Vizio PX65-G1, P-Series Quantum X, PX75-G1 User Manual

P-Series® Quantum X

User Manual

Models:

PX65-G1 & PX75-G1

Table Of Contents

Getting to Know Your TV ...........................7

Front Panel ................................................7

Rear Panel ................................................8

Wall-mounting the TV .......................................10

Using the Remote ..........................................11

Completing the First-Time Setup ....................12

Using the On-Screen Menu .........................13

Navigating the On-Screen Menu ..............................13

Changing the Input Source ...................................13

Changing the Screen Aspect Ratio .............................14

Adjusting the Picture Settings ................................15

Adjusting More Picture Settings ...........................15

Adjusting the Color Temperature .........................16

Adjusting the Picture Mode Edit Settings ...................16

Saving a Custom Picture Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Locking/Unlocking a Custom Picture Mode .................17

Deleting a Custom Picture Mode ..........................17

Adjusting the Color Tuner Settings ........................18

Adjusting the Audio Settings .................................20

Adjusting the Network Settings ...............................21

Setting Timers .............................................22

Setting the Auto Power O Feature ........................22

Using the Blank Screen Feature ...........................22

Setting Up Channels ........................................23

Scanning for Channels ..................................23

Skipping Channels ......................................23

Listening to Alternate Audio ..................................24

Changing the Analog Audio Language ......................24

Using Parental Controls .....................................25

Accessing the Parental Controls Menu .....................25

Enabling or Disabling Program Ratings .....................25

Locking and Unlocking Channels ..........................25

Blocking and Unblocking Content by Rating .................25

Setting Up Closed Captioning .................................26

Changing the Appearance of Digital Closed Captions .........26

Changing Input Settings .....................................28

Renaming Devices on the Input Menu .....................28

Input Name ...........................................28

Custom Name .........................................28

Changing the TV Settings ....................................29

Checking for System Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Viewing System Information ..............................29

Changing the On-Screen Menu Language ...................29

Setting the Time and Local Settings ........................30

Adjusting the CEC Settings ...............................30

Adjusting the Power Mode ...............................30

Changing the TV Name ..................................31

To edit your TV name: ...................................31

Manging Mobile Devices .................................31

Accessibility Settings ....................................31

Using the Reset & Admin Menu ...............................32

Restoring the TV to Factory Default Settings ................32

Performing a Soft Power Cycle ............................32

Turning the Power Indicator On or O .....................32

Setting a System PIN ....................................33

Using the USB Power Feature ............................33

About Viewing Data .....................................33

Using the Info Window ......................................34

SmartCast HomeSM .................................35

What is SmartCast Home? ...............................35

How to Launch SmartCast Home ..........................35

What you can do with SmartCast Home ....................35

Control your TV with the SmartCast Mobile™ App ............35

WatchFree™ .......................................36

What is WatchFree? .....................................36

What you can do with WatchFree .........................36

How to Launch WatchFree ...............................36

Playing USB Media .................................37

Preparing Your USB Drive to Play USB Media ................37

Displaying USB Media ...................................37

Removing the USB Drive from the TV ......................37

Product Registration and Technical Support ..........41

Help Topics .......................................42

Specications .....................................44

Regulatory Information ............................45

Limited Warranty .................................46

Legal Information .................................48

ii



Safety & Certication

THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO TV!

To get the most out of your new VIZIO product, read these instructions before using
your product and retain them for future reference. Be sure to inspect the package
contents to ensure there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services for your VIZIO
product, visit our website at www.VIZIO.com or call toll free at [phone].

We recommend that you register your VIZIO product at www.VIZIO.com.

WHEN READING THIS MANUAL

TIP: When you see this symbol, please read the accompanying

helpful tip.

WARNING: When you see this symbol, please read the accompanying
important warning or notice. It is intended to alert you to the presence
of important operating instructions.

Color Text — This is the TV menu feature you should be selecting.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within dened design limits. Misuse
may result in electric shock or re. To prevent your TV from being damaged, the

following instructions should be observed for the installation, use, and maintenance
of your TV. Read the following safety instructions before operating your TV. Keep
these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component damage, switch o the power
before connecting other components to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including ampliers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third

prong are provided for your safety. If the provided plug does not t into your

outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

Grey Text — This is an action for you to complete, such as entering in a

password.

> — The arrow sign shows the ow of the steps you should take.

1. Lists additional steps you can take for each setting.

• Bullets give more detailed information about each feature.

• Only use attachments/accessories specied by the manufacturer.

• Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.

• Unplug the power cord before cleaning your TV.

• Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.

• Unplug this apparatus during lightning storms or when unused for long periods
of time.

• When moving your TV from an area of low temperature to an area of high
temperature, condensation may form in the housing. Wait before turning on

your TV to avoid causing re, electric shock, or component damage.

• A distance of at least three feet should be maintained between your TV and any

heat source, such as a radiator, heater, oven, amplier etc. Do not install your

TV close to smoke. Operating your TV close to smoke or moisture may cause

re or electric shock.

• Slots and openings in the back and bottom of the cabinet are provided for
ventilation. To ensure reliable operation of your TV and to protect it from
overheating, be sure these openings are not blocked or covered. Do not place
your TV in a bookcase or cabinet unless proper ventilation is provided.

• Never push any object into the slots and openings on your TV cabinet. Do
not place any objects on the top of your TV. Doing so could short circuit parts

causing a re or electric shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power source indicated on the
label. If you are not sure of the type of power supplied to your home, consult
your dealer or local power company.

• Do not apply pressure or throw objects at your TV. This may compromise the
integrity of the TV. The manufacturer’s warranty does not cover user abuse or
improper installations.

• The power cord must be replaced when using dierent voltage than the voltage

specied. For more information, contact your dealer.

• When connected to a power outlet, power is always owing into your TV. To
totally disconnect power, unplug the power cord.

• The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of
un-isolated, dangerous voltage within the inside of your TV that

may be of sucient magnitude to constitute a risk of electric

shock to persons.

iii

• Do not overload power strips and extension cords. Overloading can result in

re or electric shock.

• The wall socket should be installed near your TV and easily accessible.

• Only power of the marked voltage can be used for your TV. Any other voltage

than the specied voltage may cause re or electric shock.

• Do not touch the power cord during lightning. To avoid electric shock, avoid
handling the power cord during electrical storms.

• Unplug your TV during a lightning storm or when it will not be used for long
period of time. This will protect your TV from damage due to power surges.

• Do not attempt to repair or service your TV yourself. Opening or removing the
back cover may expose you to high voltages, electric shock, and other hazards.

If repair is required, contact your dealer and refer all servicing to qualied

service personnel.

• WARNING: Keep your TV away from moisture. Do not expose your TV to rain or
moisture. If water penetrates into your TV, unplug the power cord and contact

your dealer. Continuous use in this case may result in re or electric shock.

• Do not use your TV if any abnormality occurs. If any smoke or odor becomes
apparent, unplug the power cord and contact your dealer immediately. Do not
try to repair your TV yourself.

• Avoid using dropped or damaged appliances. If your TV is dropped and the
housing is damaged, the internal components may function abnormally. Unplug
the power cord immediately and contact your dealer for repair. Continued use

of your TV may cause re or electric shock.

• Do not install your TV in an area with heavy dust or high humidity. Operating

your TV in environments with heavy dust or high humidity may cause re or

electric shock.

• Follow instructions for moving your TV. Ensure that the power cord and any
other cables are unplugged before moving your TV.

• To prevent injury, this apparatus must be securely attached to the oor/wall in
accordance with the installation instructions.

• Insert batteries in accordance with instructions. Incorrect polarities may cause
the batteries to leak which can damage the remote control or injure the operator.

Do not expose batteries to excessive heat such as sunshine, re or the like.

• When unplugging your TV,grab the head of the power plug, not the cord. Pulling

on the power cord may damage the wires inside the cord and cause re or

electric shock. When your TV will not be used for an extended period of time,
unplug the power cord.

• To reduce risk of electric shock, do not touch the connector with wet hands.

• This apparatus shall not be exposed to dripping or splashing and no objects

lled with liquids, such as vases, shall be placed on the apparatus.

• The mains plug or appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.

• If any of the following occurs, contact the dealer:

− The power cord fails or frays.

− Liquid sprays or any object drops into your TV.

− Your TV is exposed to rain or other moisture.

− Your TV is dropped or damaged in any way.

− The performance of your TV changes substantially.

• CAUTION: These servicing instructions are for use by qualied service personnel

only. To reduce the risk of electric shock, do not perform any servicing other than

that contained in the operating instructions unless you are qualied to do so.

• The lightning ash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated DANGEROUS VOLTAGE

within the product’s enclosure that may be of sucient magnitude to constitute

a risk of electrical shock to persons.

• WARNING: Exposure to loud sounds can damage your hearing causing hearing

loss and tinnitus (ringing or buzzing in the ears). With continued exposure to

loud noises, ears may become accustomed to the sound level, which may result
in permanent damage to hearing without any noticeable discomfort.

• Install the TV where it cannot be pulled, pushed or knocked over.

• Do not allow children to hang onto the product.

• Store the accessories (remote, batteries, etc.) in a location safely out of the
reach of children.

• The American Academy of Pediatrics discourages television viewing for children
younger than two years of age.

• WARNING — Stability Hazard: A television set may fall, causing
serious personal injury or death. Many injuries, particularly to
children, can be avoided by taking simple precautions such as:

• ALWAYS use cabinets or stands or mounting methods
recommended by the manufacturer of the television set.

• ALWAYS use furniture that can safely support the television set.

• ALWAYS ensure the television set is not overhanging the edge of the supporting
furniture.

• ALWAYS educate children about the dangers of climbing on furniture to reach
the television set or its controls.

• ALWAYS route cords and cables connected to your television so they cannot be
tripped over, pulled or grabbed.

• NEVER place a television set in an unstable location.

• NEVER place the television set on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television set to a
suitable support.

• NEVER place the television set on cloth or other materials that may be located
between the television set and supporting furniture.

• NEVER place items that might tempt children to climb, such as toys and remote
controls, on the top of the television or furniture on which the television is
placed.

• If the existing television set is going to be retained and relocated, the same
considerations as above should be applied.

• Disposal of a battery into re or a hot oven, or mechanically crushing or cutting
of a battery, that can result in an explosion;

• Leaving a battery in an extremely high temperature surrounding environment

that can result in an explosion or the leakage of ammable liquid or gas;

• A battery subjected to extremely low air pressure that my result in an explosion

or the leakage of ammable liquid or gas.

• WARNING: To prevent injury, this apparatus must be securely attached to the

oor/wall in accordance with the installation instructions.

iv

TELEVISION ANTENNA CONNECTION PROTECTION

If an outside antenna/satellite dish or cable system is to be connected to the TV,
make sure that the antenna or cable system is electrically grounded to provide
some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with
regard to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of the grounding conductors, location
of antenna discharge unit, connection to grounding electrodes, and requirements
of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it is left unattended
or unused for long periods of time, unplug the TV from the wall outlet and disconnect
the antenna or cable system.

Ground Clamp

Antenna Lead In Wire

Power Lines

Do not locate the antenna near overhead light or power circuits, or where it could
fall into such power lines or circuits. Remember, the screen of the coaxial cable is
intended to be connected to earth in the building installation.

Electric Service Equipment

Antenna Discharge Unit
(NEC Section 810-20)

Grounding Conductors
(NEC Section 810-21)

Ground Clamps

Power Service Grounding Electrode System

(NEC ART 250, part H)

v

The terms HDMI, HDMI High-Denition Multimedia Interface, and the

HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS, Inc. DTS, the Symbol, DTS
and the Symbol together, and DTS Studio Sound II are registered
trademarks and/or trademarks of DTS, Inc. in the United States and/or
other countries. © DTS, Inc. All Rights Reserved.

Manufactured under license from Dolby Laboratories. Dolby, Dolby
Audio, and the double-D symbol are trademarks of Dolby Laboratories.
Copyright © 1992-2015 Dolby Laboratories. All rights reserved.

Manufactured under license from Dolby Laboratories. Dolby, Dolby
Vision, and the double-D symbol are trademarks of Dolby Laboratories.
Copyright © 2013-2015 Dolby Laboratories. All rights reserved.

vi

FRONT PANEL

1Getting to Know Your TV

Remote Sensor and Power Indicator

When using the remote, aim it directly at this sensor.

The power indicator ashes on when the TV turns on, then goes out after several seconds.

To keep the power indicator on, see

Turning the Power Indicator On or O on page 32.

7

REAR PANEL

1

Power

Press to turn on the TV.

Press and hold to turn the TV o.

Volume

Press to increase or decrease the TV volume level.

Input

Press to access the input menu.

HDMI

Connect an HDMI

device

Component/Composite
Connect a component or

composite

VOL

INPUT

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

Audio Out

Connect to an RCA device, such

as sound bar

Coaxial

Connect to a coaxial cable

from cable, satellite, or

antenna

USB

Connect a USB thumb drive to play

photo, music, or video

Optical Audio Out

Connect to an optical/SPDIF

audio device, such as home audio

receiver

Ethernet

Connect an Ethernet

cable to modem/ router

8

1

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Standard

RCA

RCA To 3

5mm

HDMI

RCA To 3

5mm

HDMI

Standard

RCA

RCA To 3

5mm

HDMI

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Optical

Standard

RCA

RCA To 3

5mm

HDMI

HDMI

HDMI
RCA To 3

5mm

HDMI

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Standard

RCA

RCA To 3

5mm

HDMI

RCA To 3

5mm

HDMI

Connecting a device — AUDIO & VIDEO CABLE TYPES

Your TV can be used to display output from most devices.

1. Verify that your device has a video port that matches an available port on the TV (HDMI, Composite, etc.).

2. Connect the appropriate cable (not included) to the TV and the device.

3. Turn the TV and your device on.

4. Set the TV’s input to match the connection you used (HDMI-1, HDMI-2, etc.).

HDMI CABLE

COMPONENT CABLE

HDMI

Y

Pb/Cb

Pr/Cr

L

R

COMPOSITE (AV) CABLE

(Shared with Component input)

Y

L

R

COAXIAL CABLE

Coaxial

Connecting a device — AUDIO CABLE TYPES

Your TV can be output sound to an audio device, such as a receiver or sound bar.

1. Verify that your device has an audio port that matches an available port on the TV (optical, RCA, etc).

2. Connect the appropriate cable (not included) to the TV and the device.

3. Turn the TV and your device on.

Note: The actual ports and their locations may vary, depending on the TV model.

HDMI CABLE

HDMI

COMPONENT AND/OR COMPOSITE CABLE

R

L

OPTICAL/SPDIF CABLE

Optical

9

WALL-MOUNTING THE TV

First you will need a wall mount. Consult the provided table below to nd the

appropriate mount for your TV.

Be sure the mount you choose is capable of supporting the weight of the TV.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. Place the TV face-down on a clean, at, stable surface. Be sure the surface is
clear of debris that can scratch or damage the TV.

3. If attached, remove the stands by loosening and removing the screws.

4. Attach your TV and wall mount to the wall by carefully following the instructions
that came with your mount. Use only with a UL-listed wall mount bracket rated
for the weight/load of your TV.

1

Installing a TV on a wall requires lifting. To prevent injury or damage
to the TV, ask someone to help you.

WARNING: Do not use the screws that are included inside the wall
mount holes to mount TV.

Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.

PX65-G1 PX75-G1

Screw Size: M6 M8

Hole Depth: 14 mm 14 mm

Hole Pattern: 400 mm x 400 mm 400 mm x 400 mm

Weight w/o Stand: 54.06 lb (24.52 kg) 78.59 lb (35.65 kg)

10

1

USING THE REMOTE

Change the currently displayed input

Quickly launch the pictured app

Navigate the on-screen menus

Go to the previous on-screen menu

Increase or decrease the loudness

Input

App Launcher

Exit

Close the on-screen menu

Arrow Buttons

Back

Volume Up/Down

of the audio

INPUT

EXIT

OK

BACK

CC

VOL CH

MENU

INFO

Power

Turn television on or o

Menu

Display the settings menu

OK/Play/Pause
Select the highlighted menu
option and play or pause content

Info

Display the info window

Closed Caption

Open the closed caption menu

Open Accessibility menu featuring talk back, zoom mode, and
video description*

Channel Up/Down

Change the channel

Replacing the Batteries

1. Find the notch on the back of the remote. Insert a coin and pry open the
back cover.

2. Insert two batteries into the remote control. Make sure that the (+) and (-) symbols
on the batteries match the (+) and (-) symbols inside the battery compartment.

3. Replace the battery cover.

Pic

Cycle through the dierent picture setting modes

Enabled/disable talk back feature*

Mute

Turn the audio on or o

Number Pad

Manually enter a channel

Wide

Change the picture display size/aspect ratio

Enable/disable zoom mode*

*Enabled/disabled dierent accessibility features by holding down each

of these buttons for 5 seconds.

PIC

1

2

3

V Button

Launch SmartCast HomeSM/Return
to SmartCast Home Screen

In many places batteries cannot be thrown away or discarded with household waste. Please ensure you properly
dispose of your batteries consistent with the laws and/or regulations where you live. For more information please
visit: www.vizio.com/environment

WARNING: Keep the remote control batteries away from children.

4

7

5 6

8

0

Last

Return to the channel last viewed

9

Dash

It may cause choking and/or lead to a re or chemical burn if
mishandled. Do not dispose of batteries in re. Replace only with

batteries of the correct type.

Use with number pad to manually enter a digital
sub-channel (for example, 18-4 or 18-5)

TIP: When needed, VIZIO recommends replacing
the batteries that came with this remote with
two, new Duracell ‘AAA’ alkaline batteries.

11

Before you begin the rst-time setup:

Choose a Wi-Fi Network.

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Choose a Wi-Fi Network.

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Choose a language for your TV.

English

Español Français

Back

Français

Choose a Wi-Fi Network.

Which room is your VIZIO TV Located?

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Family Room

Add Custom Location

Living Room

Master

Bedroom Game Room

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Choose a language for your TV.

English

Español Français

Back

Français

How are you using your TV?

Home Use

Store Demo

Choose a Wi-Fi Network.

Which room is your VIZIO TV Located?

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Family Room

Add Custom Location

Living Room

Master

Bedroom Game Room

Let’s set up local channels.

Next

Skip

To search for local broadcast channels, make sure the cable from the

antenna, wall or cable box is properly connected to your VIZIO TV.

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Choose a Wi-Fi Network.

Which room is your VIZIO TV Located?

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Family Room

Add Custom Location

Living Room

Master

Bedroom Game Room

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

2Completing the First-Time Setup

• Your TV should be installed and the power cord should be connected to an
electrical outlet.

• If you have a wireless network, have the network password ready.

• If you are connecting to your network with an Ethernet cable, connect it to the
Ethernet port on the TV.

The rst time you turn on the TV, the on-screen instructions will guide you through

each of the steps necessary to get your TV ready for use:

1. Choose your language.

Choose a language for your TV.

English

Español Français

Back

Français

How are you using your TV?

3. Choose your country.

4. Choose your WI-Fi network and enter the password.

Home Network

Where is you VIZIO TV located?

USA

Mexico Canada

Choose a Wi-Fi Network.

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Which room is your VIZIO TV Located?

Let’s set up local channels.

To search for local broadcast channels, make sure the cable from the

antenna, wall or cable box is properly connected to your VIZIO TV.

Skip

Next

6. Scan for channels.

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

VIZIO Terms &

Conditions

Terms & Conditions.

VIZIO Privacy

Policy

Skip For Now Accept All

Google Privacy

Policy

Google Terms &

Conditons

7. Accept the Terms & Conditions and register your device.

2. Choose home use.

Home Use

Store Demo

5. Name your TV.

Family Room

Living Room

Master

Add Custom Location

Bedroom Game Room

Now you're all set.

Enjoy!

12

Using the On-Screen Menu

3

Your TV features an easy-to-use on-screen menu.

To open the on-screen menu, press the MENU button on the remote.

From this menu, you can:

• Adjust the picture settings

TV Settings

• Adjust the audio settings

• Adjust the network settings

• Set up timers

• Adjust the channel settings

• Set up closed captioning

• Name and adjust Inputs


Audio

Network

Timers

Channels

Closed Captions

Input Settings

System

User Manual

• Adjust TV settings

• View the user manual

NAVIGATING THE ON-SCREEN MENU

To open the on-screen menu:

1. Press the MENU button on the remote.

2. Use the Navigation buttons to highlight a menu option, and press the OK
button to select that option.

TIP: While navigating the on-screen menu, you can press the BACK
button at any time to return to the previous menu screen.

CHANGING THE INPUT SOURCE

External devices, such as DVD players, Blu-ray Players, and video game consoles,
can be connected to your TV. To use one of these devices with your TV, you must

rst change the input source using the Input menu.

To change the input sources:

1. Press the INPUT button on the remote. The input menu is displayed.

2. Use the Navigation buttons or the INPUT button on the remote to highlight
the input you wish to view. The corresponding inputs are named on the back
of your TV.

3. Press OK or release the INPUT button. The selected input is displayed.

Change Input

HDMI-1 HDMI-2 COMP TVWatchFreeSMARTCAST

HDMI-3

HDMI-4 HDMI-5

Input Name

The underlined input on the left is the current input selected. Inputs may vary by TV.

TIP: You can change the input names that appear on the Input menu
to make your devices easy to recognize. See

the Input Menu on page 31.

Renaming Devices on

13

CHANGING THE SCREEN ASPECT RATIO

3

To change the screen aspect ratio:

Menu > System > Aspect Ratio

Use the Arrow buttons to highlight the aspect ratio you wish to view.

Your TV can display images in dierent modes: Normal, Stretch, Wide, Zoom,

and Panoramic.

• Normal (default) — No change to aspect ratio.

• Stretch*—When the 16:9 signal is a 4:3 image with black bars left and right,

stretches to ll the screen.

• Wide – Stretches a 4:3 aspect ratio to ll 16:9 screen. If a 16:9 image, adds black
bars to top and bottom.

• Zoom – Expands image both horizontally and vertically by 14%.

• Panoramic* — Stretches a 4:3 image to ll 16:9 screen with an algorithm so the
center doesn’t look stretched.

Some programs have black bars on the top or sides of the screen so that the
picture keeps its original shape. Examples include widescreen movies and older TV
programs.

Normal Panoramic

Wide

Zoom

*Available aspect ratio settings may vary by input source. Panoramic mode is only available for standard

denition TV (480i/480p) and Stretch mode is only available for high denition TV (720p/1080i/1080p).

TIP: The aspect ratio cannot be changed for Ultra HD content or
HDR content.

14

3

ADJUSTING THE PICTURE SETTINGS

Your TV can be adjusted to suit your preferences and viewing conditions.

To adjust the picture settings:

Menu > Picture > Picture Mode

1. Use the Navigation buttons on the remote to highlight Picture Mode, then use
the Left/Right Navigation buttons to change the picture mode:

• Standard — Sets the picture settings to the default settings.

• Calibrated — Sets the picture settings to values ideal for watching TV in a
brightly-lit room.

• Calibrated Dark — Sets the picture settings to values ideal for watching TV in
a dark room.

• Vivid — Sets the picture settings to values that produce a brighter, more
vivid picture.

• Game — Reduces throughput delays and optimizes the picture settings for
displaying game console output.

• Computer — Optimizes the picture settings for displaying computer output.

TIP: If you save changes to the settings for a picture mode, an asterisk
will appear after is name.

2. To manually change each of the picture settings, use the Up/Down Navigation
buttons on the remote to highlight that picture setting, then use the Left/Right

Navigation buttons to adjust the setting:

• Backlight — Adjusts the LED brightness to aect the overall brilliance of the

picture. Backlight cannot be adjusted when starting from some picture modes.

• Brightness — Adjusts the black level of
the picture. When this setting is too low,
the picture may be too dark to distinguish
details. When this setting is too high, the
picture may appear faded or washed out.

• Contrast — Adjusts the white level of
the picture. When this setting is too low,
the picture may appear dark. When this
setting is too high, the picture may appear
faded or washed out. If the setting is too

high or too low, detail may be dicult

to distinguish in dark or bright areas of
the picture.

• Color — Adjusts the intensity of the


Picture Mode

Backlight

Brightness

Contrast

Color

Tint

Sharpness

More Picture

Picture Mode Edit

Color Calibration

Calibrated

picture colors.

• Tint — Adjusts the hue of the picture. This

setting is useful in adjusting the esh tones in the picture. If esh appears too

orange, reduce the level of color before adjusting tint.

• Sharpness — Adjusts the edge sharpness of picture elements. It can be used

to sharpen non-HD (high denition) content; however, it will not produce detail

that does not otherwise exist.

Adjusting More Picture Settings

To adjust more picture settings:

Menu > Picture > More Picture

Use the Navigation buttons to highlight the setting you wish to adjust, then press
the Left/Right Navigation buttons to change
the setting:

• Color Temperature — Change the white
balance of the picture. Refer to the section
on

Adjusting the Color Temperature on

page 17

.

• Black Detail — Adjusts the average
brightness of the picture to compensate for
large areas of brightness.

• Active Full Array® — Based on the content,
dynamically adjusts and balances the
brightness and the contrast ratio of the
picture by locally adjusting backlight zones.

• Motion Control — Reduce the motion blur
of the conent with fast action.

• Reduce Noise:

− Reduce Signal Noise: Lessens artifacts in the image caused by the digitizing

of image motion content.

− Reduce Block Noise: Reduces pixelation and distortion for mpeg les.

• Game Low Latency — Reduces video delay (lag) when gaming.

More Picture

Color Temperature

Black Detail

Active Full Array

Motion Control

Reduce Noise

Game Low Latency

Film Mode

Color Space

Gamma

Enhanced Viewing Angle

®

Calibrated

Off

Medium

Off

On

Auto

2.1

On

See

Saving a Custom Picture Mode on page 16.

• Film Mode — Optimizes the picture for watching lms.

• Color Space — Select Color Space for the source. Video sources uses YCbCr, but

PC uses RGB.

• Gamma — Set the shape of the Gamma curve. Use lower Gamma values for
bright room conditions, and higher values when it’s dark.

• Enhanced Viewing Angle — Increases the viewing angle with richer colors and
a higher contrast image. This mode reduces horizontal resolution.

15

3

Adjusting the Color Temperature

Adjusting the color temperature changes the white balance of the picture.

To adjust the color temperature:

Menu > Picture > More Picture > Color Temperature

Use the Navigation buttons on the remote to highlight a color temperature preset
and then press OK.

• Normal — Optimized for television viewing.

• Cool — Produces a blue-hued picture.

• Computer — Optimizes the picture for use as a PC monitor.

Color Temperature

Normal

Cool

Computer

Adjusting the Picture Mode Edit Settings

Picture Mode Edit Settings allow you to make precise adjustments to the picture.

To adjust the Picture Mode Edit settings:

Menu > Picture > Picture Mode Edit

Use the Navigation buttons to highlight the setting you wish to adjust, then press
OK to change the setting:

• Save Picture Mode — Save a custom picture mode.

• Lock Picture Mode — Prevent changes to custom picture modes.

• Reset Picture Mode — Reset the picture mode settings to factory default values.

Only available on customized preset modes.

Picture Mode Edit

Save Picture Mode

Lock Picture Mode

Reset Picture Mode — Vivid

Saving a Custom Picture Mode

Custom picture modes allow you to save a group of custom settings for various
viewing conditions and video sources.

To save a custom picture mode:

Menu > Picture > Picture Mode Edit > Save Picture Mode > Enter a Name

>Save

• Changes made while on any preset picture mode will add an asterisk on the top
right corner of the preset mode.

• The custom picture mode is not automatically saved.

Save Picture Mode

16

3

Locking/Unlocking a Custom Picture Mode

Custom picture modes can be locked/unlocked with a unique PIN to prevent
accidental changes to their settings. If not previously set, you can set up your system
PIN code here.

To lock all custom picture modes:

Menu > Picture > Picture Mode Edit > Lock
Picture Mode > Enter Your PIN > Save

Lock Picture Mode

Enter the System PIN to lock all custom
picture modes.

To unlock all custom picture modes:

Menu > Picture > Picture Mode Edit > Lock

System Pin Code

Picture Mode > O > Enter Your PIN

Deleting a Custom Picture Mode

Custom picture modes that are no longer needed can be deleted.

TIP: Inputs assigned to a deleted custom picture mode become
assigned to the

Calibrated

picture mode.

To delete a custom picture mode:

Menu > Picture > Picture Mode Edit > Delete Picture Mode > Delete

To delete the user created Custom 1

picture mode, select the Delete button.

Delete Cancel

Resetting a Picture Mode

A preset picture mode that has been edited can be restored to the factory
default settings.

To reset a customized preset picture mode:

Menu > Picture > Picture Mode Edit > Reset Picture Mode > Reset

Select Reset to restor the Standard

picture mode to factory defaults.

Reset Cancel

TIP: To set a custom PIN passcode, see

page 33.

Setting a System PIN on

17

3

Adjusting the Color Tuner Settings

The Color Tuner settings allow you to adjust the color management system, 2 point

white balance, 11 point white balance, turn color channels o for testing, and display
SMPTE, at, ramp, and uniformity analyzer test patterns.

WARNING: The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV. Calibration
requires specialized training, an input with precisely set colors, and
a specialized light meter.

To access the color tuner table:

Menu > Picture > Color Calibration > Color Tuner

To turn color channels o and on:

1. Use the Navigation buttons on the remote to highlight Red, Green, or Blue.

2. Press the OK button to turn the color channel o or on. An X appears over a

color channel that has been turned o.

3. Only two color channels can be turned o at the same time.

To adjust the color management system/2 point white balance settings:

1. Use the Navigation buttons on the remote to highlight the Hue, Saturation,

Brightness, Oset, or Gain of the color you wish to adjust. Press the OK button.

2. Use the Left/Right Navigation buttons to adjust the value. When you are
nished press the OK button to save the setting.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Oset 0 0 0

Gain 0 0 0

To adjust the 11 Point White Balance settings:

1. From the Color Tuner table, use the Navigation buttons to highlight the top bar
and then press the Left/Right Navigation buttons until the 11 POINT WHITE
BALANCE menu is displayed.

11 Point White Balance

Gain Red Green Blue

5% 0 0 0

To show or hide the SMPTE Test Pattern:

Menu > Picture > Color Calibration > Calibration Tests > SMPTE Test Pat­tern

SMPT Test Pattern

O

1. Use the Navigation buttons on the remote to highlight O. Use the Left/
Right Navigation buttons to select On to show the SMPTE Pattern.

—or—

2. To hide the SMPTE Test Pattern, use the Left/Right Navigation buttons to
select O.

TIP: Any changes made aect the color temperature setting. Select
the preferred color temperature setting rst. See

Adjusting the

Color Temperature on page 16.

2. Use the Navigation buttons on the remote to highlight the Gain and Color
values you wish to adjust. Press the OK button and use the Left/Right
Navigation buttons to adjust the value. When you are nished, press the OK

button to save the setting.

18

3

To show or hide the Flat Test Pattern:

Menu > Picture > Color Calibration > Calibration Tests > Flat Test Pattern

Flat Test Pattern

O

1. Use the Navigation buttons on the remote to highlight O. Use the Left/Right

Navigation buttons to select the percentage brightness for the at test pattern.

Selecting a percentage immediately shows the at pattern at that brightness.

—or—

2. To disable the Flat Test Pattern, use the Left/Right Navigation buttons to
select O.

To show or hide the Ramp Test Pattern:

Menu > Picture > Color Calibration > Calibration Tests > Ramp Test
Pattern

Ramp Test Pattern

O

1. Use the Navigation buttons on the remote to highlight O. Use the Left/Right
Navigation buttons to select the color for the ramp test pattern. Selecting a

color immediately shows that color ramp.

—or—

2. To hide the Ramp Test Pattern, use the Left/Right Navigation buttons to
select O.

To show or hide the Uniformity Analyzer Test Pattern:

Menu > Picture > Color Calibration > Calibration Tests > Uniformity

Analyzer Test Pattern

Uniformity Analyzer Test Pattern

O

1. Use the Navigation buttons on the remote to highlight O. Use the Left/Right
Navigation buttons to select On to show the Uniformity Analyzer Test Pattern.

—or—

2. To hide the Uniformity Analyzer Test Pattern, use the Left/Right Navigation
buttons to select O.

19

3

ADJUSTING THE AUDIO SETTINGS

To adjust the audio settings:

Menu > Audio > OK

Use the Navigation buttons to highlight the setting you wish to adjust, then press

Left/Right Navigation buttons to change the setting:

• Speakers — Turn the built-in speakers On

or O.

• Volume Control Display — Turn the

on-screen volume display slider On or O.

• Surround Sound — Surround sound uses
DTS TruSurround™ to deliver an immersive
surround sound experience from the TV’s
internal speakers. TruSurround completes
the entertainment experience by providing
deep, rich bass, crisp details, and clear,

intelligible dialog. Select On or O.

• Volume Leveling — Volume leveling uses
DTS TruVolume™ to maintain consistent
volume levels during transitions between
program content, AV formats, and input

sources. Select On or O. In a few cases, volume leveling may articially suppress
volume increases, making it dicult to hear dialog or attening sudden noises.
If this occurs, turn volume leveling o.

Audio

Speakers

Volume Control Display

Surround Sound

Volume Leveling

Balance

Lip Sync

Digital Auto Out

Analog Audio

Auto

On

On

On

Auto

Out Fixed

• Lip Sync — Adjusts the synchronization between the display image and the
accompanying audio track.

• Digital Audio Out — Changes the type of processing for digital audio out and
HDMI ARC output when connected to a home theater audio system. Select Auto,
PCM, Dolby D or Bitstream.

- To hear talk back when Talk Back function is enabled, digital audio out must

be set to PCM.

• Analog Audio Out — Sets the volume control properties for the RCA connector
when connected to a home theater audio system. Select Variable if you are
controlling the volume with the TV’s volume controls, or select Fixed if an
external audio device (sound bar or AV receiver) will control the volume.

TIP: You must select Bitstream for audio with more than two
channels (e.g., 3.0, 5.0, or 5.1).

• Balance — Adjusts the loudness of the audio output from the left and
right speakers.

TIP: When the TV speakers are set to On, DTS signals cannot be
passed through digital audio outputs.

20

3

ADJUSTING THE NETWORK SETTINGS

Your TV is Internet-ready, featuring both an Ethernet port and built-in high-speed
wireless internet.

TIP: If your TV is connected to a network with an Ethernet cable, you
will not see the wireless network connection menu. You must unplug
the Ethernet cable to set a wireless network connection.

Connecting to a Wireless Network

To connect to a wireless network whose
network name (SSID) is being broadcast:

Menu > Network > Choose your network >

Enter in the password > Connect

Network

Wired Connection

Wireless Access Points

Manual Setup

Hidden Networks

Test Connection

Disconnected

Changing the Manual Setup Settings

Advanced users can ne-tune the network settings using the Manual Setup feature.

The security settings on your router may require you to enter the TV's MAC address.

To change advanced network settings:

Menu > Network > Manual Setup > DHCP

> O

1. Use the Navigation and OK buttons to
adjust each setting:

• IP Address — The IP address assigned to
the TV.

• Subnet Mask — The subnet Exit 2D.

• Default Gateway — Your network’s

Manual Setup

DHCP

IP Address

Subnet Mask

Default Gateway

Pref. DNS Server

Alt DNS Server

RJ45 Mac

Wireless Mac

Disconnected

__. __.__.__

__. __.__.__

__. __.__.__

__. __.__.__

__. __.__.__

0:0:0:0:0:0

0:0:0:0:0:0

default gateway address.

• Pref. DNS Server — Your preferred domain
name server address.

• Alt. DNS Server — Your alternate domain
name server address.

Connecting to a Hidden Network

To connect to a wireless network whose network name (SSID) is not being broadcast:

Menu > Network > Hidden Network > Enter the Access Point Name >
Connect > Enter in the password

Testing Your Network Connection

To test your network connection:

Enter Access Point Name

Enter your access point name. This is used
to connect to an access point with a hidden
SSID.

Menu > Test Connection

If you do not see your wireless network displayed, click on:

More Access Points > Highlight your wireless network > Enter in the

password > Connect

TIP: You can display your photos in Fullscreen. Select the photo,
press OK, then highlight Fullscreen and press OK.

2. Use the Navigation buttons on the remote to highlight Save and press OK.

To nd the TV’s MAC address:

Menu > Network > Manual Setup

You can nd your TV's MAC address at the bottom of the list. The MAC addresses for

the connections in use are displayed:

• RJ45 MAC — The Ethernet or RJ45 MAC address may be needed to set up your
network when you have connected the TV to your network when you have
connected the TV to your network with an Ethernet (Cat 5) cable.

• Wireless MAC — The Wireless (Wi-Fi) MAC address may be needed to connect
your TV to your network with Wi-Fi.

21

3

SETTING TIMERS

When activated, the TV’s timer will turn the TV o after a set period of time.

To setup a sleep timer:

Menu > Timers

Use the Left/Right Navigation buttons on the remote to highlight the period of
time after which you want the TV to go to sleep: 30, 60, 90, 120, or 180 minutes. If

you don’t want the sleep timer to activate, change the setting to O.

Timer

Sleep Timer

Auto Power Off

Blank Screen

Off

10 Minutes

Setting the Auto Power O Feature

To help save energy, your TV is set by default to turn o after 10 minutes without a

video or audio signal. This feature can be deactivated.

To set the Auto Power O feature:

Menu > Timers > Auto Power O > O

Using the Blank Screen Feature

To help save LED life, your TV screen can turn on or o while audio is streaming.

To use the Blank Screen feature:

Menu > Timers > Blank Screen

To exit Blank Screen, press any key (except the volume and mute keys).

22

3

SETTING UP CHANNELS

You can use the TV’s Channels menu to:

• Find channels

• Select channels to skip

• Select analog audio mode

• Select the language for digital audio

• Set parental controls

Channels

Find Channels

Skip Channels

Analog Audio

Digital Audio

Parental Control

Stereo

English

Scanning for Channels

The TV may need to scan for channels before it can display programs and their
associated information. A channel scan is required for free over-the-air channels
(using an antenna) and cable channels from an out-of-the-wall connection (without

a cable box). Moving the TV to an area with dierent channels requires the TV to

scan for channels again.

To perform an Auto Channel Scan:

Find Channels

Menu > Channels > Find Channels

Channels Found

Wait until the channel scan is 100% complete.
Highlight Done and press OK.

• If the channel scan is canceled, the
channels that were already discovered are
retained. A new channel scan will clear all
channels.

Digital

Analog

45% Complete

8

12

Skipping Channels

After a channel scan is completed, you may nd that some channels are too weak to

watch comfortably. There may also be some channels you do not want to view. You
can remove these channels from the TV’s memory with the Skip Channel feature.

WARNING: Channels that have been removed with the Skip Channel
feature can still be viewed if the channel is entered using the Number
Pad. If you wish to completely block a channel from being viewed,
use the parental controls.

See

Locking and Unlocking Channels on page 25.

To remove a channel:

Skip Channels

1. From the CHANNELS menu, highlight
Skip Channel, and press OK. The SKIP
CHANNEL menu is displayed.

2. For each channel you wish to remove,
use the Up/Down Navigation buttons on
the remote to highlight the channel and
press OK. A P appears to the right of each
channel you select.

0 Test 0

1 Test 1

2 Test 2

3 Test 3

4 Test 4

23

3

LISTENING TO ALTERNATE AUDIO

Changing the Analog Audio Language

Some analog over-the-air (free) and cable channels broadcast programs in more
than one language. The TV’s Analog Audio feature allows you to listen to audio in an
alternate language using Secondary Audio Programming (SAP).

WARNING: Not all programs are broadcast in SAP. The Analog Audio
Language feature only works when the program being viewed is
being broadcast with Secondary Audio Programming.

To use the Analog Audio feature:

Menu > Channels > Analog Audio

• Stereo — More than one speaker channel is being used. Sounds may be dispersed

through dierent speakers depending on how the audio is programmed.

• SAP (Secondary Audio Program) — Typically used for audio in a dierent
language other than the native one used in the program.

To use the Digital Language feature:

Menu > Channels > Digital Audio

Select the preferred audio language. Available languages or video description
depend on the broadcast content.

Digital Audio

English

Spanish / Video Description

French

• Mono — All speakers are producing the same sound; there is no distinction
between left or right sounds.

Analog Audio

Stereo

SAP

Mono

24

3

USING PARENTAL CONTROLS

The TV’s parental controls allow you to prevent the TV from displaying certain
channels or programs unless a PIN is used.

Accessing the Parental Controls Menu

To access the Parental Controls menu you must rst set up a system PIN:

Menu > Channels > Parental Controls > Enter in PIN

TIP: To set a custom PIN passcode, see

page 33.

The Parental Controls menu only appears when:

• You are using the tuner to receive your TV signals, such as when you are using
an antenna for Over-the-Air signals or when connected to cable TV directly from
the wall (no cable box).

• You have a device connected using a composite video cable or a coaxial cable,
such as a VCR, satellite or cable box, or DVR.

Setting a System PIN on

Enabling or Disabling Program Ratings

To manage program content according to its rating, you must rst enable the

Program Rating feature.

To enable or disable the Program Rating feature:

Menu > Channels > Parental Controls > Locks > ON/OFF

Locking and Unlocking Channels

When a channel is locked, it cannot be accessed. Locking a channel is a good way to
prevent children from viewing inappropriate material.

To lock or unlock a channel:

Menu > Channels > Parental Controls > Channel Locks

Highlight the channel you want to lock or unlock and press OK.

• When a channel is locked, the Lock icon appears locked. The channel is not
accessible unless the system PIN is entered.

• When a channel is unlocked, the Lock icon appears unlocked.

Blocking and Unblocking Content by Rating

A channel may sometimes broadcast programs that are meant for a variety of
audiences (some for children and some for adults). You might not want to block the
channel completely using a channel lock, but you can block certain programs from
being viewed.

You can use the TV’s Rating Block feature to block content based on its rating.

To block or unblock content by its rating:

1. From the Parental Controls menu, highlight the content type you want to adjust
and press OK:

• USA TV — USA television program broadcasts.

• USA Movie — USA movie broadcasts.

• Canadian English — Canadian English television program broadcasts.

• Canadian French — Canadian French television program broadcasts.

TIP: For a list of content ratings and their definitions, please visit:
www.tvguidelines.org.

2. For each rating type you want to block or unblock, use the Navigation buttons
to highlight the rating type and press OK.

TIP: Other devices have their own parental control settings.

• When the rating type is blocked, the Lock icon appears locked. Content with
this rating and all higher ratings cannot be viewed.

• When the rating type is unblocked, the Lock icon appears unlocked. Content
with this rating and all lower ratings can be viewed.

• If you want to block all unrated content, highlight Block Unrated Shows and
use the Navigation buttons on the remote to select On.

25

3

SETTING UP CLOSED CAPTIONING

Your TV can display closed captions for programs that include them. Closed captions
display a transcription of a program’s dialogue.

TIP: If the program you are viewing is not being broadcast with closed
captions, the TV will not display them.

To activate or deactivate closed captions:

Menu > Closed Captions > Closed Captions > O/On

1. Use the Navigation buttons on the remote
to highlight either Analog or Digital Closed
Captions.

2. Use the Left/Right Navigation buttons on
the remote to select the caption channel
you wish to display.

Closed Captions

Closed Captions

Analog Closed Captions

Digital Closed Captions

Digital Style

Off

CC1

CS1

Changing the Appearance of Digital Closed Captions

Digital closed captions can be displayed according to your preference. See the
diagram on the next page for an explanation of the parts of the closed caption area.

To change the appearance of digital closed captions:

Menu > Closed Captions > Digital Style

1. Use the Left/Right Navigation buttons on the remote to select Custom. The
Digital Style menu appears as shown.

Digital Style

Text Style

Text Size

Text Color

Text Opacity

Text Edges

Text Edges Color

Background Color

Background Opacity

Window Color

Window Opacity

As Broadcast

Large

Blue

As Broadcast

As Broadcast

As Broadcast

As Broadcast

As Broadcast

As Broadcast

As Broadcast

2. Use the Up/Down Navigation buttons on the remote to highlight the setting
you wish to change, then use the Left/Right Navigation buttons to change the
setting:

• Caption Style — Choose As Broadcast to keep default settings or Custom to
manually change each setting.

• Text Style  — Change the font used for the closed captioning text.

• Text Size — Make the text larger or smaller.

• Text Color — Change the color of the text.

• Text Opacity — Change the transparency of the text.

• Text Edges — Change the eects at the edges of the text, such as raising the
edges or adding drop shadows.

• Text Edges Color — Change the color of the text edge eects.

• Background Color — Change the color of the background directly behind
the text.

• Background Opacity — Change the transparency of the background directly
behind the text.

• Window Color — Change the color of the closed captioning box.

• Window Opacity — Change the opacity of the closed captioning box.

TIP: The Closed Captions menu does not appear when an HDMI input
is selected. Closed captions are available when using the tuner or a
composite video cable.

26

Typical choices include:

• Opaque background, transparent window — Only a strip of background appears behind the text, expanding as the text appears. This is the typical "As Broadcast" mode.

• Opaque background and window in the same color — When text appears, the entire line lls with color at once.

In the example, the closed caption text is green, the background is black, and the window is red.

Text Background Window

3

CLOSED CAPTION TEXT SAMPLE

27

3

CHANGING INPUT SETTINGS

To access input settings menu:

Menu > Input Settings

Highlight the input device that you want to view/change and press OK.

Renaming Devices on the Input Menu

You can rename the inputs to make them easier to recognize on the Input menu. For
example, if you have a DVD player connected to the component input, you can rename
that input to display “DVD Player.” See

To change the name of an input:

Menu > Input Settings

To use a preset input name:

• Highlight the Name Input row and press OK.

• Highlight the input name and use the Left/Right Navigation buttons on the
remote to cycle through preset input names

To enter a custom name:

• Highlight the Name Input row and press OK.

• Enter your custom label using the on-screen keyboard and press OK.

Changing the Input Source on page 13

—or—

.

Other settings include the following:

• Full UHD Color* — expanded color display.

• Picture Size* — congure the display size to enlarge or shrink the image to ll
the screen.

• Picture Position* — move the vertical and horizontal position of the picture in
relation to the screen.

• Hide from Input Source — hide inputs that are not being used. Hidden inputs
will not be displayed in the input list.

*Only available if there is an input source. Not available for WatchFree. Menu items will be
grayed out if not available.

Input Name

Input Settings

TV

HDMI-1

HDMI-2

HDMI-3

COMP

Blu-ray

Cable Box

HDMI-3

Game Console

Custom Name

TIP: You cannot rename the tuner or WatchFree input.

28

3

CHANGING THE TV SETTINGS

Using the System menu, you can:

• Check for updates

• View system information

• Change the on-screen menu language

• Set time zone and local settings

• Adjust the CEC settings

• Adjust the power mode settings

• Adjust to preserve aspect ratio or ll the
screen

• Name the TV

• Review and maintain the list of paired
devices

• Adjust accessibility settings

• Reset the TV settings and setup administrative controls

System

Check for Updates

System Information

Menu Language

Time & Local Settings

CEC

Power Mode

Aspect Ratio

TV Name

Mobile Devices

Accessibility

Reset and Admin

English

Quick Start

Normal

Ofce TV

Checking for System Updates

To check for a system update:

Menu > System > Check for Updates

If an update is found, the TV will ask to conrm the update. If no update is found,

the screen will note The TV is up-to-date.

Viewing System Information

To view technical data and status information about your TV and network
connection:

Menu > System > System Information

Changing the On-Screen Menu Language

Your TV can display the on-screen menu in dierent languages.

To change the on-screen menu language:

Menu > System > Menu Language

Highlight your preferred language (English,
Español, or Français) and press OK.

Menu Language

English

Español

Français

29

3

Setting the Time and Local Settings

To ensure the correct time is displayed when you press the INFO button, set the
TV’s time zone:

Menu > System > Time & Local Settings > Time Zone

To turn Daylight Saving Time on or o:

1. Highlight Daylight Saving Time and press OK. The Daylight Saving Time menu
is displayed.

2. Choose On if it is currently Daylight Savings Time, O if it is Standard Time, or

Auto to have the system automatically detect Daylight Savings Settings.

Adjusting the CEC Settings

The CEC function on your TV enables you to control devices connected to HDMI
(ARC) input with the included remote, without any programming. Using CEC, your
VIZIO TV remote can control:

• Power On/O

• Volume

• Mute

WARNING: Not all HDMI devices support CEC. See your device’s user
manual for details.

To enable, disable, or adjust CEC settings:

Set up your audio device and connect it to the HDMI-1(HDMI Arc) input on the TV.
On your audio device, select the HDMI ARC input.

Menu > System > CEC

Adjusting the Power Mode

Your TV is set to Eco Mode by default. When the TV is powered o, the Eco Mode

setting uses less than 0.5W of power. Quick Start Mode enables your display to
power on faster and also to turn on when powered from another device (such as
when you are casting onto the TV).

WARNING: Please note that by changing this setting the energy
consumption required to operate this device will change.

To switch between Eco Mode and Quick Start Mode:

Menu > System > Power Mode

Highlight either Eco Mode or Quick Start Mode and press OK.

Select a setting and then press OK.

• CEC — To use CEC, you must select Enable.

• Device Discovery — To determine if your device is connected and supports
CEC, select Device Discovery and then press OK.

30

3

Changing the TV Name

Naming your TV helps dierentiate it from other cast devices you may have

in your home.

To edit your TV name:

Menu > System > TV Name > Enter a Name

TV Name

Living Room TV

Manging Mobile Devices

Your TV can be paired with a mobile device so you can easily control your TV
across multiple devices.

To see a list of paired devices or unpair a device:

Menu > System > Mobile Devices

Highlight a device name to delete it and press OK.

Mobile Devices

Djae’s Tablet

Ana’s Phone

Work iPad

Accessibility Settings

VIZIO is committed to providing intuitive, user-friendly products. Your new VIZIO TV

oers several accessibility features that can help you with easy navigation.

To access the Accessibility menu:

Menu > System > Accessibility

1. Talk Back — enables your TV to speak all settings changes and adjustments
using the remote in English.

2. Speech Rate* — Adjusts the rate in which
Text-to-Speech is spoken. Select Slow,
Normal (Default), or Fast.

3. Zoom Mode — Enlarges a section of the
screen by approximately 200%.

4. Video Description — If included by
the broadcaster, provides a narrated
description of the action for the content.

To access the Closed Caption menu:

Accessibility

Talk Back

Speech Rate

Zoom Mode

Video Description

O

Normal

O

Off

Menu > Closed Captions

To access the Video Description menu:

Menu > Channels > Digital Audio

TIP: You can also enable/disable accessibility features using the

included remote. Please see

*Available only in English.

Using the Remote on page 11.

31

3

USING THE RESET & ADMIN MENU

You can use the TV’s Reset & Admin menu to restore the TV to its factory default
settings as well as access other system settings.

Using the RESET & ADMIN menu, you can:

• Reset the TV to factory settings

• Force the system to power o and on

• Create a system pin code to lock content
and picture settings

• Turn USB power on or o.

• Enable or disable program oers and
suggestions

• Enable or disable anonymous debug data
for system performance.

• Start or stop the store demo mode

Reset & Admin

Reset to Factory Defaults

Soft Power Cycle

Power Indicator

System PIN Code

USB Power

Viewing Data

VIZIO Privacy Policy

Store Demo

On

Always On

Restoring the TV to Factory Default Settings

All of the on-screen menu settings can be reset to the factory defaults.

To restore the TV to its factory default settings:

Menu > System > Reset & Admin > Reset to Factory Settings

1. If you set a system PIN code, enter it now.

2. The TV displays, “Select Reset to restore all TV settings to factory defaults."

3. Highlight Reset and press OK.

4. Wait for the TV to turn o. The TV will turn back on shortly afterward and the
setup process will begin.

Performing a Soft Power Cycle

A soft power cycle forces the TV to turn o then on again.

Menu > System > Reset & Admin > Soft Power Cycle > YES

WARNING: If you restore the TV to the factory default settings, all

changes you have made to the settings will be lost. This includes any
wireless or picture settings.

Turning the Power Indicator On or O

The power indicator on the front of your TV normally does not glow when the TV is
on. You can change this setting if you prefer the light to be on.

To turn the Power Indicator Light On or O:

Menu > System > Reset & Admin > Power Indicator > ON/OFF

32

3

Setting a System PIN

You can set a system pin to lock content and picture modes, as well as prevent

accidental system resets. The rst time you select System PIN code, you will need

to create a PIN.

To create a PIN.

Menu > System > Reset & Admin >
System PIN Code > Enter Your PIN > Save

System Pin Code

Change the PIN used for the System PIN.

New PIN

Conrm PIN

Using the USB Power Feature

The USB port can be used to charge devices.

The two options for this feature are:

• Always On — Power is always available.

• O When TV O — Power is only available

with the TV is on.

USB Power

Always On

Off When TV Off

About Viewing Data

Video ACR collects data related to publicly available content displayed on your
television/display, such as the identity of your broadcast, cable, or satellite television
provider, and the television programs and commercials viewed (including time, date,
channel, and whether you view them live or at a later time). We also collect unique

identiers about this TV, including the IP address. This data is collectively referred to

as “Viewing Data.” For more information about Viewing Data and how VIZIO protects
its customers’ privacy, please consult our privacy policy at www.vizio.com/privacy.

When ACR collection is turned on, we may share Viewing Data with authorized data
partners including analytics companies, media companies and advertisers. VIZIO
and its authorized data partners use Viewing Data to generate summary analysis
and reports of how users engage with content on their TVs and other devices. VIZIO
Viewing Data is sometimes enhanced with household demographic data and data
about digital actions (e.g. digital purchases and other consumer behavior taken by
devices associated with the IP Address we collect). Viewing Data also enables our

authorized data partners to deliver advertising relevant to your prole that you
might nd useful, both on the VIZIO TV/display and other devices sharing your IP

Address. Viewing Data is also used to help content publishers, broadcasters or
content distribution services create or recommend more relevant entertainment
based on summary insights, as well as helps us improve the design of our products,
software and services.

WARNING: You will need to enter your current PIN code the next
time you access this menu or if you’d like to change your PIN.

You can easily turn this feature On or O in the RESET & ADMIN menu. If you have

trouble enabling or disabling Viewing Data, please contact VIZIO Customer Support
by going to support.vizio.com and selecting Contact Us.

For more information, see https://www.vizio.com/viewingdata and review VIZIO’s
privacy policy at https://www.vizio.com/privacy.

33

USING THE INFO WINDOW

Press the INFO button one time to display:

• TV name

• Current input

3

• Picture mode

• Audio type

• Network name

• Time

TV Name

Living Room

Current Input Picture Mode Audio Type* Network Name

HDMI-1

Normal HomeWiFi

5:00 pmStereo

Time

* When TV speakers are o and Dolby Atmos content is passed through the TV to a sound bar

or other audio device, the Dolby Atmos icon will display with "Audio Out."

34

SmartCast Home

Application

Application

Application

Application

Application

Program Title

Application

MOVIES

SHOWS

SUPPORT

WATCHFREE

EXTRAS

LIVING ROOM TV

Cast

SM

4

What is SmartCast Home?

SmartCast Home lets you discover, stream, and control your content like never

before! Access top apps, like Netix, Hulu, and Amazon Prime Video, by using

the remote to easily browse and launch content directly from the home screen.

SmartCast Home makes nding something to watch easy and fun.

How to Launch SmartCast Home

Begin streaming with SmartCast Home by:

• Press the V-Logo button on your remote.

—or—

• Select SmartCast from the list of inputs.

Marquee Content

Launch content with one click

Search

Find TV shows, movies and more.

HOME

What you can do with SmartCast Home

• Stream high quality entertainment.

• Launch top tier apps directly from the home screen.

• Unlock your photos and videos by mirroring your laptop or mobile device onto
your TV.

• Rearrange apps on your home screen just the way you like it.

• Works with Google Assistant and other popular voice assistants.

Discover

New or popular content across multiple apps

Control your TV with the SmartCast Mobile™ App

Download the VIZIO SmartCast Mobile app and turn your smartphone into a remote

to control and congure your TV.

Get it here, or visit www.vizio.com/smartcastapp on your device to download:

With SmartCast Mobile, you can:

• Power on/o devices, play/pause content, and modify advanced settings, all
from the palm of your hand.

• Easily enter text onto your TV/display from your mobile device using a
full keyboard.

• Browse and discover movies, TV shows, music, live streams, and more, across
multiple apps at once.

• Access a quick look at show ratings, synopsis, cast, crew, clips, and other details.

Discover

Program Title

Apps

Program Title

Streaming Apps on your TV

Program Title

Program Title

Program Title

Visit www.vizio.com/smartcastapp for minimium requirements.

35

WatchFree

10:00

Kansas C

The Kitch

™

4

What is WatchFree?

VIZIO WatchFree takes your cord-cutting entertainment experience one step further!
With the simple press of a button, enjoy free streaming TV with over 100 live TV
channels to choose from – news, movies, sports, comedy, music and more. A built-in

on-screen guide makes nding something to watch easier than ever.

And it’s all FREE – no fees, no subscriptions, or logins.

Show Details

Find out show information

What you can do with WatchFree

• Stream over 100 live TV channels absolutely free – news, movies, sports, comedy,
music and more.

• Navigate through channels, organized by genre, with an intuitive on-screen
guide.

• Watch 1000’s of free movies from major studios.

• Watch the best of internet TV.

• No logins, subscriptions or transactions fees.

On-Screen Guide

Over 100 live TV and audio channels organized by genre

Zoneless

2018 • 2h • TV-G • Sci-Fi

Outer space: The closest known resemblance to a perfect vacuum. It has
essentially no friction, allowing countless stars, planets, and moons to move
about freely. This is the story of one man’s journey in this mysterious place.

How to Launch WatchFree

To launch and begin watching entertainment oered on WatchFree:

• Push the INPUT button on your remote.

—or—

• Simply select the WatchFree app logo from the SmartCast Home app row.

Note: Not available in Canada.

FAVORITES

115

107

203

204

205

9:00 9:30

Music

Zoneless

College Football

Network Security

The City

Fun WIth Max & Daniel

36

4Playing USB Media

The USB Media Player allows you to connect a USB ash drive to your TV and play

music, video, or photos.

Preparing Your USB Drive to Play USB Media

To display USB media, you must rst save your videos onto a USB ash drive:

• The USB ash drive must be formatted as FAT32.

• Files on the USB ash drive must end in a supported le extension ( .mp3, .jpg,
etc).

• The player is not designed to play media from external hard drives, MP3 players,
cameras, or smartphones.

Displaying USB Media

To display your USB media:

1. Connect your USB ash drive to the USB port on the side of the TV.

2. The TV will recognize the USB. Use the Navigation Keys on the remote to select
the content you want to play.

—or—

3. Select USB from the bottom streaming icons on the SmartCast HomeSM page.

Removing the USB Drive from the TV

To safely remove your USB ash drive from the TV:

1. Turn the TV o.

2. Disconnect your USB ash drive from the USB port on the side of the TV.

WARNING: Do not remove the USB ash drive while the TV is on.

Doing so may damage the drive.

Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.

TIP: You can display your photos in Fullscreen. Select the photo,
press OK, then highlight Fullscreen and press OK.

37

4Playing USB Media: Music

Back Button

Highlight this button and press OK
to return to the previous screen.

Connected Sources

Displays connected USB devices.

Current Folder

Playback Control

Toggle Music/Photos

Music

USB1: MyFlashDrive

My Music

Browse Photos

Now Playing Information

Displays song title, album title,
and artist name.

Fab Apple Dream
On The Answer Is Yes
By Ana Banana

MyFlashDrive\Audio\root\My Music

Track Album Artist Duration

#

Starry Summer

Downspin JCheesy 6:202

Mango Dream Ana Banana 8:463

Crystal Waters The Dash 4:214

Smooth Waves

Progress Bar

Displays the duration of the currently­playing song. The bar will lengthen as
the song progresses.

5:50 8:46

Summer Mix JCheesy 2:421

Summer Mix

Beach Mix

Beach Mix

Breezy Mix

Rio Steve 7:585

Album Art

If included on the USB thumb drive and
associated with your music, the album
art will display here.

Folder Contents/Playlist

This area displays the contents of the currently

selected folder. You can browse among les using

the Navigation and OK buttons on the remote.

Sort by Album/Artist/Track

Artist A-Z

Sort:

View:

Artist: A - Z

Folders

All

View All or View Folders

Toggle between viewing all content
and only viewing folders.

Page 1 of 1

Page Information

If your USB thumb drive has more les

than can be displayed on a single screen,
the page number is displayed here.

38

Back Button
Highlight this button and press OK
to return to the previous screen.

4Playing USB Media: Video

Connected Sources

Displays connected USB devices.

Current Folder

Sort by Date or File Name

Video

USB1: MyFlashDrive

My Videos

Sort:

View:

Date New-Old

Folders

MyFlashDrive\Video\root\My Videos

File Date Duration

#

Family Vacation - California

1

26th Birthday Party

Japan 2017

Aby’s Graduation

-

-

-

-

Page 1 of 1

00:23:43

00:38:182

00:41:083

00:25:324

Folder Contents/Playlist

This area displays the contents of the currently

selected folder. You can browse among les using

the Navigation and OK buttons on the remote.

View All or View Folders

Toggle between viewing all content
and only viewing folders.

Page Information

If your USB thumb drive has more les

than can be displayed on a single screen,
the page number is displayed here.

39

4Playing USB Media: Photo

Back Button

Highlight this button and press OK
to return to the previous screen.

Connected Sources

Displays connected USB devices.

Current Folder

Start Fullscreen Slideshow

Sort by Date or File Name

View Thumbnails/Folders

Adjust Slideshow Settings


USB1: MyFlashDrive

root

Start Slideshow

Name A-Z

Sort:

View:

Thumbnails

Settings

Back Button

Highlight and press OK
to return to left column.

VIZIO_2GB\Photo\root



Current Folder

Displays the folder path.

Folder Contents/Playlist

This area displays the contents of the currently

selected folder. You can browse among les using

the Navigation and OK buttons on the remote.

B.jpg C.jpg

E.jpg F.jpg

View Music Files

Browse Music

File Name: D 1920x1080

Resolution: 1920x1080

Size: 1607270KB

Photo Information

Displays the name, resolution, and

le size of the selected photo.


H.jpg I.jpg

Page 1 of 1

Page Information

If your USB thumb drive has more les

than can be displayed on a single screen,
the page number is displayed here.

40

Product Registration and Technical Support

Take a moment to register your product at

VIZIO.COM/PRODUCT-REGISTRATION

A

Customized

Support

Get priority assistance from

the VIZIO Support team.

Do you have questions? Find answers at

SUPPORT.VIZIO.COM

News and

Oers

Stay up-to-date with product

news and take advantage of

exclusive oers.

Updates and

Enhancements

Be rst to know about

important product updates.

and alerts.

41

AHelp Topics

The remote is not responding.

• Make sure the batteries are properly inserted matching the - and + symbols.

• Replace the batteries with fresh ones.

The TV displays “No Signal.”

• Press INPUT button on the remote control to select a dierent input source.

• If you are using cable TV or antenna connected directly to the TV, scan for
channels. See

There is no power.

• Ensure the TV is plugged into a working electrical outlet.

• Ensure the power cable is securely attached to the TV.

• Press the Power/Standby button on the remote or on the back of the TV to
turn the TV on.

The power is on, but there is no image on the screen.

• Ensure all cables are securely attached to the TV.

• Ensure all devices are connected correctly. Devices dier; see your device’s user
manual for details.

• Adjust Brightness, Contrast, or Backlight. See

page 15

• Press the INPUT button on the remote to select a dierent input source.

The sound is at or dialog is not audible.

• Turn o Volume Leveling. See

Where do I nd information on the accessibility features of this product and

other VIZIO products?

• Please visit https://www.vizio.com/accessibility,

• Email us at: [e-mail], or

• Give us a call at 1-877-698-4746.

How do I stream apps like Netix to my VIZIO SmartCast™ TV?

• Download and open a Chromecast-enabled apps on your mobile device. Then
tap the Cast button.

Scanning for Channels on page 23

.

Adjusting the Audio Settings on page 20

.

Adjusting the Picture Settings on

.

The colors on the TV don’t look right.

• Adjust the Color and Tint settings in the Picture menu. See

Adjusting the Picture

Settings on page 15.

• Select a pre-set picture mode. VIZIO recommends selecting Calibrated.

• Check all cables to ensure they are securely attached.

There is no sound.

• Press Volume Up on the remote control.

• Press the Mute button on the remote to ensure mute is o.

• Check the audio settings. See

• Check the audio connections of external devices (Blu-ray player, game console,
cable/satellite box) that are connected to the TV.

• If you are using an antenna, the signal strength of the channel may be low.
Ensure your antenna is connected securely to the TV and move the antenna
around the room or close to a window for the best signal.

The image quality is not good.

• For the best image quality, view high-denition programs using digital sources.
Connect your devices with HDMI cables.

• If you are using an antenna, the signal strength of the channel may be low.
Ensure your antenna is connected securely to the TV and move the antenna
around the room or close to a window for the best signal.

The picture is distorted.

• Move the TV away from electrical appliances, cars, and uorescent lights.

• Ensure all cables are securely attached.

The TV image does not cover the entire screen.

• If you are using TV, AV, or Component with 480i input, go to Menu > System >
Aspect Ratio.

The TV has pixels (dots) that are always dark.

• Your HD TV is precision-manufactured using an extremely high level of
technology. However, sometimes pixels may not display correctly. These types
of occurrences are inherent to this type of product and do not constitute a
defective product.

Adjusting the Audio Settings on page 20

.

The buttons on the remote aren’t working.

• Ensure you are only pressing one button at a time.

• Point the remote directly at the TV when pressing a button.

• Replace the remote batteries with new ones. See

page 11

I see “noise” or static on the screen.

• When your TV’s digital capabilities exceed a digital broadcast signal, the
signal is up-converted (improved) to match your TV’s display capabilities. This
up-converting can sometimes cause irregularities in the image.

• If you are using an antenna, the signal strength of the channel may be low.
Ensure your antenna is connected securely to the TV and move the antenna
around the room or close to a window for the best signal.

When I change input source, the TV image changes size.

• The TV remembers the viewing mode on each input source. If the viewing mode

on the new input source diers from the one on the input source you switch
from, the dierence may be noticeable.

• See

How do I download the VIZIO SmartCast Mobile™ App?

• Make sure your phone or tablet is connected to a Wi-Fi network. Open a browser
on your phone or tablet.

• Navigate to vizio.com/smartcastapp and follow the on-screen instructions to
download the VIZIO SmartCast Mobile™ App.

How do I change the Inputs?

• Press the INPUT button on the back of the TV to cycle through the Inputs.

• Press the INPUT button on the basic remote to cycle through the Inputs.

• Make sure the VIZIO SmartCast Mobile app is installed on your phone or tablet.
Open the VIZIO SmartCast Mobile app. Tap on the Device list and select your TV.
Tap on the Input key and select the Input of your choice.

.

Changing the Screen Aspect Ratio on page 14

Replacing the Batteries on

.

42

A

How do I connect to my Wi-Fi network?

• On your TV remote, press the Menu button then go to Network > Select your
Wi-Fi name > Enter password.

• Open the VIZIO SmartCast Mobile™ app on your phone or tablet. Tap on the
device list and select your Display.

• Tap on the Settings icon > Network > Wireless Access Points. Select your Wi-Fi
network from the list, enter the Wi-Fi password, and tap Connect.

How do I exit Demo Mode

• Press and hold the INPUT button on the back of the TV to exit the demo mode.

How do I watch Cable/Antenna TV channels?

• If you subscribe to cable or satellite, simply connect an HDMI cable (not included)
to the receiver.

• If you use external antennas to watch local broadcast channels, use a coaxial
cable to connect.

Some of my Channels are missing.

• Press the MENU button on your TV remote and select the channels option. Then
select Find Channels.

How do I know I am getting 4K resolution or HDR content such as Dolby Vision?

• As you are watching content on the television, press the INFO button on the
remote or VIZIO SmartCast Mobile app. You will see the current resolution being
displayed along with the version of video.

• HDR will show as a Dolby Vision icon, HDR10 or HLG.

• Open the VIZIO SmartCast Mobile app on your phone or tablet.

• Click on: Control > Your TV/Device Name > Settings Icon > Channels > Find
Channels.

How do I disable/enable Viewing Data?

• Press the MENU button on your remote and select the System option. Select

Reset & Admin. Then select Viewing Data to turn the feature on or o.

• Open the VIZIO SmartCast Mobile app on your phone or tablet.

• Click on: Control > Your TV/Device Name > Settings Icon > System > Reset &
Admin > Viewing Data Slider.

The television will not turn on using Alexa or Google Assistant.

• Ensure the television is in Quick Start mode.

• Tap on Menu > System > Power Mode > Quick Start.

43

PX65-G1 PX75-G1

Size 65” 75”

Viewable Area 64.5” 74.5”

PRODUCT DIMENSIONS

BSpecications

Dimensions w/ Stand

Dimensions w/o Stand

Weight w/ Stand 54.90 lb (24.90 kg) 79.56 lb (36.09 kg)

Weight w/o Stand 54.06 lb (24.52 kg) 78.59 lb (35.65 kg)

Mounting Screw Size M6 M8

Hole Pattern 400 mm x 400 mm 400 mm x 400 mm

PICTURE QUALITY

Maximum Resolution 3840 x 2160 (UHD) 3840 x 2160 (UHD)

LCD Backlight Direct LED Direct LED

Refresh Rate 240 Hz (Eective Refresh rate) 240 Hz (Eective Refresh rate)

INPUTS / OUTPUTS

HDMI Inputs 5 5

Component Video Input 1 1

Composite Video Input 1 (shared component) 1 (shared component)

Ethernet Input 1 1

RF Antenna Input 1 1

USB 1 1

Audio Output HDMI ARC, RCA, Digital Optical HDMI ARC, RCA, Digital Optical

56.96” x 35.11” x 11.81”

(1446.88 x 891.92 x 300 mm)

56.96” x 32.72” x 2.72”

(1446.88 x 831.12 x 69 mm)

65.72” x 40.24” x 13.39”

(1669.24 x 1022.06 x 340 mm)

65.72” x 39.18” x 2.65”

(1669.24 x 995.06 x 67.3 mm)

OTHER

Remote Control Model XRT136 XRT136

Power Consumption 251.32 W 300.09 W

Standby Power <0.5W <0.5W

Voltage 120V 120V

OSD Language English, French, Spanish English, French, Spanish

Certication

UL, cUL, FCC Class B, BETS-7/ICES-003

Class B, IC, HDMI (CEC, ARC) Dolby Audio,

Dolby Vision

UL, cUL, FCC Class B, BETS-7/ICES-003

Class B, IC, HDMI (CEC, ARC) Dolby Audio,

Dolby Vision

44

CRegulatory Information

FCC Class B Radio Interference Statement

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined

by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

Notice

The changes or modications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Shielded interface cables and AC power cord, if any, must be used in order to comply
with the emission limits.

The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modication to this equipment. It is the responsibilities of the user to

correct such interference.

This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.

Operations in the 5GHz products are restricted to indoor usage only.

This equipment complies with FCC/ISED radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

FCC Warning

Changes or modications not expressly approved by the party responsible for

compliance with the FCC Rules could void the user’s authority to operate this
equipment.

Caution

Always use a power outlet that is properly grounded

Canada Notice for License-Exempt Radio Apparatus

This device complies with Industry Canada’s license-exempt RSSs. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

This device operates on a no-protection no-interference basis. Should the user seek
to obtain protection from other radio services operating in the same TV bands, a
radio license is required. Please consult Industry Canada’s document CPC-2-1-28,
Optional Licensing for Low-Power Radio Apparatus in the TV Bands, for details.

Cet appareil est conforme aux CNR exempts de licence d’Industrie Canada. Son
fonctionnement est sujet aux deux conditions suivantes:

1. le dispositif ne doit pas produire de brouillage préjudiciable, et

2. ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable

Cet appareil fonctionne sur une base sans protection et sans interférence. Dans
le cas où l’utilisateur cherche à obtenir de la protection des autres services de
radio fonctionnant sur les mêmes bandes TV, aucune license est requise. Veuillez
consulter le document CPC-2-1-28 d’Industrie Canada, License optionnelle pour les
appareils radio de faible puissance, pour plus de détails.

Industry Canada Class B emission compliance statement

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe B est conforme à la norme NMB-003 du Canada.

45

Limited Warranty

D

UNITED STATES AND CANADA

BY USING YOUR VIZIO PRODUCT YOU AGREE TO BE BOUND BY ALL THE TERMS OF THIS
WARRANTY. BEFORE USING YOUR VIZIO PRODUCT, PLEASE READ THIS WARRANTY
CAREFULLY. IF YOU DO NOT AGREE TO THE TERMS OF THIS WARRANTY, DO NOT USE
THE VIZIO PRODUCT AND, WITHIN THIRTY (30) DAYS OF THE DATE OF PURCHASE,
RETURN IT FOR A REFUND TO THE AUTHORIZED RETAILER WHERE YOU PURCHASED IT.
This warranty contains a binding arbitration agreement and a class action waiver
for United States residents. If you live in the United States, the binding arbitration

agreement and class action waiver aect your rights under this warranty. Please

read the text under the section titled “Binding Arbitration Agreement; Class Action
Waiver (U.S. Residents Only)” carefully.

How Long This Warranty Lasts

For non-commercial use, VIZIO warrants the product on the terms set forth below
for one (1) year from the date of original purchase. For commercial use, VIZIO
warrants this product on the terms set forth below for ninety (90) days from the
date of original purchase.

What This Warranty Covers

VIZIO warrants the product against defects in materials and workmanship when
the product is used normally in accordance with VIZIO’s user guides and manuals.
Except where restricted by law, this warranty applies only to the original purchaser
of a new product. The purchase must have been made from an authorized retailer
in the United States (including Puerto Rico) or Canada. The product must also be
located in the country where it was purchased at the time of warranty service.

Zero Bright Pixel Defect Guarantee (Displays Only)

Your product may qualify for a warranty against “zero bright pixel” defects for the
duration of the warranty on select new product purchases. To determine if this
guarantee applies to your product, refer to the model’s product information page
at www.vizio.com, look for the “zero bright pixel” guarantee on the box, or contact
VIZIO Technical Support at the email address or telephone number below.

How to Get Service

Before obtaining warranty service, you may visit www.vizio.com for additional help
and troubleshooting. To obtain warranty service, contact VIZIO Customer Support
by going to support.vizio.com and selecting Contact Us.

You can also call Customer Support:

US — [phone]

Canada — [phone]

Your Obligations Before Service

You must obtain pre-authorization before sending your product to a VIZIO service
center. You may be required to supply a purchase receipt (or copy) to show that
the product is within the warranty period. When you return a product to a VIZIO
service center, you must ship the product in its original packaging or in packaging

that aords an equal degree of protection. VIZIO Technical Support will provide

instructions for packing and shipping the product to the VIZIO service center. ALL
USER DATA AND DOWNLOADED APPLICATIONS STORED ON A PRODUCT WILL BE
DELETED IN THE COURSE OF SOME IN-HOME AND ALL SHIP-IN WARRANTY SERVICE. If
this occurs, your product will be restored to its original state. You will be responsible
for restoring all applicable user data and downloaded applications. Recovery and
reinstallation of user data and downloaded applications is not covered under this
warranty. In order to protect your personal information, VIZIO recommends that
you always clear all personal information from the product before it is serviced,
regardless of the servicer.

VIZIO’s Responsibilities

If VIZIO determines that a product is covered by this warranty, VIZIO will (at its
option) repair or replace it, or refund the purchase price to you. There will be no
charge for parts or labor during the warranty period. Replacement parts may be

new or recertied at VIZIO’s option and sole discretion. Replacement parts and

VIZIO’s labor are warranted for the remaining portion of the original warranty or for
ninety (90) days from warranty service, whichever is longer.

Types of Service

TVs that are 32 inches or larger will usually be serviced in-home. In-home service
requires complete and easy access to the product and does not include de-installation
or re-installation of the product. In-home service is subject to availability. VIZIO will
provide other service options when in-home service is not available. All other VIZIO
products must be sent to a VIZIO service center to obtain warranty service. VIZIO is
not responsible for transportation costs to the service center, but VIZIO will cover
return shipping to the customer.

What This Warranty Does Not Cover

This warranty does not cover: (a) cosmetic damage; (b) normal wear and tear; (c)
improper operation; (d) improper voltage supply or power surges; (e) signal issues;

(f) damage from shipping; (g) acts of God; (h) customer misuse, modications or

adjustments; (i) installation, set-up, or repairs attempted by anyone other than by
a VIZIO authorized service center; (j) products with unreadable or removed serial
numbers; (k) products requiring routine maintenance; or (l) products sold “AS IS”,
“CLEARANCE”, “FACTORY RECERTIFIED”, or by a non-authorized reseller.

What to Do If You Are Not Satised With Service

If you feel VIZIO has not met its obligations under this warranty, you may attempt
to resolve the issue informally with VIZIO. If you are unable to resolve the issue

informally and wish to le a formal claim against VIZIO, and if you are a resident of

the United States, you must submit your claim to binding arbitration according to
the procedures described below, unless an exception applies. Submitting a claim to
binding arbitration means that you do not have the right to have your claim heard
by a judge or jury. Instead your claim will be heard by a neutral arbitrator.

Binding Arbitration Agreement; Class Action Waiver (U.S. Residents Only)

UNLESS YOU HAVE BROUGHT AN ELIGIBLE CLAIM IN SMALL CLAIMS COURT OR
HAVE OPTED OUT AS DESCRIBED BELOW, ANY CONTROVERSY OR CLAIM RELATING
IN ANY WAY TO YOUR VIZIO PRODUCT, INCLUDING ANY CONTROVERSY OR
CLAIM ARISING OUT OF OR RELATING TO THIS WARRANTY, A BREACH OF THIS
WARRANTY, OR THE VIZIO PRODUCT’S SALE, CONDITION OR PERFORMANCE,
WILL BE SETTLED BY BINDING ARBITRATION ADMINISTERED BY THE AMERICAN
ARBITRATION ASSOCIATION AND CONDUCTED BY A SINGLE ARBITRATOR
APPOINTED BY THE AMERICAN ARBITRATION ASSOCIATION, IN ACCORDANCE
WITH ITS COMMERCIAL ARBITRATION RULES AND ITS SUPPLEMENTARY
PROCEDURES FOR CONSUMER-RELATED DISPUTES. You may learn more about
the American Arbitration Association and its rules for arbitration by visiting www.
adr.org or by calling 800-778-7879. Since this warranty concerns a transaction in
interstate or international commerce, the Federal Arbitration Act will apply.

The ling fees to begin and carry out arbitration will be shared between you and VIZIO,

but in no event will your fees ever exceed the amount allowable by the American
Arbitration Association, at which point VIZIO will cover all additional administrative
fees and expenses. VIZIO waives its right to recover attorneys’ fees in connection with
any arbitration under this warranty. If you are the prevailing party in an arbitration
to which the Supplementary Procedures for Consumer-Related Disputes applies,
then you are entitled to recover attorneys’ fees as the arbitrator may determine.
The dispute will be governed by the laws of the state or territory in which you
resided at the time of your purchase (if in the United States). The place of arbitration
will be Irvine, California, or your county of residence (if in the United States). The
arbitrator will have no authority to award punitive or other damages not measured
by the prevailing party’s actual damages, except as may be required by statute. The
arbitrator will not award consequential damages, and any award will be limited to
monetary damages and will include no equitable relief, injunction, or direction to
any party other than the direction to pay a monetary amount. Judgment on the

award rendered by the arbitrator will be binding and nal, except for any right of

appeal provided by the Federal Arbitration Act, and may be entered in any court
having jurisdiction. Except as may be required by law, neither you nor VIZIO nor

46

D

an arbitrator may disclose the existence, content, or results of any arbitration
under this warranty without the prior written consent of you and VIZIO.
ANY DISPUTE, WHETHER IN ARBITRATION, IN COURT, OR OTHERWISE, WILL BE
CONDUCTED SOLELY ON AN INDIVIDUAL BASIS. VIZIO AND YOU AGREE THAT NO
PARTY WILL HAVE THE RIGHT OR AUTHORITY FOR ANY DISPUTE TO BE ARBITRATED
AS A CLASS ACTION, A PRIVATE ATTORNEY GENERAL ACTION, OR IN ANY OTHER
PROCEEDING IN WHICH EITHER PARTY ACTS OR PROPOSES TO ACT IN A REPRESENTATIVE
CAPACITY.NO ARBITRATION OR PROCEEDING WILL BE JOINED, CONSOLIDATED, OR
COMBINED WITH ANOTHER ARBITRATION OR PROCEEDING WITHOUT THE PRIOR
WRITTEN CONSENT OF ALL PARTIES TO ANY SUCH ARBITRATION OR PROCEEDING.

Exceptions to Binding Arbitration Agreement and Class Action Waiver

IF YOU DO NOT WISH TO BE BOUND BY THE BINDING ARBITRATION AGREEMENT
AND CLASS ACTION WAIVER, THEN: (1) you must notify VIZIO in writing within sixty

(60) days of the date that you purchased the product; (2) your written notication

must be mailed to VIZIO at 39 Tesla, Irvine, CA 92618, Attn: Legal Department;

and (3) your written notication must include (a) your name, (b) your address, (c)

the date you purchased the product, and (d) a clear statement that you wish to
opt out of the binding arbitration agreement and class action waiver.
In addition, you may pursue a claim in small claims court in your county of residence
(if in the United States) or in Orange County, California. In such case the provisions
of the section titled “Binding Arbitration Agreement; Class Action Waiver (U.S.
Residents)” will not apply.

ALLEGED DAMAGE, OR DEFECTIVE GOODS, NO MATTER WHETHER SUCH DEFECTS
ARE DISCOVERABLE OR LATENT), VIZIO MAY, AT ITS SOLE AND EXCLUSIVE OPTION
AND IN ITS DISCRETION, REPAIR OR REPLACE YOUR PRODUCT, OR REFUND ITS
PURCHASE PRICE. AS NOTED, SOME STATES AND PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

How the Law Applies

This warranty gives you specic legal rights, and you may also have other rights,

which vary from state to state and province to province. This warranty applies to the
greatest extent permitted by applicable law.

General

No employee or agent of VIZIO may modify this warranty. If any term of this
warranty, other than the class action waiver, is found to be unenforceable, that

term will be severed from this warranty and all other terms will remain in eect. If

the class action waiver is found to be unenforceable, then the entire section titled
“Binding Arbitration Agreement; Class Action Waiver (U.S. Residents Only)” will not
apply. This warranty applies to the maximum extent not prohibited by law.

Changes to Warranty

This warranty may change without notice, but any change will not aect your original

warranty. Check www.vizio.com for the most current version.

Exclusions and Limitations

TO THE GREATEST EXTENT PERMITTED BY APPLICABLE LAW, THERE ARE NO
EXPRESS WARRANTIES OTHER THAN THOSE DESCRIBED ABOVE. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, WILL BE LIMITED IN DURATION TO
THE WARRANTY PERIOD SET FORTH ABOVE. SOME STATES AND PROVINCES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
VIZIO WILL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF INFORMATION OR
DATA, COMMERCIAL LOSS, LOST REVENUE OR LOST PROFITS, OR OTHER INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF VIZIO HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND EVEN IF THE REMEDY
FAILS OF ITS ESSENTIAL PURPOSE. SOME STATES AND PROVINCES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
IN LIEU OF ANY OTHER REMEDY FOR ANY AND ALL LOSSES AND DAMAGES
RESULTING FROM ANY CAUSE WHATSOEVER (INCLUDING VIZIO’S NEGLIGENCE,

47

Legal Information

E

Software Licenses

All software is provided subject to a software license agreement(s) and you agree
that you will be bound by such license agreement(s) in addition to these terms.
Your use of this product is subject to VIZIO’s privacy policy, which may be updated
from time to time, and is available to view at http://www.vizio.com/privacy.

Export Regulations

Customer acknowledges that the VIZIO products, which include technology and
software, are subject to customs and export control laws in the United States (“US”).
The products may also be subject to the customs and export control laws and
regulations of the country in which t he products are manufactured and/or received.

Internet Connectivity and App Availability

Network conditions, environmental and other factors may negatively aect

connectivity and the resulting video quality, if any. The applications and content
of the applications pictured herein or described in accompanying documentation
may only be available in certain countries or languages, may require additional fees

or subscription charges, and may be subject to future updates, modications or

discontinuation without notice. VIZIO has no control over third party applications
or content and assumes no responsibility for the availability or interruption
of such applications or content. Additional third party terms, conditions and
restrictions apply.

Information in this User Manual is subject to change without notice. To review the
most updated version of this User Manual and the associated Quick Start Guide,
go to http://www.vizio.com.

© 2019 VIZIO, Inc. All Rights Reserved.

This User Manual may not be copied in whole or in part without the written

permission of VIZIO, Inc. VIZIO, Inc. has made reasonable eorts to ensure
the accuracy of the information provided herein. All product specications,
functionality, features, congurations, performance, design and other product

information described herein are subject to change without notice. VIZIO, Inc. is
not responsible for typographical, technical, or descriptive errors.

VIZIO, the VIZIO logo, the V logo, and other terms and phrases are trademarks or
registered trademarks of VIZIO, Inc.

The terms HDMI, HDMI High-Denition Multimedia Interface, and the HDMI Logo

are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS,
Inc. DTS, the symbol, DTS and the symbol together, and DTS Studio Sound II are
registered trademarks and/or trademarks of DTS, Inc. In the United States and/or
other countries. © DTS, Inc. All rights reserved.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby Laboratories. Copyright © 1992-2015
Dolby Laboratories. All rights reserved.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, and the
double-D symbol are trademarks of Dolby Laboratories. Copyright © 2013-2015
Dolby Laboratories. All rights reserved.

Google Play logo, YouTube, and Chromecast built-in are trademarks of Google LLC.

Other names of companies, products, and services used in this User Manual may
be trademarks, trade names or ser vice marks of others and VIZIO, Inc. disclaims
any interest in trademarks, trade names or service marks other than its own.
Mention of non-VIZIO products is for informational purposes only.

App ser vices featured on the included IR remote may vary and may not be available
in all regions.

4K or HDR availability varies by app and may be subject to subscription fees,
internet service, and device capabilities.

Battery Disposal

Caution: This product may be shipped with batteries. Do not dispose

of batteries in a re or with ordinary household waste. Batteries

may explode and can cause damage. Replace batteries only with

the same or equivalent type of battery recommended by VIZIO. The
disposal of batteries may be regulated by your state. For more information on
recycling or properly disposing of your batteries, please check with your state or
go to www.vizio.com/environment.

Product Recycling

The disposal and recycling of consumer electronic products may be regulated
by your state. Always properly dispose of your VIZIO products in accordance
with local laws and regulations. VIZIO supports the proper recycling of our
products. For information on how to properly recycle your VIZIO products
and to learn more about consumer electronics recycling laws, please go to
www.vizio.com/environment or call [phone].

Packaging Disposal

VIZIO encourages the recycling of the packaging used for this product. Please
break-down all boxes and recycle eligible materials according to local laws and
regulations. For more information please go to www.vizio.com/environment or call
[phone].

Accessibility

For information on the accessibility features of this product and other VIZIO
products please visit:

https://www.vizio.com/accessibility
Email: [e-mail]
Phone: [phone]

© 2019 VIZIO INC. All rights reserved.
190531SL

48
