VIZIO
USER MANUAL
Model D40f-E1
Safet erticatio
THANK YOU FOR CHOOSING VIZIO
And congratulations on your new VIZIO TV.
To get the most out of your new VIZIO product, read these instructions
before using your product and retain them for future reference. Be sure to
inspect the package contents to ensure there are no missing or damaged
parts.
PRODUCT REGISTRATION
To purchase or inquire about accessories and installation services for your
VIZIO product, visit our website at www.VIZIO.com or call toll free at (877)
698-4946.
We recommend that you register your VIZIO product at
www.VIZIO.com
Extended Warranties
For peace of mind, and to protect your investment beyond the standard
warranty, VIZIO oers on-site extended warranty service plans. These
plans provide additional coverage during the standard warranty period.
To purchase an extended warranty service plan, visit www.VIZIO.com.
WHEN READING THIS MANUAL
When you see this symbol, please read the
accompanying important warning or notice. It is
intended to alert you to the presence of important
operating instructions.
IMPORTANT SAFETY INSTRUCTIONS
our TV is designed and manufactured to operate within dened design
limits. Misuse may result in electric shock or re. To prevent your TV from
being damaged, the following instructions should be observed for the
installation, use, and maintenance of your TV. Read the following safety
instructions before operating your TV. Keep these instructions in a safe
place for future reference.
• To reduce the risk of electric shock or component damage, switch
o the power before connecting other components to your TV.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus including ampliers that
produce heat.
• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not t into
your outlet, consult an electrician for replacement of the obsolete
outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachmentsaccessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused
for long periods of time.
• efer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as the power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally,
or has been dropped.
• Unplug the power cord before cleaning your TV.
• When moving your TV from an area of low temperature to an
area of high temperature, condensation may form in the housing.
ait before turning on your TV to avoid causing re, electric
shock, or component damage.
• A distance of at least three feet should be maintained between
your TV and any heat source, such as a radiator, heater, oven,
amplier etc. Do not install your TV close to smoke. Operating
your TV close to smoke or moisture may cause re or electric
shock.
• Slots and openings in the back and bottom of the cabinet are
provided for ventilation. To ensure reliable operation of your TV
and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your TV in a bookcase or
cabinet unless proper ventilation is provided.
• Never push any object into the slots and openings on your TV
cabinet. Do not place any objects on the top of your TV. Doing
so could short circuit parts causing a re or electric shock. ever
spill liquids on your TV.
• Your TV should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power
supplied to your home, consult your dealer or local power
company.
When you see this symbol, please read the
accompanying helpful tip.
ii
• Do not apply pressure or throw objects at your TV. This may
compromise the integrity of the TV. The manufacturer’s warranty
does not cover user abuse or improper installations.
• The power cord must be replaced when using dierent voltage
than the voltage specied. or more information, contact your
dealer.
• hen connected to a power outlet, power is always owing into
your TV. To totally disconnect power, unplug the power cord.
• The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of
un-isolated, dangerous voltage within the inside of your TV that
may be of sucient magnitude to constitute a risk of electric
shock to persons.
• Do not overload power strips and extension cords. Overloading
can result in re or electric shock.
• The wall socket should be installed near your TV and easily
accessible.
• Only power of the marked voltage can be used for your TV. Any
other voltage than the specied voltage may cause re or electric
shock.
• Do not touch the power cord during lightning. To avoid electric
shock, avoid handling the power cord during electrical storms.
• Unplug your TV during a lightning storm or when it will not be
used for long period of time. This will protect your TV from
damage due to power surges.
• Do not attempt to repair or service your TV yourself. Opening
or removing the back cover may expose you to high voltages,
electric shock, and other hazards. If repair is required, contact
your dealer and refer all servicing to qualied service personnel.
• WARNING: eep your TV away from moisture. Do not expose your
TV to rain or moisture. If water penetrates into your TV, unplug the
power cord and contact your dealer. Continuous use in this case may
result in re or electric shock.
• Do not use your TV if any abnormality occurs. If any smoke or
odor becomes apparent, unplug the power cord and contact your
dealer immediately. Do not try to repair your TV yourself.
• Avoid using dropped or damaged appliances. If your TV is
dropped and the housing is damaged, the internal components
may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your TV may
cause re or electric shock.
• Do not install your TV in an area with heavy dust or high
humidity. Operating your TV in environments with heavy dust or
high humidity may cause re or electric shock.
• Follow instructions for moving your TV. Ensure that the power
cord and any other cables are unplugged before moving your TV.
• When unplugging your TV, hold the AC/DC power adapter, not the
cord. Pulling on the power cord may damage the wires inside the
cord and cause re or electric shock. hen your TV will not be
used for an extended period of time, unplug the power cord.
• To reduce risk of electric shock, do not touch the connector with
wet hands.
• Insert batteries in accordance with instructions. Incorrect
polarities may cause the batteries to leak which can damage the
remote control or inure the operator. Do not expose batteries to
excessive heat such as sunshine, re or the like.
• If any of the following occurs, contact the dealer:
- The power cord fails or frays.
- Liquid sprays or any object drops into your TV.
- our TV is exposed to rain or other moisture.
- Your TV is dropped or damaged in any way.
- The performance of your TV changes substantially.
• This apparatus shall not be exposed to dripping or splashing and
no obects lled with liquids, such as vases, shall be placed on the
apparatus.
• The mains plug or appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
• CAUTION - These servicing instructions are for use by qualied
service personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the operating
instructions unless you are qualied to do so.
• The lightning ash with arrowhead symbol within an equilateral
h
triangle is intended to alert the user to the presence of
uninsulated DAOS VOTA within the products
enclosure that may be of sucient magnitude to constitute a risk
of electrical shock to persons.
• WARNING: xposure to loud sounds can damage your hearing
causing hearing loss and tinnitus ringing or buing in the ears.
with continued exposure to loud noises, ears may become
accustomed to the sound level, which may result in permanent
damage to hearing without any noticeable discomfort.
• Install the TV where it cannot be pulled, pushed or knocked over.
• Do not allow children to hang onto the product.
• Store the accessories remote, batteries, etc. in a location safely
out of the reach of children.
• The American Academy of Pediatrics discourages television
viewing for children younger than two years of age.
• WARNING: Never place a television set in an unstable location. A
television set may fall, causing serious personal injury or death.
Many injuries, particularly to children, can be avoided by taking
simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of
the television set.
• Only using furniture that can safely support the television set
• Ensuring the television set is not overhanging the edge of the
supporting furniture.
• ot placing the television set on tall furniture for example,
cupboards or bookcases) without anchoring both the furniture
and the television set to a suitable support.
• Not placing the television set on cloth or other materials that
may be located between the television set and the supporting
furniture.
• Educating children about the dangers of climbing on furniture to
reach the television set or its controls.
• If your existing television set is being retained and relocated, the
same considerations as above should be applied.
iii
TELEVISION ANTENNA CONNECTION
PROTECTION
If an outside antenna/satellite dish or cable system is to be
connected to the TV, make sure that the antenna or cable system
is electrically grounded to provide some protection against voltage
surges and static charges.
Article of the ational lectrical ode, ASISA , provides
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of the grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during a lightning storm or when it
is left unattended or unused for long periods of time, unplug the TV
from the wall outlet and disconnect the antenna or cable system.
Power Lines
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
Section -
Do not locate the antenna near overhead light or power circuits, or
where it could fall into such power lines or circuits. Remember, the
screen of the coaxial cable is intended to be connected to earth in
the building installation.
lectric Service quipment
Grounding Conductors
Section -
Ground Clamps
ower Service rounding lectrode System
AT , part H
iv
or DTS patents, see httppatents.dts.com.
Manufactured under license from DTS icensing imited.
DTS, the Symbol, DTS and the Symbol together are
registered trademarks, and DTS Studio Sound is a
trademark of DTS, Inc. DTS, Inc. All ights eserved.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are
trademarks of Dolby Laboratories.
or DTS patents, see httppatents.dts.com.
Manufactured under license from DTS icensing imited.
DTS, the Symbol, DTS and the Symbol together are
registered trademarks, and DTS TruVolume is a trademark
of DTS, Inc. DTS, Inc. All ights eserved.
This product qualies for STA in the factory de-
fault” settings ans this is the setting in which power savings
will be achieved. Changing the factory default picture settings or enabling other features will increase power con-
sumption that could exceed the limits necessary to qualify
for STA rating. or more information on the -
STA program, refer to energystar.gov.
HDMI, the HDMI logo and High-Denition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
v
Table Of Contents
Table Of Contents
Table Of Contents ........................................................vi
Getting to Know Your TV .............................................7
Remote Control Front .........................................................................10
Replacing the Batteries ...................................................................10
Completing The First-Time Setup ...............................11
Using the On-Screen Menu .........................................14
Navigating the On-Screen Menu ........................................................14
Changing the Input Source ................................................................14
Changing the Screen Aspect Ratio .....................................................15
Adjusting the Picture Settings ............................................................16
Adjusting More Picture Settings .....................................................17
Adjusting the Color Temperature ...................................................17
Adjusting the Picture Mode Edit Settings ......................................18
Saving a Custom Picture Mode .......................................................18
Locking/Unlocking a Custom Picture Mode ...................................18
Deleting a Custom Picture Mode ....................................................19
Resetting a Picture Mode ................................................................19
Adjusting the Color Tuner Settings ................................................20
Adjusting the Audio Settings ..............................................................22
Changing the Equalizer Settings .....................................................22
Deleting the Custom Audio Mode ..................................................23
Setting Timers .....................................................................................24
Setting the Timer .............................................................................24
Setting the Auto ower O eature ...............................................24
Blanking the Screen .........................................................................24
Finding MAC Addresses for Network Setup ......................................25
Setting Up Channels ...........................................................................27
Selecting a Channel Source .............................................................27
Scanning for Channels ....................................................................27
Skipping Channels ...........................................................................28
Listening to Alternate Audio ..............................................................29
Changing the Analog Audio Language ...........................................29
Setting Up Closed Captioning ............................................................30
Changing the Appearance of Digital Closed Captions ..................30
Renaming Devices on the Input Menu ..............................................32
Changing the TV Settings ...................................................................33
Viewing System Information ...........................................................33
Changing the On-Screen Menu Language .....................................33
Setting the Time and Local Settings ...............................................34
Using the Parental Controls ............................................................34
Accessing the Parental Controls Menu ..........................................34
Enabling or Disabling Program Ratings .........................................34
Locking and Unlocking Channels ....................................................34
Blocking and Unblocking Content by Rating .................................35
Changing the Parental Control PIN ................................................35
Resetting the Content Locks ...........................................................35
Changing the View Mode Settings ..................................................36
Changing the Screen Aspect Ratio .....................................................36
Adjusting the CEC Settings ..............................................................37
Turning the ower Indicator On or O ..........................................37
Using the Reset & Admin Menu .........................................................38
Restoring the TV to Factory Default Settings .................................38
Using the Info Window .......................................................................39
Using VIZIO Internet Apps Plus® (V.I.A. Plus) .............40
Using the Fullscreen V.I.A. Window ...................................................41
Fullscreen V.I.A. Plus Window Overview ...........................................42
Customizing the V.I.A. Plus Window ..................................................43
Adding an App to the My Apps Tab ................................................43
Deleting an App from the My Apps Tab .........................................43
Moving an App in My Apps .............................................................43
Using the USB Media Player ........................................45
Preparing Your USB Drive to Play USB Media ...............................45
Displaying USB Media .....................................................................45
Removing the USB Drive from the TV ............................................45
Troubleshooting & Technical Support ........................47
Specications ...............................................................51
Regulatory Information ...............................................52
Limited Warranty .........................................................53
Limited Warranty Mexico ............................................55
Legal Information.........................................................57
vi
7
Getting to Know Your TV
1
REMOTE SENSOR & POWER INDICATOR
When using the remote, aim it directly at this sensor.
The power indicator ashes on when the TV turns on, then goes out after several seconds.
To keep the power indicator on as long as the TV is on, see
Turning the ower Indicator On or O.
FRONT PANEL
7
USB - onnect a S thumb drive to play photo, music, or video.
Components - onnect a component or composite devices.
HDMI - onnect an HDMI device.
1
Note: The image shown here is for illustrative purposes only and may be subect to change.
The actual number of ports and their locations may vary, depending on the model.
HDMI - onnect an HDMI device.
RCA Audio Out- onnect an A audio device, such as sound bar.
Optical Audio Out - onnect an opticalSDI audio device, such ashome audio receiver.
Coaxial - onnect a coaxial cable from cable, satellite, or antenna.
Ethernet - Connect an Ethernet cable to modem/ router.
Power - ress to turn on the TV. ress and hold to turn the TV o.
Input - Press to access the input menu.
REAR PANEL
8
WALL-MOUNTING THE TV
To mount your TV on a wall, you will need a wall mount. onsult the
information on this page to nd the appropriate mount for your TV.
e sure the mount you choose is capable of supporting the
weight of the TV. After you have determined that you have
the correct mount for your TV, you can begin the installation.
To install your TV on a wall
1. Disconnect any cables connected to your TV.
2. lace the TV face-down on a clean, at, stable surface. e sure the
surface is clear of debris that can scratch or damage the TV.
3. emove the stands by loosening and removing the screws.
4. Attach your TV and wall mount to the wall, carefully following the
instructions that came with your mount. Use only with a UL-listed wall
mount bracket rated for the weightload of this TV.
1
Installing a Television on a wall requires
lifting. To prevent inury or damage to the
TV, ask someone to help you.
D40f-E1
Screw Sie M6
Hole attern mm V x mm H
eight wo Stand
17.20 lb
. kg
9
USING THE REMOTE
1
Replacing the Batteries
2
3
4 5
6 7
8
9
10 11
12
13
15 16
19
20 21
17 18
14
1
1. Power - Turn TV on or O.
2. Input - Change the currently displayed input.
3. A/V Controls - Control USB media player and some apps.
4. Closed Captions - Open the closed caption menu.
or video description hold key for seconds.
5. Menu - Display the on-screen menu.
6. Exit - Close the on-screen menu.
7. Info - Display the info window.
8. Arrows - avigate the on-screen menu.
9. OK / Enter - Select the highlighted option onrm channel or
passcode entered using the number pad.
10. Back - o to the previous on-screen menu.
11. Guide - Display the info window.
12. Volume Up/Down - Increase or decrease the
loudness of the audio.
1. emove the battery cover by pressing down on the arrow markings
and sliding out.
2. Insert two batteries into the remote control. Make sure that the and - symbols
on the batteries match the and - symbols inside the battery compartment.
3. eplace the battery cover.
13. V Button - Displays the multimedia menu.
14. Channel Up/Down - Change the channel.
15. Mute - Turn the audio on or o.
16. Wide - Change the display mode.
In many places batteries cannot be thrown away or discarded with household
waste. lease ensure you properly dispose of your batteries consistent with
the laws andor regulations where you live. or more information please visit
www.viio.comenvironment.
or Zoom Mode hold key for seconds.
17. PIC - Opens the picture mode menu.
or Text to Speech hold key for seconds.
18. Last - eturn to the last viewed channel.
WARNING: keep the remote control batteries away from children. It may
cause choking andor lead to a re or chemical burn if mishandled. Do not
dispose of batteries in re. eplace only with batteries of the correct type.
19. Number Pad - Manually enter a channel.
20. Enter - onrm channel or passcode entered using the number
pad.
21. Dash - Use with number pad to manually enter a digital
hen needed, VIZIO recommends replacing the batteries that came
with this remote with two, new Duracell ‘AAA’ alkaline batteries.
sub-channel. e.g. - or -
ong key press for accessibility options may be shorter than seconds.
REMOTE CONTROL
10
The first time you turn on the TV, the Setup App will guide
you through each of the steps necessary to get your TV
ready for use.
Before you begin the first-time setup:
• Your TV should be installed and the power cord
should be connected to an electrical outlet.
• Your devices should be connected.
• If you have a wireless network, have the network
password ready.
2
Select Store Demo for in-store display.
Seleccione "Home Use" para Modo de Casa o "Store Demo" para Demostración en la Tienda.
Choisissez "Home Use" pour le Mode Domicile ou "Store Demo" pour la Démo en Magasin.
Choose your mode.
Select Home Use for in-home use.
Store Demo Home Use
2Completing The First-Time Setup
4
• If you are connecting to your network with an
Ethernet cable, connect it to the Ethernet port on
the TV.
To complete the first-time setup:
1
3
Use the Arrow buttons on the remote to
highlight Home Use and press OK.
Use the Arrow buttons on the remote to highlight
your TV source and press OK.
If you have cable TV, select whether you have
a cable box or if you connect the TV directly
to a cable from the wall.
Press the Power button on the remote. The TV
powers on and the Setup App starts.
Use the Arrow buttons on the remote to highlight
your language of preference and press OK.
11
5
If the TV Signal channel scan screen appears, the
TV will need to scan for channels, which takes
several minutes.
Use the arrow buttons on the remote to highlight
Begin Scan and press OK.
2
Note: Number of ports may differ by TV.
Otherwise, use the Arrow and OK buttons on
the remote to select the input your TV source
is connected to.
hen you are nished, the message
“Setup is complete.” will appear.
The First-Time Setup is complete.
12
ACCESSIBILITY SETTINGS
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
VIZIO is committed to providing intuitive, user-friendly products.
our new VIZIO TV oers several accessibility features that can
help you get the most out of it.
2
To access the Accessibility menu:
1. Press the Menu button on the remote control.
2. Use the Arrow and OK buttons to navigate and select
System à Accessibility.
• Talk Back - Turn Text-to-Speech Talk Back On or . Text-toSpeech Talk Back enables your TV to speak all settings changes
adjustments, and status using the remote in English.
• Speech Rate* - Adjusts the rate in which Text-to-Speech is
spoken. Select Slow, Normal (Default), or Fast.
• Zoom Mode - Enlarges a section of the screen by approximately
200%.
To access the Closed Caption** menu:
• Press the Menu button on the remote control.
• Use the Arrow and OK buttons to navigate and select Closed
Captions.
To access the Video Description** menu:
• Press the Menu button on the remote control.
VIZIO
ACCESSIBILITY
Talk Back Off
Speech Rate Normal
Zoom Mode Off
• Use the Arrow and OK buttons to navigate and select
Settings à Channel Digital Audio à Spanish/ Video
Description.
* Only available when Talk Back is turned On.
**Input must be set to tuner for Closed Caption or Video Description to appear in settings menu.
13
Using the On-Screen Menu
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
3
Your TV features an easy-to-use on-screen menu.
To open the on-screen menu, press the MENU button on the
remote.
From this menu, you can:
• Adjust the Picture settings
• Adjust the Audio settings
• Setting the Timers
• Adjust the Channel settings
• Set up Closed Captioning
• Name Inputs
• Adjust TV settings
• View User Manual
VIZIO
TV SETTINGS
Audio
Timers
Network
Channels
CC
Closed Captions
Devices
System
User Manual
NAVIGATING THE ON-SCREEN MENU
To open the on-screen menu, press
the MENU button on the remote.
Use the Arrow buttons to highlight
a menu option, and press the OK
button to select that option.
While navigating the on-screen menu, you can
press the BACK button at any time to return to the
previous menu screen. The EXIT button will close the
on-screen menu.
CHANGING THE INPUT SOURCE
External devices such as DVD players, Blu-ray Players, and video
game consoles can be connected to your TV. To use one of these
devices with your TV, you must rst change the input source using
the Input menu.
To change the input source:
1. Press the INPUT button on
the remote. The Input menu is
displayed.
2. Use the Up/Down Arrow
buttons or the INPUT button on
the remote to highlight the input
you wish to view and press OK.
The selected input is displayed.
Input Name
Note: Inputs may vary by TV.
TV
HDMI-1
HDMI-2
COMP
RGB
You can change the input names that appear on the
Input menu to make your devices easy to recognize.
See
Renaming Devices on the Input Menu
for more
information.
14
CHANGING THE SCREEN ASPECT RATIO
3
The TV can display images in ve dierent modes ormal, Stretch,
Panoramic, Wide, and Zoom. Each mode displays the picture
dierently.
Some programs have black bars on the top or sides of the picture
so that the picture keeps its original shape. Examples include
wide-screen movies and older television programs.
To change the screen aspect ratio:
1. Press the WIDE button on the
remote.
2. Use the Arrow buttons to
highlight the aspect ratio you
Normal
Normal
wish to view and press OK.
• Normal preserves the content’s
Panoramic
Stretch
original aspect ratio and size.
• Panoramic stretches a 4:3 aspect
ratio picture to the left and right
Wide
Zoom
Wide
Zoom
edges of the screen. The center of
the image is not stretched, but the
Note: Aspect ratio settings may
vary by Input source.
sides of the image are extremely
stretched. If you are watching widescreen (1.85:1 or 2.35:1)
content with black bars on the top and bottom, the black
bars will still appear on the top and bottom of the display
image.
Tip: The aspect ratio cannot be changed for Ultra HD
content or for any video content on HDMI-5.
• Wide stretches a 4:3 aspect ratio picture to the edges of
the screen. Since the picture is being stretched, the display
image may appear distortedgures appear short and fat.
If the program is already formatted for widescreen viewing
(1.85:1 or 2.35:1), then black bars will appear on the top
and bottom of the display image.
• Zoom expands images evenly in all directions (33% taller
and wider with black bars to t the screen. A p
image will ll a p screen..
15
3
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
ADJUSTING THE PICTURE SETTINGS
Your TV display can be adjusted to suit your preferences and viewing
conditions.
If you’ve changes to the settings for a picture mode, an
asterisks appears after its name (see
Picture Mode
).
To adjust the picture settings:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Picture and
press OK. The PICTURE menu is displayed.
Saving a Custom
3. Use the Arrow buttons on the
remote to highlight Picture
Mode, then use the Left/Right
Arrow buttons to change the
picture mode:
• Standard mode sets the
picture settings to the
default settings.
• Calibrated mode sets the
picture settings to values
ideal for watching TV in a
brightly-lit room.
• Calibrated Dark mode sets
the picture settings to values
ideal for watching TV in a
VIZIO
Picture Mode Standard
Auto Brightness Control Medium
Backlight 85
Brightness 50
Contrast 50
Color 63
Tint 0
Sharpness 60
More Picture
Picture Mode Edit
Color Calibration
dark room.
• Vivid mode sets the picture
settings to values that
produce a brighter, more
vivid picture.
• Game mode reduces
throughput delays and
optimizes the picture settings
for displaying game console
output.
• Computer mode optimizes the picture settings for
displaying computer output.
Standard picture mode meets Energy Star® requirements. For
the best picture, switch to Calibrated mode. Note that Calibrated
mode does not meet Energy Star® requirements. Customizing
picture settings will change the energy consumption required to
operate the TV.
4. To manually change each of the picture settings, use the Up/
Down Arrow buttons on the remote to highlight that picture
setting, then use the Left/Right Arrow buttons to adjust the
setting:
-
-
-
-
-
-
+
+
+
+
+
+
• Auto Brightness Control - The auto brightness control detects
the light levels in the room and automatically adjusts the
backlight for the best picture. Select , Low, Medium, or
High.
• Backlight - Adusts the D brightness to aect the overall
brilliance of the picture. Backlight cannot be adjusted when
starting from some picture modes.
• Brightness - Adjusts the black level of the picture. When this
setting is too low, the picture may be too dark to distinguish
details. When this setting is too high, the picture may appear
faded or washed out.
• Contrast - Adjusts the white level of the picture. When this
setting is too low, the picture may appear dark. When this
setting is too high, the picture may appear faded or washed
out. If the setting is too high or too low, detail may be dicult
to distinguish in dark or bright areas of the picture.
• Color - Adjusts the intensity of the picture colors.
• Tint - Adjusts the hue of the picture. This setting is useful in
adusting the esh tones in the picture. If esh appears too
orange, reduce the level of color before adjusting tint.
• Sharpness - Adjusts the edge sharpness of picture elements.
It can be used to sharpen non-HD high denition content
however, it will not produce detail that does not otherwise
exist.
5. hen you have nished adusting the picture settings, press
the EXIT button on the remote.
16
3
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
Adjusting More Picture Settings
To adjust more picture settings:
1. From the PICTURE menu, use the
Arrow buttons to highlight More
Picture, and then press OK.
2. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press the Left/
Right Arrow buttons to change
the setting:
• Color Temperature -
See
Adjusting the Color
Temperature.
• Black Detail - Adjusts the
VIZIO
MORE PICTURE
Color Temperature Cool
Black Detail Low
Backlight Control On
Reduce Signal Noise Off
Game Low Latency Off
Picture Size & Position
Film Mode Auto
Gamma 2.1
average brightness of the
picture to compensate for
large areas of brightness.
Select , Low, Medium, or
High.
• Backlight Control -
Dynamically improves the
contrast ration of the picture
by adjusting the backlight.
Select or On.
• Reduce Signal Noise -
Diminishes artifacts in
the image caused by the
digitizing of image motion
content. Select , Low,
Medium, or High.
• Game Low Latency - Select On to reduce video delay (lag)
when gaming.
• Picture Size: Increase or decrease the vertical and
horizontal size of the displayed picture. Use the Left/
Right Arrow buttons to adjust the horizontal size of the
displayed picture. Use the Up/Down Arrow buttons to
adjust the vertical size of the displayed picture. Press the
OK button when you are nished.
• Picture Position: Adjust the vertical and horizontal
positions of the picture to ensure the image is centered
and completely lls the screen. se the Left/Right
Arrow buttons to adjust the horizontal position of the
displayed picture. Use the Up/Down Arrow buttons to
adjust the vertical position of the displayed picture. Press
the OK button when you are nished.
• Film Mode - Optimies the picture for watching lm. Select
Auto or .
• Gamma - Set the shape of the Gamma curve. Use lower
Gamma values for bright room conditions, and higher
values when it’s dark.
3. hen you have nished adusting More icture Settings, press the
EXIT button on the remote.
Adjusting the Color Temperature
Adjusting the color temperature changes the white balance of the
picture.
To adjust the color temperature:
1. From the MORE PICTURE menu,
use the Arrow buttons to
highlight Color Temperature,
and then press OK.
VIZIO
COLOR TEMPERATURE
Cool
Normal
Computer
2. Use the Arrow buttons on the
remote to highlight a color
temperature preset and then
press OK.
• Normal is optimized for
television viewing.
• Cool produces a blue-hued
picture.
• Computer optimizes the
picture for use as a
PC monitor.
3. hen you have nished
adjusting the color temperature,
press the EXIT button on the
remote.
• Picture Size & Position - Highlight Picture Size & Position
and press OK. The PICTURE SIZE & POSITION menu is
displayed.
3
VIZIO
VIZIO
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
Help
Network
Sleep
Timer
Input CC
ABC
Audio
Wide
Normal
Settings
PanoramicWide Zoom
2D 3DExit
Adjusting the Picture Mode Edit Settings
Picture Mode Edit Settings allow you to make precise adjustments
to the picture and to create picture modes to save groups of picture
settings.
To adjust the Picture Mode Edit settings:
1. From the PICTURE menu, use the
Arrow buttons to highlight Picture
Mode Edit, and then press OK.
The PICTURE MODE EDIT menu is
displayed.
2. Use the Arrow buttons to
PICTURE MODE EDIT - Vivid*
Save Picture Mode
Lock Picture Mode
Reset Picture Mode - Vivid*
highlight the setting you wish to
adjust, then press OK to change
the setting:
• Save Picture Mode - Save a
custom picture mode.
• Lock Picture Mode - Prevent
changes to custom picture
modes.
• Unlock Picture Mode - Allow
changes to custom picture
modes. (Available after a custom
PICTURE MODE EDIT - MyMode
Save Picture Mode
Unlock Picture Mode
Delete Picture Mode - MyMode
picture mode is locked)
• Delete Picture Mode - Delete
a custom picture mode. Inputs
assigned to that custom picture
mode will be set to Calibrated
picture mode. (Available after a
custom picture mode is saved)
• Reset Picture Mode
†
- Reset
the picture mode settings to
factory default values.
Saving a Custom Picture Mode
Custom picture modes allow you to save a group of custom settings
for various viewing conditions and video sources.
• Changes made while on any preset picture mode will add an
asterisk on the top right corner of the preset mode.
• The custom picture mode is not automatically saved.
To save a custom picture mode:
1. From the PICTURE MODE EDIT
menu, use the Arrow buttons
to highlight Save Picture
VIZIO
SAVE PICTURE MODE
Mode, and then press OK. The
SAVE PICTURE MODE menu is
displayed.
2. Use either the on-screen
keyboard or keyboard on your
remote control to enter a name
for your custom picture mode.
3. Highlight Save and press OK.
Custom1_
a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0
1 2 3 4 5 6 7 8 9
.@# .com Space
Save
äêí
4. Press the EXIT button to exit the
menu screens.
Locking/Unlocking a Custom Picture Mode
Custom picture modes can be locked/unlocked with a unique PIN to
prevent accidental changes to their settings.
To lock all custom picture modes:
1. From the PICTURE MODE EDIT
menu, use the Arrow buttons
to highlight Lock Picture
Mode, and then press OK. The
LOCK PICTURE MODE menu is
VIZIO
LOCK PICTURE MODE
Create a picture control PIN to prevent changes
to all custom picture modes.
displayed.
2. Use the Number Pad on your
remote to enter a unique 4-digit
PIN.
3. Highlight Save and press OK.
Save
4. Press the EXIT button to exit the
menu screens.
To unlock all custom picture modes:
Create a 4 digit passcode using the number
keys on the remote.
1. From the PICTURE MODE EDIT
menu, use the Arrow buttons
to highlight Unlock Picture
Mode, and then press OK. The
UNLOCK PICTURE MODE menu
is displayed.
2. Use the Number Pad on your remote to enter your 4-digit PIN.
3. Make any desired changes to the picture modes.
4. Relock the picture modes, if desired. You must create a new
4-digit PIN.
5. Press the EXIT button to exit the menu screens.
†
Only available on customized preset modes.
18
Loading...
