Vizio D39hn-E1 User Manual

Download

VIZIO

USER MANUAL

Model:D39hn-E1

Table Of Contents

Getting to Know Your TV .............................................7

Remote Control Front ......................................................................... 9

Replacing the Batteries ...................................................................9

Completing The First-Time Setup ...............................10

Using the On-Screen Menu .........................................12

Navigating the On-Screen Menu ........................................................ 12

Changing the Input Source ................................................................12

Changing the Screen Aspect Ratio ..................................................... 13

Adjusting the Picture Settings ............................................................ 14

Adjusting More Picture Settings .....................................................15

Adjusting the Color Temperature ................................................... 15

Adjusting the Picture Mode Edit Settings ......................................16

Saving a Custom Picture Mode ....................................................... 16

Locking/Unlocking a Custom Picture Mode ................................... 16

Deleting a Custom Picture Mode .................................................... 17

Resetting a Picture Mode ................................................................ 17

Adjusting the Color Tuner Settings ................................................18

Adjusting the Audio Settings .............................................................. 20

Changing the Equalizer Settings ..................................................... 20

Deleting the Custom Audio Mode ..................................................21

Setting Timers .....................................................................................22

Setting the Sleep Timer ................................................................... 22

Setting the Auto Power O Feature ...............................................22

Setting Up Channels ...........................................................................23

Selecting a Channel Source .............................................................23

Scanning for Channels ....................................................................23

Adding New Channels .....................................................................23

Skipping Channels ...........................................................................24

Listening to Alternate Audio ..............................................................25

Changing the Analog Audio Language ...........................................25

Setting Up Closed Captioning ............................................................26

Changing the Appearance of Digital Closed Captions ..................26

Renaming Devices on the Input Menu .............................................. 28

Changing the TV Settings ...................................................................29

Viewing System Information ........................................................... 29

Changing the On-Screen Menu Language .....................................29

Setting the Time and Local Settings ............................................... 30

Using the Parental Controls ............................................................ 30

Accessing the Parental Controls Menu ..........................................30

Enabling or Disabling Program Ratings .........................................30

Locking and Unlocking Channels .................................................... 30

Blocking and Unblocking Content by Rating .................................31

Changing the Parental Control PIN ................................................31

Resetting the Content Locks ........................................................... 31

Changing the View Mode Settings .................................................. 32

Changing the Screen Aspect Ratio ..................................................... 32

Adjusting the CEC Settings .............................................................. 33

Turning the Power Indicator On or O .......................................... 33

Accessibility ...................................................................................... 33

Using the Reset & Admin Menu ......................................................... 34

Restoring the TV to Factory Default Settings ................................. 34

Using the Info Window .......................................................................35

Using the USB Media Player ........................................36

Preparing Your USB Drive to Play USB Media ...............................36

Displaying USB Media .....................................................................36

Removing the USB Drive from the TV ............................................36

Troubleshooting & Technical Support ........................38

Specications ...............................................................42

Regulatory Information ...............................................43

Limited Warranty .........................................................44

Mexico Limited Warranty ............................................46

Legal Information.........................................................48

Safety & Certication



THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO HDTV.

To get the most out of your new VIZIO product, read these instructions before using your product and retain them for future reference. Be sure to inspect the package contents to ensure there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services for your VIZIO product, visit our website at www.VIZIO.com or call toll free at (877) 698-4946.

We recommend that you register your VIZIO product at www.VIZIO.com

Extended Warranties

For peace of mind, and to protect your investment beyond the

standard warranty, VIZIO oers on-site extended warranty service

plans. These plans provide additional coverage during the standard warranty period. To purchase an extended warranty service plan, visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the accompanying important warning or notice. It is intended to alert you to the presence of important operating instructions.

When you see this symbol, please read the accompanying helpful tip.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within dened design limits. Misuse may result in electric shock or re. To prevent

your TV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your TV. Read the following safety instructions before operating your TV. Keep these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component damage,

switch o the power before connecting other components

to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers)

that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories specied by the manufacturer.

• Use only with the cart, stand, tripod, bracket,

or table specied by the manufacturer, or

sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your TV to avoid causing

re, electric shock, or component damage.

• A distance of at least three feet should be maintained between your TV and any heat source, such as a radiator,

heater, oven, amplier etc. Do not install your TV close to

smoke. Operating your TV close to smoke or moisture may

cause re or electric shock.

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your TV in a bookcase or cabinet unless proper ventilation is provided.

• Never push any object into the slots and openings on your TV cabinet. Do not place any objects on the top of your TV.

Doing so could short circuit parts causing a re or electric

shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

iii

• Do not apply pressure or throw objects at your TV. This may compromise the integrity of the display. The manufacturer’s warranty does not cover user abuse or improper installations.

• The power cord must be replaced when using dierent

voltage than the voltage specied. For more information,

contact your dealer.

• When connected to a power outlet, power is always owing into your TV. To totally disconnect power, unplug the power cord.

• The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the

inside of your TV that may be of sucient magnitude to

constitute a risk of electric shock to persons.

• Do not overload power strips and extension cords.

Overloading can result in re or electric shock.

• The wall socket should be installed near your TV and easily accessible.

• Only power of the marked voltage can be used for your TV.

Any other voltage than the specied voltage may cause re

or electric shock.

• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.

• Unplug your TV during a lightning storm or when it will not be used for long period of time. This will protect your TV from damage due to power surges.

• Do not attempt to repair or service your TV yourself. Opening or removing the back cover may expose you to high voltages, electric shock, and other hazards. If repair is required, contact your dealer and refer all servicing to

qualied service personnel.

• WARNING: Keep your TV away from moisture. Do not expose your TV to rain or moisture. If water penetrates into your TV, unplug the power cord and contact your dealer. Continuous

use in this case may result in re or electric shock.

• Do not use your TV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your TV yourself.

• Avoid using dropped or damaged appliances. If your TV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair.

Continued use of your TV may cause re or electric shock.

• Do not install your TV in an area with heavy dust or high humidity. Operating your TV in environments with heavy

dust or high humidity may cause re or electric shock.

• Follow instructions for moving your TV. Ensure that the power cord and any other cables are unplugged before moving your TV.

• When unplugging your TV, hold the AC/DC power adapter, not the cord. Pulling on the power cord may damage the

wires inside the cord and cause re or electric shock. When

your TV will not be used for an extended period of time, unplug the power cord.

• To reduce risk of electric shock, do not touch the connector with wet hands.

• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to leak which can damage the remote control or injure the operator. Do not

expose batteries to excessive heat such as sunshine, re or

the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

- Your TV is exposed to rain or other moisture.

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

• This apparatus shall not be exposed to dripping or

splashing and no objects lled with liquids, such as vases,

shall be placed on the apparatus.

• The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• CAUTION - These servicing instructions are for use by

qualied service personnel only. To reduce the risk of

electric shock, do not perform any servicing other than that contained in the operating instructions unless you are

qualied to do so.

• The lightning ash with arrowhead symbol within an

equilateral triangle is intended to alert the user to the presence of uninsulated DANGEROUS VOLTAGE within the

product’s enclosure that may be of sucient magnitude to

constitute a risk of electrical shock to persons.

• WARNING: Exposure to loud sounds can damage your hearing causing hearing loss and tinnitus (ringing or

buzzing in the ears). with continued exposure to loud

noises, ears may become accustomed to the sound level, which may result in permanent damage to hearing without any noticeable discomfort.

• Install the TV where it cannot be pulled, pushed or knocked over.

• Do not allow children to hang onto the product.

• Store the accessories (remote, batteries, etc.) in a location safely out of the reach of children.

• The American Academy of Pediatrics discourages television viewing for children younger than two years of age.

TELEVISION ANTENNA CONNECTION PROTECTION

If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.

Power Lines

Ground Clamp

Antenna Lead In Wire

Antenna Discharge Unit (NEC Section 810-20)

Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. Remember, the screen of the coaxial cable is intended to be connected to earth in the building installation.

Electric Service Equipment

Grounding Conductors (NEC Section 810-21)

Ground Clamps

Power Service Grounding Electrode System

(NEC ART 250, part H)

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a

This product qualies for ENERGY STAR in the “factory

default” settings ans this is the setting in which power savings will be achieved. Changing the factory default picture settings or enabling other features will increase power consumption that could exceed the limits necessary to qualify for ENERGY STAR rating. For more information

on the ENERGY STAR program, refer to energystar.gov.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio,

and the double-D symbol are trademarks of Dolby Laboratories.

HDMI, the HDMI logo and High-Denition Multimedia

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

Getting to Know Your TV

REMOTE SENSOR & POWER INDICATOR

When using the remote, aim it directly at this sensor. The power indicator ashes on when the TV turns on, then goes out after several seconds.

To keep the power indicator on as long as the TV is on, see

Turning the Power Indicator On or O.

FRONT PANEL

USB - Connect a USB thumb drive to play photo, music, or video.

HDMI - Connect an HDMI device.

Stereo Audio Out- Connect an RCA audio device, such as sound bar.

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

Optical Audio Out - Connect an optical/SPDIF audio device, such as home audio receiver.

Coaxial - Connect a coaxial cable from cable, satellite, or antenna.

Component/Composite - Connect a component or composite device.

HDMI - Connect an HDMI device.

Power/Input - Press to turn on the TV. Press and hold to turn the TV o. Press once to

access the input menu

REAR PANEL

USING THE REMOTE

Replacing the Batteries

Two AAA batteries are included for you to use with the basic remote control.

3 4

7 8

14 15

1. Power - Turn TV on or O.

2. Input - Change the currently displayed input.

3. Exit - Close the on-screen menu.

To insert/replace the batteries:

1. Find the notch on the back of the remote. Insert a coin and pry

2. Remove the back cover and insert two AAA batteries (included). Be sure to align the + and - signs on the batteries and remote..

4. Menu - Display the on-screen menu.

5. Arrows - Navigate the on-screen menu.

6. OK / Enter - Select the highlighted option / Conrm channel or passcode entered

using the number pad.

7. Back - Go to the previous on-screen menu.

8. Info - Display the info window.

9. Volume Up/Down - Increase or decrease the loudness of the audio.

10. Closed Caption - Turn closed captions on or o.

11. Pic - Cycle through the dierent aspect ratios.

12. Wide - Change the display mode.

13. Channel Up/Down - Change the channel.

14. Mute - Turn the audio on or o.

15. Last - Return to the last viewed channel.

16. Number Pad - Manually enter a channel.

17. Enter - Conrm channel or passcode entered using number pad.

18. Dash - Use with number pad to manually enter a digital

sub-channel. (e.g. 18-4 or 18-5)

1817

REMOTE CONTROL

The first time you turn on the TV, the TV will guide you through each of the steps necessary to get your TV ready for use.

Before you begin the first-time setup:

• Your TV should be installed and the power cord should be connected to an electrical outlet.

• Your devices should be connected.

• If you have a wireless network, have the network password ready.

Select Store Demo for in-store display.

Seleccione "Home Use" para Modo de Casa o "Store Demo" para Demostración en la Tienda.

Choisissez "Home Use" pour le Mode Domicile ou "Store Demo" pour la Démo en Magasin.

Choose your mode.

Select Home Use for in-home use.

Store Demo Home Use

2Completing The First-Time Setup

• If you are connecting to your network with an Ethernet cable, connect it to the Ethernet port on the TV.

To complete the first-time setup:

Use the Arrow buttons on the remote to

highlight Home Use and press OK.

Use the Arrow buttons on the remote to highlight

your TV source and press OK.

If you have cable TV, select whether you have

a cable box or if you connect the TV directly

to a cable from the wall.

Press the Power button on the remote. The TV

powers on and the Setup App starts.

Use the Arrow buttons on the remote to highlight

your language of preference and press OK.

If the TV Signal channel scan screen appears, the

TV will need to scan for channels, which takes

several minutes.

Use the arrow buttons on the remote to highlight

Begin Scan and press OK.

Note: Number of ports may differ by TV.

Otherwise, use the Arrow and OK buttons on the remote to select the input your TV source

is connected to.

When you are nished, the message

“Setup is complete.” will appear.

The First-Time Setup is complete.

Using the On-Screen Menu

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Your TV features an easy-to-use on-screen menu.

To open the on-screen menu, press the MENU button on the remote.

From this menu, you can:

• Adjust the Picture settings

• Adjust the Audio settings

• Setting the Sleep Timers

• Adjust the Channel settings

• Set up Closed Captioning

• Name Inputs

VIZIO

TV SETTINGS

Picture Audio Timers Channels

Closed Captions Devices System

• Adjust TV settings

NAVIGATING THE ON-SCREEN MENU

To open the on-screen menu, press the MENU button on the remote.

Use the Arrow buttons to highlight a menu option, and press the OK button to select that option.

While navigating the on-screen menu, you can press the BACK button at any time to return to the previous menu screen. The EXIT button will close the on-screen menu.

CHANGING THE INPUT SOURCE

External devices such as DVD players, Blu-ray Players, and video game consoles can be connected to your TV. To use one of these

devices with your TV, you must rst change the input source using

the Input menu.

To change the input source:

1. Press the INPUT button on the remote. The Input menu is displayed.

2. Use the Up/Down Arrow buttons or the INPUT button on the remote to highlight the input you wish to view and press OK. The selected input is displayed.

Input Name

Note: Inputs may vary by TV.

HDMI-1

HDMI-2

COMP

RGB

You can change the input names that appear on the Input menu to make your devices easy to recognize. See

Renaming Devices on the Input Menu

for more

information.

CHANGING THE SCREEN ASPECT RATIO

The TV can display images in ve dierent modes: Normal, Stretch,

Panoramic, Wide, and Zoom. Each mode displays the picture

dierently.

Some programs have black bars on the top or sides of the picture so that the picture keeps its original shape. Examples include wide-screen movies and older television programs.

To change the screen aspect ratio:

1. Press the WIDE button on the remote.

2. Use the Arrow buttons to highlight the aspect ratio you wish to view and press OK.

• Normal preserves the content’s

original aspect ratio and size.

• Standard Denition (480i and 480p—old TV programs) - Since the 4:3 aspect ratio is not large

enough to ll the TV’s screen,

black bars are added to the left and right of the display image.

Normal

Panoramic

Wide

Zoom

Note: Aspect ratio settings may vary by Input source.

Normal

Stretch

Wide

Zoom

not stretched, but the sides of the image are extremely stretched. If you are watching widescreen (1.85:1 or 2.35:1) content with black bars on the top and bottom, the black bars will still appear on the top and bottom of the display image.

• Standard Denition (480i and 480p) - Fills the screen from the left to right edges.

• 720p and 720i - Not available.

• 1080p and 1080i - Not available.

• Wide stretches a 4:3 aspect ratio picture to the edges of the screen. Since the picture is being stretched, the display

image may appear distorted—gures appear short and fat.

If the program is already formatted for widescreen viewing (1.85:1 or 2.35:1), then black bars will appear on the top and bottom of the display image.

• Zoom expands images evenly in all directions (33% taller

and 33% wider) with black bars to t the screen. A 720p image will ll a 1080p screen.

• Standard Denition - Not available.

• 720p and 720i HD - Fills a 1080p screen

• 1080p and 1080i - Not available.

• 720p and 720i HD - Fills a 720p or 1080p screen.

• 1080p and 1080i HD - Fills a 720p or 1080p screen.

• Stretch expands a widescreen image to ll the screen from

top to bottom and stretches it half as much from right to left. Figures appear tall and thin.

• Standard Denition - Not available.

• 720p and 720i HD - If you are watching widescreen

1.85:1 content, the image will ll the screen. With 2.35:1

widescreen content, one-sixth of the image is cut o by the left and right sides of the screen.

• 1080p and 1080i - Not available.

• Panoramic stretches a 4:3 aspect ratio picture to the left and right edges of the screen. The center of the image is

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

ADJUSTING THE PICTURE SETTINGS

Your TV display can be adjusted to suit your preferences and viewing conditions.

If you’ve changes to the settings for a picture mode, an asterisks appears after its name (see

Picture Mode

To adjust the picture settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Picture and press OK. The PICTURE menu is displayed.

Saving a Custom

3. Use the Arrow buttons on the remote to highlight Picture

Mode, then use the Left/Right Arrow buttons to change the

picture mode:

• Standard mode sets the

picture settings to the default settings.

• Calibrated mode sets the

picture settings to values ideal for watching TV in a brightly-lit room.

VIZIO

PICTURE Picture Mode Standard Backlight 85 Brightness 50 Contrast 50 Color 63 Tint 0 Sharpness 60 More Picture Picture Mode Edit Color Calibration

• Calibrated Dark mode sets the picture settings to values ideal for watching TV in a dark room.

• Vivid mode sets the picture settings to values that produce a brighter, more vivid picture.

• Game mode reduces throughput delays and optimizes the picture settings for displaying game console output.

• Computer mode optimizes the picture settings for displaying computer output.

4. To manually change each of the picture settings, use the Up/ Down Arrow buttons on the remote to highlight that picture setting, then use the Left/Right Arrow buttons to adjust the setting:

+ + + + + +

• Backlight - Adjusts the LED brightness to aect the overall

brilliance of the picture. Backlight cannot be adjusted when starting from some picture modes.

• Brightness - Adjusts the black level of the picture. When this

setting is too low, the picture may be too dark to distinguish details. When this setting is too high, the picture may appear faded or washed out.

• Contrast - Adjusts the white level of the picture. When this

setting is too low, the picture may appear dark. When this setting is too high, the picture may appear faded or washed

out. If the setting is too high or too low, detail may be dicult

to distinguish in dark or bright areas of the picture.

• Color - Adjusts the intensity of the picture colors.

• Tint - Adjusts the hue of the picture. This setting is useful in

adjusting the esh tones in the picture. If esh appears too

orange, reduce the level of color before adjusting tint.

• Sharpness - Adjusts the edge sharpness of picture elements.

It can be used to sharpen non-HD (high denition) content;

however, it will not produce detail that does not otherwise exist.

5. When you have nished adjusting the picture settings, press the EXIT button on the remote.

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Adjusting More Picture Settings

To adjust more picture settings:

1. From the PICTURE menu, use the

Arrow buttons to highlight More Picture, and then press OK.

2. Use the Arrow buttons to highlight the setting you wish to adjust, then press the Left/ Right Arrow buttons to change the setting:

• Color Temperature -

See

Adjusting the Color

Temperature.

VIZIO

MORE PICTURE

Color Temperature Cool

Black Detail O

Backlight Control On

Reduce Signal Noise O

Reduce Block Noise O

Game Low Latency O

Picture Size & Position Film Mode Auto Gamma 2.1

• Black Detail - Adjusts the

average brightness of the picture to compensate for large areas of brightness. Select O, Low, Medium, or

High.

• Backlight Control -

Dynamically improves the contrast ration of the picture by adusting the backlight. Select O or On.

• Reduce Signal Noise - Diminishes artifacts in the image

caused by the digitizing of image motion content. Select O,

Low, Medium, or High.

• Reduce Block Noise - Diminishes artifacts in the image

caused by the digitizing of image motion content. Select

O, Low, Medium, or High.

• Picture Size: Increase or decrease the vertical and horizontal size of the displayed picture. Use the Left/ Right Arrow buttons to adjust the horizontal size of the

displayed picture. Use the Up/Down Arrow buttons to adjust the vertical size of the displayed picture. Press the

OK button when you are nished.

• Picture Position: Adjust the vertical and horizontal

positions of the picture to ensure the image is centered

and completely lls the screen. Use the Left/Right Arrow buttons to adjust the horizontal position of the

displayed picture. Use the Up/Down Arrow buttons to adjust the vertical position of the displayed picture. Press the OK button when you are nished.

• Film Mode - Optimizes the picture for watching lm. Select

Auto or O.

• Gamma - Set the shape of the Gamma curve. Use lower

Gamma values for bright room conditions, and higher values when it’s dark.

3. When you have nished adjusting More Picture Settings, press the

EXIT button on the remote.

Adjusting the Color Temperature

Adjusting the color temperature changes the white balance of the picture.

To adjust the color temperature:

1. From the MORE PICTURE menu, use the Arrow buttons to highlight Color Temperature, and then press OK.

VIZIO

COLOR TEMPERATURE

Normal

Cool

Computer

2. Use the Arrow buttons on the remote to highlight a color temperature preset and then press OK.

• Normal is optimized for television viewing.

• Cool produces a blue-hued picture.

• Computer optimizes the picture for use as a PC monitor.

3. When you have nished adusting the color temperature, press the EXIT button on the remote.

• Game Low Latency - Select On to reduce video delay (lag) when gaming.

• Picture Size & Position - Highlight Picture Size & Position and press OK. The PICTURE SIZE & POSITION menu is displayed.

VIZIO

ABC

Normal

PanoramicWide Zoom

2D 3DExit

VIZIO

ABC

Normal

PanoramicWide Zoom

2D 3DExit

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Adjusting the Picture Mode Edit Settings

Picture Mode Edit Settings allow you to make precise adjustments to the picture and to create picture modes to save groups of picture settings.

To adjust the Picture Mode Edit settings:

1. From the PICTURE menu, use the

Arrow buttons to highlight Picture Mode Edit, and then press OK.

The PICTURE MODE EDIT menu is displayed.

PICTURE MODE EDIT - Vivid* Save Picture Mode Lock Picture Mode Reset Picture Mode - Vivid*

2. Use the Arrow buttons to highlight the setting you wish to adjust, then press OK to change the setting:

• Save Picture Mode - Save a

custom picture mode.

• Lock Picture Mode - Prevent

changes to custom picture modes.

• Unlock Picture Mode - Allow

changes to custom picture modes. (Available after a custom

PICTURE MODE EDIT - MyMode

Save Picture Mode

Unlock Picture Mode Delete Picture Mode - MyMode

picture mode is locked)

• Delete Picture Mode - Delete a custom picture mode. Inputs assigned to that custom picture mode will be set to Calibrated picture mode. (Available after a custom picture mode is saved)

• Reset Picture Mode† - Reset

the picture mode settings to factory default values.

* Not available on HDMI input 5.

†

Only available on customized preset modes.

‡

Only available on HDMI input.

Saving a Custom Picture Mode

Custom picture modes allow you to save a group of custom settings for various viewing conditions and video sources.

• Changes made while on any preset picture mode will add an asterisk on the top right corner of the preset mode.

• The custom picture mode is not automatically saved.

To save a custom picture mode:

1. From the PICTURE MODE EDIT menu, use the Arrow buttons to highlight Save Picture Mode, and then press OK. The SAVE PICTURE MODE menu is displayed.

2. Use either the on-screen keyboard or keyboard on your remote control to enter a name for your custom picture mode.

3. Highlight Save and press OK.

VIZIO

SAVE PICTURE MODE

Custom1_

a b c d e f g h i j k l m n o p q r s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# .com Space

Save

äêí

4. Press the EXIT button to exit the menu screens.

Locking/Unlocking a Custom Picture Mode

Custom picture modes can be locked/unlocked with a unique PIN to prevent accidental changes to their settings.

To lock all custom picture modes:

1. From the PICTURE MODE EDIT menu, use the Arrow buttons to highlight Lock Picture Mode, and then press OK. The LOCK PICTURE MODE menu is

VIZIO

LOCK PICTURE MODE

Create a picture control PIN to prevent changes to all custom picture modes.

displayed.

2. Use the Number Pad on your remote to enter a unique 4-digit PIN.

Save

3. Highlight Save and press OK.

4. Press the EXIT button to exit the menu screens.

Create a 4 digit passcode using the number keys on the remote.

To unlock all custom picture modes:

1. From the PICTURE MODE EDIT menu, use the Arrow buttons to highlight Unlock Picture Mode, and then press OK. The UNLOCK PICTURE MODE menu is displayed.

2. Use the Number Pad on your remote to enter your 4-digit PIN.

3. Make any desired changes to the picture modes.

4. Relock the picture modes, if desired. You must create a new 4-digit PIN.

5. Press the EXIT button to exit the menu screens.

Deleting a Custom Picture Mode

Custom picture modes that are no longer needed can be deleted.

Inputs assigned to a deleted custom picture mode become assigned to the

Calibrated

picture mode.

To delete a custom picture mode:

1. From the PICTURE MODE EDIT menu, use the Arrow buttons to highlight Delete Picture Mode, and then press OK. The DELETE PICTURE

To delete the user created Custom 1 picture mode,

select the Delete button.

Delete Cancel

MODE window is displayed.

2. Use the Left/Right Arrow buttons to highlight Delete and press OK.

3. Press the EXIT button to exit the menu screens.

Resetting a Picture Mode

A preset picture mode that has been edited can be restored to the factory default settings.

To reset a customized preset picture mode:

1. From the PICTURE MODE EDIT menu, use the Arrow buttons to highlight Reset Picture Mode, and then press OK. The RESET PICTURE MODE

Select Reset to restore Standard

picture mode to factory defaults.

Reset Cancel

window is displayed.

2. Use the Left/Right Arrow buttons to highlight Reset and press OK.

3. Press the EXIT button to exit the menu screens.

Adjusting the Color Tuner Settings

The Color Tuner settings allow you to adjust the HSB color and 11

point white balance, turn color channels o for testing, and display color bar, at, and ramp test patterns.

The Color Tuner, 11 Point White Balance, and test patterns allow technicians to manually calibrate the TV. Calibration requires specialized training, an input with precisely set colors, and a specialized light meter.

To adjust the HSB color settings:

1. From the COLOR CALIBRATION menu, use the Arrow buttons to highlight Color Tuner, and then press OK. The Color Tuner menu is displayed.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Oset 0 0 0

Gain 0 0 0

2. Use the Arrow buttons on the remote to highlight the Hue, Saturation, Brightness, Oset, or Gain of the color you wish to adjust. Press the OK button.

To turn color channels o and on:

1. From the COLOR CALIBRATION menu, use the Arrow buttons to highlight Color Tuner, and then press OK. The Color Tuner menu is displayed.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Oset 0 0 0

Gain 0 0 0

2. Use the Arrow buttons on the remote to highlight Red, Green, or Blue.

3. Press the OK button to turn the color channel o or on. An X

appears over a color channel that has been turned o.

4. Use the Arrow buttons to highlight another color channel to

turn o or on. Only two color channels can be turned o at the

same time.

5. When you are nished with the color channels, press the EXIT button.

To adjust the 11 Point White Balance settings:

1. From the Color Tuner menu, use the Arrow buttons to highlight Color Tuner, and then press the Left/Right Arrow buttons until the 11 Point White Balance menu is displayed.

11 Point White Balance

Gain Red Green Blue

5% 0 0 0

2. Use the Arrow buttons on the remote to highlight the Gain and Color values you wish to adjust. Press the OK button and use the Left/Right Arrow buttons to adjust the value. When you are nished, press the OK button to save the setting.

3. When you are nished, press the EXIT button.

3. Use the Left/Right Arrow buttons to adjust the value. When you are nished press the OK button to save the setting.

4. When you are nished adjusting the color tuner settings, press the EXIT button.

To show or hide the SMPTE Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight Color Tuner, and then press the Left/Right Arrow buttons until the SMPTE Test Pattern menu is displayed.

SMPTE Test Pattern

O

2. Use the Arrow buttons on the remote to highlight O. Use the Left/Right Arrow buttons to highlight On to show the SMPTE

Pattern. —or—

To hide the SMPTE Test Pattern, use the Left/Right Arrow buttons to highlight O.

3. When you are nished, press the EXIT button.

To show or hide the Flat Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight Color Tuner, and then press the Left/Right Arrow buttons until the Flat Test Pattern menu is displayed.

Flat Test Pattern

O

2. Use the Arrow buttons on the remote to highlight O. Use the Left/Right Arrow buttons to select the percentage brightness

for the at test pattern. Selecting a percentage immediately shows the at pattern at that brightness.

—or—

To disable the Flat Test Pattern, use the Left/Right Arrow buttons to highlight O.

3. When you are nished, press the EXIT button.

To show or hide the Ramp Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight Color Tuner, and then press the Left/Right Arrow buttons until the Ramp Test Pattern menu is displayed.

Ramp Test Pattern

O

2. Use the Arrow buttons on the remote to highlight O. Use the Left/Right Arrow buttons to select the color for the ramp test

pattern. Selecting a color immediately shows that color ramp.

—or—

To hide the Ramp Test Pattern, use the Left/Right Arrow buttons to highlight O.

3. When you are nished, press the EXIT button.

VIZIO

Input CC

ABC

Wide

Normal

PanoramicWide Zoom

2D 3DExit

ADJUSTING THE AUDIO SETTINGS

To adjust the audio settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Audio and press OK. The AUDIO menu is displayed.

3. Use the Arrow buttons to highlight the setting you wish to adjust, then press Left/ Right Arrow buttons to change the setting:

• TV Speakers - Turns the

built-in speakers On or O.

When the TV speakers are set to On, DTS signals cannot be passed through digital audio outputs.

• Surround Sound - Surround sound uses DTS TruSurround™

to deliver an immersive surround sound experience from the TV’s internal speakers. TruSurround completes the entertainment experience by providing deep, rich bass and by delivering crisp details and clear, intelligible dialog. Select

On or O.

• Balance - Adjusts the loudness of the audio output from the

left and right speakers.

AUDIO TV Speakers On Surround Sound On Balance 0 Lip Sync 0 Digital Audio Out PCM Analog Audio Out Fixed Equalizer Delete Audio Mode

• Lip Sync - Adjusts the synchronization between the display image and the accompanying audio track.

• Digital Audio Out - Changes the type of processing for

Changing the Equalizer Settings

The graphic equalizer has several pre-set modes and allows you to

create one custom mode. digital audio out and HDMI ARC output when connected to a home theater audio system. Select PCM or Bitstream.

To select a pre-set audio mode:

1. Press the MENU button on the remote. The on-screen menu is

You must select Bitstream for audio with more than two channels (3.0, 5.0, or 5.1, for example).

+ +

• Analog Audio Out - Sets the volume control properties for the RCA connector when connected to a home theater audio

displayed.

2. Use the Arrow buttons on the remote to highlight Audio and press OK. The AUDIO menu is displayed.

3. Use the Arrow buttons to highlight Equalizer and press OK. The Audio Mode and equalizer settings screen appears.

system. Select Variable if you are controlling the volume with the TV’s volume controls, or select Fixed if an external audio device (sound bar or AV receiver) will control the volume.

• Equalizer - Adjusts the boost or attenuation of dierent

4. Use the Left and Right Arrow buttons to select an audio mode.

The equalizer bars change to reect the mode.

5. Press the EXIT button on the remote.

frequencies using either preset or custom settings. See

Changing the Equalizer Settings

• Delete Audio Mode - Deletes a custom audio mode created using the Equalizer Settings. See

Mode.

Deleting the Custom Audio

To create, modify, or replace the single custom equalizer setting:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Audio and

4. When you have nished adjusting the audio settings, press the

press OK. The AUDIO menu is displayed.

EXIT button on the remote.

3. Use the Arrow buttons to highlight Equalizer and press OK. The Audio Mode and equalizer settings screen appears.

4. Use the Left and Right Arrow buttons to select any audio mode as a starting point.

5. Use the Arrow buttons to highlight a frequency and then press OK.

6. Use the Up and Down Arrow buttons to adjust the boost (up) and attenuation (down) for the frequency.

7. Use the Left and Right Arrow buttons to select another frequency, if desired, and adjust it.

8. Press the EXIT button on the remote.

Deleting the Custom Audio Mode

To delete the custom audio mode that has been created:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Audio and press OK. The AUDIO menu is displayed.

3. Use the Arrow buttons to highlight Delete Audio Mode and press OK. The TV displays, “To delete the user created custom audio mode, select the Delete button.”

4. Highlight Delete and press OK.

5. Press the EXIT button on the remote.

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

SETTING TIMERS

Setting the Sleep Timer

When activated, the TV’s sleep timer will turn the TV o after a set

period of time.

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Timers and press OK. The TIMERS menu is displayed.

3. Use the Left/Right Arrow buttons on the remote to highlight the period of time after which you want the TV to go to sleep: 30, 60, 90, 120, or 180 minutes. If you don’t want the sleep timer to activate, change the setting to O.

VIZIO

TIMERS

Sleep Timer O

Auto Power O 10 minutes

Setting the Auto Power O Feature

To help save energy, your TV is set by default to turn o after

10 minutes without a video or audio signal. This feature can be deactivated.

To set the Auto Power O feature:

1. From the TIMERS menu, use the Up/Down Arrow buttons on the remote to highlight Auto Power O.

2. Use the Left/Right Arrow buttons on the remote to change

whether the TV will turn o. If you don’t want the TV to turn o

when there is no signal, change the setting to O. Otherwise, select 10 minutes.

3. When you have nished setting the auto power o time, press the EXIT button on the remote.

4. When you have nished setting the sleep timer, press the EXIT button on the remote.

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Help

VIZIO

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Input CC

ABC

Wide

Normal

PanoramicWide Zoom

2D 3DExit

SETTING UP CHANNELS

You can use the TV’s Channels menu to:

• Select a Channel Source

• Find Channels

• Perform a Partial Channel Scan

• Manually Add Channels

• Select channels to skip

VIZIO

CHANNELS Channels not searched Channel Source Cable Find Channel Skip Channel Analog Audio Stereo Digital Language English

Selecting a Channel Source

Select the type of tuner input you will be using. You can select either Antenna (Over-the-air) or Cable (Out-of-the-wall) connections.

1. From the CHANNELS menu, highlight Channel Source and press OK. The CHANNEL SOURCE menu displays.

2. Highlight Antenna or Cable and press OK. Press EXIT.

Scanning for Channels

The TV may need to scan for channels before it can display programs and their associated information. A channel scan is required for free over-the-air channels (using an antenna) and cable channels from an out-of-the-wall connection (without a cable box). Moving

the TV to an area with dierent channels requires the TV to scan for

channels again.

To perform an Auto Channel Scan:

1. From the CHANNELS menu, highlight Find Channels, and press OK. The auto channel scan begins.

2. Wait until the channel scan is 100% complete. Highlight Done and press OK.

VIZIO

FIND CHANNELS Channels Found Digital: 0 Analog: 19 18% Complete

Cancel

3. Press the EXIT button on the remote.

Adding New Channels

Occasionally, you may need to add a new range of channels or add a new analog channel. You can do this by using the Partial Channel Search and Add Analog Channel options. This is quicker than scanning all possible channels.

To add a range of new channels:

1. From the CHANNELS menu, highlight Partial Channel Search, and press OK. The PARTIAL CHANNEL SEARCH menu is displayed.

2. Highlight Scan Mode and select the type of channel you are adding: Analog, Digital, or Analog/Digital.

3. Highlight From Channel and enter the channel where you want to begin the scan. (Use the Left Arrow button to backspace. Use the Number Pad on the remote to enter the channel.)

4. Highlight To Channel and enter the channel where you want to end the scan. (Use the Left Arrow button to backspace. Use the Number Pad on the remote to enter the channel.)

5. Highlight Start and press OK. The partial channel search begins.

6. Wait until the partial channel search is 100% complete. Highlight Done and press OK.

7. Press the EXIT button on the remote.

If the channel scan is cancelled, the channels that were already discovered are retained. A new channel scan will clear all channels.

Cancel the channel scan.

Skipping Channels

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

After a channel scan is completed, you may nd that some channels

are too weak to watch comfortably. There may also be some channels you do not want to view. You can remove these channels from the TV’s memory with the Skip Channel feature.

Channels that have been removed with the Skip Channel feature can still be viewed if the channel is entered using the Number Pad. If you wish to completely block a channel from being viewed, use the parental controls. See

Locking and Unlocking Channels

To remove a channel:

1. From the CHANNELS menu,

VIZIO

1 1 1-2 2 2-2 2-3

SKIP CHANNEL

Test 0

Test 1

Test 2

Test 3

Test 4

Test 5

highlight Skip Channel, and press OK. The SKIP CHANNEL menu is displayed.

2. For each channel you wish to remove, use the Up/Down Arrow buttons on the remote to highlight the channel and press

OK. A P appears to the right of each channel you select.

3. When you have selected all of the channels you wish to remove, press the EXIT button on the remote.

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

LISTENING TO ALTERNATE AUDIO

Changing the Analog Audio Language

Some analog over-the-air (free) and cable channels broadcast programs in more than one language. The TV’s Analog Audio feature allows you to listen to audio in an alternate language using Secondary Audio Programming (SAP).

Not all programs are broadcast in SAP. The Analog Audio Language feature only works when the program being viewed is being broadcast with Secondary Audio Programming.

To use the Analog Audio feature:

1. From the CHANNELS menu, highlight Analog Audio and press OK. The ANALOG AUDIO menu is displayed.

2. Select Stereo, SAP (secondary audio programming), or Mono. Press OK.

3. Press the EXIT button on the remote.

VIZIO

ANALOG AUDIO

Stereo

SAP

Mono

To use the Digital Audio feature:

1. From the CHANNELS menu, highlight Digital Language and press OK. The DIGITAL LANGUAGE menu is displayed.

2. Select your preferred language: English, Español or Français. Press OK.

3. Press the EXIT button on the remote.

VIZIO

DIGITAL AUDIO

English

Español

Français

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

SETTING UP CLOSED CAPTIONING

Your TV can display closed captions for programs that include them. Closed captions display a transcription of a program’s dialogue.

If the program you are viewing is not being broadcast with closed captions, the TV will not display them.

The Closed Captions menu does not appear when an HDMI input is selected.

To activate or deactivate closed captions:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Closed Captions and press OK. The CLOSED CAPTIONS menu is displayed.

3. Use the Arrow buttons on the remote to highlight Closed

Captions and then use the Left/ Right Arrow buttons to select On or O.

4. Use the Arrow buttons on the remote to highlight either

Analog or Digital Closed Captions.

5. Use the Left/Right Arrow buttons on the remote to select the caption channel you wish to display, then press EXIT.

VIZIO

CLOSED CAPTIONS

Closed Captions O

Analog Closed Captions CC1 Digital Closed Captions CS1 Digital Style

Changing the Appearance of Digital Closed Captions

Digital closed captions can be displayed according to your preference. See the diagram on the next page for an explanation of the parts of the closed caption area.

To change the appearance of digital closed captions:

1. From the CLOSED CAPTIONS menu, use the Arrow buttons to highlight Digital Style and press OK.

2. Use the Left/Right Arrow buttons on the remote to select Custom. The DIGITAL STYLE menu appears as shown.

3. Use the Up/Down Arrow buttons on the remote to highlight the setting you wish to change, then use the Left/Right Arrow buttons to change the

VIZIO

DIGITAL STYLE

Caption Style

Text Style

Text Size

Text Color

Text Opacity

Text Edges

Text Edges Color

Background Color

Background Opacity

Window Color

Window Opacity

Custom

As Broadcast

Large

Green As Broadcast As Broadcast As Broadcast

Black

As Broadcast

Red

As Broadcast

setting:

• Caption Style - Choose As Broadcast to keep

default settings or Custom to manually change each setting.

• Text Style - Change the font used for the closed captioning text.

• Text Size - Make the text larger or smaller.

• Text Color - Change the color of the text.

• Text Opacity - Change the transparency of the text.

• Text Edges - Change the eects at the edges of the text,

such as raising the edges or adding drop shadows.

• Text Edges Color - Change the color of the text edge

eects.

• Background Color - Change the color of the background directly behind the text.

• Background Opacity - Change the transparency of the background directly behind the text.

• Window Color - Change the color of the closed captioning box.

• Window Opacity - Change the opacity of the closed captioning box.

4. When you are satised with the appearance of the closed captions, press the EXIT button on the remote.

Typical choices include:

• Opaque background, transparent window—Only a strip of background appears behind the text, expanding as the text appears. This is the typical "As Broadcast" mode.

• Opaque background and window in the same color—When

text appears, the entire line lls with color at once.

In the example below, the closed caption text is green, the background is black, and the window is red.

Text

Background

CLOSED CAPTION TEXT SAMPLE

Window

CLOSED CAPTIONS SCREEN LAYOUT

RENAMING DEVICES ON THE INPUT MENU

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

You can rename the inputs to make them easier to recognize on the Input menu. For example, if you have a DVD player connected

to the Component input, you can rename that input to display “DVD

Player.” See

To change the name of an input:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight Devices and press OK. The DEVICES menu is displayed.

Changing the Input Source.

Input Port

VIZIO

NAME INPUT

HDMI-1 DVD

Input Name

3. Highlight the input device that you want to rename and press OK.

4. To use a preset input name:

a. Highlight the Input Port row and press OK.

b. Highlight the input name you want to use and press OK. —or—

To enter a custom name:

a. Enter your custom label using the on-screen keyboard.

b. Highlight OK and press OK.

c. The Input Name changes to show the custom name that

you created.

5. When you have nished naming your input, press the EXIT button on the remote.

DVD_

a b c d e f g h i j k l m n o p q r s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# .com Space

OK Cancel

Select the input name from a list of common device names (Blu-ray, Cable Box, DVD, etc).

äêí

Custom Name

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

CHANGING THE TV SETTINGS

Using the System menu, you can:

• View system information

• Change the on-screen menu language

• Set time zone and local settings

• Set up parental controls

• Resize the video size

• Adjust wide mode

• Adjust the CEC settings

• Adjust when the power indicator is illuminated

• Reset the TV settings & set up administrative controls

VIZIO

SYSTEM System Information Menu Language English Time & Local Settings Parental Controls View Mode Overlay Wide CEC Power Indicator O Accessibility Reset & Admin

View status information for the TV, current input and your network.

Viewing System Information

To view technical data and status information about your TV and network connection:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and press OK. The SYSTEM menu is displayed.

3. Highlight System Information and press OK.

4. Use the Up/Down Arrow buttons to scroll through the system information.

5. When you are nished reviewing the system information, press the EXIT button on the remote.

Changing the On-Screen Menu Language

Your TV can display the on-screen menu in dierent languages.

To change the on-screen menu language:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and

VIZIO

MENU LANGUAGE

English

Español

Français

press OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight Menu Language and press OK. The MENU LANGUAGE menu is displayed.

4. Highlight your preferred language (English, Español, or Français) and press OK.

5. Press the EXIT button on the remote.

VIZIO

Input CC

ABC

Wide

Normal

PanoramicWide Zoom

2D 3DExit

Setting the Time and Local Settings

To ensure the correct time is displayed when you press the INFO button, set the TV’s time zone:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the

June 11, 2015 11:48AM

Time Zone Pacic (-8)

Daylight Savings Time Auto

remote to highlight System and press OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight Time & Local Settings and press OK. The menu headed by the local date and time is displayed.

4. Highlight Time Zone and press OK. The TIME ZONE menu is displayed.

5. Highlight your time zone and press OK.

6. Highlight Daylight Saving Time and press OK. The DAYLIGHT SAVING TIME menu is displayed. Choose On if it is currently Daylight Savings Time, O if it is Standard Time, or Auto to have the system automatically detect Daylight Savings Settings.

Using the Parental Controls

The TV’s parental controls allow you to prevent the TV from displaying certain channels or programs without a password.

The Parental Controls menu only appears when:

• You are using the tuner to receive your TV signals, such as when you are using an antenna for Over-the-Air signals or when connected to cable TV directly from the wall (no cable box).

• You have a device connected using a composite video cable or a coaxial cable, such as a VCR, satellite or cable box, or DVR.

Other devices have their own parental control settings.

Accessing the Parental Controls Menu

To access the Parental Controls menu:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and press OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight Parental

Controls and press OK.

Enabling or Disabling Program Ratings

To manage program content according to its rating, you must enable the Program Rating feature.

To enable or disable the Program Rating feature:

1. From the PARENTAL CONTROLS menu, highlight Locks and press OK. The LOCKS menu is displayed.

2. Select On or O and press OK.

Locking and Unlocking Channels

When a channel is locked, it will be inaccessible. Locking a channel is a good way to prevent children from viewing inappropriate material.

To lock or unlock a channel:

1. From the PARENTAL CONTROLS menu, highlight Channel Locks and press OK. The CHANNEL LOCKS menu is displayed.

2. Highlight the channel you want to lock or unlock and press OK.

3. When a channel is

locked

, the Lock icon appears locked. The channel is not accessible unless the parental PIN is entered.

4. When a channel is

unlocked

, the Lock icon appears

unlocked. The channel is accessible.

7. Press the EXIT button on the remote.

4. Enter your parental PIN. If you have not set a PIN, enter the default, 0000. The PARENTAL CONTROLS menu is displayed.

To set a custom parental passcode, see

Parental Control PIN

Changing the

Blocking and Unblocking Content by Rating

A channel may sometimes broadcast programs that are meant for children, and at other times broadcast programs that are meant for mature audiences. You may not want to block the channel completely using a channel lock, but you may wish to block certain programs from being viewed.

When this is the case, you can use the TV’s Rating Block feature to block content based on its rating.

For a list of content ratings and their denitions, visit www.tvguidelines.org.

To block or unblock content by its rating:

1. From the PARENTAL CONTROLS menu, highlight the content type you want to adjust and press OK:

USA TV - USA television program broadcasts. USA Movie - USA movie broadcasts. Canadian English - Canadian English television program

broadcasts. Canadian French - Canadian French television program

broadcasts.

Changing the Parental Control PIN

If you use the parental controls, you should change the PIN to prevent children from accessing inappropriate material.

To change the parental control PIN:

1. From the PARENTAL CONTROLS menu, highlight Change PIN and press OK. The CHANGE PIN menu is displayed.

2. In the NEW PIN eld, use the Number Pad on the remote to enter your new 4-digit parental control PIN.

3. In the CONFIRM PIN eld, use the Number Pad on the remote to re-enter your new 4-digit parental control PIN.

4. Write down your new parental control PIN and save it in a secure location.

5. Press the EXIT button on the remote.

Resetting the Content Locks

To reset the content locks to the factory-default settings:

1. From the PARENTAL CONTROLS menu, highlight Reset Locks and press OK. The TV displays, “Select Reset to restore Parental Controls to factory defaults.”

2. Highlight Reset and press OK.

2. For each rating type you want to block or unblock, use the Up/Down and Left/Right Arrow buttons on the remote to highlight the rating type and press OK.

3. When the rating type is blocked, the Lock icon appears locked. Content with this rating and all higher ratings cannot be viewed.

4. When the rating type is unblocked, the Lock icon appears unlocked. Content with this rating and all lower ratings can be viewed.

If you want to block all unrated content, highlight Block Unrated Shows and use the Arrow buttons on the remote to select On.

5. When you are nished adjusting the rating level blocks, press the EXIT button on the remote.

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

Changing the View Mode Settings

You can resize the video content to t while the menu is open.

To change the view mode settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and

VIZIO

VIEW MODE

Viewport

Overlay

Centered Overlay

press OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight View Mode and press OK. The VIEW MODE menu is displayed.

4. Highlight Viewport, Overlay, or Centered Overlay and press

OK.

• Viewport - The entire picture

is visible in the space to the right of the menu.

• Overlay - The left-hand

portion of the picture covered by the menu.

• Centered Overlay - The picture extends o of the right

side of the screen.

5. Press the EXIT button on the remote.

CHANGING THE SCREEN ASPECT RATIO

The TV can display images in ve dierent modes: Normal, Stretch,

Panoramic, Wide, and Zoom. Each mode displays the picture

dierently.

Some programs have black bars on the top or sides of the picture so that the picture keeps its original shape. Examples include wide-screen movies and older television programs.

To change the screen aspect ratio:

1. Press the WIDE button on the remote.

2. Use the Arrow buttons to highlight the aspect ratio you wish to view and press OK.

• Normal preserves the content’s

original aspect ratio and size.

• Standard Denition (480i and 480p—old TV programs) - Since the 4:3 aspect ratio is not large

enough to ll the TV’s screen,

black bars are added to the left and right of the display image.

• 720p and 720i HD - Fills a 720p or 1080p screen.

• 1080p and 1080i HD - Fills a 720p or 1080p screen.

• Stretch expands a widescreen image to ll the screen from

top to bottom and stretches it half as much from right to left. Figures appear tall and thin.

Normal

Panoramic

Wide

Zoom

Note: Aspect ratio settings may vary by Input source.

Normal

Stretch

Wide

Zoom

• Standard Denition (480i and 480p) - Fills the screen from the left to right edges.

• 720p and 720i - Not available.

• 1080p and 1080i - Not available.

• Wide stretches a 4:3 aspect ratio picture to the edges of the screen. Since the picture is being stretched, the display

image may appear distorted—gures appear short and fat.

If the program is already formatted for widescreen viewing (1.85:1 or 2.35:1), then black bars will appear on the top and bottom of the display image.

• Zoom expands images evenly in all directions (33% taller

and 33% wider) with black bars to t the screen. A 720p image will ll a 1080p screen.

• Standard Denition - Not available.

• 720p and 720i HD - Fills a 1080p screen

• 1080p and 1080i - Not available.

• Standard Denition - Not available.

• 720p and 720i HD - If you are watching widescreen

1.85:1 content, the image will ll the screen. With 2.35:1

widescreen content, one-sixth of the image is cut o by the left and right sides of the screen.

• 1080p and 1080i - Not available.

• Panoramic stretches a 4:3 aspect ratio picture to the left and right edges of the screen. The center of the image is

Adjusting the CEC Settings

The CEC function on your TV enables you to control devices connected to HDMI (ARC) input with the included remote, without any programming. Using CEC, your VIZIO TV remote can control:

• Power On/O

• Volume

• Mute

Not all HDMI devices support CEC. See your device’s user manual for details.

To enable, disable, or adjust CEC settings:

1. Set up your audio device and connect it to the HDMI-1(HDMI Arc) input on the TV

2. On your audio device, select the HDMI ARC input

3. Press the MENU button on the remote. The on-screen menu is displayed.

4. Use the Arrow buttons on the remote to highlight System and press OK. The SYSTEM menu is displayed.

Turning the Power Indicator On or O

The Power Indicator on the front of your TV normally does not glow when the TV is on. You can change this setting if you prefer the light to be on.

To turn the Power Indicator Light On or O:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and press OK. The SYSTEM menu is displayed.

3. Highlight Power Indicator and press OK.

4. Use the Up/Down Arrow buttons to select On or O, then press OK.

Accessibility

VIZIO is committed to providing intuitive, user-friendly products.

Your new VIZIO TV oers several accessibility features that can help

you get the most out of it.. To access the Accessibility menu:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and press OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight Accessibility and press OK. The ACCESSIBILITY menu is displayed.

• Talk Back - Turn Text-to-Speech Talk Back On or O.

Text-to-Speech Talk Back enables your TV to speak all settings changes and adjustments using the remote in English.

• Speech Rate* - Adjusts the rate in which Text-to-Speech is

spoken. Select Slow, Normal (Default), or Fast.

• Zoom Mode - Enlarges a section of the screen by 200%.

5. Use the Arrow buttons on the remote to highlight CEC and press OK. The CEC menu is displayed.

6. Highligh CEC and press OK. Select a setting and then press OK.

• CEC - To use CEC, you must select Enable.

• Device Discovery - To determain if your device is

connected and supports CEC, select Device Discovery and then press OK.

7. Press the EXIT button on the remote.

4. Press the EXIT button on the remote when done.

* Only available on English

Help

Network

Sleep

Timer

Input CC

ABC

Audio

Wide

Normal


Settings

PanoramicWide Zoom

2D 3DExit

USING THE RESET & ADMIN MENU

You can use the TV’s Reset & Admin menu to restore the TV to its factory default settings.

Restoring the TV to Factory Default Settings

All of the on-screen menu settings can be reset to the factory defaults.

If you restore the TV to the factory default settings, all changes you have made to the settings will be lost!

This includes any V.I.A. Plus Apps that you have added and any changes you have made to the settings for those Apps.

To restore the TV to its factory default settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight System and press OK. The SYSTEM menu is displayed.

VIZIO

RESET & ADMIN Reset TV to Factory Defaults Store Demo

5. If you have changed the default parental control PIN, enter it now.

The TV displays, “Select Reset to restore all TV settings to

factory defaults and clear all account information.”

6. Highlight Reset and press OK.

7. Wait for the TV to turn o. The TV will turn back on shortly afterward and the Setup App will begin.

3. Highlight Reset & Admin and press OK. The RESET & ADMIN menu is displayed.

4. Highlight Reset TV to Factory Defaults and press OK.

USING THE INFO WINDOW

The Info Window can be displayed by pressing the INFO or GUIDE button on the remote:

• Press the INFO or GUIDE button one time to display channel, input, and display information.

• Press the INFO or GUIDE button two times to display the program title, program rating, audio information, and the start and end times of the program.

Channel/Input Information

28-1

KCET-HD

Oliver’s Holiday Surprise

Oliver wakes up one morning only to discover that his pals are missing. In this hourlong holiday special, Oliver goes on a journey in search of his pals. Who knows what he’ll encounter on the way?

720p 6:15pm

Program Title/Rating Information

TV-PG-V

Dolby D Stereo

Normal

11:00AM - 12:00PM

Program Description

DIGITAL EPISODE GUIDE & INFO WINDOW

4Using the USB Media Player

Using the USB Media Player

The USB Media Player allows you to connect a USB thumb drive to your TV to view photos

Preparing Your USB Drive to Play USB Media

To display USB media, you must rst save your photos onto a USB

thumb drive:

• The USB thumb drive must be formatted as FAT32.

• Files on the USB thumb drive must end in a supported le extension ( .jpg or .jpeg).

• The player is not designed to play media from external hard drives, MP3 players, cameras, or smartphones

Displaying USB Media

To display your USB media:

1. Connect your USB thumb drive to the USB port on the side of the TV.

2. Use the Arrow buttons to highlight the Yes and press OK. (The highlighted App is in the center of the dock.)

3. Use the Arrow buttons to highlight the USB drive from the list and press OK.

4. Use the Arrow buttons to highlight Photo and press OK.

Removing the USB Drive from the TV

To safely remove your USB drive from the TV:

1. Turn o the TV.

2. Disconnect your USB thumb drive from the USB port on the side of the TV.

Do not remove the USB thumb drive while the TV is on. Doing so may damage the drive.

Note:

The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.

5. Use the Arrow buttons to highlight the le you want to display. Press OK. The photos display.

You can display your photos in fullscreen. Select the photo, press OK, then highlight Fullscreen and press OK.

Connected Sources

Displays connected USB devices.

Back Button Highlight this button and press OK to return to the previous screen.

VIZIO


USB1:

Back Button Highlight and press OK to return to left column.

Current Folder

Displays the folder path.

VIZIO_2GB\Photo\root

Folder Contents

This area displays the contents of the currently selected folder. You can

browse les and folders

using the Arrow and OK buttons on the remote.

Current Folder

Start Fullscreen Slideshow

Sort by Date or File Name

View Thumbnails/Folders

Adjust Slideshow Settings

View Music Files

root

Start Slideshow

Sort:

View:

File Name: D 1920x1080 Resolution: 1920x1080 Size: 1607270KB

Name A-Z

Thumbnails

Settings

Browse Music

Photo Information

Displays the name,

resolution, and le

size of the selected photo.




B.jpg C.jpg

E.jpg F.jpg

H.jpg I.jpg

Page 1 of 1

Page Information

If your USB thumb drive has more

les than can be displayed on a

single screen, the page information is displayed here.

PHOTO VIEWER

Do You Have Questions? Find Answers At

SUPPORT.VIZIO.COM

Find help with:

• New Product Setup

• Connecting Your Devices

• Technical Problems

• Product Updates

ATroubleshooting & Technical Support

• And More

Live Chat Support Available

You can also contact our award-winning support team at:

Phone:

(877) 698-4946 (TOLL-FREE)

Take A Moment To Register Your Product At

VIZIO.COM/PRODUCT-REGISTRATION

Why Register?

Customized Support

Get assistance quickly with your information on-hand.

News & Offers

Take advantage of the latest news and special offers from VIZIO.

Safety & Satisfaction

Stay up to date with important product updates and notifications.

The remote is not responding.

• Make sure the batteries are properly inserted matching the - and + symbols.

• Replace the batteries with fresh ones.

The TV displays “No Signal.”

• Press the INPUT button on the remote control to select a

dierent input source.

• If you are using cable TV or antenna connected directly to the TV, scan for channels. See

There is no power.

• Ensure the TV is plugged into a working electrical outlet.

• Ensure the power cable is securely attached to the TV.

• Press the Power/Standby button on the remote or on the back of the TV to turn the TV on.

The power is on, but there is no image on the screen.

• Ensure all cables are securely attached to the TV.

• Ensure all devices are connected correctly. Devices dier; see your device’s user manual for details.

• Adjust Brightness, Contrast, or Backlight. See

the Picture Settings

• Press the INPUT button on the remote to select a dierent input source.

Scanning for Channels

Adjusting

There is no sound.

• Press Volume Up on the remote control.

• Press the MUTE button on the remote to ensure mute is o.

• Check the audio settings. See

• Check the audio connections of external devices (Blu-ray player, game console, cable/satellite box) that are connected to the TV.

• If you are using an antenna, the signal strength of the channel may be low. Ensure your antenna is connected

The colors on the TV don’t look right.

The buttons on the remote aren’t working.

securely to the TV and move the antenna around the room or close to a window for the best signal.

• Adjust the Color and Tint settings in the Picture menu. See

Adjusting the Picture Settings

• Select a pre-set picture mode. See

Settings

• Check all cables to ensure they are securely attached.

• Ensure you are only pressing one button at a time.

• Point the remote directly at the TV when pressing a button.

• Replace the remote batteries with new ones. See

Replacing the Batteries.

. VIZIO recommends selecting Calibrated.

Adjusting the Audio Settings.

Adjusting the Picture

The image quality is not good.

• For the best image quality, view high-denition programs using digital sources. Connect your devices with HDMI cables.

• If you are using an antenna, the signal strength of the channel may be low. Ensure your antenna is connected securely to the TV and move the antenna around the room or close to a window for the best signal.

The picture is distorted.

• Move the TV away from electrical appliances, cars, and

uorescent lights.

• Ensure all cables are securely attached.

The display image does not cover the entire screen.

• If you are using TV, AV, or Component with 480i input, press the button on the remote to change the screen mode.

The TV has pixels (dots) that are always dark.

• Your HD TV is precision-manufactured using an extremely high level of technology. However, sometimes pixels may not display correctly. These types of occurrences are inherent to this type of product and do not constitute a defective product.

I see “noise” or static on the screen.

• When your TV’s digital capabilities exceed a digital broadcast signal, the signal is up-converted (improved) to match your TV’s display capabilities. This up-converting can sometimes cause irregularities in the image.

When I change input source, the display image changes size.

• The TV remembers the viewing mode on each input source. If the viewing mode on the new input source

diers from the one on the input source you switch from, the dierence may be noticeable.

• See

Changing the Screen Aspect Ratio

BSpecications

D39hn-E1

Screen Size: 39"

Viewable Area: 38.5"

Dimensions w/ Stand:

w/o Stand:

Weight w/ Stand:

w/o Stand:

LCD Backlight: Full Array LED

Refresh Rate: 60 Hz

Maximum Resolution: 1366 x 768 (720p)

Dynamic Contrast Ratio: 200,000:1

Pixel Pitch: 0.62700 mm (H) X 0.61475 mm (V)

Viewing Angle: 176° (H) / 176° (V)

HDMI Inputs: 2

34.94” x 22.48” x 8.27”

34.94” x 20.33” x 2.68”

17.31 lbs

16.87 lbs

D39hn-E1

Remote Control Model: XRT134

Certications:

Voltage Range: 120 V @ 60 Hz

Power Consumption: 35.5 W

Standby Power: <0.5W

Zero Bright Pixel Guarantee: Yes

UL, cUL, FCC Class B, BET-7/ICES-003 Class B,

IC, HDMI (CEC, ARC), Dolby Digital

Component Video Inputs: 1

Composite Inputs: 1 (Shared with Component)

RF Antenna Input: 1

USB Port: 1

Audio Outputs: RCA Analog Stereo Output, Optical Digital

OSD Language: English, French, Spanish

Ambient Light Sensor: Yes

CRegulatory Information

FCC Class B Radio Interference Statement

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/Display technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Notice

The changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.

The manufacturer is not responsible for any radio or Display

interference caused by unauthorized modication to this

equipment. It is the responsibilities of the user to correct such interference.

FCC Warning

Changes or modications not expressly approved by the party

responsible for compliance with the FCC Rules could void the user’s authority to operate this equipment.

Caution

Always use an AC/DC power adapter that is properly grounded. Use the AC cords listed below for each area.

Canada Notice for License-Exempt Radio Apparatus

This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This device operates on a no-protection no-interference basis. Should the user seek to obtain protection from other radio services operating in the same TV bands, a radio license is required. Please consult Industry Canada’s document CPC-2-1-28, Optional Licensing for Low-Power Radio Apparatus in the TV Bands, for details.

Cet appareil est conforme aux CNR exempts de licence d’Industrie Canada. . Son fonctionnement est sujet aux deux conditions suivantes:

1. le dispositif ne doit pas produire de brouillage préjudiciable, et

2. ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable

Cet appareil fonctionne sur une base sans protection et sans interférence. Dans le cas où l’utilisateur cherche à obtenir de la protection des autres services de radio fonctionnant sur les mêmes bandes TV, aucune license est requise. Veuillez consulter le document CPC-2-1-28 d’Industrie Canada, License optionnelle pour les appareils radio de faible puissance, pour plus de détails.

Industry Canada Class B emission compliance statement This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Declaración de México:

La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.

DLimited Warranty

UNITED STATES AND CANADA

BY USING YOUR VIZIO PRODUCT YOU AGREE TO BE BOUND BY ALL THE TERMS OF THIS WARRANTY. BEFORE USING YOUR VIZIO PRODUCT, PLEASE READ THIS WARRANTY CAREFULLY. IF YOU DO NOT AGREE TO THE TERMS OF THIS WARRANTY, DO NOT USE THE VIZIO PRODUCT AND, WITHIN THIRTY (30) DAYS OF THE DATE OF PURCHASE, RETURN IT FOR A REFUND TO THE AUTHORIZED RETAILER WHERE YOU PURCHASED IT. This warranty contains a binding arbitration agreement and a class action waiver for United States residents. If you live in the United States, the

binding arbitration agreement and class action waiver aect your rights under this warranty. Please read the text under the section titled “Binding Arbitration Agreement; Class Action Waiver (U.S. Residents Only)”

carefully.

How Long This Warranty Lasts

For non-commercial use, VIZIO warrants the product on the terms set forth below for one (1) year from the date of original purchase. For commercial use, VIZIO warrants this product on the terms set forth below for ninety (90) days from the date of original purchase.

What This Warranty Covers

VIZIO warrants the product against defects in materials and workmanship when the product is used normally in accordance with VIZIO’s user guides and manuals. Except where restricted by law, this warranty applies only to the original purchaser of a new product. The purchase must have been made from an authorized retailer in the United States (including Puerto Rico) or Canada. The product must also be located in the country where it was purchased at the time of warranty service.

Zero Bright Pixel Defect Guarantee (Displays Only)

Your product may qualify for a warranty against “zero bright pixel” defects

for the duration of the warranty on select new product purchases. To determine if this guarantee applies to your product, refer to the model’s

product information page at www.vizio.com, look for the “zero bright

pixel” guarantee on the box, or contact VIZIO Technical Support at the email address or telephone number below.

How to Get Service

Before obtaining warranty service, you may visit www.vizio.com for additional help and troubleshooting. To obtain warranty service, contact

VIZIO Technical Support via email at TechSupport@VIZIO.com or via

phone at 877 MY VIZIO (877-698-4946). The VIZIO Technical Support hours are 6:00AM to 9:00PM Monday through Friday and 7:00AM to

4:00PM Saturday and Sunday, Pacic Time.

Your Obligations Before Service

You must obtain pre-authorization before sending your product to a VIZIO service center. You may be required to supply a purchase receipt (or copy) to show that the product is within the warranty period. When you return a product to a VIZIO service center, you must ship the

product in its original packaging or in packaging that aords an equal

degree of protection. VIZIO Technical Support will provide instructions for packing and shipping the product to the VIZIO service center. ALL USER DATA AND DOWNLOADED APPLICATIONS STORED ON A PRODUCT WILL BE DELETED IN THE COURSE OF SOME IN-HOME AND ALL SHIP-IN WARRANTY SERVICE. If this occurs, your product will be restored to its original state. You will be responsible for restoring all applicable user data and downloaded applications. Recovery and reinstallation of user data and downloaded applications is not covered under this warranty. In order to protect your personal information, VIZIO recommends that you always clear all personal information from the product before it is serviced, regardless of the servicer.

VIZIO’s Responsibilities

If VIZIO determines that a product is covered by this warranty, VIZIO will (at its option) repair or replace it, or refund the purchase price to you. There will be no charge for parts or labor during the warranty period.

Replacement parts may be new or recertied at VIZIO’s option and sole

discretion. Replacement parts and VIZIO’s labor are warranted for the remaining portion of the original warranty or for ninety (90) days from warranty service, whichever is longer.

Types of Service

Displays that are 32 inches or larger will usually be serviced in-home. In-home service requires complete and easy access to the product and does not include de-installation or re-installation of the product. In-home service is subject to availability. VIZIO will provide other service options when in-home service is not available. All other VIZIO products must be sent to a VIZIO service center to obtain warranty service. VIZIO is not responsible for transportation costs to the service center, but VIZIO will cover return shipping to the customer.

What This Warranty Does Not Cover

This warranty does not cover: (a) cosmetic damage; (b) normal wear and tear; (c) improper operation; (d) improper voltage supply or power surges; (e) signal issues; (f) damage from shipping; (g) acts of God; (h) customer misuse, modications or adjustments; (i) installation, set-up, or repairs attempted by anyone other than by a VIZIO authorized service center; (j) products with unreadable or removed serial numbers; (k) products requiring routine maintenance; or (l) products sold “AS IS”, “CLEARANCE”, “FACTORY RECERTIFIED”, or by a non-authorized reseller.

What to Do If You Are Not Satised With Service

If you feel VIZIO has not met its obligations under this warranty, you may attempt to resolve the issue informally with VIZIO. If you are unable to

resolve the issue informally and wish to le a formal claim against VIZIO,

and if you are a resident of the United States, you must submit your claim to binding arbitration according to the procedures described below, unless an exception applies. Submitting a claim to binding arbitration means that you do not have the right to have your claim heard by a judge or jury. Instead your claim will be heard by a neutral arbitrator.

Binding Arbitration Agreement; Class Action Waiver (U.S. Residents Only)

UNLESS YOU HAVE BROUGHT AN ELIGIBLE CLAIM IN SMALL CLAIMS COURT OR HAVE OPTED OUT AS DESCRIBED BELOW, ANY CONTROVERSY OR CLAIM RELATING IN ANY WAY TO YOUR VIZIO PRODUCT, INCLUDING ANY CONTROVERSY OR CLAIM ARISING OUT OF OR RELATING TO THIS WARRANTY, A BREACH OF THIS WARRANTY, OR THE VIZIO PRODUCT’S SALE, CONDITION OR PERFORMANCE, WILL BE SETTLED BY BINDING ARBITRATION ADMINISTERED BY THE AMERICAN ARBITRATION ASSOCIATION AND CONDUCTED BY A SINGLE ARBITRATOR APPOINTED BY THE AMERICAN ARBITRATION ASSOCIATION, IN ACCORDANCE WITH ITS COMMERCIAL ARBITRATION RULES AND ITS SUPPLEMENTARY PROCEDURES FOR CONSUMER-RELATED DISPUTES. You may learn more about the American Arbitration Association and its rules for arbitration by visiting www.adr.org or by calling 800-778-7879. Since this warranty concerns a transaction in interstate or international commerce, the Federal Arbitration Act will apply.

The ling fees to begin and carry out arbitration will be shared between

you and VIZIO, but in no event will your fees ever exceed the amount allowable by the American Arbitration Association, at which point VIZIO will cover all additional administrative fees and expenses. VIZIO waives its

right to recover attorneys’ fees in connection with any arbitration under this warranty. If you are the prevailing party in an arbitration to which the Supplementary Procedures for Consumer-Related Disputes applies, then you are entitled to recover attorneys’ fees as the arbitrator may determine. The dispute will be governed by the laws of the state or territory in which you resided at the time of your purchase (if in the United States). The place of arbitration will be Irvine, California, or your county of residence (if in the United States). The arbitrator will have no authority to award punitive or other damages not measured by the prevailing party’s actual damages, except as may be required by statute. The arbitrator will not award consequential damages, and any award will be limited to monetary damages and will include no equitable relief, injunction, or direction to any party other than the direction to pay a monetary amount. Judgment

on the award rendered by the arbitrator will be binding and nal, except

for any right of appeal provided by the Federal Arbitration Act, and may be entered in any court having jurisdiction. Except as may be required by law, neither you nor VIZIO nor an arbitrator may disclose the existence, content, or results of any arbitration under this warranty without the prior written consent of you and VIZIO. ANY DISPUTE, WHETHER IN ARBITRATION, IN COURT, OR OTHERWISE, WILL BE CONDUCTED SOLELY ON AN INDIVIDUAL BASIS. VIZIO AND YOU AGREE THAT NO PARTY WILL HAVE THE RIGHT OR AUTHORITY FOR ANY DISPUTE TO BE ARBITRATED AS A CLASS ACTION, A PRIVATE ATTORNEY GENERAL ACTION, OR IN ANY OTHER PROCEEDING IN WHICH EITHER PARTY ACTS OR PROPOSES TO ACT IN A REPRESENTATIVE CAPACITY. NO ARBITRATION OR PROCEEDING WILL BE JOINED, CONSOLIDATED, OR COMBINED WITH ANOTHER ARBITRATION OR PROCEEDING WITHOUT THE PRIOR WRITTEN CONSENT OF ALL PARTIES TO ANY SUCH ARBITRATION OR PROCEEDING. Exceptions to Binding Arbitration Agreement and Class Action Waiver IF YOU DO NOT WISH TO BE BOUND BY THE BINDING ARBITRATION AGREEMENT AND CLASS ACTION WAIVER, THEN: (1) you must notify VIZIO in writing within sixty (60) days of the date that you purchased the

product; (2) your written notication must be mailed to VIZIO at 39 Tesla, Irvine, CA 92618, Attn: Legal Department; and (3) your written notication

must include (a) your name, (b) your address, (c) the date you purchased the product, and (d) a clear statement that you wish to opt out of the binding arbitration agreement and class action waiver. In addition, you may pursue a claim in small claims court in your county of residence (if in the United States) or in Orange County, California. In such

case the provisions of the section titled “Binding Arbitration Agreement;

Class Action Waiver (U.S. Residents)” will not apply.

Exclusions and Limitations

TO THE GREATEST EXTENT PERMITTED BY APPLICABLE LAW, THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE DESCRIBED ABOVE.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WILL BE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. VIZIO WILL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR LOST PROFITS, OR OTHER INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF VIZIO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND EVEN IF THE REMEDY FAILS OF ITS ESSENTIAL PURPOSE. SOME STATES AND PROVINCES DO NOT ALLOW

THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY

TO YOU. IN LIEU OF ANY OTHER REMEDY FOR ANY AND ALL LOSSES AND DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER (INCLUDING VIZIO’S NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS, NO MATTER WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT), VIZIO MAY,

AT ITS SOLE AND EXCLUSIVE OPTION AND IN ITS DISCRETION, REPAIR

OR REPLACE YOUR PRODUCT, OR REFUND ITS PURCHASE PRICE. AS

NOTED, SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION

OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE

ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

How the Law Applies

This warranty gives you specic legal rights, and you may also have other

rights, which vary from state to state and province to province. This warranty applies to the greatest extent permitted by applicable law.

General

No employee or agent of VIZIO may modify this warranty. If any term of this warranty, other than the class action waiver, is found to be unenforceable, that term will be severed from this warranty and all other terms will

remain in eect. If the class action waiver is found to be unenforceable,

then the entire section titled “Binding Arbitration Agreement; Class Action

Waiver (U.S. Residents Only)” will not apply. This warranty applies to the maximum extent not prohibited by law.

Changes to Warranty

This warranty may change without notice, but any change will not aect

your original warranty. Check www.vizio.com for the most current version.

Mexico Limited Warranty

VIZIO PRODUCT, PLEASE READ THIS WARRANTY CAREFULLY. IF YOU DO NOT AGREE TO THE TERMS OF THIS WARRANTY, DO NOT USE THE VIZIO PRODUCT AND, WITHIN THIRTY (30) DAYS OF THE DATE OF PURCHASE, RETURN IT FOR A REFUND TO THE AUTHORIZED RETAILER WHERE YOU PURCHASED IT.

Warrantor

The warrantor under this warranty is VIZIO Sales & Marketing Mexico S. de R.L. de C.V.

How Long This Warranty Lasts

What This Warranty Covers

VIZIO warrants the product against defects in materials and workmanship when the product is used normally in accordance with VIZIO’s user guides and manuals. Except where restricted by law, this warranty applies only to the original purchaser of a new product. The purchase must have been made from an authorized retailer in Mexico. The product must also be located in Mexico at the time of warranty service.

Zero Bright Pixel Defect Guarantee (Displays Only)

Your product may qualify for a warranty against “zero bright pixel”

defects for the duration of the warranty on select new product purchases. To determine if this guarantee applies to your product, refer to the model’s product information page at www.vizio.mx,

look for the “zero bright pixel” guarantee on the box, or contact

VIZIO Technical Support at the email address or telephone number below.

How to Get Service

Before obtaining warranty service, you may visit www.vizio. mx for additional help and troubleshooting. To obtain warranty

service, contact VIZIO Technical Support via email at serviciovizio@

warrantyserviceslatinamerica.com or via phone at 01-800-8010096 or 001-855-472-7444. The VIZIO Technical Support hours are 9:00AM to 6:00PM Monday through Friday, Central Standard Time.

Your Obligations Before Service

the product in its original packaging or in packaging that aords

an equal degree of protection. VIZIO Technical Support will provide instructions for packing and shipping the product to the VIZIO service center. ALL USER DATA AND DOWNLOADED APPLICATIONS STORED ON A PRODUCT WILL BE DELETED IN THE COURSE OF SOME IN-HOME AND ALL SHIP-IN WARRANTY SERVICE. If this occurs, your product will be restored to its original state. You will be responsible for restoring all applicable user data and downloaded applications. Recovery and reinstallation of user data and downloaded applications is not covered under this warranty. In order to protect your personal information, VIZIO recommends that you always clear all personal information from the product before it is serviced, regardless of the servicer.

VIZIO’s Responsibilities

period. Replacement parts may be new or recertied at VIZIO’s

option and sole discretion. Replacement parts and VIZIO’s labor are warranted for the remaining portion of the original warranty or for ninety (90) days from warranty service, whichever is longer.

Types of Service

Displays that are 32 inches or larger will usually be serviced in-

home. In-home service requires complete and easy access to the product and does not include de-installation or re-installation of the product. In-home service is subject to availability. VIZIO will provide other service options when in-home service is not available. All other VIZIO products must be sent to a VIZIO service center to obtain warranty service. VIZIO is not responsible for transportation costs to the service center, but VIZIO will cover return shipping to the customer.

What This Warranty Does Not Cover

(i) installation, set-up, or repairs attempted by anyone other than

by a VIZIO authorized service center; (j) products with unreadable or removed serial numbers; (k) products requiring routine maintenance; or (l) products sold “AS IS”, “CLEARANCE”, “FACTORY

RECERTIFIED”, or by a non-authorized reseller.

What to Do If You Are Not Satised With Service

If you feel VIZIO has not met its obligations under this warranty, you may attempt to resolve the issue informally with VIZIO. If you

are unable to resolve the issue informally and wish to le a formal

claim against VIZIO, you may do so.

Exclusions and Limitations

TO THE GREATEST EXTENT PERMITTED BY APPLICABLE LAW, THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE DESCRIBED

ABOVE. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WILL BE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

VIZIO WILL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR LOST PROFITS, OR OTHER INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF VIZIO HAS BEEN ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES, AND EVEN IF THE REMEDY FAILS OF ITS ESSENTIAL PURPOSE. SOME STATES AND PROVINCES

DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU.

IN LIEU OF ANY OTHER REMEDY FOR ANY AND ALL LOSSES AND DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER (INCLUDING VIZIO’S NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS, NO MATTER WHETHER SUCH DEFECTS ARE DISCOVERABLE OR

LATENT), VIZIO MAY, AT ITS SOLE AND EXCLUSIVE OPTION AND IN

ITS DISCRETION, REPAIR OR REPLACE YOUR PRODUCT, OR REFUND ITS PURCHASE PRICE. AS NOTED, SOME STATES AND PROVINCES

DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU.

How the Law Applies

This warranty gives you specic legal rights, and you may also

have other rights, which vary from state to state and province to province. This warranty applies to the greatest extent permitted by applicable law.

General

No employee or agent of VIZIO may modify this warranty. If any term of this warranty is found to be unenforceable, that term will be severed from this warranty and all other terms will remain in

eect. This warranty applies to the maximum extent not prohibited

by law.

Changes to Warranty

This warranty may change without notice, but any change will not

aect your original warranty. Check www.vizio.mx for the most

current version.

VIZIO Sales & Marketing Mexico S. de R.L. de C.V. PRESIDENTE MASARYK 111, Of 152 - Of 111 COL. POLANCO V SECCIÓN

DELEGACION MIGUEL HIDALGO, MEXICO D.F. 11560

Warranty Service Provider Warranty Support LATAM SA de C.V. Calle Nubes No. 412 Col. Jardines del Moral Leon Gto. Mexico, C.P. 37160 01-800-801-0096 or 001-855-472-7444 Date of purchase: Model: Brand: To make a warranty claim, present your product and either this warranty, duly stamped by the establishment from whom you purchased the VIZIO product, or a valid invoice or receipt showing the date of purchase. Under the terms of this warranty, VIZIO or its representative must exchange parts and components of the product and include labor and shipping expenses of the product on which this warranty is valid, within the service network, at no cost to the consumer. VIZIO is not obligated to honor the warranty in the following cases. (a) When the product has been used under other than normal conditions. (b) When the product has not been operated according to the accompanying instructions for use. (c) When the product has been altered or repaired by persons not authorized by VIZIO or the respective seller.

INFORMATION EXCLUSIVELY FOR MEXICO

To make a warranty claim, or to obtain parts, components, supplies and accessories, you may contact the importer of record, the warranty service provider, or the establishment from whom you purchased the VIZIO product.

Importer of Record

DLegal Information

Software Licenses

All software is provided subject to a software license agreement(s) and you agree that you will be bound by such license agreement(s) in addition to these terms. Your use of this product is subject to VIZIO’s

Export Regulations

Customer acknowledges that the VIZIO products, which include technology and software, are subject to customs and export control

laws in the United States (“US”). The products may also be subject to

the customs and export control laws and regulations of the country in which the products are manufactured and/or received.

Internet Connectivity

Network conditions, environmental and other factors may negatively

aect connectivity and the resulting video quality, if any.

The applications and content of the applications pictured herein or described in accompanying documentation may only be available in certain countries or languages, may require additional fees or subscription charges, and may be subject to future updates,

modications or discontinuation without notice. VIZIO has no

control over third party applications or content and assumes no responsibility for the availability or interruption of such applications or content. Additional third party terms, conditions and restrictions apply. Information in this Quick Start Guide is subject to change without notice. To review the most updated version of this Quick Start Guide and the associated User Manual, go to http://www.vizio.com.

congurations, performance, design and other product information

described herein are subject to change without notice. VIZIO, Inc. is not responsible for typographical, technical, or descriptive errors.

VIZIO, the VIZIO logo, the V logo, and other terms and phrases are trademarks or registered trademarks of VIZIO, Inc.

HDMI, HDMI High-Denition Multimedia Interface, and the HDMI

Logo are trademarks or registered trademarks of HDMI Licensing LLC.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Used under license.

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Studio Sound is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.

Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.

Other names of companies, products, and services used in this Quick Start Guide may be trademarks, trade names or service marks of others and VIZIO, Inc. dis- claims any interest in trademarks, trade names or service marks other than its own. Mention of non-VIZIO products is for informational purposes only.

If you are traveling internationally, check the customs regulations for device use for each country you will visit, and check the power cord and adapter requirements for each location in which you plan

to use the computer as voltage, frequency and plug congurations

may vary.

Warning: To reduce risk of electric shock, re or

damage to your device or other property, do not attempt to power the device with a voltage converter kit sold for appliances.

Battery Disposal

Caution: Battery cells may explode. Do not dispose of

the battery in a re or with ordinary household waste.

Dispose of batteries promptly. Replace the battery only with the same or equivalent type of battery recommended by VIZIO.

This Quick Start Guide may not be copied in whole or in part without the written permission of VIZIO, Inc. VIZIO, Inc. has made

reasonable eorts to ensure the accuracy of the information provided herein. All product specications, functionality, features,

Caution: Avoid exposing a drive to magnetic elds. Security devices with magnetic elds may include

airport walk-through devices and security wands. Airport conveyor belts or similar security devices that

check carry-on luggage generally use X-rays and should

not cause magnetic damage to drives.

Vizio D39hn-E1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
