damage. Once you have opened the carton, check that your
HDTV is in good condition and that all of the contents are included.
The screen surface can easily be scratched or broken, so handle your HDTV gently and never place your
HDTV with the screen facing downwards on a surface without protective padding.
IMPORTANT: Save the carton and packing material for future shipping.
Package Contents
• VIZIO M190VA or M220VA or M260VA
• VIZIO remote
control VR10 or
VR10W
(Depending on your
TV color)
• 2 AA batteries for
the remote control
• This user manual
• Cleaning cloth
• Quick Setup Guide
• Registration Card
Reminder: These models are either black or white.
Caution:
of the display. The manufacturer’s warranty does not cover user abuse or improper installations.
Do not apply pressure or throw objects at your HDTV. This may compromise the integrity
HDTV Accessories and Services
Additional certified accessories for your HDTV are sold separately, including:
• Wall mounts
• High Definition cables
• Extra or replacement remote controls
• Sound Bars
• Blu-ray DVD Players
VIZIO also offers installation services and extended warranty services for your HDTV.
To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our website
at www.VIZIO.com or call us toll free at 877-MYVIZIO (877-698-4946).
Version 2/3/2010 7
www.VIZIO.com
VIZIO VA SERIES User Manual
Chapter 1 Setting Up Your HDTV
• Read this user manual carefully before installing your HDTV.
• The power consumption of your HDTV is
When an extension cord is required, use one with the correct power rating. The cord must be
grounded and the grounding feature must not be compromised.
• Install your HDTV on a flat surface to avoid tipping.
• For proper ventilation, you must allow a 1” space between the back of your HDTV and the wall.
• Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the
service life of the electronic components.
• Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent
poor ventilation and excessive component damage.
• If you want to mount your HDTV on the wall, see below for additional information.
• Read this user manual carefully before installing your HDTV.
VIZIO offers professional installation. Contact VIZIO for more information on these services at 877MYVIZIO (877-698-4946) or www.VIZIO.com.
Attaching the TV Stand
Unpack the TV and stand base:
1. Remove the remote control, batteries,
and base.
2. Remove the TV from the box and lay it
face down on a clean, flat surface.
Note: Make sure that the surface is free of debris to prevent the TV screen from getting scratched.
25W (M190VA), 28W (M220VA and 44W (M260VA) average.
Attach the TV stand base:
1. Align the stand hooks
with the holes at the
bottom surface of TV.
2. Push the base gently into
place.
3. A snap sound could be heard, it means that the
base is locked into place.
8
www.VIZIO.com
VIZIO VA SERIES User Manual
Detach the TV stand base:
1. Lay the HDTV face
down on a clean, flat
surface.
2. Pull up on the locking
clip, release it, and
then slowly slide the
base towards you.
Wall Mounting Your HDTV
Your HDTV can be mounted on the wall for viewing. If you choose to mount your HDTV on the wall, follow
the instructions below.
1. Write down the serial number located on the back of your HDTV in the space provided on page 1 to
have it handy if you need to call for support.
2. Remove the stand base and neck:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft,
flat surface to prevent damage to the
screen.
c. Remove the TV stand base per above
instructions.
3. Mount your HDTV on the wall:
a. Attach your HDTV to a wall mount
(sold separately) using the mounting
holes in the back panel of your HDTV
(see illustration at the right).
b. Read the instructions that came with your specific wall mount to properly hang your HDTV.
Wall Mounting Specifications
Screw Size
Screw Length
Screw Pitch
Hole Pattern
• M4
• 10mm
• 0.7 mm
•
VESA standard 75 x 75 mm (M190VA and M220VA)
VESA standard 100 x 100 mm (M260VA)
NOTE: If using wall mounts different from our certified ones, please verify that they are
UL/CSA/ETL listed wall mount brackets with suitable weight specs.
Version 2/3/2010 9
www.VIZIO.com
VIZIO VA SERIES User Manual
Chapter 2 Basic Controls and Connections
Front Panel
Remote Control Sensor—Point the remote
control directly at this window on the lower right
corner of your HDTV for the best response to
the remote signal.
Side Control Panel
1. LIGHT SENSOR—Activate it through the OSD menu if
you would like the TV to automatically adjust to the ambient
lighting of the room. This location applies only to the 19”
models, the 22” and 26” models have the sensor placed on
the power light indicator area.
2. POWER (
button once. Press the button again to turn your HDTV off.
3. MENU—Press to launch the on-screen menu. If a sub-
menu is active, this button will proceed to the next level.
4. CH
While the menu is active, these buttons function as up and
down controls.
5. VOL
volume. While the menu is active, these buttons function as
left and right controls.
6. INPUT (SELECT)—Press to cycle through the various
devices connected to your TV (called Inputs). The inputs
cycle in the following sequence: DTV/TV, AV (Composite),
COMPONENT, HDMI 1, HDMI 2, RGB (VGA) and PHOTO.
Once you have stepped through the entire sequence, you
will return to the beginning. If a sub-menu is active, pressing
this button will return to the previous menu level.
Additionally, when the menu is active, this button confirms the menu function to be adjusted.
▲/▼—Press to change the channels up or down.
▲/▼—Press to increase or decrease the speaker
)—Turn your HDTV on by pressing the
10
www.VIZIO.com
VIZIO VA SERIES User Manual
Rear Panel Connections
1. HDMI 1—Connect digital video devices such as a DVD player or Set-Top Box through these all
digital connectors. For users who want to connect to a DVI enabled device, use a DVI-HDMI
cable and connect the analog audio output of the device to the 1/8” stereo jack called AUDIO, a
Y-adapter may be needed.
HDMI 2—Connect another digital video device such as a DVD player or Set-Top Box through
this all digital connector. For users who want to connect to a DVI enabled device, use a DVIHDMI cable and connect the analog audio output of the device to the 1/8” stereo jack called
AUDIO, a Y-adapter may be needed. Your VIZIO Certified HDMI-DVI cables are available for
purchase from www.VIZIO.com or by calling 877-MYVIZIO (877-698-4946).
2. SPDIF—(OPTICAL) When digital TV is selected for viewing, the audio associated with the
programming will be available on the SPDIF Optical connector for connection to a VIZIO Sound
Bar or your Home Theater system.
3. RGB PC— Connect the video and audio from a computer here. Connect a 1/8” mini plug stereo
connector from the computer to the TV if you want the sound to come from the HDTV speakers.
4. DTV/TV— Connect to an antenna or digital cable source. For digital TV stations in your area
visit www.antennaweb.org. For cable and satellite set-top boxes, we recommend that you use a
HDMI or component cable connection for high definition image quality.
5. COMPONENT (Y Pb/Cb Pr/Cr)—Connect component video devices such as a DVD Player or
set top box here.
Below picture applies to black color models
Version 2/3/2010 11
www.VIZIO.com
VIZIO VA SERIES User Manual
Side Panel Connections
1. HEADPHONES— Connect your personal
headphones here.
2. AV— Connect composite video devices, such as a
VCR or game console. Use the white and red
connectors to connect the external audio from the
same source.
3. USB PORT—Insert a FAT/FAT32 formatted USB
drive to view pictures. This port is also used for
service.
Below picture applies to black color models
12
www.VIZIO.com
Chapter 3 VIZIO Remote Control
Installing the Batteries
1. Remove the battery cover.
2. Insert two AA batteries into the remote control. Make
sure that you match the (+) and (-) symbols on the
batteries with the (+) and (-) symbols inside the
battery compartment.
3. Replace the battery cover.
Precautionary Tips for Inserting the Batteries:
• Only use AA batteries.
• Do not mix new and old batteries. This may
result in cracking or leakage that may cause a
fire or lead to personal injury.
• Inserting the batteries incorrectly may also result
in cracking or leakage that may cause a fire or
lead to personal injury.
• Dispose of batteries according to local
hazardous waste regulations.
• Keep the batteries away from children and pets.
VIZIO VA SERIES User Manual
Remote Control Range
• Point the remote control directly at this sensor
for the best response to the remote signal.
• Do not place any obstacles between the
remote control and the remote control sensor.
• The effective range of the remote control is
approximately 22 feet (7 meters) from the
front of the remote control sensor, 30° to the
left and right, 15° up and down.
VIZIO Remote Control Precautions
• The remote control should be kept dry and away from heat sources. Avoid humidity.
• If the TV responds erratically to the remote control or does not respond at all, check the batteries.
If the batteries are low or exhausted, replace them with fresh batteries.
• When not using the remote control for a long period of time, remove the batteries.
• Do not take the batteries apart, heat them, or throw them into a fire.
• Do not subject the remote control to undue physical stress, such as striking or dropping it.
• Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp
cloth.
Version 2/3/2010 13
www.VIZIO.com
VIZIO VA SERIES User Manual
Remote Control Buttons
INPUT—Press to cycle through the various devices connected to your TV
(called Inputs). The inputs cycle in the following sequence: DTV/TV, AV
(Composite), COMPONENT, HDMI 1, HDMI 2, RGB and USB. Once you
have stepped through the entire sequence, you will return to the beginning.
POWER (
)—Press to turn the TV on from the Standby mode. Press it
again to return to the Standby mode.
TV—Press to select the TV input.
AV—Press to select the AV (Composite) input.
COMP—Press to select the Component input.
HDMI—Press to select the HDMI input. Press repeatedly to cycle between
both HDMI inputs.
SLEEP—Press to select the Sleep Timer options: Off, 30, 60, 90 or 120
minutes.
WIDE—Press to cycle through the available aspect ratios or screen
formats, the options are Normal, Wide, Zoom, Panoramic and Stretch.
CC (Closed Caption)—Pres to select the Closed Caption option. The
options are: Off, CC1, CC2, CC3 and CC4 for analog signals and Off,
Service1 through Service6 for digital signals when they are being
broadcast.
EXIT— Press to exit from open menus.
Up (▲), Down (▼), Left (◄) or Right (►)
navigation buttons — Press to navigate open
menus, adjust other TV settings such as
Brightness and Contrast, or turn menu options On
and Off.
MENU/OK— Press to bring up the OSD menu.
When the OSD menu is up, pressing this key
select the highlighted option in the menu.
VOL ▲/▼—Press to turn the volume up or down.
CH ▲/▼—Press to change the channels up or down.
MUTE
—Press to turn the sound on and off.
LAST— Press to recall the previously viewed channel. When the Menu is
active, press this button repeatedly to go to the previous level or out of the
On Screen Menu completely.
Number Button Pad—Press to select a channel or enter a password.
INFO—Press to display program and channel information.
- (DASH) —Press to insert a dash between the main and sub-channels. For example, channel 28-2 would
be selected by the button sequence 2, 8, DASH, 2.
The following keys do not function on these models:
Pause (II)—Press to pause live TV. It does not apply to this model.
Play (►)—Press to start playing the recorded programming when in Pause Live TV mode. It does not
apply to this model.
Stop (
)—Press to take you out of Pause Live TV mode and back to live TV. It does not apply to this
model.
GUIDE— Press to display program information. It does not apply to this model.
14
www.VIZIO.com
VIZIO VA SERIES User Manual
Chapter 4 Getting Started
Your HDTV has a built-in setup Wizard that runs when you turn on your TV for the first time. Follow the
on-screen directions to easily setup your new HDTV.
1. Insert the batteries into the remote control.
2. Plug the attached power cord into an AC wall
socket.
3. Connect your devices to your HDTV (see
Chapter 6 for detailed steps).
4. Turn on your TV. The Setup Wizard will
automatically play and guide your thru the
initial setup of your HDTV. Use the Arrow and
MENU/OK buttons to navigate through the
setup App. During the setup process you will:
• Choose your Menu language
• Select the TV to Home Mode for the best picture and most efficient energy usage.
• Select the signal input (Antenna or Cable)
• Scan your TV channels (unless you have a Cable/Satellite Set-Top Box)
Version 2/3/2010 15
www.VIZIO.com
VIZIO VA SERIES User Manual
Chapter 5 Using your HDTV for the first time
Select Input Source
Select the input source for your HDTV by pressing the INPUT button on
the remote control or the side of your TV. Pressing this button will cycle
you through the following options: DTV/TV, AV, COMPONENT, HDMI 1,
HDMI 2, RGB, and PHOTO.
Turn on your device and you will see a picture on your HDTV. If there is
no picture, make sure you have selected the correct input on your HDTV.
Note: If the selected device is RF connected, your HDTV needs to be in
TV mode and on either channel 3 or channel 4 matching the channel
which has been selected on the back of the VCR, Cable Box, External TV
Tuner or Satellite Receiver. Please refer to the User’s Manual of the
respective equipment for details.
Watching a TV Program
Before you start watching TV, please make sure that any cable, satellite or off-air antenna connections
are secure. Also, verify that the AC power cord is plugged into a correctly grounded electrical outlet or
surge protector.
1. Press the power button on the remote control.
2. Select the input to which your device is connected that provides TV programming (e.g. TV, HDMI,
COMP).
Note: You should be able to see a picture. If you do not, make sure that all of your HDTV connections
are secure and you have selected the correct video input source. Each press of the INPUT button on the
remote control will cycle through the available inputs. Press the button until the input associated with the
device you want to view is shown.
3. When using the TV input, press the channel buttons on the remote control or the CH ▲ or ▼
buttons to change the channel. The Channel buttons and on the remote, control will not work if
you are watching a program using HDMI, Component, or AV ( Composite video) inputs.
16
www.VIZIO.com
Loading...
