Vivotek NR9682-V2 Specsheet

NR9682-v2

H.265 64CH 16Bay NVR

H.265 • VAST 2 Inside • 64CH • 16 x HDD • ONVIF • Dual LAN • Fisheye Dewarp •
RAID • Redundant Power

H.265/ H.264 C ompres s ion Tec hnology

Up to 64C H R ec ording, 64C H D is play

Support HD MI, D isplay P ort & D V I S im ultaneous O utput

16 H ot- S w appable H D D B ays

Support R AID 0/1/5/6/10 S torage

R edundant P ower

VIVO T E K VAS T 2 C MS Inside

C yber s ecur ity Management S olution

Sm art Search II

Sm art VC A/S m art 360 VC A E vent S earc h

D ual L an Giga Network P orts

Multiple F isheye D ew arp S upport

Multiple Video Search Modes

Technical Specifications

Device

Model NR9682-v 2

OS Embedded Windows 10

CPU Int el CPU

Flas h 128GB mSATA

RAM 4GB x 2

Watc hdog Hardware + Sof tware

Power Res t orat ion Sy st em res t art aut omat ic all y af ter power rec ov ery

Local Display

Liv eView Displ ay

64 Channels
Equal: 1x1, 2x2, 3x3, 4x4, 5x5, 6x6, 7x7, 8x8
Panorama: 1P+6, 2P, 2P+3, 3P
Focus: 1+12, 1+16, 1+3, 1+5, 1+7, 1+9, 2+8
Vert ic al: 1V+6, 2V+2, 2 V+3, 3V, 3V+4, 4V, 4V+4, 5V
Single l ay out dis play , f ull sc reen display
Cust om lay out, lay out rotat ion

Video Output HDMI x1, Display Port x1, DVI x 1

Dis play Res oluti on

HDMI: 1920x1080
DVI: 1920x1080
DP: 4096x2304

Dual Moni t or Support ed

Camera Posit ion Change t he v iew cel l pos it ion on the li v e v iew sc reens

Stream Applicat ion Stream sel ect ion & auto st ream s ize

Monitor Enhancement

eMap embedded
Drag & Drop
Remot e I/ O cont rol
PiP (digit al zoom)
Ins t ant pl ay back
Video dis play mode (as pect rat io & camer a inf ormat ion)
Metadat a display (VC A, POS and Data Magnet )

Fis hey e Dewarp 1O, 1P, 1R, 1O3R, 4R, 2P, 4 R Pro, 1O8R and f is hey e auto-pan

PTZ/ePTZ Operat ion

Direct ion c ont rol , home, zoom, f ocus, ir is , preset , patr ol (gr oup), tr ack ing, pan, st op,
speed, wiper blade c ont rol

Video

Video For mat MJPEG, MPEG4, H.264 AVC, H.264 SVC, H.265

Graphic Decoder Sof t ware decodi ng

Decodi ng Res olut ion Up to 8192x8192

Decodi ng Capabi li ty

H.264: 1920x1080 @ 540 f ps
H.265: 1920x1080 @ 270 f ps

Audio

Audio For mat G.711, G. 726, AMR, AAC

Audio I n/ Out

Microphone audio jac k Input x1

3.5 l ine output audio jack x1

2-way Audio Support ed

Record

Recor ding Time (sec. )

Pre-Record: 3-15
Post -Rec ord: 10-60

Recor ding Stream Single

Recor ding Throughput 512 Mbps

Recor ding Mode Cont inuous , ev ent , c ust omized s chedule, act ivit y adapt iv e str eaming

Recor ding Setti ng Recy cli ng ti me depends on t he remai ning s t orage space or t he set number of days

Seamles s Recording Support ed

Storage & Backup

HDD Devi ces

Hot-Swappable t ray x16
*H DD is purc hased by separat ely .

HDD Max . Capaci ty *Pl ease ref er to t he HDD s upported list on the VIVOTEK websi te.

RAID RAI D 0, 1, 5, 6, 10

Dis k Management Creat e, f ormat and remov e di sk

Manual Bac kup

USB Dongle (FAT For mat )
NAS ( SMB & CIFS)

Schedul e Backup NAS ( SMB & CIFS)

Playback

Play back Di spl ay

64 Channels (t he max . number of monit ors support ed depends on t he decodi ng capabilit y
of y our s y stem)
Equal: 1x1, 2x2, 3x3, 4x4, 5x5, 6x6, 7x7, 8x8
Panorama: 1P+6, 2P, 2P+3, 3P
Focus: 1+12, 1+16, 1+3, 1+5, 1+7, 1+9, 2+8
Vert ic al: 1V+6, 2V+2, 2 V+3, 3V, 3V+4, 4V, 4V+4, 5V
Single l ay out dis play , f ull sc reen display
Cust om lay out, lay out rotat ion

Play back Cont rol Pl ay, rewind, pause, st op, next /prev ious f rame, 1/64X ~ 64X speed contr ol, bookmark

Video Searc h

Calendar, ev ent , al arm, bookmark, thumbnail , Smart Search I I, trans act ion ( POS), Data
Magnet, l og

Snapshot BMP & JPEG

Video Cl ip Export 3GP & EXE

Networ k

Ether net 10/100/1000Mbps Ether net ( RJ-45) x2

Video Throughput f or Remote Cli ent 400 Mbps

Prot ocol s

IPv 4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/ RTCP, SMTP, FTP, DHCP, NTP, DNS,
DDNS, I P F il ter

Alarm Management

Alarm Period (sec. ) Max. 30

Alarm Filt er Time, tr igger ty pe ( camer a/subs tati on/ sy st em), st atus, name, trigger sour ce

Alarm Setting

Realt ime s y stem notif icati on
Alarm result dis play by list or t humbnai l

Schedul e Type Cont inuous , schedule, manual

Camera Event

General:
motion det ect ion, camera DI , camera DO, IR (inf rared), PIR ( pass iv e i nf rared),
tampering detec t ion, temperat ure, camer a dis connec t ed, recording er ror, stop recordi ng,
v ideo l oss (v ideo serv er onl y ), SD card l if e expec tancy det ect ion, audio detec t ion,
shoc k detect ion
Smart VCA:
int rus ion det ecti on, loiter ing detect ion, line cross ing detect ion, unat t ended object
detect ion, missi ng object detect ion, face det ect ion
Smart 360 VCA:
int rus ion det ecti on, crowd det ect ion, loit eri ng detect ion
Trend Micro IoT Sec urity :
brut e f orce at tack, cy berat t ack , quarant ine ev ent

Subst at ion

ND Series NVR:
f an st atus, network dis connect ed, st orage failure, st orage f ull , number of remaining
people, brut e f orce at tack , cy berat tack , quarant ine event
NR Series NVR:
network dis connect ed, st orage f ail ure, st orage f ull
NV Series NVR:
abnormal G-sens or motion, speedi ng, GPS di sc onnect ed

Ext ernal Dev ices Event DI/O (wit h I / O box ), TCP mes sage

Act ion

Star t to record v ideos, set DO st at us, go to camera pres et s, send HTTP request s, send
liv e st reaming, send emai l wit h snaps hot of ass igned c amera(s) , go to eMap, sound the
alarm and add bookmar k

Alarm State f or Management New, in progress , f alse alar m and close

Alarm Result Export .c sv f ile

eMap

Source Import pictur e & f older

Dev ice Camera, ext ernal DI / O

Marked Add, remov e, di rec t ion control, PTZ c ont rol , F OV c ont rol, liv e v iew & play back

Ev ent Notif icat ion One or more li v e st reaming

External Interface

USB

Front : USB 3. 0 x2
Back: USB 3.0 x 6, USB2.0 x 2

Audio

Microphone audio jac k Input x1

3.5 Li ne out put audio jack x 1

System

POS I ntegrat ion Support ed

UPS Int egrati on Suppor ted

Camera Integrat ion ONVI F Prof ile S

I/ O Box Integr at ion

Adv ant ech ADAM- 6000 ser ies
CHI YU CYT-133SC
MOXA ioLogi k E1210, E1211 and E1212

User Management

Authent icat ion: basi c account / Windows AD acc ount
User account: 1024
User l ev el: adminis tr at or / customized user

Log Operation, sy st em and ev ent log

Date & Time Sync s erv er

Advanced Features

VCA Counting Soluti on Support ed

VCA Event Sear ch Smart VCA, Smart 360 VCA

Smart Search Smart Search, Smart Searc h I I

Cy bersecurity Management Support ed

Fail ov er Supported

Remote Client

Sof t ware AP Shepherd, VAST 2

Mobile/ Tablet App iViewer (iOS/Androi d)

Web Browser Int ernet Expl orer 9 (32 bit) or abov e

Gener al

Power I nput Redundant power 100~220V AC

Power Consumpt ion Max. 550 W

Redundant Power Suppor ted

80 Plus Cert if ied Sil v er

Dimens ions 132 ( H) x 435 (W) x 540 (D) mm

Weight 33 kg (without HDD)

Operating Temperat ure 5°C ~ 35° C (41° F ~ 95°F )

Humidi t y 0 ~ 95%

Saf et y Cert if ic at ions CE, FCC, VCCI , C-Tick , UL, CB

Warrant y 36 months

Dimensions

Ordering I nformation

Model Description P/N

NR9682-v2 H.265 64CH 16Bay NVR 100217100G
