Vizio SV320XVT User Manual
VIZIO SV320XVT & SV370XVT User Manual
Dear VIZIO Customer,
Congratulations on your new VIZIO SV320XVT & SV370XVT television purchase.
Thank you for your support. For maximum benefit of your set, please read these
instructions before making any adjustments, and retain them for future reference.
We hope you will experience many years of enjoyment from your new VIZIO HDTV
High Definition Television.
For assistance, please call (877) 668-8462 or e-mail us at www.vizio.com.
To purchase or inquire about accessories and installation services for your
VIZIO HDTV, please visit our website at
www.vizio.com or call toll free at
(888) 849-4623.
We recommend you register your VIZIO HDTV either at our website
www.VIZIO.com or fill out and mail your registration card. For peace of mind and
to protect your investment beyond the standard warranty, VIZIO offers on-site
extended warranty service plans. These plans give additional coverage during the
standard warranty period. Visit our website or call us to purchase a plan.
Write down the serial number located on the back of your HDTV.
__ __ __ __ __ __ __ __ __ __ __ __ __
Purchase Date _____________________
VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.
HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED ARE FOR
ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION MEETS VALUE AND OTHER VIZIO
TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT SPECIFICATIONS ARE SUBJECT TO
CHANGE WITHOUT NOTICE OR OBLIGATION. © 2008 VIZIO INC. ALL RIGHTS RESERVED.
and are trademarks of SRS Labs, Inc.
Version 12/1/2009 1
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Important Safety Instructions
Your HDTV is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent your HDTV from being damaged, the following
rules should be observed for the installation, use, and maintenance of your HDTV. Read the
following safety instructions before operating your HDTV. Keep these instructions in a safe place
for future reference.
! To reduce the risk of electric shock or component damage, switch off the power before
connecting other components to your HDTV.
! Unplug the power cord before cleaning your HDTV. A damp cloth is sufficient for cleaning your
HDTV. Do not use a liquid or a spray cleaner for cleaning your HDTV. Do not use abrasive
cleaners.
! Always use the accessories recommended by the manufacturer to insure compatibility.
! When moving your HDTV from an area of low temperature to an area of high temperature,
condensation may form in the housing. Wait before turning on your HDTV to avoid causing fire,
electric shock, or component damage.
! Use only with the cart, stand, tripod, bracket, or table specified by manufacturer or sold with your
HDTV. When a cart is used, use caution when moving the cart/HDTV combination to avoid injury
from tip-over. Do not place your HDTV on an unstable cart, stand, or table. If your HDTV falls, it
can injure a person and cause serious damage to your HDTV. Use only a cart or stand
recommended by the manufacturer or sold with your HDTV.
! A distance of at least 3 feet should be maintained between your HDTV and any heat source, such
as a radiator, heater, oven, amplifier etc. Do not install your HDTV close to smoke. Operating
your HDTV close to smoke or moisture may cause fire or electric shock.
! Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure
reliable operation of your HDTV and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your HDTV in a bookcase or cabinet unless proper
ventilation is provided.
! Never push any object into the slots and openings on your HDTV cabinet. Do not place any
objects on the top of your HDTV. Doing so could short circuit parts causing a fire or electric shock.
Never spill liquids on your HDTV.
! Your HDTV should be operated only from the type of power source indicated on the label. If you
are not sure of the type of power supplied to your home, consult your dealer or local power
company.
! Do not apply pressure or throw objects at your HDTV. This may compromise the integrity of the
display. The manufacturer’s warranty does not cover user abuse or improper installations.
! The power cord must be replaced when using different voltage than the voltage specified. For
more information, contact your dealer.
! Your HDTV is equipped with a three-pronged grounded plug (a plug with a third grounding
pin). This plug will fit only into a grounded power outlet. This is a safety feature. If
your outlet does not accommodate the three-pronged, have an electrician install
the correct outlet, or use an adapter to ground your HDTV safely. Do not defeat
the safety purpose of the grounded plug.
! When connected to a power outlet, power is always flowing into your HDTV. To
totally disconnect power, unplug the power cord.
! The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-isolated, dangerous
voltage within the inside of your HDTV that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
! The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and servicing instructions in the literature
accompanying your HDTV.
! Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
2
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
! The wall socket should be installed near your HDTV and easily accessible.
! Only power of the marked voltage can be used for your HDTV. Any other voltage than the
specified voltage may cause fire or electric shock
! Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power
cord during electrical storms.
! Unplug your HDTV during a lightning storm or when it will not be used for long period of time.
This will protect your HDTV from damage due to power surges.
! Do not attempt to repair or service your HDTV yourself. Opening or removing the back cover may
expose you to high voltages, electric shock, and other hazards. If repair is required, contact your
dealer and refer all servicing to qualified service personnel.
! Keep your HDTV away from moisture. Do not expose your HDTV to rain or moisture. If water
penetrates into your HDTV, unplug the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.
! Do not use your HDTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug
the power cord and contact your dealer immediately. Do not try to repair your HDTV yourself.
! Avoid using dropped or damaged appliances. If your HDTV is dropped and the housing is
damaged, the internal components may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your HDTV may cause fire or electric shock.
! Do not install your HDTV in an area with heavy dust or high humidity. Operating your HDTV in
environments with heavy dust or high humidity may cause fire or electric shock.
! Follow instructions for moving your HDTV. Ensure that the power cord and any other cables are
unplugged before moving your HDTV.
! When unplugging your HDTV, hold the power plug, not the cord. Pulling on the power cord may
damage the wires inside the cord and cause fire or electric shock. When your HDTV will not be
used for an extended period of time, unplug the power cord.
! To reduce risk of electric shock, do not touch the connector with wet hands.
! Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to
leak which can damage the remote control or injure the operator.
! If any of the following occurs, contact the dealer:
o The power cord fails or frays.
o Liquid sprays or any object drops into your HDTV.
o Your HDTV is exposed to rain or other moisture.
o Your HDTV is dropped or damaged in any way.
o The performance of your HDTV changes substantially.
Version 12/1/2009 3
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during
a lightning storm or when it is left
unattended or unused for long periods
of time, unplug the TV from the wall
outlet and disconnect the antenna or
cable system.
Power Lines
Do not locate the antenna near
overhead light or power circuits, or
where it could fall into such power
lines or circuits.
Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.
4
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Advisory of the DTV Transition
The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your local
television stations may switch sooner. After the switch, analog-only television sets that receive TV
programming through an antenna will need a converter box to continue to receive over-the-air TV. Watch
your local stations to find out when they will turn off their analog signal and switch to digital-only
broadcasting. Analog-only TVs should continue to work as before to receive low power, Class A or
translator television stations and with cable and satellite TV services, gaming consoles, VCRs, DVD
players, and similar products.
For additional information, please contact the parties listed below, as appropriate:
FCC (US Federal Communications Commission)
http://www.fcc.gov/
Phone: 1-888-CALL-FCC (1-888-225-5322)
TTY: 1-888-TELL-FCC (1-888-835-5322)
Fax: 1-866-418-0232
E-mail: fccinfo@fcc.gov
NTIA (National Telecommunications and Information Administration)
http://www.ntia.doc.gov/
1-888-DTV-2009
Listings of US Television Stations
http://www.high-techproductions.com/usTVstations.htm
Note: Your VIZIO HDTV is capable of receiving Digital Broadcasts, and no Digital Converter Box is
required.
Version 12/1/2009 5
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Table of Contents
Important Safety Instructions.....................................................................................................................2
Television Antenna Connection Protection ...............................................................................................4
Advisory of the DTV Transition..................................................................................................................5
TV Setup and Stand Assembly ...............................................................................................................10
Setting Up Your HDTV ............................................................................................................................11
Wall Mounting your HDTV.......................................................................................................................11
CHAPTER 1 BASIC CONTROLS AND CONNECTIONS............................................. 12
Front Panel ..............................................................................................................................................12
Side Panel Controls.................................................................................................................................12
Rear Panel Connections..........................................................................................................................13
VIZIO Remote Control.............................................................................................................................14
Quick Menu Operation.........................................................................................................................15
Insertion of Batteries in the Remote Control........................................................................................16
Remote Control Range ........................................................................................................................16
VIZIO Remote Control Precautions ..................................................................................................... 16
CHAPTER 2 CONNECTING EQUIPMENT................................................................... 17
Which Video Connection Should I Use? .................................................................................................17
Connecting Your Cable or Satellite Box.................................................................................................. 18
Using HDMI (Best) ...............................................................................................................................18
HDMI Connections for Cable or Satellite Boxes with DVI ...................................................................19
Using Component Video (Better)......................................................................................................... 19
Using S-Video (Compatible) ................................................................................................................ 20
Using Composite Video (Compatible).................................................................................................. 20
Using Coaxial (Antenna) (Compatible) ................................................................................................ 20
Connecting Coaxial (RF) ......................................................................................................................... 21
Using Your Antenna or Digital Cable for Standard TV or Digital TV ................................................... 21
Using the Antenna or Cable through Your VCR..................................................................................21
Connecting Your DVD Player.................................................................................................................. 22
Using HDMI (Best) ...............................................................................................................................22
HDMI Connections for DVD Players with DVI .....................................................................................22
Using Component Video (Better)......................................................................................................... 23
Using S-Video (Compatible) ................................................................................................................ 23
Using Composite (AV) Video (Compatible) ......................................................................................... 24
Connecting Your VCR or Video Camera................................................................................................. 24
Connecting an External Receiver/Amp ................................................................................................... 25
Optical Output of audio received with HD Programs............................................................................... 25
Connecting a Computer........................................................................................................................... 26
Preset PC Resolutions.........................................................................................................................27
Resolution through RGB Input............................................................................................................. 27
CHAPTER 3 USING THE MEDIA PORT ...................................................................... 28
Supported File Formats........................................................................................................................... 28
Viewing Multimedia Content.................................................................................................................... 29
Picture Settings ....................................................................................................................................... 30
Slideshow Mode................................................................................................................................... 30
Slideshow with Music...........................................................................................................................30
Music file browser ................................................................................................................................ 30
Audio Mode..........................................................................................................................................30
Repeat..................................................................................................................................................30
Sort By .................................................................................................................................................30
Duration ............................................................................................................................................... 30
Slideshow Effect .................................................................................................................................. 31
6
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Thumbnail Size .................................................................................................................................... 31
Info .......................................................................................................................................................31
Music Settings ......................................................................................................................................... 31
Sort By .................................................................................................................................................31
Play Mode ............................................................................................................................................31
Repeat..................................................................................................................................................31
Audio Mode..........................................................................................................................................31
Info .......................................................................................................................................................31
Video Settings ......................................................................................................................................... 32
Sort By .................................................................................................................................................32
Play Mode ............................................................................................................................................32
Repeat..................................................................................................................................................32
Picture Mode........................................................................................................................................32
Wide Format ........................................................................................................................................ 32
Audio Mode..........................................................................................................................................32
Info .......................................................................................................................................................32
CHAPTER 4 USING YOUR HDTV THE FIRST TIME................................................... 33
Setup Wizard ...........................................................................................................................................33
Select Input Source ................................................................................................................................. 35
Fine Tuning the picture............................................................................................................................36
Watching a TV Program .......................................................................................................................... 37
Adjusting Basic HDTV Settings............................................................................................................... 38
Program Information................................................................................................................................38
CHAPTER 5 ADVANCED ADJUSTMENT OF HDTV................................................... 39
Using the On Screen Display (OSD)....................................................................................................... 39
Picture Menu ........................................................................................................................................... 40
Picture Mode........................................................................................................................................40
Backlight ..............................................................................................................................................40
Brightness ............................................................................................................................................40
Contrast ............................................................................................................................................... 40
Color..................................................................................................................................................... 40
Tint .......................................................................................................................................................40
Sharpness............................................................................................................................................40
Advanced Video...................................................................................................................................41
Reset Picture Mode ............................................................................................................................. 41
Audio Menu ............................................................................................................................................. 42
Audio Mode..........................................................................................................................................42
Equalizer ..............................................................................................................................................42
Balance ................................................................................................................................................42
SRS TSHD...........................................................................................................................................42
SRS TruVolume ...................................................................................................................................42
Digital Audio Out ..................................................................................................................................42
Speakers..............................................................................................................................................42
Analog Audio Out.................................................................................................................................43
Lip Sync ...............................................................................................................................................43
Reset Audio Mode ............................................................................................................................... 43
TV Menu ..................................................................................................................................................44
Tuner Mode.......................................................................................................................................... 44
Auto Search ......................................................................................................................................... 44
Partial Channel Search........................................................................................................................ 44
Skip Channel........................................................................................................................................ 44
MTS......................................................................................................................................................44
Time Zone............................................................................................................................................44
Daylight Saving ....................................................................................................................................44
Version 12/1/2009 7
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Channel Info......................................................................................................................................... 44
Setup Menu ............................................................................................................................................. 45
Language .............................................................................................................................................45
PIP .......................................................................................................................................................45
CEC Menu ........................................................................................................................................... 46
Sleep Timer.......................................................................................................................................... 46
Wide..................................................................................................................................................... 46
Input Naming........................................................................................................................................ 47
CC (Closed Caption)............................................................................................................................47
H/V Position .........................................................................................................................................48
Parental................................................................................................................................................ 48
System Info ..........................................................................................................................................50
System Reset....................................................................................................................................... 50
Understanding Viewing Features ............................................................................................................51
Viewing Modes ........................................................................................................................................ 51
CHAPTER 6 PROGRAMMING THE VIZIO UNIVERSAL REMOTE CONTROL .......... 52
Programming for VCR.......................................................................................................................... 52
Programming for Cable Set-Top Box................................................................................................... 52
Programming for DVD Player .............................................................................................................. 53
Searching for Component Codes ........................................................................................................ 53
Using a Cable or Satellite Remote .......................................................................................................... 53
CHAPTER 7 MAINTENANCE AND TROUBLESHOOTING ........................................ 54
Maintenance ............................................................................................................................................54
Troubleshooting Guide ............................................................................................................................ 55
Telephone & Technical Support.............................................................................................................. 57
Compliance.............................................................................................................................................. 58
FCC Class B Radio Interference Statement ........................................................................................... 58
CHAPTER 8 SPECIFICATIONS................................................................................... 59
Remote Control Codes ........................................................................................................................ 61
LIMITED PRODUCT WARRANTY ............................................................................... 81
VIZIO RETURN POLICY............................................................................................... 82
Index........................................................................................................................................................84
8
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Opening the Package
Your HDTV and its accompanying accessories are carefully packed in a cardboard carton that has been
designed to protect it from transportation damage. Once you have opened the carton, check that your
HDTV is in good condition and that all of the contents are included.
The screen can easily be scratched or broken, so handle your HDTV gently and never place your HDTV
with the screen facing downwards on a surface without protective padding.
IMPORTANT: Save the carton and packing material for future shipping.
Package Contents
! VIZIO SV320XVT or SV370XVT
! Stand with thumb screw (attached)
! VIZIO remote control VUR9M
! AAA batteries for remote control (2)
! Power cord
! Cleaning Cloth
! This user manual
! Quick Setup Guide
! Registration Card
Additional certified accessories for your HDTV are sold
separately:
! Wall mounts
! High Definition cables
! Extra or replacement remote control
VIZIO also offers installation services and extended warranty services for your HDTV.
To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our web site
at www.VIZIO.com or call us toll free at 888-VIZIOCE (888-849-4623)
Caution:
integrity of the display. The manufacturer’s warranty does not cover user abuse or improper
installations.
Do not apply pressure or throw objects at your HDTV. This may compromise the
Version 12/1/2009 9
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
TV Setup and Stand Assembly
To unpack the TV and stand base:
1. Remove the remote control, batteries, and power cord from the foam end caps.
2. Remove the top foam end caps.
3. Remove the stand base and the thumb screw.
4. Remove the TV from the box and lay it face down on a clean, flat surface.
Note: Make sure that the surface is free of debris to prevent the TV screen from getting scratched.
To attach the TV stand base:
1. Push the stand base onto the stand neck (already connected to TV).
2. On the bottom of the base, insert the thumb screw and tighten. Move the TV into an upright
position.
10
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Setting Up Your HDTV
! Read this user manual carefully before installing your HDTV.
! The power consumption of your HDTV is about 98W (AVG) for the SV320XVT; 125W (AVG) for
the SV370XVT. Use the included power cord. When an extension cord is required, use one with
the correct power rating. The cord must be grounded and the grounding feature must not be
compromised.
! Your HDTV should be installed on a flat surface to avoid tipping.
! For proper ventilation, you must allow space between the back of your HDTV and the wall.
! If you want to mount your HDTV on the wall, see below for additional information.
! Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the
service life of the electronic components.
! Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent
poor ventilation and excessive component damage.
VIZIO offers professional installation services. Contact VIZIO for more information on these services at
888-VIZIOCE (888-849-4623) or www.VIZIO.com.
Wall Mounting your HDTV
Your HDTV can be mounted on the wall for viewing. If
you choose to mount your HDTV on the wall, follow
the instructions below.
1. Remove the stand base and neck:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft, flat
surface to prevent damage to the screen.
c. Remove the six screws and pull off base.
Note: To remove the base from the neck, unscrew
thumbscrew on bottom.
2. Mount your HDTV on the wall:
a. Attach your HDTV to a wall mount (sold
separately) using the mounting holes in
the back panel of your HDTV.
b. Read the instructions that came with your
specific wall mount to properly hang your
HDTV.
Note: Use M6 x 20mm 1.0 pitch screws in two upper
holes, M6 x 14mm in two lower holes.
Version 12/1/2009 11
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Chapter 1 Basic Controls and Connections
Front Panel
POWER ‘VIZIO’ LIGHT– The VIZIO name lights white
when powered on and orange when powered off.
REMOTE CONTROL SENSOR – Point the remote control
directly at this window for the best response to the remote
signal.
Side Panel Controls
Right side
POWER/Jog Wheel ( ) – Switch the HDTV on by pressing the button
once. Press the button again to turn the HDTV off.
Left side
Multimedia Port – Insert a FAT/FAT32 formatted USB drive to view
pictures, listen to music, or watch movies.
.
12
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Rear Panel Connections
1. HDMI 1 & 2 – Connect digital video devices such as DVD multimedia players or set top box
through these all digital connectors.
2. RGB PC – Connect the video and audio from a computer here. A cable with a 1/8” mini plug
stereo connector at the end connecting to the TV is needed if sound is also transmitted with this
signal.
3. S-VIDEO/AV – Connect composite or S-Video video devices, such as a VCR or video game.
Use the white and red connectors to connect the external audio from the same source.
4. DTV/TV – Connect to an antenna or digital cable (no Cable Box) for Digital TV. For digital TV
stations in your area visit www.antennaweb.org.
5. AUDIO OUT –
a. (OPTICAL) When digital TV is selected for viewing, the audio associated with the
programming will be available on the SPDIF Optical connector for connection to your
home theater system.
b. (ANALOG L/R) Connect the audio from the HDTV to an external device, such as a home
theater system, external amplifier or stereo. Speakers can not be connected directly here.
6. HDMI 3 - Connect another digital video device such as a DVD multimedia player or set top box
through this all digital connector. For users who want to connect to a DVI enabled device, use a
DVI-HDMI cable and connect the analog audio output of the device to the L+R AUDIO here.
Your VIZIO Certified HDMI and HDMI-DVI cables are available for purchase from
www.VIZIO.com or by calling 888-VIZIOCE (888-849-4623).
7. COMPONENT (YPb/CbPr/Cr with Audio L/R) – Connect component video devices such as a
DVD Player or set top box here.
Version 12/1/2009 13
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
VIZIO Remote Control
POWER (
) – Press this button to turn the TV on from the Standby
mode. Press it again to return to the Standby mode.
SET – This button starts all programming of the Remote Control.
HDMI – Press this button to select the HDMI input. By pressing it
repeatedly you will go through all HDMI inputs in sequence.
COMP – Press this button to select Component input.
AV – Press this button to select AV (either Composite or S-Video) input.
TV – Press this button to select TV.
PIP – Pressing this button will activate the picture-in-picture feature. The
screen will display the sub-screen in the corner over the main screen.
Pressing it again will display the POP (Picture Outside Picture) option.
P.SIZE – Repeatedly press this button to set the size of the PIP screen to
small, medium, or large.
P.INPUT – Press the button to choose the input source for the PIP screen.
P.CH – Press this button to change the channels in the PIP screen when
TV is selected as PIP input.
WIDE – This button cycles through the available screen formats. The
options are Zoom1, Zoom2, Stretch, Panoramic, Full, and Normal
(depending on input selected).
FREEZE – Press this button to “Freeze-Frame” the current screen. Press
this button again to continue playing.
MTS – This button will select the MTS options of Stereo, SAP or Mono in
standard TV mode and alternate audio channels, where available, in DTV
mode.
SWAP – While in PIP/POP mode; pressing SWAP will switch the displays
from the main screen to the sub-screen or vice versa.
MODE – Use this button to change the picture mode from Custom,
Standard, Movie, Game, Vivid, Football, Golf, Basketball, and Baseball.
INFO – This button displays the image and system information display.
P.AUDIO – Press this button to switch the audio from the main screen to
the sub-screen while in PIP or POP mode.
CC – This button will select the Closed Caption mode.
DVD – This button selects a programmed DVD player.
AUDIO – This button selects a programmed Audio Receiver/Amp/Home
Theater System.
CABLE – This button selects a programmed cable TV set-top box or a
satellite TV set-top box.
TV – This button has been pre-programmed to select the codes to operate
the VIZIO HDTV.
MENU – Use this button for the On-Screen Display (OSD) menu. When it
is used within a menu selection, pressing this button will return to the
previous selection or exit the menu.
EXIT
– Press this button to exit from the On-Screen Display (OSD) menu
OK
– Use this button for the On-Screen Display (OSD) menu. Press it to
confirm or choose a highlighted menu selection. In Multi Media mode,
14
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
press this button to select folders and files and to play/pause a slideshow, playing music, or movies.
!"# $
-These buttons are used to navigate the OSD menu. They will also be used as value settings
when the slide bar is shown on the screen and option settings to turn a feature off or on.
GUIDE – This button displays program information. Note: This function is only available on DTV.
LAST – This button recalls the previously viewed channel. If the On-Screen Display (OSD) menu is being
used, this button will allow you to get back to previous menu screen or out to your program when you
press it repeatedly.
MEDIA – Press this button to view pictures, listen to music, or watch movies on a USB drive connected to
the Multi Media port on the side of the HDTV.
VOL +/- – This button turns the volume up or down.
CH !/" – This button changes the channels up or down.
MUTE – This button turns the sound on and off.
NUMBER BUTTON PAD – Use these buttons to select a channel or enter a password.
INPUT – This button allows the user to cycle through the inputs. Repeatedly pressing this button will step
you through the input sources in the following sequence: TV, AV, Component, RGB, HDMI1, HDMI2, and
HDMI3. Once you have stepped through the entire
sequence, you will return to the beginning.
- (DASH) – When selecting a digital channel directly,
use this button between the main and sub-channels.
For example, channel 28-2 would be selected by the
button sequence 2, 8, DASH, 2.
Quick Menu Operation
Standby/Power on
By pressing the Power button, VIZIO logo turns to
white to indicate power on. To turn off the HDTV,
press this button again.
Note: When the Quick Menu is not displayed,
pressing this button turns the HDTV On or Off.
Menu operation
Rotate the Jog Wheel Left or Right to activate the
QUICK MENU, then rotate Left or Right to select
one of the functions:
Volume adjustment
Rotate the Jog Wheel Left or Right to
select Volume and press in on the
button. Rotate the Jog Wheel Left or
Right to increase or decrease volume.
Channel selection
Rotate the Jog Wheel Left or Right to select Channel and press in on the button. A Channel
list will appear. Select a channel by rotating the Jog Wheel Left or Right, then press in on the
button to confirm the channel selection.
Version 12/1/2009 15
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Input Source
Rotate the Jog Wheel Left or Right to select Input and press in on the button. Rotate the Jog
Wheel Left or Right to cycle through the input sources by the following sequence: TV, AV(Svideo or Composite), COMPONENT, RGB ,HDMI1 , HDMI2, HDMI3. Press in on the button
to confirm the channel selection.
Exit
Rotate the Jog Wheel Left or Right to select Exit. Press in on the button to exit the Quick
Menu.
Power Off
Rotate the Jog Wheel Left or Right to select Power Off and Press in to turn off the HDTV.
Note: When the Quick Menu is displayed and no selection is made within three seconds, the menu will
exit automatically.
Insertion of Batteries in the Remote Control
Insert two AAA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the
batteries with the (+) and (-) symbols inside the battery compartment. Re-attach the battery cover.
Precautionary Tips for Inserting the Batteries:
! Only use the specified AAA batteries.
! Do not mix new and old batteries. This may result in cracking or
leakage that may pose a fire risk or lead to personal injury.
! Inserting the batteries incorrectly may also result in cracking or
leakage that may pose a fire risk or lead to personal injury.
! Dispose of the batteries in accordance with local laws and
regulations.
! Keep the batteries away from children and pets.
Remote Control Range
Point the remote control at the remote control sensor to transmit the commands.
Do not place any obstacles between the remote control and the receiver window.
The effective range of the remote control is approximately 30 feet (10 meters) from the front of the
receiver window, 30° to the left and right, 20° up and down.
VIZIO Remote Control Precautions
The remote control should be kept dry and away from heat sources. Avoid humidity.
If the TV responds erratically to the remote control or does not respond at all, check the batteries. If the
batteries are low or exhausted, replace them with fresh batteries.
When not using the remote control for a long period of time, remove the batteries.
Do not take the batteries apart, heat them, or throw them into a fire.
Do not subject the remote control to undue physical stress, such as striking or dropping it.
Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp cloth.
16
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Chapter 2 Connecting Equipment
Which Video Connection Should I Use?
The VIZIO HDTV has six different ways to connect your video equipment from a basic connection to the
most advanced for digital displays.
Connection
Quality (type)
Best
(digital)
Best
(digital)
- - - - - - - - - - -
Compatible
(analog)
Best
(analog)
Better
(analog)
Connector Description
HDMI provides an interface between any audio/video source, such as
a set-top box, DVD player, or A/V receiver and a digital television
(DTV), over a single cable.
Connect a digital or analog antenna cable or coaxial cable to watch TV
programming.
RGB PC (VGA) – This is most commonly used for PC input.
Component - Component video provides a sharper image than
composite video and S-video because the three video signals are
transmitted via three separate channels.
S-Video (AV) - Combining the three video signals into two channels,
S-Video provides a sharper image than Composite video, but is not as
Compatible
(analog)
Version 12/1/2009 17
good as Component video.
Composite (AV) - All three video signals are combined into one
channel, thus making the image less sharp than Component or
S-Video.
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Connecting Your Cable or Satellite Box
You have four options for connecting your cable or satellite box to your HDTV: HDMI, Component,
Composite, or Coax (RF). Based on your home theater configuration, you can decide which option is the
right one for you. Refer to your set-top box user manual for more information about the video output
requirements or consult your cable or satellite operator.
SET TOP BOX
Using HDMI (Best)
Cable and Satellite Boxes that have a HDMI digital interface should be connected to the HDMI input of
the HDTV for optimal results.
Note: To maintain the display quality, use a VIZIO certified HDMI cable. Length is available up to 10
meters. See www.vizio.com or call 1-888-VIZIOCE (1-888-849-4623) for details.
1. Turn off the power to the HDTV and HDTV Set-Top Box.
2. Connect an HDMI cable to the HDMI output of your HDTV Set-Top Box and the other end to the
HDMI 1 input at the rear of the HDTV.
3. Turn on the power to the HDTV and HDTV Set-Top Box.
4. Select HDMI 1 using the INPUT button on the remote control, or directly by pressing the HDMI
button on the remote control.
Note:
! The HDMI input on the HDTV supports High-bandwidth Digital Content Protection (HDCP).
HDCP encrypts the transmission between the video source and the digital display for added
security and protection.
! If you are already using the HDMI1 input for another device, or you do not want to use the HDMI1
input for the Set-Top Box, you can connect the Set-Top Box to another HDMI connection.
! Refer to your HDTV Set-Top Box user manual for more information about the video output
requirements of the product or consult your cable or satellite operator.
18
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
HDMI Connections for Cable or Satellite Boxes with DVI
SET TOP BOX
1. Turn off the power to the HDTV and HDTV Set-Top Box.
2. Using a HDMI-DVI cable, connect the DVI end to your HDTV Set-Top Box and the HDMI end
to the HDMI 3 input at the rear of the HDTV.
3. Using an audio cable, connect the cable to the audio output connectors associated with the
DVI output on your HDTV Set-Top Box and connect the other end to the audio connectors
associated with the HDMI input at the rear of the HDTV.
4. Turn on the power to the HDTV and HDTV Set-Top Box.
5. Select HDMI 3 using the INPUT button on the remote control, or directly by pressing the
HDMI button on the remote control.
Note:
! The HDMI input on the HDTV supports High-bandwidth Digital Content Protection (HDCP).
HDCP encrypts the transmission between the video source and the digital display for added
security and protection.
! Refer to your HDTV Set-Top Box user manual for more information about the video output
requirements of the product or consult your cable or satellite operator.
Using Component Video (Better)
SET TOP BOX
1. Turn off your HDTV and set-top box.
2. Connect the component cables (green, blue, and red) from your set-top box to the
COMPONENT jacks on the back of your HDTV.
3. Connect the audio cables (white and red) from your set-top box to the adjacent
COMPONENT L and R Audio jacks on the back of your HDTV.
4. Turn on your HDTV and set-top box.
5. Press COMP on the remote control to view the content.
Version 12/1/2009 19
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Using S-Video (Compatible)
SET TOP BOX
1. Turn off your HDTV and set-top box.
2. Connect the S-VIDEO cable from your set-top box to the S-VIDEO jack on the back of your HDTV.
3. Connect the audio cables (white and red) on your set-top box to the corresponding L and R
AUDIO jacks on the back of your HDTV.
4. Turn on your HDTV and set-top box.
5. Press AV on the remote control to view the content.
Using Composite Video (Compatible)
SET TOP BOX
1. Turn off your HDTV and set-top box.
2. Connect the video cable (yellow) from your set-top box to the AV jack (yellow) on the back of your
HDTV.
3. Connect the audio cables (white and red) on your set-top box to the corresponding L and R
AUDIO jacks on the back of your HDTV.
4. Turn on your HDTV and set-top box.
5. Press AV on the remote control to view the content.
Using Coaxial (Antenna) (Compatible)
SET TOP BOX
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or digital cable to the DTV/TV
CABLE/ANTENNA connector at the rear of the HDTV.
3. Turn on the power to the HDTV.
4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button
on the remote control.
20
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Connecting Coaxial (RF)
Using Your Antenna or Digital Cable for Standard TV or Digital TV
CABLE BOX
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or cable to the DTV/TV
CABLE/ANTENNA connector at the rear of the HDTV
3. Turn on the power to the HDTV.
4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button
on the remote control.
Using the Antenna or Cable through Your VCR
VCR
1. Turn off the power to the HDTV and VCR.
2. Connect the “Output to TV”, “RF Out” or “Antenna Out” connector on the rear of your VCR to
the DTV/TV CABLE/ANTENNA connector at the rear of the HDTV.
3. Turn on the power to the HDTV and VCR.
4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button
on the remote control.
Note: If you have an off-air antenna or cable TV, connect it to the “Antenna In” connector on the rear of
your VCR.
Version 12/1/2009 21
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Connecting Your DVD Player
You have several options for connecting your DVD player to your HDTV: HDMI, Component, S-Video and
Composite (AV) inputs. Based on your home theater configuration, you can decide which option is the
right one for you.
Using HDMI (Best)
CD DVD
For optimal results, DVD players that have a digital interface such as HDMI should be connected to the
HDMI input on your HDTV.
1. Turn off your HDTV and DVD player.
2. Connect a HDMI cable to the HDMI output of your DVD player and the other end to the HDMI
1 input at the rear of the HDTV.
3. Turn on the power to the HDTV and your DVD player.
4. Select HDMI 1 using the INPUT button on the remote control, or directly by pressing the
HDMI button on the remote control.
Note: If HDMI 1 is being used, connect to another HDMI port instead.
HDMI Connections for DVD Players with DVI
CD DVD
1. Turn off your HDTV and DVD player.
2. Using a HDMI-DVI cable, connect the DVI end to your DVD player and the HDMI end to the
HDMI 3 Input at the rear of the HDTV.
3. Connect the audio cables (white and red) from the DVI audio output jacks on the DVD player
to the adjacent HDMI 3 L and R AUDIO jacks on the back of your HDTV.
4. Turn on the power to the HDTV and your DVD player.
5. Select HDMI 3 using the INPUT button on the remote control, or directly by pressing the
HDMI button on the remote control.
Note: To maintain the display quality, use a VIZIO certified HDMI cable. Length is available up to 10
meters. See www.VIZIO.com or call 1-888-VIZIOCE (1-888-849-4623) for details.
22
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Using Component Video (Better)
CD DVD
1. Turn off the power to the HDTV and DVD player.
2. Connect the component cable (green, blue, and red) from your DVD player to the
COMPONENT jacks on the back.
3. Connect the audio cables (white and red) from your DVD player to the COMPONENT L and
R AUDIO jacks on the back.
4. Turn on the power to the HDTV and DVD player.
5. Select Component using the INPUT button on the remote control, or directly by pressing the
COMP button on the remote control.
Using S-Video (Compatible)
CD DVD
1. Turn off the power to the HDTV and DVD player.
2. Connect the S-VIDEO cable from your DVD player to the S-VIDEO jack on the back of your
HDTV.
3. Using an audio cable, connect the cable to the audio output connectors associated with the
S-Video output on your DVD player and connect the other end to the audio connectors
associated with the AV input at the rear of the HDTV.
4. Turn on the power to the HDTV and DVD player.
5. Select AV using the INPUT button on the remote control, or directly by pressing the AV
button on the remote control.
Version 12/1/2009 23
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Using Composite (AV) Video (Compatible)
CD DVD
1. Turn off the power to the HDTV and DVD player.
2. Connect the Video cable (yellow) from your DVD player to the S-VIDEO/AV jack on the back
of your HDTV.
3. Connect the audio cables (white and red) on your DVD player to the S-VIDEO/AV L and R
AUDIO jacks on the back of your HDTV.
4. Turn on the power to the HDTV and DVD Player.
5. Select AV using the INPUT button on the remote control, or directly by pressing the AV
button on the remote control.
Connecting Your VCR or Video Camera
VCR
1. Turn off the power to the HDTV and VCR or Video Camera.
2. Connect the S-VIDEO cable from your VCR or video camera to the S-VIDEO jack on the
back of your HDTV.
3. Connect the audio cables on your set-top box to the corresponding L and R AUDIO jacks on
the back of your HDTV.
4. Turn on the power to the HDTV and VCR or Video Camera.
5. Select AV using the INPUT button on the remote control, or directly by pressing the AV
button on the remote control.
Note: Refer to your VCR or Video Camera user manual for more information about the video output
requirements of the product.
24
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Connecting an External Receiver/Amp
STEREO SYSTEM
1. Turn off the power to the HDTV and Receiver/Amp.
2. Using an audio cable (white and red connectors), connect the
cable to the audio input connectors on the Receiver/Amp and
connect the other end to the AUDIO OUT audio connectors at the
rear of the HDTV.
3. Turn on the power to the HDTV and Receiver/Amp.
4. Then press the MENU button on the remote control to open the
On-Screen Display (OSD) menu.
5. Press
6. Press
7. Press # on the remote control to select OFF so the sound from
Note:
! Refer to your Receiver/Amp user manual to select the corresponding audio input.
! The audio output is not amplified and cannot be connected directly to external speakers.
" on the remote control to highlight the Audio menu, then
press OK to select.
" on the remote control to select SPEAKERS.
the HDTV will be routed through your Receiver/Amp system.
Optical Output of audio received with HD Programs
If your sound system has a SPDIF (optical) digital audio input you can
connect it to the OPTICAL digital audio out at the rear of the HDTV. This
is active when receiving audio with the programs being viewed no matter
what input is being used.
Version 12/1/2009 25
www.VIZIO.com
VIZIO SV320XVT & SV370XVT User Manual
Connecting a Computer
COMPUTER
1. Turn off the power to the HDTV and Computer.
2. Connect the VGA cable from your computer to the RGB PC jack on the back of your HDTV.
3. Connect the 1/8-inch audio cable from your computer to the RGB PC Audio jack on the back
of your HDTV. This step is optional and only needed if you want to transmit audio from the
Computer through the TV.
4. Turn on the power to the HDTV and Computer.
5. Select RGB using the INPUT button on the remote control.
Note:
! For a better picture quality when connecting a PC computer through RGB PC, set your PC
computer timing mode to VESA 1920 x 1080 at 60Hz.
! Refer to your PC computer user manual for more information about the video output requirements
of the product.
! A RGB (VGA) cable and stereo mini jack cable are not included and can be purchased at an
electronics store.
26
www.VIZIO.com
Loading...
