Vitamix A3500 User Manual

Vitamix® Containers

For Use With Vitamix Ascent and Venturist Series Blenders

Use and Care Manual

Read and save these instructions

Vita-Mix® Corporation

Cleveland, OH 44138-2103 U.S.A.

1-800-848-2649 / 1-440-235-4840

8615 Usher Road

vitamix.com

Im p o rta n t Sa f e g u a r d S

WARNING: To avoid the risk of serious injury when using your Vitamix® blender, basic safety precautions should be followed, including the following.

BEFORE OPERATING BLENDER.

1. Read all instructions.

2. Do not use blender for other than intended use.

3. Avoid contacting moving parts.

4. Keep hands and utensils out of container while blending to reduce the risk of severe

injury to persons or damage to the blender. A rubber scraper or spatula may be used, but only when the blender is not running.

5. The tamper provided must be used only when the main part of the lid is in place.

6. Blades are sharp. Clean around the blade assembly in the container with extreme care

to avoid injury. To reduce the risk of injury, never place a blade assembly on the motor base unless assembled to the Vitamix container.

7. Care should be taken when handling the sharp cutting blades, emptying the container

and during cleaning.

8. Do not leave foreign objects, such as spoons, forks, knives or the lid plug, in the

container as this will damage the blades and other components when starting the blender and may cause injury.

9. Never attempt to operate with damaged blades.

10. Always operate blender with lid and lid plug ﬁrmly in place. The lid plug should be

removed only when adding ingredients and when using the tamper.

11. When blending hot liquids or ingredients in the 48 oz. or 64 oz. containers, use

caution; spray or escaping steam may cause burns. Keep hands and other exposed skin away from lid opening to prevent possible burns.

12. Do not ﬁll container to the maximum capacity.

13. Always begin processing on the lowest speed setting, variable speed 1.

14. When making nut butters or oil-based foods, do not process for more than one

minute after the mixture starts to circulate in the container. Processing for longer periods can cause overheating.

15. Make sure that the container is ﬂush with the centering pad to ensure that the drive

spline is engaged with the drive socket before operating.

READ ALL INSTRUCTIONS, SAFEGUARDS, AND WARNINGS

SAVE THESE INSTRUCTIONS

WARNING

To Avoid Injury.

Read and understand instruction manual.

IMPORTANT INSTRUCTIONS FOR SAFE USE

This product is intended for HOUSEHOLD USE ONLY and is not intended to be used for commercial purposes.

Any repair, servicing, or replacement of parts must be performed by Vitamix or an authorized service representative.

NOTICE: THE FAILURE TO FOLLOW ANY OF THE IMPORTANT SAFEGUARDS AND IMPORTANT INSTRUCTIONS FOR SAFE USE IS A MISUSE OF YOUR VITAMIX BLENDER THAT CAN VOID YOUR WARRANTY AND CREATE THE RISK OF SERIOUS INJURY.

2

pa rtS a n d f e at u r e S

Note: Your container, lid, lid plug and tamper may look dierent from this illustration. 64 oz. (2 L) container shown here for detail.

2-Part Lid

Container

Centering Pad

2-Part Lid: Always use the lid and the lid plug when the machine is in operation.

CAUTION: Lids and tampers are not interchangeable between dierent container styles, types, and sizes.

The tamper allows you to accelerate the process of very thick or frozen mixtures that

Tamper:

cannot be processed in a regular blender. Using the tamper maintains circulation by preventing air pockets from forming. While the machine is running, and only through the lid plug opening, use the tamper to press ingredients into the blades.

Vitamix

64 oz. Low Proﬁle Containers use Tamper P/N 016041 that is approximately 11 inches long. Vitamix 32 oz. and 48 oz. Containers use Tamper P/N 015033 that is approximately 9-¾inches long.

Lid Plug: Insert through the lid and secure by turning clockwise. Remove the lid plug to use the tamper or add ingredients.

Lid Plug (in place)

Lid

Tamper

To Lock the Lid in Place:

1. Position lid on container with lid ﬂaps midway between the spout and the handle.

2. Push the lid onto the container until it locks in place.

3. The lid must always be secured when processing, especially hot liquids that may scald.

WARNING

Rotating Blades Can Cause Severe Injury.

DO NOT reach into container while machine is running.

To Remove the Lid: Lift up on one lid ﬂap while holding the container securely. To Remove the Lid Plug: Rotate the lid plug counterclockwise from the “locked” to

“unlocked” position and lift out. Container: Ounces, cups, and milliliters are clearly marked.

op e r at I n g I n S t r u c t I o n S

For operating instructions, refer to the owner’s manual that was provided with your Vitamix blender.

3

ca r e a n d cl e a n I n g

BEFORE FIRST USE:

Wash the container, cups, lids, lid plug, and tamper with warm, soapy water. Rinse all parts. Wipe dry with a dry, soft cloth.

Note: Your Vitamix container is designed to be completely cleanable without removing the retainer nut and blade assembly. DO NOT attempt to remove the retainer nut or blade assembly from the container. The In-Place Cleaning and Sanitizing procedures or a dishwasher cycle will ensure complete and thorough cleaning of your container and it’s components. If your container is damaged, please do not use. Contact Vitamix Customer Service IMMEDIATELY for assistance.

Dishwasher:

The parts are dishwasher safe. If preferred, wash the parts in warm soapy water. Rinse clean under running water, then dry.

In-Place Cleaning:

1. Fill the container half full with warm water and add a couple of drops of

dishwashing liquid.

2. Snap or push the complete 2-Part lid into the locked position.

3. Perform one of the following procedures:

• Variable Speed:

a. Press Start / Stop. b. Slowly increase variable speed to 10. c. Run the machine for 30 to 60 seconds. d. Rotate the Variable Speed dial back to Variable 1. Press Start / Stop.

• Model A3500, press the Self-Cleaning Icon (

The program will stop automatically when complete.

4. Rinse and drain all pieces.

) to select. Press Start/Stop.

To Sanitize:

1. Follow the cleaning instructions above.

2. Fill the container half full with water and 1 ½ teaspoons of liquid bleach.

3. Snap or push the complete 2-part lid into the locked position.

4. Perform one of the following procedures:

• Variable Speed:

a. Press Start / Stop. b. Slowly increase variable speed to 10. c. Run the machine for 30 to 60 seconds. d. Rotate the Variable Speed dial back to Variable 1. Press Start / Stop.

• Model A3500, press the Self-Cleaning Icon ( The program will stop automatically when complete.

) to select. Press Start/Stop.

5. Allow mixture to stand in the container for an additional 1 ½ minutes.

6. Pour bleach mixture out. Allow container to air dry. Do not rinse after sanitizing.

4

Wa r r a n t y

3-YEAR FULL WARRANTY ON SEPARATELY SOLD CONTAINER AND CONTAINER COMPONENTS

1. WHAT IS COVERED.

Vita-Mix Corporation (“Vitamix”) warrants that a container (the “Container”), lid, blade assembly and/or retainer nut (the (“Container Component”) that is purchased separately from a blender motor-base will be free from defects in material or workmanship and will withstand wear and tear from ordinary household use for 3 years from the date of purchase. Vitamix will, within 30 days of receipt of the returned product, repair the failed Container or Container Component free of charge. If, in Vitamix’s sole discretion, the failed Container or Container Component cannot be repaired, Vitamix will elect to either (A) replace the Container or Container Component free of charge or (B) refund the full purchase price to the owner, unless Vitamix receives prior written notice of the owner’s preference.

2. WHAT IS NOT COVERED.

This Warranty applies only to owners for ordinary household use. This Warranty does not cover cosmetic changes that do not aect performance, such as discoloration or the eects of the use of abrasives or cleaners or food build up. This Warranty is only valid if the Container or container in which the Container Component is installed is used in accordance with the instructions, warnings and safeguards contained in the owner’s manual.

Vitamix will not be responsible for the cost of any unauthorized warranty repairs.

REPAIR, REPLACEMENT OR REFUND OF THE PURCHASE PRICE ARE THE EXCLUSIVE REMEDIES OF PURCHASER AND THE SOLE LIABILITY OF VITAMIX UNDER THIS WARRANTY. NO EMPLOYEE OR REPRESENTATIVE OF VITAMIX IS AUTHORIZED TO MAKE ANY ADDITIONAL WARRANTY OR ANY MODIFICATION TO THIS WARRANTY WHICH MAY BE BINDING UPON VITAMIX. ACCORDINGLY, PURCHASER SHOULD NOT RELY UPON ANY ADDITIONAL STATEMENTS MADE BY ANY EMPLOYEE OR REPRESENTATIVE OF VITAMIX. IN NO EVENT, WHETHER BASED ON CONTRACT, INDEMNITY, WARRANTY, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, SHALL VITAMIX BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOSS OF PROFIT OR REVENUE.

Some states do not allow limits on warranties. In such states, the above limitations may not apply to you. Outside the U.S.A. and Canada, other warranties may apply.

3. WHAT VOIDS THIS WARRANTY.

Abuse, misuse, negligent use, alteration of the Container or Container Component or motor base, exposure to abnormal or extreme conditions, or failure to follow the operating instructions, will void this Warranty.

The Warranty is also void if repairs to the machine, Container, Container Component or any portion of the blade assembly are performed by someone other than Vitamix or an authorized Vitamix Service Provider or if any part subject to this Warranty is used in combination with a motor-base or container that is not expressly authorized by Vitamix.

5

Wa r r a n t y

4. HOW TO OBTAIN RETURN AUTHORIZATION UNDER THIS WARRANTY.

In the event the Container or Container Component needs service or repair, please call Vitamix Customer Service at 1-800-848-2649. You will be asked to provide a date of purchase and proof of purchase for any product that has not been registered with Vitamix. For product subject to this Warranty you will be provided with a return authorization number, up-to-date shipping instructions and a pre-paid return pick up label. Vitamix will pay standard shipping costs on the return of a Container or Container Component for warranty service and repair and for return shipment of the product to you after the warranty repair or replacement. Purchaser is responsible for the costs of special shipping requests.

Within the U.S.A. and Canada, this Warranty is honored directly through the Vita-Mix® Corporation.

United States Canada Vita-Mix® Corporation Vita-Mix® Corporation

8615 Usher Road 200-1701 Shepherd Street East Cleveland, Ohio 44138-2199 Windsor, Ontario N8Y 4Y5 1-800-848-2649 1-800-848-2649 service@vitamix.com service@vitamix.com

You will be deemed to have accepted the returned product “as is” upon delivery unless you notify Vitamix of any problem, including shipment damage, within 48 hours of delivery.

SPECIAL INTERNATIONAL INSTRUCTIONS

If a machine was purchased within the U.S.A. or Canada, but is currently outside the U.S.A.

or Canada, all shipping and resulting taxes and duties are at the owner’s expense.

Call +1-440-235-4840 or email service@vitamix.com for more details.

6

not e S

_____________________________________________________________

7

To see the complete line of Vitamix® products, visit vitamix.com.

Vita-Mix® Corporation 8615 Usher Road Cleveland, OH 44138-2103 U.S.A. 1-800-848-2649 / 1-440-235-4840

vitamix.com

®

Corporation. No part of this publication may be reproduced or transmitted in any form or by any

123796_Rev A 1/17
