USER MANUAL

Model D32h-G0

Safety & Certification

Safety & Certication

THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO TV. To get the most out of your new VIZIO product, read these instructions

before using your product and retain them for future reference. Be sure to inspect the package contents to ensure there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services for your VIZIO product, visit our website at www.VIZIO.com or call toll free at (877) 698-4946.

We recommend that you register your VIZIO product at www.VIZIO. com.

Extended Warranties For peace of mind, and to protect your investment beyond the standard

warranty, VIZIO oers on-site extended warranty service plans. These plans provide additional coverage during the standard warranty period. To purchase an extended warranty service plan, visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the accompanying important warning or notice. It is intended to alert you to the presence of important operating instructions.

When you see this symbol, please read the accompanying helpful tip.

IMPORTANT SAFETY INSTRUCTIONS

Your TV is designed and manufactured to operate within dened design limits. Misuse may result in electric shock or re. To prevent your TV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your TV. Read the following safety instructions before operating your TV. Keep these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component damage, switch o the power before connecting other components to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories specied by the manufacturer.

• Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your TV to avoid causing re, electric shock, or component damage.

• A distance of at least three feet should be maintained between your TV and any heat source, such as a radiator, heater, oven, amplier etc. Do not install your TV close to smoke. Operating your TV close to smoke or moisture may cause re or electric shock.

• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your TV in a bookcase or cabinet unless proper ventilation is provided.

• Never push any object into the slots and openings on your TV cabinet. Do not place any objects on the top of your TV. Doing so could short circuit parts causing a re or electric shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

• Do not apply pressure or throw objects at your TV. This may compromise the integrity of the TV. The manufacturer’s warranty does not cover user abuse or improper installations.

• The power cord must be replaced when using dierent voltage than the voltage specied. For more information, contact your dealer.

• When connected to a power outlet, power is always owing into your TV. To totally disconnect power, unplug the power

cord.

• The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the inside

of your TV that may be of sucient magnitude to constitute a

risk of electric shock to persons.

• Do not overload power strips and extension cords.

Overloading can result in re or electric shock.

• The wall socket should be installed near your TV and easily accessible.

• Only power of the marked voltage can be used for your TV.

Any other voltage than the specied voltage may cause re or

electric shock.

• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.

• Unplug your TV during a lightning storm or when it will not be used for long period of time. This will protect your TV from damage due to power surges.

• Do not attempt to repair or service your TV yourself. Opening

or removing the back cover may expose you to high voltages,

electric shock, and other hazards. If repair is required,

contact your dealer and refer all servicing to qualied service

personnel.

• WARNING: Keep your TV away from moisture. Do not expose

your TV to rain or moisture. If water penetrates into your TV, unplug the power cord and contact your dealer. Continuous use

in this case may result in re or electric shock.

• Do not use your TV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your TV yourself.

• Avoid using dropped or damaged appliances. If your TV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use

of your TV may cause re or electric shock.

• Do not install your TV in an area with heavy dust or high humidity. Operating your TV in environments with heavy dust

or high humidity may cause re or electric shock.

• Follow instructions for moving your TV. Ensure that the power cord and any other cables are unplugged before moving your TV.

• When unplugging your TV, hold the AC/DC power adapter, not the cord. Pulling on the power cord may damage the wires

inside the cord and cause re or electric shock. When your TV will not be used for an extended period of time, unplug the

power cord.

• To reduce risk of electric shock, do not touch the connector with wet hands.

• Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to leak which can damage

the remote control or injure the operator. Do not expose batteries to excessive heat such as sunshine, re or the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

- Your TV is exposed to rain or other moisture.

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

• This apparatus shall not be exposed to dripping or splashing

and no objects lled with liquids, such as vases, shall be

placed on the apparatus.

• The mains plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• CAUTION: These servicing instructions are for use by qualied

service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the

operating instructions unless you are qualied to do so.

• The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the

presence of uninsulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sucient magnitude to

constitute a risk of electrical shock to persons.

• WARNING: Exposure to loud sounds can damage your hearing

causing hearing loss and tinnitus (ringing or buzzing in the

ears). with continued exposure to loud noises, ears may

become accustomed to the sound level, which may result in permanent damage to hearing without any noticeable

discomfort.

• Install the TV where it cannot be pulled, pushed or knocked over.

• Do not allow children to hang onto the product.

• Store the accessories (remote, batteries, etc.) in a location safely out of the reach of children.

• The American Academy of Pediatrics discourages television viewing for children younger than two years of age.

• WARNING: Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death.

• Many injuries, particularly to children, can be avoided by taking

• simple precautions such as:

• Using cabinets or stands recommended by the manufacturer of the television set.

• Only using furniture that can safely support the television set

• Ensuring the television set is not overhanging the edge of the supporting furniture.

• Not placing the television set on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television set to a suitable support.

• Not placing the television set on cloth or other materials that may be located between the television set and the supporting furniture.

• Educating children about the dangers of climbing on furniture to reach the television set or its controls.

• If your existing television set is being retained and relocated, the same considerations as above should be applied.

iii

TELEVISION ANTENNA CONNECTION PROTECTION

If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides

information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it is left unattended or unused for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.

Power Lines

Ground Clamp

Antenna Lead In Wire

Antenna Discharge Unit

(NEC Section 810-20)

Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines or circuits. Remember, the

screen of the coaxial cable is intended to be connected to earth in

the building installation.

Electric Service Equipment

Grounding Conductors

(NEC Section 810-21)

Ground Clamps

Power Service Grounding Electrode System

(NEC ART 250, part H)

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Studio Sound is a

Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are

trademarks of Dolby Laboratories.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruVolume is a trademark

HDMI, the HDMI logo and High-Denition Multimedia

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.
