Vizio Co-Star VAP430, ISG-B03 User Manual

USER

GUIDE

INSTALLING THE CO-STAR

GETTING TO KNOW THE CO-STAR

WATCHING TV ON THE CO-STAR

BROWSING THE WEB

USING THE ON-SCREEN MENU

TROUBLESHOOTING & SUPPORT

SPECIFICATIONS, SAFETY & LEGAL

MODELS

// E3D320VX
// E3D420VX
// E3D470VX

MODEL

VAP430

This product qualifies for ENERGY STAR in the “factory
default” setting and this is the setting in which power
savings will be achieved. Changing the factory default
picture settings or enabling other features will increase
power consumption that could exceed the limits

necessary to qualify for ENERGY STAR rating.

HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing

LLC.

®

Welcome

THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO Co-Star.

To get the most out of your new VIZIO product, read these
instructions before using your product and retain them for future
reference. Be sure to inspect the package contents to ensure
there are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services
for your VIZIO product, visit our website at www.VIZIO.com or call
toll free at [phone].

We recommend that you either:

• Register your VIZIO product at www.VIZIO.com

• Complete the on-screen registration

Extended Warranties

For peace of mind, and to protect your investment beyond the
standard warranty, VIZIO offers on-site extended warranty service
plans. These plans provide additional coverage during the
standard warranty period. To purchase an extended warranty
service plan, visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the
accompanying important warning or notice. It is
intended to alert you to the presence of important
operating instructions.

When you see this symbol, please read the
accompanying helpful tip.

Important Safety Warnings

4

Your Stream Player is designed and manufactured to operate
within defined design limits. Misuse may result in electric shock
or fire. To prevent your Stream Player from being damaged, the
following instructions should be observed for the installation,
use, and maintenance of your Stream Player. Read the following
safety instructions before operating your Stream Player. Keep
these instructions in a safe place for future reference.

To reduce the risk of electric shock or component damage,
switch off the power before connecting other components to
your Stream Player.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with a dry cloth.

• Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

• Protect the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.

• Only use attachments/accessories specified by the
manufacturer.

• Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when
unused for long periods of time.

• Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been
damaged in any way, such as when the power-supply
cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally or has been dropped.

• Unplug the power cord before cleaning your Stream
Player.

• When moving your Stream Player from an area of
low temperature to an area of high temperature,
condensation may form in the housing. Wait before
turning on your Stream Player to avoid causing fire,
electric shock, or component damage.

• A distance of at least three feet should be maintained
between your Stream Player and any heat source, such
as a radiator, heater, oven, amplifier etc. Do not install
your Stream Player close to smoke. Operating your
Stream Player close to smoke or moisture may cause fire
or electric shock.

• Slots and openings in the back and bottom of the
cabinet are provided for ventilation. To ensure reliable
operation of your Stream Player and to protect it from
overheating, be sure these openings are not blocked or
covered. Do not place your Stream Player in a bookcase
or cabinet unless proper ventilation is provided.

• Never push any object into the slots and openings on
your Stream Player cabinet. Do not place any objects on
the top of your Stream Player. Doing so could short circuit
parts causing a fire or electric shock. Never spill liquids
on your Stream Player.

• Your Stream Player should be operated only from the type
of power source indicated on the label. If you are not
sure of the type of power supplied to your home, consult
your dealer or local power company.



Important Safety Warnings

5

• Do not apply pressure or throw objects at your Stream
Player. This may compromise the integrity of the display.
The manufacturer’s warranty does not cover user abuse
or improper installations.

• The power cord must be replaced when using different
voltage than the voltage specified. For more information,
contact your dealer.

• When connected to a power outlet, power is always
flowing into your Stream Player. To totally disconnect
power, unplug the power cord.

• The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of un-isolated, dangerous voltage within the
inside of your Stream Player that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

• Do not overload power strips and extension cords.
Overloading can result in fire or electric shock.

• The wall socket should be installed near your Stream
Player and easily accessible.

• Only power of the marked voltage can be used for
your Stream Player. Any other voltage than the specified
voltage may cause fire or electric shock.

• Do not touch the power cord during lightning. To avoid
electric shock, avoid handling the power cord during
electrical storms.

• Unplug your Stream Player during a lightning storm or
when it will not be used for long period of time. This will
protect your Stream Player from damage due to power
surges.

• Do not attempt to repair or service your Stream Player
yourself. Opening or removing the back cover may
expose you to high voltages, electric shock, and other
hazards. If repair is required, contact your dealer and
refer all servicing to qualified service personnel.

• WARNING: Keep your Stream Player away from moisture.
Do not expose your Stream Player to rain or moisture.
If water penetrates into your Stream Player, unplug the
power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.

• Do not use your Stream Player if any abnormality occurs.
If any smoke or odor becomes apparent, unplug the
power cord and contact your dealer immediately. Do
not try to repair your Stream Player yourself.

• Avoid using dropped or damaged appliances. If your
Stream Player is dropped and the housing is damaged,
the internal components may function abnormally.
Unplug the power cord immediately and contact your
dealer for repair. Continued use of your Stream Player
may cause fire or electric shock.

• Do not install your Stream Player in an area with heavy
dust or high humidity. Operating your Stream Player in
environments with heavy dust or high humidity may
cause fire or electric shock.

• Follow instructions for moving your Stream Player.
Ensure that the power cord and any other cables are
unplugged before moving your Stream Player.

• When unplugging your Stream Player, hold the AC/DC
power adapter, not the cord. Pulling on the power cord
may damage the wires inside the cord and cause fire or
electric shock. When your Stream Player will not be used
for an extended period of time, unplug the power cord.

• To reduce risk of electric shock, do not touch the
connector with wet hands.

• Insert batteries in accordance with instructions.
Incorrect polarities may cause the batteries to leak
which can damage the remote control or injure the
operator. Do not expose batteries to excessive heat
such as sunshine, fire or the like.

Important Safety Warnings

6

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your Stream
Player.

- Your Stream Player is exposed to rain or other moisture.

- Your Stream Player is dropped or damaged in any way.

- The performance of your Stream Player changes
substantially.

• This apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.

• The mains plug or appliance coupler is used as the
disconnect device, the disconnect device shall remain
readily operable.

• CAUTION - These servicing instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you
are qualified to do so.

The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to
the presence of uninsulated DANGEROUS VOLTAGE
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electrical
shock to persons.

The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.

h

7

Table of Contents

What is the Co-Star? ...........................................9

A New Kind of Television experience ..................................9

Watch This! ..........................................................................10

Explore & Discover .............................................................. 11

What Sets the Co-Star Apart ............................................... 12

Have Fun! ............................................................................13

Installing the Co-Star ....................................... 14

Inspecting the Package Contents .....................................14

First time setup ...................................................................15

Connecting the Co-Star to Your Home Audio System ........ 19

Using Guided Setup ...........................................................21

Getting to Know the Co-Star ............................ 22

Co-Star (Rear).....................................................................22

Resetting the Co-Star .......................................................23

Remote Control ..................................................................25

Remote Control (Continued) ............................................. 26

Using the Remote ...............................................................27

Replacing the Batteries ...................................................27

Using the Trackpad ..........................................................28

Getting to know the On-Screen Menu ...............................29

Connecting Additional Accessories ..................................30

Connecting USB Devices .................................................31

Using the On-Screen Menu .............................. 32

Navigating the On-Screen Menu .......................................32

Google TV™ & Featured Apps ............................................ 32

Notifications ........................................................................ 33

Accessing and Managing Notifications .........................33

Managing Apps .................................................................34

Adding and Removing Apps ...........................................34

Managing Favorite Apps .................................................35

Creating a Custom Category .......................................... 36

Removing Apps from a Custom Category ......................36

Deleting a Custom Category ..........................................36

Using the Settings Menus ...................................................37

Using the Guided Setup ..................................................37

Adjusting Video Settings .................................................. 38

Adjusting Basic Video Settings ........................................38

Adjusting Advanced Video Settings ............................... 39

Adjusting Audio Settings ..................................................39

Setting up Devices .............................................................. 40

Adding/Removing Video and Audio Devices .................40

Adding/Removing a TV (HDMI Out device) .................... 40

Adding/Removing a Bluetooth Device ...........................41

Managing Pointer Devices ..............................................42

Enabling/Disabling HDMI CEC ........................................42

Restoring the Co-Star to Factory Default Settings ..........43

Application Settings ...........................................................43

Search Bar Settings ..........................................................43

Managing Privacy and Safety .........................................44

Managing Accounts ........................................................ 45

Managing Applications ................................................... 46

Managing Services .......................................................... 46

Accessing Development Tools ......................................... 47

Reset Applications to Factory Default Settings ................47

Network Settings ................................................................. 48

Manual Ethernet Setup .................................................... 48

Wi-Fi Setup ........................................................................ 49

8

Manual Wi-Fi Network Setup ............................................ 49

System Settings ...................................................................50

Adjusting the Time and Local Settings ............................50

Using Chrome with the Co-Star ........................ 51

Web Browsing with the Co-Star ...........................................51

Navigating the Web ...........................................................52

Using Bookmarks ................................................................52

Deleting Browser History .....................................................52

Sharing Web Pages ............................................................53

Managing Privacy and Safety ............................................53

Troubleshooting................................................ 54

Limited Warranty ............................................... 58

Legal and Compliance .................................... 59

9

1

What is the Co-Star?

A NEW KIND OF TELEVISION EXPERIENCE

The VIZIO Co-Star merges live TV and streaming entertainment into
one experience, bringing apps and full-screen Web browsing to
your existing HDTV, all without interrupting what you’re watching.

1

10

WATCH THIS!

Use the TV & Movies app to easily browse content. Setup the app
with your watching preferences, and results will be tailored to
your personal tastes.

1

11

EXPLORE & DISCOVER

We’ve pre-loaded some of the best apps available, but there are
thousands more waiting for you in the Google Play store. Check
out its easy-to-use menus to search for new apps, games, and
more!

1

12

Web Surfing

Co-Star is among a few stream players
that feature a full Internet browser
with the blazing fast Google Chrome.
Support for Adobe Flash Player® and
HTML 5 means you can access any of
the popular Flash or HTML 5 enabled
sites without limits.

Remote Control

VIZIO Co-Star includes a universal
Bluetooth® remote with an innovative
touchpad that lets you touch,
tap, scroll and drag. A full QWERTY
keyboard helps users search for their
favorite entertainment. The built-in IR
blaster provides universal functionally,
making it easy to control all your
home entertainment devices with
one remote.

Advanced Technology

The VIZIO Co-Star incorporates a
number of features intended to satisfy
power users, including support for
1080p Full HD and 3D entertainment.
Built-in 802.11n Wi-Fi provides easy
wireless Internet access without
unsightly wires, and thanks to the
USB port, you can connect storage
devices, keyboards and other
peripherals. And don’t forget, geeks:
Using apps from Google Play Store,
you can enjoy photos, music, and
movies from any DLNA-enabled
phone, tablet, or computer.

Live TV Integration

The VIZIO Co-Star™ is unique in
that you can connect it to a cable
or satellite box. This allows you
to enjoy live TV while surfing the
web, using apps, gaming online,
streaming entertainment—all without
interruption. You can even pull search
results across apps, the Web, local
content and television listings at the
same time.

Apps Everywhere

Co-Star takes the app entertainment
experience to the next level like
no other stream player before.
With access to thousands of apps,
including favorites like Netflix®,
Amazon Instant Video, and Pandora®.
Co-Star also introduces new app
experiences such as the OnLive

®

game service, which lets you play
top-tier video games from the cloud
to your TV.

WHAT SETS THE CO-STAR APART

13

1

HAVE FUN!

Sure, the VIZIO Co-Star is a powerful new way to enjoy TV, but more than
anything, it’s fun! So whether you’re a casual user or “super-geek,” use this
manual to help you to get the most from your new stream player; there is a
lot to discover.

Explore and enjoy—and thank you for supporting VIZIO.

14

2

Installing the Co-Star

INSPECTING THE PACKAGE CONTENTS

Before installing your new Co-Star take a moment to inspect
the package contents. Use the images below to ensure
nothing is missing or damaged.

Package Contents

Power Adapter

Quick Start Guide

VIZIO Co-Star with Google TV

™

Stream Player

Remote with Batteries

YOU WILL NEED

Internet connection

(Wired or wireless)

HDTV with an available

HDMI input port

HDMI

Cable

HD Cable or satellite box

with an available HDMI port

A second HDMI Cable

FOR THE BEST EXPERIENCE, YOU SHOULD ALSO HAVE

For the best online experience, you should have a
high-speed internet connection (Minimum 10 Mbps­higher is better).

2

15

Connect to

HDMI IN

HDMI Cable*

HD Cable/Satellite Box

FIRST TIME SETUP

After removing the Co-Star from the box and inspecting
the package contents you can begin installing the Co-Star.
Before you begin, make sure your TV has an available HDMI
port and that all devices are powered off.

*HDMI Cable sold separately.

Connecting the Co-Star

1

Connect your cable or satellite box to the Stream Player
with an HDMI cable.*

The Stream Player can be used without an HD Cable/
Satellite Box, but you will not be able to enjoy the TV
search, picture-in-picture, and other great features.

2

16

Connect to

HDMI OUT

HDMI Cable*

HDTV

Connecting the Co-Star

Connect the Stream Player to your TV with an HDMI cable.*

*HDMI Cable sold separately.

2

2

17

Ethernet Cable*

Connect to LAN

Router or Modem

*Ethernet Cable sold separately.

Connecting the Co-Star

Connect the Stream Player to your router or
modem with an Ethernet cable.*

If you want to connect wirelessly, skip this step.
[For best experience, wired connection is
recommended.]

3

2

18

Connecting Power Cord

Connect to DC IN

Power Light

4

Connect the power adapter to the Stream Player to DC IN as shown.

Plug the power adapter into an electrical outlet. The Stream Player

powers on.

2

19

CONNECTING THE CO-STAR TO YOUR HOME AUDIO
SYSTEM

If you have a home audio system that you would like to use
with your Stream Player, use the diagrams below to connect
your devices.

HDTV with ARC

Cable Box Co-Star

Sound Bar

or

AV Receiver

Connect your HDTV to a
Sound Bar or AV receiver
using one of the following
cables (not included).

HDMI Cable

HDMI Cable

Co-Star AV Setup - HDTV with ARC

RCA Cable

3.5 mm Cable

Good

Better

HDMI Cable

Best

Optical Cable

OR

OR
