VIZIO M320VT User Manual

Dear VIZIO Customer,

Congratulations on your new VIZIO High Definition LCD Television purchase. This User
Manual covers M320VT model for any specification difference, please refer to the table in
Chapter 6. Thank you for your support. For maximum benefit of your set, please read
these instructions before making any adjustments, and retain them for future reference.
We hope you will experience many years of enjoyment from your new VIZIO HDTV.

For assistance, please call [phone] or visit us at www.vizio.com

To purchase or inquire about accessories and installation services for your VIZIO LCD
HDTV, please visit our website at

We recommend you register your VIZIO HDTV either at our website

www.vizio.com or call toll free at [phone].

www.VIZIO.com or

fill in your registration card and mail it in. For peace of mind and to protect your
investment beyond the standard warranty, VIZIO offers on-site extended warranty service
plans. These plans give additional coverage during the standard warranty period. Visit
our website or call us to purchase a plan.

Write down the serial number located on the back of your HDTV.

__ __ __ __ __ __ __ __ __ __ __ __ __

Purchase Date _____________________

VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.
HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.

TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc.

This product qualifies for ENERGY STAR in the “factory default (Home Use)” setting and this is the
setting in which power savings will be achieved. Changing the factory default picture setting or enabling
other features will increase power consumption that could exceed the limits necessary to qualify for
Energy Star rating.

and are trademarks of SRS Labs, Inc.

THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS;
IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. VIZIO, THE V LOGO, WHERE VISION
MEETS VALUE AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO
INC. PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. © 2010 VIZIO
INC. ALL RIGHTS RESERVED.

Version 4/21/2010 1

www.VIZIO.com

VIZIO M320VT User Manual

Important Safety Instructions

Your HDTV is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent your HDTV from being damaged, the following
rules should be observed for the installation, use, and maintenance of your HDTV. Read the
following safety instructions before operating your HDTV. Keep these instructions in a safe place
for future reference.

Warnings:

• To reduce the risk of electric shock or component damage, switch off the power before
connecting other components to your HDTV.

• Unplug the power cord before cleaning your HDTV. A damp cloth is sufficient for cleaning your
HDTV. Do not use a liquid or a spray cleaner for cleaning your HDTV. Do not use abrasive
cleaners.

• Always use the accessories recommended by the manufacturer to insure compatibility.

• When moving your HDTV from an area of low temperature to an area of high temperature,

condensation may form in the housing. Wait before turning on your HDTV to avoid causing fire,
electric shock, or component damage.

• Use only with the cart, stand, tripod, bracket, or table specified by manufacturer or sold with your
HDTV. When a cart is used, use caution when moving the cart/HDTV combination to avoid injury
from tip-over. Do not place your HDTV on an unstable cart, stand, or table. If your HDTV falls, it
can injure a person and cause serious damage to your HDTV. Use only a cart or stand
recommended by the manufacturer or sold with your HDTV.

• A distance of at least 3 feet should be maintained between your HDTV and any heat source, such
as a radiator, heater, oven, amplifier etc. Do not install your HDTV close to smoke. Operating
your HDTV close to smoke or moisture may cause fire or electric shock.

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure
reliable operation of your HDTV and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your HDTV in a bookcase or cabinet unless proper
ventilation is provided.

• Never push any object into the slots and openings on your HDTV cabinet. Do not place any
objects on the top of your HDTV. Doing so could short circuit parts causing a fire or electric
shock. Never spill liquids on your HDTV.

• Your HDTV should be operated only from the type of power source indicated on the label. If you
are not sure of the type of power supplied to your home, consult your dealer or local power
company.

• Do not apply pressure or throw objects at your HDTV. This may compromise the integrity of the
display. The manufacturer’s warranty does not cover user abuse or improper installations.

• The power cord must be replaced when using different voltage than the voltage specified. For
more information, contact your dealer.

• Your HDTV is equipped with a three-pronged grounded plug (a plug with a third grounding
pin). This plug will fit only into a grounded power outlet. This is a safety feature. If

your outlet does not accommodate the three-pronged, have an electrician install
the correct outlet, or use an adapter to ground your HDTV safely. Do not defeat
the safety purpose of the grounded plug.

• When connected to a power outlet, power is always flowing into your HDTV. To
totally disconnect power, unplug the power cord.

• The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-isolated, dangerous
voltage within the inside of your HDTV that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.

Version 4/21/2010 2

www.VIZIO.com

VIZIO M320VT User Manual

• The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and servicing instructions in the literature accompanying your HDTV.

• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.

• The wall socket should be installed near your HDTV and easily accessible.

• Only power of the marked voltage can be used for your HDTV. Any other voltage than the

specified voltage may cause fire or electric shock

• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power
cord during electrical storms.

• Unplug your HDTV during a lightning storm or when it will not be used for long period of time.
This will protect your HDTV from damage due to power surges.

• Do not attempt to repair or service your HDTV yourself. Opening or removing the back cover may
expose you to high voltages, electric shock, and other hazards. If repair is required, contact your
dealer and refer all servicing to qualified service personnel.

• Keep your HDTV away from moisture. Do not expose your HDTV to rain or moisture. If water
penetrates into your HDTV, unplug the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.

• Do not use your HDTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug
the power cord and contact your dealer immediately. Do not try to repair your HDTV yourself.

• Avoid using dropped or damaged appliances. If your HDTV is dropped and the housing is
damaged, the internal components may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your HDTV may cause fire or electric shock.

• Do not install your HDTV in an area with heavy dust or high humidity. Operating your HDTV in
environments with heavy dust or high humidity may cause fire or electric shock.

• Follow instructions for moving your HDTV. Ensure that the power cord and any other cables are
unplugged before moving your HDTV.

• When unplugging your HDTV, hold the power plug, not the cord. Pulling on the power cord may
damage the wires inside the cord and cause fire or electric shock. When your HDTV will not be
used for an extended period of time, unplug the power cord.

• To reduce risk of electric shock, do not touch the connector with wet hands.

• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to

leak which can damage the remote control or injure the operator.

• If any of the following occurs, contact the dealer:

o The power cord fails or frays.
o Liquid sprays or any object drops into your HDTV.
o Your HDTV is exposed to rain or other moisture.
o Your HDTV is dropped or damaged in any way.
o The performance of your HDTV changes substantially.

Version 4/21/2010 3

www.VIZIO.com

VIZIO M320VT User Manual

Television Antenna Connection Protection

External Television Antenna Grounding

If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a
lightning storm or when it is left unattended
or unused for long periods of time, unplug
the TV from the wall outlet and disconnect
the antenna or cable system.

Power Lines

Do not locate the antenna near overhead
light or power circuits, or where it could fall
into such power lines or circuits.

Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.

FCC Bulletin for New TV Owners

The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your
local television stations may switch sooner. After the switch, analog-only television sets that receive
TV programming through an antenna will need a converter box to continue to receive over-the-air
TV. Watch your local stations to find out when they will turn off their analog signal and switch to
digital-only broadcasting. Analog-only TVs should continue to work as before to receive low power,
Class A or translator television stations and with cable and satellite TV services, gaming consoles,
VCRs, DVD players, and similar products.
For additional information, please contact the parties listed below, as appropriate:
FCC (US Federal Communications Commission)

http://www.fcc.gov/

Phone: 1-888-CALL-FCC (1-888-225-5322)
TTY: 1-888-TELL-FCC (1-888-835-5322)
Fax: [phone]
E-mail: [e-mail]

NTIA (National Telecommunications and Information Administration)

http://www.ntia.doc.gov/

1-888-DTV-2009

Listings of US Television Stations

http://www.high-techproductions.com/usTVstations.htm

Note: Your HDTV comes with a built-in tuner capable of processing digital broadcasts. No extra

converter box is needed.

Version 4/21/2010 4

www.VIZIO.com

VIZIO M320VT User Manual

Table of Contents

Important Safety Instructions ..................................................................................................................................... 2

HDTV Accessories and Services .............................................................................................................................. 6

Chapter 1 Setting Up Your HDTV .................................................................................................................................. 7

Attaching the TV Stand ............................................................................................................................................. 7

Wall Mounting Your HDTV ........................................................................................................................................ 8

Chapter 2 Basic Controls and Connections .............................................................................................................. 10

Front Panel .............................................................................................................................................................. 10

Side Panel Controls................................................................................................................................................. 10

Rear and Side Panel Connections .......................................................................................................................... 11

Remote Control Buttons .......................................................................................................................................... 13

Programming the Remote Control ........................................................................................................................... 14

Searching Automatically for the Codes ........................................................................................................................ 14

Remote Control Range ............................................................................................................................................ 15

VIZIO Remote Control Precautions .................................................................................................................... 15

Inserting the remote control batteries ................................................................................................................. 15

Using a Cable or Satellite Remote ...................................................................................................................... 15

Chapter 3 Connecting Equipment ................................................................................................................................ 16

Connecting Your Cable or Satellite Box .................................................................................................................. 17

Using HDMI ........................................................................................................................................................ 17

Using Component Video ..................................................................................................................................... 19

Connecting Coaxial (RF) ......................................................................................................................................... 20

Using Your Antenna or Digital Cable for DTV ..................................................................................................... 20

Using Your Antenna or Cable for TV .................................................................................................................. 20

Using the Antenna or Cable through your VCR .................................................................................................. 20

Connecting Your DVD Player .................................................................................................................................. 21

Using HDMI ........................................................................................................................................................ 21

Using Component Video ..................................................................................................................................... 23

Using Composite (AV) Video .............................................................................................................................. 24

Connecting a USB (FAT32 Format) Storage Device .................................................................................................... 24

Connecting an external Receiver/Amp .................................................................................................................... 25

Connecting a PC (Computer) .................................................................................................................................. 26

Chapter 4 Setting Up to Watch Television ................................................................................................................... 27

Basic LCD HDTV Start Up ...................................................................................................................................... 27

Selecting Inputs ............................................................................................................................................................ 29

Using the INFO Guide .................................................................................................................................................. 31

Watching a TV Program .......................................................................................................................................... 32

Using the On-Screen Display (OSD) ....................................................................................................................... 32

Using the Navigation Wheel .................................................................................................................................... 33

Unique TV Features ................................................................................................................................................ 34

Adjusting Settings ................................................................................................................................................... 35

Adjusting Timer Settings ......................................................................................................................................... 35

Adjusting Multimedia Settings ................................................................................................................................. 36

Adjusting the Audio Settings ................................................................................................................................... 39

Adjusting the TV Settings ........................................................................................................................................ 40

Adjusting the Picture Settings ................................................................................................................................. 40

Adjusting the Parental Control settings ................................................................................................................... 42

Adjustments on the Help Menu ............................................................................................................................... 48

Adjusting the CC (Closed Caption) settings ............................................................................................................ 49

Chapter 5 Maintenance and Troubleshooting .............................................................................................................. 50

Maintenance ............................................................................................................................................................ 50

Troubleshooting Guide ............................................................................................................................................ 51

Telephone & Technical Support .............................................................................................................................. 53

Compliance ............................................................................................................................................................. 53

FCC Class B Radio Interference Statement ............................................................................................................ 54

Chapter 6 Specifications .............................................................................................................................................. 55

Preset PC Resolutions ....................................................................................................................................... 56

Glossary – Standard Definitions .............................................................................................................................. 57

Chapter 7 Warranty ...................................................................................................................................................... 58

Chapter 8 Index ............................................................................................................................................................ 60

Version 4/21/2010 5

www.VIZIO.com

VIZIO M320VT User Manual

Code for Programming the Remote Control ............................................................................................................ 62

Opening the Package

Your VIZIO HDTV and accessories are carefully packed in a cardboard carton that has been designed to
protect it from transportation damage. Now you have opened the carton check that your HDTV is in good
condition and that all of the accessories are included.

Due to the weights and sizes of your HDTV models, we strongly advise that you have at least 2 people to
unpack and install the HDTV.

The screen can easily be scratched or broken so please handle the product gently and never place the
HDTV with the glass facing downwards on a surface without protective padding.

IMPORTANT: Save the carton and packing material for future shipping.

Package Contents

VIZIO M320VT
Detachable Stand Base
4 Thumbscrews (to attach Stand)
VIZIO Remote Control
Screen Cleaning Cloth
This User Manual
Quick Setup Guide
Registration Card
2 AA Batteries for the Remote Control

Caution:

of the display. The manufacturer’s warranty does not cover user abuse or improper installations.

Do not apply pressure or throw objects at your HDTV. This may compromise the integrity

HDTV Accessories and Services

Additional certified accessories for your HDTV are sold separately, including:

• Wall mounts

• High Definition cables

• Extra or replacement remote controls

• Sound Bars

• Blu-ray DVD Players

VIZIO also offers installation services and extended warranty services for your HDTV.

To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our website
at www.VIZIO.com or call us toll free at 877-MYVIZIO (877-698-4946).

Version 4/21/2010 6

www.VIZIO.com

VIZIO M320VT User Manual

Chapter 1 Setting Up Your HDTV

• Read this user manual carefully before installing your HDTV.

• For the power consumption of your HDTV, please check the specification sheet for your model in

Chapter 6. When an extension cord is required, use one with the correct power rating. The cord
must be grounded and the grounding feature must not be compromised.

• Install your HDTV on a flat surface to avoid tipping.

• For proper ventilation, you must allow a 1” space between the back of your HDTV and the wall.

• Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the

service life of the electronic components.

• Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent
poor ventilation and excessive component damage.

• If you want to mount your HDTV on the wall, see below for additional information.

• Read this user manual carefully before installing your HDTV.

VIZIO offers professional installation. Contact VIZIO for more information on these services at 877­MYVIZIO (877-698-4946) or www.VIZIO.com.

Attaching the TV Stand

Note: We strongly recommend that two people perform the setup and assembly due to the weight and

size of the TV.

To unpack the TV and stand base:

1. Remove the remote control, batteries, and power cord
from the foam end caps.

2. Remove the two top foam end caps.

3. Remove the stand base under foam end cap.

4. Remove the TV from the box and lay it
face down on a clean, flat surface.

Note: Make sure that the surface is free of
debris to prevent the TV screen from getting
scratched.

To attach the TV stand
base:

1. Line up the stand
neck (attached to the
TV) with the stand
base.

2. Push the stand base onto the stand
neck.

3. On the bottom of the base, insert the
included (Qty. 4) thumbscrews and
tighten it.

4. Move the TV into an upright position.

Caution: Do not apply pressure to the screen or throw objects at your HDTV. This may compromise the

integrity of the display. The manufacturer’s warranty does not cover user abuse or improper installations.

Version 4/21/2010 7

www.VIZIO.com

VIZIO M320VT User Manual

Wall Mounting Your HDTV

Your HDTV can be mounted on the wall for viewing. If you choose to mount your HDTV on the wall, follow
the instructions below.

1. Write down the serial number located on the back of your HDTV in the space provided on page 1 to
have it handy if you need to call for support.

2. Remove the stand base and neck:

a. Disconnect the cables from your

HDTV.

b. Place your HDTV face down on a

soft, flat surface to prevent damage
to the screen.

c. Remove the TV stand base per

above instructions.

3. Mount your HDTV on the wall:

a. Attach your HDTV to a wall mount

(sold separately) using the mounting
holes in the back panel of your HDTV (see illustration at the right).

b. Read the instructions that came with your specific wall mount to properly hang your HDTV.

M320VT Wall Mounting Specifications

Screw Size

Screw Length

Screw Pitch

Hole Pattern

• M4

• 10 mm

• 0.7 mm

• VESA standard 200mm x 100mm

NOTE: If using wall mounts different from our certified ones, please verify that they are
UL/CSA/ETL listed wall mount brackets with suitable weight specs.

Version 4/21/2010 8

www.VIZIO.com

VIZIO M320VT User Manual

Preparing your LCD HDTV for Wall Mounting

Your VIZIO HDTV can either be kept on the stand base or mounted on the wall for viewing. If you choose
to mount the TV on the wall, please follow the instructions below for removing the stand.

To remove the base stand:

5. Unplug all cables from the HDTV.

6. Place your HDTV face down on a soft and flat

surface (blanket, foam, cloth, etc) to prevent
any damage to the TV.

7. Remove the total of eight (4) screws holding

the base stand to the TV.

8. Carefully remove the stand, pulling the base

towards you.

The TV can fit securely to a mount (sold separately) by utilizing the mounting holes in the center of the
back panel of the TV. Please make sure to read the instructions of your specific mount to properly hang
your TV.
The pitch of the mounting holes is 200mm horizontally and 100mm vertically.
The screw type required is metric M4, 0.7mm pitch. The length of the screws will depend on the thickness
plate being attached to the TV.

To find the perfect mount for your HDTV, browse VIZIO’s certified mount selection at www.VIZIO.com
call directly 888-VIZIOCE (888-849-4623).

or

Version 4/21/2010 9

www.VIZIO.com

VIZIO M320VT User Manual

Chapter 2 Basic Controls and Connections

Front Panel

POWER ‘VIZIO’ LIGHT– The VIZIO name lights

white when powered on and it will get dimmer
when powered off.

REMOTE CONTROL SENSOR and LIGHT
SENSOR – This is the window through which all

of the remote control signals pass to the sensor.
Point the remote control directly at this window
for the best response to the remote signal.

The light sensor allows controlling the
adjustment of the backlight intensity
automatically by sensing the ambient lighting, this is a feature selectable through the OSD menu.

Side Panel Controls

( ) – Press this button once to
power your TV on. Press the button
again to power the TV off.

MENU – This button activates the
On Screen Display (OSD). If a sub­menu is active, pressing this button
confirms the selection to be adjusted
or takes the user to the next level of
the menu.

ST – Use these buttons to

CH

step up or down the TV channels.
While the OSD is active, these
buttons function as up and down
controls in the OSD menus.

WX – Use these buttons to

VOL

increase or decrease to the speaker
volume. While the OSD is active,
these buttons function as left and
right controls in the OSD menus.

INPUT (LAST) – Repeated pressing of this button steps through the input sources
in the following sequence: DTV/TV, AV, COMPONENT, HDMI1, HDMI2, HDMI3, HDMI4, RGB, PHOTO
and MUSIC. Once you have stepped through the entire sequence, you will return to the beginning of the
sequence.

Additionally, when the OSD is active, this button allows returning to previous menu level. When the OSD

is not active, this button will show the current input selections.

Note: When using the A/V input (usually, a composite signal) the video signal (yellow color coded cable)
need to be connected to the green jack connector. Expect to see a black/white display if COMPONENT
input is selected by accident.

Version 4/21/2010 10

www.VIZIO.com

VIZIO M320VT User Manual

Rear and Side Panel Connections

Version 4/21/2010 11

www.VIZIO.com

VIZIO M320VT User Manual

No. Connection Description

1 SPDIF

2

DTV/TV

(Cable/Antenna)

COMPONENT

3

(YPb/CbPr/Cr

with Audio L/R)

4

RGB PC /PC

Audio

5 USB

6 HDMI

Connect an SPDIF Optical cable from your HDTV to your home
theater system to play digital audio through your home speakers.

Connect to an antenna or digital cable for digital TV. For digital TV
stations in your area visit www.antennaweb.org

Connect your primary source component (like a DVD Player or set
top box) here. From left to right, use green for Y, blue for Pb (or
Cb), and red for Pr (or Cr) inputs. Use white for left audio and red
for right audio.

When using the A/V input (usually, a composite

.

signal) the video signal (yellow color coded cable) need to be
connected to the green jack connector.

Connect the video from a computer here. Connect the audio (1/8
in. mini plug stereo connector) from a computer here.

Connect a storage source (format FAT32) JPEG files (like a hard
drive or thumb drive or card reader). It is recommended to back up
your important document files as a precaution to prevent lost of
data. This input is also used as a factory service connection

for authorized personal, unauthorized usage of this
connection to attend service of this equipment will void the
manufacturer’s warranty of the TV.

Best connection in the field to transmit digital Audio and Video
content. Connect an audio/video source for digital video such as a
DVD multimedia player, a digital set-top box for cable or satellite
receiver system. Your TV comes with four HDMI inputs.

NOTE: When using the A/V input (usually, a composite signal) the video signal (yellow color coded
cable) need to be connected to the green jack connector. Expect to see a black/white video in the
Component input, if it is selected by accident.

Certified HDMI and HDMI-DVI cables are available for purchase from www.VIZIO.com

or by calling 888-

VIZIOCE (888-849-4623)

Version 4/21/2010 12

www.VIZIO.com

VIZIO M320VT User Manual

Remote Control Buttons

SET — Use to program a different device (DVD, AUDIO SYSTEM, TV and CABLE/SATELLITE BOX) to

be controlled by this control.

POWER (

) — Press to turn the TV on from the Standby mode. Press it again to return to the Standby

mode.
DVD, AUDIO, TV and CABLE — Press the button of the equipment you would like to control using this

remote control. Make sure that the remote has been set up the code
to the specific device.

RECORD, PAUSE, PLAY and STOP —
Only PAUSE (pause the slideshow), PLAY (start the slideshow) and
STOP (stop the slideshow) are active buttons for your HDTV. The
RECORD button does not operate your TV.

SKIP BACK, BACKWARDS, FAST

FORWARD and SKIP FORWARD — These buttons do not operate

your TV, they are function keys used by other devices, mainly DVD
and DVR devices. Skip Back allows jumping to previous chapter in
DVD and DVR. Backwards (Rewind in the old VCRs) allows
reviewing previous scenes. Fast Forward allows to reviewing the
next scenes. Skip Forward allows jumping to next chapter in DVD
and DVR.

HDMI — Press to select the HDMI input. Press repeatedly to cycle
through the HDMI inputs.

COMP — Press to select the Component input.
AV — Press to select the AV or Composite input.
DTV/TV — Press to select the TV or RF input.

Color-Coded Programmable Keys — These
buttons are keys which could be customized with most used
commands, they usually perform cable, satellite and teletext
functions.

LIST — This button is most commonly used by cable and satellite
boxes to display the list of your recorded programs. This key allows
opening the channels list OSD of your HDTV.

INPUT — Press to cycle through the various devices connected to
your TV (called Inputs). The inputs cycle in the following sequence:
DTV/TV, AV COMPONENT, HDMI 1, HDMI 2, HDMI 3, HDMI 4, RGB,
PHOTO and MUSIC. Once you have stepped through the entire
sequence, you will return to the beginning.

EXIT— Press to exit from open menus.
MENU — Press it to bring up the OSD menu on your HDTV.

Up (▲), Down (▼), Left (◄) or Right (►)
navigation buttons — Press to navigate open

menus, adjust other TV settings such as Brightness and Contrast, or turn menu
options On and Off.

OK — When the OSD menu is up, pressing this key select the highlighted option in
the menu.

Version 4/21/2010 13

www.VIZIO.com

VIZIO M320VT User Manual

BACK — When use with the TV, this button behaves in the same way as the LAST button. It is used as a
functional key on the set-top box for cable and satellite services with DVR features. It allows skipping
back to previous prerecorded programs.

GUIDE — This button does not function with your TV, follow the INFO
description to see programming information.

VOL ▲/▼— Press it to either increase or decrease the volume level of the
sound.

MEDIA — Use to select viewing of pictures on a USB device connected to
the USB port.

LAST — Press to recall the previously viewed channel. When the Menu is
active, press this button repeatedly to go to the previous level or out of the
On Screen Menu completely.

— Press to turn the sound on and off.

CH ▲/▼— Press to change the channels up or down.
Number Button Pad — Press to select a channel or enter a password.
INFO — Press to display program and channel information. Pressing this

button twice will allow reading the description of the current and next hour
programming.

(DASH) — Press to insert a dash between the main and sub-channels. For example, channel 28-

2 would be selected by the button sequence 2, 8, DASH, 2.

Programming the Remote Control

The included remote control can be programmed to control different devices: DVD players, Audio Players,
TV and Set-Top Boxes. Please, refer to the tables at the end of this User’s manual for the different codes
to match the different manufacturers including the codes for VIZIO preferred accessories and equipment
systems. The following procedure is required to do the programming:

1. Find the matching code and write it down, some makers may have more than one code. It may
require trying all of them to find the one matching your specific model.

2. Press and release the key matching your equipment: DVD, AUDIO, TV or CABLE.

3. Press and hold down the SET key until the light indicator blinks twice.

4. Release the SET key, and press the 5-digits code you had written down on Step 1.

5. The light indicator should blink twice again after you had entered the last digit, it means that the
remote control has accepted the code. At this point, you should try to use the power button to turn
off and on the equipment.

6. Try different keys to confirm that your accessory or equipment responds properly. If it is not the
case and other codes are applicable, please try Steps 1 through 5 to the next code until the
correct code is found.

Searching Automatically for the Codes

If the device does not respond to the remote control after trying all listed codes for the brand, or if the
brand is not listed, then try searching for code as follows:

1. Turn on the device.

2. Press and hold the device key for 3 seconds. LED indicator comes ON. Release key.

3. Press and release PLAY key, the indicator goes OFF during pressing and comes ON after
release.

4. Aim the remote control at the device. Press either the channel up or channel down key to start
searching. If the device turns off a working code has been found. Press OK key to save this code
and exit the code search. The LED indicator flashes slowly 4 times and it goes OFF.

Version 4/21/2010 14

www.VIZIO.com

VIZIO M320VT User Manual

Remote Control Range

• The effective range of the remote control is approximately 26 feet (8 meters) from the front of the
receiver window and 13 feet (4 meters) at 45° to the left and right.

• Point the remote control at the remote control sensor on the front of your HDTV to send
commands.

• Do not place any obstacles between the remote control and the remote control sensor.

VIZIO Remote Control Precautions

• Keep the remote dry and away from heat sources and humidity.

• If your HDTV responds erratically to the remote control or does not respond at all, check the

batteries. If the batteries are low or exhausted, replace them with fresh batteries.

• When not using the remote control for a long period of time, remove the batteries.

• Do not take the batteries apart, heat them, or throw them into a fire.

• Do not subject the remote control to undue physical stress, such as striking or dropping it.

• Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp

cloth.

• Do not mix old and new batteries or different types of batteries.

Inserting the remote control batteries

1. Remove the battery cover on the back of the remote control.

2. Insert two AA batteries (included) into the remote control, making sure you match the (+) and (-)
symbols on the batteries with the (+) and (-) symbols inside the battery compartment.

3. Re-attach the battery compartment cover.

Precautionary Tips for Inserting the Batteries:

• Only use the specified AA batteries.

• Do not mix new and old batteries. This may result in cracking or leakage that may pose a fire

risk or lead to personal injury.

• Inserting the batteries incorrectly may also result in cracking or leakage that may pose a fire

risk or lead to personal injury.

• Dispose of the batteries in accordance with local laws and regulations.

• Keep the batteries away from children and pets.

Using a Cable or Satellite Remote

Your VIZIO remote uses codes 11758 and 10178 to work your LCD HDTV. To use a cable or satellite remote
to work the LCD HDTV, refer to your cable or satellite remote user guide for more information on how to
program the remote. If your cable or satellite remote uses a 5-digit code (like most Direct TV units), first try
11758 and then, if that does not work, 10178. If your cable or satellite remote uses a 4-digit code, try 1758 and
then 0178 as an alternative. If your cable or satellite remote uses a 3-digit code (EchoStar or Dish Network for
example), use code 627.

Cleaning the Housing and Remote Control

1. Use a soft cloth for cleaning.

2. If the housing or remote control is seriously contaminated, use a soft cloth moistened with

diluted neutral cleaner to clean the display. Wring water out of the cloth before cleaning to
prevent water from penetrating into the housing. Wipe the display with a dry cloth after
cleaning.

Version 4/21/2010 15

www.VIZIO.com

VIZIO M320VT User Manual

Chapter 3 Connecting Equipment

Your HDTV has six different ways to connect your video equipment from a basic connection to the most
advanced for digital signals.

Connection

Quality

(type)

Best

(digital)

Connector Description

HDMI (High-Definition Multimedia Interface). It is the first and

only industry-supported, uncompressed, all-digital audio/video
interface. HDMI provides an interface between any audio/video
source, such as a set-top box, DVD player, or A/V receiver and
an audio and/or video monitor, such as a digital television
(DTV), over a single cable.

Best

(digital)

- - - - - - - - -
Good

(analog)

Best

(analog)

Better

(analog)

Good

(analog)

Best

(digital)

DTV Coaxial RF. When used for MPEG2 encoded bit streams
from ATSC broadcast programming, this input takes advantage
of the High Definition content.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

TV Coaxial RF. This is the connection for standard NTSC TV
using antenna or cable.

RGB PC (VGA). This video input has separate red, green and
blue color components. The signal carries horizontal and
vertical sync information on the green signal. This is most
commonly used for PC input.

Component. The video signal is separated into three signals,
one containing the black-and-white information and the other
two containing the color information. This enhancement over S­Video takes advantage of the superior picture provided by
progressive scan DVD players and HDTV formats.

Composite. The complete video signal is carried through this
single pin connector. This is the most commonly used video
connection.

USB (Universal Serial Bus). USB is an interface port designed
to connect storage devices holding data (FAT32 format: JPEG
for image) files without a need to power off the host (TV) unit.

Note: You can use your HDTV Component input to accept A/V signal (Composite) from a source

with A/V out, please plug your video signal (yellow connector) into the Component input (green
connector) and match up the audio connectors (R and L) for the sound. Expect to see a
black/white video in the Component input, if selected by accident.

Version 4/21/2010 16

www.VIZIO.com

VIZIO M320VT User Manual

Connecting Your Cable or Satellite Box

Using HDMI

Cable and Satellite Boxes that have a HDMI digital interface should be connected to the HDMI input of
the LCD HDTV for optimal results.

Note: To maintain the display quality, use a VIZIO certified HDMI cable. Lengths are available up to 10

Meters. See www.vizio.com

Connecting your Cable or Satellite Box (Best)

1. Turn off the power to the LCD HDTV and HDTV Set-Top Box.

2. Connect a HDMI cable to the HDMI output of your HDTV
Set-Top Box and the other end to the HDMI Input at the
side of the LCD HDTV.

3. Turn on the power to the LCD HDTV and HDTV Set­Top Box.

4. Select HDMI using the INPUT button on
the remote or side of the LCD HDTV, or
directly by pressing the HDMI button on
the Remote Control.

Note:

• The HDMI input on the LCD TV supports High-bandwidth Digital Content

Protection (HDCP). HDCP encrypts the transmission between the video
source and the digital display for added security and protection.

• If you are already using the HDMI1 input for another component, or you do not want to use the

HDMI1 input for the Set-Top Box, you can connect the Set-Top Box to the HDMI2, HDMI3 or
HDMI4 input.

• Refer to your HDTV Set-Top Box user manual for more information about the video output

requirements of the product or consult your cable or satellite operator.

or call 1-888-VIZIOCE (1-888-849-4623) for details.

Version 4/21/2010 17

www.VIZIO.com

VIZIO M320VT User Manual

For Cable or Satellite Boxes with DVI:

1. Turn off the power to the LCD HDTV and HDTV
Set-Top Box.

2. Using a HDMI-DVI cable, connect the DVI end to
your HDTV Set-Top Box and the HDMI end to the
HDMI2 Input at the side of the LCD HDTV.

3. Using an audio cable (1/8’ stereo connector on the
going into the TV), connect the cable to the
audio output connectors associated with the
DVI output on your HDTV Set-Top Box and
connect the other end to the audio
associated with the RGB input at
the side of the LCD HDTV.

4. Turn on the power to the LCD
HDTV and HDTV Set-Top Box.

5. Select HDMI2 using the INPUT button on the remote or side of the
LCD HDTV, or directly by pressing the HDMI button on the Remote Control.

Note:

• The HDMI input on the LCD TV supports High-bandwidth Digital Content Protection (HDCP).

HDCP encrypts the transmission between the video source and the digital display for added
security and protection.

• If you are already using the HDMI2 input for another component, or you do not want to use the

HDMI2 input for the Set-Top Box, you can connect the Set-Top Box to the HDMI1, HDMI3 or
HDMI4 connection. The LCD TV will recognize the DVI connection and obtain audio information
from the audio connectors on the rear of the TV.

• Refer to your HDTV Set-Top Box user manual for more information about the video output

requirements of the product or consult your cable or satellite operator.

Version 4/21/2010 18

www.VIZIO.com

VIZIO M320VT User Manual

Using Component Video

Connecting your Cable or Satellite Box (Better)

1. Turn off the power to the LCD HDTV and HDTV Set-Top Box.

2. Connect the Y (green color) connector on your HDTV Set-Top Box to the corresponding Y
(green color) connector in the Component input at the rear of the LCD HDTV.

3. Connect the PbCb (blue color) connector on your HDTV Set-Top Box to the corresponding
Pb (blue color) connector in the Component input at the rear of the LCD HDTV.

4. Connect the PrCr (red color) connector on your HDTV Set-Top Box to the corresponding Pr
Cr (red color) connector in the Component input at the rear of the LCD HDTV.

5. Using an audio cable (white and red connectors), connect the cable to the audio output
connectors associated with the Component output on your HDTV Set-Top Box and connect
the other end to the audio connectors associated with the Component input at the rear of the
LCD HDTV.

6. Turn on the power to the LCD HDTV and HDTV Set-Top Box.

7. Select Component using the INPUT button on the remote or side of the LCD HDTV, or
directly by pressing the COMP button on the Remote Control.

Note:

• Refer to your HDTV Set-Top Box user manual for more information about the video output

requirements of the product or consult your cable or satellite operator.

Version 4/21/2010 19

www.VIZIO.com

VIZIO M320VT User Manual

Connecting Coaxial (RF)

Using Your Antenna or Digital Cable for DTV

1. Turn off the power to the LCD HDTV.

2. Connect the coaxial (RF) connector from your antenna or digital
cable to the DTV/TV CABLE/ANTENNA connector at the rear
of the LCD HDTV.

3. Turn on the power to the LCD HDTV.

4. Select TV using the INPUT button on the remote
or side of the LCD HDTV, or directly by pressing
the TV button on the Remote Control.

Note:

• Not all digital TV broadcasts are High Definition (HD). Refer to the program guides, or consult

your cable, satellite or TV station operator.

• Digital broadcasts are not available in all areas. Refer to www.antennaweb.org

information.

• Make sure the antenna and coaxial cable are correctly grounded.

for detailed

Using Your Antenna or Cable for TV

1. Turn off the power to the LCD HDTV.

2. Connect the coaxial (RF) connector from your
antenna or cable to the DTV/TV
CABLE/ANTENNA connector at the rear of the
LCD HDTV

3. Turn on the power to the LCD HDTV.

4. Select TV using the INPUT button on the remote or side of the LCD
HDTV, or directly by pressing the TV button on the Remote Control.

Using the Antenna or Cable through your VCR

1. Turn off the power to the LCD HDTV and VCR.

2. Connect the “Output to TV”, “RF Out” or “Antenna Out”
connector on the rear of your VCR to the DTV/TV
CABLE/ANTENNA connector at the rear of the LCD HDTV.

3. Turn on the power to the LCD HDTV and VCR.

4. Select TV using the INPUT button on the remote or
side of the LCD HDTV, or directly by pressing
the TV button on the Remote Control.

Note: If you have an off-air antenna or cable TV, connect it to the “Antenna In” connector on the rear of

your VCR.

Version 4/21/2010 20

www.VIZIO.com

VIZIO M320VT User Manual

Connecting Your DVD Player

You have several options for connecting your DVD player to your HDTV: HDMI, Component and
Composite inputs. Based on your home theater configuration, you can decide which option is the right
one for you.

Using HDMI

DVD players that have a digital interface such as HDMI (High Definition Multimedia Interface) should be
connected to the HDMI input of you HDTV for optimal results.

Note: To maintain the display quality, use a VIZIO certified HDMI cable. Length is available up to 10

meters. See www.VIZIO.com

or call 1-888-VIZIOCE (1-888-849-4623) for details.

Connecting your DVD Player (Best):

1. Turn off the power to the LCD HDTV and DVD player.

2. Connect a HDMI cable to the HDMI output of your DVD player and the other
end to the HDMI Input at the side of the LCD HDTV.

3. Turn on the power to the LCD HDTV and your DVD player.

4. Select HDMI using the INPUT button on the remote or side of the
LCD HDTV, or directly by pressing the HDMI button on the
Remote Control.

Note:

• If you are already using the HDMI1 input for another component, or you do not want to use the

HDMI1 input for the DVD player, you can connect the DVD player to the HDMI2, HDMI3 or
HDMI4 connection.

• Refer to your DVD player user manual for more information about the video output requirements

of the product.

Version 4/21/2010 21

www.VIZIO.com

VIZIO M320VT User Manual

For DVD Players with DVI:

1. Turn off the power to the LCD HDTV and DVD player.

2. Using a HDMI-DVI cable, connect the DVI end to your DVD
player and the HDMI end to the HDMI Input at the side of the

LCD HDTV.

3. Using an audio cable (1/8’ stereo connector on the
going into the TV), connect the cable to the audio
output connectors associated with the DVI output
on your HDTV Set-Top Box and connect the
other end to the audio associated with
the RGB input at the side of the LCD
HDTV.

4. Turn on the power to the LCD HDTV
and your DVD player.

5. Select HDMI1 using the INPUT button on the remote or side of the
LCD HDTV, or directly by pressing the HDMI button on the Remote
Control.

Note:

• If you are already using the HDMI1 input for another component, or you do not want to use the

HDMI input for the DVD Player, you can connect the DVD player to the HDMI2, HDMI3 or HDMI4
input. The LCD TV will recognize the DVI connection and obtain audio information from the audio
connectors on the rear of the TV.

• Refer to your DVD player user manual for more information about the video output requirements

of the product.

Version 4/21/2010 22

www.VIZIO.com

VIZIO M320VT User Manual

Using Component Video

Connecting your DVD Player (Better):

1. Turn off the power to the LCD HDTV and DVD player.

2. Connect the Y (green color) connector on your
DVD player to the corresponding Y (green
color) connector in the Component input at the
rear of the LCD HDTV.

3. Connect the PbCb (blue color) connector on

your DVD player to the corresponding PbCb (blue
color) connector in the Component input at the rear
of the LCD HDTV.

4. Connect the PrCr (red color) connector on your
DVD player to the corresponding PrCr (red

color) connector in the Component input at the
rear of the LCD HDTV.

5. Using an audio cable (white and red
connectors), connect the cable to the audio output connectors associated with the
Component output on your DVD player and connect the other end to the audio connectors
associated with the Component input at the rear of the LCD HDTV.

6. Turn on the power to the LCD HDTV and DVD player.

7. Select Component using the INPUT button on the remote or side of the LCD HDTV, or
directly by pressing the COMP button on the Remote Control.

Note:

• Refer to your DVD player user manual for more information about the video output requirements

of the product.

Version 4/21/2010 23

www.VIZIO.com

VIZIO M320VT User Manual

Using Composite (AV) Video

Connecting your DVD Player (Good):

1. Turn off the power to the LCD HDTV and DVD
player.

2. Connect the Video (yellow color) connector on your
DVD player to the Video Y (green color) connector in
the Component input of connectors at the rear of the

LCD HDTV.

3. Connect the R (red color) and L (white color) audio
connectors on your DVD player to the corresponding R
(red color) and L (white color) audio input connectors in
the Component input at the rear of the LCD HDTV.

4. Turn on the power to the LCD HDTV and DVD Player.

5. Select AV using the INPUT button on the
remote or side of the LCD HDTV, or directly by
pressing the AV button on the Remote
Control.

Notes:

1. Refer to your DVD player user manual for more information about the video output
requirements of the product.

2. Expect to see a black/white video in the Component input, if it is selected by accident.

Connecting a USB (FAT32 Format) Storage Device

1. Connect a thumb drive, directly inserting it into the USB connection or by using an extension (if

thumb drive housing is too big to have it fit in place) cable. Connecting a portable hard drive or
card reader to this input is also possible

2. If your HDTV has been turned off, please turn it on.

3. The TV will start reading the contents in the

USB device automatically to make sure of
compatibility of files (JPEG and MP3 format).

4. Please follow the instructions in the Multimedia

section to either see the pictures (picture by
picture or as a slideshow).

Note: This input is also used as factory service port. Please back up important files to prevent lost

of data. Format your device to FAT32 and load your picturefiles, and enjoy your viewing. A high
speed FAT32 storage device is also needed; preferable, new and memory emptied device for a
better performance at least a 1Gb of memory device must be used.

Version 4/21/2010 24

www.VIZIO.com

VIZIO M320VT User Manual

Connecting an external Receiver/Amp

If your sound system has a SPDIF (optical) digital audio input you can connect it to the optical SPDIF
OUT at the rear of the TV. This is active when receiving audio with the programs being viewed no matter
what input is being used.

1. Turn off the power to the HDTV and Receiver/Amp.

2. Using an audio cable (optical cable), connect the cable to
the audio input connectors on the Receiver/Amp and
connect the other end to the SPDIF OUT audio optical
connector at the rear of the LCD HDTV.

3. Turn on the power to the HDTV and Receiver/Amp.

4. Then press the MENU button on the remote control to
bring up the On-Screen Display (OSD) menu.

5. Press any navigation arrow button on the remote control
to select the Audio menu.

6. Press OK on the remote control to enter the Audio sub-
menu. Press any navigation arrow button and select
SPEAKERS.

7. Press OK key to select Off so that the sound from the TV
will now be routed through your Receiver/Amp system.

8. Press EXIT key to exit the menu display.

Note:

• Refer to your Receiver/Amp user manual to select the corresponding audio input.

• The audio output is not amplified and cannot be connected directly to external speakers.

Version 4/21/2010 25

www.VIZIO.com

VIZIO M320VT User Manual

Connecting a PC (Computer)

1. Turn off the power to the LCD HDTV and PC Computer.

2. Connect a 15-pin D-Sub RGB (VGA) cable to the RGB output of your pc computer and the
other end to the RGB PC input at the rear of the LCD HDTV.

3. Using a 1/8” stereo cable, connect the Audio Out on your personal computer to the RGB PC
Audio input at the rear of the LCD HDTV.

4. Turn on the power to the LCD HDTV and Computer.

5. Select RGB using the INPUT button on the remote or side of the LCD HDTV.

Note:

• For a better picture quality when connecting a computer through RGB PC, set your personal

computer timing mode to VESA 1920x1080 at 60Hz.

• Refer to your pc computer user manual for more information about the video output requirements

of the product.

• A RGB (VGA) cable and stereo mini jack cable are not included and can be purchased at an

electronics store.

Version 4/21/2010 26

www.VIZIO.com
