Vizio D32H-G9 User Manual

USER MANUAL

Models: D24h-G9, D32h-G9, D40f-G9, D50x-G9, V405-G9, V505-G9 & V655-G9



Safety & Certication

THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO TV.

To get the most out of your new VIZIO product, read these instructions
before using your product and retain them for future reference. Be
sure to inspect the package contents to ensure there are no missing or
damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services for
your VIZIO product, visit our website at www.VIZIO.com or call toll free at
[phone].

We recommend that you register your VIZIO product at www.VIZIO.com.

EXTENDED WARRANTIES

For peace of mind, and to protect your investment beyond the standard

warranty, VIZIO oers on-site extended warranty service plans. These

plans provide additional coverage during the standard warranty period.
To purchase an extended warranty service plan, visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the accompanying
important warning or notice. It is intended to alert you to
the presence of important operating instructions.

When you see this symbol, please read the accompanying
helpful tip.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within dened design
limits. Misuse may result in electric shock or re. To prevent your TV

from being damaged, the following instructions should be observed for
the installation, use, and maintenance of your TV. Read the following
safety instructions before operating your TV. Keep these instructions in a
safe place for future reference.

• To reduce the risk of electric shock or component damage, switch o
the power before connecting other components to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the

provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.

• Only use attachments/accessories specied by the manufacturer.

• Use only with the cart, stand, tripod, bracket, or table

specied by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for
long periods of time.

• Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature to an area
of high temperature, condensation may form in the housing. Wait

before turning on your TV to avoid causing re, electric shock, or

component damage.

• A distance of at least three feet should be maintained between your

TV and any heat source, such as a radiator, heater, oven, amplier

etc. Do not install your TV close to smoke. Operating your TV close to

smoke or moisture may cause re or electric shock.

• Slots and openings in the back and bottom of the cabinet are
provided for ventilation. To ensure reliable operation of your TV
and to protect it from overheating, be sure these openings are not
blocked or covered. Do not place your TV in a bookcase or cabinet
unless proper ventilation is provided.

• Never push any object into the slots and openings on your TV
cabinet. Do not place any objects on the top of your TV. Doing so

could short circuit parts causing a re or electric shock. Never spill

liquids on your TV.

• Your TV should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power
supplied to your home, consult your dealer or local power company.

• Do not apply pressure or throw objects at your TV. This may
compromise the integrity of the TV. The manufacturer’s warranty
does not cover user abuse or improper installations.

• The power cord must be replaced when using dierent voltage than

the voltage specied. For more information, contact your dealer.

• When connected to a power outlet, power is always owing into your
TV. To totally disconnect power, unplug the power cord.

• The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of
un-isolated, dangerous voltage within the inside of your TV that

may be of sucient magnitude to constitute a risk of electric

shock to persons.

• Do not overload power strips and extension cords. Overloading can

result in re or electric shock.

• The wall socket should be installed near your TV
and easily accessible.

ii

• Only power of the marked voltage can be used for your TV. Any other

voltage than the specied voltage may cause re or electric shock.

• Do not touch the power cord during lightning. To avoid electric shock,
avoid handling the power cord during electrical storms.

• Unplug your TV during a lightning storm or when it will not be used
for long period of time. This will protect your TV from damage due to
power surges.

• Do not attempt to repair or service your TV yourself. Opening or
removing the back cover may expose you to high voltages, electric
shock, and other hazards. If repair is required, contact your dealer

and refer all servicing to qualied service personnel.

• WARNING: Keep your TV away from moisture. Do not expose your TV to
rain or moisture. If water penetrates into your TV, unplug the power cord

and contact your dealer. Continuous use in this case may result in re or

electric shock.

• Do not use your TV if any abnormality occurs. If any smoke or odor
becomes apparent, unplug the power cord and contact your dealer
immediately. Do not try to repair your TV yourself.

• Avoid using dropped or damaged appliances. If your TV is dropped
and the housing is damaged, the internal components may function
abnormally. Unplug the power cord immediately and contact your

dealer for repair. Continued use of your TV may cause re or electric

shock.

• Do not install your TV in an area with heavy dust or high humidity.
Operating your TV in environments with heavy dust or high humidity

may cause re or electric shock.

• Follow instructions for moving your TV. Ensure that the power cord
and any other cables are unplugged before moving your TV.

• To prevent injury, this apparatus must be securely attached to the

oor/wall in accordance with the installation instructions.

• When unplugging your TV,grab the head of the power plug, not the
cord. Pulling on the power cord may damage the wires inside the

cord and cause re or electric shock. When your TV will not be used

for an extended period of time, unplug the power cord.

• To reduce risk of electric shock, do not touch the connector with wet
hands.

• Insert batteries in accordance with instructions. Incorrect polarities
may cause the batteries to leak which can damage the remote control
or injure the operator. Do not expose batteries to excessive heat

such as sunshine, re or the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

- Your TV is exposed to rain or other moisture.

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

• This apparatus shall not be exposed to dripping or splashing and

no objects lled with liquids, such as vases, shall be placed on

the apparatus.

• The mains plug or appliance coupler is used as the disconnect device,
the disconnect device shall remain readily operable.

• CAUTION: These servicing instructions are for use by qualied

service personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the operating

instructions unless you are qualied to do so.

• The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated

DANGEROUS VOLTAGE within the product’s enclosure that may be
of sucient magnitude to constitute a risk of electrical shock to

persons.

• WARNING: Exposure to loud sounds can damage your hearing
causing hearing loss and tinnitus (ringing or buzzing in the ears). With

continued exposure to loud noises, ears may become accustomed to

the sound level, which may result in permanent damage to hearing
without any noticeable discomfort.

• Install the TV where it cannot be pulled, pushed or knocked over.

• Do not allow children to hang onto the product.

• Store the accessories (remote, batteries, etc.) in a location safely out
of the reach of children.

• The American Academy of Pediatrics discourages television viewing
for children younger than two years of age.

• WARNING: Never place a television set in an unstable
location. A television set may fall, causing serious personal
injury or death.

• Many injuries, particularly to children, can be avoided by
taking simple precautions such as:

• Using cabinets or stands recommended by the manufacturer of the
television set.

• Only using furniture that can safely support the television set.

• Ensuring the television set is not overhanging the edge of the
supporting furniture.

• Not placing the television set on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture and
the television set to a suitable support.

• Not placing the television set on cloth or other materials that may be
located between the television set and the supporting furniture.

• Educating children about the dangers of climbing on furniture to
reach the television set or its controls.

• If your existing television set is being retained and relocated, the
same considerations as above should be applied.

• WARNING: To prevent injury, this apparatus must be securely

attached to the oor/wall in accordance with the installation

instructions.

iii

TELEVISION ANTENNA CONNECTION PROTECTION

If an outside antenna/satellite dish or cable system is to be connected
to the TV, make sure that the antenna or cable system is electrically
grounded to provide some protection against voltage surges and static
charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides

information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit,
size of the grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements of the grounding
electrode.

Lightning Protection

For added protection of the TV during a lightning storm, or when it is left
unattended or unused for long periods of time, unplug the TV from the
wall outlet and disconnect the antenna or cable system.

Power Lines

Do not locate the antenna near overhead light or power circuits, or
where it could fall into such power lines or circuits. Remember, the
screen of the coaxial cable is intended to be connected to earth in the
building installation.

Ground Clamp

Antenna Lead In Wire

Antenna Discharge Unit

(NEC Section 810-20)

Grounding Conductors

(NEC Section 810-21)

Ground Clamps

Electric Service Equipment

Power Service Grounding Electrode System

(NEC ART 250, part H)

iv

For DTS patents, see http://patents.dts.com.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS, Inc. DTS, the Symbol,
DTS and the Symbol together, and DTS Studio Sound are
registered trademarks and/or trademarks of DTS, Inc. in the
United States and/or other countries. © DTS, Inc. All Rights

Reserved.

Manufactured under license from Dolby Laboratories. Dolby,
Dolby Audio, and the double-D symbol are trademarks of
Dolby Laboratories.

Manufactured under license from DTS, Inc. DTS, the Symbol,
DTS and the Symbol together, and DTS Studio Sound II are
registered trademarks and/or trademarks of DTS, Inc. in the
United States and/or other countries. © DTS, Inc. All Rights

Reserved.

* Only available on D50x-G9, V405-G9, V505-G9 and V655-G9

The terms HDMI, HDMI High-Denition Multimedia Interface,

and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing Administrator, Inc.

v

Table Of Contents

Getting to Know Your TV .............................................7

Front Panel .......................................................................................... 7

Rear Panel ...........................................................................................8

Connecting Your Devices ...................................................................11

Wall-mounting the TV ......................................................................... 14

Using the Remote ...............................................................................15

Completing The First-Time Setup ...............................16

Using the On-Screen Menu .........................................17

Navigating the On-Screen Menu ........................................................ 17

Changing the Input Source ................................................................ 17

Changing the Screen Aspect Ratio ..................................................... 18

Adjusting the Picture Settings ............................................................ 19

Adjusting More Picture Settings ..................................................... 19

Adjusting the Color Temperature ................................................... 20

Adjusting the Picture Mode Edit Settings ......................................20

Saving a Custom Picture Mode ....................................................... 20

Locking/Unlocking a Custom Picture Mode ................................... 21

Deleting a Custom Picture Mode .................................................... 21

Resetting a Picture Mode ................................................................ 21

Adjusting the Color Tuner Settings ................................................22

Adjusting the Audio Settings .............................................................. 24

Adjusting the Network Settings ......................................................... 25

Setting Timers ..................................................................................... 27

Setting the Timer ............................................................................. 27

Setting the Auto Power O Feature ...............................................27

Setting Up Channels ........................................................................... 28

Scanning for Channels ....................................................................28

Skipping Channels ...........................................................................28

Listening to Alternate Audio ..............................................................29

Changing the Analog Audio Language ...........................................29

Parental controls ................................................................................30

Using Parental Controls ..................................................................30

Enabling or Disabling Program Ratings .........................................30

Locking and Unlocking Channels .................................................... 30

Blocking and Unblocking Content by Rating .................................30

Setting Up Closed Captioning ............................................................ 31

Changing the Appearance of Digital Closed Captions ..................31

Renaming Devices on the Input Menu .............................................. 33

Changing the TV Settings ................................................................... 34

Viewing System Information ........................................................... 34

Changing the On-Screen Menu Language .....................................34

Setting the Time and Local Settings ............................................... 35

Adjusting the CEC Settings .............................................................. 35

Changing the TV Name .................................................................... 36

Using the Reset & Admin Menu ......................................................... 37

Restoring the TV to Factory Default Settings ................................. 37

Turning the Power Indicator On or O .......................................... 37

Using the Info Window .......................................................................39

SmartCast HomeSM ........................................................40

What is SmartCast Home? ............................................................... 40

What You Can Do with SmartCast Home ....................................... 40

How to Launch SmartCast Home ...................................................40

WatchFree.....................................................................41

What is WatchFree? .........................................................................41

What You Can Do with WatchFree..................................................41

How to Launch WatchFree .............................................................. 41

Playing USB Media .......................................................42

Displaying USB Media .........................................................................42

Preparing Your USB Drive to Play USB Media ............................... 42

Removing the USB Drive from the TV ............................................42

Troubleshooting & Technical Support ........................46

Specications ...............................................................50

Regulatory Information ...............................................52

Limited Warranty .........................................................53

Legal Information.........................................................55

vi

Getting to Know Your TV

FRONT PANEL

1

Remote Sensor and Power Indicator

When using the remote, aim it directly at this sensor. The power indicator ashes on when the TV turns on, then goes out after several seconds.

To keep the power indicator on as long as the TV is on, see

Turning the Power Indicator On or O.

7

Rear Panel - D24h-G9

Stereo Audio Out - Connect 3.5 mm audio device, such as a headset or sound bar.

1

HDMI - Connect an HDMI device.

Composite - Connect a composite.

Video/ L/R

Coaxial - Connect to a coaxial cable from cable, satellite, or antenna.

USB - Connect a USB thumb drive to play photo, music, or video.

Optical Audio Out - Connect to an optical/SPDIF audio device, such as home audio receiver.

Power - Press to turn on the TV. Press and hold to turn the TV o.

Volume - Press to increase or decrease the TV volume level.

Input - Press to access the input menu.

VOL

INPUT

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

8

1

Rear Panel - D40f-G9

HDMI - Connect an HDMI device.

Component/Composite - Connect a component or composite.

Audio Out - Connect to an RCA device, such as sound bar.

Coaxial - Connect to a coaxial cable from cable, satellite, or antenna.

USB - Connect a USB thumb drive to play photo, music, or video.

Optical Audio Out - Connect to an optical/SPDIF audio device, such as home audio receiver.

Ethernet - Connect an Ethernet cable to modem/ router.

Power - Press to turn on the TV. Press and hold to turn the TV o.

Volume - Press to increase or decrease the TV volume level.

Input - Press to access the input menu.

VOL

INPUT

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

9

Rear Panel - D32h-G9, D50x-G9, V405-G9, V505-G9 & V655-G9

Composite - Connect a composite device.

Audio Out - Connect to an RCA device, such as sound bar.

1

HDMI - Connect an HDMI device.

Coaxial - Connect to a coaxial cable from cable, satellite, or antenna.

USB - Connect a USB thumb drive to play photo, music, or video.

Optical Audio Out - Connect to an optical/SPDIF audio device, such as home audio receiver.

Ethernet - Connect an Ethernet cable to modem/ router.

Power - Press to turn on the TV. Press and hold to turn the TV o.

Volume - Press to increase or decrease the TV volume level.

Input - Press to access the input menu.

VOL

INPUT

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

10

Connecting Your Devices

Optical

Standard

RCA

Optical

Standard

RCA

RCA To 3

5mm

Optical

Standard

RCA

Optical

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Optical

Standard

RCA

RCA To 3

5mm

Optical

Standard

RCA

RCA To 3

5mm

CONNECTING A DEVICE - AUDIO & VIDEO CABLE TYPES

Your TV can be used to display output from most devices.

1. Verify that your device has a video port that matches an available port on the TV (HDMI, Component, etc.).

2. Connect the appropriate cable (not included) to the TV and the device.

3. Turn the TV and your device on. Set the TV’s input to match the connection you used (HDMI-1, HDMI-2, etc.).

1

HDMI CABLE

HDMI

COMPONENT CABLE

R L YPr/Cr Pb/Cb

COMPOSITE (AV) CABLE

(Shared with Component input)

Y L R

COAXIAL CABLE

Coaxial

Note: The actual ports and their locations may

vary, depending on the TV model.

11

CONNECTING A DEVICE - D24h-G9 ONLY

Optical

Standard

RCA

RCA To 3

5mm

Optical

Standard

RCA

RCA To 3

5mm

HDMI

Standard

RCA

RCA To 3

5mm

HDMI

RCA To 3

5mm

HDMI

HDMI

Optical

Standard

RCA

RCA To 3

5mm

D24h-G9 includes a Composite In / AV In port that requires additional adapters (not included).

1. Connect the appropriate cable (not included) to the TV and the device using an adapter (not included).

2. Turn the TV and your device on. Set the TV’s input to match the connection you used (Composite).

1

Composite input on

back of TV*

Video/ L/R

Connecting to a composite device

Video / Audio L/R

Adapter (Not Included)

Composite Connection

on Your Device

*The actual ports and their locations may vary, depending on the TV model.

12

CONNECTING A DEVICE - AUDIO CABLE TYPES

Optical

Standard

RCA

RCA To 3

5mm

Optical

Standard

RCA

Your TV can be output sound to an audio device, such as a receiver or sound bar.

1. Verify that your device has audio port that matches an available port on the TV (Optical, RCA, etc).

2. Connect the appropriate cable (not included) to the TV and the device.

3. Turn the TV and your device on.

1

OPTICAL/SPDIF CABLERCA CABLEHDMI CABLE

Note: The actual ports and their locations may vary,

depending on the TV model.

HDMI

RL

Optical

13

WALL-MOUNTING THE TV

To mount your TV on a wall, you will need a wall mount. Consult the

information on this page to nd the appropriate mount for your TV.

Be sure the mount you choose is capable of supporting the weight of the TV.
After you have determined that you have the correct mount for your TV, you
can begin the installation.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. Place the TV face-down on a clean, at, stable surface. Be sure the surface
is clear of debris that can scratch or damage the TV.

3. If attached, remove the stands by loosening and removing the screws.

4. Attach your TV and wall mount to the wall, carefully following the
instructions that came with your mount. Use only with a UL-listed wall
mount bracket rated for the weight/load of this TV.

1

Installing a TV on a wall requires lifting. To prevent injury or
damage to the TV, ask someone to help you.

Note: The image shown here is for illustrative purposes only and may be subject to change.

The actual number of ports and their locations may vary, depending on the model.

D24h-G9 D32h-G9 D40f-G9 D50x-G9 V405-G9 V505-G9 V655-G9

Screw Size: M4 M4 M6 M6 M6 M6 M6

Hole Depth: 8.5 mm 8.5 mm 10 mm 9 mm 10 mm 9 mm 9 mm

Hole Pattern: 100 mm x 100 mm 100 mm x 100 mm 200 mm x 200 mm 200 mm x 200 mm 200 mm x 200 mm 200 mm x 200 mm 400 mm x 200 mm

Weight w/o Stand: 6.90 lb (3.13 kg) 9.26 lb (4.20 kg) 14.33 lb (6.5 kg) 21.32 lb (9.67 kg) 14.99 lbs (6.80 kg) 21.32 lb (9.67 kg) 45.81 lb (20.78 kg)

14

1

USING THE REMOTE

1

INPUT

3

4

EXIT

6

BACK

10

11

OK

CC

Replacing the Batteries

1. Find the notch on the back of the remote. Insert a coin and pry open

2

the back cover.

1. Input - Change the currently displayed input

5

MENU

2. Power - Turn Television on or o

3. App Launcher - Quickly launch the pictured app

4. Exit - Close the on-screen menu

5. Menu - Display the settings menu

6. Arrow - Navigate the on-screen menus

7

7. OK/Play/Pause - Select the highlighted menu option and play or pause content

2. Insert two batteries into the remote control. Make sure that the (+)
and (-) symbols on the batteries match the (+) and (-) symbols inside
the battery compartment.

3. Replace the battery cover.

8. Back - Go to the previous on-screen menu

98

INFO

9. Info - Display the info window

10. Volume Up/Down - Increase or decrease the loudness of the audio

14

11. Closed Caption - Open the closed caption menu

12

VOL CH

13

PIC

15

1

2

17

4

7

5

8

0

18

3

6

9

16

19

12. V Button - Launch SmartCast Home/Return to SmartCast Home Screen

13. Pic - Cycle through the dierent picture setting modes

14. Channel Up/Down- Change the channel

15. Mute - Turn the audio on or o

16. Last - Return to the channel last viewed

17. Number Pad - Manually enter a channel

18. Wide - Change the Television mode

19. Dash - Use with number pad to manually enter a digital sub-channel

(For example, 18-4 or 18-5)

In many places batteries cannot be thrown away or discarded with household waste. Please ensure you
properly dispose of your batteries consistent with the laws and/or regulations where you live. For more
information please visit: www.vizio.com/environment

WARNING: keep the remote control batteries away from

children. It may cause choking and/or lead to a re or

chemical burn if mishandled. Do not dispose of batteries

inre. Replace only with batteries of the correct type.

When needed, VIZIO recommends
replacing the batteries that came with
this remote with two, new Duracell ‘AAA’
alkaline batteries

15

Completing The First-Time Setup

Choose a Wi-Fi Network.

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Choose a Wi-Fi Network.

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Choose a Wi-Fi Network.

Which room is your VIZIO TV Located?

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Family Room

Add Custom Location

Living Room

Master

Bedroom Game Room

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Choose a language for your TV.

English

Español Français

Back

Français

Choose a Wi-Fi Network.

Which room is your VIZIO TV Located?

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Family Room

Add Custom Location

Living Room

Master

Bedroom Game Room

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Choose a language for your TV.

English

Español Français

Back

Français

How are you using your TV?

Home Use

Store Demo

Choose a Wi-Fi Network.

Which room is your VIZIO TV Located?

Home Network

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Family Room

Add Custom Location

Living Room

Master

Bedroom Game Room

Let’s set up local channels.

Next

Skip

To search for local broadcast channels, make sure the cable from the

antenna, wall or cable box is properly connected to your VIZIO TV.

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

Congratulations!

Start streaming your favorite

shows now!

Start Watching

By the way...

You can turn your phone into the ultimate remote. The
VIZIO SmartCast

TM

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

Terms & Conditions.

Skip For Now Accept All

VIZIO Terms &

Conditions

VIZIO Privacy

Policy

Google Privacy

Policy

Google Terms &

Conditons

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

The rst time you turn on the TV, the on-screen instructions will guide you through each of the steps necessary to get your TV ready for use.

Before you begin the rst-time setup:

• Your TV should be installed and the power cord should be connected to an electrical outlet.

• If you have a wireless network, have the network password ready.

• If you are connecting to your network with an Ethernet cable, connect it to the Ethernet port on the TV.

2

Choose a language for your TV.

1. Choose your language. 2. Choose home use. 3. Choose your country. 4. Choose your Wi-Fi and enter the password.

English

Which room is your VIZIO TV Located?

Family Room

Living Room

Español Français

Back

Master

Français

Bedroom Game Room

How are you using your TV?

Home Use

Let’s set up local channels.

To search for local broadcast channels, make sure the cable from the

antenna, wall or cable box is properly connected to your VIZIO TV.

Next

Skip

Store Demo

Your use of this device and software functionality are covered by VIZIO and Google ‘s respective Terms of Service and Privacy Policies.

By pressing “Accept All”, you agree to be bound by the (i) VIZIO Terms of Service and Privacy Policy and (ii) the Google Terms of Service and Privacy

Policy. NOTE: Accepting the terms and policiesis a condition of using the Cast functionality of this device.

VIZIO Terms &

Conditions

Where is you VIZIO TV located?

USA

Terms & Conditions.

VIZIO Privacy

Policy

Mexico Canada

Google Privacy

Policy

Google Terms &

Conditons

Home Network

Choose a Wi-Fi Network.

Public Wi-Fi John’s Network Ana’s Network Encrypted

Rescan Networks Hotten Netwok Help Skip

Congratulations!

Start streaming your favorite

shows now!

Start Watching

Add Custom Location

5. Name your TV. 6. Scan for channels. 7. Accept the T&Cs and register your device.

Skip For Now Accept All

All set!

By the way...

You can turn your phone into the ultimate remote. The

TM

VIZIO SmartCast

App brings together TV Shows, movies,

and more from multiple apps into one simple experience.

Download now from the App Store or Google Play.

16

Using the On-Screen Menu

MENU

INPUT

OK

BACK

INFO

EXIT

3

Your TV features an easy-to-use on-screen menu.

To open the on-screen menu, press the Menu button on the remote.

From this menu, you can:

• Adjust the Picture settings

• Adjust the Audio settings

• Adjust the Network settings

• Set up the Timers

• Adjust the Channel settings

• Set up Closed Captioning

• Name and adjust Inputs

• Adjust TV settings

TV Settings


Audio

Network

Timers

Channels

Closed Captions

Input Settings

System

User Manual

• View the User Manual

NAVIGATING THE ON-SCREEN MENU

To open the on-screen menu:

1. Press the Menu button on the remote.

2. Use the Arrow buttons to highlight a
menu option, and press the OK button
to select that option.

CHANGING THE INPUT SOURCE

External devices, such as DVD players, Blu-ray Players, and video game
consoles, can be connected to your TV. To use one of these devices with

your TV, you must rst change the input source using the Input menu.

To change the input sources:

1. Press the Input button on the remote. The Input menu is displayed.

1

2. Use the Right/Left Arrow buttons or the Input button on the remote
to highlight the input you wish to view and press OK. The selected input
is displayed.

2

Change Input

Input Name

While navigating the on-screen menu, you can press the
Back button at any time to return to the previous menu
screen. The Exit button will close the on-screen menu.

SMARTCAST

HDMI-1WatchFree HDMI-2 COMP TV

Note: Inputs may vary by TV.

HDMI-3

HDMI-4

You can change the input names that appear on the

Input menu to make your devices easy to recognize. See

Renaming Devices on the Input Menu

for more information.

17

CHANGING THE SCREEN ASPECT RATIO

3

To change the screen aspect ratio:

1. Press the Wide button on the remote.

2. Use the Arrow buttons to highlight the aspect ratio you wish to view
and press OK.

Your TV can display images in dierent modes: Normal, Stretch, Wide,

Zoom, and Panoramic.

• Normal (default) – No change to aspect ratio.

• Stretch – When the 16:9 signal is a 4:3 image with black bars left and

right, stretches to ll the screen.

• Wide – Stretches a 4:3 aspect ratio to ll 16:9 screen. If a 16:9 image,

adds black bars to top and bottom.

• Zoom – Expands image both horizontally and vertically by 14%.

• Panoramic* - Stretches a 4:3 image to ll 16:9 screen with an

algorithm so the center doesn’t look stretched.

Some programs have black bars on the top or sides of the picture so that the

picture keeps its original shape. Examples include widescreen movies and
older television programs.

Normal

Stretch Wide Zoom

* Available aspect ratio settings may vary by input source. Panoramic mode is only available

for standard denition TV (480i/480p) and Stretch mode is only available for high denition
TV (720p/1080i/1080p).

Tip: The aspect ratio cannot be changed for Ultra HD
content or HDR content.

18

3

ADJUSTING THE PICTURE SETTINGS

Your TV can be adjusted to suit your preferences and viewing conditions.

If you save changes to the settings for a picture mode, an asterisk
appears after its name (see

To adjust the picture settings:

1. Press the Menu button on the remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the remote to highlight Picture and press
OK. The Picture menu is displayed.

3. Use the Arrow buttons on the remote to highlight Picture Mode,
then use the Left/Right Arrow buttons to change the picture mode:

• Standard mode sets the picture settings to the
default settings.

• Calibrated mode sets the picture settings to values ideal for
watching TV in a brightly-lit room.

• Calibrated Dark mode sets the picture settings to values ideal for
watching TV in a dark room.

• Vivid mode sets the picture settings to values that produce a
brighter, more vivid picture.

• Game mode reduces throughput delays and optimizes the picture
settings for displaying game console output.

• Computer mode optimizes the picture settings for displaying
computer output.

Saving a Custom Picture Mode

).

4. To manually change each of the picture settings, use the Up/
Down Arrow buttons on the remote to highlight that picture
setting, then use the Left/Right Arrow buttons to adjust the
setting:

• Backlight - Adjusts the LED

brightness to aect the overall

brilliance of the picture. Backlight
cannot be adjusted when starting
from some picture modes.

• Brightness - Adjusts the black
level of the picture. When this
setting is too low, the picture may
be too dark to distinguish details.
When this setting is too high,
the picture may appear faded or
washed out.

• Contrast - Adjusts the white
level of the picture. When this
setting is too low, the picture may
appear dark. When this setting is


Picture Mode Calibrated

Backlight 90

Brightness 50

Contrast 50

Color 50

Tint 0

Sharpness 20

More Picture

Picture Mode Edit

Color Calibration

Back

too high, the picture may appear
faded or washed out. If the setting
is too high or too low, detail may

be dicult to distinguish in dark

or bright areas of the picture.

• Color - Adjusts the intensity of the
picture colors.

• Tint - Adjusts the hue of the picture. This setting is useful in

adjusting the esh tones in the picture. If esh appears too

orange, reduce the level of color before adjusting tint.

• Sharpness - Adjusts the edge sharpness of picture elements.

It can be used to sharpen non-HD (high denition) content;

however, it will not produce detail that does not otherwise exist.

When you have nished adjusting the picture settings, press the Exit

button on the remote.

Adjusting More Picture Settings

To adjust more picture settings:

More Picture

Back

1. From the PICTURE menu, use the

Arrow buttons to highlight More
Picture, and then press OK.

2. Use the Arrow buttons to highlight
the setting you wish to adjust, then
press the Left/Right Arrow buttons to
change the setting:

• Color Temperature - See

Adjusting

the Color Temperature.

• Black Detail* - Adjusts the

Color Temperature Normal

Black Detail* Off

Backlight Control On

Reduce Noise

Game Low Latency Off

Film Mode* On

Color Space** Auto

Gamma 2.2

average brightness of the picture
to compensate for large areas of
brightness. Select O, Low, Medium,
or High.

• Backlight Control - When ON, it
will improve the contrast ratio of
the picture by adjusting backlight

zones. Specic adjustments are based

on content.

• Reduce Noise:

- Reduce Signal Noise - Diminishes artifacts in the image caused by
the digitizing of image motion content. Select O, Low, Medium, or

High.

- Reduce Block Noise - Reduces pixelation and distortion for mpeg

les. Select O, Low, Medium, or High.

• Game Low Latency - Select On to reduce video delay (lag)

when gaming.

• Film Mode* - Optimizes the picture for watching lm. Select Auto
or O.

• Color Space** – Select color space for the source. Video sources use

YCbCr, but PC uses RGB. Available for HDMI input only.

• Gamma - Set the shape of the Gamma curve. Use lower Gamma

values for bright room conditions, and higher values when it’s dark.

3. When you have nished adjusting More Picture Settings, press the Exit
button on the remote.

* Not applicable to D24h-G9

**Applicable models: D50x-G9, V505-G9, V405-G9 and V655-G9

19

3

Adjusting the Color Temperature

Adjusting the color temperature changes the white balance of the
picture.

To adjust the color temperature:

1. From the MORE PICTURE menu, use
the Arrow buttons to highlight Color

Color Temperature

Temperature, and then press OK.

2. Use the Arrow buttons on the remote
to highlight a color temperature preset
and then press OK.

Normal

Cool

Computer

• Normal is optimized for
television viewing.

• Cool produces a blue-hued picture.

• Computer optimizes the

picture for use as a
PC monitor.

3. When you have nished adjusting
the color temperature, press the Exit
button on the remote.

Back

Adjusting the Picture Mode Edit Settings

Picture Mode Edit Settings allow you to make precise adjustments to the

picture and to create picture modes to save groups of picture settings.

To adjust the Picture Mode Edit settings:

1. From the PICTURE menu, use the Arrow
buttons to highlight Picture Mode Edit,
and then press OK. The PICTURE MODE
EDIT menu is displayed.

2. Use the Arrow buttons to highlight
the setting you wish to adjust, then
press OK to change the setting:

Picture Mode Edit

Save Picture Mode

Lock Picture Mode

Reset Picture Mode - Vivid

Back

• Save Picture Mode - Save a custom

picture mode.

• Lock Picture Mode - Prevent changes to
custom picture modes. Choose between
On or O.

• Reset Picture Mode† - Reset the picture

mode settings to factory default values.

Saving a Custom Picture Mode

Custom picture modes allow you to save a group of custom settings for
various viewing conditions and video sources.

• Changes made while on any preset picture mode will add an asterisk
on the top right corner of the preset mode.

• The custom picture mode is not automatically saved.

To save a custom picture mode:

1. From the PICTURE MODE EDIT menu,
use the Arrow buttons to highlight
Save Picture Mode, and then press

Save Picture Mode

Back

OK. The SAVE PICTURE MODE menu is
displayed.

2. Use either on-screen keyboard to
enter a name for your custom picture
mode.

3. Highlight Save and press OK.

4. Press the Exit button to exit the menu
screens.

a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# äêí Space

Save

†

Only available on customized preset modes.

20

3

Locking/Unlocking a Custom Picture Mode

Custom picture modes can be locked/unlocked with a unique PIN to
prevent accidental changes to their settings.

To lock all custom picture modes:

1. From the PICTURE MODE EDIT
menu, use the Arrow buttons to
highlight Lock Picture Mode, and
then press OK. The LOCK PICTURE

Lock Picture Mode

Enter the System PIN to lock all custom picture
modes.

Back

MODE menu is displayed.

2. Use the Number Pad on your

System Pin Code

remote to enter a unique 4-digit
PIN. If a system PIN is set, then lock/
unlock. If no system PIN is set, then
you will be prompted to set a PIN.

Cancel Save

3. Highlight Save and press OK.

4. Press the Exit button to exit the
menu screens.

To unlock all custom picture modes:

1. From the PICTURE MODE EDIT
menu, use the Arrow buttons to
highlight Lock Picture Mode, and
then press OK. The LOCK PICTURE
MODE menu is displayed.

2. Use the Arrow buttons to select O.

3. Use the Number Pad on your remote to enter your 4-digit PIN.

4. Make any desired changes to the picture modes.

5. Then turn ON Lock Picture Mode.

6. Press the Exit button to exit the menu screens.

Deleting a Custom Picture Mode

Custom picture modes that are no longer needed can be deleted.

Inputs assigned to a deleted custom picture mode become
assigned to the

Calibrated

picture mode.

To delete a custom picture mode:

1. From the PICTURE MODE EDIT menu,
use the Arrow buttons to highlight
Delete Picture Mode, and then press
OK. The DELETE PICTURE MODE window

To delete the user created Custom 1

picture mode, select the Delete button.

Delete Cancel

is displayed.

2. Use the Left/Right Arrow buttons to
highlight Delete and press OK.

3. Press the Exit button to exit the menu screens.

Resetting a Picture Mode

A preset picture mode that has been edited can be restored to the factory

default settings.

To reset a customized preset picture mode:

1. From the PICTURE MODE EDIT menu,
use the Arrow buttons to highlight
Reset Picture Mode, and then press
OK. The RESET PICTURE MODE window is
displayed.

Select Reset to restor the Standard

picture mode to factory defaults.

Reset Cancel

2. Use the Left/Right Arrow buttons to
highlight Reset and press OK.

3. Press the Exit button to exit the menu screens.

21

3

Adjusting the Color Tuner Settings

The Color Tuner settings allow you to adjust the HSB color and 11 point
white balance, turn color channels o for testing, and display color bar,
at, and ramp test patterns.

The Color Tuner, 11 Point White Balance, and test patterns

allow technicians to manually calibrate the TV. Calibration
requires specialized training, an input with precisely set
colors, and a specialized light meter.

To adjust the HSB color settings:

1. From the COLOR CALIBRATION menu, use the Arrow buttons to

highlight Color Tuner, and then press OK. The Color Tuner menu is
displayed.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Oset 0 0 0

Gain 0 0 0

2. Use the Arrow buttons on the remote to highlight the Hue,

Saturation, Brightness, Oset, or Gain of the color you wish to adjust.

Press the OK button.

3. Use the Left/Right Arrow buttons to adjust the value. When you are
nished press the OK button to save the setting.

4. When you have nished adjusting the color tuner settings, press the
Exit button.

To turn color channels o and on:

1. From the COLOR CALIBRATION menu, use the Arrow buttons to

highlight Color Tuner, and then press OK. The COLOR TUNER menu
is displayed.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Oset 0 0 0

Gain 0 0 0

2. Use the Arrow buttons on the remote to highlight Red, Green, or
Blue.

3. Press the OK button to turn the color channel o or on. An X

appears over a color channel that has been turned o.

4. Use the Arrow buttons to highlight another color channel to turn o
or on. Only two color channels can be turned o at the same time.

5. When you have nished with the color channels, press the Exit
button.

To adjust the 11 Point White Balance settings:

1. From the Color Tuner menu, use the Arrow buttons to highlight

Color Tuner, and then press the Left/Right Arrow buttons until the

11 POINT WHITE BALANCE menu is displayed.

11 Point White Balance

Gain Red Green Blue

5% 0 0 0

To show or hide the SMPTE Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight

Calibration Tests, and then press the Left/Right Arrow buttons

until the SMPTE TEST PATTERN menu is displayed.

SMPT Test Pattern

O

2. Use the Arrow buttons on the remote to highlight O. Use the Left/
Right Arrow buttons to highlight On to show the SMPTE Pattern.

—or—

To hide the SMPTE Test Pattern, use the Left/Right Arrow buttons to
highlight O.

3. When you are nished, press the Exit button.

To show or hide the Flat Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight
Calibration Tests, and then press the Left/Right Arrow buttons until

the FLAT TEST PATTERN menu is displayed.

Flat Test Pattern

O

2. Use the Arrow buttons on the remote to highlight the Gain and
Color values you wish to adjust. Press the OK button and use the
Left/Right Arrow buttons to adjust the value. When you are nished,

press the OK button to save the setting.

3. When you have nished, press the Exit button.

2. Use the Arrow buttons on the remote to highlight O. Use the Left/
Right Arrow buttons to select the percentage brightness for the

at test pattern. Selecting a percentage immediately shows the at

pattern at that brightness.

—or—

To disable the Flat Test Pattern, use the Left/Right Arrow buttons to
highlight O.

3. When you are nished, press the Exit button.

22

3

To show or hide the Ramp Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight
Calibration Tests, and then press the Left/Right Arrow buttons until

the RAMP TEST PATTERN menu is displayed.

Ramp Test Pattern

O

2. Use the Arrow buttons on the remote to highlight O. Use the Left/
Right Arrow buttons to select the color for the ramp test pattern.

Selecting a color immediately shows that color ramp.

—or—

To hide the Ramp Test Pattern, use the Left/Right Arrow buttons to
highlight O.

3. When you are nished, press the Exit button.

To show or hide the Uniformity Analyzer Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to highlight
Calibration Test, and then press the Left/Right Arrow buttons until

the UNIFORMITY ANALYZER TEST PATTERN menu is displayed.

Uniformity Analyzer Test Pattern

O

2. Use the Arrow buttons on the remote to highlight O. Use the Left/
Right Arrow buttons to highlight On to show the Uniformity Analyzer

Test Pattern.

—or—

To hide the Uniformity Analyzer Test Pattern, use the Left/Right
Arrow buttons to highlight O.

3. When you are nished, press the Exit button.

23

3

ADJUSTING THE AUDIO SETTINGS

To adjust the audio settings:

1. Press the Menu button on the
remote. The on-screen menu
is displayed.

2. Use the Arrow buttons on the remote
to highlight Audio and press OK. The
Audio menu is displayed.

3. Use the Arrow buttons to highlight
the setting you wish to adjust, then
press Left/Right Arrow buttons to
change the setting:

• Speakers - Turns the built-in speakers

On or O.

• Volume Control Display - Toggle

between On or O to hide or display

the on-screen volume slider that
appears when volume is adjusted.

• Surround Sound - Surround sound
uses DTS TruSurround™ to deliver

an immersive surround sound
experience from the TV’s internal

speakers. TruSurround completes

the entertainment experience by providing deep, rich bass and by

delivering crisp details and clear, intelligible dialog. Select On or O.

• Volume Leveling - Volume leveling uses DTS TruVolume™ to

maintain consistent volume levels during transitions between

program content, AV formats, and input sources. Select On or O.
In a few cases, volume leveling may articially suppress volume
increases, making it dicult to hear dialog or attening sudden
noises. If this occurs, turn volume leveling o.

Audio

Speakers Auto

Volume Control Display On

Surround Sound On

Volume Leveling On

Balance 0

Lip Sync 0

Digital Audio Out Auto

Analog Audio Out Fixed

• Lip Sync - Adjusts the synchronization between the display image
and the accompanying audio track.

• Digital Audio Out - Changes the type of processing for digital audio
out and HDMI ARC output when connected to a home theater audio

system. Select Auto, PCM, Dolby D or Bitstream.

Back

You must select Bitstream for audio with more than two

channels (3.0, 5.0, or 5.1, for example).

• Analog Audio Out - Sets the volume control properties for the RCA
connector when connected to a home theater audio system. Select

Variable if you are controlling the volume with the TV’s volume
controls, or select Fixed if an external audio device (sound bar or AV
receiver) will control the volume.

4. When you have nished adjusting the audio settings, press the Exit
button on the remote.

When the TV speakers are set to On, DTS signals cannot be

passed through digital audio outputs.

• Balance - Adjusts the loudness of the audio output from the left and
right speakers.

24

3

ADJUSTING THE NETWORK SETTINGS

Your TV is Internet-ready, featuring both an Ethernet port and built-in
high-speed Wireless-N. D24h-G9 , D32h-G9 and D40f-G9 support
Wireless-N. D50x-G9, V405-G9, V505-G9 and V655-G9 support Wireless-AC.

If your TV is connected to a network with an Ethernet cable,
you will not see the wireless network connection menu. You
must unplug the Ethernet cable to set a wireless network
connection

Connecting to a Wireless Network

To connect to a wireless network whose

network name (SSID) is being broadcast:

1. Press the Menu button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote
to highlight Network and press OK.
The NETWORK menu is displayed.

3. If you do not see your wireless network
displayed, highlight More Access

Points and press OK. The WIRELESS
ACCESS POINTS menu, which is a

list of available wireless networks, is
displayed.

4. Highlight the name of your wireless

network (this is the network’s SSID)

and press OK.

5. Using the on-screeen keyboard,
enter your network’s password, then
highlight Connect and press OK.

6. Press the Exit button on the remote.

Network

Wired Connection Disconnected

Wireless Access Points

Manual Setup

Hidden Networks

Test Connection

Back

Changing the Manual Setup Settings

Advanced users can ne-tune the network settings using the Manual Setup

feature.

To change advanced network settings:

1. From the NETWORK menu, highlight

Manual Setup

Back

Manual Setup and press OK. The
MANUAL SETUP menu is displayed.

2. To change the settings manually, use
the Arrow buttons on the remote to
highlight DHCP and then use the Left/
Right Arrow buttons to change the

setting to O.

3. Use the Arrow and OK buttons to adjust
each setting:

• IP Address - The IP address assigned to

DHCP Off

IP Adress __. __.__.__

Subnet Mask __. __.__.__

Defult Gateway __. __.__.__

Pref. DNS Server __. __.__.__

Alt DNS Server __. __.__.__

RJ45 Mac 0:0:0:0:0:0

Wireless Mac 0:0:0:0:0:0

the TV.

• Subnet Mask - The subnet Exit 2D

• Default Gateway - Your network’s

default gateway address.

Save

Cancel

• Pref. DNS Server - Your preferred
domain name server address.

• Alt. DNS Server - Your alternate domain
name server address.

4. Use the Arrow buttons on the remote to highlight Save and press OK.

5. Press the Exit button on the remote.

Finding MAC Addresses for Network Setup

The security settings on your router may require you to enter the TV’s

MAC address in the router’s settings. To nd the TV’s MAC address:

1. From the NETWORK menu, highlight Manual Setup and press OK. The

MANUAL SETUP menu is displayed.

2. Find the MAC address for the TV at the bottom of the list. The MAC
addresses for the connections in use are displayed:

• RJ45 MAC - The Ethernet or RJ45 MAC address may be needed to set
up your network when you have connected the TV to your network
when you have connected the TV to your network with an Ethernet
(Cat 5) cable.

• Wireless MAC - The Wireless (WiFi) MAC address may be needed to
connect your TV to your network with WiFi.

25

3

Connecting to a Hidden Network

To connect to a wireless network whose network name (SSID) is not being

broadcast:

1. From the NETWORK menu, highlight
Hidden Network and press OK. The

ENTER ACCESS POINT NAME screen is

displayed.

2. Using the on-screen keyboard, enter

Enter Acces Point Name

Enter your access point name. This
is used to connect to an access point
with a hidden SSID.

Back

your network’s name (SSID), then

highlight Connect and press OK.

3. Using the on-screen keyboard, enter
your network’s password, then
highlight Connect and press OK.

4. Press the Exit button on the remote.

a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# äêí Space

Connect

Testing Your Network Connection

To test your network connection:

1. From the NETWORK menu, highlight Test Connection and press OK.

2. The TEST CONNECTION screen displays the connection method,
network name, signal strength, and download speed of your network
connection.

3. Press the Exit button on the remote.

26

3

SETTING TIMERS

Setting the Timer

When activated, the TV’s timer will turn the TV o after a set period of

time.

1. Press the Menu button on the
remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the
remote to highlight Timers and
press OK. The TIMERS menu is
displayed.

3. Use the Left/Right Arrow buttons
on the remote to highlight the
period of time after which you want
the TV to go to sleep: 30, 60, 90,
120, or 180 minutes. If you don’t
want the sleep timer to activate,
change the setting to O.

4. When you have nished setting the
sleep timer, press the Exit button
on the remote.

Timers

Sleep Timer Off

Auto Power Off 10 Minutes

Blank Screen

Back

Setting the Auto Power O Feature

To help save energy, your TV is set by default to turn o after 10 minutes

without a video or audio signal. This feature can be deactivated.

To set the Auto Power O feature:

1. From the TIMERS menu, use the Up/Down Arrow buttons on the

remote to highlight Auto Power O.

2. Use the Left/Right Arrow buttons on the remote to change whether

the TV will turn o. If you don’t want the TV to turn o when there is

no signal, change the setting to O. Otherwise, select 10 minutes.

3. When you have nished setting the auto power o time, press the

Exit button on the remote.

Using the Blank Screen Feature

To help save LED life, your TV screen can turn on or o while audio is
streaming. To use the Blank Screen feature:

1. From the TIMERS menu, use the Up/Down Arrow buttons on the

remote to highlight Blank Screen.

2. Press the OK button to immediatly blank the screen.

3. To exit Blank Screen, press any key.

27

3

SETTING UP CHANNELS

You can use the TV’s Channels menu to:

• Find Channels

• Select channels to skip

• Select Analog Audio mode

• Select the language for Digital Audio

• Set Parental Controls

Channels

Find Channels

Skip Channels

Analog Audio Stereo

Digital Audio English

Parental Control

Back

Scanning for Channels

The TV may need to scan for channels before it can display programs
and their associated information. A channel scan is required for free
over-the-air channels (using an antenna) and cable channels from an out­of-the-wall connection (without a cable box). Moving the TV to an area

with dierent channels requires the TV to scan for channels again.

To perform an Auto Channel Scan:

1. From the CHANNELS menu,

highlight Find Channels, and press
OK. The auto channel scan begins.

2. Wait until the channel scan is 100%
complete. Highlight Done and press
OK.

Find Channels

Channels Found

Digitial : 8

Analog: 12

45% Complete

Back

3. Press the Exit button on the remote.

If the channel scan is canceled, the

Cancel

channels that were already discovered
are retained. A new channel scan will
clear all channels.

Skipping Channels

After a channel scan is completed, you may nd that some channels are

too weak to watch comfortably. There may also be some channels you do
not want to view. You can remove these channels from the TV’s memory

with the Skip Channel feature.

Channels that have been removed with the Skip Channel

feature can still be viewed if the channel is entered using the
Number Pad. If you wish to completely block a channel from

being viewed, use the parental controls. See

Unlocking Channels

.

Locking and

To remove a channel:

1. From the CHANNELS menu, highlight
Skip Channel, and press OK. The
SKIP CHANNEL menu is displayed.

Skip Channels

Back

2. For each channel you wish to remove,
use the Up/Down Arrow buttons on
the remote to highlight the channel

and press OK. A P appears to the
right of each channel you select.

3. When you have selected all of the
channels you wish to remove, press

0 Test 0

1 Test 1

2 Test 2

3 Test 3

4 Test 4

the Exit button on the remote.

28

3

LISTENING TO ALTERNATE AUDIO

Changing the Analog Audio Language

Some analog over-the-air (free) and cable channels broadcast programs

in more than one language. The TV’s Analog Audio feature allows you

to listen to audio in an alternate language using Secondary Audio
Programming (SAP).

Not all programs are broadcast in SAP. The Analog

Audio Language feature only works when the program

being viewed is being broadcast with Secondary Audio

Programming.

To use the Analog Audio feature:

1. From the Channels menu, highlight
Analog Audio and press OK. The
Analog Audio menu is displayed.

2. Select Stereo, SAP (secondary audio
programming), or Mono. Press OK.

3. Press the Exit button on the remote.

Analog Audio

Stereo

SAP

Mono

Back

To use the Digital Language feature:

1. From the CHANNELS menu, highlight
Digital Audio and press OK.
The DIGITAL LANGUAGE menu is
displayed.

2. Select your preferred language:

English, Spanish/Video Description,
French. Press OK.

3. Press the Exit button on the remote.

Digital Audio

English

Spanish/ Video Description

French

Back

29

3

USING PARENTAL CONTROLS

The TV’s parental controls allow you to prevent the TV from displaying
certain channels or programs without a password.

Other devices have their own parental control settings.

The PARENTAL CONTROLS menu only appears when:

• You are using the tuner to receive your TV signals, such as when you
are using an antenna for Over-the-Air signals or when connected to
cable TV directly from the wall (no cable box).

• You have a device connected using a composite video cable or a
coaxial cable, such as a VCR, satellite or cable box, or DVR.

Accessing the Parental Controls Menu

To access the PARENTAL CONTROLS menu:

1. Press the Menu button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight Channels and
press OK. The CHANNELS menu is displayed.

3. Use the Arrow buttons on the remote to highlight Parental Controls
and press OK.

4. Enter your set System PIN.

To set a custom PIN passcode, see

Setting a System Pin.

Enabling or Disabling Program Ratings

To manage program content according to its rating, you must enable the
Program Rating feature.

To enable or disable the Program Rating feature:

1. From the PARENTAL CONTROLS menu, highlight Locks and press OK.
The LOCKS menu is displayed.

2. Select On or O and press OK.

Locking and Unlocking Channels

When a channel is locked, it will be inaccessible. Locking a channel is a

good way to prevent children from viewing inappropriate material.

To lock or unlock a channel:

1. From the PARENTAL CONTROLS menu, highlight Channel Locks and
press OK. The CHANNEL LOCKS menu is displayed.

2. Highlight the channel you want to lock or unlock and press OK.

3. When a channel is
channel is not accessible unless the parental PIN is entered.

4. When a channel is
The channel is accessible.

locked

unlocked

, the Lock icon appears locked. The

, the Lock icon appears unlocked.

Blocking and Unblocking Content by Rating

A channel may sometimes broadcast programs that are meant for
children, and at other times broadcast programs that are meant for
mature audiences. You may not want to block the channel completely
using a channel lock, but you may wish to block certain programs from
being viewed.

For a list of content ratings and their denitions, visit
www.tvguidelines.org.

When this is the case, you can use the TV’s Rating Block feature to block
content based on its rating.

To block or unblock content by its rating:

1. From the PARENTAL CONTROLS menu, highlight the content type you
want to adjust and press OK:

• USA TV - USA television program broadcasts.

• USA Movie - USA movie broadcasts.

• Canadian English - Canadian English television program broadcasts.

• Canadian French - Canadian French television program broadcasts.

2. For each rating type you want to block or unblock, use the Up/Down
and Left/Right Arrow buttons on the remote to highlight the rating
type and press OK.

3. When the rating type is blocked, the Lock icon appears locked.
Content with this rating and all higher ratings cannot be viewed.

4. When the rating type is unblocked, the Lock icon appears
unlocked. Content with this rating and all lower ratings can be
viewed.

If you want to block all unrated content, highlight Block Unrated Shows

and use the Arrow buttons on the remote to select On.

5. When you are nished adjusting the rating level blocks, press the Exit
button on the remote.

30

3

SETTING UP CLOSED CAPTIONING

Your TV can display closed captions for programs that include them.
Closed captions display a transcription of a program’s dialogue.

If the program you are viewing is not being broadcast with
closed captions, the TV will not display them.

The Closed Captions menu does not appear when an HDMI
input is selected.

To activate or deactivate closed captions:

1. Press the Menu button on the
remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the remote
to highlight Closed Captions and
press OK. The CLOSED CAPTIONS
menu is displayed.

3. Use the Arrow buttons on the remote
to highlight Closed Captions and then
use the Left/Right Arrow buttons to

select On or O.

4. Use the Arrow buttons on the remote
to highlight either Analog or Digital
Closed Captions.

5. Use the Left/Right Arrow buttons
on the remote to select the caption
channel you wish to display, then
press Exit.

Closed Captions

Closed Captions Off

Analog Closed Captions CC1

Digital Closed Captions CS1

Digital Style

Back

Changing the Appearance of Digital Closed Captions

Digital closed captions can be displayed according to your preference.

See the diagram on the next page for an explanation of the parts of the

closed caption area.

To change the appearance of digital closed captions:

1. From the CLOSED CAPTIONS menu, use the Arrow buttons to
highlight Digital Style and press OK.

2. Use the Left/Right Arrow buttons on the remote to select Custom.
The DIGITAL STYLE menu appears as shown.

3. Use the Up/Down Arrow buttons on the remote to highlight the
setting you wish to change, then use the Left/Right Arrow buttons to
change the setting:

• Caption Style - Choose As Broadcast to keep default settings or
Custom to manually change each setting.

• Text Style - Change the font used for the
closed captioning text.

• Text Size - Make the text larger or smaller.

• Text Color - Change the color of the text.

• Text Opacity - Change the transparency of the

text.

• Text Edges - Change the eects at the edges

of the text, such as raising the edges or adding
drop shadows.

• Text Edges Color - Change the color of the text

edge eects.

• Background Color - Change the color of the
background directly behind the text.

• Background Opacity - Change the

Digital Style

Text Style As Broadcast

Test Size Large

Text Color Blue

Text Opacity As Broadcast

Text Edges As Broadcast

Text Edges Color As Broadcast

Background Color As Broadcast

Background Opacity As Broadcast

Window Color As Broadcast

Window Opacity As Broadcast

transparency of the background directly behind
the text.

• Window Color - Change the color of the closed
captioning box.

• Window Opacity - Change the opacity of the
closed captioning box.

Back

4. When you are satised with the appearance of the closed
captions, press the Exit button on the remote.

31

Typical choices include:

• Opaque background, transparent window—Only a strip of
background appears behind the text, expanding as the text appears.
This is the typical "As Broadcast" mode.

• Opaque background and window in the same color—When text

appears, the entire line lls with color at once.

In the example, the closed caption text is green, the background is black,
and the window is red.

Text

3

Background

CLOSED CAPTION TEXT SAMPLE

Window

CLOSED CAPTIONS SCREEN LAYOUT

32

RENAMING DEVICES ON THE INPUT MENU

3

You can rename the inputs to make them easier to recognize on the
Input menu. For example, if you have a DVD player connected to the

Component input, you can rename that input to display “DVD Player.”
See

Changing the Input Source.

To change the name of an input:

1. Press the Menu button on the remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the remote to highlight Input Settings and
press OK. The INPUT SETTINGS menu is displayed.

3. Highlight the input device that you want to rename and press OK.

To use a preset input name:

• Highlight the Name Input row and press OK.

• Highlight the input name and use the Left/Right Arrow buttons on
the remote to cycle through preset input names

—or—

To enter a custom name:

• Highlight the Name Input row and press OK.

• Enter your custom label using the on-screen keyboard.

• Highlight and press OK.

• The Input Name changes to show the custom name that you created.

4. When you have nished naming your input, press the Exit button on
the remote.

Input Name

Input Settings

TV

HDMI-1 Blu-Ray

HDMI-2 Cable Box

HDMI-3 HDMI-3

COMP Game Console

Back

Custom Name

33

3

CHANGING THE TV SETTINGS

Using the SYSTEM menu, you can:

• Check for updates

• View system information

• Change the on-screen menu
language

• Set time zone and local settings

• Adjust the CEC settings

• Adjust the power mode settings

• Adjust to preserve Aspect Ratio or ll
the screen

• Name the TV

• Review and maintain the list of
paired devices

• Adjust accessibility settings

• Reset the TV settings & setup
administrative controls

System

Check for Updates

System Information

Menu Language English

Time & Local Settings

CEC

Power Mode Quick Start

Aspect Ratio Normal

TV Name Ofce TV

Mobile Devices

Accessibility

Reset and Admin

Back

Checking for System Updates

To check for a system update:

1. Press the Menu button on the remote. The on-screen Menu is
displayed.

2. Use the Arrow buttons on the remote to highlight System and press
OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight Check for
Updates and press OK. The TV will begin to check for updates.

4. If an update is found, the TV will ask to conrm the update. If no
update is found, the screen will note No Update Available.

Viewing System Information

To view technical data and status information about your TV and network
connection:

1. Press the Menu button on the remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the remote to highlight System and press
OK. The SYSTEM menu is displayed.

3. Highlight System Information and press OK.

4. Use the Up/Down Arrow buttons to scroll through the system
information.

5. When you are nished reviewing the system information, press the

Exit button on the remote.

Changing the On-Screen Menu Language

Your TV can display the on-screen menu in

dierent languages.

To change the on-screen menu language:

1. Press the Menu button on the remote.
The on-screen menu is displayed.

2. Use the Arrow buttons on the remote
to highlight System and press OK. The
SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote
to highlight Menu Language and
press OK. The MENU LANGUAGE menu
is displayed.

4. Highlight your preferred language
(English, Español, or Français) and
press OK.

5. Press the Exit button on the remote.

Menu Language

English

Español

Français

Back

34

3

Setting the Time and Local Settings

To ensure the correct time is displayed when you press the Info button,
set the TV’s time zone:

1. Press the Menu button on the
remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the remote
to highlight System and press OK.

The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote
to highlight Time & Local Settings
and press OK. The menu headed by
the local date and time is displayed.

4. Highlight Time Zone and press OK.
The TIME ZONE menu is displayed.

5. Highlight your time zone and press
OK.

6. Highlight Daylight Saving Time and
press OK. The DAYLIGHT SAVING
TIME menu is displayed. Choose On if

it is currently Daylight Savings Time,
O if it is Standard Time, or Auto to have the system automatically
detect Daylight Savings Settings.

7. Press the Exit button on the remote.

Time and Local Settings

June 11, 2018 11:48AM

Time Zone Pacic (-8)

Daylight Savings Time Auto

Time Format

Country USA

Back

Adjusting the CEC Settings

The CEC function on your TV enables you to control devices connected to
HDMI (ARC) input with the included remote, without any programming.
Using CEC, your VIZIO TV remote can control:

• Power On/O

• Volume

• Mute

Not all HDMI devices support CEC. See your device’s user

manual for details.

To enable, disable, or adjust CEC settings:

1. Set up your audio device and connect it to the HDMI-1(HDMI Arc)

input on the TV

2. On your audio device, select the HDMI ARC input.

3. Press the Menu button on the remote. The on-screen menu is
displayed.

4. Use the Arrow buttons on the remote to highlight System and press
OK. The SYSTEM menu is displayed.

5. Use the Arrow buttons on the remote to highlight CEC and press OK.
The CEC menu is displayed.

6. Highlight CEC and press OK. Select a setting and then press OK.

• CEC - To use CEC, you must select Enable.

• Device Discovery - To determine if your device is connected and

supports CEC, select Device Discovery and then press OK.

7. Press the Exit button on the remote.

Adjusting the Power Mode

Your TV is set to Eco Mode by default. When the TV is powered o, Eco
Mode setting uses less than 0.5W of power. Quick Start Mode enables

your Display to power on faster.

Please note that by changing this setting the energy
consumption required to operate this device will change.

To switch between Eco Mode and Quick Start Mode:

1. Press the Menu button on the remote. The on-screen Menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and press

OK. The SYSTEM Menu is displayed.

3. Use the Arrow buttons on the remote to highlight Power Mode and
press OK. The Power Mode Menu is displayed.

4. Highlight either Eco Mode or Quick Start Mode and press OK to
select.

35

3

Changing the TV Name

Naming your TV helps dierentiate it from other cast devices you may

have in your home.

To edit your TV name:

1. Press the Menu button on the
remote. The on-screen menu is
displayed.

TV Name

Living Room TV

Back

2. Use the Arrow buttons on the remote
to highlight System and press OK.
The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote
to highlight TV Name and press OK.

a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# äêí Space

The TV name input menu is displayed.

4. Enter your custom name using the
on-screen keyboard.

5. Press the Exit button on the remote.

Ok

Cancel

Manging Mobile Devices

Your TV can be paired with a mobile device so you can easily control your
TV across multiple devices .

To see a list of paired devices or unpair
a device:

1. Press the Menu button on the

Mobile Devices

Back

remote. The on-screen Menu is
displayed.

2. Use the Arrow buttons on the

remote to highlight System and press

Djae’s Tablet

Ana’s Phone

Work iPad

OK. The SYSTEM Menu is displayed.

3. Use the Arrow buttons on the
remote to highlight Mobile Devices
and press OK. The list of paired
devices appears.

4. Highlight a device name to delete it
and press OK.

5. Use the Left/Right Arrows to select

Yes or No when asked to conrm.

Accessibility settings

VIZIO is committed to providing intuitive, user-friendly products. Your

new VIZIO TV oers several accessibility features that can help you get

the most out of it.

To access the Accessibility menu:

1. Press the Menu button on the remote
control.

2. Use the Arrow and OK buttons
to navigate and select System à
Accessibility.

Accessibility

Talk Back Off

Speech Rate Normal

Zoom Mode Off

3. Talk Back - Turn Text-to-Speech Talk
Back On or O. Text-to-Speech Talk Back
enables your TV to speak all settings
changes and adjustments using the
remote in English.

4. Speech Rate* - Adjusts the rate in which

Text-to-Speech is spoken. Select Slow,
Normal (Default), or Fast.

5. Zoom Mode - Enlarges a section of the

screen by approximately 200%.

To access the Closed Caption menu:

• Press the Menu button on the remote
control.

• Use the Arrow and OK buttons to navigate and select Closed
Captions.

Back

To access the Video Description menu:

• Press the Menu button on the remote control.

• Use the Arrow and OK buttons to navigate and select Settings à

Channel à Digital Audio à Spanish/ Video Description.

*Available only in English.

36

3

USING THE RESET & ADMIN MENU

You can use the TV’s RESET & ADMIN menu to restore the TV to its factory
default settings as well as access other system settings.

Using the RESET & ADMIN, you can:

• Reset the TV to factory settings

• Force the system to power o and on

• Create a system pin code to lock
content and picture settings

• Enable or disable program oers and
suggestions

• Enable or disable anonymous debug
data for system performance.

• Start or stop the Store Demo Mode

Reset & Admin

Reset to Factory Defaults

Soft Power Cycle

Power Indicator On

System PIN Code

USB Power Always On

Viewing Data

VIZIO Privacy Policy

Store Demo

Back

Restoring the TV to Factory Default Settings

All of the on-screen menu settings can be reset to the factory defaults.

If you restore the TV to the factory default settings, all
changes you have made to the settings will be lost! This
includes any wireless or picture settings

To restore the TV to its factory default settings:

1. Press the Menu button on the remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the remote to highlight System and press
OK. The SYSTEM menu is displayed.

3. Highlight Reset & Admin and press OK. The RESET & ADMIN menu is
displayed.

4. Highlight Reset to Factory Defaults and press OK. If you have
changed the set system PIN, enter it now.

The TV displays, “Select Reset to restore all TV settings to factory

defaults and clear all account information.”

5. Highlight Reset and press OK.

6. Wait for the TV to turn o. The TV will turn back on shortly afterward
and the setup process will begin.

Turning the Power Indicator On or O

The Power Indicator on the front of your TV normally does not glow
when the TV is on. You can change this setting if you prefer the light to
be on.

To turn the Power Indicator Light On or O:

1. Press the Menu button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and press

OK. The System menu is displayed.

3. Use the Arrow buttons on the remote to highlight Reset & Admin
and press OK. The Reset & Admin menu is displayed.

4. Highlight Power Indicator and press OK.

5. Use the Left/Right Arrow buttons to select On or O.

Performing a Soft Power Cycle

A soft power cycle forces the TV to turn o then on again.

1. Press the Menu button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and press
OK. The SYSTEM menu is displayed.

3. Highlight Reset & Admin and press OK. The RESET & ADMIN menu is
displayed.

4. Highlight Soft Power Cycle and press OK.”

5. Highlight Yes and press OK.

6. The TV will turn o then on again

37

3

Setting a System PIN

You can set a System Pin to lock content and picture modes as well as
prevent accidental system resets. The rst time you select System PIN

code, you will need to create a PIN. To create a PIN.

1. Press the Menu button on the
remote. The on-screen menu is
displayed.

2. Use the Arrow buttons on the
remote to highlight System and press

System PIN Code

Change the PIN used for the System PIN.

Back

OK. The SYSTEM menu is displayed.

3. Highlight Reset & Admin and press

New PIN

OK. The RESET & ADMIN menu is
displayed.

4. Highlight System PIN Code and press

Conrm PIN

OK.”

5. Enter and conrm your new PIN.

Cancel Save

6. Highlight and select Save to conrm.

Using the USB Power Feature

The USB port can be used to charge

devices The two options for this feature
are:

• Always On - Power is always available.

• O When TV O - When the TV is

powered o, no power is available.

USB Power

Always On

Off When TV Off

Back

About Viewing Data

Video ACR collects data related to publicly available content displayed on
your television/display, such as the identity of your broadcast, cable, or
satellite television provider, and the television programs and commercials
viewed (including time, date, channel, and whether you view them live or at

a later time). We also collect unique identiers about this TV, including the
IP address. This data is collectively referred to as “Viewing Data.” For more

information about Viewing Data and how VIZIO protects its customers’
privacy, please consult our privacy policy at www.vizio.com/privacy.

When ACR collection is turned on, we may share Viewing Data with
authorized data partners including analytics companies, media companies
and advertisers. VIZIO and its authorized data partners use Viewing Data to
generate summary analysis and reports of how users engage with content
on their TVs and other devices. VIZIO Viewing Data is sometimes enhanced
with household demographic data and data about digital actions (e.g.
digital purchases and other consumer behavior taken by devices associated
with the IP Address we collect). Viewing Data also enables our authorized

data partners to deliver advertising relevant to your prole that you might
nd useful, both on the VIZIO TV/display and other devices sharing your IP

Address. Viewing Data is also used to help content publishers, broadcasters
or content distribution services create or recommend more relevant
entertainment based on summary insights, as well as helps us improve the
design of our products, software and services.

You will need to enter your current PIN code the next time
you access this menu or if you’d like to change your PIN.

You can easily turn this feature On or O in the RESET & ADMIN menu.

If you have trouble enabling or disabling Viewing Data, please contact

VIZIO Customer Support by going to support.vizio.com and selecting
Contact Us.

For more information, see https://www.vizio.com/viewingdata and review
VIZIO’s privacy policy at https://www.vizio.com/privacy.

38

USING THE INFO WINDOW

The Info Window can be displayed by pressing the Info button on the remote:

• Press the Info button one time to display the TV name, current input, picture mode, network name, and time.

3

TV Name

Living Room

HDMI-1

Picture Mode

Network NameCurrent Input

HomeWiFiWide

5:00 pm

Time

INFO WINDOW

39

SmartCast Home

SM

What is SmartCast HomeSM?

SmartCast Home lets you discover, stream, and control your content like never before! Access top
apps, like Netix, Hulu, and Amazon Prime Video by using the remote to easily browse and launch
content directly from the home screen. SmartCast Home makes nding something to watch easy and

fun.

What you can do with SmartCast Home:

• Stream high quality entertainment.

4

Home Movies TV Shows Support Extra

1

• Launch top tier apps directly from the home screen.

• Unlock your photos and videos by mirroring your laptop or mobile device onto your TV.

• Turn your iOS or Android device into the ultimate streaming companion with the VIZIO SmartCast
Mobile app.

• Rearrange apps on your home screen just the way you like it.

• Works with Google Assistant and Amazon Alexa.

How to Launch SmartCast Home:

Begin streatming with SmartCast Home by:

• Press the V-Logo button ( ) on your remote

—or—

• Select SmartCast from the list of inputs.

Discover

2

Apps

3

1. Marquee Content Carousel - Launch content with one click.

2. Discover - New or popular content across multiple apps.

3. Streaming Apps on your TV

4. Quick Access to Popular Apps

5. V-Key - Launch SmartCast Home with one click.

4

INPUT

EXIT

OK

BACK

CC

VOL CH

PIC

1

2

5

4

7

8

0

MENU

INFO

5

3

6

9

40

Kansas C

The Kitch

206

WatchFree™

What is WatchFree™?

VIZIO WatchFree takes your cord-cutting entertainment experience one step further! With the simple

press of a button, enjoy free streaming TV with over 100 live TV channels to choose from – news, movies,
sports, comedy, music and more. A built-in on-screen guide makes nding something to watch easier

than ever. And it’s all FREE – no fees, no subscriptions, or logins.

What you can do with WatchFree:

• Stream over 100 live TV channels absolutely free – news, movies, sports, comedy, music and more.

• Navigate through channels, organized by genre, with an intuitive on-screen guide.

• Watch 1000’s of free movies from major studios.

• Watch the best of the internet TV.

• No logins, subscriptions or transactions fees.

FAVORITES

115

1

Zoneless

2018 • 2h • TV-G • Sci-Fi

Outer space: The closest known resemblance to a perfect vacuum. It has
essentially no friction, allowing countless stars, planets, and moons to move
about freely. This is the story of one man’s journey in this mysterious place.

9:00 9:30

Music

4

3

10:00

INPUT

How to Launch WatchFree:

To launch and begin watching entertainment oered on WatchFree:

• Press the Input button on your remote and select WatchFree

-or-

• Simply select the WatchFree app logo from the SmartCast Home app row.

107

Zoneless

2

203

204

205

1. Show Details - Find out show information.

2. On-Screen Guide - Over 100 live TV and audio channels organized by genre.

3. Input Button- Press INPUT and select WatchFree.

4. OK Button - Press the OK button to return to the WatchFree on-screen guide. Use the up/down

College Football

Network Security

The City

arrow buttons to scroll through the guide.

Fun WIth Max & Daniel

EXIT

OK

BACK

CC

VOL CH

PIC

1

2

5

4

7

8

0

MENU

4

INFO

3

6

9

41

Playing USB Media

4

The USB Media Player allows you to connect a USB thumb drive to your

TV and play music, video, or photos.

Preparing Your USB Drive to Play USB Media

To display USB media, you must rst save your videos onto a USB thumb

drive:

• The USB thumb drive must be formatted as FAT32.

• Files on the USB thumb drive must end in a supported le extension
( .mp3, .jpg, etc.)

• The player is not designed to play media from external hard drives,
MP3 players, cameras, or smartphones.

Displaying USB Media

To display your USB media:

1. Connect your USB thumb drive to the USB port on the side of the TV.

2. The TV will recognize the USB stick. Use the Arrow Keys on the
remote to select the content you’d like to play.

-OR-

3. Select USB from the bottom streaming icons on the

SmartCast Homepage.

Removing the USB Drive from the TV

To safely remove your USB drive from the TV:

1. Turn o the TV.

2. Disconnect your USB thumb drive from the USB port on the side of
the TV.

Do not remove the USB thumb drive while the TV is on.

Doing so may damage the drive.

Note: The image shown here is for illustrative purposes only and may be subject to

change. The actual number of ports and their locations may vary, depending on
the model.

You can display your photos in Fullscreen. Select the photo,

press OK, then highlight Fullscreen and press OK

42

Connected Sources

displays connected USB devices.

Current Folder

Playback Controls

Use to control audio playback. Highlight
Play/Pause, Previous, or Next and press OK.

Toggle Music/Photos

Sort by Album/Artist/Track

Back Button

Highlight this button and
press OK to return to the
previous screen.

Music

USB1: MyFlashDrive

My Music

Browse Photos

Sort:

Artist A-Z

Now Playing Information

displays song title, album title, and artist name.

Progress Bar

displays the duration of the currently-playing song.
The blue bar will lengthen as the song progresses.

Fab Apple Dream
On The Answer Is Yes
By Ana Banana

5:50 8:46

MyFlashDrive\Audio\root\My Music

#

Track Album Artist Duration

1

Starry Summer

Downspin JCheesy 6:20

2
3

Mango Dream

4

Crystal Waters The Dash

5

Smooth Waves Rio Steve 7:58

Summer Mix
Summer Mix

Beach Mix
Beach Mix

Breezy Mix

JCheesy

Ana Banana 8:46

2:42

4:21

4

Album Art

If included on the USB thumb drive and

associated with your music, the album art will
display here.

Folder Contents/Playlist

This area displays the contents of the
currently selected folder. You can browse
les and folders using the Arrow and OK
buttons on the remote.

View:

All

Toggle between
viewing all content and
only viewing folders.

Page 1 of 1

Page Information

If your USB thumb drive has more les

than can be displayed on a single screen,
the page information is displayed here.

MUSIC PLAYER

43

Back Button
Highlight this button and
press OK to return to the
previous screen.

4

Connected Sources

displays connected USB

devices.

Current Folder

Sort by Date or File Name

Video

USB1: MyFlashDrive

My Videos

Date New-Old

Sort:

View:

Folders

MyFlashDrive\Video\root\My Videos

File

#

Family Vacation - California

1
2

26th Birthday Party
Japan 2017

3

Aby’s Graduation

4

Page 1 of 1

Date Duration

-

-

-

-

00:23:43
00:38:18
00:41:08
00:25:32

Folder Contents/Playlist

This area displays the contents of the
currently selected folder. You can browse
among les using the Arrow and OK
buttons on the remote.

View All or View Folders

Page Information

If your USB thumb drive has more les

than can be displayed on a single screen,
the page information is displayed here.

VIDEO PLAYER

44

4

Connected Sources

displays connected USB devices.

Current Folder

Start Fullscreen Slideshow

Sort by Date or File Name

View Thumbnails/Folders

Back Button

Highlight this button
and press OK to return
to the previous screen.


USB1:

root

Start Slideshow

Name A-Z

Sort:

View:

Thumbnails

Back Button

Highlight and press OK to return to left column.

Current Folder

Displays the folder path.

VIZIO_2GB\Photo\root


B.jpg C.jpg

Folder Contents

This area displays the contents of the
currently selected folder. You can browse
les and folders using the Arrow and OK
buttons on the remote.

Adjust Slideshow Settings

View Music Files

Settings

Browse Music

File Name: D 1920x1080

Resolution: 1920x1080

Size: 1607270KB

Photo Information

displays the name, resolution, and

le size of the selected photo.



E.jpg F.jpg

H.jpg I.jpg
Page 1 of 1

Page Information

If your USB thumb drive has more les than can be

displayed on a single screen, the page information is
displayed here.

PHOTO VIEWER

45

Troubleshooting & Technical Support

Do You Have Questions? Find Answers At

SUPPORT.VIZIO.COM

A

Find help with:

• New Product Set-up

• Connecting Your Devices

• Technical Problems

• Product Updates

• And More

You can also contact our
award-winning support team at:

Phone: [phone] (TOLL-FREE)

Live Chat
Support Available

Or text VIZIO support using your mobile device:

Text Message: [phone]

Note: This number accepts SMS/MMS messages only. No voice calls accepted.
Message and data rates may apply. Only available in the U.S.

46

46

Take A Moment To Register Your Product At

VIZIO.COM/PRODUCT-REGISTRATION

Why Register?

Customized Support

Get assistance quickly with your information on-hand.

A

News & Offers

Take advantage of the latest news and special offers from VIZIO.

Safety & Satisfaction

Stay up to date with important product updates and notifications.

REGISTER YOUR VIZIO PRODUCT NOW

47

HELP TOPICS

A

The remote is not responding.

• Make sure the batteries are properly inserted matching the

- and + symbols.

• Replace the batteries with fresh ones.

The TV displays “No Signal.”

• Press INPUT button on the remote control to select a dierent
input source.

• If you are using cable TV or antenna connected directly to the TV,

scan for channels. See Scanning for Channels.

There is no power.

• Ensure the TV is plugged into a working electrical outlet.

• Ensure the power cable is securely attached to the TV.

• Press the Power/Standby button on the remote or on the back of
the TV to turn the TV on.

The power is on, but there is no image on the screen.

• Ensure all cables are securely attached to the TV.

• Ensure all devices are connected correctly. Devices dier; see your
device’s user manual for details.

• Adjust Brightness, Contrast, or Backlight.

See Adjusting the Picture Settings.

• Press the INPUT button on the remote to select a dierent
input source.

The sound is at or dialog is not audible.

• Turn o Volume Leveling. See Adjusting the Audio Settings.

There is no sound.

• Press Volume Up on the remote control.

• Press the MUTE button on the remote to ensure mute is o.

• Check the audio settings. See Adjusting the Audio Settings.

• Check the audio connections of external devices (Blu-ray player, game
console, cable/satellite box) that are connected to the TV.

• If you are using an antenna, the signal strength of the channel may be
low. Ensure your antenna is connected securely to the TV and move
the antenna around the room or close to a window for the best signal.

The colors on the TV don’t look right.

• Adjust the Color and Tint settings in the Picture menu. See Adjusting
the Picture Settings.

• Select a pre-set picture mode. See Adjusting the Picture Settings. VIZIO
recommends selecting Calibrated.

• Check all cables to ensure they are securely attached.

The image quality is not good.

• For the best image quality, view high-denition programs using digital
sources. Connect your devices with HDMI cables.

• If you are using an antenna, the signal strength of the channel may be
low. Ensure your antenna is connected securely to the TV and move
the antenna around the room or close to a window for the best signal.

The picture is distorted.

• Move the TV away from electrical appliances, cars, and

uorescent lights.

• Ensure all cables are securely attached.

The TV image does not cover the entire screen.

• If you are using TV, AV, or Component with 480i input, press the
button on the remote to change the screen mode.

The TV has pixels (dots) that are always dark.

• Your HD TV is precision-manufactured using an extremely high level

of technology. However, sometimes pixels may not display correctly.
These types of occurrences are inherent to this type of product and do
not constitute a defective product.

I see “noise” or static on the screen.

• When your TV’s digital capabilities exceed a digital broadcast signal,

the signal is up-converted (improved) to match your TV’s display
capabilities. This up-converting can sometimes cause irregularities in
the image.

• If you are using an antenna, the signal strength of the channel may be

low. Ensure your antenna is connected securely to the TV and move
the antenna around the room or close to a window for the best signal.

Where do I nd information on the accessibility features of this
product and other VIZIO products?

• Please visit https://www.vizio.com/accessibility, Email us at:

[e-mail], or give us a call at 1-877-698-4746.

The buttons on the remote aren’t working.

• Ensure you are only pressing one button at a time.

• Point the remote directly at the TV when pressing a button.

• Replace the remote batteries with new ones. See Replacing the

Batteries.

48

A

When I change input source, the TV image changes size.

• The TV remembers the viewing mode on each input source. If the

viewing mode on the new input source diers from the one on the
input source you switch from, the dierence may be noticeable.

• See Changing the Screen Aspect Ratio.

How do I download the VIZIO SmartCast Mobile™ app?

• Make sure your phone or tablet is connected to a Wi-Fi network.
Open a browser on your phone or tablet.
Navigate to vizio.com/smartcastapp and follow the on-screen

instructions to download the VIZIO SmartCast
Mobile™ app.

How do I change the Inputs?

• Press the Input button on the back of the TV to cycle through
the Inputs.

• Press the Input button on the basic remote to cycle through
the Inputs.

• Make sure the VIZIO SmartCast

• Mobile™ app is installed on your phone or tablet. Open the VIZIO

SmartCast Mobile™ app. Tap on the Device list and select your TV.

Tap on the Input key and select the Input of your choice.

How do I connect to my Wi-Fi network?

• On your TV remote, press the Menu button then go to Network >
Select your Wi-Fi name > Enter password.

• Open the VIZIO SmartCast Mobile™ app on your phone or tablet.
Tap on the device list and select your Display.
Tap on the Settings icon > Network > Wireless Access Points.

Select your Wi-Fi network from the list, enter the Wi-Fi password,

and tap Connect.

How do I stream apps like Netix to my VIZIO SmartCast™ TV?

• Download and open a Chromecast-enabled apps on your mobile
device. Then tap the Cast button.

How do I exit Demo Mode

• Press and hold the Input button on the back of the TV to exit the
demo mode.

How do I watch Cable/Antenna TV channels?

• If you subscribe to cable or satellite, simply connect an HDMI cable
(not included) to the receiver.

• If you use external antennas to watch local broadcast channels, use a
coaxial cable to connect.

Some of my Channels are missing.

• Press the MENU button on your TV remote and select the channels
option. Then select Find Channels.

• Open the VIZIO SmartCast Mobile™ app on your phone or tablet.
Click on: Control > Your TV/Device Name > Settings Icon >

Channels > Find Channels.

How do I disable/enable Viewing Data?

• Press the MENU button on your remote and select the System option.

Select Reset & Admin. Then select Viewing Data to turn the feature on
or o.

• Open the VIZIO SmartCast Mobile™ app on your phone or tablet.
Click on: Control > Your TV/Device Name > Settings Icon > System >

Reset & Admin > Viewing Data Slider.

The television will not turn on using Alexa or Google Assistant.

• Ensure the television is in Quick Start mode.

• Tap on Menu > System > Power Mode > Quick Start.

How do I know I am getting 4K resolution or HDR content such as
Dolby Vision?

• As you are watching content on the television, press the INFO button

on the remote or VIZIO SmartCast Mobile™ app. You will see the

current resolution being displayed along with the version of video.

• HDR will show as a Dolby Vision icon, HDR10 or HLG.

The TV has pixels (dots) that are always dark.

• Your HD TV is precision-manufactured using an extremely high level
of technology. However, sometimes pixels may not display correctly.
These types of occurrences are inherent to this type of product and do
not constitute a defective product.

I see “noise” or static on the screen.

• When your TV’s digital capabilities exceed a digital broadcast signal,
the signal is up-converted (improved) to match your TV’s display
capabilities. This up-converting can sometimes cause irregularities in
the image.

• If you are using an antenna, the signal strength of the channel may be
low. Ensure your antenna is connected securely to the TV and move
the antenna around the room or close to a window for the best signal.

49

Specications

D24h-G9 D32h-G9 D40f-G9 D50x-G9

Size 24” 32” 40” 50”

Viewable Area 23.5” 31.5” 39.5” 49.5”

MOUNTING

B

Dimensions w/ Stand

Dimensions w/o Stand

Weight w/ Stand 7.01 lb (3.18 kg) 9.44 lb (4.28 kg) 14.55 lb (6.60 kg) 21.83 lb (9.90 kg)

Weight w/o Stand 6.90 lb (3.13 kg) 9.26 lb (4.20 kg) 14.33 lb (6.5 kg) 21.32 lb (9.67 kg)

Mounting Screw Size M4 M4 M6 M6

Hole Pattern 100 mm x 100 mm 100 mm x 100 mm 200 mm x 200 mm 200 mm x 200 mm

PICTURE QUALITY

Maximum Resolution 720p 1366 x 768 (HD) 1920 x 1080 (Full HD) 3840 x 2160 (UHD)

LCD Backlight Edgelit LED Full Array LED Full Array LED Full Array LED

Refresh Rate 60 Hz 60 Hz 60 Hz 60 Hz

INPUTS / OUTPUTS

HDMI Inputs 2 2 2 3

Component Video Inputs 0 0 1 0

Composite Video Inputs 1 1 1 1

Ethernet Input 0 1 1 1

RF Atenna Input 1 1 1 1

USB 1 1 1 1

Audio Output HDMI ARC, Digital Optical HDMI ARC, RCA, Digital Optical HDMI ARC, RCA, Digital Optical HDMI ARC, RCA, Digital Optical

21.83” x 14.78” x 6.18”

(554.5 x 375.4 x 157.0 mm)

21.83” x 13.15” x 2.06”

(554.5 x 334.0 x 52.3 mm)

28.64” x 18.97” x 7.04”

(727.5 x 482.4 x 178.7 mm)

28.64” x 16.98” x 2.46”

(727.5 x 431.4 x 62.6 mm)

35.51” x 22.59” x 8.36”

(902.0 x 573.8 x 212.3 mm)

35.51” x 20.40” x 2.55”

(902.0 x 518.2 x 64.8 mm)

44.13” x 28.00” x 10.07”

(1120.9 x 711.2 x 255.8 mm)

44.13” x 25.59” x 2.42”

(1120.9 x 650.0 x 61.5 mm)

OTHER

Remote Control Model XRT136 XRT136 XRT136 XRT136

Power Consumption 45W 69W 75W 135W

Standby Power <0.5W <0.5W <0.5W <0.5W

Voltage 120V 120V 120V 120V

OSD Language English, French, Spanish English, French, Spanish English, French, Spanish English, French, Spanish

Certication

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

50

Specications

V405-G9 V505-G9 V655-G9

Size 40” 50” 65”

Viewable Area 39.5” 49.5” 64.5”

MOUNTING

B

Dimensions w/ Stand

Dimensions w/o Stand

Weight w/ Stand 15.21 lb (6.90 kg) 21.83 lb (9.90 kg) 46.69 lb (21.18 kg)

Weight w/o Stand 14.99 lb (6.80 kg) 21.32 lb (9.67 kg) 45.81 lb (20.78 kg)

Mounting Screw Size M6 M6 M6

Hole Pattern 200 mm x 200 mm 200 mm x 200 mm 400 mm x 200 mm

PICTURE QUALITY

Maximum Resolution 3840 x 2160 (UHD) 3840 x 2160 (UHD) 3840 x 2160 (UHD)

LCD Backlight Full Array LED Full Array LED Full Array LED

Refresh Rate 60 Hz 60 Hz 60 Hz

INPUTS / OUTPUTS

HDMI Inputs 3 3 3

Component Video Inputs 0 0 0

Composite Video Inputs 1 1 1

Ethernet Input 1 1 1

RF Atenna Input 1 1 1

USB 1 1 1

Audio Output HDMI ARC, RCA, Digital Optical HDMI ARC, RCA, Digital Optical HDMI ARC, RCA, Digital Optical

35.51” x 22.70” x 8.36”

(902.0 x 576.5 x 212.4 mm)

35.51” x 20.51” x 2.55”

(902.0 x 521.0 x 64.8 mm)

44.13” x 28.00” x 10.07”

(1120.9 x 711.2 x 255.8 mm)

44.13” x 25.59” x 2.42”

(1120.9 x 650.0 x 61.5 mm)

57.37” x 35.61” x 11.95”

(1457.2 x 904.6 x 303.5 mm)

57.37” x 33.10” x 2.41”

(1457.2 x 840.7 x 61.1 mm)

OTHER

Remote Control Model XRT136 XRT136 XRT136

Power Consumption 98W 135W 200W

Standby Power <0.5W <0.5W <0.5W

Voltage 120V 120V 120V

OSD Language English, French, Spanish English, French, Spanish English, French, Spanish

Certication

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

UL, cUL, FCC Class B, BETS-7/

ICES-003 Class B, IC, HDMI (CEC, ARC)

Dolby Audio

51

Regulatory Information

C

FCC Class B Radio Interference Statement
NOTE: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment o and

on, the user is encouraged to try to correct the interference by one or
more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

Notice

The changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the
equipment.

Shielded interface cables and AC power cord, if any, must be used in

order to comply with the emission limits.

The manufacturer is not responsible for any radio or TV interference

caused by unauthorized modication to this equipment. It is the

responsibilities of the user to correct such interference.

FCC Warning

Changes or modications not expressly approved by the party

responsible for compliance with the FCC Rules could void the user’s
authority to operate this equipment.

Caution
Always use a power outlet that is properly grounded.

Canada Notice for License-Exempt Radio Apparatus

This device complies with Industry Canada’s license-exempt RSSs.
Operation is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.

CPC-2-1-28 d’Industrie Canada, License optionnelle pour les appareils

radio de faible puissance, pour plus de détails.

Industry Canada Class B emission compliance statement

This Class B digital apparatus complies with Canadian ICES-003. Cet

appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.

This device operates on a no-protection no-interference basis. Should

the user seek to obtain protection from other radio services operating in
the same TV bands, a radio license is required. Please consult Industry

Canada’s document CPC-2-1-28, Optional Licensing for Low-Power Radio

Apparatus in the TV Bands, for details.

Cet appareil est conforme aux CNR exempts de licence d’Industrie

Canada. Son fonctionnement est sujet aux deux conditions suivantes:

1. le dispositif ne doit pas produire de brouillage préjudiciable, et

2. ce dispositif doit accepter tout brouillage reçu, y compris
un brouillage susceptible de provoquer un fonctionnement
indésirable

Cet appareil fonctionne sur une base sans protection et sans
interférence. Dans le cas où l’utilisateur cherche à obtenir de la
protection des autres services de radio fonctionnant sur les mêmes
bandes TV, aucune license est requise. Veuillez consulter le document

52

Limited Warranty

D

UNITED STATES AND CANADA

BY USING YOUR VIZIO PRODUCT YOU AGREE TO BE BOUND BY ALL
THE TERMS OF THIS WARRANTY. BEFORE USING YOUR VIZIO PRODUCT,
PLEASE READ THIS WARRANTY CAREFULLY. IF YOU DO NOT AGREE TO
THE TERMS OF THIS WARRANTY, DO NOT USE THE VIZIO PRODUCT AND,
WITHIN THIRTY (30) DAYS OF THE DATE OF PURCHASE, RETURN IT FOR A
REFUND TO THE AUTHORIZED RETAILER WHERE YOU PURCHASED IT.

This warranty contains a binding arbitration agreement and a class

action waiver for United States residents. If you live in the United States,
the binding arbitration agreement and class action waiver aect your

rights under this warranty. Please read the text under the section titled

“Binding Arbitration Agreement; Class Action Waiver (U.S. Residents

Only)” carefully.

How Long This Warranty Lasts

For non-commercial use, VIZIO warrants the product on the terms set

forth below for one (1) year from the date of original purchase. For

commercial use, VIZIO warrants this product on the terms set forth
below for ninety (90) days from the date of original purchase.

What This Warranty Covers

VIZIO warrants the product against defects in materials and
workmanship when the product is used normally in accordance with
VIZIO’s user guides and manuals.
Except where restricted by law, this warranty applies only to the original
purchaser of a new product. The purchase must have been made from

an authorized retailer in the United States (including Puerto Rico) or

Canada. The product must also be located in the country where it was
purchased at the time of warranty service.

Zero Bright Pixel Defect Guarantee (Displays Only)

Your product may qualify for a warranty against “zero bright pixel”

defects for the duration of the warranty on select new product
purchases. To determine if this guarantee applies to your product, refer
to the model’s product information page at www.vizio.com, look for

the “zero bright pixel” guarantee on the box, or contact VIZIO Technical
Support at the email address or telephone number below.

How to Get Service

Before obtaining warranty service, you may visit www.vizio.com for
additional help and troubleshooting. To obtain warranty service, contact

VIZIO Technical Support via email at [e-mail] or via

phone at 877 MY VIZIO (877-698-4946).

Your Obligations Before Service

You must obtain pre-authorization before sending your product to a
VIZIO service center. You may be required to supply a purchase receipt
(or copy) to show that the product is within the warranty period. When
you return a product to a VIZIO service center, you must ship the

product in its original packaging or in packaging that aords an equal
degree of protection. VIZIO Technical Support will provide instructions

for packing and shipping the product to the VIZIO service center. ALL

USER DATA AND DOWNLOADED APPLICATIONS STORED ON A PRODUCT
WILL BE DELETED IN THE COURSE OF SOME IN-HOME AND ALL SHIP-IN
WARRANTY SERVICE. If this occurs, your product will be restored to its

original state. You will be responsible for restoring all applicable user
data and downloaded applications. Recovery and reinstallation of user
data and downloaded applications is not covered under this warranty.
In order to protect your personal information, VIZIO recommends that
you always clear all personal information from the product before it is
serviced, regardless of the servicer.

VIZIO’s Responsibilities

If VIZIO determines that a product is covered by this warranty, VIZIO will
(at its option) repair or replace it, or refund the purchase price to you.
There will be no charge for parts or labor during the warranty period.

Replacement parts may be new or recertied at VIZIO’s option and sole

discretion. Replacement parts and VIZIO’s labor are warranted for the
remaining portion of the original warranty or for ninety (90) days from
warranty service, whichever is longer.

Types of Service

TVs that are 32 inches or larger will usually be serviced in-home. In-home
service requires complete and easy access to the product and does not
include de-installation or re-installation of the product. In-home service
is subject to availability. VIZIO will provide other service options when
in-home service is not available.All other VIZIO products must be sent to
a VIZIO service center to obtain warranty service. VIZIO is not responsible
for transportation costs to the service center, but VIZIO will cover return
shipping to the customer.

What This Warranty Does Not Cover

This warranty does not cover: (a) cosmetic damage; (b) normal wear
and tear; (c) improper operation; (d) improper voltage supply or power
surges; (e) signal issues; (f) damage from shipping; (g) acts of God; (h)
customer misuse, modications or adjustments; (i) installation, set-up,

or repairs attempted by anyone other than by a VIZIO authorized service

center; (j) products with unreadable or removed serial numbers; (k)
products requiring routine maintenance; or (l) products sold “AS IS”,
“CLEARANCE”, “FACTORY RECERTIFIED”, or by a non-authorized reseller.

What to Do If You Are Not Satised With Service

If you feel VIZIO has not met its obligations under this warranty, you
may attempt to resolve the issue informally with VIZIO. If you are unable

to resolve the issue informally and wish to le a formal claim against
VIZIO, and if you are a resident of the United States, you must submit

your claim to binding arbitration according to the procedures described

below, unless an exception applies. Submitting a claim to binding

arbitration means that you do not have the right to have your claim
heard by a judge or jury. Instead your claim will be heard by a neutral
arbitrator.

Binding Arbitration Agreement; Class Action Waiver
(U.S. Residents Only)

UNLESS YOU HAVE BROUGHT AN ELIGIBLE CLAIM IN SMALL CLAIMS
COURT OR HAVE OPTED OUT AS DESCRIBED BELOW, ANY CONTROVERSY

OR CLAIM RELATING IN ANY WAY TO YOUR VIZIO PRODUCT, INCLUDING

ANY CONTROVERSY OR CLAIM ARISING OUT OF OR RELATING TO THIS
WARRANTY, A BREACH OF THIS WARRANTY, OR THE VIZIO PRODUCT’S
SALE, CONDITION OR PERFORMANCE, WILL BE SETTLED BY BINDING
ARBITRATION ADMINISTERED BY THE AMERICAN ARBITRATION
ASSOCIATION AND CONDUCTED BY A SINGLE ARBITRATOR APPOINTED
BY THE AMERICAN ARBITRATION ASSOCIATION, IN ACCORDANCE WITH
ITS COMMERCIAL ARBITRATION RULES AND ITS SUPPLEMENTARY
PROCEDURES FOR CONSUMER-RELATED DISPUTES. You may learn more

about the American Arbitration Association and its rules for arbitration

by visiting www.adr.org or by calling 800-778-7879. Since this warranty

concerns a transaction in interstate or international commerce, the
Federal Arbitration Act will apply.

The ling fees to begin and carry out arbitration will be shared between

you and VIZIO, but in no event will your fees ever exceed the amount
allowable by the American Arbitration Association, at which point VIZIO
will cover all additional administrative fees and expenses. VIZIO waives
its right to recover attorneys’ fees in connection with any arbitration
under this warranty. If you are the prevailing party in an arbitration to

which the Supplementary Procedures for Consumer-Related Disputes

applies, then you are entitled to recover attorneys’ fees as the arbitrator
may determine.
The dispute will be governed by the laws of the state or territory in which

you resided at the time of your purchase (if in the United States). The

place of arbitration will be Irvine, California, or your county of residence

(if in the United States). The arbitrator will have no authority to award

punitive or other damages not measured by the prevailing party’s
actual damages, except as may be required by statute. The arbitrator
will not award consequential damages, and any award will be limited

53

D

to monetary damages and will include no equitable relief, injunction,
or direction to any party other than the direction to pay a monetary
amount. Judgment on the award rendered by the arbitrator will be

binding and nal, except for any right of appeal provided by the Federal

Arbitration Act, and may be entered in any court having jurisdiction.
Except as may be required by law, neither you nor VIZIO nor an arbitrator
may disclose the existence, content, or results of any arbitration under
this warranty without the prior written consent of you and VIZIO.

ANY DISPUTE, WHETHER IN ARBITRATION, IN COURT, OR OTHERWISE,
WILL BE CONDUCTED SOLELY ON AN INDIVIDUAL BASIS. VIZIO AND YOU

AGREE THAT NO PARTY WILL HAVE THE RIGHT OR AUTHORITY FOR ANY

DISPUTE TO BE ARBITRATED AS A CLASS ACTION, A PRIVATE ATTORNEY

GENERAL ACTION, OR IN ANY OTHER PROCEEDING IN WHICH EITHER

PARTY ACTS OR PROPOSES TO ACT IN A REPRESENTATIVE CAPACITY.
NO ARBITRATION OR PROCEEDING WILL BE JOINED, CONSOLIDATED,

OR COMBINED WITH ANOTHER ARBITRATION OR PROCEEDING

WITHOUT THE PRIOR WRITTEN CONSENT OF ALL PARTIES TO ANY SUCH

ARBITRATION OR PROCEEDING.
Exceptions to Binding Arbitration Agreement and Class Action Waiver

IF YOU DO NOT WISH TO BE BOUND BY THE BINDING ARBITRATION
AGREEMENT AND CLASS ACTION WAIVER, THEN: (1) you must notify

VIZIO in writing within sixty (60) days of the date that you purchased the

product; (2) your written notication must be mailed to VIZIO at 39 Tesla,
Irvine, CA 92618, Attn: Legal Department; and (3) your written notication

must include (a) your name, (b) your address, (c) the date you purchased
the product, and (d) a clear statement that you wish to opt out of the
binding arbitration agreement and class action waiver.
In addition, you may pursue a claim in small claims court in your county

of residence (if in the United States) or in Orange County, California.
In such case the provisions of the section titled “Binding Arbitration
Agreement; Class Action Waiver (U.S. Residents)” will not apply.

Exclusions and Limitations

TO THE GREATEST EXTENT PERMITTED BY APPLICABLE LAW, THERE ARE
NO EXPRESS WARRANTIES OTHER THAN THOSE DESCRIBED ABOVE.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WILL BE
LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE.
SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY

NOT APPLY TO YOU.

VIZIO WILL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF
INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR
LOST PROFITS, OR OTHER INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, EVEN IF VIZIO HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES, AND EVEN IF THE REMEDY FAILS OF ITS
ESSENTIAL PURPOSE. SOME STATES AND PROVINCES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY

TO YOU.

IN LIEU OF ANY OTHER REMEDY FOR ANY AND ALL LOSSES AND
DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER (INCLUDING
VIZIO’S NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS, NO
MATTER WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT),
VIZIO MAY, AT ITS SOLE AND EXCLUSIVE OPTION AND IN ITS DISCRETION,
REPAIR OR REPLACE YOUR PRODUCT, OR REFUND ITS PURCHASE
PRICE. AS NOTED, SOME STATES AND PROVINCES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY

TO YOU.

How the Law Applies

This warranty gives you specic legal rights, and you may also have other

rights, which vary from state to state and province to province. This
warranty applies to the greatest extent permitted by applicable law.

General

No employee or agent of VIZIO may modify this warranty. If any term
of this warranty, other than the class action waiver, is found to be
unenforceable, that term will be severed from this warranty and all

other terms will remain in eect. If the class action waiver is found to
be unenforceable, then the entire section titled “Binding Arbitration
Agreement; Class Action Waiver (U.S. Residents Only)” will not apply. This

warranty applies to the maximum extent not prohibited by law.

Changes to Warranty

This warranty may change without notice, but any change will not aect

your original warranty. Check www.vizio.com for the most current
version.

54

Legal Information

E

Software Licenses

All software is provided subject to a software license agreement(s)
and you agree that you will be bound by such license agreement(s) in
addition to these terms. Your use of this product is subject to VIZIO’s
privacy policy, which may be updated from time to time, and is available
to view at http://www.vizio.com/privacy.

Export Regulations

Customer acknowledges that the VIZIO products, which include
technology and software, are subject to customs and export control

laws in the United States (“US”). The products may also be subject to the

customs and export control laws and regulations of the country in which
the products are manufactured and/or received.

Internet Connectivity

Network conditions, environmental and other factors may negatively

aect connectivity and the resulting video quality, if any. The applications

and content of the applications pictured herein or described in
accompanying documentation may only be available in certain countries
or languages, may require additional fees or subscription charges, and

may be subject to future updates, modications or discontinuation

without notice. VIZIO has no control over third party applications or
content and assumes no responsibility for the availability or interruption
of such applications or content. Additional third party terms, conditions
and restrictions apply.

Information in this User Manual is subject to change without notice. To
review the most updated version of this User Manual and the associated

Quick Start Guide, go to http://www.vizio.com.

For DTS patents, see http://patents.dts.com. Manufactured under license
from DTS, Inc. DTS, the Symbol, DTS and the Symbol together, and DTS
Studio Sound II are registered trademarks and/or trademarks of DTS,
Inc. in the United States and/or other countries. © DTS, Inc. All Rights

Reserved.

Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby
Laboratories. Manufactured under license from Dolby Laboratories.

Condential unpublished work. Copyright © 2013-2015 Dolby

Laboratories. All rights reserved.

© 2018 Google Inc. All rights reserved. Google Cast is a trademark of

Google Inc.

Other names of companies, products, and services used in this User
Manual may be trademarks, trade names or service marks of others
and VIZIO, Inc. disclaims any interest in trademarks, trade names or
service marks other than its own. Mention of non-VIZIO products is for
informational purposes only.

Battery Disposal

Caution:This product may be shipped with batteries.Do not

dispose of batteries in a re or withordinaryhouseholdwaste.

Batteries may explode and can cause damage. Replace
batteries only with the same or equivalent type of battery

recommended by VIZIO. The disposal of batteries may be
regulated by your state.For more information on recycling or properly
disposing of your batteries, please check with your state or go to www.
vizio.com/environment.

Accessibility
For information on the accessibility features of this product and other
VIZIO products please visit:
https://www.vizio.com/accessibility
Email: [e-mail]

Phone: [phone]

© 2018 VIZIO, Inc. All Right Reserved.

This User Manual may not be copied in whole or in part without the

written permission of VIZIO, Inc. VIZIO, Inc. has made reasonable eorts

to ensure the accuracy of the information provided herein. All product

specications, functionality, features, congurations, performance,

design and other product information described herein are subject to
change without notice. VIZIO, Inc. is not responsible for typographical,
technical, or descriptive errors.

VIZIO, the VIZIO logo, the V logo, and other terms and phrases are
trademarks or registered trademarks of VIZIO, Inc.

The terms HDMI, HDMI High-Denition Multimedia Interface, and the

HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.

Product Recycling
The disposal and recycling of consumer electronic products may be
regulated by your state. Always properly dispose of your VIZIO products
in accordance with local laws and regulations. VIZIO supports the proper
recycling of our products. For information on how to properly recycle
your VIZIO products and to learn more about consumer electronics
recycling laws, please go to www.vizio.com/environment or call (800)
374-3473.

Packaging Disposal
VIZIO encourages the recycling of the packaging used for this
product. Please break-down all boxes and recycle eligible
materials according to local laws and regulations. For more
information please go to www.vizio.com/environment or call
[phone].

© 2018 VIZIO INC. ALL RIGHTS RESERVED.
181219SL

55
